HP AD278A Installation instructions

HP AD278A and AD279A PCI Multiplexer
Support Guide
HP-UX 11i v3
HP Part Number: AD278-9002D
Published: November 2008
Edition: Edition 1

©Copyright 2008 Hewlett-Packard Development Company, L.P
Legal Notices
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP
shall not be liable for technical or editorial errors or omissions contained herein.
UNIX is a registered trademark of The Open Group. Intel and Itanium are trademarks or registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
2008Hewlett-Packard Development Company, L.P

Table of Contents
About This Document.........................................................................................................7
Intended Audience.................................................................................................................................7
Document Organization.........................................................................................................................7
Typographic Conventions.................................................................................................................7
HP-UX Release Name and Release Identifier...................................................................................8
Related Documents.................................................................................................................................8
HP Encourages Your Comments............................................................................................................8
1 Introduction......................................................................................................................9
Overview.................................................................................................................................................9
AD278A/AD279A PCI Multiplexer Components...................................................................................9
AD278A/AD279A PCI MUX Adapters.............................................................................................9
AD278A PCI MUX 8-Port Adapter............................................................................................10
AD279A PCI MUX 64-Port Adapter..........................................................................................10
Port Modules...................................................................................................................................11
Fan-Out Cable for AD278A PCI MUX 8-Port Adapter...................................................................12
Power Supply for Port Modules......................................................................................................12
2 Troubleshooting............................................................................................................15
The pmux_diag Utility..........................................................................................................................15
Starting pmux_diag Utility..............................................................................................................15
The pmux_diag Utility Conventions...............................................................................................15
Exiting pmux_diag Utility...............................................................................................................15
Driver Status Menu Selections..............................................................................................................16
Driver Status....................................................................................................................................16
Board Status.....................................................................................................................................17
Counters...........................................................................................................................................17
Topology..........................................................................................................................................18
Port Status Menu Selections..................................................................................................................19
Breakout Box....................................................................................................................................19
Data Scope.......................................................................................................................................20
Termio..............................................................................................................................................22
Register Dump.................................................................................................................................22
Diagnostics Menu Selections................................................................................................................23
Loopback.........................................................................................................................................23
Send.................................................................................................................................................24
Quit.......................................................................................................................................................24
Excessive Frequent getty Spawning.....................................................................................................25
Terminal Login Problems......................................................................................................................25
Printer Problems...................................................................................................................................26
Connecting a Modem............................................................................................................................27
Troubleshooting Modem.................................................................................................................28
System Crashes or Panics......................................................................................................................28
A Technical Specifications..............................................................................................29
Card Specifications...............................................................................................................................29
HP AD278A PCI MUX 8-port Serial Adapter Specifications..........................................................29
HP AD279A PCI MUX 64-port Serial Adapter Specifications........................................................30
Table of Contents 3

AD280A/AD281A Port Module Specifications.....................................................................................30
Cable Requirements and Specifications................................................................................................31
Physical Characteristics...................................................................................................................31
Grounding Requirements................................................................................................................31
Environmental Requirements..........................................................................................................31
Data Rate Information.....................................................................................................................31
Transmission Errors.........................................................................................................................32
B Peripheral Connections................................................................................................33
RS-232 Asynchronous: DB-25...............................................................................................................33
DB-25 Pin Assignments...................................................................................................................33
DB-25 Software Handshaking (XON/XOFF) Cable.........................................................................33
DB-25 4-Wire Hardware Handshaking (DTR) Cable......................................................................34
DB-25 Hardware Handshaking (RTS/CTS) Cable...........................................................................34
DB-25 Fully-Wired Terminal/Printer Cable.....................................................................................35
DB-25 Modem Cable........................................................................................................................35
RS-232 Asynchronous: RJ-45.................................................................................................................35
RJ-45 Pin Assignments.....................................................................................................................35
RJ45 8-Pin Plug Hardware Handshaking (DTR) Cable...................................................................36
RJ-45 8-Pin Plug Hardware Handshaking (RTS/CTS) Cable..........................................................36
RJ45 Fully-Wired Terminal/Printer Cable.......................................................................................37
RJ-45 10-Pin Plug to DB-25 Modem Cable......................................................................................37
Cabling Pin-outs for HP Proprietory RJ45 and DB25 Devices.............................................................38
C Port Naming and Numbering Conventions..............................................................43
HP-UX Port Assignments.....................................................................................................................43
HP-UX Port Names..........................................................................................................................43
Hardware Regulatory Statements.........................................................................................................45
FCC Statement (For U.S.A.).............................................................................................................45
Canada.............................................................................................................................................45
EMI Statement (European Community)..........................................................................................46
Japan................................................................................................................................................46
Declaration of Conformity....................................................................................................................47
Declaration of Conformity....................................................................................................................48
4 Table of Contents

List of Figures
1-1 AD278A PCI MUX 8-Port Adapter...............................................................................................10
1-2 AD279A PCI MUX 64-Port Adapter..............................................................................................10
1-3 RS-232 RJ45 Port Module...............................................................................................................11
1-4 RS-232 DB25 Port Module.............................................................................................................12
1-5 Fan-Out Cable for AD278A PCI MUX 8-Port Adapter.................................................................12
1-6 Power Supply................................................................................................................................13
2-1 pmux_diag utility Driver Status main menu................................................................................16
2-2 Driver Status Display....................................................................................................................17
2-3 Board Status Display.....................................................................................................................17
2-4 Select Port Group Display.............................................................................................................18
2-5 Selected Group Communications Monitor Display......................................................................18
2-6 Topology Display..........................................................................................................................19
2-7 Breakout Box Device Name Selection Display..............................................................................19
2-8 Breakout Box Display....................................................................................................................20
2-9 Data Scope Parameter Setup Display............................................................................................21
2-10 Data Scope Data Monitor Display.................................................................................................21
2-11 Data Scope Capture Data Display.................................................................................................22
2-12 Termio Flags Display.....................................................................................................................22
2-13 Register Dump Display.................................................................................................................23
2-14 Diagnostics Loopback Test............................................................................................................24
2-15 Diagnostics Send Test....................................................................................................................24
2-16 Quit pmux_diag utility program Display.....................................................................................25
5

List of Tables
1 HP-UX 11i Releases.........................................................................................................................8
1-1 PCI MUX 8-Port Adapter AD278A Solution...................................................................................9
1-2 AD279A PCI MUX 64-Port Adapter Solution.................................................................................9
1-3 PCI MUX AD280A RJ45 Port Module.............................................................................................9
1-4 PCI MUX AD281A DB25 Port Module...........................................................................................9
1-5 HP PCI MUX Adapter Types........................................................................................................10
1-6 Port Modules.................................................................................................................................11
1-7 Metrics Equivalent.........................................................................................................................11
1-8 Metrics Equivalent.........................................................................................................................12
2-1 pmux_diag Key Conventions........................................................................................................15
2-2 Excessive Frequent getty Spawning..............................................................................................25
2-3 Terminal Login Problems..............................................................................................................26
2-4 Printer Problems............................................................................................................................26
2-5 Modem Error Messages.................................................................................................................28
2-6 System Crashes or Panics..............................................................................................................28
A-1 AD278A PCI MUX 8-port Serial Adapter Specifications..............................................................29
A-2 AD279A PCI MUX 64-port Serial Adapter Specifications............................................................30
A-3 AD280A/AD281A Port Module Specifications..............................................................................30
A-4 Data Rate Versus Cable Length.....................................................................................................32
B-1 DB-25 Pin Assignments.................................................................................................................33
B-2 Simple Terminal/Printer Cable......................................................................................................33
B-3 Terminal/Printer Cable with DTR Handshaking..........................................................................34
B-4 Terminal/Printer Cable with RTS/CTS Handshaking...................................................................34
B-5 Terminal/Printer Cable for Software (XON/XOFF) or Hardware (DTR) Handshaking...............35
B-6 RJ-45 Pin Assignments..................................................................................................................36
B-7 Terminal/Printer Cable with DTR Handshaking..........................................................................36
B-8 Terminal/Printer Cable with RTS/CTS Handshaking...................................................................37
B-9 Terminal/Printer Cable for Software (XON/XOFF) or Hardware (RTS/CTS) Handshaking........37
B-10 RJ-45 to DB-25 Modem Cable ( 10 Wire )......................................................................................38
B-11 RS-232 RJ-45 Pinouts to HP Proprietary RJ-45 Pinouts.................................................................38
B-12 RS-232 RJ-45 Pinouts to HP Proprietary DB-25 Pinouts...............................................................39
B-13 RS-232 DB-25 Pinouts to HP Proprietary RJ-45 Pinouts...............................................................39
B-14 RS-232 DB-25 Pinouts to HP Proprietary DB-25 Pinouts..............................................................39
B-15 RS-232 RJ-45 to A6748A/A6749A RJ-45 Converter........................................................................40
B-16 RS-232 DB-25 to A6748A/A6749A RJ-45 Converter......................................................................40
C-1 Instance 1, Port module a, Port Names (or fan out cable ports 1 - 8)............................................44
C-2 HP MUX 64 Card 1, Port Module d, Port Names..........................................................................44
6 List of Tables

About This Document
This document describes how to troubleshoot HP AD278A/AD279A PCI Multiplexer (MUX)
serial adapters and peripherals. It also discusses technical specifications for the adapters and
peripheral connections.
Document updates may be issued between editions to correct errors or document product changes.
To ensure that you receive the updated or new editions, you must subscribe to the appropriate
product support service. See your HP sales representative for details.
The latest version of this document is available at:
http://www.docs.hp.com
Intended Audience
This document is intended for system and network administrators responsible for installing and
managing PCI MUX serial adapters. You are expected to have knowledge of operating system
concepts and I/O concepts. You must also have knowledge of networking and network
configuration concepts.
This document is not a tutorial.
Document Organization
The HP PCI Multiplexer Support Guide is organized as follows:
Chapter 1 Introduction Presents an overview of HP PCI Multiplexer product and describes
its components.
Chapter 2 Troubleshooting Describes the diagnostics tools available and how to
troubleshoot PCI Multiplexer.
Appendix A Appendix AProvides technical specification details for components of PCI
Multiplexer.
Appendix B Appendix BProvides RJ45 and DB25 pin-out tables for RJ-45 and DB-25
connectors.
Appendix C Appendix CDescribes the naming and numbering conventions followed for
ports and device drivers.
Typographic Conventions
This document uses the following conventions.
audit(5) An HP-UX manpage. In this example, audit is the name and 5is the section in
the HP-UX Reference. On the Web and on the Instant Information CD, it may
be a link to the manpage itself. From the HP-UX command line, you can enter
“man audit” or “man 5 audit” to view the manpage. See man(1).
Book Title The title of a book. On the Web and on the Instant Information CD, it may be
a link to the book itself.
KeyCap The name of a keyboard key. Note that Return and Enter both refer to the
same key.
Emphasis Text that is emphasized.
Bold Text that is strongly emphasized.
Bold The defined use of an important word or phrase.
ComputerOut Text displayed by the computer.
UserInput Commands and other text that you type.
Command A command name or qualified command phrase.
Intended Audience 7

Variable The name of a variable that you can replace in a command or function or
information in a display that represents several possible values.
[ ] The contents are optional in formats and command descriptions. If the contents
are a list separated by |, you can choose one of the items.
{ } The contents are required in formats and command descriptions. If the contents
are a list separated by |, you can choose one of the items.
... The preceding element may be repeated an arbitrary number of times.
| Separates items in a list of choices.
HP-UX Release Name and Release Identifier
Each HP-UX 11i release has an associated release name and release identifier. Theuname(1)
command with the -r option returns the release identifier. Table 1 shows the releases available
for HP-UX 11i.
Table 1 HP-UX 11i Releases
Supported Processor ArchitectureRelease NameRelease Identifier
PA-RISCHP-UX 11i v1B.11.11
Intel®Itanium®
HP-UX 11i v1.5B.11.20
Intel®Itanium®
HP-UX 11i v1.6B.11.22
Intel®Itanium®
HP-UX 11i v2.0B.11.23
Related Documents
For more information about HP AD278A/AD279A PCI MUX, see the following documents
available at:
http://www.docs.hp.com/en/netcom.html#Multiplexers
HP AD278A and AD279A PCI Multiplexer Release Notes
HP AD278A PCI 8-Port Serial Multiplexer Installation Guide
HP AD279A PCI 64-Port Serial Multiplexer Installation Guide
HP Encourages Your Comments
HP encourages your comments concerning this document. We are truly committed to providing
documentation that meets your needs.
Include document title, manufacturing part number, and any comment, error found, or suggestion
for improvement you have concerning this document. Also, please include what we did right
so we can incorporate it into other documents.
8

1 Introduction
This chapter introduces the HP Peripheral Components Interconnect Multiplexer (PCI MUX)
product. It also describes the components of HP AD278A/AD279A PCI MUX.
This chapter addresses the following topics:
•“AD278A/AD279A PCI Multiplexer Components” (page 9)
•“AD278A/AD279A PCI MUX Adapters” (page 9)
•“Port Modules” (page 11)
•“Fan-Out Cable for AD278A PCI MUX 8-Port Adapter” (page 12)
Overview
HP AD278A/AD279A PCI MUX is a high-speed serial communication multiple port product. It
combines various signals for transmission over a single channel, and provides intelligent
communication functions to off-load CPU serial communication processing tasks. The multiple
ports connect different peripheral devices for communication.
AD278A/AD279A PCI Multiplexer Components
Table 1-1 to Table 1-4 list components of HP AD278A/AD279A PCI MUX product and their part
numbers. All the components are Restriction of Hazardous Substance (RoHS) compliant.
Table 1-1 PCI MUX 8-Port Adapter AD278A Solution
Part NumberComponent Name
AD278-60001HP PCI MUX 8-port serial adapter
AD278-2000A4 feet (1.21920 metre) Octopus Cable and DB 25 Loop back
AD278-2001ADB25-RJ45 Conversion Kit
Table 1-2 lists the AD279A PCI MUX 64-port adapter solution components.
Table 1-2 AD279A PCI MUX 64-Port Adapter Solution
Part NumberComponent Name
AD279-60001HP PCI MUX 64-port serial adapter
AD279-2000A5 feet (1.52400 metre) External Bus Interface (EBI) cable
Table 1-3 PCI MUX AD280A RJ45 Port Module
Part NumberComponent Name
AD280-2000AHP 16 port RS-232 RJ45 port module
Table 1-4 PCI MUX AD281A DB25 Port Module
Part NumberComponent Name
AD281-2000AHP 16 port RS-232 DB25 port module
AD278A/AD279A PCI MUX Adapters
AD278A/AD279A PCI MUX adapters are supported only on the PCI slots. Table 1-5 lists the
types of MUX adapters.
Overview 9

Table 1-5 HP PCI MUX Adapter Types
Number of
Ports
Bus VoltageCard Type
and Speed
Maximum Port
Speed
InterfaceDescriptionProduct
Number
83.3 V and 5.0 VPCI 33MHz115.2 kbpsFan-Out CableHP AD278A PCI
MUX 8-port serial
adapter
AD278A
16 to 643.3 V and 5.0 VPCI 33MHz38.640 kbpsPort ModulesHP AD279A PCI
MUX 64-port serial
adapter
AD279A
Every AD278A/AD279A PCI MUX adapter card has processors that control the flow of data
through multiple communication ports.
AD278A PCI MUX 8-Port Adapter
The AD278A PCI MUX 8-port adapter can control the operations of up to eight high speed serial
ports. It works on both 3.3 V and 5 V systems. For more information, see “Card Specifications”
(page 29). The AD278A PCI MUX 8-port adapter supports a fan out cable as an interface.
Figure 1-1 shows AD278A PCI MUX 8-port adapter.
Figure 1-1 AD278A PCI MUX 8-Port Adapter
AD279A PCI MUX 64-Port Adapter
The AD279A PCI MUX 64-port adapter can control the operations of up to 64 high speed serial
ports. It works on both 3.3 V and 5 V systems. For more information, see “Card Specifications”
(page 29). The AD279A PCI MUX 64-port adapter supports 16 to 64 ports by using up to four
external port modules, to be ordered separately.
Figure 1-2 shows AD279A PCI MUX 64-port adapter.
Figure 1-2 AD279A PCI MUX 64-Port Adapter
10 Introduction

Port Modules
A port module is an interface between the AD279A PCI MUX 64-port adapter and the RS-232
peripheral device. Table 1-6 lists the port modules that can be connected to the AD279A PCI
MUX 64-port adapter.
Table 1-6 Port Modules
Number of PortsInterfaceDescriptionProduct Number
16RS-232 RJ-45HP 16-port RS 232 RJ-45 port moduleAD280A
16RS-232 DB-25HP 16-port RS 232 DB-25 port moduleAD281A
Each AD279A PCI MUX 64-port adapter supports a maximum of four port modules (64 ports)
connected together. The RS-232 RJ45 port module (AD280A) and RS-232 DB25 port module
(AD281A) can be intermixed using an EBI cable. The DB25 connectors are male.
NOTE: The pin assignments on the RJ-45 ports are incompatible with the RJ-45 pin assignments
used on the older A6748A/A6749A PCI MUX products.
Cables used to connect port modules two, three, and four are known as EBI cables. Each EBI
cable is one feet (0.30480 metre) in length. The RJ45 and DB25 port modules use the same EBI
cable. The AD280A and the AD281A use the same power supply (AD280-2001A).
NOTE: The AD279A PCI MUX 64-port adapter can support 2 port modules or up to 32 port
configurations without the port module power supply. The port module power supply is required
on the third port module and the fourth port module or 33 through 64 port configurations.
Figure 1-3 shows a PCI MUX 16-port RS-232 RJ45 port module.
Figure 1-3 RS-232 RJ45 Port Module
Table 1-7 lists the metrics equivalent.
Table 1-7 Metrics Equivalent
CentimetreInches
30.48012
17.7807
5.7152.25
Figure 1-4 shows a PCI MUX 16-port RS-232 DB25 port module.
AD278A/AD279A PCI Multiplexer Components 11

Figure 1-4 RS-232 DB25 Port Module
Table 1-8 lists the metrics equivalent.
Table 1-8 Metrics Equivalent
CentimetreInches
10.6684.2
Fan-Out Cable for AD278A PCI MUX 8-Port Adapter
A fan-out cable is an interface between AD278A PCI MUX 8-port adapter and RS-232 peripheral
devices. The fan-out cable has a DB78 connector at one end. This end is connected to the AD278A
PCI MUX 8-port adapter. The other eight ends of the cable have DB25 male connectors. Therefore
an F-F gender changer is required if the device cabling uses male DB-25 connectors.
Figure 1-5 shows AD278A PCI MUX 8-port adapter fan-out cable.
Figure 1-5 Fan-Out Cable for AD278A PCI MUX 8-Port Adapter
The RJ-45 to DB-25 adapter cables can be built and used to connect the fan out cable ports to
various peripheral devices.
Power Supply for Port Modules
The first and second port modules connected to a AD279A PCI MUX 64-port adapter do not
require power supply. However, the third and fourth port modules require seperate power
supply. The power supply requires 110-220 V and 50-60 W AC input.
Figure 1-6 shows the external power supply (AD280-2001A) for the port modules.
12 Introduction

Figure 1-6 Power Supply
NOTE: Third and fourth port modules require a seperate power supply.
AD278A/AD279A PCI Multiplexer Components 13

14

2 Troubleshooting
This chapter describes how to use the pmux_diag diagnostic utility. It also describes how to
troubleshoot the terminal, printers, and modem installation problems after the ports are configured
and enabled.
This chapter addresses the following topics:
“The pmux_diag Utility” (page 15)
“The pmux_diag Utility Conventions” (page 15)
“Driver Status Menu Selections” (page 16)
“Port Status Menu Selections” (page 19)
“Quit” (page 24)
“Excessive Frequent getty Spawning” (page 25)
“Terminal Login Problems” (page 25)
“Printer Problems” (page 26)
“Connecting a Modem” (page 27)
“System Crashes or Panics” (page 28)
The pmux_diag Utility
The pmux_diag utility is a stand-alone program that supports diagnostic operations. All diagnostic
operations are supported by the pmux_diag utility in the current release.
Starting pmux_diag Utility
To start the pmux_diag utility, complete the following steps:
1. Log in to the system as super user.
2. Run the following command at the command prompt:
$ /usr/bin/pmux_diag
3. Press Enter. The main menu displays the following options:
• Driver Status
• Port Status
• Diagnostics
• Quit
The pmux_diag Utility Conventions
Table 2-1 lists the conventions used to run the pmux_diag utility.
Table 2-1 pmux_diag Key Conventions
PurposeKeys
To move between menus and menu selections.Arrow
To move out of sub-menusEsc (escape)
To select the highlighted menu itemReturn
To display a context sensitive helpF1
Exiting pmux_diag Utility
To exit the pmux_diag utility, complete the following steps:
The pmux_diag Utility 15

1. Select Quit on the main menu.
2. Press Enter.
Driver Status Menu Selections
The Driver Status drop down menu displays the following selections:
• Driver Status
• Board Status
• Counters
• Topology
Figure 2-1 shows the Driver Status selection.
Figure 2-1 pmux_diag utility Driver Status main menu
NOTE: The pmux_diag utility version number is of the form B.x.xxxx
Where:
x - represents the release number, for example, 11.31.
xxxx - represents the AR release number or the version number for a Web release or OS initial
release.The AR release number can be 0609, 0612, and so on. The version number for a Web
release or OS initial release can be 01, 02, and so on.
Driver Status
The Driver Status sub-menu enables you to view the device driver version. The Driver Status
sub-menu is enabled by default. To view the version of the device driver, press Enter.
Figure 2-2 shows the device driver version.
16 Troubleshooting

Figure 2-2 Driver Status Display
Board Status
The Board (card) Status sub-menu enables you to view card specific information such as the card
type, buffer block starting location, buffer size, and bus slot location. To view the card specific
information, select Board Status sub-menu and press Enter. Information about additional boards,
if any, is also displayed.
Figure 2-3 shows the Board Status Display.
Figure 2-3 Board Status Display
Counters
The Counters sub-menu allows you to monitor in realtime the selected board's (or module's )
transmit and receive activity. The values displayed are the accumulated totals since the system
was booted or since the last reset counters were issued.
Figure 2-4 displays port groups.
Driver Status Menu Selections 17

Figure 2-4 Select Port Group Display
Highlight the desired group (for example, ports a1 through a16) and press Enter. Up to sixteen
ports are displayed at a time.
Figure 2-5 displays port group communication.
Figure 2-5 Selected Group Communications Monitor Display
Topology
The Topology sub-menu allows you to troubleshoot problems related to the host cable. To view
the host adapter card and port modules attached to it, select Topology sub-menu and press Enter.
A pictorial representation of a host adapter card and port modules attached to it is displayed.
To exit Topology, press Esc.
Figure 2-6 displays the topology of the host adapter card and the port modules attached to it.
18 Troubleshooting

Figure 2-6 Topology Display
Port Status Menu Selections
The second menu selection on the main menu is Port Status. The Port Status drop down menu
displays the following selections:
• Breakout Box
• Data Scope
• Termio
• Register Dump
Breakout Box
The Breakout Box sub-menu allows you to do real time monitoring of data and control signal
leads, calculated received and transmitted rates and cumulative bi-directional character counts.
Figure 2-7 shows the port name of the selected device.
Figure 2-7 Breakout Box Device Name Selection Display
If the port name displayed in the device selection box is incorrect, enter the correct port name in
the space provided on the screen.
Port Status Menu Selections 19

Press Enter or use the arrow key to select Data Scope. The lead status for the selected port is
displayed.
Figure 2-8 shows lead status for the selected port.
Figure 2-8 Breakout Box Display
This selection displays the RS-232 lead status. You can check for modem CD problems as well
as the status of output flow-control. Additionally, transmit rate, receive rate, total characters
received, total characters transmitted and buffered data counters are also displayed.
Data Scope
The Data Scope setup screen allows you to establish the parameters that identify the data selected
for display.
To view realtime window of the on board memory, select Data Scope and press Enter.
To view the datascope parameter setup display, perform the following steps:
• Select the Device Port Name (that is, /dev/tty3al).
• Select the type of monitor you want [INPUT, OUTPUT, FULL DUPLEX].
• Select the Buffer Full options [Continue, Stop].
• Select the Display Options [Data Only, Show Detail].
• Highlight Start Scope and press Return key to display actual data.
Figure 2-9 shows the Data Scope Parameter Setup display.
20 Troubleshooting
