HP ProLiant ML350e Gen 8 v2 Assembly instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Servers
Marketing Name / Model
[List multiple models if applicable.]
HP ProLiant ML350e Gen 8 v2
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
3
Batteries
All types including standard alkaline and lithium coin
or button style batteries
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
0
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
Depending on Power Supply Model
4
External electrical cables and cords
0
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Torx Driver
T-15
Philps screw driver
#2
Flat Head screw driver
Medium
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Board Battery - Remove the top cover and locate the battery on the system board.
2. Capacitors in 460W ATX power supply=> 2.5 cm () - Remove the power supply from the system with a T-15 torx
driver. With a #2 Philips screw driver remove the screws securing the top cover then locate the capacitors and pry from
the PCB with a flat head screw driver or Long Nose Plier () and dispose of properly.
3. Capacitors in 460W and 750W redundant power supply=> 2.5 cm () - Remove the power supply from the system with
a T-15 torx driver. With a #2 Philips screw driver remove the screws securing the top cover then locate the capacitors
and pry from the PCB with a flat head screw driver or Long Nose Plier and dispose of properly.
4.
5.
6.
7.
8.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Attachment 1 –RTC location
Attachment 2-4- 2.5cm Capacitor location

EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Attachement 1

EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Number 10 is RTC battery.

EL-MF877-00 Page 5
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Attachment 2
POWER CAPACITOR –460W ATX PSU

EL-MF877-00 Page 6
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Attachment 3
POWER CAPACITOR –460W RPSU
Attachment 4
POWER CAPACITOR –750W RPSU
