Regulatory Information
iv

Regulatory Information
Regulatory Notices - Electromagnetic Compliance
Electromagnetic Compatibility (EMC) requirements have been established in
many countries to regulate the radio frequency energy generated by Information
Technology Equipment (ITE). This energy is generated during the normal and
intended use of this equipment and so it is limited by country regulations to levels
intended to minimize potential interference to other electrical equipment,
including public safety services.
Two levels of radio frequency energy are allowed according to the type or use of
equipment. Class A levels have been established for use in commercial or
business environments. Class B levels are lower than the Class A requirement and
have been established for use in residential environments. Class B levels are also
suitable when the environment includes electrically sensitive equipment.
The server equipment you have purchased has been provided with a compliance
label to indicate where it may be used with reasonable protection to the
environment in which it is used. Additional statements are provided below as
required by the requirements of international and domestic regulations.
NOTE Check the label on your product to determine the level of
operation.
Shielded cables should be used for connecting peripherals to this server device to
reduce the possibility of interference with radio communications services. Using
shielded cables ensures that you maintain the appropriate EMC classification for
the intended environment.
Notice for United States
Class A Equipment
This equipment has been tested and found to comply with the limits for Class A
digital devices, pursuant to Part 15 of the FCC (Federal Communications
Commission) Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions manual,
may cause harmful interference to radio communications. Operation of this
1

Regulatory Information
equipment in a residential area is likely to cause harmful interference in which
case the user is required to correct the interference at their own expense.
Class A Accessories
Installation and use of a Class A accessory creates a system that meets the
requirements for industrial and commercial environments. If you are installing a
Class A accessory in a system that has been labeled as a Class B product, the
requirements and notice for Class A equipment shall be applied.
Class B Equipment
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC (Federal Communications
Commission) Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates
and uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to correct the interference by one or more of the
following measures:
·Reorient or relocate the receiving antenna.
·Increase the separation between the equipment and the receiver.
·Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
·Consult the dealer or an experienced radio/television technician for help.
Hewlett-Packard's system certification tests were conducted with HP-supported
peripheral devices and HP shielded cables, such as those you receive with your
computer. Changes or modifications not expressly approved by Hewlett-Packard
could void the user's authority to operate the equipment. Cables used with this
device must be properly shielded to comply with the requirements of the FCC.
Notice for Canada (Industry Canada)
This digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Cet appareil numérique respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
2

Regulatory Information
Notice for Japan
The configuration of the server you have purchased may be in either the Class A
or Class B category.
For products labeled as Class B:
This equipment is in the Class B category information technology equipment
based on the rules of Voluntary Control Council For Interference by Information
Technology Equipment (VCCI). Although aimed for residential area operation,
radio interference may be caused when used near a radio or TV receiver.
Read the instructions for correct operation.
For products labeled as Class A:
This equipment is in the Class A category information technology equipment
based on the rules of Voluntary Control Council For Interference by Information
Technology Equipment (VCCI). When used in a residential area, radio
interference may be caused. In this case, user may be required to take appropriate
corrective actions.
3

Regulatory Information
Notice for Korea
The configuration of the server you have purchased may be in either the Class A
or Class B category.
Class A Equipment:
Please note that this equipment has been approved for business purposes with
regards to electromagnetic interference, if purchased in error for use in residential
areas, you may wish to exchange the equipment where you purchased it.
Class B Equipment:
Please note that this equipment has been approved for non-business purposes with
regards to electromagnetic interference. This equipment can be allowed for use in
all areas as well as residential areas.
4

Regulatory Information
Notice for Taiwan
Class A Warning Statement
Notice for European Union
Radio Frequency Emissions Warning for Accessories ( For Class B products )
This product has been found to comply with CISPR 22 Class B EMC emission
limits. Installation and use of a Class A accessory creates a system that meets the
requirements for industrial and commercial environments. However, in a domestic
environment, this product may cause radio interference, in which case the user
may be required to take adequate measures.
5

Regulatory Information
Declaration of Conformity (US and EU)
DECLARATION OF CONFORMITY (US and EU)
according to ISO/IEC Guide 22 and EN 45014
Manufacturer's Name:
Manufacturer's Address:
Hewlett-Packard Company
10955 Tantau Avenue
Cupertino, California, 95014-5040, USA
declares, that the product
Product Name:
Regulatory Id:
Model Number:
Product Options:
HP Server
8BTC4100
tc4100
All
conforms to the following Product Specifications:
Safety: IEC 60950:1991+A1+A2+A3+A4 /
EN 60950:1992+A1+A2+A3+A4+A11
IEC 60825-1:1993 +A1 / EN 60825-1:1994 +A11 (Class 1 Laser/LED)
EMC: EMC: CISPR 22:1997 / EN 55022:1998
CISPR 24:1997 / EN 55024:1998
IEC 61000-3-2:1995 / EN 61000-3-2:1995 +A14
IEC 61000-3-3:1994 / EN 61000-3-3:1995
Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and the EMC
Directive 89/336/EEC and carries the CE-marking accordingly.
Date: January 17, 2002 Product Regulations Manager
European contact for regulatory topics only:
Hewlett-Packard GmbH, HQ-TRE, Herrenberger Strasse 130, D-71034 Böblingen
(FAX: [phone])
North American Contact:
Hewlett-Packard Company Product Regulations Manager,
3000 Hanover Street, Palo Alto, California, 94304
(Phone: [phone])
6

Regulatory Information
Regulatory Notices - Product Safety
The following information applies only to HP Servers with factory-installed
components.
CD-ROM or DVD and Laser Safety Statements
The following information applies only to HP Servers with factory-installed
CD-ROM or DVD drives.
CD-ROM or DVD Safety – United States
WARNING To prevent fire or shock hazard, do not expose the unit to rain
or moisture.
To avoid electrical shock, do not open the cabinet. Refer
servicing to qualified personnel only.
Laser Safety– United States
CAUTION This CD-ROM or DVD mass storage system contains a laser
system and is classified as a "Class-1 Laser Product" under a
U.S. Department of Health and Human Services (DHHS)
Radiation Performance standard according to the Radiation
Control for Health and Safety Act of 1968.
To ensure proper use of this product, please read this
instruction manual carefully and retain for future reference.
Should the unit ever require maintenance, contact an
authorized service location.
CAUTION Use of controls, adjustments or the performance procedures
other than those specified herein may result in hazardous
radiation exposure. To prevent direct exposure to laser beam,
do not try to open the enclosure.
7

Regulatory Information
Laser Safety - Finland
LASERTURVALLISUUS
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
HP Server tc4100 - verkkopalvelimeen voidaan asentaa lisävarusteena
laitteensisainen CD-ROM or DVD-lukulaite, joka on laserlaite.
Kyseinen CD-ROM or DVD-lukulaite on käyttäjän kannalta turvallinen luokan 1
laserlaite. Normaalissa käytössä lukulaitteen suojakotelo estää laseräteen pääsyn
laiteen ulkopuolelle. Laitteen turvallisuusluokka on määritetty standardin EN
60825 (1991) mukaisesti.
Laser Safety - Germany
VORSICHT Diese Gerät enthält ein Laser-System und ist als "LASER
PRODUKT DER KLASSE 1"klassifiziert. Für den richtigen
Gebrauch dieses Modells die Bedienungsanleitung sorgfältig
durchlesen und als Referenz aufbewahren. Falls Probleme mit
diesem Modell aufreten, die nächste "authorisierte Services-
Verrtetung" benachrichtigen. Um einen direkten Kontakt mit
dem Laserstrahl zu vermeiden, soll das Gehäuse nicht geöffnet
werden.
VORSICHT Die Verwendung von anderen Steuerungen oder Einstellungen
oder das Durchführen von anderen Vorgängen als in der
Bedienungsanleitung beschrieben kann gefährliche
Strahlenexpositionen zur Folge haben.
8

Regulatory Information
CLASS 1
LASER
PRODUCT
This CD-ROM or DVD Drive Unit is classified as
a CLASS 1 LASER PRODUCT.
LASSER
KLASSE 1
PRODUKT
The CLASS 1 LASER PRODUCT label is located
on the top of the drive.
Bei diesem CD-ROM or DVD-Laufwerk
CDU56S handelt es sich um ein Laser-Produkt der
Klasse 1. Ein entsprechender Aufkelber mit der
Beschriftung LASER KLASSE 1 PRODUKT
befindet sich der Obersiete des Geräts.
Battery Safety Statements
This product uses a lithium battery.
Battery Safety - United States
WARNING Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to
the manufacturer's instructions.
Battery Safety – France
AVERTISSEMENT Il y a danger d'explosion s'il y a remplacement incorrect de
la batterie.
Remplacer uniquement avec une batterie du même type
ou d'un type équivalent recommandé par le constructeur.
Mettre au rebut les batteries usagées conformément aux
instructions du fabricant.
9

Regulatory Information
Accessory Board Safety Statements
Accessory Board Safety - United States
CAUTION Some accessory board outputs may exceed U.S. National
Electrical code (NFPA 70) Class 2 or limited power source
limits and must use appropriate interconnecting cabling in
accordance with the National Electrical Code.
NOTE All Hewlett-Packard accessory boards comply with the U.S.
National Electrical code (NFPA 70) Class 2.
Do not plug a modem or telephone cable into the network interface controller
(NIC) receptacle.
Noise and Ergonomic Safety Statements
Noise Declaration and Ergonomics - Germany
Sound Pressure: LpA < 55 dB (A)
am Arbeitsplatz, Beobachter Position (workplace, bystander position)
normaler Betrieb (normal operation)
nach DIN 45635 T. 19 (per ISO 7779)
This product has not been evaluated for compliance with the ZH1/618 ergonomic
requirements.
Servers with multiple power cords
CAUTION The power control button on the system does not turn off the
electrical current supplied to the system. To remove all
electrical current from the device, ensure that all power cords
are disconnected from the power source.
10

Service and Support
For all service and support information, see the HP Server Warranty and
Service/Support Booklet included with your product.
11

Regulatory Information
12

Warranty and Software License
Warranty
See the HP Server Warranty and Service/Support Booklet included with your
product for all warranty and service/support information.
HP Software Product License Agreement
ATTENTION: USE OF THE SOFTWARE IS SUBJECT TO THE HP
SOFTWARE LICENSE TERMS SET FORTH BELOW. USING THE
SOFTWARE INDICATES YOUR ACCEPTANCE OF THESE LICENSE
TERMS. IF YOU DO NOT ACCEPT THESE LICENSE TERMS, YOU
MAY RETURN THE SOFTWARE FOR A FULL REFUND. IF THE
SOFTWARE IS BUNDLED WITH ANOTHER PRODUCT, YOU MAY
RETURN THE ENTIRE UNUSED PRODUCT FOR A FULL REFUND.
The HP Software Product License Agreement will govern all Software, which is
provided to you with the exception of Microsoft Software. Microsoft Products are
licensed to you under the Microsoft End User License Agreement (EULA)
contained in the Microsoft documentation.
The following License Terms govern your use of the accompanying Software
unless you have a separate signed agreement with HP.
License Grant.HP grants you a license to Use one copy of the Software. "Use"
means storing, loading, installing, executing or displaying the Software. You may
not modify the Software or disable any licensing or control features of the
Software. If the Software is licensed for "concurrent use," you may not allow
more than the maximum number of authorized users to Use the Software
concurrently.
Ownership. The Software is owned and copyrighted by HP or its third party
suppliers. Your license confers no title to, or ownership in, the Software and is not
a sale of any rights in the Software. HP's third party suppliers may protect their
rights in the event of any violation of these License Terms.
Copies and Adaptations. You may only make copies or adaptations of the
Software for archival purposes or when copying or adaptation is an essential step
in the authorized Use of the Software. You must reproduce all copyright notices in
the original Software on all copies or adaptations. You may not copy the Software
onto any public network.
13

Warranty and Software License
If your Computer was shipped with a Recovery CD,(i) the Recovery CD
and/or Support Utility software may be used only for restoring the hard disk of the
HP computer system with which the Recovery CD originally was provided, and
(ii) if separate EULA(s) are included with your Computer for any other MS
products which are included on the Recovery CD, those MS products are subject
to the terms of their respective EULA(s).
No Disassembly or Decryption. You may not disassemble or decompile the
Software unless HP's prior written consent is obtained. In some jurisdictions, HP's
consent may not be required for limited disassembly or decompilation. Upon
request, you will provide HP with reasonably detailed information regarding any
disassembly or decompilation. You may not decrypt the Software unless
decryption is a necessary part of the operation of the Software.
Transfer.Your license will automatically terminate upon any transfer of the
Software. Upon transfer, you must deliver the Software, including any copies and
related documentation, to the transferee. The transferee must accept these License
Terms as a condition to the transfer.
Termination.HP may terminate your license upon notice for failure to comply
with any of these License Terms. Upon termination, you must immediately
destroy the Software, together with all copies, adaptations and merged portions in
any form.
Export Requirements.You may not export or re-export the Software or any copy
or adaptation in violation of any applicable laws or regulations.
U.S. Government Restricted Rights. The Software and any accompanying
documentation have been developed entirely at private expense. They are
delivered and licensed as "commercial computer software" as defined in DFARS
252.227-7013 (Oct 1988), DFARS 252.211-7015 (May 1991) or DFARS
252.227-7014 (Jun 1995), as a "commercial item" as defined in FAR 2.101(a), or
as "restricted computer software" as defined in FAR 52.227-19 (Jun 1987)(or any
equivalent agency regulation or contract clause), whichever is applicable. You
have only those rights provided for such Software and any accompanying
documentation by the applicable FAR or DFARS clause or the HP standard
software agreement for the product involved.
Non-Nuclear Usage
HP Servers are not specifically designed, manufactured, or intended for sale as
parts, components, or assemblies for the planning, construction, maintenance, or
direct operation of a nuclear facility. Customer is solely liable if Products or
Support purchased by Customer are used for these applications. Customer releases
14

Warranty and Software License
HP and will hold HP harmless from all loss, damage, expense, or liability in
connection with such use.
15

Warranty and Software License
16
