HP 615N - JetDirect Print Server Manual

hp jetdirect
615n/610n/600n
Print Server
hardware
installation
guide
HW6xxfrontEN.ai black + PMS 660 + registration

Hardware Installation Guide
This guide is provided in a PDF format that is
compatible with screen readers used for
accessibility.
HP Jetdirect 615N/610N/600N
Print Server

©Copyright Hewlett-Packard
Company 2001. All rights reserved.
Reproduction, adaptation or translation
without prior written permission is
prohibited, except as allowed under
the copyright laws.
Publication number
5971-3231
First Edition December 2001
Applicable Products:
J3110A (600N)
J3111A (600N)
J4167A (610N)
J4169A (610N)
J6057A (615N)
Trademark Credits
Microsoft®, MS-DOS®, Windows®,
Microsoft Windows NT®are trademarks
or U.S. registered trademarks of Microsoft
Corporation. NetWare®and Novell®
are registered trademarks of Novell
Corporation. IBM®, AIX®are registered
trademarks of International Business
Machines Corp. Ethernet is a registered
trademark of Xerox Corporation.
PostScript®is a trademark of Adobe
Systems, Incorporated. UNIX®is a
registered trademark of the Open Group.
Disclaimer
The information contained in this
document is subject to change without
notice.
HEWLETT-PACKARD COMPANY
MAKES NO WARRANTY OF ANY KIND
WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.
Hewlett-Packard shall not be liable for
errors contained herein or for incidental
or consequential damages in connection
with the furnishing, performance or use
of this material.
Customer Support
For assistance, visit HP Customer Care
Online at:
http://www.hp.com/support/net_printing
or refer to HP Customer Care By Phone
described in the Quick Start Guide
supplied with this product.
Warranty and Service
For product warranty and service
information, refer to the Quick Start
Guide supplied with this product.
A copy of the specific warranty terms
applicable to your HP product and
replacement parts can be obtained from
your HP Sales and Service Office or
Authorized dealer.
Safety Considerations
Prior to the installation and use of this
product, review all safety markings and
instructions.
Do not proceed beyond a WARNING or
Caution notice until you have understood
the hazard and have taken appropriate
steps.
Grounding. This product is installed in a
safety class 1 product that has a protective
earthing terminal. There must be an
uninterrupted safety earth ground from
the main power source to the product’s
input wiring terminals, power cord or
supplied power cord set. Whenever it
is likely that the protection has been
impaired, disconnect the power cord
until the ground has been restored.
Hewlett-Packard Company
8000 Foothills Boulevard
Roseville, California 95747-6588
Instruction Manual
Symbol. If the product
is marked with this
symbol, refer to the
product manuals to
protect the product
from damage.
WARNING Denotes a hazard that
can cause injury
CAUTION Denotes a hazard that
can damage equipment
or data.
!

5
Table of Contents
1. Introduction
Supported Network Protocols . . . . . . . . . . . . . . . . . . . 1-8
Supported Printers . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Related Documentation. . . . . . . . . . . . . . . . . . . . . . . . 1-9
2. Installing the Print Server
What You Need for Installation . . . . . . . . . . . . . . . . . 2-11
Step 1. Identify Your HP Jetdirect 615N/610N/600N
Internal Print Server . . . . . . . . . . . . . . . . . . . . . . 2-12
Step 2. (J4167A Only) If Necessary,
Set the Token Ring Data Rate Switch . . . . . . . . . 2-14
Step 3. Before Installing the Card,
Verify That Your Printer Works . . . . . . . . . . . . . 2-15
Step 4. Turn Off Your Printer and Insert the Card . . 2-16
Step 5. Verify That the HP Jetdirect Card
is Operating Properly. . . . . . . . . . . . . . . . . . . . . . 2-18
Step 6. Configure the Card with Network Parameters
Required for Your Network . . . . . . . . . . . . . . . . . 2-21
Step 7. Install the Printer On Your System
(If Not Already Installed) . . . . . . . . . . . . . . . . . . . 2-22
3. 10/100Base-TX Link Configuration
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
Link-Speed LEDs . . . . . . . . . . . . . . . . . . . . . . 3-24
Link Troubleshooting . . . . . . . . . . . . . . . . . . . 3-24

6
A. Network Configuration Notes
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-27
Enabling or Disabling Network Protocols . . . A-27
To Restore Factory Default Values . . . . . . . . A-28
HP Jetdirect EIO Menu . . . . . . . . . . . . . . . . . . . . . . . . A-29
Classic Control Panel . . . . . . . . . . . . . . . . . . . A-30
Graphical Control Panel . . . . . . . . . . . . . . . . . A-32
Configuring IPX Frame Types . . . . . . . . . . . . A-34
Configuring IPX Source Routing (Token Ring
Cards Only) . . . . . . . . . . . . . . . . . . . . . . . . A-34
Configuring TCP/IP Parameters . . . . . . . . . . A-34
Configuring Apple EtherTalk Phase Parameters
(600N Ethernet Cards Only) . . . . . . . . . . A-35
B. Specifications and Regulatory Statements
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-37
Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . B-38

Introduction 1-7
ENWW
1
Introduction
The HP Jetdirect 615N/610N/600N family of internal print servers
are network interface cards for HP Enhanced I/O (EIO) printers and
MFP (multifunction peripheral) products. With an HP Jetdirect
print server, you can connect and share your printer anywhere on
your network and print at network speeds.
A typical network using an HP Jetdirect 615N/610N/600N print
server is illustrated below. The card must first be installed into the
printer and connected to the network. Then, you must configure the
card for network operation.
●To configure the card, you can use the HP Jetdirect printer
installation and setup software. Refer to the HP Jetdirect
software installation instructions included with this product.
●Alternatively, for printers equipped with a control panel, you
can use the printer’s control panel to configure basic network
parameters. See Appendix A.
HP Jetdirect 615N/610N/600N

1-8 Introduction ENWW
Supported Network Protocols
Supported
Network
Protocols
Network Printing Environments* HP
Jetdirect
Product
TCP/IP Microsoft Windows 95/98/Me/NT4.0/2000/XP
Novell NetWare 5 via NDPS
UNIX and Linux, including:
Hewlett-Packard HP-UX, Sun
Microsystems Solaris (Sun
SPARCsystems only), IBM AIX**,
HP MPE-iX**, RedHat Linux, SuSE Linux
LPD (line printer daemon)
IPP (Internet Printing Protocol)
J3110A
J3111A
J4167A
J4169A
J6057A
IPX/SPX and
compatible Novell NetWare
Microsoft Windows 95/98/Me/NT4.0/2000/XP J3110A
J3111A
J4167A
J4169A
J6057A
EtherTalk Mac OS J3110A
J3111A
J4169A
J6057A
LocalTalk Mac OS J3111A
DLC/LLC Microsoft Windows NT**
Artisoft LANtastic** J3110A
J3111A
J4167A
J4169A
J6057A
* Refer to the current HP Jetdirect product data sheets for supported
network versions. For other networks, consult your system vendor or
authorized HP dealer.
**Contact your network system vendor for software, documentation, and
support.

Introduction 1-9
ENWW
Supported Printers
The HP Jetdirect 615N/610N/600N print servers are supported in
all HP printers and multifunction peripheral devices (MFPs)
with Enhanced Input/Output (EIO) slots, such as:
■HP LaserJet EIO printers and MFPs
■HP Color LaserJet EIO printers and MFPs
■HP DesignJet EIO large format printers
■HP Business InkJet EIO printers
For most of these printers, you can use the printer’s control panel
to configure basic network parameters on the HP Jetdirect
615N/610N/600N internal print server. Refer to Appendix A.
Note For installation procedures or limitations in
peripheral devices not covered in this guide, refer
to the manuals supplied with the peripheral device.
Related Documentation
Additional documentation for installation, configuration and
management of HP Jetdirect EIO print servers are located on the
HP Jetdirect CD-ROM:
●HP Jetdirect Print Servers Administrator’s Guide (Models
610N/615N)
Note This guide is provided in a PDF format that is
compatible with screen readers used for
accessibility.
●HP Jetdirect Print Servers 600N/400N/500X/300X
Administrator’s Guide

1-10 Introduction ENWW

Installing the Print Server 2-11
ENWW
2
Installing the Print Server
What You Need for Installation
●The proper HP Jetdirect print server, documentation, and
software for your network.
●The proper network cables and connectors for connecting the card
and printer to your network.
●A static-safe environment for handling the card.
CAUTION HP Jetdirect cards contain electronic
components that can be damaged by static
electricity through electrostatic discharge
(ESD). To prevent ESD damage, maintain frequent
contact with any bare sheet metal surface on the
printer. A grounding wrist strap (or similar device)
is useful for this purpose. Handle the card carefully
at all times. Avoid touching electronic components
or circuit paths.

2-12 Installing the Print Server ENWW
Step 1. Identify Your HP Jetdirect
615N/610N/600N Internal
Print Server
Remove the HP Jetdirect card from its packaging and verify that
you have the correct card for your network.
HP J3110A (600N) for Ethernet
and IEEE 802.3 Type 10Base-T
networks (10 Mbps).
This card provides a single
RJ-45 connector for networks
that use unshielded twisted-pair
cables.
HPJ3111A(600N)forEthernet,
IEEE 802.3 Type
10Base-T/10Base-2 networks
(10 Mbps), and LocalTalk
networks.
This card provides an RJ-45
connector for networks that use
unshielded twisted-pair cables,
a BNC connector for ThinLAN
coaxialcables,andaMini-DIN8
connector for a LocalTalk
connector box.
You can use the LocalTalk port and only
one Ethernet port: RJ-45 or BNC.

Installing the Print Server 2-13
ENWW
HP J4167A (610N) for Token
Ring (IEEE 802.5) networks. A
Data Rate switch selects
operation for 4-Mbps or 16-
Mbps Token Ring networks.
This card provides an RJ-45
connector for networks that use
unshielded twisted-pair cables,
and a DB 9 connector for Type
1, 2 or 6 shielded twisted-pair
cables. You can use only one Token Ring port:
RJ-45 or DB 9.
HP J6057A (615N) or J4169A
(610N) for Ethernet, IEEE 802.3
Type 10Base-T or IEEE 802.3u
Type 100Base-TX networks.
The card autonegotiates
operationat10or100Mbps,full-
or half-duplex mode, but can be
manually set through the
printers control panel.
This card provides a single
RJ-45 connector for networks
that use unshielded twisted-pair
cables.
To manually set link operation, see
Appendix A.
Data Rate Switch

2-14 Installing the Print Server ENWW
Step 2. (J4167A Only) If Necessary, Set
the Token Ring Data Rate Switch
●If you have an HP J4167A 610N Token Ring print server,
you must set the Data Rate switches on the card to either 4 Mbps
or 16 Mbps. The selection depends on the data rate of your
Token Ring network.
a. Locate the Token Ring card Data Rate switches.
b. Set the switches to 4 or 16 Mbps. The default is 16 Mbps.
4 Mbps 16 Mbps

Installing the Print Server 2-15
ENWW
Step 3. Before Installing the Card,
Verify That Your Printer Works
To verify that your printer is working properly, print a Printer
Configuration page. The Printer Configuration page will display the
operating status of the printer.
The steps to print a Printer Configuration page varies with each
printer. Some printers provide a menu map to help you navigate
the printer’s control panel to print a Printer Configuration page.
See your printer documentation for specific instructions.
Note The name of the Printer Configuration page may
also vary by printer. For example, HP DesignJet
printers provide a “Service Configuration print”
that displays status information.

2-16 Installing the Print Server ENWW
Step 4. Turn Off Your Printer and
Insert the Card
Figure 2-1 Typical Card Installation and Network Connection
1. Turn off the printer.
2. Identify an available HP Enhanced I/O (EIO) slot (typically, in
the back of the printer).
Note You can install the card into any EIO slot in the
HP printer.
3. If the slot has a cover plate, remove it.
4. Insert the card. Align the card with the guide rails in the slot.
5. Press the card into the slot until firmly seated and tighten each
retaining screw a little at a time until both screws are secure.
6. Connect the network cable to the card.
RJ-45 BNC

Installing the Print Server 2-17
ENWW
Note For the HP J3111A 600N Ethernet card, you can
connect to the LocalTalk port and to only one of the
Ethernet ports (RJ-45 or BNC).
For the HP J4167A 610N Token Ring card, you can
connect to only one of the Token Ring ports
(RJ-45 or DB 9).
7. Turn on the printer.

2-18 Installing the Print Server ENWW
Step 5. Verify That the HP Jetdirect
Card is Operating Properly
1. Print another Printer Configuration Page (or Service
Configuration print) as described previously in (page 15) and
verify that Jetdirect Configuration Page information also prints.
In HP LaserJet printers, a Jetdirect Configuration Page will
print for each EIO slot that contains an HP Jetdirect card.
In HP DesignJet printers, Jetdirect configuration information
will be included on the Service Configuration print.
2. In the General Information section of the Jetdirect
Configuration Page, locate the message “I/O CARD READY”.
This section of the configuration page also contains product-
specific information, such as:
■HP Jetdirect product number
■Firmware revision number
■LAN Hardware (MAC) address
■Manufacturing identification number
Note For a description of other messages that may appear
on the Jetdirect Configuration Page, refer to the
applicable HP Jetdirect Administrator’s Guide
located on the HP Jetdirect CD-ROM.

Installing the Print Server 2-19
ENWW
Figure 2-2 Example of HP Jetdirect Configuration Page
3. If I/O CARD READY appears, the card has been installed
successfully. Proceed to “Step 6. Configure the Card with
Network Parameters Required for Your Network.”
4. If I/O CARD READY does not appear, check that you have:
■Installed the card correctly and properly connected the card
to the network
■Verified that the network is operating properly
■Turned the printer off and then on again
(600N)
I/O CARD READY
(615N/610N)
I/O CARD READY

2-20 Installing the Print Server ENWW
Note For HP J6057A 615N or J4169A 610N
10/100Base-TX cards: See Chapter 3 in this guide
for link configuration and troubleshooting
information.
For HP J3111A (600N) LocalTalk-Only
Customers: If you are not connected to an
Ethernet network, “I/O CARD NOT READY”and
“LAN ERROR - EXTERNAL LOOPBACK”
messages may appear. These messages should stop
appearing after three minutes. To eliminate the
messages, attach an Ethernet loopback connector to
one of the Ethernet ports.
For persistent problems, refer to the troubleshooting sections in the
applicable HP Jetdirect Administrator’s Guide supplied
electronically on the HP Jetdirect CD-ROM.
