HP StorageWorks MSA2000 3.5-inch
LFF Drive Enclosure Firmware Release
Notes
Part number: 536919–003
Third edition: February 2010

Legal and notice information
© Copyright 2009-2010 Hewlett-Packard Development Company, L.P.

Firmware version: O300B28
Description
These release notes are for the firmware indicated above, which adds improvements and corrects
issues found during use and additional qualification testing after initial product release.
Firmware can be installed from any computer running a supported operating system with an Ethernet
connection to the storage array system. For supported operating systems, see Operating systems.
Installation procedures vary, depending on connection environment and user preference. For details,
see Installation instructions.
Update recommendation Recommended
Supersedes All previously released firmware versions.
Product models
HP StorageWorks MSA2000 3.5-inch LFF Drive Enclosure
Operating systems
Operating systems supported for use with the HP StorageWorks MSA2000 disk enclosure and the
binary firmware package:
•Microsoft Windows Server 2008 and 2008 R2 IA32, x64, IA64 (Standard, Enterprise, Datacenter)
•Microsoft Windows Server 2008 x64 Hyper-V
•Microsoft Windows 2003 and 2003 R2 IA32, x64, IA64
•Red Hat Enterprise Linux 4 x86, x64, IA64
•Red Hat Enterprise Linux 5 x86, x64, IA64
•SuSE Linux Enterprise Server 10 x86, x64, IA64
•VMware ESX 3.0.1, 3.0.2, 3.5, 4.0 Editions
•Citrix XenServer HP Enterprise Edition
•Red Hat Virtualization
•HP-UX 11i V3 Integrity, HP9000
•HP-UX 11i V2 Integrity, HP9000
•OpenVMS 8.3. OpenVMS 8.3-1H1
Operating systems supported for use with the Smart Component firmware package:
•Microsoft Windows Server 2003 x86, x64, IA64
•Microsoft Windows Server 2008 x86, x64, IA64
•Red Hat Enterprise Linux 4 x86, x64, IA64
•Red Hat Enterprise Linux 5 x86, x64, IA64
•SuSE Linux Enterprise Server 10 x86, x64, IA64
HP StorageWorks MSA2000 3.5-inch LFF Drive Enclosure Firmware Release Notes 3

Enhancements
•Added support for the P2000 G3 MSA Array System.
•In systems operating on a single power supply, performance was improved by implementing a
staggered spin-up for the disk drives in the enclosures. (Do not perform system updates or operate
the enclosure for an extended period of time on one power supply; replace failed components as
soon as possible.)
•Improved event log reporting to include older entries from the event buffer in the log.
•Added support for additional power supply monitoring.
Fixes
•Fixed an issue where drive LEDs may not be turned off after the issue that turned the light on has
been corrected.
•Fixed SMU Show Expander Status display to correctly show logical and physical mappings.
Installation instructions
When planning for a firmware upgrade, select and schedule an appropriate time to perform an online
upgrade.
•For single domain systems, I/O must be halted.
•For dual domain systems, selecting the appropriate time is essential. Because the online firmware
upgrade is performed while host I/Os are being serviced, the I/O load can impact the upgrade
process. Selecting a period of low I/O activity will ensure the upgrade completes as quickly as
possible and will avoid disruptions to hosts and applications due to timeouts.
WARNING!
Do not cycle power or restart devices during a firmware update. If the update is interrupted or there
is a power failure, the module could become inoperative. If this occurs, contact technical support. The
module may need to be returned to the factory for reprogramming.
CAUTION:
Before upgrading firmware, ensure that the storage system configuration is stable and is not being
reconfigured or changed in any way. If configuration changes are in progress, monitor them and
wait until they are completed before proceeding with the upgrade.
IMPORTANT:
As with any firmware upgrade, it is a recommended best practice to ensure that you have a full
backup prior to the upgrade.
4

NOTE:
To install this firmware, you must download the firmware package from the HP website and save the
file to your local filesystem.
Smart Component installation instructions for Windows environments
This is a self-extracting executable module. You can execute this module from the Windows graphical
user interface (GUI) or the command line console (CLI).
GUI option
1. Place the downloaded firmware package in a temporary directory.
2. Using Windows Explorer, navigate to the directory containing the download.
3. Double click the executable file.
4. Follow onscreen instructions.
NOTE:
When prompted for logon information, enter credentials for an account with management
access rights.
CLI option
Execute the Smart Component by entering the following command: CPxxxxxxx.exe /target
<ip_address> /user <username> /passwd <password> /s
where:
•ip_address is the management IP address of the array controller
•username is the username account with management rights
•password is the password associated with the username account
Instead of command line parameters you can use the following DOS environment variables:
•oa_address: set this variable for the IP address of the array controller
•oa_username : set this variable for the username of the account for the array controller
•oa_password : set this variable for the password for the username account
NOTE:
When prompted for logon information, enter credentials for an account with management access
rights.
HP StorageWorks MSA2000 3.5-inch LFF Drive Enclosure Firmware Release Notes 5

Smart Component installation instructions for Linux environments
1. Place the downloaded firmware package in a temporary directory.
2. Open a Linux command console.
3. From the directory containing the downloaded file, enable execute access by entering chmod
+x CPxxxxxx.scexe, where CPxxxxxx.scexe represents the downloaded file.
4. Execute the Smart Component by entering a command similar to the following: ./
CPxxxxxx.scexe --target <ip_address> --user <username> --passwd
<password>
NOTE:
•Use the -e or -f option when flashing a device, even if it is up to date.
•Use the -g option when downgrading.
•For details on supported command options, see the online help by executing the command
./CPxxxxxx.scexe or ./CPxxxxxx.scexe -h.
•If the user name or password contains an exclamation mark (!), enclose the string in
single quotes or enter a backslash (\) before the exclamation point. For example,
'!manage' or \!manage.
5. Follow onscreen instructions.
NOTE:
When prompted for logon information, enter credentials for an account with management
access rights.
6

Instructions using Storage Management Utility (SMU) —MSA2000 G1
environments
WARNING!
Do not cycle power or restart devices during a firmware update. If the update is interrupted or there
is a power failure, the module could become inoperative. If this occurs, contact technical support. The
module may need to be returned to the factory for reprogramming.
1. Place the downloaded firmware package in a temporary directory.
2. If using a Smart Component, extract the contents of the Smart Component.
In Windows —Click Extract on the first screen of the Smart Component.
In Linux —Enter ./CPxxxxxx.scexe --unpack=<folder name> to extract the contents of
the Smart Component to the <folder name> folder. For example,./CP001123.scexe
–unpack=extract_here
3. Locate the firmware file in the extracted folder. The firmware filename is in the following format:
mercurysw-O300B28-01.bin
4. If the system has a single controller, stop I/O to vdisks before starting the firmware update.
5. Login to the SMU and select Manage > Update Software > Enclosure Firmware > Update Firmware.
6. Select the type of expansion modules to update. Expansion modules that have the same
manufacturer, model, and firmware revision are considered the same type. For example, two
identical expansion modules with different firmware revisions are considered to be different types.
7. Click Select Type And Continue.
Enclosure processors of the selected type are listed, with the following information displayed for
each enclosure:
•Device WWN : The drive enclosure's node World Wide Name.
•Address : The channel and loop ID of the expansion module.
•Manufacturer : The expansion module manufacturer.
•Model : The expansion module model number.
•Rev : The revision code for the firmware currently in the expansion module.
If more than two enclosure modules are listed, a Select All check box is displayed.
8. Select the enclosure modules to update.
NOTE:
All enclosures in an array configuration must use the same firmware version.
9. Click Continue.
10. Click Browse and select the firmware file to install.
11. Click Load Device Firmware File.
12. In the SMU display, verify that the proper firmware version appears for each updated module.
HP StorageWorks MSA2000 3.5-inch LFF Drive Enclosure Firmware Release Notes 7

Installation instructions using Storage Management Utility (SMU) —MSA2000
G2 and P2000 G3 environments
WARNING!
Do not cycle power or restart devices during a firmware update. If the update is interrupted or there
is a power failure, the module could become inoperative. If this occurs, contact technical support. The
module may need to be returned to the factory for reprogramming.
1. Place the downloaded firmware package in a temporary directory.
2. If using a Smart Component, extract the contents of the Smart Component.
In Windows —Click Extract on the first screen of the Smart Component.
In Linux —Enter ./CPxxxxxx.scexe --unpack=<folder name> to extract the contents of
the Smart Component to the <folder name> folder. For example,./CP001123.scexe
–unpack=extract_here
3. Locate the firmware file in the extracted folder. The firmware filename is in the following format:
mercurysw-O300B28-01.bin
4. In single-domain environments, I/O to vdisks before starting the firmware update.
5. Login to the SMU and, in the Configuration View panel, right-click the system and select Tools >
Update Firmware.
A table displays currently installed firmware versions.
6. Select the modules to update.
7. Click Browse and select the firmware file to install.
8. Click Install Expansion-Module Firmware File.
Wait for progress messages to specify that the update is complete.
9. In the SMU display, verify that the proper firmware version appears for each module.
8

Installation instructions using FTP
WARNING!
Do not cycle power or restart devices during a firmware update. If the update is interrupted or there
is a power failure, the module could become inoperative. If this occurs, contact technical support. The
module may need to be returned to the factory for reprogramming.
1. Place the downloaded firmware package in a temporary directory.
2. If using a Smart Component, extract the contents of the Smart Component.
In Windows —Click Extract on the first screen of the Smart Component.
In Linux —Enter ./CPxxxxxx.scexe --unpack=<folder name> to extract the contents of
the Smart Component to the <folder name> folder. For example,./CP001123.scexe
–unpack=extract_here
3. Locate the firmware file in the extracted folder. The firmware filename is in the following format:
mercurysw-O300B28-01.bin
4. Do one of the following:
•To update all modules, proceed to step 5.
•To update specific modules, do the following to determine the address of each module to
update:
In the CLI, display the addresses by entering the show enclosures command. The needed
data is displayed in the columns labeled EMP A CH:ID Rev and EMP B CH:ID Rev.
5. In the SMU, prepare to use FTP:
a. Determine the network-port IP addresses of the system controllers.
b. Verify that the system FTP service is enabled.
c. Verify that the user you will log in as has permission to use the FTP interface and has
management access rights.
6. In single-domain environments, I/O to vdisks before starting the firmware update.
7. Open a command prompt (Windows) or a terminal window (UNIX), and navigate to the directory
containing the firmware file to load.
a. Enter ftp <controller-network-address>. (For example: ftp 10.1.0.9)
b. Log in as an FTP user (user = ftp, password = flash).
c. Enter one of the following commands:
•To update all detected modules, enter: put <firmware-file> encl flash. For
example: put O300B28.bin encl flash
•To update a specific module, enter: put <firmware-file> encl:<channel-
ID>:<EMP-number> flash. For example: put O300B28.bin encl:0:15 flash
8. If needed, repeat these steps to load the firmware on additional modules.
9. Quit the FTP session.
10. In the SMU display, verify that the proper firmware version appears for each module.
HP StorageWorks MSA2000 3.5-inch LFF Drive Enclosure Firmware Release Notes 9

Effective date
February 2010
