HP ProLiant DL380 - G2 Server User instructions

1. 1.44 MB (3.5”) Floppy Disk Drive
2. Latching Mechanism (facilitates easy hood removal)
3. 24x Max CD-ROM (with easy front ejection removal)
4. Front LED's (show server status)
5. Unit Identification button and LED (for easy in rack server identification)
6. Six 1" Wide Ultra3 SCSI Hot Plug Hard Drives OR Five 1" Hot Plug Hard
Drive and one AIT or 20/40-GB DAT Hot Plug Tape Drive
7. 2U Form Factor
What's New
What's NewWhat's New
What's New
New DC Power Supply for the DL380 G2 (48V)
At A Glance
At A GlanceAt A Glance
At A Glance
New Smart Array 5i Plus Controller & Battery-Backed Write Cache (BBWC) Enabler bundle option kit
Setting a new standard for 2-way dense computing, the new ProLiantDL380 is the first density-optimized server to provide enterprise class availability
and performance for demanding Internet and business applications - all in a 2U form factor
Intel® Pentium® III FC-PGA2 1.40 GHz Processor (dual capability) with 512-KB level 2 ECC cache
ServerWorks HE-SLChipset
Triple Peer PCI Architecture with 133-MHz Front Side Bus
256-MB PC133-MHz Registered ECC SDRAM memory (2 x 1 Interleaved Memory), expandable to 6 GB or 4 GB with 2 GB online spare memory
Three PCI expansion slots: Two HP 64-bit/66 MHz and one standard 64-bit/33 MHz
Two Compaq NC3163 Fast Ethernet NICs Embedded 10/100 WOL (Wake On LAN)
Smart Array 5i Controller (integrated on system board)
Support for up to six 1" Wide Ultra3/Ultra320 SCSI hot plug hard drives or for five hot plug hard drives and one AIT or 20/40-GB DAT hot plug tape
drive
Internal hot plug capacity 880.8 GB standard (6 x 146.8 GB 1" HD)
400-Watt Hot Plug Power Supply and Hot Pluggable Fans (optional redundancy for both)
Sliding rails and cable management arm for easy serviceability and in-rack tool-less access to major components
Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU), Compaq Insight Manager 7, Status LEDs including system health and UID and
SmartStart
Protected by HP Services, including a three-year, Next Business Day, on-site limited Global warranty and extended Pre-Failure Warranty, which covers
processors, memory, and hard drives — Certain restrictions and exclusions apply. Consult the HP Customer Support Center at 1-800-345-1518 for
details.
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Overview
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 1

Processor
ProcessorProcessor
Processor Intel Pentium III FC-PGA2 1.40 GHz Processor
Cache Memory
Cache MemoryCache Memory
Cache Memory
512-KB second level ECC cache (full speed)
Upgradability (per server)
Upgradability (per server)Upgradability (per server)
Upgradability (per server) Upgradable to dual processing
Chipset
ChipsetChipset
Chipset ServerWorks HE-SL Chipset
NOTE:
NOTE:NOTE:
NOTE: For more information regarding ServerWorks, please see the following URL:
http://www.serverworks.com/products/overview.html .
NOTE:
NOTE:NOTE:
NOTE: This Web site is available in English only.
Memory
MemoryMemory
Memory
Standard 256 MB (PC133-MHz Registered ECC SDRAM Memory)
(2 x 1 Interleaved Memory)
Maximum 6 GB
Network Controller
Network ControllerNetwork Controller
Network Controller Two Compaq NC3163 Fast Ethernet NICs (embedded) PCI 10/100 WOL (Wake on LAN)
Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots I/O (3 Total, 3 available) PCI Voltage:
64-bit/66 MHz Hot Plug PCI 2 3.3 Volt or universal cards
64-bit/33 MHz Non Hot Plug
PCI
1 5 Volt or universal cards
Storage Controllers
Storage ControllersStorage Controllers
Storage Controllers Smart Array 5i Controller (integrated on system board)
NOTE:
NOTE:NOTE:
NOTE: For complete list of devices supported the Smart array 5i Controller see the following:
http://h18000.www1.hp.com/products/quickspecs/10890_div/10890_div.HTML (Worldwide)
http://h18000.www1.hp.com/products/quickspecs/10890_na/10890_na.HTML (North America)
Storage
StorageStorage
Storage Diskette Drives 1.44 MB
CD-ROM 24x IDE CD-ROM Drive (Slimline)
Hard Drives None
Maximum Internal
Storage
880.8 GB (6 x 146.8 GB Ultra320 1")
Interfaces
InterfacesInterfaces
Interfaces Serial 1
Pointing Device (Mouse) 1
Graphics 1
Keyboard 1
External SCSI 1
Network RJ-45 2
USB 2
NOTE:
NOTE:NOTE:
NOTE: Please see the following URL for additional information regarding USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb-support.html .
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Standard Features
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 2

Graphics
GraphicsGraphics
Graphics Integrated ATI Rage XL Video Controller with 8-MB SDRAM Video Memory
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), (3.5-inch)
Product Tour
Product TourProduct Tour
Product Tour To view the Product Tour, please see the following URL, then click on "PRODUCT TOUR":
http://h18000.www1.hp.com/products/servers/proliantdl380/index.html .
NOTE:
NOTE:NOTE:
NOTE: This Web site is available in English only.
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Standard Features
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 3

ProLiant
ProLiantProLiant
ProLiant Essentials
EssentialsEssentials
Essentials
Foundation Pack
Foundation PackFoundation Pack
Foundation Pack
Software
SoftwareSoftware
Software
Insight Manager 7 Insight Manager 7 helps maximize system uptime and performance and reduces the cost of
maintaining the IT infrastructure by providing proactive notification of problems before
those problems result in costly downtime and reduced productivity. Insight Manager 7 is
easy to set up and provides rapid access to detailed fault and performance information
gathered by the Management Agents. One-click access to the Integrated Lights-Out or
Remote Insight Lights Out Edition board allows systems administrators to take full
graphical control of ProLiant servers in remote locations or lights-out data centers. Finally,
Insight Manager 7 in concert with the Version Control Agents and Version Control
Repository Manager enables systems administrators to version manage and update system
software across groups of ProLiant servers.
SmartStart SmartStart is a tool that simplifies server setup, providing a rapid way to deploy reliable
and consistent server configurations. For more information, please visit the SmartStart Web
site at http://www.hp.com/servers/smartstart .
SmartStart version supported (minimum): SmartStart 5.10.
Management Agents The Management Agents form the foundation for HP's Intelligent Manageability strategy.
They provide direct, browser-based access to in-depth instrumentation built into HP servers,
workstations, desktops, and portables, and send alerts to Insight Manager 7 and other
enterprise management applications in case of subsystem or environmental failures. For
additional information about the Management Agents and other management products
from HP, please visit the management Web site at http://www.hp.com/servers/manage .
ActiveUpdate Active Update is a web-based application that keeps IT managers directly connected to HP
for proactive notification and delivery of the latest software updates.
ROMPaq , support software,
and
configuration utilities
The latest software, drivers, and firmware fully optimized and tested for your ProLiant server
and options.
Survey Utility and diagnostics
utilities
The most advanced configuration analysis, reporting and troubleshooting utilities used by
HP and at your fingertips.
Optional ProLiant Essentials
Value Packs
Optional software offerings that selectively extend the functionality of an Adaptive
Infrastructure to address specific business problems and needs:
Rapid Deployment Pack – an automated solution for multi-server deployment and
provisioning, enabling companies to quickly and easily adapt to changing
business demands.
Workload Management Pack – provides easier management of complex
environments, improving overall server utilization and enabling Windows® 2000
customers for the first time to confidently deploy multiple applications on a single
multiprocessor ProLiant Server.
Performance Management Pack – a performance management solution that
identifies and explains hardware performance bottlenecks on ProLiant servers and
attached options enabling users to better utilize their valuable resources.
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer to
http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack product QuickSpecs for more
information.
NOTE:
NOTE:NOTE:
NOTE: For more information regarding ProLiant Essentials Software, please see the following URL:
http://www.hp.com/servers/proliantessentials
NOTE:
NOTE:NOTE:
NOTE: These Web sites are available in English only.
Industry Standard
Industry StandardIndustry Standard
Industry Standard
Compliance
ComplianceCompliance
Compliance
ACPI 1.0b Compliant
PCI-X and PCI 2.2 Compliant
WOL Support
Microsoft® Logo certifications
USB 1.1
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Standard Features
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 4

Manageability
ManageabilityManageability
Manageability Insight Manager 7
Redundant ROM
Remote Flash ROM
Management Agent
Automatic Server Recovery (ASR)
Compaq Remote Insight Lights-Out Edition (optional)
Integrated Management Log
Drive Parameter Tracking (with Smart Array Controllers)
Dynamic Sector Repairing (with Smart Array Controllers)
Hot Spare Boot
( NOTE:
NOTE:NOTE:
NOTE: Upon the event of a failed processor or VRM in a multi-processing environment, the system will automatically
reboot and use the remaining good processor(s).)
Pre-Failure Warranty (covers processors, hard drives and memory)
Security
SecuritySecurity
Security Power-on password
Keyboard password
Diskette drive control
Diskette boot control
QuickLock, Network Server Mode
Serial interface control
Administrator's password
Disk configuration lock
Server Power Cords
Server Power CordsServer Power Cords
Server Power Cords One Lowline power cord ships standard
Power Supply
Power SupplyPower Supply
Power Supply 400 Watt, CE Mark Compliant
Optional Hot Plug Redundant Power Supply Capability
System Fans
System FansSystem Fans
System Fans 5 fans ship standard. 8 total supported internally
NOTE:
NOTE:NOTE:
NOTE: The additional 3 fans are available via Option Kit (PN 225012-B21).
Required Cabling
Required CablingRequired Cabling
Required Cabling For required cabling information, refer to the Web site at: http://h18000.www1.hp.com/products/servers/ProLiantDL380/ .
NOTE:
NOTE:NOTE:
NOTE: This Web site is available in English only.
OS Support
OS SupportOS Support
OS Support Microsoft Windows NT® erver
Microsoft Windows 2000
Novell NetWare
SCO UnixWare®
LINUX (Red Hat, SuSE, TurboLinux Server, Caldera eServer)
Sun Solaris Intel Platform Edition
NOTE:
NOTE:NOTE:
NOTE: For a more complete and up-to-date listing of supported OS's and versions, please visit our OS Support Matrix at:
ftp://ftp.compaq.com/pub/products/servers/os-support-matrix-310.pdf .
NOTE:
NOTE:NOTE:
NOTE: For an up-to-date listing of the latest drivers available for the ProLiant DL380, please see:
http://h18023.www1.hp.com/support/files/server/us/index.html .
NOTE:
NOTE:NOTE:
NOTE: These Web sites are available in English only.
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Standard Features
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 5

Rack Airflow Requirements
Rack Airflow RequirementsRack Airflow Requirements
Rack Airflow Requirements Rack 9000 and 10000 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-
mounted servers. The Compaq 9000 Series Rack and the new 10000 Series Racks provides enhanced airflow for
maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.
Rack 7000 series Cabinets
When installing a server with processors running at speeds of 550 MHz or greater in Compaq Rack 7000 series racks
with glass doors (165753-001 (42U), and 163747-001 (22U)), the new processor technology requires the
installation of Compaq’s new High Airflow Rack Door Inserts (327281-B21 (42U), 327281-B22 (42U 6 pack), or
157847-B21 (22U)) to promote enhanced airflow for maximum cooling.
CAUTION:
CAUTION:CAUTION:
CAUTION: If a third-party rack is used, observe the following additional requirements to ensure adequate airflow and to
prevent damage to the equipment:
Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow 830
square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit adequate airflow
(equivalent to the required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side panels of the rack must be a
minimum of 2.75 inches (7 cm).
CAUTION:
CAUTION:CAUTION:
CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This arrangement
ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.
NOTE:
NOTE:NOTE:
NOTE: For additional information, refer to the Setup and Installation Guide or the Documentation CD provided with the
server, or to the server documentation located in the Support section at the following URL:
http://h18000.www1.hp.com/products/servers/ProLiantdl760/index.html .
Service and Support
Service and SupportService and Support
Service and Support HP Services provides a three-year, limited warranty, including Pre-Failure Warranty (coverage of hard drives, memory and
processors) fully supported by a worldwide network of resellers and service providers. HP technical assistance is available
7x24, toll free in the United States and Canada. Telephone support services may be covered under warranty or available for
an additional fee.
NOTE:
NOTE:NOTE:
NOTE: Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support.
A full range of HP Care Pack packaged hardware and software services:
Installation and start up
Extended coverage hours and enhanced response times
System management and performance services
Availability and recovery services
NOTE:
NOTE:NOTE:
NOTE: For more information, customer/resellers can contact http://www.hp.com/hps/ .
Please see the following URL regarding Warranty Information For Your HP Products:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html .
For additional information regarding Worldwide Limited Warranty and Technical Support, please see the following URL:
ftp://ftp.compaq.com/pub/supportinformation/ejourney/176738.pdf .
NOTE:
NOTE:NOTE:
NOTE: Certain restrictions and exclusions apply. Consult the Customer Support Center at 1-800-345-1518 for details.
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Standard Features
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 6

DL380R02 P1400-512KB,
DL380R02 P1400-512KB,DL380R02 P1400-512KB,
DL380R02 P1400-512KB,
256MB
256MB256MB
256MB
253864-xx1
Processor(s)
Processor(s)Processor(s)
Processor(s) (1) Intel Pentium III FC PGA2 1.40 GHz Processor standard (up to 2 supported)
Cache Memory
Cache MemoryCache Memory
Cache Memory 512-KB level 2 ECC cache
Memory
MemoryMemory
Memory 256 MB (Standard) to 6 GB (Maximum) PC133-MHz Registered ECC SDRAM
Network Controller
Network ControllerNetwork Controller
Network Controller (2) Compaq NC3163 Fast Ethernet NIC (embedded) PCI 10/100 WOL (Wake on LAN)
Storage Controller
Storage ControllerStorage Controller
Storage Controller Smart Array 5i Controller (integrated on system board
Hard Drives
Hard DrivesHard Drives
Hard Drives None ship standard
Internal Storage
Internal StorageInternal Storage
Internal Storage 880.8 GB max (with optional hard drives)
Optical Drive
Optical DriveOptical Drive
Optical Drive 24x IDE CD-ROM Drive (Slimline)
Form Factor
Form FactorForm Factor
Form Factor Rack (2U), (3.5-inch)
Country Code Key
Country Code KeyCountry Code Key
Country Code Key XX=00 US
XX=01 Australia
XX=03 UK
XX=29 Japan
XX=37 APD
XX=42 EURO
XX=AA PRC
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Models
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 7

ProLiant DL380 G2
ProLiant DL380 G2ProLiant DL380 G2
ProLiant DL380 G2
Unique Options
Unique OptionsUnique Options
Unique Options
Pentium III P1400-512KB Processor Option Kit 201099-B21
Pentium III P1266-512KB Processor Option Kit 201098-B21
Pentium III P1133-512KB Processor Option Kit 201097-B21
Smart Array 5i Plus Controller & BBWC Enabler Bundle 264030-B21
NOTE:
NOTE:NOTE:
NOTE: This option kit (PN 264030-xx1) supports the ProLiant DL380 G2 only.
Smart Array 5i Plus Controller & BBWC Enabler Bundle (Japan) 264030-291
NOTE:
NOTE:NOTE:
NOTE: This option kit (PN 264030-xx1) supports the ProLiant DL380 G2 only.
2-Post Telco Rail Kit 228892-B21
Third Party, 4-Post Sliding Rail Kit 228894-B21
Compaq Hot Plug Redundant Power Supply Module 225011-001
Compaq Hot Plug Redundant Power Supply Module (Australia) 225011-011
Compaq Hot Plug Redundant Power Supply Module (Int'l) 225011-021
Compaq Hot Plug Redundant Power Supply Module (UK) 225011-031
Compaq Hot Plug Redundant Power Supply Module (Japan) 225011-291
Hot Plug Redundant Fan Option Kit 225012-B21
NOTE:
NOTE:NOTE:
NOTE: Hot Plug Redundant Fan Option Kit (PN 225012-B21) contains three fans per kit
DC Power Supply for the DL380 G2 (48V) 268290-B21
NOTE:
NOTE:NOTE:
NOTE: The ProLiant DL380 G2 ships standard with a 100-240 volt auto-switching AC power
supply. Each 48 volt DC option kit (PN 268290-B21) contains one power supply. Therefore, to convert
to redundant DC power supplies, two must be purchased
ProLiant Essentials
ProLiant EssentialsProLiant Essentials
ProLiant Essentials
Value Pack Software
Value Pack SoftwareValue Pack Software
Value Pack Software
Rapid Deployment Pack, 1 User, V1.x
NOTE:
NOTE:NOTE:
NOTE: This license allows 1 server to be managed and deployed via the Deployment Server.
267196-B21
Rapid Deployment Pack, 1 User, V1.x (Japan)
NOTE:
NOTE:NOTE:
NOTE: This license allows 1 server to be managed and deployed via the Deployment Server.
267196-291
Rapid Deployment Pack, 10 Users, V1.x
NOTE:
NOTE:NOTE:
NOTE: This license allows 10 servers to be managed and deployed via the Deployment Server.
269817-B21
Rapid Deployment Pack, 10 Users, V1.x (Japan)
NOTE:
NOTE:NOTE:
NOTE: TThis license allows 10 servers to be managed and deployed via the Deployment Server.
269817-291
ProLiant Essentials Workload Management Pack (Featuring Compaq Resource Partitioning Manager
version 2.0)
303284-B21
ProLiant Essentials Recovery Server Option Pack 280189-B21
ProLiant Essentials Performance Management Pack v2.0, Single License 306696-B21
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs.
Refer to http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack
product QuickSpecs for more information.
NOTE:
NOTE:NOTE:
NOTE: For more information regarding ProLiant Essentials Software, please see the following URL:
http://www.hp.com/servers/proliantessentials .
NOTE:
NOTE:NOTE:
NOTE: These Web sites are available in English only.
Software
SoftwareSoftware
Software HP digital asset protection 302316-001
Software – Secured
Software – SecuredSoftware – Secured
Software – Secured
Solutions
SolutionsSolutions
Solutions
InterScan/Immunix Secured Solution for hp ProLiant servers 307039-B21
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 8

NetServer to ProLiant
NetServer to ProLiantNetServer to ProLiant
NetServer to ProLiant
integrations services
integrations servicesintegrations services
integrations services
HP NetServer to ProLiant integration and assessment service
304164-002
NOTE:
NOTE:NOTE:
NOTE: HP identifies current levels of NetServer support, services, and management. This service
helps maximize customer’s ability to add ProLiant platforms into their current environment.
HP TopTools to Insight Manager 7 installation and startup service 304163-002
NOTE:
NOTE:NOTE:
NOTE: Provides on-site review, installation and configuration services for Insight Manager 7. HP will
also re-create, as closely as possible, the views and reports from the customer’s current TopTools
configuration. This service assures a smooth transition to the ProLiant Essentials software.
HP NetServer to ProLiant Essentials Rapid Deployment Pack installation and startup service 304162-002
NOTE:
NOTE:NOTE:
NOTE: Install and configure Rapid Deployment Pack in a test environment, then deploy a server
image to a maximum of 250 systems in the production environment. This service helps to assure
successful system deployment.
Processor
ProcessorProcessor
Processor Pentium III P1400-512-KB Processor Option Kit 201099-B21
Pentium III P1266-512-KB Processor Option Kit 201098-B21
Pentium III P1133-512-KB Processor Option Kit 201097-B21
Memory
MemoryMemory
Memory 256-MB PC133-MHz Registered ECC SDRAM Memory Option Kit (2 x 128 MB) 201692-B21
512-MB PC133-MHz Registered ECC SDRAM Memory Option Kit (2 x 256 MB) 201693-B21
1024-MB PC133-MHz Registered ECC SDRAM Memory Option Kit (2 x 512 MB) 201694-B21
2048-MB PC133-MHz Registered ECC SDRAM Memory Option Kit (2 x 1024 MB) 201695-B21
Optical Drives
Optical DrivesOptical Drives
Optical Drives Slimline CD-RW/DVD-ROM 24X Combo Drive Option Kit 331903-B21
Hard Drives
Hard DrivesHard Drives
Hard Drives Ultra 320 SCSI – Universal Hot Plug
Ultra 320 SCSI – Universal Hot PlugUltra 320 SCSI – Universal Hot Plug
Ultra 320 SCSI – Universal Hot Plug
36.4GB 10,000 rpm, U320 Universal Hard Drive, 1" 286713-B22
72.8GB 10,000 rpm, U320 Universal Hard Drive, 1" 286714-B22
146.8GB 10,000 rpm, U320 Universal Hard Drive, 1" 286716-B22
18.2GB 15,000 rpm, U320 Universal Hard Drive, 1" 286775-B22
36.4GB 15,000 rpm, U320 Universal Hard Drive, 1" 286776-B22
72.8GB 15,000 rpm, U320 Universal Hard Drive, 1" 286778-B22
NOTE:
NOTE:NOTE:
NOTE: All U320 Universal Hard Drives are backward compatible to U2 or U3 speeds. U320 drives
require an optional U320 Smart Array Controller or U320 SCSI HBA to support U320 transfer rates.
NOTE:
NOTE:NOTE:
NOTE: Please see the Hard Drive QuickSpecs for Technical Specifications such as capacity, height,
width, interface, transfer rate, seek time, physical configuration, and operating temperature:
U320 Hard Drive QS:
http://h18000.www1.hp.com/products/quickspecs/11531_div/11531_div.HTML (Worldwide)
http://h18000.www1.hp.com/products/quickspecs/11531_na/11531_na.HTML (North America)
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 9

Storage Controllers
Storage ControllersStorage Controllers
Storage Controllers Smart Array 5i Plus Controller & BBWC Enabler Bundle 264030-B21
NOTE:
NOTE:NOTE:
NOTE: This option kit (PN 264030-xx1) supports the ProLiant DL380 G2 only.
Smart Array 5i Plus Controller & BBWC Enabler Bundle (Japan) 264030-291
NOTE:
NOTE:NOTE:
NOTE: This option kit (PN 264030-xx1) supports the ProLiant DL380 G2 only.
Smart Array 532 Controller 225338-B21
Smart Array 532 Controller (Japan) 225338-291
Smart Array 5302/128 Controller 283552-B21
Smart Array 5302/128 Controller (Japan) 283552-291
Smart Array 5304/256 Controller 283551-B21
Smart Array 5304/256 Controller (Japan) 283551-291
Smart Array 5312 Controller 238633-B21
Smart Array 5312 Controller (Japan) 238633-291
Ultra3 Channel Expansion Module for Smart Array 5300 Controller 153507-B21
128-MB Cache Module for Smart Array 5302 Controller 153506-B21
RAID ADG Upgrade for Smart Array 5302 288601-B21
256-MB Battery-Backed Cache Module 254786-B21
NOTE:
NOTE:NOTE:
NOTE: This 256-MB Battery-Backed Cache Module supports the Smart Array 5300 series controllers,
MSA 1000 and the Smart Array Cluster Storage.
64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 154457-B21
64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter 129803-B21
64-Bit/133MHz Dual Channel Ultra320 SCSI Adapter 268351-B21
64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter, Alternate OS 284688-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the following Controller or SCSI Adapter QuickSpecs for Technical Specifications
such as PCI Bus, PCI Peak Data Transfer Rate, SCSI Protocols supported, SCSI Peak Data Transfer
Rate, Channels, SCSI Ports, Drives supported, Cache, RAID support, and additional information:
http://h18000.www1.hp.com/products/quickspecs/11063_div/11063_div.HTML (Smart Array 5i Plus)
http://h18000.www1.hp.com/products/quickspecs/10851_div/10851_div.HTML (Smart Array 532)
http://h18000.www1.hp.com/products/quickspecs/10640_div/10640_div.HTML (Smart Array 5300
Series)
http://h18000.www1.hp.com/products/quickspecs/11328_div/11328_div.HTML (Smart Array 5312)
http://h18000.www1.hp.com/products/quickspecs/10429_div/10429_div.HTML (SCSI Adapter)
http://h18000.www1.hp.com/products/quickspecs/11555_div/11555_div.HTML (U320 Adapter)
Communications
CommunicationsCommunications
Communications Compaq NC3123 Fast Ethernet NIC PCI 10/100 WOL 174830-B21
Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Port 10/100 138603-B21
Compaq NC3135 Fast Ethernet Upgrade Module 138604-B21
Compaq NC6132 Gigabit Module 1000 SX Upgrade Module for NC3134 and NC3131 338456-B23
Compaq NC6133 Gigabit Module 1000LX Upgrade Module for NC3134 and NC3131 338456-B24
Compaq NC3133 Fast Ethernet Module 100FX Upgrade Module for NC3134 and NC3131 338456-B25
Compaq NC6136 Gigabit Server Adapter, 64-bit/66-MHz, PCI, 1000 SX 203539-B21
Compaq NC7131 Gigabit Server Adapter, 64-bit/66-MHz, PCI, 10/100/1000-T 158575-B21
Compaq NC7132 10/100/1000-T Upgrade Module for NC3134 and NC3131 153543-B21
NOTE:
NOTE:NOTE:
NOTE: Any NC31XX, NC61XX or NC71XX NIC can be used for redundancy with the embedded
NC3163 Network Controller.
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 10

DC Power Supply
DC Power SupplyDC Power Supply
DC Power Supply DC Power Supply for the DL380 (48V) 268290-B21
NOTE:
NOTE:NOTE:
NOTE: The ProLiant DL380 G2 ships standard with a 100-240 volt auto-switching AC power
supply. Each 48 volt DC option kit (PN 268290-B21) contains one power supply. Therefore, to convert
to redundant DC power supplies, two must be purchased.
Redundant Options
Redundant OptionsRedundant Options
Redundant Options Compaq Hot Plug Redundant Power Supply Module 225011-001
Compaq Hot Plug Redundant Power Supply Module (Australia) 225011-011
Compaq Hot Plug Redundant Power Supply Module (Int'l) 225011-021
Compaq Hot Plug Redundant Power Supply Module (UK) 225011-031
Compaq Hot Plug Redundant Power Supply Module (Japan) 225011-291
Hot Plug Redundant Fan Option Kit 225012-B21
Hot Plug AC Redundant Power Supply Module (NEMA cord) (NA) 313054-001
Hot Plug AC Redundant Power Supply Module (IEC cord) (WW) 313054-B21
Management Options
Management OptionsManagement Options
Management Options Remote Insight Lights-Out Edition II (NA, LA) 227251-001
Remote Insight Lights-Out Edition II (EMEA) 227251-021
Remote Insight Lights-Out Edition II (ROW) 227251-371
Compaq Remote Insight Lights-Out Edition (NA, LA) 157866-001
Compaq Remote Insight Lights-Out Edition (EMEA) 157866-021
Compaq Remote Insight Lights-Out Edition (ROW) 157866-371
Security
SecuritySecurity
Security HP/Atalla AXL600L SSL Accelerator Card for ProLiant Servers 524545-B21
Compaq AXL300 Accelerator PCI Card (HW SSL Encryption) for ProLiant Servers 227933-B21
Monitors
MonitorsMonitors
Monitors
Essential Series
Essential SeriesEssential Series
Essential Series
Compaq S9500 CRT Monitor (19-inch, Carbon/Silver) 261615-XXX
Compaq S7500 CRT Monitor (17-inch, Carbon/Silver) 261606-XXX
Compaq S5500 CRT Monitor (15-inch Carbon/Silver) 261602-XXX
Compaq TFT1501 Flat Panel Monitor
(15-inch, Carbon/Silver, North America)
301042-003
Compaq TFT1501 Flat Panel Monitor
(15-inch, Carbon/Silver, Outside North America)
P4825D-XXX
Compaq TFT1701 Flat Panel Monitor
(17-inch, Carbon/Silver, North America)
292847-003
Compaq TFT1701 Flat Panel Monitor
(17-inch, Carbon/Silver, Outside North America)
P9019A-XXX
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 11

Advantage Series
Advantage SeriesAdvantage Series
Advantage Series
Compaq V7550 CRT Color Monitor
(17-inch, Carbon/Silver)
261611-XXX
Compaq TFT1720 Flat Panel Monitor
(17-inch, Carbon/Silver, North America)
295926-003
Compaq TFT1720 Flat Panel Monitor
(17-inch, Carbon/Silver, outside North America)
D5064D-XXX
Compaq FT1720M Flat Panel Monitor
(17-inch, Carbon/Silver, includes speaker, USB port, headphone, North America)
301958-003
Compaq TFT1720M Flat Panel Monitor
(17-inch, Carbon/Silver, includes speaker, USB port, headphone, outside North America)
D5064P-XXX
Compaq TFT1520 Flat Panel Monitor
(15-inch, Carbon/Silver, North America)
295925-003
Compaq TFT1520 Flat Panel Monitor
(15-inch, Carbon/Silver, outside North America)
D5063D-XXX
Compaq TFT1520M Flat Panel Monitor
(15-inch, Carbon/Silver includes speaker, USB port, headphone, North America)
301957-003
Compaq TFT1520M Flat Panel Monitor
(15-inch, Carbon/Silver includes speaker, USB port, headphone, outside North America)
D5063P-XXX
Performance Series
Performance SeriesPerformance Series
Performance Series
HP P930 CRT Monitor (19-inch, Flat-screen, Carbon/Silver, North America) 302268-003
HP P930 CRT Monitor (19-inch, Flat-screen, Carbon/Silver, Outside North America) P909W-XXX
HP P1130 CRT Monitor (21-inch, Flat-screen, Carbon/Silver, North America) 302270-003
HP P1130 CRT Monitor (21-inch, Flat-screen, Carbon/Silver, Outside North America) P4819-XXX
HP L1825 Flat Panel Monitor (18-inch, Carbon/Silver, North America) 303486-003
HP L1825 Flat Panel Monitor (18-inch, Carbon/Silver, Outside North America) P9021W-XXX
HP L2025 Flat Panel Monitor (20-inch, Carbon/Silver, North America) 303102-003
HP L2025 Flat Panel Monitor (20-inch, Carbon/Silver, Outside North America) P4831W-XXX
Compaq TFT1825 Flat Panel Monitor
(18-inch, Carbon/Silver, North America)
296751-003
Compaq TFT1825 Flat Panel Monitor
(18-inch, Carbon/Silver, Outside North America)
P9021A-XXX
Compaq TFT2025 Flat Panel Monitor
(20-inch, Carbon/Silver, North America)
285550-003
Compaq TFT2025 Flat Panel Monitor
(20-inch, Carbon/Silver, Outside North America)
P4831D-XXX
Rackmount
RackmountRackmount
Rackmount Flat Panel Monitors
Flat Panel MonitorsFlat Panel Monitors
Flat Panel Monitors
TFT5110R Flat Panel Monitor (Carbon) (1U rack mountable) 281683-B21
TFT5010R Flat Panel Monitor (NA) (2U rack mountable) 217248-001
TFT5010R Flat Panel Monitor (Int’l) (2U rack mountable) 217248-B31
TFT5010R Flat Panel Monitor (Japan) (2U rack mountable) 217248-291
NOTE:
NOTE:NOTE:
NOTE: Monitors larger than 17" may be too heavy for use in rack systems.
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 12

Tape Drives
Tape DrivesTape Drives
Tape Drives
External DAT Tape Drives
External DAT Tape DrivesExternal DAT Tape Drives
External DAT Tape Drives
HP StorageWorks 20/40-GB DAT DDS-4 Tape Drive, External (Carbon) (NA) 157770-002
HP StorageWorks 20/40-GB DAT DDS-4 Tape Drive, External (Int’l) (Carbon) 157770-B32
HP StorageWorks 20/40-GB DAT DDS-4 Tape Drive, External (Japan)(Carbon) 157770-292
HP StorageWorks Internal 20/40-GB DAT, Hot Plug (Carbon) 215488-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the 20/40-GB DAT Tape Drive QuickSpecs for additional options such as host
bus adapters, controllers, cassettes, and for an up-to-date listing of the latest O/S Support details,
please see the following:
http://h18006.www1.hp.com/products/quickspecs/10426_div/10426_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/10426_na/10426_na.html (North America)
External AIT Tape Drives
External AIT Tape DrivesExternal AIT Tape Drives
External AIT Tape Drives
HP StorageWorks External AIT 35-GB, LVD Tape Drive (Carbon) 216885-001
HP StorageWorks External AIT 35-GB, LVD Tape Drive (Carbon) (Int’l) 216885-B31
HP StorageWorks External AIT 35-GB, LVD Tape Drive (Carbon) (Japan) 216885-291
HP StorageWorks Internal AIT 35-GB, LVD Hot Plug (Carbon) 216886-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the AIT 35 GB, LVD Tape Drive QuickSpecs for additional options such as
adapters, controllers, and cassettes, and for an up-to-date listing of the latest O/S Support details,
please see the following:
http://h18006.www1.hp.com/products/quickspecs/10712_div/10712_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/10712_na/10712_na.html (North America)
HP StorageWorks AIT 50-GB Tape Drive, External (Carbon) (NA) 157767-002
HP StorageWorks AIT 50-GB Tape Drive, External (Int’l) (Carbon) 157767-B32
HP StorageWorks AIT 50-GB Tape Drive, External (Japan) (Carbon) 157767-292
HP StorageWorks Internal AIT 50-GB, Hot Plug (Carbon) 215487-B21
HP StorageWorks AIT 50GB Tape Drive, 3U Rackmount 274333-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the AIT 50-GB Tape Drive QuickSpecs for additional options such as adapters,
controllers, and cassettes, and for an up-to-date listing of the latest O/S Support details, please see
the following:
http://h18006.www1.hp.com/products/quickspecs/10425_div/10425_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/10425_na/10425_na.html (North America)
HP StorageWorks External AIT 100-GB Tape Drive (Carbon) 249160-001
HP StorageWorks External AIT 100-GB Tape Drive (Carbon) (Int’l) 249160-B31
HP StorageWorks Internal AIT 100-GB, Hot Plug (Carbon) 249161-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the AIT 100-GB Tape Drive QuickSpecs for additional options such as adapters,
controllers, and cassettes, and for an up-to-date listing of the latest O/S Support details, please see
the following:
http://h18006.www1.hp.com/products/quickspecs/11062_div/11062_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/11062_na/11062_na.html (North America)
External DLT/SDLT Tape Drives
External DLT/SDLT Tape DrivesExternal DLT/SDLT Tape Drives
External DLT/SDLT Tape Drives
HP StorageWorks 40/80-GB DLT Tape Drive, External (Carbon) (NA) 146197-B22
HP StorageWorks 40/80-GB DLT Tape Drive, External (Carbon) (Japan) 146197-293
HP StorageWorks Rackmount DLT 40/80, 3U (Single Drive) 274332-B21
HP StorageWorks Rackmount DLT 40/80, Dual Drive 3U (Two Drives) 274335-B21
HP StorageWorks Rackmount DLT 40/80, Tape Array III, 5U (Four Drives) 274337-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the 40/80-GB DLT Drive QuickSpecs for additional options such as host bus
adapters, controllers, cassettes, and for an up-to-date listing of the latest O/S Support details, please
see the following:
http://h18006.www1.hp.com/products/quickspecs/10658_div/10658_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/10658_na/10658_na.html (North America)
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 13

External DLT VS Tape Drives
External DLT VS Tape DrivesExternal DLT VS Tape Drives
External DLT VS Tape Drives
HP StorageWorks DLT VS 40/80 Tape Drive, External (Carbon) (NA) 280129-B22
HP StorageWorks DLT VS 40/80 Tape Drive, External (Carbon) (Int’l) 280129-B31
HP StorageWorks DLT VS 40/80 Tape Drive, External (Carbon) (Japan) 280129-291
NOTE:
NOTE:NOTE:
NOTE: Please see the DLT VS 40/80 Tape Drive QuickSpecs for additional options such as host bus
adapters, controllers, cassettes, and for an up-to-date listing of the latest O/S Support details, please
see the following:
http://h18006.www1.hp.com/products/quickspecs/10403_div/10403_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/10403_na/10403_na.html (North America)
HP StorageWorks Rackmount SDLT 110/220, 3U (Single Drive) 274331-B21
HP StorageWorks Rackmount SDLT 110/220, Dual-Drive, 3U (Two Drives) 274334-B21
HP StorageWorks Rackmount SDLT 110/220, Tape Array III, 5U (Four Drives) 274336-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the SDLT 110/22-0GB Tape Drive QuickSpecs for additional options such as
adapters, controllers, and media, and for an up-to-date listing of the latest O/S Support details,
please see the following:
http://h18000.www1.hp.com/products/quickspecs/10772_div/10772_div.HTML (Worldwide)
http://h18000.www1.hp.com/products/quickspecs/10772_na/10772_na.HTML (North America)
HP StorageWorks SDLT 160/320, External NA (carbon) 257319-001
HP StorageWorks SDLT 160/320, External WW (carbon) 257319-B31
HP StorageWorks SDLT 160/320, External Japan (carbon) 257319-291
NOTE:
NOTE:NOTE:
NOTE: Please see the SDLT 160/320-GB Tape Drive QuickSpecs for additional options such as
adapters, controllers, and media, and for an up-to-date listing of the latest O/S Support details,
please see the following:
http://h18006.www1.hp.com/products/quickspecs/10406_div/10406_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/10406_na/10406_na.html (North America)
External SuperLoader
External SuperLoaderExternal SuperLoader
External SuperLoader
DLT1 1280 SuperLoader 268664-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks DLT1 1280 SuperLoader QuickSpecs for additional options and
for an up-to-date listing of the latest O/S Support details, please see the following:
http://h18006.www1.hp.com/products/quickspecs/11406_div/11406_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/11406_na/11406_na.html (North America)
External LTO Ultrium Tape Drives
External LTO Ultrium Tape DrivesExternal LTO Ultrium Tape Drives
External LTO Ultrium Tape Drives
HP StorageWorks Ultrium 230 Tape Drive, External (Carbon) NA Q1516A
HP StorageWorks Ultrium 230 Tape Drive, External (Carbon) Int’l Q1517A
NOTE:
NOTE:NOTE:
NOTE: Please see the HP StorageWorks Ultrium Tape Drive QuickSpecs for additional options such
as controllers, and other related items, and for an up-to-date listing of the latest O/S Support details,
please see the following:
http://h18006.www1.hp.com/products/quickspecs/11415_div/11415_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/11415_na/11415_na.html (North America)
HP StorageWorks Ultrium 460 Tape Drive for ProLiant, External (Carbon) NA Q1519A
HP StorageWorks Ultrium 460 Tape Drive for ProLiant, External (Carbon) Int’l Q1520A
NOTE:
NOTE:NOTE:
NOTE: Please see the HP StorageWorks Ultrium 460 Tape Drives for ProLiant QuickSpecs for
additional options such as data and cleaning cartridges, and for an up-to-date listing of the latest
O/S Support details, please see the following:
http://h18006.www1.hp.com/products/quickspecs/11530_div/11530_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/11530_na/11530_na.html (North America)
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 14

External DAT Autoloader
External DAT AutoloaderExternal DAT Autoloader
External DAT Autoloader
20/40-GB DAT 8 Cassette Autoloader External (Opal) 166505-001
20/40-GB DAT 8 Cassette Autoloader External (Opal) (Int’l) 166505-B31
20/40-GB DAT 8 Cassette Autoloader External (Opal) (Japan) 166505-291
NOTE:
NOTE:NOTE:
NOTE: Please see the 20/40-GB DAT DDS-4 8 Cassette Autoloader QuickSpecs for additional
options
such as adapters, controllers, and cassettes, and for an up-to-date listing of the latest O/S Support
details, please see the following:
http://h18000.www1.hp.com/products/quickspecs/10518_div/10518_div.HTML (Worldwide)
http://h18000.www1.hp.com/products/quickspecs/10518_na/10518_na.HTML (North America)
AIT Autoloader
AIT AutoloaderAIT Autoloader
AIT Autoloader
HP StorageWorks AIT 35 GB Autoloader, Rackmount (Carbon) (NA) 280349-001
HP StorageWorks AIT 35 GB Autoloader, Rackmount (Carbon) (Int’l) 280349-B31
NOTE:
NOTE:NOTE:
NOTE: Please see the AIT 35-GB Autoloader QuickSpecs for additional options such as adapters,
controllers, and cassettes, and for an up-to-date listing of the latest O/S Support details, please see
the following:
http://h18000.www1.hp.com/products/quickspecs/11404_div/11404_div.HTML (Worldwide)
http://h18000.www1.hp.com/products/quickspecs/11404_na/11404_na.HTML (North America)
HP
HPHP
HP StorageWorks
StorageWorksStorageWorks
StorageWorks 1/8 Autoloader
1/8 Autoloader1/8 Autoloader
1/8 Autoloader
HP StorageWorks 1/8 Autoloader, Tabletop, Ultrium 230 C9572CB
HP StorageWorks 1/8 Autoloader, Tabletop, DLT VS80 C9264CB
HP StorageWorks 1/8 Autoloader, Rackmount kit C9266R
Rackmount
RackmountRackmount
Rackmount Tape Drive
Tape DriveTape Drive
Tape Drive Kits
KitsKits
Kits
3U Rackmount Kit 274338-B21
NOTE:
NOTE:NOTE:
NOTE: The 3U Rackmount Kit (PN 274338-B21) can support up to (2) full-height or (4) half-height
tape drives and compatible with multiple internal Single-Ended and LVD SCSI Tape Drives including
the 12/24-GB DAT, 20/40-GB DAT, 20/40-GB DAT DDS-4 8 Cassette Autoloader, AIT 35-GB LVD,
AIT 50 GB, AIT 100 GB, 20/40-GB DLT, 40/80-GB DLT, SDLT 110/220-GB, SDLT 160/320-GB,
Ultrium 230, and Ultrium 460 Tape Drives.
5U Rackmount Kit 274339-B21
NOTE:
NOTE:NOTE:
NOTE: The 5U Rackmount Kit (PN 274339-B21) can support up to (4) full-height tape drives and is
compatible with all HP internal DLT/SDLT/Ultrium tape drives including the 20/40-GB DLT, 35/70-
GB DLT, 40/80-GB DLT, SDLT 110/220-GB, SDLT 160/320, Ultrium 230, and Ultrium 460 tape
drives.
NOTE:
NOTE:NOTE:
NOTE: Please see the Rackmount Tape Drive Kits QuickSpecs for additional information regarding
these kits, please see the following:
http://h18006.www1.hp.com/products/quickspecs/10854_div/10854_div.html (Worldwide)
http://h18006.www1.hp.com/products/quickspecs/10854_na/10854_na.html (North America)
Rackmount
RackmountRackmount
Rackmount Tape Drive
Tape DriveTape Drive
Tape Drive Cable Kits
Cable KitsCable Kits
Cable Kits
LVD Cable Kit, VHDCI/HD68 168048-B21
NOTE:
NOTE:NOTE:
NOTE: For use with the 3U RM Storage Enclosure and DLT Tape Array III only.
LVD Cable Kit, HD68/HD68 242381-B21
NOTE:
NOTE:NOTE:
NOTE: For use with the 3U RM Storage Enclosure and DLT Tape Array III only.
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 15

Tape Automation
Tape AutomationTape Automation
Tape Automation
Entry Level Tape Libraries
Entry Level Tape LibrariesEntry Level Tape Libraries
Entry Level Tape Libraries
SSL2020 Automated AIT Library
SSL2020 Automated AIT LibrarySSL2020 Automated AIT Library
SSL2020 Automated AIT Library
SSL2020 AIT Mini-Library 1 drive, 20 slot Rackmount 175196-B21
SSL2020 AIT Mini-Library 2 drive, 20 slot Rackmount 175196-B22
SSL2020 AIT Library Pass Thru with Transport 175312-B21
SSL2020 AIT Library Pass Thru Extender 175312-B22
AIT 50-GB Drive Add-On LVD Drive for SSL2020 AIT Library 175197-B21
Required Adapters/Controllers for SSL2020 AIT Library
Required Adapters/Controllers for SSL2020 AIT LibraryRequired Adapters/Controllers for SSL2020 AIT Library
Required Adapters/Controllers for SSL2020 AIT Library
64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter 129803-B21
SAN Access Module for Smart Array 5302 Controller 216687-B21
SAN Access Module for Smart Array 5302 Controller (Japan) 216687-291
NOTE:
NOTE:NOTE:
NOTE: Please see the SSL2020 Automated AIT Tape Library Solution QuickSpecs for additional
information including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed
for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/10580_na/10580_na.HTML
(North America) http://h18000.www1.hp.com/products/quickspecs/10580_div/10580_div.HTML
(Worldwide)
MSL5000 Libraries
MSL5000 LibrariesMSL5000 Libraries
MSL5000 Libraries
Mainstream Tape Library
Mainstream Tape LibraryMainstream Tape Library
Mainstream Tape Library
MSL5026DLX DLT Library
MSL5026DLX DLT LibraryMSL5026DLX DLT Library
MSL5026DLX DLT Library
MSL5026DLX, 1 40/80-GB DLT, LVD Rackmount 231891-B21
MSL5026DLX, 2 40/80-GB DLT, LVD Rackmount 231891-B22
MSL5026SL SDLT Library
MSL5026SL SDLT LibraryMSL5026SL SDLT Library
MSL5026SL SDLT Library
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MSL5026DLX or MSL5026SL Library QuickSpecs for additional
information including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed
for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/10860_na/10860_na.HTML
(North America)
http://h18000.www1.hp.com/products/quickspecs/10860_div/10860_div.HTML (Worldwide)
MSL5026SL, Rackmount, 1 SDLT Drive (Graphite) 302512-B21
MSL5026SL, Rackmount, 2 SDLT Drive (Graphite) 302512-B22
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MSL5026SL Library QuickSpecs for additional information
including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a
complete solution at:
http://h18000.www1.hp.com/products/quickspecs/11440_na/11440_na.HTML
(North America) http://h18000.www1.hp.com/products/quickspecs/11440_div/11440_div.HTML
(Worldwide)
MSL5026S2 SDLT Library
MSL5026S2 SDLT LibraryMSL5026S2 SDLT Library
MSL5026S2 SDLT Library
MSL5026S2, Rackmount, 0 Drive Library 293472-B21
MSL5026S2, Rackmount, 1 Drive, SDLT2 Library 293472-B22
MSL5026S2, Rackmount, 2 Drives, SDLT2 Library 293472-B23
MSL5026S2FC, Rackmount, 1 Drive, SDLT2 Library 293472-B24
MSL5026S2FC, Rackmount, 2 Drives, SDLT2 Library 293472-B25
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MSL5026S2 Library QuickSpecs for additional information
including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a
complete solution at:
http://h18000.www1.hp.com/products/quickspecs/11453_na/11453_na.HTML
(North America)
http://h18000.www1.hp.com/products/quickspecs/11453_div/11453_div.HTML (Worldwide)
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 16

Departmental Tape Library
Departmental Tape LibraryDepartmental Tape Library
Departmental Tape Library
MSL5052SL SDLT Library
MSL5052SL SDLT LibraryMSL5052SL SDLT Library
MSL5052SL SDLT Library
MSL5052, Rackmount, 0 Drive, SDLT ALL 255102-B21
MSL50502SL, SDLT, 110/220, 2 Drives, LVD, Rackmount 249491-B21
MSL5K Field Upgrade SDLT 110/220 Drive, LVD 231823-B22
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MSL5052SL Library QuickSpecs for additional information
including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a
complete solution at:
http://h18000.www1.hp.com/products/quickspecs/11061_na/11061_na.HTML
(North America)
http://h18000.www1.hp.com/products/quickspecs/11061_div/11061_div.HTML (Worldwide)
MSL5052S2 SDLT Library
MSL5052S2 SDLT LibraryMSL5052S2 SDLT Library
MSL5052S2 SDLT Library
MSL5052S2, Rackmount, 2 Drives, SDLT2 Library 293474-B21
MSL5052S2FC, Rackmount, 2 Drives, SDLT2 Library 293474-B24
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MSL5052S2 Library QuickSpecs for additional information
including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a
complete solution at:
http://h18000.www1.hp.com/products/quickspecs/11442_na/11442_na.HTML
(North America)
http://h18000.www1.hp.com/products/quickspecs/11442_div/11442_div.HTML (Worldwide)
MSL5030 LTO Library
MSL5030 LTO LibraryMSL5030 LTO Library
MSL5030 LTO Library
MSL5030L1, Rackmount, 0 Drive Library 301897-B21
MSL5030L1, Rackmount, 1 Drive, LTO1 Library 301897-B22
MSL5030L1, Rackmount, 2 Drives, LTO1 Library 301897-B23
MSL5030L1FC, Rackmount, 1 Drive, LTO1 Library 301897-B24
MSL5030L1FC, Rackmount, 2 Drives, LTO1 Library 301897-B25
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MSL5030 LTO Library QuickSpecs for additional information
including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a
complete solution at:
http://h18000.www1.hp.com/products/quickspecs/11439_na/11439_na.HTML
(North America)
http://h18000.www1.hp.com/products/quickspecs/11439_div/11439_div.HTML (Worldwide)
MSL5060 LTO Library
MSL5060 LTO LibraryMSL5060 LTO Library
MSL5060 LTO Library
MSL5060L1, Rackmount, 0 Drive Library 301899-B21
MSL5060L1, Rackmount, 2 Drives, LTO1 Library 301899-B22
MSL5060L1FC, Rackmount, 2 Drives, LTO1 Library 301899-B23
MSL5060L1, Tabletop, 2 Drives, LTO1 Library 301900-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MSL5060 LTO Library QuickSpecs for additional information
including Upgrade Kits, Accessories, and SCSI Cable Kits and additional options needed for a
complete solution at:
http://h18000.www1.hp.com/products/quickspecs/11438_na/11438_na.HTML
(North America)
http://h18000.www1.hp.com/products/quickspecs/11438_div/11438_div.HTML (Worldwide)
MSL5000 series Libraries Options
MSL5000 series Libraries OptionsMSL5000 series Libraries Options
MSL5000 series Libraries Options
MSL5K Field Upgrade SDLT 110/220 Drive, LVD 231823-B22
MSL5000 SDLT2 Upgrade Drive 293475-B21
MSL5000 LTO1 Upgrade Drive 301901-B21
MSL5000 Dual Magazine LTO 301902-B21
MSL5000 Dual Magazine DLT 232136-B21
Required Adapters for MSL5000 series Libraries
Required Adapters for MSL5000 series LibrariesRequired Adapters for MSL5000 series Libraries
Required Adapters for MSL5000 series Libraries
64-Bit/66MHz Dual Channel Wide Ultra3 SCSI Adapter 129803-B21
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 17

Smart Array
Smart ArraySmart Array
Smart Array
ClusterStorage
ClusterStorageClusterStorage
ClusterStorage
Smart Array Cluster Storage 201724-B21
Smart Array Cluster Storage Redundant Controller Option Kit 218252-B21
4-Port Shared Storage Module with Smart Array Multipath Software for Smart Array Cluster Storage 292944-B21
128-MB Cache Module for Smart Array 5302 Controller 153506-B21
256-MB Battery-Backed Cache Module 254786-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the Compaq Smart Array Cluster Storage QuickSpecs for additional information
including configuration steps and additional options needed for a complete solution at:
http://h18000.www1.hp.com/products/quickspecs/11050_na/11050_na.html
(North America)
http://h18000.www1.hp.com/products/quickspecs/11050_div/11050_div.html (Worldwide)
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 18

Cluster Options
Cluster OptionsCluster Options
Cluster Options Compaq ProLiant Cluster HA/F100 for Windows NT and 2000 Advanced Server 309816-B21
Compaq ProLiant Cluster HA/F200 Upgrade Kit (NT 4.0EE to W2K AS) 176848-B22
Compaq ProLiant Cluster HA/F200 for Windows NT and 2000 Advanced Server 380357-B23
Compaq ProLiant Cluster HA/F200 for Windows NT and 2000 Advanced Server (Japan) 380357-293
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the Compaq ProLiant Cluster for HA/F100, HA/F200
for Windows NT and 2000 Advanced Server please see the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/10777_na/10777_na.html (North America)
http://h18000.www1.hp.com/products/quickspecs/10777_div/10777_div.html (Worldwide)
ProLiant Cluster HA/F500 Enhanced Kit for Enterprise Virtual Array v.2 254623-B22
ProLiant Cluster HA/F500 Basic Kit for Enterprise Virtual Array (v.2) 313047-B21
ProLiant Cluster HA/F500 Basic Kit for MA8000/EMA16000 103250-B25
ProLiant Cluster HA/F500 Enhanced Kit for MA8000/EMA16000 379937-B25
ProLiant Cluster HA/F500 Enhanced DT Kit for MA8000/EMA16000 164227-B23
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the Compaq ProLiant Cluster for HA/F500 please see
the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/10232_na/10232_na.html
(North America)
http://h18000.www1.hp.com/products/quickspecs/10232_div/10232_div.html (Worldwide)
ProLiant Cluster HA/F500 Basic Kit for MA8000/EMA16000 103250-B25
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the Compaq ProLiant Cluster HA/F500 for Enterprise
Virtual Array please see the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11055_na/11055_na.html (North America)
http://h18000.www1.hp.com/products/quickspecs/11055_div/11055_div.html (Worldwide)
ProLiant Cluster HA/F100 for MSA1000 v2 252408-B22
ProLiant Cluster HA/F100 for MSA1000 v2 (Japan) 252408-292
ProLiant Cluster HA/F200 for MSA1000 v2 252409-B22
ProLiant Cluster HA/F200 for MSA1000 v2 (Japan) 252409-292
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the Compaq ProLiant Cluster HA/F100 and HA/F200
for MSA1000, please see the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11035_na/11035_na.html
North America
http://h18000.www1.hp.com/products/quickspecs/11035_div/11035_div.html (Worldwide)
ProLiant Cluster HA/L100 LifeKeeper for Linux 303523-B22
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the ProLiant Cluster HA/L100 LifeKeeper for Linux,
please see the following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11533_na/11533_na.html (North America)
http://h18000.www1.hp.com/products/quickspecs/11533_div/11533_div.html (Worldwide)
HP Serviceguard for Linux ProLiant Cluster 305199-B21
NOTE:
NOTE:NOTE:
NOTE: Kit includes 2 licenses, documentation and an Ethernet crossover cable
HP Serviceguard for Linux License 307554-B21
NOTE:
NOTE:NOTE:
NOTE: Kit includes single license version and documentation
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the HP Serviceguard for Linux License, please see the
following QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11518_na/11518_na.html (North America)
http://h18000.www1.hp.com/products/quickspecs/11518_na/11518_na.html (Worldwide)
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 19

External Storage – Rack
External Storage – RackExternal Storage – Rack
External Storage – Rack StorageWorks Enclosure Model 4314R (rack-mountable) 201723-B22
StorageWorks Enclosure Model 4314R (rack-mountable) (Int'l) 218231-B22
StorageWorks Enclosure Model 4314R (rack-mountable) (Japan) 218960-B21
StorageWorks Enclosure Model 4354R (rack-mountable) 218232-B21
StorageWorks Enclosure Model 4354R (rack-mountable) (Int'l) 245299-B21
StorageWorks Enclosure Model 4354R (rack-mountable) (Japan) 286763-B21
NOTE:
NOTE:NOTE:
NOTE: The StorageWorks Enclosure 4300 Family supports the Wide Ultra2/Ultra3 1" Hot Plug Hard
Drives.
StorageWorks Enclosure 4200 Redundant Power Supply Option 119826-B21
StorageWorks Enclosure 4200 Ultra3 Single Bus I/O Module Option 190212-B21
StorageWorks Enclosure 4200 Ultra3 Dual Bus I/O Module Option 190213-B21
StorageWorks Enclosure Tower to Rack Conversion Kit 150213-B21
MSA1000
MSA1000MSA1000
MSA1000 MSA1000 201723-B22
MSA1000 Controller 218231-B22
MSA Fibre Channel I/O Module 218960-B21
MSA1000 Fabric Switch 218232-B21
MSA1000 Fibre Channel Adapter (FCA) 2101 245299-B21
HP StorageWorks msa hub 2/3 286763-B21
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks by Compaq Modular SAN Array 1000 QuickSpecs for
additional options and configuration information at:
http://h18000.www1.hp.com/products/quickspecs/11033_na/11033_na.HTML (North America)
http://h18000.www1.hp.com/products/quickspecs/11033_div/11033_div.HTML (Worldwide)
StorageWorks
StorageWorksStorageWorks
StorageWorks Modular
ModularModular
Modular
Array 8000/Enterprise
Array 8000/EnterpriseArray 8000/Enterprise
Array 8000/Enterprise
Modular Array 12000
Modular Array 12000Modular Array 12000
Modular Array 12000
EMA12000 D14 60Hz 175990-B21
EMA12000 D14 50Hz 175990-B22
EMA12000 S14 60Hz 175991-B21
EMA12000 S14 50Hz 175991-B22
MA8000 60Hz 175992-B21
MA8000 50Hz 175992-B22
EMA12000 Blue 60Hz 175993-B21
EMA12000 Blue 50Hz 175993-B22
NOTE:
NOTE:NOTE:
NOTE: Options include controller, solution kits, ACS. MA8000/EMA12000 includes controller shelf,
drive shelves and cabinet. Packaging upgrade to RA8000/ESA12000.
NOTE:
NOTE:NOTE:
NOTE: Please see the StorageWorks MA8000/EMA12000 QuickSpecs for FC Hubs, FC switches,
platform software, host adapters, disks and options for complete solutions at:
http://h18000.www1.hp.com/products/quickspecs/10545_na/10545_na.HTML (North America)
http://h18000.www1.hp.com/products/quickspecs/10545_div/10545_div.HTML (Worldwide)
QuickSpecs
Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2Compaq ProLiant DL380 G2
Compaq ProLiant DL380 G2
Options
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 20
