Prepare to be impressed with this
incredibly thin and sleek 13.3-inch
diagonal notebook PC at an amazing
price.
Sleek is the word
Starting at only 3.79 lb / 1.72 kg and
only .93 inches thin, this incredibly sleek
notebook has a sophisticated aesthetic
with a durable anodized aluminum
display enclosure and palm rest. With a
16:9 LED-backlit antiglare or BrightView
HD4 display, you get improved
brightness, contrast and clarity.
Power in a small package
This notebook PC is packed with a
powerful, standard voltage or affordable
ultra-low voltage Intel®processor, 2 MP
webcam with dual-microphone array for
clear web conferencing,5strong security
features to help protect your data, and a
stylish, lightweight metal design that
redefines notebook style.
Life on the move
Integrated HP Mobile Broadband
powered by Gobi7allows you to
conveniently access the internet,
company intranet, e-mail, and mission
critical information in more places
than ever before.
HP Professional Innovations help you
focus on your business
Built to protect. Integrated,
customizable security solutions help
defend your network, your
applications, and your data.
Credential Manager for HP
ProtectTools lets you specify how the
different available security
technologies will work together to
provide increased protection against
unauthorized access.
Built to simplify. HP QuickLook 3
provides read and write capability of
email, calendar, task and contact
information in seconds at the touch of
a button, without having to boot up.9
Built to last. A durable and lightweight
metal case combines an anodized
aluminum display enclosure and a
magnesium alloy bottom case to
protect your notebook from the rigors
of daily mobile use.
Built to conserve. Choose the HP
ProBook 5310m with the BFR/PVC-
free17 option that uses materials with
lower environmental impact.
Windows®. Life without Walls™. HP recommends Windows 7.
HP ProBook 5310m Notebook PC
Thin and sleek
business notebook
design that
combines
performance and
affordability

HP ProBook 5310m Notebook PC
Windows®. Life without Walls™. HP recommends Windows 7.
Operating system
(Windows®7 will be
offered upon general
availability from
Microsoft)
Preinstalled:
Genuine Windows®7 Professional 321
Genuine Windows 7 Home Premium 321
Genuine Windows 7 Home Basic 321
Genuine Windows Vista®Business 3219
Genuine Windows Vista Home Basic 3219
Genuine Windows®XP Professional available through
downgrade rights from Windows 7 Professional1,20
Genuine Windows XP Professional available through
downgrade rights from Windows Vista Business2,19
FreeDOS
Red Flag Linux (PRC only)
Supported:
Genuine Windows 7 Enterprise 321
Genuine Windows Vista®Enterprise 3219
Certified:
SUSE Linux Enterprise Desktop 10
Processor Intel®CoreTM2 Duo3 SP9300 (2.26 GHz, 6 MB L2 cache)
Intel®Celeron3SU2300 (1.20 GHz, 1 MB L2 cache)
Chipset Mobile Intel GS45 Express Chipset ICH9M-Enhanced
Memory DDR3 SDRAM, 1333 MHz (running at 1066 MHz), one slot supporting 1024/2048/4096 MB SODIMM11
Internal Storage12 160/250/320 GB 7200 rpm SATA with HP 3D DriveGuard (supported on Windows models only);
or 80/128 GB Solid State Drive
Removable
Storage14 Optional HP External USB 2.0 CD/DVD R/RW Drive
Display 13.3-inch diagonal LED-backlit HD4(1366 x 768) (BrightView or antiglare)
Graphics18 Mobile Intel GMA 4500MHD
Audio/Visual High Definition Audio, stereo speakers, combo stereo headphone/mic jack, integrated dual-microphone array;
integrated 2 MP webcam
Wireless
support5, 6, 7,14
Optional HP un2420 EV-DO/HSPA Mobile Broadband Module (requires mobile network operator service); Intel
802.11 a/b/g/n draft 2.0; Broadcom 802.11 a/b/g/n draft 2.0, b/g; Bluetooth™ 2.1, HP Wireless Assistant
Communications13 Marvell Ethernet (10/100/1000 NIC)
Expansion slots Secure Digital slot: supports SD (Secure Digital), MMC (MultiMedia Card)
Ports and
connectors
(3) USB 2.0 ports (1 powered), DisplayPort, power connector, RJ-45/Ethernet, combo stereo headphone/mic
jack
Input device Full-sized keyboard, touchpad with scroll zone, gesture support capable
Software HP QuickLook 3,9HP QuickWeb,16 HP Softpaq Download Manager, HP Recovery Manager (Windows Vista
only), Roxio Creator 10 (requires separately purchased external optical drive),14 Microsoft® Office Ready10
Security HP ProtectTools, Device Access Manager, Enhanced Pre-Boot Security, HP Spare Key, HP Disk Sanitizer,8Drive
Encryption for HP ProtectTools, Credential Manager for HP ProtectTools, File Sanitizer for HP ProtectTools,8
Kensington Lock slot, McAfee Security Solution15
Dimensions .93 x 12.9 x 8.7 in / 23.5 x 328 x 221 mm
Weight Starting at: 3.79 lb / 1.72 kg (weight will vary by configuration)
Power 4-cell (41WHr) Lithium-Ion battery, 6-cell (62WHr) Lithium-Ion battery, 65W HP Smart AC Adapter
Expansion
Solutions14 HP USB 2.0 Docking Station, HP Essential USB Port Replicator, HP Basic Adjustable Stand
Warranty Limited 1-year and 90-day warranty options available, depending on country, 1-year limited warranty on
primary battery. Optional HP Care Pack Services are extended service contracts which go beyond your
standard warranties.
For more details visit: http://www.hp.com/go/lookuptool.

2 MP Webcam
Full-size, user-friendly
QWERTY keyboard
DisplayPort
Touchpad with
scroll zone
Black anodized brushed
aluminum finish
13.3-inch diagonal, 16:9 LED-
backlit HD4 display
HP QuickLook 39and
HP QuickWeb16 buttons
HP ProBook 5310m Notebook PC
Windows®. Life without Walls™.
HP recommends Windows 7.

HP ProBook 5310m Notebook PC
Windows®. Life without Walls™. HP recommends Windows 7.
© 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The
only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein. Bluetooth is a trademark of its proprietor and used by Hewlett-Packard Company
under license. Microsoft, Windows and Vista are trademarks of the Microsoft group of companies. Intel, Celeron and Core are
trademarks or registered trademarks of Intel Corporation or its subsidiaries in the U.S. and other countries. To learn more, visit
www.hp.com
September 2009
1. This system may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software a
n
take full advantage of Windows 7 functionality. See http://www.microsoft.com/windows/windows-7/ for details.
2. Windows Vista Business disk may be included for future upgrade if desired. To qualify for this downgrade an end user must be a
business (including governmental or educational institutions) and is expected to order at least 25 customer systems with the same
custom image.
3. Dual Core is a technology designed to improve performance of certain software products. Not all customers or software
applications will necessarily benefit from use of this technology 64-bit computing on Intel architecture requires a computer system
with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture. Processors
will not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on
your hardware and software configurations.
4. HD content required to view HD images
5. Wireless access point and Internet service is required and is not included. Availability of public wireless access points limited
6. The specifications for the 802.11n WLAN are draft specifications and are not final. If the final specifications differ from the draft
specifications, it may affect the ability of the notebook to communicate with other 802.11n WLAN devices.
7. Gobi requires a separately purchased service contract. Check with provider for availability and coverage in your area.
8. For the use cases outlined in the DOD 5220.22-M Supplement.
9. HP QuickLook 3 is accessible when the notebook is off in Windows XP, Windows Vista or Windows 7-based systems; not
supported from hibernation. Timing may vary depending on the system configuration. To enable the feature following the removal
of the battery, reboot the notebook prior to subsequent use. QuickLook 3 on HP ProBook s-series requires configuration with Intel
and DDR3 or AMD and DDR2
10. Microsoft® Office 2007 is a trial version; functionality is reduced after 60 days. The full version is sold separately
11. Up to 1 GB may not be available with 32-bit operating systems due to system resource requirements.
12. For hard drives, GB = 1 billion bytes. Up to 15 GB of system disk is reserved for the system recovery software.
13. The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
14. Sold separately or purchased as an optional feature.
15. 60 day trial period. Internet access required to receive updates. First update included. Subscription required for updates.
16. HP QuickWeb is accessible when the notebook is off in Windows XP, Windows Vista or Windows 7-based systems; not
supported from hibernation. Internet access required. Timing may vary depending on the system configuration. To enable the
feature following the removal of the battery, reboot the notebook prior to subsequent use. Not available on HP ProBook s-series or
HP Minis.
17. HP ProBook 5310m is BFR/PVC-free on notebooks including Broadcom WLAN that are non-WWAN; meeting the evolving
definition of 'BFR/PVC-free' as set forth in the "iNEMI Position Statement on the 'Definition of Low-Halogen' Electronics
(BFR/CFR/PVC-Free)’". Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source is from BFRs] and < 1000 ppm
(0.1%) of chlorine [if the Cl source is from CFRs or PVC or PVC copolymers]. Power supply and power cords are not BFR/PVC-free.
Service parts after purchase may not be BFR/PVC-free. Configuration is not available until 9/27/09.
18. Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to video
performance is not available for other use by programs
19. Certain Windows Vista product features require advanced or additional hardware. See
www.microsoft.com/windowsvista/getready/hardwarereqs.mspx. Windows Vista Upgrade Advisor can help you determine
which features of Windows Vista will run on your computer. To download the tool, visit www.windowsvista.com/upgradeadvisor.
20. Windows 7 Business disk may be included for future upgrade if desired. To qualify for this downgrade an end user must be a
business (including governmental or educational institutions) and is expected to order at least 25 customer systems with the same
custom image.
