Product End-of-Life Disassembly Instructions
Product Category: Servers
Marketing Name / Model
[List multiple models if applicable.]
HPE XL270d GEN10 NODE SERVER
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HPE products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
11
Batteries
All types including standard alkaline and lithium
coin or button style batteries
2
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface
greater than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
0
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
2
External electrical cables and cords
4
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0

MF877-00 Page 2
Template Revision A
HPE instructions for this template are available at MF877-01
Item Description
Notes
Quantity
of items
included
in product
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screwdriver
T15
Screwdriver
T10
Screwdriver
T25
Philpsdriver
#2
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Board Battery - Locate the battery on the system board. Use a medium flat head screwdriver or fingers to
remove the battery and dispose of properly.
2. Megacell Module –Remove the top cover and locate the megacell on the system. Remove the magecell and dispose of
properly.
3. Capacitors>2.5 cm - Remove the PSU from the system. With screw driver, remove the screws securing the top cover,
locate the capacitors and use a medium flat head screwdriver to remove them and dispose of properly.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Attachment 1
Attachment 1 –System Battery Location
Attachment 2 –Megacell Module Location
Attachment 3 –Super Cap Location in PSU

MF877-00 Page 3
Template Revision A
HPE instructions for this template are available at MF877-01
Remove Battery
Attachment 2
Remove Megacell Module
Attachment 3

MF877-00 Page 4
Template Revision A
HPE instructions for this template are available at MF877-01
Model: MC2200B4-3-3R1-02
Remove capacitor
