8-Port Serial PCI ACC Multiplexer
Installation and User’s Guide
HP e3000 MPE/iX Computer Systems
Edition 1
Manufacturing Part Number: 30291-90508
E0201
U.S.A. February 2001

2
Notice
The information contained in this document is subject to change
without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability or fitness for a particular purpose. Hewlett-Packard
shall not be liable for errors contained herein or for direct, indirect,
special, incidental or consequential damages in connection with the
furnishing or use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of
its software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information which is protected by
copyright. All rights reserved. Reproduction, adaptation, or translation
without prior written permission is prohibited, except as allowed under
the copyright laws.
Restricted Rights Legend
Use, duplication, or disclosure by the U.S. Government is subject to
restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in
Technical Data and Computer Software clause at DFARS 252.227-7013.
Rights for non-DOD U.S. Government Departments and Agencies are
as set forth in FAR 52.227-19 (c) (1,2).
Acknowledgments
UNIX is a registered trademark of The Open Group.
Hewlett-Packard Company
3000 Hanover Street
Palo Alto, CA 94304 U.S.A.
© Copyright 2001 by Hewlett-Packard Company

Contents
3
1. Overview
Multiplexer Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Multiplexer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8-Port PCI Multiplexer Maximum Baud Rates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Multiplexer Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Multiplexer Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Multiplexer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Interchange Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Rack Mounting Plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
HP Z7325A MUX/Interchange Panel Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Octopus Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Interchange Panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Overview of the Interchange Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
RS-232 Interchange Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
V.35 Interchange Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2. Hardware Installation
Unpacking and Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Anti-Static Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Installing the 8-Port PCI ACC Multiplexer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Replacing Interchange Panel(s). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Storing the 8-Port PCI ACC Multiplexer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3. Configuration
Configuration of Clock Source Using NMMGR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
A. Interchange Panels
Interchange Panels, Signals and Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
RS-232 Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
V.35 Loopback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
B. Regulatory/Safety Statements
FCC EMI Statement (USA Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Industry Canada EMI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Europe EMI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Telecommunications Europe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4
Contents

Figures
5
Figure 1-1. Block Diagram of the 8-Port PCI ACC Multiplexer . . . . . . . . . . . . . . . . . . . . . 10
Figure 1-2. HP Z7340A 8-Port PCI ACC Card with Interchange Panels. . . . . . . . . . . . . . 11
Figure 1-3. HP Z7325A Cable Connector (Male) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 1-4. HP Z7340A 8-Port PCI ACC Card with Octopus Cable. . . . . . . . . . . . . . . . . . 12
Figure 1-5. Z7321A RS-232 Interchange Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 1-6. Supported RS-232 Signals (Panel Connectors). . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 1-7. Z7322A V.35 Interchange Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 1-8. Supported V.35 Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 2-1. Rack Mounting Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 2-2. Rack Mounting Plate In Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 2-3. MUX Card Bulkhead with Self Test Indicator. . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure A-1. RS-232 Loopback Cable Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure A-2. V.35 Loopback Cable Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

6
Figures

Tables
7
Table 1-1. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 2-1. MUX Card LED Display Interpretation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 3-1. Clock Source Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table A-1. Pin Out Chart for Interchange Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

8
Tables

9
1Overview
Multiplexer Overview
The Advanced Communications Controller (ACC) Subsystem is an
intelligent serial communication product for HP e3000 Workstations
and Servers. It provides a high performance Wide Area Network (WAN)
platform for customers who have large synchronous and asynchronous
networks. A complete HP ACC subsystem consists of both the
multiplexer hardware and ACC software. This manual describes the
8-port PCI ACC Multiplexer hardware. This multiplexer is compatible
with the Peripheral Component Interface (PCI) format. Refer to the
manuals provided with your ACC software products for information on
the ACC software.
Multiplexer Features
The major features of the HP multiplexer are:
• Serial communications at high speeds.
• Ideally suited for Wide Area Networks (WAN).
• Data rates configurable up to 128k baud on RS-232 and V.35 ports.
• Synchronous support.
• Support of the following telecommunications protocols:
— LAPB
— HDLC normal mode (SDLC)
— HDLC-Level 1
• Level 1 support for RS-232 and V.35.
• Each port can be set to the following modes.
— RS-232
— V.35
— Differential Loopback

10 Chapter1
Overview
Multiplexer Overview
8-Port PCI Multiplexer Maximum Baud Rates
Although the ACC MUX card can handle rates above 19.2 Kbps for
RS-232 and 64 Kbps for V.35, it is the customer’s responsibility to
ensure that the cable type and length are chosen appropriately.
Per Port RS-232 128 Kbps
V.35 128 kbps
Aggregate RS-232 1024 Kbps
V.35 1024 kbps
Multiplexer Architecture
The 8-port PCI ACC Multiplexer is an intelligent microprocessor-based
interface that supports a wide variety of serial data communication
protocols. The architecture allows the protocols to be implemented as
downloaded modules which enhance the flexibility of the interface. The
multiplexer has sufficient memory to provide data buffering and
configuration tables, as well as space for multiple downloaded protocol
modules. Figure 1-1 shows a functional block diagram of the
multiplexer card.
Figure 1-1 Block Diagram of the 8-Port PCI ACC Multiplexer
Primary
PCI Bus
64K
ROM
SIPEX 505
Transceiver
SIPEX 505
Transceiver
SIPEX 505
Transceiver
SIPEX 505
Transceiver
DSCC4
Serial Controller
Secondary
PCI Bus
16mb
RAM
Intel i960RD
I/O Processor
PCI Bridge
lattice
1032
PLD SIPEX 505
Transceiver
SIPEX 505
Transceiver
SIPEX 505
Transceiver
SIPEX 505
Transceiver
DSCC4
Serial Controller

Chapter 1 11
Overview
Multiplexer Overview
Multiplexer Hardware Requirements
The 8-port PCI ACC multiplexer consists of the major hardware
components described in Figure 1-2 and shows the components and how
they combine to provide the functionality of the ACC subsystem.
Figure 1-2 HP Z7340A 8-Port PCI ACC Card with Interchange Panels
NOTE Interchange panels and cables are not included with the Z7340A 8-port
PCI ACC product. These must be ordered separately. Refer to the
section on “Accessories” for a list of interchange panel and cable
products.
Multiplexer
The multiplexer (or MUX) installs as an I/O interface card in the
HP e3000 computer. The MUX is a one-half length PCI card, which
supports eight synchronous or asynchronous ports at speeds up to
128 Kbps on RS-232 and V.35 ports.
Interchange Panel
An Interchange Panel acts as an intermediary between the MUX and
the Packet Switching Network (PSN). Each individual interchange
panel is designed for a specific serial communications standard, such as
RS-232, and V.35 specifications.
Rack Mounting Plate
A rack mounting plate allows up to two interchange panels to be
mounted in the HP e3000 computer system’s rack. Panels can be
mounted in any orientation.
Interchange Panels
8-port PCI ACC
Multiplexer
HP e3000 System
with PCI Backplane
PCI Bus Slot Cable (160-pin)
Z7340A
Z7325A RS-232
(Z7321A)
V.35
(Z7322A)

12 Chapter1
Overview
Multiplexer Overview
HP Z7325A MUX/Interchange Panel Cable
The MUX connects to the interchange panel by a 160-conductor
(28 AWG) cable, three meters (10.77 feet) in length. The cable has male
connectors on each end, refer to Figure 1-3. The signals for each of the
pins are listed in Appendix A , “Interchange Panels.”
Figure 1-3 HP Z7325A Cable Connector (Male)
Octopus Cables
Two-meter octopus cables with a 160-conductor connector on one end
and eight RS-232 or V.35 female connectors on the other end are also
available for connecting the MUX and the Packet Switching Network.
This cable replaces the 160-conductor cable and interchange panels for
RS-232 or V.35 connections. Figure 1-4 shows the MUX card with an
octopus cable.
NOTE The octopus cables do not support dual configuration (high-availability
systems). You must use the 160-conductor cable and interchange panel
to implement the dual configuration feature if you require an highly
available system.
Figure 1-4 HP Z7340A 8-Port PCI ACC Card with Octopus Cable
Pin 1
Pin 80
Pin 81
Pin 160
Pin 40
Pin 41
Pin 120
Pin 121
8-port PCI ACC
Multiplexer
HP e3000 System
with PCI Backplane
PCI Bus Slot
Octopus Cable
Z7340A
160-Conductor Connector
RS-232 or V.35 Connectors

Chapter 1 13
Overview
Accessories
Accessories
Table 1-1 lists the accessories available for the 8-port PCI ACC
multiplexer.
Table 1-1 Accessories
Part Number Description
Interchange Panels — Each interchange panel product includes the
interchange panel, MUX/interchange panel cable, rack-mounting plate, and
loopback test kit.
Z7321A RS-232 Interchange Panel for PCI ACC
Z7322A V.35 Interchange Panel for PCI ACC
MUX/Interchange Panel Cable
Z7325A 3-Meter, 160-Conductor Cable
Octopus Cables — Each octopus cable product includes the octopus cable
and loopback test kit.
Z7326A 2-Meter V.35 Octopus Cable
Z7327A 2-Meter RS-232 Octopus Cable
Loopback Cables
Z7223--60002 RS-232 Loopback Cable
Z7363-63001 V.35 Loopback Cable
Rack Mounting Plate
Z7340-00002 Rack Mounting Plate for Interchange Panels

14 Chapter1
Overview
Interchange Panels
Interchange Panels
Overview of the Interchange Panels
The Multiplexer is designed to connect to an interchange panel, which
“breaks out” the signal into the ports. These panels are “passive”
distribution panels, accepting the input from the MUX and distributing
it to the network.
This section describes the various models of interchange panels that
are compatible with the 8-port PCI ACC product. Each interchange
panel is designed for a specific serial communications standard.
The following interchange panels that are compatible with the 8-port
PCI ACC Multiplexer. Individual illustrations for each of the
interchange panels appear later in this section.
Z7321A RS-232 Interchange Panel, refer to Figure 1-5.
Z7322A V.35 Interchange Panel, refer to Figure 1-7.

Chapter 1 15
Overview
Interchange Panels
RS-232 Interchange Panel
The RS-232 Interchange Panel is shown in Figure 1-5.
Figure 1-5 Z7321A RS-232 Interchange Panel
The signals supported on the RS-232 panels are in Figure 1-6.
Figure 1-6 Supported RS-232 Signals (Panel Connectors)
J0J1J2J3 P1
J4J5J6J7 P2
Z7321A
RS-232 INTERCHANGE PANEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
TxD
RxD
RTS
GND
DCD
TxC
RxC
DTR
ETC
Signal Pin SignalPin
CTS

16 Chapter1
Overview
Interchange Panels
V.35 Interchange Panel
The V.35 Interchange Panel is shown in Figure 1-7.
Figure 1-7 Z7322A V.35 Interchange Panel
J0J1J2J3 P1
J4J5J6J7 P2
Z7322A
V.35 INTERCHANGE PANEL

Chapter 1 17
Overview
Interchange Panels
The signals supported on the V.35 panels are shown in Figure 1-8.
Figure 1-8 Supported V.35 Signals
B
D
F
L
I
R
T
V
X
A
C
E
H
K
BB AA
Y
W
U
S
P
TxCb
TxCa
ETCb
ETCa
DTR
GND
DCD
CTS RTS
RxCb
RxCa
RxDb
RxDa TxDb TxDa
Signal Pin SignalPin

18 Chapter1
Overview
Interchange Panels

19
2Hardware Installation
This chapter describes how to install the 8-port PCI ACC Multiplexer
and the interchange panel hardware for HP e3000 Workstations and
Servers with a PCI backplane

20 Chapter2
Hardware Installation
Unpacking and Handling
Unpacking and Handling
If evidence of damage is observed when the carton containing the
product is opened, inspect all items carefully, keep the shipping carton
and packing material for the carrier’s inspection.
If any item appears to be damaged, or if the product does not pass
verification procedures described in this chapter, notify the nearest HP
Sales and Support Office. Arrangements for the repair or replacement
of the defective item(s) will be made without waiting for settlement of
possible claims against the carrier.
Save the shipping carton and packing material after unpacking the
product. These will be useful in the event that any item must be
returned to Hewlett-Packard.
WARNING Before installing the ACC Multiplexer, be sure to refer to the
computer’s manual that details the installation of accessories.
To avoid severe personal injury, pay particular attention to
Warnings and Cautions related to hazards exposed when
opening covers in the computer. Because of the risk of electric
shock or exposure to high-energy (high-amperage) circuits,
some computers require that accessories be installed by
persons qualified in the installation and servicing of computer
equipment and who are trained to recognize the hazards
involved.
