HP ProLiant MicroServer Generation 8 User manual

HP ProLiant MicroServer Gen8 is a small, quiet, and stylishly designed server that is ideal for micro and small businesses looking to build
their first IT server environment. With a form factor that is easy to use and service, HP MicoServer Gen8 helps businesses get to a server
that provides better and secured access to data, more efficiency in operations, while driving down their operating expenses.
Front View: Rear View:
1. USB 2.0 connector 1. NIC 2 connector
2. USB 2.0 connector 2. NIC 1 connector / Shared iLO connector
3. DVD-RW (optional) 3. Power cord connector
4. Power On/Standby button and system power LED button 4. PCIe 2.0 x16 slot
5. NIC status LED 5. iLO 4 connector
6. Hard Drive status LED 6. Video connector
7. Intel® Processor 7. USB 3.0 connectors
8. 2 DIMM slots: DDR3 Unbuffered (UDIMM) memory 8. USB 2.0 connectors
9. Health LED
10. Hard Drive Bays
11. Front bezel
What's New
Front Bezel Faceplate Kit allows you to customize your MicroServer
RDX support for disk based data protection
PS1810-24G switch for larger office environments
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Overview
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 1

Processor NOTE: : Intel® Celeron® G1610T and Intel® Pentium® G2020T support up to 1333MHz DDR3 memory speed.
Intel® Celeron® G1610T (2.3Hz/2-core/2MB/35W) Processor
Intel® Pentium® G2020T (2.5GHz/2-core/3MB/35W) Processor
Cache Memory 3MB (1 x 3MB) L3 Cache
NOTE: For Dual-core Pentium processor.
2MB (1 x 2MB) L3 Cache
NOTE: For Dual-core Celeron processor.
NOTE: All processor models above list the L3 Cache associated with that particular processor.
Chipset Intel® C204 Chipset
NOTE: For more information regarding Intel® chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/ .
On System Management
Processor
HP iLO (Firmware: HP iLO 4)
NOTE: For more information, visit: http://www.hp.com/go/ilo .
Memory Protection ECC
Memory Type HP SmartMemory
DDR3 Unbuffered (UDIMM)
DIMM Slots Available 2
Standard 2GB (1 x 2GB) PC3-12800E DDR3 UDIMM
Maximum 16GB (2 x 8GB) PC3-12800E DDR3 UDIMM
NOTE: HP memory from previous generation servers are not fully compatible with the HP ProLiant
MicroServer Gen8.
Network Controller HP Ethernet 1Gb 2-port 332i Adapter
Expansion Slots Expansion
Slot #
Technology Bus
Width *
Connector
Width
Form Factor Notes
1 PCIe 2.0 x16 x16 Low Profile
* Indicates the number of physical electrical lanes running to a PCI-e connector.
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Standard Features
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 2

HP Server ROM HP ROM (Read Only Memory) is now digitally signed using HP's Corporate Signing Service. This signature is
verified before the flash process starts, reducing accidental programming and preventing malicious efforts
to corrupt system ROM.
HP ROM provides for essential initialization and validation of hardware components before control is
passed to the customer-installed operating system. The ROM also provides the capability of booting from
various fixed media (HDD, CD-ROM) and removable media (USB), to continue operation to the operating
system.
HP ROM performs very early configuration of the video controller, to allow monitoring of initialization
progress via an attached monitor. If configuration or hardware errors are discovered during this early
phase of hardware initialization, suitable messages are now displayed on the connected monitor.
Additionally, these configuration or hardware errors are logged to the Integrated Management Log (IML) to
assist in diagnosis.
HP's ProLiant ROM is used to configure the following:
Processor and chipset status registers
System memory, memory map, and memory initialization
System hardware configuration (Integrated PCI devices and optional PCIe cards).
Customer-specific BIOS configuration (using the HP ROM-Based Setup Utility (RBSU).
NOTE: For further information, please refer to HP's RBSU (ROM based setup utility) user guide:
www.hp.com/support/rbsu .
Storage Controller HP Dynamic Smart Array B120i Controller
NOTE: HDD bays 1 and 2 support 6.0Gb/s SATA. HDD bays 3 and 4 support 3.0Gb/s SATA.
NOTE: Supports RAID 0/1/10 only. No FBWC support. For FBWC, a standup Smart Array Controller card
must be configured.
NOTE: For more information about the controller and its features, see the HP Dynamic Smart Array RAID
Controller User Guide on the HP website: ( http://www.hp.com/support/DSA_RAID_UG_en ).
NOTE: To configure arrays, see the Configuring Arrays on HP Smart Array Controllers Reference Guide on
the HP website ( http://www.hp.com/support/CASAC_RG_en ).
NOTE: For general information about HP Smart Array B120i SATA RAID Controller, please go to:
http://h18004.www1.hp.com/products/servers/proliantstorage/
arraycontrollers/dynamicsmartarray/index.html
Internal Storage Devices Optical Drive Optional: SATA DVD-RW drive
Hard Drives None ship standard
Maximum Internal Storage Non-Hot Plug SATA 12TB (4 x 3TB) 3.5" SATA
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Standard Features
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 3

Interfaces Video 1 Rear standard video
HP iLO Remote
Management Network Port
1Gb Dedicated (default iLO4 configuration)
Micro SD slot 1 Internal
NOTE: The MicroSD slot is not a hot-pluggable device. Customers should not
attempt to plug a MicroSD card into the MicroSD slot while the server is
powered.
USB 2.0 Ports 5 total (2 front, 2 rear, 1 internal)
USB 3.0 Ports 2 total (2 rear)
NOTE: Functional after OS boot.
Network RJ-45 (Ethernet) 2 (Port 1 shared for HP iLO4 as optional configuration)
Industry Standard
Compliance
ACPI V2.0b Compliant
PCIe 2.0 Compliant
PXE Support
WOL Support
USB 2.0
USB 3.0
SATA Gen 2
SATA Gen 3
Server Power Cords The MicroServer models ship standard with a 6' country specific NEMA power cord. If customers require an
alternative local power cord, they can check the power cord matrix for the appropriate country specific
sku. Please see the following power cord matrix: http://www.hp.com/go/powercordmatrix .
Power Specifications To review typical system power ratings use the HP Power Advisor which is available via the online tool
located at URL: www.hp.com/go/proliant-energy-efficient or www.hp.com/go/hppoweradvisor .
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html
Power Supply One (1) 150 Watts Non-Hot Plug, Non redundant Power Supply
System Fans One (1) - Non-redundant system fan shipped standard
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Standard Features
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 4

Operating Systems and
Virtualization Software
Support for ProLiant
Servers
Microsoft Windows Server
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
http://www.hp.com/go/ossupport and our driver download page:
http://www.hp.com/support/MicroServerGen8
Graphics Integrated Matrox G200 video standard
1280 x 1024 (32 bpp)
1920 x 1200 (16 bpp)
HP iLO 4 On System Management Memory
16 MB Flash
256 MB DDR 3 with ECC (112 MB after ECC and video)
Form Factor Ultra Micro Tower
On System Management HP iLO Management
Engine
HP iLO Management Engine is a comprehensive set of embedded management
features supporting the complete lifecycle of the server, from initial
deployment, through ongoing management, to service alerting and remote
support. HP iLO Management Engine comes standard on all HP ProLiant Gen8
servers. The HP iLO Management Engine portfolio includes:
HP iLO: The HP iLO (Integrated Lights-Out) management processor is
the core foundation for the HP iLO Management Engine
HP Agentless Management: Provides built in server health monitoring
and alerting capability without OS agents, that starts working the
moment a power cord and an Ethernet cable are connected.
HP Active Health System: Always on, continuous monitoring for
increased stability and shorter downtimes; 100% configuration history;
Health and service alerts and easy export and upload to Service and
Support.
HP Intelligent Provisioning: Lets customers provision and configure a
single server without any separate media. No more SmartStart CDs or
Smart Update Firmware DVD are needed.
To start Intelligent Provisioning:
Press the F10 key during the ProLiant Gen8 server boot
process (also known as power on self test or POST).
Please go to the Intelligent Provisioning website at
www.hp.com/go/intelligentprovisioning for additional
information and to view usage videos.
Use the Service Pack for ProLiant (SPP) at
www.hp.com/go/spp to get firmware and software
updates.
HP iLO Mobile App: Enables the ability to access, deploy, and manage
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Standard Features
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 5

your server anytime from anywhere from select smartphones and
mobile devices. For additional information please visit:
www.hp.com/go/ilo/mobileapp
NOTE: For more information, visit: http://www.hp.com/go/ilo or HP iLO
Management Engine technologies whitepaper
HP Insight Management HP Service Pack for
ProLiant (SPP)
HP Service Pack for ProLiant (SPP) and HP Smart Update Manager (HP SUM)
version 5 provide a new, comprehensive approach to firmware and system
software maintenance. Together they provide better operating stability and
ensure maximum uptime. The SPP will be updated at a predictable cadence,
typically coinciding with new HP server hardware launches. By enabling all
firmware to be updated online and integrating firmware and system software
updates in one operation HP SUM and the SPP offer faster updates of
individual servers and dramatically faster updates of entire BladeSystem
enclosures. Further improving system uptime and stability is the fact that HP
provides 12 months of support on each Service Pack for ProLiant.
The user experience around HP SUM and the SPP has been improved in several
ways, starting with the web download. A single web page provides access to a
single download containing both the latest version of HP SUM version 5 and
the latest SPP. Optional smaller subsets with only specific types of servers or
specific operating systems are offered to save on download time. The HP SUM
application has been re-written to provide a more straightforward, intuitive
user interface that guides the user through the steps of discovery, analyses
and update, providing comprehensive information on available updates,
criticality and interdependencies. This information is also available in reports.
By providing the option of multiple local or shared repositories which can be
easily updated from hp.com, HP SUM provides the tools to optimize stability
and consistency throughout the company. While HP SUM and the SPP will
recommend the combinations of firmware and system software that HP has
found to be the best practice, the application gives customers the flexibility to
set their own specific baseline.
The Service Pack for ProLiant has been rigorously tested with specific
attention for interaction between firmware, drivers and agents both within the
server as well as in interaction with the BladeSystem enclosure components
(Onboard Administrator and Virtual Connect). This testing ensures the highest
quality as well as providing the input for HP SUM to deploy updates taking into
account all interdepencies, when determining the correct updates and order of
update deployment.
NOTE: The Service Pack for ProLiant (which includes HP SUM 5) can be
downloaded from www.hp.com/go/spp/download . More information can be
found: www.hp.com/go/spp and http://www.hp.com/go/hpsum
Security Setup password
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Standard Features
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 6

Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one
year from date of purchase. Support for software and initial setup is available for 90 days from date of
purchase. Enhancements to warranty services are available through HP Care Pack services or customized
service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard
drive QuickSpecs for details.
NOTE: Server Warranty includes 1 year Next Day Parts replacement, 0-Years Labor, 0-Years Onsite
support. Additional information regarding worldwide limited warranty and technical support is available
at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html .
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Standard Features
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 7

HP Insight management
software
HP Insight Control HP Insight Control, a product option, delivers essential infrastructure
management that can help save time and money by making it easy to deploy,
migrate, monitor, remote control, and optimize your IT infrastructure through
a single, simple management console. HP Insight Control also supports
Location and Power Discovery Services to automate many configuration, asset
tracking, and power management tasks to speed implementation and prevent
downtime. For more information, see http://www.hp.com/go/insightcontrol .
HP Insight Control includes one year of 24 x 7 HP Software Technical Support
and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, see:
http://www.hp.com/services/insight .
HP iLO Essentials HP iLO Essentials license ideal for small and medium business customers. The
specially created HP iLO Essentials (a subset of iLO Advanced functionality)
saves SMB customers time and money, by ease of remote server set up
through the interactive virtual media, lowering operational costs with remote
access via the Integrated Remote Console, and faster time to resolution with
email-based proactive notifications. With this newly designed HP iLO
Essentials license SMB customers now have the option of a server
management package solely design and priced just right for their IT
environments. HP iLO Essentials is available on all HP ProLiant Gen8 e-series
making this an ideal solution for small business owners. For more
information, see: http://www.hp.com/go/iLO/essentials
HP iLO Advanced HP Integrated Lights-Out Advanced License a product option, providing smart
remote server management without compromise. iLO Advanced unlocks the
full set of remote administration functionality for all HP ProLiant servers by
activating the full Virtual Keyboard Video and Mouse remote console, multi-
user collaboration, console record and replay, GUI-based and scripted virtual
media and virtual folders, and enhanced security and power management
functionality. For more information, see: http://www.hp.com/go/iloadvance
HP Insight Online HP Insight Online is a new addition to the HP Support Center for one stop, secure access to product and HP
support information personalized to your IT environment. Insight Online can automatically display devices
remotely monitored by HP Insight Remote Support. With Insight Online's easy navigation you can
efficiently track your IT support contracts and device status from anywhere and at anytime.
www.hp.com/go/insightonline
Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
HP Simple Configurator SCE is a guided self service tool to help sales and non technical people provide customers with initial
configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in
your existing ordering processes. If you require "custom" rack configuration or configuration for products
not available in SCE, please contact HP's Customer Business Center or an Authorized Partner for
assistance. http://www.hp.com/products/configurator
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Optional Features
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 8

Service and Support HP Technology Services for Industry Standard Servers
Capitalizing on HP ProLiant server capabilities requires a service partner who understands your
increasingly complex business technology environment. That's why it makes sense to team up with the
people who know HP infrastructure hardware and software best - the experienced professionals at HP
Services.
Protect your business beyond warranty with HP Care Pack Services
HP Care Pack services offer complete care and support expertise with committed response choices
designed to meet your IT and business needs.
HP Foundation Care services offer scalable reactive support-packages for HP industry-standard
servers and software. You can choose the type and level of service that is most suitable for your IT
and business needs.
Optimized Care Supports maintaining servers at optimum performance availability
3-Year HP Hardware Support Onsite Service, 4-hour response, 24x7
For customers who need same day response service level 24x7.
Provides you with an HP authorized representative who will arrive at the Customer's site any time and day
of the year to begin hardware maintenance service within 4 hours of the service request being logged.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE.pdf
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
Standard Care Supports maintaining high level of server availability
3-Year HP Hardware Support Onsite Service, 4-hour response, 13x5
Delivers increased equipment availability and productivity with rapid remote support and onsite response
for your HP server and storage hardware.
The benefits include:
Help improve or maintain system uptime
Convenient onsite support
Committed response time
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner.
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Service and Support
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 9

http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
Basic Care Delivers Minimum Recommended Support Service Level
3-Year HP Hardware Support Onsite Service, Next Business Day Response 9x5
Provides high-quality remote assistance and onsite support for your covered hardware, helping you to
improve product uptime.
The benefits include:
Help improve or maintain system uptime
Convenient onsite support
Reliable response time
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE.pdf
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
Related Services HP Proactive Select Service
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy
Proactive Select Service Credits when you purchase your hardware and then use the credits over the next
12 months. http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN.pdf
Additional HP Care Pack services can be found at: http://www.hp.com/go/cpc
Insight Online/Insight
Remote Support
HP Insight Remote Support provides 24 X 7 remote monitoring, proactive notifications, and problem
resolution. This comes at no additional cost with your HP solution * . Learn more about Insight Remote
Support http://www.hp.com/go/insightremotesupport and Insight Online
http://www.hp.com/go/insightonline
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Service and Support
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 10

HP Support Center Personalized online support portal with access to information, tools and experts to support HP business
products. Submit support cases online, chat with HP experts, access support resources or collaborate with
peers. Learn more http://www.hp.com/go/hpsc
HP's Support Center Mobile App ** allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty,
HP Care Pack or HP contractual support agreement.
** HP Support Center Mobile App is subject to local availability
Parts and Materials HP will provide HP-supported replacement parts and materials necessary to maintain the
covered hardware product in operating condition, including parts and materials for available
and recommended engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the
maximum usage limitations as set forth in the manufacturer's operating manual, product
quick-specs, or the technical product data sheet will not be provided, repaired, or replaced as
part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction.
For more information To learn more on HP ProLiant servers, please contact your HP sales representative or HP Authorized
Channel Partner. Or visit: http://www.hp.com/services/proliant
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Service and Support
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 11

Entry Model
HP ProLiant MicroServer
Gen8 G1610T 1P 2GB-U
B120i NHP SATA 150W PS
Server
712317-xx1
Processor (1) Intel® Celeron® G1610T (2.3GHz/2-core/2MB/35W) Processor
Cache Memory 2MB (1 x 2MB) L3 cache
Memory 2GB (1 x 2GB) PC3-12800E DDR3 UDIMM
NOTE: Total of 2 DIMM slots.
Network Controller HP Ethernet 1Gb 2-port 332i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
Hard Drive None ship standard
Internal Storage 4 LFF NHP SATA HDD cage; includes 4 LFF hard drive carriers
Optical Drive Bay None ship standard
PCI Slots 1 standard (1-Low Profile) PCIe 2.0
Power Supply 150W Non-Hot Plug, Non-Redundant Power Supply
Fans One (1) Non-redundant system fan ships standard
Management HP iLO Management Engine
Optional: iLO Essentials; iLO Advanced
Operating System None
Form Factor Ultra Micro Tower
Warranty Server Warranty includes 1-Year Parts, 0-Year Labor, 0-Year Onsite support
with next business day response
Base Model
HP ProLiant MicroServer
Gen8 G2020T 1P 2GB-U
B120i NHP SATA 150W PS
Server
712318-xx1
Processor (1) Intel® Pentium® G2020T (2.5GHz/2-core/3MB/35W) Processor
Cache Memory 3MB (1 x 3MB) L3 cache
Memory 2GB (1 x 2GB) PC3-12800E DDR3 UDIMM
NOTE: Total of 2 DIMM slots.
Network Controller HP Ethernet 1Gb 2-port 332i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
Hard Drive None ship standard
Internal Storage 4 LFF NHP SATA HDD cage; includes 4 LFF hard drive carriers
Optical Drive Bay None ship standard
PCI-Express Slots 1 standard (1-Low Profile) PCIe 2.0
Power Supply 150W Non-Hot Plug, Non-Redundant Power Supply
Fans One (1) Non-redundant system fan ships standard
Management HP iLO Management Engine
Optional: iLO Essentials; iLO Advanced
Operating System None
Form Factor Ultra Micro Tower
Warranty Server Warranty includes 1-Year Parts, 0-Year Labor, 0-Year Onsite support
with next business day response
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Pre-configured Models
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 12

Country Code Key xx = 00 U.S.
xx = 20 Brazil
xx = 29 Japan
xx = 37 APD
xx = 42 Europe
xx = AA PRC
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Pre-configured Models
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 13

HP Unique Options HP Wireless 802.11 b/g/n PCIe Card FH971AA
HP MicroServer Gen8 Front Bezel Faceplate Kit 722320-B21
HP Memory Unbuffered with ECC DIMMs (UDIMMs)
HP 2GB (1x2GB) Single Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669320-B21
HP 2GB (1x2GB) Single Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647905-B21
HP 4GB (1x4GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669322-B21
HP 4GB (1x4GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647907-B21
HP 8GB (1x8GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669324-B21
HP 8GB (1x8GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647909-B21
NOTE: All DDR3 memory option kits consist of one DIMM per kit. For detailed memory
configuration rules and guidelines, please use the Online DDR3 Memory Configuration
Tool: www.hp.com/go/ddr3memory-configurator .
NOTE: Depending on the memory configuration and processor model, 1600MHz and
1333MHz memory may operate at a lower speed. Please see the see the "Memory"
section later in this document and the Online Memory Configuration Tool for details at
www.hp.com/go/ddr3memory-configurator .
NOTE: For additional memory rules and guidelines, see the "Memory" section later in
this document.
NOTE: For more information on ProLiant Energy Efficient Features, see:
www.hp.com/go/proliant-energy-efficient
NOTE: PC3L is a low voltage memory.
HP Optical Drives HP 9.5mm SATA DVD-RW JackBlack Optical Drive 652241-B21
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Core Options
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 14

HP Hard Drives NOTE: The components of a storage subsystem (e.g. the drive, the HBA/controller,
firmware, and the server backplane) should operate at the same data transfer rate or
the system bandwidth will be negotiated down to an acceptable level for all
components.
NOTE: Hard drives have either a one year or three year warranty; refer to the specific
hard drive QuickSpecs for details.
6G SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives
HP 3TB 6G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard Drive 628065-B21
HP 2TB 6G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard Drive 659339-B21
HP 1TB 6G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard Drive 659337-B21
HP 500GB 6G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard
Drive
659341-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13021_div/13021_div.html
(Worldwide)
HP Networking HP NC112T PCI Express Gigabit Server Adapter 503746-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information: www.hp.com/go/ProLiantNICs
HP Networking Switches HP PS1810-8G Switch J9833A
HP PS1810-24G Switch J9834A
NOTE: HP PS1810 Series Switches have been custom designed to work with the HP
ProLiant MicroServer Gen8. These are layer 2 web-managed gigabit switches with two
offerings - 8 port and 24 port models. PS1810 Switches have built-in technology that
will enable automatic discovery of ProLiant Gen8 Servers. In addition the 8 port switch
had a unique chassis design that enables physical stacking on the MicroServer.
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18004.www1.hp.com/products/quickspecs/14586_div/14586_div.html
(Worldwide)
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Core Options
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 15

HP Insight Software HP Insight Control
HP Insight Control including 1yr 24x7 Technical Support and Updates Single Server
License
C6N27A
HP Insight Control including 1yr 24x7 Technical Support and Updates Electronic License C6N28ABE
HP Insight Control Server Provisioning Media Kit BD883A
HP Insight Management Media Kit
C6N31A
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle FIO Electronic
License
C6N36ABE
NOTE: Electronic and Flexible-Quantity licenses can be used to purchase multiple
licenses with a single activation key.
NOTE: Customer will receive a license entitlement certificate. The license entitlement
certificate must be redeemed online or via fax in order to obtain the license activation
key(s). Includes one year of 24 x 7 HP Software Technical Support and Update Service.
NOTE: Licenses ship without media. The HP Insight Control Media Kit can be ordered
separately, or can be downloaded at: http://www.hp.com/go/insightupdates
HP Insight Control server deployment
HP Insight Control Server Deployment including 1yr 24x7 Support Single Server License 452151-B21
HP Insight Control Server Deployment including 1yr 24x7 Support Electronic License T9082AAE
NOTE: For additional license options please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html .
HP Integrated Lights-Out (iLO)
HP Integrated Lights-Out (iLO) Advanced for ProLiant
HP Integrated Lights-Out Essentials including 1yr 24x7 Tech Support and Updates E-
LTU
E6U62ABE
HP Integrated Lights-Out Essentials including 3yr 24x7 Tech Support and Updates E-
LTU
E6U61ABE
HP iLO Advanced including 3yr 24x7 Tech Support and Updates Electronic License
E6U64ABE
HP iLO Advanced including 1yr 24x7 Technical Support and Updates Electronic License E6U59ABE
NOTE: For additional license options please see the QuickSpecs at:
http://h18004.www1.hp.com/products/quickspecs/14276_div/14276_div.html
NOTE: For more information, visit: http://www.hp.com/go/ilo .
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Additional Options
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 16

HP Security HP MicroServer Gen8 Front Bezel Faceplate Kit 722320-B21
HP Trusted Platform Module Option 488069-B21
NOTE: The TPM (Trusted Platform Module) is a microcontroller chip that can securely
store artifacts used to authenticate the server platform. These artifacts can include
passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption
(BitLocker) is a data protection feature available in Windows Server® 2008. BitLocker
leverages the enhanced security capabilities of a Trusted Platform Module (TPM)
version 1.2. The TPM works with BitLocker to help protect user data and to ensure that
a server running Windows Server 2008 has not been tampered with while the system
was offline. For more information about TPM, including a white paper, go to:
www.hp.com/go/TPM .
NOTE: The TPM key is unique to every TPM deployed server and must be retained.
Misplacing or losing the key could result in data loss.
HP Storage Controllers SAS Controllers
Smart Array P222 Controller
HP Smart Array P222/512 FBWC 6Gb 1-port Int/1-port Ext SAS Controller
NOTE: HP Smart Array P22/512 FBWC qualified for RAID support only for HP ProLiant
MicroServer Gen8.
631667-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/14227_div/14227_div.html
(Smart Array P222 Controller)
HP Disk Backup NOTE: For the complete range of RDX drives and media see: http://www.hp.com/go/rdx
HP RDX Removable Disk Backup Systems USB
HP RDX500 USB3.0 Internal Disk Backup System B7B64A
HP RDX500 USB3.0 Internal Disk Backup System B7B64A
HP RDX320 USB3.0 Internal Disk Backup System B7B62A
HP RDX320 USB3.0 External Disk Backup System B7B63A
HP RDX500 USB3.0 External Disk Backup System B7B66A
HP RDX1000 USB3.0 External Disk Backup System B7B69A
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Additional Options
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 17

HP Uninterruptible Power
Systems
HP Tower - UPS
HP T750 G2 UPS Models
HP T750 G2 750VA NA Tower Uninterruptible Power System AF446A
HP T750 G2 750VA INTL Tower Uninterruptible Power System AF447A
HP T750J JP Uninterruptible Power System AF456A
HP T1000 G3 UPS Models
HP T1000 G3 1000VA NA Tower Uninterruptible Power System AF448A
HP T1000 G3 1000VA INTL Tower Uninterruptible Power System AF449A
HP T1000J JP Uninterruptible Power System AF457A
HP T1500 G3 UPS Models
HP T1500 G3 1400VA NA Tower Uninterruptible Power System AF450A
HP T1500 G3 1400VA INTL Tower Uninterruptible Power System AF451A
HP T1500J JP Uninterruptible Power System AF458A
NOTE: For additional information please go to: http://www.hp.com/go/rackandpower
(Worldwide)
NOTE: Please see QuickSpecs for Technical Specifications and additional information:
http://h18004.www1.hp.com/products/quickspecs/13160_div/13160_div.html
HP Rack Options HP USB Keyboard and Mouse
HP USB BFR with PVC Free US Keyboard/Mouse Kit 631341-B21
HP USB BFR with PVC Free UK Keyboard/Mouse Kit 631344-B21
HP USB BFR with PVC Free FR Keyboard/Mouse Kit 631346-B21
HP USB BFR with PVC Free ES Keyboard/Mouse Kit 631348-B21
HP USB BFR with PVC Free DE Keyboard/Mouse Kit 631358-B21
HP USB BFR with PVC Free JP Keyboard/Mouse Kit 631360-B21
HP USB BFR with PVC Free IT Keyboard/Mouse Kit 631362-B21
HP USB BFR with PVC Free CN Keyboard/Mouse Kit 631364-B21
HP USB BFR with PVC Free AE Keyboard/Mouse Kit 638212-B21
HP USB BFR with PVC Free RU Keyboard/Mouse Kit 638214-B21
HP USB BFR with PVC Free SE Keyboard/Mouse Kit 672097-103
HP USB BFR with PVC Free CH Keyboard/Mouse Kit 672097-113
HP USB BFR with PVC Free PT Keyboard/Mouse Kit 672097-133
HP USB BFR with PVC Free TR Keyboard/Mouse Kit 672097-143
HP USB BFR with PVC Free CZ Keyboard/Mouse Kit 672097-223
HP USB BFR with PVC Free FI Keyboard/Mouse Kit 672097-353
HP USB BFR with PVC Free AP-Intl Keyboard/Mouse Kit 672097-373
HP USB BFR with PVC Free Intl Keyboard/Mouse Kit 672097-B33
HP USB BFR with PVC Free IN Keyboard/Mouse Kit 672097-D63
HP USB BFR with PVC Free KR Keyboard/Mouse Kit 672097-KD3
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Additional Options
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 18

NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13972_div/13972_div.html
(Worldwide)
HP USB and SD Options HP Flash Media Kits for USB Drives
HP 2GB USB Flash Media Drive Key Kit
NOTE: HP qualified blank USB key for use with HP ProLiant servers that support the
VMware virtualization environment and other HP value-add software. HP recommends
this industry standard USB flash device for use with VMware ESXi. USB device must be
installed in the internal slot of the ProLiant server for use with VMware ESXi. Refer to
HP VMware Getting Started Guide for installation instructions.
608447-B21
HP Enterprise Performance Flash Media Kits for Memory Cards
HP 4GB microSD Enterprise Performance Flash Media Kit 647444-B21
HP Enterprise Mainstream Flash Media Kits for Memory Cards
HP 8GB microSD Enterprise Mainstream Flash Media Kit 726116-B21
HP 32GB microSD Enterprise Mainstream Flash Media Kit 700139-B21
NOTE: Blank SD media device is supported for use with VMware. SD media must be
installed in the internal slot of the ProLiant server. Learn more at:
http://www.hp.com/go/proliantvirtualization .
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/13971_div/13971_div.html
HP Care Pack Services HP 3 year Next business day ProLiant MicroServer Hardware Support UR482E
HP 3 year 4 hour 13x5 ProLiant MicroServer Hardware Support UR483E
HP 3 year 4 hour 24x7 ProLiant MicroServer Hardware Support UR484E
HP Install ProLiant MicroSever Service UR508E
NOTE: For more information, customer/resellers can contact:
http://www.hp.com/services/carepack .
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Additional Options
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 19

HP ProLiant Micro Server Generation 8
Standard Memory
2GB (1x2GB) PC3-12800E DDR3 UDIMM Memory kit installed
Standard Memory Replaced with Optional Memory
Up to 16GB of memory is available with the removal of the standard 2GB of memory and the optional installation of 2 x 8 GB PC3-
12800E DDR3 UDIMM Memory kits.
NOTE: The below chart does not represent all possible memory configurations.
Memory Slot
1A 2B
Standard 2 GB 2 GB Empty
Optional 4 GB 2 GB 2 GB
Optional 4 GB 4 GB Empty
Optional 8 GB 4 GB 4 GB
Maximum 16 GB 8 GB 8 GB
Following are memory options available from HP:
HP Memory Unbuffered with ECC DIMMs (UDIMMs)
HP 2GB (1x2GB) Single Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669320-B21
HP 2GB (1x2GB) Single Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647905-B21
HP 4GB (1x4GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669322-B21
HP 4GB (1x4GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647907-B21
HP 8GB (1x8GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669324-B21
HP 8GB (1x8GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647909-B21
NOTE: All DDR3 memory option kits consist of one DIMM per kit. For detailed memory
configuration rules and guidelines, please use the Online DDR3 Memory Configuration
Tool: www.hp.com/go/ddr3memory-configurator .
NOTE: Depending on the memory configuration and processor model, 1600MHz and
1333MHz memory may operate at a lower speed. Please see the see the "Memory"
section later in this document and the Online Memory Configuration Tool for details at
www.hp.com/go/ddr3memory-configurator .
NOTE: For additional memory rules and guidelines, see the "Memory" section later in
this document.
NOTE: For more information on ProLiant Energy Efficient Features, see:
www.hp.com/go/proliant-energy-efficient
NOTE: PC3L is a low voltage memory. Low voltage memory operates at standard
QuickSpecs
HP ProLiant MicroServer Generation 8 (Gen8)
Memory
DA - 14565 Worldwide — Version 6 — October 11, 2013 Page 20
