CHASSIS

SERVICE MANUAL

SPECIFICATIONS

G1W

N.Hemisphere Model

Chassis No. SCC-L34E-A

24-inch Color Monitor

GDM-FW9012

HP

()

CRT 0.23 – 0.27 mm aperture grille pitch

24 inches measured diagonally

90-degree deflection

FD Trinitron

Viewable image size Approx. 482.1 ×308.2 mm (w/h)

(19 ×12

1

/

4

inches)

22.5" viewing image

Resolution Maximum (16:10)

Horizontal: 2304 dots

Vertical: 1440 lines

Maximum (4:3)

Horizontal: 2048 dots

Vertical: 1536 lines

Recommended (16:10)

Horizontal: 1920 dots

Vertical: 1200 lines

Input signal levels Video signal

Analog RGB: 0.700 Vp-p

(positive), 75 Ω

SYNC signal

H/V separate or composite sync:

TTL 2 k

Ω

, Polarity free

Sync on Green: 0.3 Vp-p

(negative)

Standard image area 16:10

Approx. 474

×

296 mm (w/h)

(18

3

/

4

×

11

3

/

4

inches)

4:3 Approx. 395

×

296 mm (w/h)

(15

5

/

8

×

11

3

/

4

inches)

5:4 Approx. 370

×

296 mm (w/h)

(14

5

/

8

×

11

3

/

4

inches)

()

Deflection frequency* Horizontal: 30 to 121 kHz

Vertical: 48 to 160 Hz

AC input voltage/current 100 to 240 V, 50/60 Hz, 2.2 – 1.2A

Power consumption Approx.160W(withnoUSBdevices

connected)

Operating temperature 10˚C to 40˚C

Dimensions

Approx. 571.5

×

500

×522.5

mm(w/h/

d)

(22

1

/

2

×

19

3

/

4

×

20

5

/

8

inches)

Mass Approx. 42 kg (92 lb 10 oz)

Plug and Play DDC1/DDC2B/DDC2Bi, GTF**

Supplied accessories • Power cord (1)

• Video signal cable (1)

• USB cable (1)

• Exclusive Power Mac G3/G4

adapter (1)

• Warranty card (1)

• Notes on cleaning the screen’s

surface (1)

• This instruction manual (1)

* Recommended horizontal and vertical timing condition

• Horizontal sync width duty should be more than 4.8% of

total horizontal time or 0.8 µs, whichever is larger.

• Horizontal blanking width should be more than 2.3 µsec.

• Vertical blanking width should be more than 450 µsec.

** If the input signal is Generalized Timing Formula (GTF)

compliant, the GTF feature of the monitor will automatically

provide an optimal image for the screen.

Design and specifications are subject to change without notice.

GDM-FW9012(E) 3-1

SECTION 3

ADJUSTMENTS

Note: Hand degauss must be used on stand-by or power-off condition.

This model has an automatic earth magnetism correction function by using an earth magnetism sensor and a LCC coil. When

using a hand degauss while monitor (LCC coil) is being operated, it sometimes gets magnetized, and the system may not

work properly as a result.

•Landing Rough Adjustment

1. Enter the full white signal. (or the full black dots signal).

2. Adjust the contrast to the maximum.

3. Make the screen monogreen.

Note:Off the outputs from R ch and B ch of SG.

4. Reverse the DY, and adjust coarsely the purity magnet so that

a green raster positions in the center of screen.

5. Adjust the tilt of DY, and fix lightly with a clamp.

Note:“TILT” = “128”.

•Landing Fine Adjustment

1. Put the set inside the Helmholtz coil. (“LCC SW” = “12”)

2. Input the single green signal and set the “CONTRAST” =

“255”.

Note:After the W/B adjustment with 9300K, measure an average

of ΣIk when a full white signal is entered in the CONT

MAX/BRT CENT status. Then make adjustment so that the

specified screen can be attained after aging for 2 hours with

Ik equivalent to 30% of the average value.

3. Demagnetize the metal part of the chassis with the hand degausser and coil

degausser, and the CRT surface with the hand degausser.

Input AC 230V to AC IN, turn on and off the power to perform auto

degaussing. (Perform auto degaussing by setting “FUNCTION SW” = 1.

Return to the original value after use.)

Demagnetize the CRT surface with the hand degausser again.

Note:

(1) Hand degauss must be used on stand-by or power-off condition.

This model has an automatic earth magnetism correction function by using

an earth magnetism sensor and a LCC coil. When using a hand degauss while

monitor (LCC coil) is being operated, it sometimes gets magnetized, and the

system may not work properly as a result.

(2) Adjust in a non-magnetic field.

(3) If adjusting in a magnetic fields, add the shift from the non-magnetic field in

your estimation.

4. Attach the wobbling coil to the designated part of the CRT neck.

5. Attach the sensor of the landing adjustment unit on the CRT surface.

GDM-FW9012(E) 3-2

6. Adjust the DY position and purity, and the DY tilt, and landing

of the center and 4 corners with the landing checker.

After adjustment, set “LCC SW” to “13”.

•Write terrestrial magnetism sensor reading VX and VY to

“LCC VX” and LCC VY” respectively. Adjust the landing by

moving “LCC NS”, “LCC LT”, “LCC LB”, “LCC RT” and

“LCC RB”. However, the register adjustment must be limited

within the following range.

“LCC NS” 128 ±45

“LCC LT”, “LCC LB”, “LCC RT”, “LCC RB” 128 ±40

Save the service data.

* Adjustment and measurement should be made at the points one

inch inside the fluorescent screen.

7. Tighten DY screw.

Note:Torque 22 ±2 kg.cm (2.2 ±0.2 Nm) auto degauss it.

8. For the up/down swing, swing the DY and insert a wedge so

that the up and down pins are equal at the top and bottom.

Adjust the H.TRP VR of DY so that the horizontal trapezoid is

equal at the left and right. Insert the wedge firmly so that the DY

does not shake.

9. Check the landing of each corner, and if it does not satisfy the

specification, adjust the landing of four corners using “LCC

LT“, “LCC LB”, “LCC RT” and “LCC RB”.

However, the register adjustment must be limited within the

following range.

“LCC NS” 128 ±15

Adjust so that the green is within the

specification given right.

4 corner adjust target : within ±1

The red and blue must be within the

specification given right with respect to

the green.

A difference between red and blue must

be within the specification given right.

“LCC LT”, “LCC LB”, “LCC RT”, “LCC RB” 128 ±45

After adjustment, save the service data.

10. Remove the sensor and wobbling coil.

11. Switch the signal to R.G.B., and check that each color is pure.

12. Check that the DY is not tilting, and fix the purity Mg with a white pen. Fix

wedges with RTV.

±6 ±6 ±6

0 ±30±7.5 0 ±3

10 10 10

10 7 10

10 10 10

(µm)

GDM-FW9012(E) 3-3

Connect the communication cable of the computer to the connector located on the D board. Run the service software and then follow the instruction.

IBM AT Computer

as a Jig

*The parts above (1and 2) are necessary for DAS adjustment.

To BUS CONNECTOR

1-690-391-21

Cord,Connection

D-sub

(9 pin [female]) mini Din

(8 pin)

1A-1500-819-A

Interface Unit

2

Connector

Attachment

Box Unit

4 pin

•Convergence Rough Adjustment

(1) Receive an image of the white crosshatch signals (white lines

on black).

(2) Place the protrusions of the 6-fold poles magnet attached to

the CRT neck upon each other.

(3) Make rough adjustment of the H and V direction convergence

by using 4-fold poles magnet.

H-TRP

YBH

TLH

TLV

APH

XBV

YCH

XCV

Purity

4-pole magnet

6-pole magnet

2-pole magnet

* Set so that the protruding parts of the 2

magnet rings agree with each other.

GDM-FW9012(E) 3-4

•Convergence Specification

XBVXCV

B

R

B

R

B

R

BBR

TLV

TLH

YBHYCH

R B

B

C

AA0.24 mm

70kHz 70kHz >

0.24 mm

B0.24 mm

C0.28 mm

0.28 mm

0.32 mm

V

fH

•White Balance Adjustment Specification

1. 9300K

x = 0.283 ±0.015

y = 0.298 ±0.015

(All White)

2. 6500K

x = 0.313 ±0.015

y = 0.329 ±0.015

(All White)

3. 5000K

x = 0.346 ±0.015

y = 0.359 ±0.015

(All White)

•Vertical and Horizontal Position and Size

Specification

B

a

a 3.5 mm

b 3.5 mm

a

b

A

MODE

A

B

16 : 9

474

16 : 10

266

296

MODE

A

B

4 : 3

395

296

5 : 4

370

296

•Focus adjustment

Adjust the focus volume 1 and 2 for the optimum focus.

Focus 1

Focus 2

FBT

GDM-FW9012(E) 4-1

SECTION 4

DIAGRAMS

4-1. BLOCK DIAGRAMS

18

21

19

17

16

20

12

7

6

2

4

13

14

8

9

10

DDC +5V 1

HOST GND 1

DDC SCL 1

VS1

HS/CS1

DDC SDA 1

INPUT SEL

G. SYNC DET

SYNC ON G

CLP

C. BLK

SCL

SDA

H. SYNC

V. SYNC

HFBP

B

TO N BOARD

CN001

5

3

1

35

32

29

23

21

19

17 26

27

28

11

9

7

BIN2

GIN2

RIN2

OSD R

OSD G

OSD B

OSD BLK

ROUT

GOUT

BOUT

41

38

33

2

8

12

2

6

11

ROUT

GOUT

BOUT

4

6

14

ROUT

GOUT

BOUT

RIN

GIN

BIN

RIN

GIN

BIN

R DET IN

G DET IN

B DET IN

V-DET D/A4

D/A3

D/A2

CLP

C. BLK

SCL

SDA

BIN1

GIN1

RIN1

18

14

25

21

30

22

23

INPUT SW

G. DET

SYNC SEP OUT D/A5

CLP

BLK

SCL

SDA

2

4

6

BIN2

GIN2

RIN2

CN402

IC407

CN403

CN401

HD15

5

4

3

2

1

10

15

9

14

8

13

7

12

6

11

INPUT1(HD15)

VCC KICK

Q402

IC404

OSD

5V

IC401

INPUT SELECT IC402

RGB DRIVE IC403

RGB AMP

4 9 13 1

18 19 20 21 15 16 17

10 11 12

17

6

514

11

12

7

5

3

26

25

24

4

3

5

6

7

13

14

15

ROUT

GOUT

BOUT

GND

RCI

GCI

BCI

PWM1

XT1

XT0

H. SYNC

V. SYNC

HFBP

SCL

SDA SCL

SDA

VS

Hfly

RIN

GIN

BIN

IC406

CUTOFF AMP

X401

8MHz

G2 G2 CONT

Q406, 407, 410

IC405 (1/2)

+

-

ROUT

GOUT

BOUT

FBLK

AV

PWM2

PWM3

PWM4

B BKG

G BKG

R BKG

BUFFER

Q101,

Q201,

Q301

9

1

2

4

6

8

HEATER

STBY+5V

1W+5V

+80V

+220V

+12V

5V

5V-2

+80V

+220V

+12V

PS401 1A

CN405

G2

1G2

CN406

5

3

1

7

KR

KG

KB

HEATER+

CN407

5

3

1

7

KR

KG

KB

HEATER+

FV

FC

HV

CN408 V901

PICTURE TUBE

8

E

TO G BOARD

CN652

A

(VIDEO AMP, RGB OUT)

RIK

GIK

BIK

DRIFT CORRECT

Q401

HD HV

C

TO N BOARD

CN010

16

18

20

24

25

22

23

14

12

10

9

8

7

6

5

4

3

2

1

STBY+5V

RXD

TXD

+15V

-15V

HDF

VDF

ABL

HV OUT SW

HV DET

S0

H CENT

S6

HSPBAL

HLINBAL

H SIZE

H SHAPE

HDF

VDF

ABL DET

HV

HV DET

S0

H CENT

S6

HSPBAL

HLIN

H SIZE

HSP

CN504

H DRV

Q502, 503

AMP

Q910

H OUT

Q509

H OUT, BUFF

Q515, 520

T501

HDT

H CENT

Q514

IC501

PIN CONTROL

IC504

+12V REG

IC503

AMP

IC502

H CENT OUT

T502

HCT

+12V

T503

HST

L505

HOC

OUT

HFBP

TH DET

VDF

V RET

V SHAPE V+

V— V—

V+

HDF

S0-4, S6, S7

S5

HV DET

+220V(+B)

+220V

(+B)

+220V

(+B) +220V

(+B)

+12V

PIN OUT

Q508

H DRV

Q701-705

S CAP CHANGE

Q501, 506, 507,

510-513, 517,

525,527

HL OUT

Q516, 518

RELAY DRV

Q519

V DRV

Q706, 707

T701

DFT

HV DET

Q907, 908

HV DRV

Q903, 904 HV OUT

Q906

SW

Q902,909 HV OUT

Q901

HV REG SW

Q905 T901

HRC

T902 FBT HV HV

FC FC

RV901

HV ADJ

FV FV

5

3

1

24

45

81

36

25

21

3

91

5

14

3

6

7

8

6

14

13

1G2

CN506

D

(DEFLECTION)

D

TO N BOARD

CN011

20

18

16

14

12

10

25

24

23

22

21

19

8

6

3

1

4

17

STBY+5V

1W+5V

ECO SW

PWR SW

DGUS SW

HTR SW

TH DET

S4

S3

S5

S2

S1

HFBP

HD

V RET

VSHAPE

+12V

S7

TH DET

S4

S3

S5

S2

S1

HFBP

HD

V RET

VSHAPE

S7

CN505

2

3

4

STBY+5V

RXD

TXD

CN503

ECS

2

4

6

+15V

-15V

+80V

CN501

CN508

F

TO G BOARD

CN653

1

2

3

4

5

6

STBY+5V

1W+5V

ECO SW

PWR SW

DGUS SW

HTR SW

CN502

+80V

—15V

+15V

H

TO G BOARD

CN650

5

4

3

2

1

+220V

H CENT L

H CENT N

H CENT H

HDIN

PWMOUT

REFIN

O2

O3 HLIN

O4

-4

+1

O1

ABL

ABL DET

HSP

H SIZE

S5-1

-3 -2

H CENT H

H CENT L

H CENT N

H CENT

HSPBAL

VCC

VEE

+VNH

-VIN

G

TO G BOARD

CN654

PIN DRV

Q504, 505

GAIN SW

Q526

Q523

PIN AMP

Q524

TH DET

Q521, 522

2

1

6

5

17

14

16

15

11

15

14

57

112

T505

HLC

41

23

5

2

14

10

12

13 3

11

5

4

2

3

5

PWMOUT

+

HVD

ERR OUT

-

HDIN

DELAY

IC901

HV CONTROL

ABL

OUT VCC

-+

OUT

IC701

V DY OUT

RY501

V. DY

H. DY

XS5

2

3

9

10

5

6

V. DY C

V. DY H

H. DY H

H. DY C

CN509

XS5

B-SS3536<AEP> -BD1-24

S5-1

VDD

A

TO N BOARD

CN002

CONNECTOR PANEL

INPUT2(BNC)

HDVD RGB

5BNC

IN OUT +12V

1

4

GDM-FW9012(E) 4-2

1

3AC L OUT

AC L IN

CN891

1

3

AC L OUT

AC L IN

CN603 TH601

D610

AC RECT D613

IC610

PFI

D620

RY602

1

3

AC L

AC N

CN602 F601

6.3A T601

AC INLET

RY603

1

4

DGC

CN601

POWER

S891

J

(POWER SW)

G

(POWER SUPPLY)

DGC

12

43

L610

AFC

IC620

SW REG CONTROL

T620 PIT

PS650

2.0A

D654

H CENT L

D653

H CENT H

IC654

+12V REG

PH610

D650

+220V RECT

D652

+15/-15V RECT

D651

+80V RECT

D655

+80V RECT

VCC

L SEN

V SENSE

VC1

DRAIN

AC SEN

CATHODE

OCP

VG(H)

VG(L)

F/B

GND

8

2

73

6

2

12

16

6

8

5

3

42

1

4

2

1

7

91

8

5

3

10

7

6

8

16

13

15

14

13

11

12

10

18

17

41

1

10 13

VCC SW

Q610

D680

6.5V RECT

D631

VCC RECT

D632

D633

T630

SRT

PROTECT

Q652,653,667

IC650

+220V SHUNT REG 1

2

3

6

7

H CENT H

H CENT N

H CENT L

+220V

CN654

6

4

2

+80V

15V

+15V

CN653

1

3

+15V

-15V

CN655

4

6

8

9

1

2

+80V

+220V

+12V

HEATER

SYBY+5V

1W 5V

CN652

1

2

3

6

4

5

STBY+5V

1W+5V

ECO SW

HTR SW

PWR SW

DGUS SW

CN650

VCC SW

Q631-633

HEATER SW

Q671

RELAY DRV

Q691

IC630

PWM

CONTROL

REG SW

Q630

IC653

1W+5V REG

IC652

STBY+5V REG

IC651

HEATER REG

VCC OUT

CTL

VCC OUT

CTL

VADJ

1

2

4

1

4

1

5

3

IN OUT

PH630

IC680

3

41

2

PH620

D664

4

32

1

G

TO D BOARD

CN508

F

E

TO D BOARD

CN501

K

TO S BOARD

CN3003

TO A BOARD

CN405

H

TO D BOARD

CN502

L

TO US BOARD

CN2601

1

2USB 7V

USB 7V

CN651

B-SS3536<AEP>-BD3-24

SW

Q613 POWER CONT

Q611,612

REG SW(L)

Q620

REG SW(H)

Q621

GDM-FW9012(E) 4-3

4

3

2

6

5

1

20

18

16

10

15

9

8

14

13

12

46

47

104

103

29

53

51

108

69

41

42

52

156

152

157

153

149

140

148

131

56

DDC+5V 1

DDC SCL 1

DDC SDA 1

HS/CS 1

VS 1

HOST GND 1

CLP

C. BLK

SYNC ON G

INPUT SEL

G. SYNC DET

SCL

SDA

H. SYNC

V. SYNC

HFBP

D SCL1

D SDA1

HS/CS1

VS1

HOST GND1

CLP

C BLK

SONG

INPUT SEL

SCL2

SDA2

H SYNC

LCC LB

LCC LT

LCC RB

LCC RT

LCC NS

ROTATION

H CONV

V CONV

LCC LB

LCC LT

LCC RB

LCC RT

LCC NS

ROTATION

H CONV

V CONV

83

84

39

38

40

33

34

VX

VY

SDA1

SCL1

EEPWC

WDP

RESET

3

4

76

13

77

19

8

OFF DET

ECO

6

89

71

128

86

138

126

144

136

133

45

44

HV OUT SW

ABL DET

HDF0

VDF

HV DET

H CENT

HSP BAL

HL IN BAL

H SIZE

HSP

TXD

RXD

LED0

LED1

KEYDET

INPUT SW

ENV

LED0

LED1

KEYDET

INPUT SW

ENV

59

58

60

56

55

88

15, 94

95

93

92

25

35

34

33

29

27

13

9

5

8

4

30

S4

S3

S5

S6

S1

TH DET

PWR SW/PRT DET

DGS

HTR

V RET

AFC FIL

VSHPLVL

DV SHAPE

VDC

H PHASE

H FREQ

HPLL

AFC SW

VSH

FBP

V SAW RST

HS

HD DUTY

REG9V

HD

V SHAPE

5

18

124

99

120

117

122

114

111

90

96

67

109

66

98

HD SW

P45/D5

MOIRE CONT

MOIRE PLS

VSH PL VL

DV SHAPE

VDC

H PHASE

HF REQ

HPLL

AFC SW

VSH

HFBP

V SAW RST

HS OUT

63 XTB

54

61

9

10

11

S0

S6

D RES

D CHG

D MUTE

D RES

D CHG

D MUTE

VSP

HD

ECO SW

VSOSD

HFBP

VSOSD

64

25 XTD

SC OUT

2

1

4

106

107

31

HS/CS 2

VS 2

HOST GND 2

HS/CS2

VS2

HOST GND2

17

16

12

14

18

20

22

23

24

25

6

8

1

2

3

4

10

19

21

HV OUT SW

ABL

HDF

VDF

HV DET

H CENT

HSP BAL

HL IN BAL

H SIZE

H SHAPE

TXD

RXD

+15V

-15V

STBY+5V

S0

S6

2

3

4

5

7

1

12

14

16

23

10

18

20

25

22

6

8

9

S4

S3

S5

S2

S1

TH DET

PWR SW

DGUS SW

HTR SW

VRET

ECO SW

HFBP

HD

V SHAPE

+12V

STBY+5V

1W+5V

S7

CN002

IC001

CPU/DSP STBY+5V

DDE

D015

CN001

CN010

IC006

TEMP

Q010

Q012

Nµ-COM, V.CONV, H. CONV,

LCC, GEO MAGNETIC SENSOR

+

-

A

B

C

D

CN011

ECO SW

HFBP

HD

VSP

+12V

STBY+5V

1W+5V

+15V

STBY+5V

SOG DET

VS OSD

HFBP

D SCL

D SDA

HS1

VC1

HC2

VC2

VS1

SDA1

SCL1

DDE

VCLK

SCL

SDA

VS1

SCL1

SDA1

VCC

X001

24.756MHz

TO D BOARD

CN505

TO D BOARD

CN504

TO A BOARD

CN403

TO CONNECTOR

PANEL

75

7

5

6

+12V

765

6

78

8

+

—

+

—

+

—

+

—

+

—

+

—

+

—

+

—3

4

1

2

7

8

5

6

LCC-LB (+)

LCC-LB (-)

LCC-LT (+)

LCC-LT (-)

LCC-RB (+)

LCC-RB (-)

LCC-RT (+)

LCC-RT (-)

1

2LCC-NS (+)

LCC-NS (-)

B-SS3536<AEP>-BD2-24

CN5002

IC5301 (2/2)

STBY+5V

4

32

IC5301 (1/2)

6

78

IC5101 (2/2)

4

32

IC5101 (1/2)

6

78

IC5201 (2/2)

4

32

IC5201 (1/2)

6

78

IC5401 (2/2)

4

32

IC5401 (1/2)

CN5003

ITO H BOARD

CN801

LCC-LB

LCC-LT

LCC-RB

LCC-RT

5

6

3

4

1

2

ROTATION (+)

ROTATION (-)

H CONV (+)

H CONV (-)

V CONV (+)

V CONV (-)

CN5001

6

7

1

2

3

4

8

1W+5V

STBY+5V

LED0

LED1

KEY DET

INPUT SW

ENV DRI

LED0

LED1

KEY DET

INPUT SW

ENV

STBY+5V

HFBP

VS OSD

D CHG

D RES

D MUTE

D SCL

D SDA

CN007

JTO S BOARD

CN3001

9

7

6

5

4

3

2

1

STBY+5V

HFBP

V SAW RST

D CON CH

D CON RES

D CON MUTE

SCL

SDA

CN003

ROTATION

LCC-NS

H. CONV

V. CONV

1CLR

2CLR

1CK

2CK

HC1

VC1

HC2

VC2

1Q

2Q

P41/D1 14

GS5001

GEOSENSOR

IC003

EEP ROM

SW

Q008

HD SW

Q011

CURRENT MILLER

Q001-003

ECO SW

Q007

ACTIVE OFF DET

Q004-006 IC004

ECO DET

SOG DET

IC005

ECO DET

IC010

H. V. OSC, AFC,

H. DRV, V. SHAPE

+15V

IC002

WDT

5

6

7

SDA

SCL

WC

3

8CK

RESET

IC011

EEP ROM

1W+5V

STBY+5V

15

6

21

14

1

13

5

9

3

11

1

13

5

9

3

11

1CLR

2CLR

1CK

2CK

1Q

2Q

GDM-FW9012(E) 4-4

S

(CONVERGENCE CONTROL)

CN3003

1

3

+15V

-15V

+15V

-15V

K

TO G BOARD

CN655

CN3001

1

3

4

6

8

9

5

7

STBY+5V

HFBP

V SAW RST

D CON RES

SCL

SDA

ROM WC

D CON MUTE

J

TO N BOARD

CN003

42

43

47

34

91

92

93

96

95

798

99

54

36

37

IC3001

DIGITAL CONV CONTROL

SDA

SCL

WC

+3.3V

STBY+5V

IC3005

EEP ROM

IC3006

RESET

STBY +5V

IC3004

+3.3V REG

1

6

IC3002

CONV OUT

6

1

4

5

2

3

10

+3.3V

2

3

5

4

10

V OUT2

V OUT1

V OUT2

V IN+2

V IN-2

V IN+1

V IN -1

MUTE

V IN-1

V IN+1

V IN-2

V IN+2

MUTE

HS

VS

CLR

SCL 0

SDA 0

U OUT1

IR REF1

U OUT3

U OUT2

U OUT0

IR REF0

SDA 1

SCL1

IC3003

CONV OUT

1

2

3

4

5

6

7

8

HMC-

HMC+

VMC-

VMC+

H AMP-

H AMP+

V AMP-

V AMP+

CN3002

IN OUT

B-SS3536<AEP>-BD6-24

MUTE SW

Q3001-Q3005

GDM-FW9012(E) 4-5

H

(USER CONTROL)

LED DRV

Q801, 802

LED DRV

Q803, 804

6

7

1

2

4

3

8

1W+5V

STBY+5V

LED0

LED1

INPUT SW

KEY DET

ENV DRI

1W+5V

STBY+5V

S811

CN801

D801

GR

TH801

S801

TACTILE SW

I

TO N BOARD

CN007

S812, S813

FUNCTION KEY

POWER

INPUT1INPUT2

RESET ASC

BRT+

BRT-

CONT

-

CONT

+

B-SS3536<AEP>-BD5-24

POWER SW

Q2601

6.5V

IC2602

POWER DISTRIBUTION SW

IC2603

POWER DISTRIBUTION SW

POWER SW

Q2602

POWER SW

Q2603

POWER SW

Q2604

1

2

3

V BUS

D-

D+

CN2901

41

40

37

42

43

4

8

1

5

15

16

11

12

4

8

1

5

15

16

11

12

31

32

10

11

12

3

7

3

7

13

35

36

7

6

25

24

3

2

4

5

I

VC O

G

DP1

DM1

DM0

DP0

DM2

DP2

DP3

DM3

DM4

DP4

IC2601

5V-REG

OUT

VC

G

IC2902

RESET

X2901

12MHz

5V

IC2901

USB CONT

5V

6.5V

3

2

1

D+1

D-1

V BUS1

CN2902

D+3

D-3

V BUS3

CN2904

1

2

3

2

1

2

3

OVR-1

OVR-2

POW-1

POW-2

POW-3

POW-4

OVR-3

OVR-4

V BUS2

D-2

D+2

CN2903

V BUS4

D-4

D+4

CN2905

B-SS3536<AEP>-BD4-24

US (USB CONTROL)

RST

XIN

XOUT

6.5V

CN2601

1

2

V IN1

V IN2

FLG1

FLG2

VC1

VC2

VOUT1

VOUT2

V IN1

V IN2

FLG1

FLG2

VC1

VC2

VOUT1

VOUT2

6.5V

L

TO G BOARD

CN891

GDM-FW9012(E) 4-6

4-2. FRAME SCHEMATIC DIAGRAM

1

2

3

4

5

6

1

2

3

4

5

6

7

8

9

10

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

4

1

2

3

4

5

6

7

8

9

10

11

1

2

3

4

5

6

7

8

9

1

2

3

1

2

3

1

2

3

1

2

3

4

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

1

2

3

4

5

6

8

7

6

5

4

3

2

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

211

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

1

2

H

KBKG

KRG1

G2 GM

G4

RCV

HV

2

1

2

3

4

5

6

1

2

1

2

3

4

5

6

1

2

3

4

5

6

7

1

2

3

4

5

6

7

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

4

5

6

7

8

CN405

CN406

CN407 CN408

CN506

CN501

CN508

CN502

CN503

CN509

CN507

CN5001

CN650

CN653

CN601

CN604

CN603

CN602

CN891

CN652

CN010

CN011

CN401

CN002

CN007

CN403

CN001

CN402

CN504

CN505

CN5002

CN5003

9P

WHT-L

:S-MICRO

2P

WHT

:VH

8P 8P

2P

WHT

:VH

6P

WHT

:S-MICRO

10P

WHT

:S-MICRO

7P

WHT

:S-MICRO

4P

WHT

10P

:VH

1P

6P

WHT

:S-MICRO

7P

WHT

:S-MICRO

6P

WHT

:S-MICRO

4P

WHT

:VH

1P

3P

WHT

:VH

3P

WHT

:VH

9P

WHT

:S-MICRO

25P

:FFC/FPC

25P

:FFC/FPC

HD15D-SUB

8P

WHT

:S-MICRO

11P

:FPC

CN801

11P

:FPC

21P

L-FPC

21P

:FFC

6P

WHT

:S-MICRO

25P

8P

YEL

:S-MICRO

2P

WHT

:S-MICRO

FASTEN

V.DY

H.DY

FV

FC

HV

ECS

FV

FC

G2

GND

G2

GND

LCC-LT

LCC-LB

LCC-RT

LCC-RB

LCC-NS

H.CONV

V.CONV

DGC

+220V

N.C

+80V

GND

+12V

STBY+5V

HEATER

CLP

GND

C.BLK

GND

ABL

G2

N.C

KB

GND

KG

GND

KR

GND

HEATER+

GND

KB

GND

KG

GND

KR

GND

HEATER+

GND

STBY+5V

GND

LED0

LED1

B IN 2

G GND 2

G IN 2

R GND 2

R IN 2

N.C

B GND 2

ROTATION

-15V

GND

N.C

9 GND

10 GND

+220V

N.C

HTR SW

+80V

+15V

GND

STBY+5V

1W+5V

ECO SW

PWR SW

DGUS SW

STBY+5V

RXD

TXD

GND

+220V

H.DY H

H.DY C

NC

V.DY H

V.DY C

GND

NC

GND

CHASSIS GND

N.C

G2

1W+5V

GND

STBY+5V

N.C

AC L

AC N

PWR SW

DGUS SW

HTR SW

DGC

N.C

DGC

GND

+15V

GND

-15V

+80V

+220V

N.C

+80V

GND

+12V

HEATER

STBY+5V

AC L OUT

N.C

AC L IN

AC L OUT

N.C

AC L IN

LED0

LED1

GND

10 GND

11 GND

STBY+5V

1W+5V

NC

HOST GND 2 (NC)

HS/CS2

VS2

GND

GND (NC)

GND

1W+5V

GND

SCL

SDA

V.SYNC

H.SYNC

12345

6789

10

1112131415

LCC-LT(+)

LCC-LT(-)

LCC-LB(+)

LCC-LB(-)

LCC-RT(+)

LCC-RT(-)

LCC-RB(+)

LCC-RB(-)

LCC-NS(+)

LCC-NS(-)

V CONV(+)

V CONV(-)

H CONV(+)

H CONV(-)

ROTATION(+)

ROTATION(-)

+15V

-15V

GND

HV DET

ABL

TH DET

GND

HSHAPE

HSIZE

TXD

RXD

GND

SH DET

HDF

VDF

GND

HCENT

STBY+5V

1W+5V

HV OUT SW

GND

S0

S1

S2

S3

S4

S5

S6

S7

PWR SW

DGUS SW

HTR SW

GND

HFBP

HD

GND

VSHAPE

GND

VRET

GND

ECO_SW

STBY+5V

HLINBAL

HSPBAL

TH DET

1W+5V

GND

S1

S2

S3

S4

S5

S7

PWR SW

DGUS SW

HTR SW

GND

HFBP

HD

GND

VSHAPE

GND

VRET

GND

ECO_SW

STBY+5V

+15V

-15V

GND

HV DET

ABL

GND

HSHAPE

HSIZE

TXD

RXD

GND

SH DET

HDF

VDF

GND

HCENT

STBY+5V

HV OUT SW

S0

S6

HLINBAL

HSPBAL

N.C

HS/CS 1

VS 1

GND

DDC+5V 1

DDCSCL 1

DDCSDA 1

HOSTGND 1

N.C

ECO SW

CLP

GND

C.BLK

GND

ABL

GND

SCL

SDA

V.SYNC

H.SYNC

HS/CS 1

VS 1

GND

DDC+5V 1

DDCSCL 1

DDCSDA 1

HOSTGND 1

INPUT_SEL

SYNC_ON_G

G.SYNC_DET

HFBP

INPUT_SEL

SYNC_ON_G

G.SYNC_DET

INPUT_SW

KEY_DET

ENV_DRI

KEY_DET

INPUT_SW

ENV_DRI

HFBP


TUBE

C BLOCK

(CRT SOCKET)

A

D

(DEFLECTION)

H CENT H

H CENT N

H CENT L

POWER

J

(POWER SW)

G

VIDEO AMP,

RGB OUT

1W+5V

1W 5V

POWER

SUPPLY

S

CONVERGENCE

CONTROL

(USER CONTROL)

H(H1)(H2)

N

V.CONV,H.CONV,LCC,

GEO MAGNETIC SENSOR

+12V

µ-COM,

FBT

+12V

B-SS3536<AEP>-KESSENZU-24

CONNECTOR PANEL

HDVD RGB

INPUT2(BNC)

5BNC

INPUT1(HD15)

1

2

3

4

5

4

3

2

1

CN651

CN2601 4P

5P

USB 7V

GND

USB 7V

6.5V

GND

6.5V

1

GND

(USB CONTROL)

US

WHT

:S-MICRO

1

2RED

3 GREEN

GND

1

2

CN802

2P

BLK

:S-MICR0

CN803 CN804

GND

RED

GREEN

GND 3

2

1

STBY+5V

GND

HFBP

V SAW RST

D CON CHG

D CON RES

D CON MUTE

SCL

SDA

CN3001

FFC-L



CN3002

8P

WHT-L

:S-MICRO

CN3003

3P

WHT-L

:S-MICRO

CN655

3P

WHT

:S-MICRO

CN654

10P

WHT

:S-MICRO

CN605

1P

CN003

9P

:FFC

9

8

7

6

5

4

3

2

1

STBY+5V

GND

HFBP

V SAW RST

ROMWC

D CON RES

D CON MUTE

SCL

SDA

HMC-

HMC+

VMC-

VMC+

H AMP-

H AMP+

V AMP-

V AMP+

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8



+15V

GND

-15V

1

2

3

+15V

GND

-15V

1

2

3

H CENT H

H CENT N

H CENT L

N.C

+220V

N.C

GND

GND

1

2

3

4

5

6

7

8

9

10

HMC

VMC

H AMP

V AMP

GDM-FW9012(E) 4-8

Note:

•All capacitors are in µF unless otherwise noted. (pF: µµF)

Capacitors without voltage indication are all 50 V.

•Indication of resistance, which does not have one for rating electrical power, is as follows.

Pitch: 5 mm

Rating electrical power 1/4 W (CHIP : 1/10 W)

• All resistors are in ohms.

• : nonflammable resistor.

• : fusible resistor.

•T :internal component.

• : panel designation, and adjustment for repair.

• All variable and adjustable resistors have characteristic curve B, unless otherwise noted.

• : earth-ground.

• : earth-chassis.

• The components identified by [in this basic schematic diagram have been carefully factory-selected for each

set in order to satisfy regulations regarding X-ray radiation.

Should replacement be required, replace only with the value originally used.

• When replacing components identified by ], make the necessary adjustments indicated. (See page 2-1)

• When replacing the part in below table, be sure to perform the related adjustment.

• All voltages are in V.

• Readings are taken with a 10 MΩdigital multimeter.

• Readings are taken with a color-bar signal input.

• Voltage variations may be noted due to normal production tolerances.

•*: Can not be measured.

• Circled numbers are waveform references.

• : B + bus.

• : B – bus.

4-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS

Note: The components identified by shading and

mark !are critical for safety. Replace only

with part number specified.

Note: Les composants identifiés par un tramé et

une marque !sont critiques pour la

sécurité. Ne les remplacer que par une pièce

portant le numéro spécifié.

•Divided circuit diagram

One sheet of D board circuit diagram is divided into three sheets,

each having the code D-ato D-c.For example, the destination

ab1 on the code D-asheet is connected to ab1 on the D-bsheet.

a b 1

Ref. No.

Circuit diagram division code

GDM-FW9012(E) 4-9

G

D

S

2

3

4

5

6

7

8

9

0

qa

qs

qf

qh

–

1

G

D

S

G

SS

D

G

D

Ver.1.6

Transistor

(FET)

Transistor

Discrete semiconductot

(Chip semiconductors that are not actually used are included.)

Diode

Source

Anode Anode

(NC)

Cathode

Anode

Cathode

Common

Cathode Cathode

Common

Cathode Cathode

Common

Cathode

Anode

Base Emitter

Collector

Base Emitter

Collector

Drain

Gate

Drain

Device Printed symbol Terminal name Circuit

Terminal name of semiconductors in silk screen

printed circuit ( )

Anode

Anode Cathode

Anode Anode

Cathode

qd

Transistor

(FET)

Transistor

(FET)

qg

Emitter

Collector

Base

Transistor

Source

Gate

Drain

Cathode

Anode

Anode Cathode

Anode

*

Part Replaced ([)

RV901

HV ADJ

HV Regulator

Circuit Check

HV Protector

Circuit Check

Beam Current

Protector Circuit

Check

Part Replaced (])

D Board C901, R923, R924,

R929, R943, T902(FBT)

• Mounted D Board

D Board C922, C926, D912,

D915, D921, Q907,

Q908, R921, R922,

R932, R937, R939,

T902(FBT)

• Mounted D Board

D Board C921, C933, D901,

D913, R920, R928,

R930, 931, T902(FBT)

• Mounted D Board

N Board IC001, R031, R032

• Mounted N Board

GDM-FW9012( E) 4-10

12345678 9 10 11 12 13 14

A

B

C

D

E

F

G

H

I

J

(1) Schematic Diagram of A Board

0

2.7

0

2.6

0

2.9

0.1

4.9

2.8

0.7

4.4

2.6

2.0

4.6

2.6

2.7

2.4

2.5

2.6

2.4

2.5

4.3

3.4

4.5 2.7

2.6

2.7

0.6

0.5

1243 56

2.7

79.0

65.5

2.7

2.6

2.7

58.1

+220V

5.8

103

102

109

107

105

103

1.2

1.7

0.5

5.8

+80V

11.8 11.9

2.6

2.7

3.8

534

4.3

4.9

4.3

522

82.6

95.6

104

4.7

7

8

9

4.9

4.3

4.9

4.3

2.72.6

4.9

0.5

0.3

0.7

3.4

2.3

3.5

0

4.3

+5V

4.3

4.9

10

1

2

3

4

5

6

123456789101112131415161718

19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36

12345678910 11 12 13 14 15

1234567891011121314

15 16 17 18 19 20 21 22 23 24 25 26 27 28

1 4 6 7 10 11 13 14 15 16 173 85 12

1

3

4

5

6

78

9

10

11

13

GND

1

2

1

2

3

4

5

6

7

8

9

123456789101112131415161718192021

22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42

1

2

3

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

1234567

8 9 10 11 12 13 14

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

R418

SG402

CN406

C457

D201

C201

C203

D202

C204

R205

R206

R454

C202

C459

R459

R464

L402

C419

R463

C207

C112

C212

C312

CN405

R421

R422

R430

C433

C435

C440

C444

C458

C462

R214

R314

R114

PS401

C101

R105

D101

C302

C301

R305

D301

C307

C107

D302

R306

C303

C304

D102

R106

C103

C104

C442

C434

C102

R438

R411

C206

C416

C402

C408

C413

C404 C407

C403

C401

R402

R202

R457

R101

R201

R301

R103

R203

R303

R428

R436

C432

C423

R413

R417

R419

R138

R238

R338

R415

R426

C467

C114

C214

C314

R420

R444

R445

R456

R447

R448

R113

R213

R313

D105

D205

D305

R121 R120

R221 R220

R321 R320

R137

R237

R337

C425

R449

R453

R442

C410

R409

R460

C436

D405

D107

D206

D207

D306

D307

D106

CN403

C205

C216

C443

C421

C463

C464

R455

R130

R230

R330

R222

R322

C406

R122

C108

C308

D103

D203

D303

C446

L404

R458

C424

C417

SG101SG201

SG301

SG401

CN401

X401

C113

C213

C313

L403

L405

FB402

FB403

FB404

FB405

FB406

FB411

R119

R219

R319

R310

R210

R110

C438

R424

R425

R427

R431

C405

SK401

C430

C441

R404

R405

R118

R218

R318

R107

R207

R307

C420

R403

D406

CN407 CN408

C115

C215

C315

C320 C220 C120

R109

R209

R309

R117

R217

R317

R128

R228

R328

CN402

IC401

IC407

IC402

C422

R488

IC403

R211

C209

C309

C210

R316

C310 R312

IC406

Q401

R115

R215

R315

Q410

Q407

IC405(2/2)

IC405(1/2)

D403

Q406

Q301

Q101

Q201

C208

C415

IC404

C431

R212

R216

R446

R443

0.01

B:C IP

2P

W T

:V

220k

1/2W

1PS226-115

0.01

B:C IP

0.01

B:C IP

1PS226-115

47

25V

47

:C IP

47

:C IP

2.2M

:C IP

47

25V

22

100V

10M

:RN

2.2k

:C IP

1000p

500V

B

100k

:C IP

0.1

25V

B:C IP

100

:C IP

1000p

500V

B

0.01

B:C IP

1000p

500V

B

0.1

:C IP

0.1

:C IP

22

:C IP

22

:C IP

22

:C IP

1A

0.01

B:C IP

47

:C IP

1PS226-115

47

25V

0.01

B:C IP

47

:C IP

1PS226-115

0.1

25V

B:C IP

0.1

25V

B:C IP

1PS226-115

47

:C IP

0.01

B:C IP

47

25V

1PS226-115

47

:C IP

0.01

B:C IP

47

25V

0.22

16V

0.22

16V

0.22

16V

B:C IP

16V

0.01

B:C IP

9P

W T-L

:S-MICRO

100

:C IP

100

:C IP

1000p

500V

B

0.01

B:C IP

47

25V

2.2

1

10V

B:C IP

47

25V

220p

C :C IP

220p

C :C IP

0.01

B:C IP

0.01

B:C IP

0.01

B:C IP

4.7k

:C IP

4.7k

:C IP

10

1k

:C IP

100k

:C IP

10M

:RN

22µ

75

:RN

75

:RN

75

:RN

75

:RN

75

:RN

75

:RN

100 :C IP

100k :C IP

47

25V

0.22 16V

B:C IP

1M

:C IP

220

:C IP

2.2k

:C IP

120

:C IP

120

:C IP

120

:C IP

100 :C IP

47

:C IP

47

:C IP

47

:C IP

470k

:C IP

470k

:C IP

470k

:C IP

470k

:C IP

470k

:C IP 470k

:C IP

22k

:C IP

R414

47k

:C IP

10k

:C IP

1k

:C IP

0.1

25V

B:C IP

0.1

25V

B:C IP

0.1

25V

B:C IP

1

250V

SS83TD

390

100k

:C IP

220k

:C IP

0.01

B:C IP

0.01

B:C IP

0.01

B:C IP

0.1

B:C IP 0.1

B:C IP

0.01

B:C IP

100p

C :C IP

0.22

0.01

B:C IP

21P

L-FPC

1SS119

2.2M

:C IP

100 :C IP

47 :C IP

100 :C IP

10k

:C IP

100k

:C IP

470k

:C IP

470k

:C IP

470k

:C IP

22k

:C IP

22k

:C IP

0.01

B:C IP

22k

:C IP

0.1

25V

B:C IP

0.1

25V

B:C IP

47

25V

1PS181-115

100µ

2.2M

1W

:RN

1000p

500V

B

4700p

2kV

B

0.22

16V

B:C IP

0.22

16V

B:C IP

0.22

16V

B:C IP

100µ

8M z

22µ

1.1µ

15k :C IP

100k :C IP

R161

470

:C IP

R261

470

:C IP

R361

470

:C IP

R439

470

:C IP

0.1

B:C IP

1k :C IP

1k

:C IP

1k :C IP

470k

:C IP

0.1

25V

B:C IP

0.01 B:C IP

680

:C IP

680

:C IP

680

:C IP

22k :C IP

0.22

16V

B:C IP

1M

:C IP

1M

:C IP

1M

:C IP

2.2k

:C IP

680

:C IP

8P 8P

0.01

B:C IP

SU83TRF

1PS226-115

12k

:C IP

12k

:C IP

12k

:C IP

1M

:C IP

1M

:C IP

1M

:C IP

4.7k

:C IP

4.7k

:C IP

4.7k

:C IP

0.1

250V

0.1

250V

0.1

250V

25V

0.1

250V

0.1

250V

0.1

250V

D15D-SUB

6P

W T

:S-MICRO

M52757FP-TP

INPUT SELECT

SN74 C04ANSR

G SYNC BUFFER

M52749FP-TP

RGB DRIVE

0.22

16V

B:C IP

R407

470k:RN-CP

12V

47k

:C IP

FA4301

RGB AMP

100

:C IP

27p

C :C IP

33p

C :C IP

0.001

C :C IP

4.7k

:C IP

0.001

C :C IP

47

:C IP

8D2972

CUT OFF AMP

2SC2412K

DRIFT CORRECT

47

1/2W

:SURGE

47

1/2W

:SURGE

47

1/2W

:SURGE

2SC5022-02

G2 CONT

DTA114TUA

G2 CONT

NJM2904M(TE2)

G2 CONT

NJM2904M(TE2)

G2 CONT

MTZJ-T-77-39B

2SB709A

G2 CONT

2SC2412K

BUFFER

2SC2412K

BUFFER

2SC2412K

BUFFER

0.1

25V

B:C IP

16V

0.22

B:C IP

CXD9514M

OSD

1000p

B:C IP

56

:C IP

4.7k

:C IP

100 :C IP

G

+12V

G2

+80V

R_CUTOFF

G_CUTOFF

B_CUTOFF

1.5KV

R

B

R

B

+220V

G2

R_BKG

G_BKG

B_BKG

R_IK

G_IK

B_IK

12V

5V

12V

5V-2

5V

5V-2

5V

5V-2

5V

5

4

3

2

1

10

9

8

7

6

15

14

13

12

11

1

7

2

3

6

5

8

4

C426

100p

C :C IP

C427

22p

C :C IP

KB

GND

KG

GND

KR

GND

EATER +

(G2)

(GND) (GND)

GND

R_IN

R_E.P

R_OUT

GND

G_OUT

G_E.P.

G_IN

VBB

GND

VBB

B_IN

B_E.P.

B_OUT

VCC

KB

GND

KG

GND

KR

GND

EATER +

FV

IMR

FC

GND GND

OSD_BLK

R_IN

VCC1(R)

OSD_R

GND1(R)

G_IN

SOG_IN

VCC1(G)

OSD_G

GND1(B)

ABL_IN

NC

VCC_5V

SOG_OUT

VCC2

R_OUT

GND2

G_OUT

B_OUT

BLK

D/A_1

D/A_2

D/A_3

D/A_4

G_IN2

R_IN2

NC

B_IN2

R_IN1

GND

G_IN1

GND

B_IN1

VCC1

V_DET

VCC2

R_OUT

VCC2

G_OUT

GND

VCC2

B_OUT

GND

G_BUF.OUT

G_BUF.IN

SYNC_SEP.OUT

VCC2

R_DET_IN

G_DET_IN

B_DET_IN

SDA

SCL

GND

V.SYNC

.SYNC

CONT_DAC

CONT_REF

OLD_CR1

OLD_CR2

G.DET

V_DET_C

INPUT_SW

CLP

C.BLK

SYNC_ON_G

ABL(NC)

GND

G.SYNC_DET

R IN 2

G IN 2

R GND 2

G GND 2

B IN 2

B GND 2

S/CS 1

VS 1

GND

DDC+5V 1

DDCSCL 1

DDCSDA 1

OSTGND 1

+80V

GND

NC

+12V

+220V

G2

N.C.

STBY +5V

EATER

GND

NC

GND

Main_Brightness

VBB

B-IN

GND1(G)

VCC1(B)

OSD_B

NC

VCC2

NC

CLP

SCL

SDA

GND

D/A_5

INPUT_SEL

OSCREF

ADCREF

RCI

GCI

BCI

AVDD

OVDD

BOUT

GOUT

ROUT

PWM4

PWM3

PWM2PWM1

PWM0

XT0

XT1

DVSS

DVDD

AV

VS

S

SCL

SDA

AGND

FILTER

fly

FBLK

FBP

+B

B_OUT

B_BASE

R_IK

R_IN

VBB

GND

G_OUT

G_BASE

R_OUT

R_BASE

G_IK

B_IK

G_IN

B_IN

A1

Y1

A2

Y2

A3

Y3

GND

VDD

A6

Y6

A5

Y5

A4

Y4

FC

G1

G2

KB KG KR

G1

2

1

G1

FV

TO CONNECTOR

PANEL

INPUT2

INPUT1

( D15)

TO D BOARD

1W_5V

CN652

TO G BOARD

TO D BOARD

CN506

A

(VIDEO AMP,RGB OUT)

CN001

C BLOCK

TO N-a BOARD

B-SS3536<AEP>-A..-P1-24

R111

470

:C IP

R311

470

:C IP

S

D402

R406

R490

R491

Q402

R412

D407

C449

1

4.7k

:C IP

MA151WK-TX

100k

:C IP

4.7k

:C IP

2SJ360-TE12L

VCC KICK

220k

:C IP

R441

1M

:C IP

1PS226-115

5V

C411

47

25V

C450

0.47

16V

B:C IP

10V

B:C IP

C437

220

16V

R451

2.2M

:C IP

C456

0.1

25V

B:C IP

C452

0.1

25V

B:C IP

R116

R112

C109

C110

4.7k

:C IP

39

:C IP 33p

C :C IP

0.001

C :C IP

R204

C211

1k

:C IP

10p

C :C IP

R304

C311

1k

:C IP

10p

C :C IP

R104

C111

1k

:C IP

10p

C :C IP

L101

68n

L201

68n

L301

68n

C412

0.22

25V

B:C IP

C217

C117

C317

0.1

25V

B:C IP

0.1 25V

B:C IP

0.1 25V

B:C IP

GDM-FW9012( E) 4-11

• A BOARD IC401 M52757FP

2

4

CLAMP SUB

CONTRAST MAIN

CONTRAST OSD MIX AMP

CLAMP

F/B

RETRACE

BLANKING 41

303442

6

9

5

3

CLAMP SUB

CONTRAST MAIN

CONTRAST OSD MIX AMP

CLAMP

F/B

RETRACE

BLANKING 38

11

13

10

8

17

16

21 25 26 27 28 29 32 36 3914 1

12

20

7

CLAMP SUB

CONTRAST MAIN

CONTRAST OSD MIX

DAC BUS

I/F

AMP

CLAMP

F/B

OSD

LEVEL

4bit

Main

CONTRAST

8bit

B SUB CONT 8bit

G SUB CONT 8bit

R SUB CONT 8bit

RETRACE

BLANKING 33

35

31

24

22

23

19

Sync On

Green

Sep

OSD BLK IN

INPUT (R)

VCC1 (R)

OSD IN (R)

GND1 (R)

INPUT (G)

INPUT (SOG)

VCC1 (G)

OSD IN (G)

GND1 (G)

INPUT (B)

VCC1 (B)

OSD IN (B)

GND

GND1 (B)

ABL IN VCC=5V

SOG Sep OUT

Clamp Pulse IN

VCC2

OUTPUT (R)

GND2

OUTPUT (G)

GND

Contrast ref.

Main Brightness

OUTPUT (B)

GND

Contrast cont.

Retrace BLK IN

D/A OUT1

D/A OUT2

D/A OUT3

D/A OUT4

D/A OUT5

GND (5V)

SDA

SCL

36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

Sync

Sepa OR

G DET

Input1 (R)

Vcc1 (R)

Input1 (G)

Vcc1 (G)

Input1 (B)

Vcc1 (B)

Input2 (R)

GND1

Input2 (G)

GND5

Input2 (B)

Sync DET1

Sync DET2

S-DET out

Vcc5

Video DET-Hold

V-DET out

SWITCH

Vcc2 (R)

OUTPUT (R)

GND2 (R)

Vcc2 (G)

OUTPUT (G)

GND2 (G)

Vcc2 (B)

OUTPUT (B)

GND2 (B)

G Buffer out

Sync SEP in

Sync SEP out

Vcc3

V-DET in3

GND4

V-DET in2

Vcc4

V-DET in1

RGB

G

• A BOARD IC402 M52749FP

11

122

22

233

33

3

44

466

66

6

77

7

55

5

88

899

99

9

• A BOARD WAVEFORMS

4.0 Vp-p (H)

58.0 Vp-p (H)

56.0 Vp-p (H)

58.0 Vp-p (H)

4.0 Vp-p (H)

53.0 Vp-p (H)

4.2 Vp-p (H)

55.0 Vp-p (H)

56.0 Vp-p (H)

00

0

2.2 Vp-p (8MHz)

KB

KG

KR

G1

G2

GM

G4

RCV

V

CONNECTOR PANEL

INPUT2(BNC)

CN402

TO A BOARD

TO N BOARD

CN002


TUBE

V901

24TXF

TO D BOARD

T902(FBT) V

B-SS3536<AEP>-A..-P2-24

VD D B G R

5BNC

GDM-FW9012(E) 4-13

12345678 9 10 11 12 13 14

A

B

C

D

E

F

G

H

I

(2) Schematic Diagram of D Board

123

46

5

• D BOARD WAVEFORMS

54.5 Vp-p (H)

1.9 Vp-p (H)

2.1 Vp-p (H)

1.25 kVp-p (H)

4.5 Vp-p (H)

80.0 Vp-p (H)

+15V

-15V

+12V

-15V

+80V

+15V

+220V

+15V

9.0

8.9

3.5

2.0

2.5

9.0

0

0.6

3.1

0

3.2

9.1

9.3

+90V

82.5 82.0

82.5 75.5

78.4

4.5

5.0

528

-0.9

0.1

0.7

5.0 4.4

7.7

0

2.5

-7.6

1.1

1.8

0

1.1

0.5

+15V

3.3

2.5

6.8

9.4

2.5

9.0

2.0

9.0

3.6

+12V

14.7

0

27.4

00

28.1

0

28.4

0

4.84.8

0

4.84.8

0

28.5

0

1.1 0.6

1.2

4.3

-14.4

1.8

161

218

9.1

9.0

147

217

83.5 11.4

0

8.9

8.3

8.2

14.7

14.7 0

29.6

29.5

28.9

29.3

29.9

31.4

11.5

4.7

0

2.5

1.8

198.1

1.7

1.1

-0.1 1.8

13.9 -13.41.8

1

2

3

5

4

6

0

1

2

3

4

5

6

7

1

2

3

4

5

2

4

56

10

1

9

1 8

4 5

3

2

1

2

3

4

5

6

7

8

9

10

S

1

2

3

4

5

6

1

2

3

4

1

2

3

4

5

6

7

1 2 3 4 5 6 7 8 9 10

11121314151617181920

1 2 3 4 5 6 7 8 9

101112131415161718

1

2

5

8

9

10

6

3

4

13

HV

7

8

9

10

17

11

6

5

12

1

2

16

18

14

15

FV

FC

SSSSSSS

2

3

4

5

7

9

10

11

12

S

1

2

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

6

7

8

9

10

1

2

4

3

S

1234567

8 9 10 11 12 13 14

2

1

3

4

5

R725 R726

R728

R724

R723

C710

C708

R727

C712 C713

C709

C707R721

R720

R560

C539

C533

C534

R549

R550

R574 C552

C549

C540

C532

R557

C546

C547

R570

R576

R567

C510

L501

R525

FB501

FB502

D507

R546

C506

C507

R529 R532

C522

C520

C518

C523

R544

R538

R530

R524

R542 R548

C517 C519 C526 C530 R552 C535

R551

R526

R531 R539

R545

R722

R553

CN509

R513

C505

R514

R507

R504

R505 R515

C702

R702

C920

C924

SG901 C923

SG903

D912

C922

C921

R923

SG902

R928

C913

L901

R911

R916

R563

C1575

R565 R573

R583

R584

R585

R588

D517

C524

R535

R534

C527

C515

R918

L902

C536

R904 R906

R719

R718

CN501

CN503

C704 R516

C559

CN502

C928

C929 C935

C927

C901

C908

C932

R561

R555

C545

C554

C548

R533

R522 R537 R558

R729

C711 TH501

R506

TH502

R707

R706

R705

R701

R924

R935

R925

R919

R927

R922

R932

R930

R931

R926

FB901

D906

C915

R908

C542

L503

C560

C529

C516

C558

C918

C919

R939

C926

C925

C706

R929 RV901

C909

R943

C902

R902

R903

R901

C910

R907

C931

R945

R912

R501

R1501

R1502

C502

C508

D511

D513

D514

D516

D701

D702

D703

D901

D910

D918 D919

D921

R547

FB507

1.1µH

D922

R503

R512

D509

D506

R708

T505

R915

R509

R519

T902

R578

R579

L505

D508

D920

D707

D510

D505

D907

D909

D915

D515

R580

R582

C501

R937

R933

R934

C503

C903

R732

C930

C571

R510

C543

C537

CN504

CN505

R920

D913

C933

R940

C917

R523

C513

R569

R568

R554

R562 R564

C511

L504

R566

D512

D519

D708

R1506 R1507

C557

C531

C556

C544

C528

C509 C521

R572

C701

R709 R711 R713

R714

R715

R710

R716

R717

C703

C720

D709

D710

R556

R586

R595

R536

R517

R541 R518

C568

0.047

B:CHIP

R597

D522

R593

R591

C565

R598

C561

R917

R508

R590

R502

R599

R589

FB503

FB504

T503

R941

C538

R587

C907

D905

C905

C572

T501

T701

R703

R704

C715

R730

R731

T901

C914

C912

C514 C573

L502

R540

R594

C541

R1503 R1504

R543

R575

R1505

R527

C551

C525

R528 R521

C555

R577

R581

C575

FB505

R914

R520

D917

D904

D520

D504

Q519

Q517

Q513

Q512

Q511

Q510

Q507 Q525

Q501 Q506

Q521 Q522

IC501

Q526

Q516

Q518

IC503

Q524

Q520

Q514

IC502

Q508

Q504

Q505

Q502

Q503

CN508

CN506

D908

IC901

Q905

Q903

Q904

Q906

Q907

Q908

Q702

Q704

Q705

Q703

Q701

Q706

Q707

IC701

D902

Q515

Q509

D923

RY501

1.8

1/2W

:RN

1.8

1/2W

:RN

220

1W

:RS

2.2k

:RN-CP

3.3k

:RN-CP

220

35V

:HT

1000

25V

1

:FPRD

0.27

250V

:PT

1000

25V

0.01

B:CHIP

0.1

:PT

10k

:CHIP

10k

:CHIP

10k

:RN-CP

4700p

B:CHIP

220

25V

:HT

220

25V

:HT

0.47

1/2W

:FPRD

0.47

1/2W

:FPRD

100k

:CHIP 0.01

B:CHIP

0.1

:PT

0.001

200V

:PT

0.001

B:CHIP

27

1W

:RS

1500p

630V

:PP

2.2k

1/2W

:FPRD

1k

1W

:RS

100

1/2W

:RN

33

250V

4.7k

:CHIP

1.1µH

YG911S3R

0.22

5W

:RS

0.47

:MPS

0.22

:MPS

2.2k

:CHIP

33

1W

:RS

4700p

:PT

1000

25V

0.47

:MPS

4700p

:PT

100 :CHIP

100

:CHIP

1k

:CHIP

100

:CHIP

47k 47k

0.01

B:CHIP

0.01

B:CHIP

B:CHIP 0.01

B:CHIP

0.01

B:CHIP 100k

:CHIP 0.01

B:CHIP

100 :CHIP

100k

:CHIP

100

:CHIP 100k

:CHIP

100k

:CHIP

1

1/2W

:FPRD

220

10P

:VH

100

:CHIP

100k

:CHIP

100k

:CHIP

100

:CHIP

1k

:CHIP 1k

:CHIP

47

100V

25V

10

:FPRD

0.022

:PT

0.1

100V

:PT

3300p

200V

:PT

EGP10GPKG

0.1

100V

:PT

0.22

100V

:PT

220k

:RN-CP

5.1k

:RN-CP

33

400V

470

:CHIP

22

:FPRD

100

0.1

:CHIP

100k

:CHIP 47k

47k

10k

:CHIP

68

1/2W

ERA91-02TP1

470p

CH:CHIP

4.7k

:CHIP

39k

:RN-CP

0.01

B:CHIP

0.1

B:CHIP

68

:10W

15µH

47

C577

10

220

:CHIP 220

:CHIP

3.3k

:RN-CP

18k

:RN-CP

4P

WHT

470p

2kV

B

1k

:CHIP

2.2

250V

7P

WHT

:S-MICRO

470p

CH:CHIP

0.1

B:CHIP

1000p

CH:CHIP

47p

CH:CHIP

0.01

B:CHIP

0.01

B:CHIP

0.01

B:CHIP

8.2k

:RN

10k

:RN-CP

22p

500V

CH

1

1/2W

:FUSE

47k 47k 47k

1

1/2W

:FPRD

6800p

B:CHIP

1k

:CHIP

4.7

:FPRD

4.7

:FPRD

470

:FPRD

1k

:CHIP

10k

:CHIP

47k

:CHIP

330k

1/2W

:RC

4.7k

1/2W

:RC

1k

1/2W

:RC

4.7

:FPRD

3.9k

:CHIP

1.2k

:RN-CP

1k

:RN-CP

1k

1/2W

:RC

1.1µH

YG911S3R

0.22

:MPS

6.8

3W

:RS

0.01

B:CHIP

1mH

0.01

100

25V

220

16V

25V

100

25V

4700p

100V

:PT

4700p

2kV

:E

1k

:CHIP

47

R921

300

47

0.1

B:CHIP

47k

:RN-CP 100k

220

16V

25V 4.7k

:CHIP

100

25V

680k

:RN-CP

47k

:CHIP

100k

:CHIP

3.3

22k

:CHIP

10

100

:CHIP

1k

:CHIP

R913

100k

:CHIP

6P

WHT

:S-MICRO

100µH

47

2W

:RS

1k

:CHIP

0.22

:MPS

22

FMQ-G5GS

1SS133T-77

1SS133T-77 1SS133T-77

1SS33T-77

220

:CHIP

1.8 10W :RN

1k

:CHIP

100p

2kV

:HR

470p

2kV

B

100p

2kV

:HR

1SS133T-77

D502

JW(5)

D503

JW(5)

D501

JW(15)

ERA34-10TP1

D925

ERA34-10TP1

1k

:CHIP

22k

:RN

C566

0.01

:PT

15

2W

:RS

4.7k

:CHIP

0.01

RD13ES-T1B2

D5SC4M

HZS5.1NB2TD

HZS5.6NB2TD

HZS5.1NB2TD

HZS16NB2TD

RD27ES-T1B2

RD4.7EST1B2

HOC

22k

:CHIP

1k

:CHIP

1k

:CHIP

100

1/2W

:RN

100

1/2W

:RN

:FBT

0.01

B:CHIP

10

33k

:RN-CP

4.7k

:RN-CP

4.7k

:CHIP

10p

CH:CHIP

10p

CH:CHIP

10k

:RN-CP

470k

1/2W

:SURGE

0.068

250V

:PP

3600p

1.8kV

25P

:FFC

25P

:FFC

47k

:CHIP

1

1SS133T-77

10k

:CHIP

R559

10k

:CHIP

C567

2200p

B:CHIP

0.33

250V

:PP

220

:CHIP

4700p

B:CHIP

9.1k

:RN-CP

12k

:RN-CP 12k

:RN-CP

3.9k

:CHIP

47k

:RN-CP

68p

CH:CHIP

1SS355TE-17

4.7mH

27k

:RN-CP

GP08DPKG23

HLC

0.01

B:CHIP

100

:CHIP 100k

:CHIP

0.033

400V

1

250V

:PP

0.47

250V

:PP

0.24

250V

:CQ

0.12

250V

:PP

2

250V

:PP

0.47

3W

22

100V

1k

:CHIP

2.7k

:CHIP

2.2k

:CHIP

HZS5.1NB2

1SS355TE-17

0.1

25V

B:CHIP

47

25V

C564

1

2200p

1kV

:E

10

ERA22-06AVRB

27k

:RN-CP

68k

:RN-CP

22k

:RN-CP

R511

4.7k

:CHIP

C504

4700p

B:CHIP

0

:CHIP

22k

:RN-CP

22k

:RN-CP

100

R1510

10k :CHIP

10k

:CHIP

2.2k

:CHIP

10k

:CHIP

R1518

100

:CHIP

10k

:RN-CP

10k

:CHIP

1k

:CHIP

4.7

:FPRD

39k

:CHIP

10k

:CHIP

220

1/2W

:FUSE

C904

1000p

2kV

220

2.2k

:CHIP

2.7k

:CHIP

1.8k

:RN-CP

2.2k

:CHIP

1.1µH

HST

100

:CHIP

0.01

B:CHIP

220

3W

:RS

120p

CH:CHIP

HZS13NB2TD

270p

CH:CHIP

0.001

B:CHIP

HDT

DFT

30k

:RN

1k

:RN-CP

0.1

25V

B:CHIP

22k

:CHIP

5.1k

:CHIP

HRC

0.047

200V

:PT

0.047

200V

:PT

0.022

200V

:PT

0.022

200V

:PT

1mH

47

3W

:RS

R1515

47

3W

:RS

22k

:RN-CP

2200p

B:CHIP

15k

:RN-CP

2.2k

:CHIP

12k

:RN-CP

7.5k

:RN-CP

4.7k

:RN-CP

8.2k

:RN-CP

4700p

B:CHIP

0.047

B:CHIP

12k

:RN-CP

4.7k

:RN-CP

2.2

250V

47

1/2W

:FPRD

22

1/2W

:FPRD

0.01

CH:CHIP

1.1µH

FB506

1.1µH

22

1SS355TE-17

DTC114GKA

RELAY DRIVE

2SK3262

S-CAP

CHANGE

2SK3262

S-CAP

CHANGE

2SK3262

S-CAP

CHANGE

2SK3262

S-CAP CHANGE

2SK3262

S-CAP CHANGE

2SK3262

S-CAP

CHANGE

2SK3262

S-CAP

CHANGE

2SK3262

S-CAP

CHANGE

2SK3262

S-CAP CHANGE

2SC2412K

TH DET 2SC2412K

TH DET

BA9759F

CONTROL

DTA143TKA

GAIN SW

2SB1565EF

Q523

2SC2412K

HL OUT

2SD2394-EF

HL OUT

BA10324AF

AMP

2SA1037AK

PIN AMP

2SC2412K

BUFF

2SC3209LK

H CENT

LA6500-FA

H CENT OUT

2SJ569LS

PIN OUT

2SC2411K

PIN DRIVE

2SA1036K

PIN DRIVE

2SC2412K

H DRIVE

2SA1036K

H DRIVE

10P

WHT

:S-MICRO

2P

WHT

:VH

CN507

1P

ERA34-10TP1 D911

ERA34-10TP1

BA9758FS

HV CONTROL

2SJ569LS

HV REG SW

2SC2411K

HV DRIVE

2SA1036K

HV DRIVE

2SK2655

HV OUT HV OUT

DTA114GKA

HV DET

DTC114GKA

HV DET

2SC2459

H DRIVE

2SC3421

H DRIVE

2SA1358

H DRIVE

2SA1049

H DRIVE

2SC2362KG

H DRIVE

2SA1037AK

V DRIVE

2SC4634LS-CB11

V DRIVE

LA7841L

V DY OUT

HZS12NB2TD

2SC5570 H OUT

2SC3746

H OUT

1SS355TE-17

+B

15V -15V

400V

2

1

S0

S1

S2

S3

S4

S5

S5-1

S6

HDF

ABL

S5

S6

S0

S1

S2

S3

S4

HCENT

HSPBAL

V+

V-

V+

V-

HSIZE

HSP

THDET

HDF

VDF

RXD

TXD

HTR

DGUS

ECO

HD

HVDET

VSHAPE

VRET

VSHAPE

HSP

HSPBAL

HVDET

HCENT L

HCENT N

HCENT H

HCENT L

HLIN

HFBP

THDET

HD

VDF

HSIZE

ABL

ABL_DET

S5≠≠≠

HCENT H

HTR

DGUS

ECO

TXD

RXD

+VIN

VEE

VCC

OUT

-VIN

H.DY H

H.DY C

NC

V.DY H

V.DY C

GND

S

G

D

NC

GND

NC

+220V

4

5

NC

-15V

GND

HTR SW

+80V

+15V

GND

STBY+5V

1W+5V

ECO SW

PWR SW

DGUS SW

N.C

G2

1

GND

STBY+5V

RXD

TXD

GND

OUT + Vcc

VEE - OUT

OUT

Vcc UP

PUMP

PVCC

PWMOUT

PGND

SLOW SW

VREG9

SAWR

SAWOUT

SGND

HDIN

HVD

AGC

+

-

PWMOUT

PVcc NC

SAWOUT

NC

SGND

HDIN

DELAY

VREG9SVcc

PGND

HVDCAP

NC

SLOW SW

NC

ERROUT

GND

HV

OUT

SW

+15V

-15V

TH DET

-15V

HDF

GND

VDF

HV DET

ABL

HSPBAL

HCENT

TXD

RXD

SHDET

HSHAPE

STBY+5V

HSIZE

1W+5V

GND

S4

S7

GND

HD

GND

S1

S3

S0

S2

S6

GND

S5

ECO SW

GND

PWR SW

VSHAP

VRET

+12V

HFBP

GND

STBY+5V

HLINBAL

DGUS SW

HTR SW

NC

MIX+

MIX-

MIXOUT

VCC

REFIN

ERRIN

NC

ERROUT

O2

-2

+2

VCC

+1

-1

O1

O3

-3

+3

VEE

+4

-4

O4

D

(DEFLECTION)

H CENT H

H CENT N

H CENT L

TO G BOARD CN654TO A BOARD CN406

HV ADJ

TO

A BOARD

FV

TO

A BOARD

FC

TO G BOARD

CN653

TO G BOARD

CN650

TO ECS

TO N-a BOARD

CN010

TO N-a BOARD

CN011

H.DY

V.DY

FASTEN

HV TUBE

TO PICTURE

B-SS9327<NH>-D..-24

D914

JW(5)

D704

:CHIP

0

S5-1

S7

D706

EGP10PKG23

C562

0.033

B:CHIP

C512

100

CH:CHIP

D923

1SS355TE-17

S-CAP

CHANGE

L506

1.0mH

C946

0.1

25V

:CHIP

S

R1587

Q527

C580

R1588

C579

0.01

B:CHIP

2SK3262

47k

100k

:CHIP

0.015

400V

:PP

C578

0.065

400V

:PP

S7

R1589

100 :CHIP

FB1503

C1570

JW1501

JW(15)

JW(5)

5MM JW1502

5MM

R592

220

3W

:RS

S

Q901

C911

R909

C916

C906

0.01

B:CHIP

2SK2655

100k

:CHIP

1k

:CHIP

3000p

1.2kV

:PP

1500p

1.2kV

:PP

µPC2912HF

12V REG

IO

G

C576

IC504

C569

100

16V

0.22

25V

F:CHIP

Q910

C936

R942

68p

CH:CHIP

2SC2412K

10k

:CHIP

AMP

R910

R936

Q902

Q909

R938

DTC114EKA

SW

DTC114EKA

SW

4.7k

:CHIP

4.7k

:CHIP

0

:CHIP

T502

:HCT

2

1

3

6

7

9

11

12

C550

0.065

400V

GDM-FW9012(E) 4-16

12345678 9 10 11 12 13 14

A

B

C

D

E

F

G

H

I

(3) Schematic Diagram of G Board

6.7

4.0

0

4.0

0.7

0.1

5.7

179.1

2.5

13.0

0.1

1.3

5.6

2.4

2.6

4.8 1.2 1.2

3.5

4.7

0

0.1

14.0

15.2

379

188

189

0

1.5

4.9

2.5

3.2

0

993

1.4

2.5 0

2.1

14.7

181

0.5

4.9

4.7 0

0

14.0

2.3

3762.1

0.1

86.2

86.3

2.1

13.9

192

187.8

4.4

197.4

4.3

0

4.5

0

2.5

2.2

1.8

192

187.7

375

1.7

0

10.3

14.0

0.8

13.0

0

100µH

230µH

µPC2912HF

22µH

12345

1

2 3

4

1

2

3

1 8

5

2

3

4

6

1

2

3

1

2

3

4

5

6

7

8

9

1 2 3 4 5 1 2 3 4 5

1

2

3

4

1 2 3 4

5678

1

2

3

1

2

3

4

5

8

9 10

12

13

14

15

17

11

7

IO

G

IO

G

1

2

3

4

5

6

7

8

9

10

1

2

4

3

1

2

3

4

1

2

3

1

2

4

3

1 2 3 4 5 6 7 8 9 10

1

2

3

4

5

6

1

2

3

4

5

6

7

S

1

2

4

3

S

123456789

10 11 12 13 14 15 16 17 18

1

2

3

4

5

6

7

8

9 10

11

12

13

14

15

16

17

18

TH601

SG601

VDR601

PS650

CN603

CN602

CN601

C606

D610

C605

D690

C603

C604

R601

D692

Q691

R693

D631

FB630

C612

C613

IC653

D681

D654

D653

C658

D652

D651

IC650

D650

C662

C682

CN652

CN650

C692

R686

R665

R695

R664

R694

R613

R667

R673

IC652

D637

R649

R666

R681

R682

D664

L650

L651

R636

C680

R680

R688

Q652

Q653

C650 C651

C652 C653

C655

C657

C681

C683

C686

L680

IC680 Q671

Q667

D632

R696

R674

RY603

R677

RY602

R630

R633

R634

R635

R670 R671

R687

C629

C630

C633

C634

D635

Q630

IC630

R608

R609

R616 R617

R618

R607

R602

R603

R604

R605

R606

Q631

Q632

Q633

R650

D633

D680

IC651

FB632

D613

R615

C667

C685

C659

C601

AC INLET

DGC

C602

C684

CN651

CN655

C607

C647

C646

C648

C640

C643

C641

R620

R627

R628

R626

R625

C642

R631

C610

C649

R624

D640

R675

R676

R632

R612

R622

C644

R623

C639

R643

R691

R692

R684

R672

R653

C661

R637

R638

R656

T620

D655

L652

L653

CN604

FH1

FH2

PH610

PH620

PH630

CN654

CN653

C645

R651

IC620

L610

R668

C665

IC654

CN605

F601

C631

C654

C614

C608

C609

R645

R639

R640

R641

Q611

R644

Q612

D620

R642

R610

R611

C656

D601

R614

R698

Q613

T630

C611

THP601

R678

PS680

IC610

D630

D682

R699

Q610

T601

Q620

Q621

R629

L611

R619

R652

2.0A

3P

WHT

:VH

4P

WHT

:VH

4700p

250V

D4SB60L

4700p

250V

330k 1/2W :SURGE

1SS119

2SC3311A

68

1/2W

D2S4MTA1

2200

10V

D4SBS4

D4SBL40

0.01

:PT

0.22

:MPS

47

1SS119

0.45UH

4700p

:PT

0.1

B:CHIP

7P

WHT

:S-MICRO

9P WHT :S-MICRO

DM-57N

47k

:CHIP

10k

:CHIP 2.2k

:CHIP 47k

:CHIP

10k

:CHIP

220

:CHIP

10k

:CHIP

4.7k

:CHIP

1SS119

BA05T

D1NL20U

RD22ESB2

RD5.6ESB2

22k

47k

:FPRD

10k

:CHIP

10k

:CHIP

1k

:CHIP

180k

:RN

150k

:RN

2SC2412K

470p

250V

B

470p

250V

B

4.7

250V

100

100V 4.7

100V

47

25V

47

25V

47

10V

47

10V

47

10V

P6KE200AG23

2SA1037AK

HEATER SW

HEATER REG

1W+5V REG

STBY+5V REG

RECT

6.5V RECT

REG SW

PWM CONTROL

RELAY DRIVE

VCC RECT

VCC SW

TO J BOARD

CN891

VCC SW

POWER CONT

SW REG CONTROL

REG SW(H)

+15/-15V RECT

H CENT L

+220V RECT

+12V REG

PROTECT

+220V SHUNT REG

PROTECT

H CENT H

+80V RECT

REG SW(L)

SW

PFI

100k

:CHIP

2.7k

:RN-CP

0.01

:PT

470p

B:CHIP

2200p

B:CHIP

1000p

B:CHIP

RD20ESB2

2SK2647-01MR

3.3

:FPRD

1M

1/2W

1M

1/2W

27k

2W

:RS 2.2k

:CHIP

12k

:RN-CP 12k

:RN-CP

22k

:CHIP

BA05ST-V5

RM11A

2200

10V

:HT

47

16V

100

10V

470p

250V

B

10

0.1

:MPS

2.2

47

100

250V

220

10V

:HT

4P

WHT

:S-MICRO

3P

WHT

:S-MICRO

ERB38-06V1

BA00AST-V5

2SC4015

2SC2412K

27k

2W

:RS

470k

:CHIP

470k

:CHIP

100k

:CHIP

100k

:CHIP

10k

:CHIP

6.8k

:CHIP

6.8k

:RN-CP 1k

1

2W

:RS

10

10k

10

10k

100

D1NL20U

4.7k

22

:RN

3.3k

:RN-CP

5.1k

:RN-CP

470

:CHIP

0.001

B:CHIP

0.001

B:CHIP

220p

500V

B

6800

10V

ERB38-06

YG802C09

FA13842P

HA17431PA-TZ

22k

:RN-CP

6.8k

:RN-CP

100

:RN-CP

JW(5)

0.22

3W

:RS

JW(5)

1k

:CHIP

2.2k

:CHIP

330p

1kV

R:HR

330p

1kV

R:HR

3.3k

:RN-CP

1P

150

6P

WHT

:S-MICRO

10P

WHT

:S-MICRO

TO D BOARD

CN508

TO D BOARD

CN501

TO A BOARD

CN405

TO S BOARD

CN3003

TO US BOARD

CN2601

TO D BOARD

CN502

B-SS9327<NH>-G..-24



2.2M

1/2W

:SURGE

R621

2.2M

1/2W

:SURGE

330

450V

33k

:RN

47

10V

:HT

1P

0.018

800V

:MPP

6.3AH

100p

:CHIP

0.1

B:CHIP

0.1

B:CHIP

100

2200

25V

RD22ESB2

2SA1037AK

2SC2412K

10k

:CHIP

10k

:CHIP

MA111

2200

25V

0.33

2W

0.33

2W

0.001

:PP

100

10

DTA114EKA

10k

:CHIP

AFC

470k

:RN

330k

:RN

330k

:RN

68k

:RN-CP

SRT

1

400V

1.2

3W

:RS

RD22ES-T1B2

RD9.1ES

MZ1540

4A

0.1

1/2W

:RF

1

275V

1.0

275V

MCZ3001D

0.1

1/2W

:RF

PIT

PC123F2

270

2SA1317

2SK2640-01MR

:LFT

1k

:CHIP

10k

:CHIP

15V

1

2

4

3

2

14

3

1

2

6

5

4

3

NC

DGC

NC

DGC

AC L

AC N

AC L OUT

NC

AC L IN

GND

-15V

H CENT H

H CENT N

H CENT L

+80V

GND

G

+220V

N.C

DRAIN

GATE

AC SEN

SOURCE

L SEN

GND

COMP

VCC

CATHODE

STBY+5V

1W+5V

ECO SW

PWR SW

DGUS SW

HTR SW

GND

+220V

N.C

+12V

HEATER

GND

+15V

GND

+80V

STBY+5V

1W 5V

GND

CTL

Vcc

GND

OUT

NC

Vcc

CTL

OUT

GND

VADJ

GND

N.C

+15V

GND

-15V

GND

VSENSE

F/B

CT

RT

GND

TIMER

SS

VC1

OCP

VD

NC

VG(H)

VS

NC

VG(L)

P.GND

VC2

VB

N.C

GND

USB 7V

(POWER SUPPLY)

GDM-FW9012(E) 4-18

1234567

A

B

C

D

E

(4) Schematic Diagram of H Board

0

4.4

4.9

0.1

0.2

3.7

2.2

1

2

3

4

5

6

7

8

9

10

11

1

2

1

2

3

1

2

3

G

R

TH801

Q801

Q802

D801

R823

R821

R811

R812

R815

R814

R822

C806

S801

Q803

Q804

R813 C802

R851

R802

R852

R853

R801

R804 R803

CN801

R824

S813 S812

FB801

FB802

FB803

FB804

FB805

CN803

CN804

CN802

S811 JR1

JR4

150

:RN

10K

470

:RN

47

16V

10

16V

SPR-505MVWT31

11P

:FPC

2SC2412K

DTA124EKA

1k

:CHIP

470

:CHIP

220

:CHIP

220

:CHIP

10k

:CHIP

10k

:CHIP

22k

:CHIP

100k

:CHIP

10k

:RN-CP

1k

:RN-CP 1.5k

:RN-CP

470

:CHIP

100

:CHIP

100

:CHIP

2P

BLK

:S-MICRO

0

:CHIP

0

:CHIP

0

:CHIP 0

:CHIP

0

:CHIP

0

:CHIP

0

:CHIP

LED0

LED1

KEY_DET

STBY+5V

GND

1W+5V

ENV DRI

POWER

INPUT_SW

CONT+

BRT-

CONT-

BRT+

INPUT1

INPUT2

H H1

GND

H2

RESET

ASC

GREEN

RED

GND

GREEN

RED

GND

NC

B-SS3536<AEP>-H..-24

(USER CONTROL)

TO N- a BOARD

CN007

LED DRIVE

GDM-FW9012(E) 4-21

12345678 9 10 11 12 13 14

A

B

C

D

E

F

G

H

I

(6) Schematic Diagrams of N (a, b, c) Board

•Divided circuit diagram

One sheet of D board circuit diagram is divided into three sheets,

each having the code D-ato D-c.For example, the destination

ab1 on the code D-asheet is connected to ab1 on the D-bsheet.

a b 1

Ref. No.

Circuit diagram division code

-15V

+15V

VCC+4.5V

STBY+5V

+12V

STBY+5V

SUB+5V

1W+5V

+15V

-15V

1 2 3 4

5678

1 2 3 4 5 6 7

891011121314

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

192021222324252627282930313233343536

1 2 3 4 5 6 7

891011121314

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

C064

C063 C071

C069

C075 C074

C073

C070

C079 C080

C091

R1028

R1024

R003

R004

R014

R054

R1030

R1031

R1032

R1033

R1034

R1035

R1037

R1038

R1041

R1042

R1043

C082

C089

C066

C067

R039

R040

R081

R1025

R1040

R007

R008

C001

R009

R053 C012

C011

R1006

R1007

R022

R1029

D001

D002

D003

D004

D015

C078

D025

R1049

R1051

R1070

R1058

C083

C084

C085

C087

D022

D023

D024

R1045

R1050

R1059

R018

R017

R016

R015

R020

R019

R021

R025

R026

R005

R006

R1053

R1057

R1054

R010

C002

R085

R082

R1056

D021

L002

R048

D012

D010

D009

D008

R059

R060

C094

C099

R058 R062 R063 R064

R075

R076

CN001

R1039

C068

R030

R034

L003

C072

R1027

R032

R044

R1022

R1023

R045

C065

FB003

D016

R024

R1026

C1005

R1047

CN002

R055

IC011

Q011

C077

IC010

Q003

Q002

Q001

D026

D018

CN010

R031

D017

IC004

IC005

Q006

Q004

D020

Q005

Q007

CN007

CN011

R1052

R1055

R047

FB002 FB001

R086

3300p

25V

CH:CHIP

2200p

CH:CHIP680p

B:CHIP

0.1

B:CHIP

100p

CH:CHIP

680p

CH:CHIP

0.1

B:CHIP

1000

16V

0.01

B:CHIP 47

100

16V

680

:RN-CP

18k

:RN-CP

100

:CHIP

100

:CHIP

1k

:CHIP

15k

:CHIP

100 :CHIP

47

25V

0.01

B:CHIP

2200p

CH:CHIP

0.1

25V

B:CHIP

100

:CHIP

100

:CHIP

R1075

0

:CHIP

1k

:CHIP

2.2k

:CHIP

2.2k

:CHIP

0.001

B:CHIP

2.2k

:CHIP

4.7k

:CHIP 47

0.1

B:CHIP

100 :CHIP

1PS226

MA151WK-TX

0.22

:MPS

4.7k

:CHIP

100k

:CHIP

2.2k

:CHIP

10k

:CHIP

4.7k

:CHIP

10k

:CHIP

1k

:CHIP

1k :CHIP

47 :CHIP

4.7 :FPRD

100 :CHIP

1k :CHIP

10k

:CHIP

2.2k

:CHIP

0.001

B:CHIP

1k :CHIP

10k

:CHIP

0.01

B:CHIP

10

0.01

B:CHIP

10

MA151WK-TX

1PS226-115

1k :CHIP

100 :CHIP

1SS355TE-17

100µH

1k :CHIP

HZS5.6NB2TD

5.6k

:CHIP

100

:CHIP

0.22

:MPS

1000

25V

0.1

25V

B:CHIP

0.1

25V

B:CHIP

21P

:FFC

1mH

1k :CHIP

2.2k

:CHIP 2.2k

:CHIP

27

:RN-CP 27

:RN-CP

270

:RN

270

:RN

2.2k

:CHIP

3.9k

:RN-CP

1.8k

:RN-CP

1k

:CHIP

2.2k

:RN-CP

2.2k

:RN-CP

1

1.1µH

HZS5.6NB2TD

100 :CHIP

470p

B:CHIP

330k

:CHIP

10k

:CHIP

8P

:S-MICRO

15k :CHIP

24LC21AT/SN

ROM

2SA1037AK

HD SW

0.1

B:CHIP

LA7865M-TLM

H.V.OSC,AFC,

H.DRV,V.SHAPE

2SA1037AK

CURRENT

MILLER

2SA1037AK

CURRENT

MILLER

2SA1037AK

CURRENT

MILLER

1PS226-115

HZS5.6NB2TD

25P

FFC

5.6k

:RN-CP

HZS5.6NB2TD

TC74HVCT74AFT

ECO DET

DTC123EKA

ACTIVE OFF DET

DTA124EUA

ACTIVE OFF DET

1SS355TE-17

DTA114GKA

ACTIVE

OFF DET

DTC124EKA

ECO SW

11P

WHT

:S-MICRO

25P FFC

10k :CHIP

1k :CHIP

1.1µH 1.1µH

1k :CHIP

R1063

4.7k

:CHIP

DGS

HTR

SOGDET

SOG

CBLK

CLP

VS1

HS/CS1

VS2

HS/CS2

SDA

SCL

HSIZE

HSHPBAL

VDF

HVDET

THDET

LED0

LED1

S0

S1

S2

S3

S4

S5

INPUTSEL

TXD

RXD

HSP

S6

HLINBAL

PWR_SW

VRET

HOST G 1

HOST G 2

HSOUT1

ABLDET

HCENT

VSHPLVL

DVSHAPE

VDC

HSOUT

HPHASE

HFREQ

MOIRE

VSAWRST

VSH

AFCSW

HPLL

HFBP

ECO_SW

HC1

VC1

HC2

VC2

HC1

PRT_DET

ENV

KEYDET

INPUT_SW

OFFDET

VSOSD

DSDA1

DSCL1

VC2

ECO

SOGDET

HC2

VC1

ECO_SW

HDSW

NC

VSS

VCLK

SCL

SDA

VCC

CLP

GND

C.BLK

GND

ABL(NC)

GND

SCL

SDA

LED0

LED1

KEY DET

GND

10

GND

11

GND

NC

HOST GND 2

DDC+5V 1

HS/CS2

VS2

V.SYNC

H.SYNC

GND

STBY+5V

1W+5V

+15V

-15V

GND

HV DET

ABL

TH DET

GND

HSHAPE

HSIZE

TXD

RXD

GND

SHDET

HDF

VDF

GND

HCENT

STBY+5V

1W+5V

HV OUT SW

GND

S0

S1

S2

S3

S4

S5

S6

S7

PWR SW

DGUS SW

HTR SW

GND

HFBP

HD

GND

VSHAPE

GND

VRET

GND

ECO_SW

STBY+5V

HLINBAL

HSPBAL

VSHPLVL

VDC

VSHP_C

GND

HS

HPHASE

HSDLY

AFC_FIL

VCO_C

GND

FILTER

REG9V

S/HC

VSAWRST

VSH

VSHAPE

VCC12

FBP

AFC_SW

NC

HPLL

HD_DUTY

HD

VCC12

IREF_RFBP_DLY1

HFREQFBP_DLY

NC

VCC4.5 DVSHAPE

VCC

2CLR

2D

2CK

2PR

2Q

1Q

1CLR

1D

1CK

1PR

1Q

GND

VCC

2CLR

2D

2CK

2PR

2Q

1Q

1CLR

1D

1CK

1PR

1Q

GND

INPUT_SW

HFBP

SYNC_ON_G

G.SYNC_DET

DDCSCL 1

DDCSDA 1

HOSTGND 1

INPUT_SEL

ENV_DRI

HS/CS 1

VS 1

TO CONNECTOR

PANEL

ac1

ab8

ab7

ab6

ab5

ab3

ab4

ab2

ab1

(H.OSC,V.OSC,AFC,H.DRV,V.SHAPE)

TO A BOARD CN403TO D BOARD CN504TO D BOARD CN505TO H BOARD CN801TO S BOARD CN3001

+12V

N

-a

INPUT2

B-SS3536<AEP>-N..-P1-24

S7

D036

HZS5.6NB2TD

D037

HZS5.6NB2TD

D038

RD2.2SB-T1

R046

10k

:CHIP

Q009

R1060

R1061 C093

2SC2412K

10k

:CHIP

10k

:CHIP

0.1

B:CHIP

1

2

3

4

5

6

7

8

9

R068

R069

R070

R071

R072

R073

R074

CN003

9P

:FFC

0 :CHIP

D_CHG

D_SCL

D_SDA

D_RES

D_MUTE

VSOSD

STBY+5V

GND

HFBP

VSAWRST

DCONCHG

DCONRES

SCL

SDA

DCONMUTE

GDM-FW9012(E) 4-22

12345678 9 10 11 12 13 14

A

B

C

D

E

F

G

H

I

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81828384858687888990919293949596979899

100101102103104105106107108109110111112113114115116117118119120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

1234

5 6 7 8

1234

5 6 7 8

2 3 4 5 6 7

891011121314

1 2 3 4

5678

C022

C021

C020

C019

C018

C017

C016

C015

C024

C025

C026

C013

C023

C043

C041

C040

C050

C049

C039

C038

C037

C055

C056

C057

C059

C062

C086

C090

C095

C096

D029

C097

R078

X001

R5005

R5006

C5004 C5002

R5007

R5015 C5003

C5005

C5008

R5010

R5011

GS5001

D013

R029

R035

R036

R037

R5003

R043

C053

C036

R049

R080

R079

C008

R023

C1004

C1006

R056

R057

R061

C014

R067

R066

C051

C048

C047

C046

C045

C044

C042

R1003

R1002

R1001 R099 R098

R097 R096 R095 R094 R093 R092 R091

R090

R1021

R1020

R1008

C054

C058

R1014

R1013

R1012

R1011

R1010

R1009

R1016

R1017

R1018

R1019

C061

C027

R1036

R1005

C033

R1064

D027

D028

R1067

R1066

R1065

R1068

R1069

C098

C028

C029

C5009

C003

C005

R1004

C052

C006

C007

R042

C031

C1003

R1044

R084

IC006

Q010

Q012

Q008

IC002

IC003

IC001

0.01

B:CHIP

0.01

B:CHIP

0.01

B:CHIP

0.01

B:CHIP

0.01

B:CHIP

0.01

B:CHIP

0.01

B:CHIP

0.01

B:CHIP

0.0022

B:CHIP

0.001

B:CHIP

100

25V

22

0.1

B:CHIP

22

10

47

25V

22

10

470

10V

0.01

B:CHIP

0.1

B:CHIP

2200

10V

0.01

B:CHIP

HZS5.1NB2TD

10

1M

:CHIP

24.756MHz

22k

:CHIP

10k

:CHIP

47

25V 10

1k

:CHIP

1k

:CHIP

100

16V

47

25V

47

25V

0

:CHIP

10k

:CHIP

HZS10NB2TD

10k

:CHIP

4.7k:CHIP

2.2k

:RN-CP

10k

:CHIP

0

:CHIP

1k

:CHIP

0.01

B:CHIP

0.022 B:CHIP

10k

:CHIP

0

:CHIP

0

:CHIP

0.1

25V

B:CHIP

4.7k

R1071

22k

:CHIP

0.1

B:CHIP

2200p

B:CHIP

10k

:CHIP

10k

:CHIP

1k :CHIP

0.1

B:CHIP

10k

:CHIP

1k

:CHIP

0.1

B:CHIP

0.01 B:CHIP

0.001 B:CHIP

0.022 B:CHIP

0.1 B:CHIP

1k

:CHIP 1k

:CHIP

1k

:CHIP 1k

:CHIP 10k

:CHIP

10k

:CHIP

4.7k

:CHIP

1k

:CHIP 1k

:CHIP

1k

:CHIP 1k

:CHIP

1k

:CHIP

10k :CHIP

4.7k

:CHIP

4.7k

:CHIP

4.7k

:CHIP

0.1

B:CHIP

2200p

CH:CHIP

1k

:CHIP

2.2k

:CHIP

2.2k

:CHIP

1k

:CHIP

1k

:CHIP

1k

:CHIP

1k

:CHIP

1k

:CHIP

1k :CHIP

1k

:CHIP

0.1

B:CHIP

0.1

B:CHIP

100 :CHIP

1k

:CHIP

0.1

B:CHIP

1k

:CHIP

1SS355TE-17

2.2k

:CHIP

10k

:CHIP

680k

:CHIP

4.7k

:CHIP

1k :CHIP R1046

100 :CHIP

0.1

B:CHIP

5p

:CHIP

27p

CH:CHIP

0.1

25V

B:CHIP

0.01

B:CHIP

150p

CH:CHIP

1k

:CHIP

100

16V

22p

CH:CHIP

22p

CH:CHIP

10k

:CHIP

10

47

25V

4.7k

:RN-CP

10k

:CHIP

R1062

1k

:CHIP

R1076

0

:CHIP

R1015

1k

:CHIP

TL082CPS-E20

ABL DET AMP

2SA1037AK

INV.

DTC124EKA

INV.

DTC114GKAT146

SW

MM1170BFB

WDT

M24C16-MN6T(A)

EEP ROM

CXD8744Q

CPU/DSP

STBY+5V

GND

HSOUT

AFCSW

VSH

HFBP

HFREQ

HPHASE

VDC

DVSHAPE

VSHPLVL

VS2

HS/CS2

HS/CS1

VS1

VSAWRST

MOIRE

VY

VX

HVDET

THDET

ABLDET

VRET

ENV

KEYDET

INPUTSEL

S0

S1

S2

S3

S5

S6

MOIREPLS

DSCL1

MOIREPLS

SOG

HTR

PWR_SW

DGS

CLP

CBLK

TXD

RXD

SDA

SCL

HPLL

DSDA1

HSOUT1

S4

OFFDET

HSHPBAL

VDF

VCONV

HSP

HSIZE

HCENT

ROTATION

HLINBAL

HCONV

LCCNS

LCCLT

LCCRT

LCCLB

LCCRB

LED0

LED1

HDSW

ECO

INPUT_SW

PRT_DET

HOST G2

HOST G1

VY

VX

A0

A1

A2

VSS

VCC

SCL

SDA

TC

NC

CK

GND

VS

RCT

VCC

RESET

VPP

MVBIAS

P10/A0

P11/A1

P12/A2

P13/A3

P14/A4

P15/A5

P30/A8

P31/CSIO

P40/D0

P41/D1

P42/D2

P43/D3

P44/D4

P45/D5

P46/D6

VDD1

P47/D7

P32/RD

P33/WR

P34/CLK

P35/SCOUT

ICE

TEST

P51/INT0

P52/INT2

P53/INT3

P54/INT4

P55/INT5

P90

RESET

VDD2

P50/X1OUT

GND1

SCK2/P85

RXD

TXD

UBI1

UBI2

UBI3

UBI4

GND2

UOUT1

UOUT2

UOUT3

PA0

PA1

PA2

GND3

PA3

PA4

PA5

PA6

OSCVSS

XTB

XTO

OSCVDD

UOUT4

UOUT5

UOUT6

P91

GND4

DAC0

AVSS1

DAC1

AVDD1

AIN1

AIN2

AIN6

AIN7

AIN8

AIN9

AIN10

AVDD2

AIN11

AIN12

AIN13

GND5

INT1

P92

P93

P94

P95

UOUT7

UOUT8

VDD3

UIN1

UIN2

GND6

UIN3

UIN4

UIN5

UIN6

GND7

UPWM1

VDD5

VDD6

UPWM2

GND8

GND9

UPWM3

VDD7

VDD8

UPWM4

GND10

UPWM5

GND11

UPWM6

VDD9

UPWM7

VDD10

UPWM8

GND12

GND13

UPWM9

VDD11

UPWM10

GND14

GND15

UPWM11

VDD12

UPWM12

VDD13

UPWM13

GND16

UPWM14

GND17

UPWM15

VDD14

VDD15

UPWM17

UPWM18

GND18

GND19

UPWM19

UPWM20

VDD16

VDD17

UPWM21

UPWM22

GND20

GND21

VDD18

HDCONT

VDD

WC

SDA2

SCL2

P82

SDA1

SCL1

WDP

EEPWC

P17/A7

P16/A6

P96

UBI5

CLPDLY

HPHASESW

AIN5

AIN4

AVSS2

AIN3

AIN0

TEMP

MOIRECONT

HDF0

GEOMAGNETIC SENSOR

Vcc 0 - +

0-+VDD

N

ab8

ab7

ab5

ab3

ab4

ab2

ab1

bc3

-b

bc2

bc1

ab6

(µ-COM,GEO MAGNETIC SENSOR)

B-SS9327<NH>-N..-P2-24

D_RES

D_CHU

D_MUTE

S7

DSCL2

DSDA2

D_SDA

D_SCL

R1077

100

:CHIP

C1008

C1009

4p

CH:CHIP

2p

CK:CHIP

HP GDM-FW9012 User manual

Popular Monitor manuals by other brands
