Do you need a direct attached or shared storage solution within your BladeSystem enclosure?
Direct attached storage
Direct attached storageDirect attached storage
Direct attached storage
The D2200sb Storage Blade delivers direct attached storage for c-Class servers, with support for up to twelve hot plug small form
factor (SFF) SAS hard disk drives or SAS/SATA SSDs or SATA Midline hard disk drives . The enclosure backplane provides a PCI
Express connection to the adjacent c-Class server blade and enables high performance storage access without any additional cables.
The D2200sb Storage Blade features an onboard Smart Array P410i controller with 1 GB flash-backed write cache, for increased
performance and data protection.
Two ways to create shared storage with the D2200sb
Two ways to create shared storage with the D2200sbTwo ways to create shared storage with the D2200sb
Two ways to create shared storage with the D2200sb
Use HP P4000 Virtual SAN Appliance (VSA) software to turn the D2200sb into an iSCSI SAN for use by all servers in the enclosure
and any server on the network. HP VSA software is installed in a virtual machine on a VMware ESX host server adjacent to the
D2200sb. HP P4000 VSA turns the D2200sb into a scalable and robust iSCSI SAN, featuring storage clustering for scalability,
Network RAID for storage failover, thin provisioning, snapshots, remote replication, and cloning. Expand capacity within the same
enclosure or to other BladeSystem enclosures by adding additional D2200sb Storage Blades and HP VSA licenses. A cost effective
bundle of the D2200sb Storage Blade and a HP P4000 VSA license makes purchasing convenient. If storage needs increase, add
HP P4300 or P4500 systems externally and manage everything via a single pane of glass.
The HP X1800sb Network Storage Blade is a flexible storage server solution for BladeSystem environments. Combine the X1800sb
with the D2200sb Storage Blade to enable file serving and iSCSI shared storage inside the BladeSystem enclosure.
1. Product information tag 4. Hard drive drawer handle
2. LED panel 5. Storage blade locking lever *
3. Hard drive drawer release latch * Removing the storage blade from the enclosure removes
power from the hard drives.
What's New
What's NewWhat's New
What's New
Support of new Enterprise 300GB 15K SAS HDD
Support BL 860c.
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Overview
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 1

Key Features
Key FeaturesKey Features
Key Features Features of the D2200sb include:
Features of the D2200sb include:Features of the D2200sb include:
Features of the D2200sb include:
SFF (SAS/SAS SSD/SATA SSD) support - Delivering data transfer rates up to 6 Gb/s for SAS and SAS SSD
and 3Gb/s for SATA SSD and SATA MDL HDD
Support for up to twelve (12) hot plug SFF SAS or SAS/SATA/Solid State or SATA Midline hard disk
drives in a half-height blade
Internal Smart Array P410i with 1 GB flash-backed write cache
Simple configuration and setup with HP's Array Configuration Utility (ACU)
Easy to maintain and troubleshoot with industry standard management tools including HP System
Insight Manager
Use with HP LeftHand Virtual SAN Appliance software to create a robust shared storage
environment inside BladeSystem enclosures
Protected by HP Services and a worldwide network of HP Authorized Channel Partners. Three-year
parts limited global warranty. Certain restrictions and exclusions apply.
Mix and Match of Hard
Mix and Match of HardMix and Match of Hard
Mix and Match of Hard
Drive Types
Drive TypesDrive Types
Drive Types
D2200sb supports mixing of different drive types (SAS/SATA, SSD/HDD) in a single enclosure. However,
please note also that an array can be created across only one drive type.
Universal hot plug Hard
Universal hot plug HardUniversal hot plug Hard
Universal hot plug Hard
Drive
DriveDrive
Drive
Form factor is for use across multiple HP ProLiant servers, disk enclosures and storage systems. With
compatibility across many enterprise platforms, you are free to deploy and re-deploy these drives to
quickly deliver increased storage capacity, migrate data between systems, and easily manage spare
drives.
LED Indicators
LED IndicatorsLED Indicators
LED Indicators Front panel LEDs indicate drive activity and system health status.
Density
DensityDensity
Density The D2200sb fits into a half height bay on the BladeSystem c3000 and c7000 Enclosure.
Fault Tolerance
Fault ToleranceFault Tolerance
Fault Tolerance Using the internal Smart Array P410i controller with1 GB flash-backed write cache, the D2200sb can be
configured for RAID levels 0, 1, 1 + 0, 5, and 6 (RAID ADG)
NOTE:
NOTE:NOTE:
NOTE: RAID 6 and RAID 60 support requires purchase of Smart Array Advanced Pack (SAAP) license
Manageability
ManageabilityManageability
Manageability All Smart Array products utilize a standard set of management and utility software. These tools minimize
Total Cost of Ownership (TCO) by reducing training requirements and technical expertise necessary to
install and maintain the HP server storage.
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Product Highlights
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 2

Fault Prevention
Fault PreventionFault Prevention
Fault Prevention The following features offer detection of possible failures before they occur, allowing preventive action to
be taken:
S.M.A.R.T.: Self Monitoring Analysis and Reporting Technology first developed at HP detects
possible hard disk failure before it occurs, allowing replacement of the component before failure
occurs.
Drive Parameter Tracking monitors drive operational parameters, predicting failure and notifying
the administrator.
Dynamic Sector Repairing continually performs background surface scans on the hard disk drives
during inactive periods and automatically remaps bad sectors, ensuring data integrity.
Smart Array Cache Tracking monitors integrity of controller cache, allowing pre-failure
preventative maintenance.
Environment Tracking for External Storage System: Monitors fan speed and cabinet temperature of
ProLiant Storage System and newer HP storage enclosures.
D2200sb Blade server support matrix
D2200sb Blade server support matrixD2200sb Blade server support matrix
D2200sb Blade server support matrix
Supported Servers
Supported ServersSupported Servers
Supported Servers Server: Full Height
Server: Full HeightServer: Full Height
Server: Full Height
or Half Height
or Half Heightor Half Height
or Half Height
No of D2200sb
No of D2200sbNo of D2200sb
No of D2200sb
Storage blades
Storage bladesStorage blades
Storage blades
Supported
SupportedSupported
Supported
Pass Thru Card
Pass Thru CardPass Thru Card
Pass Thru Card
Required
RequiredRequired
Required
Mezz slot to support
Mezz slot to supportMezz slot to support
Mezz slot to support
1st Pass Thru Card
1st Pass Thru Card1st Pass Thru Card
1st Pass Thru Card
Mezz slot to support
Mezz slot to supportMezz slot to support
Mezz slot to support
2nd Pass Thru Card
2nd Pass Thru Card2nd Pass Thru Card
2nd Pass Thru Card
X86 server blades
X86 server bladesX86 server blades
X86 server blades
BL280c G6
BL280c G6BL280c G6
BL280c G6 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL460c G6
BL460c G6BL460c G6
BL460c G6 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL460c G7
BL460c G7BL460c G7
BL460c G7 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL490c G6
BL490c G6BL490c G6
BL490c G6 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL490c G7
BL490c G7BL490c G7
BL490c G7 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL465c G6
BL465c G6BL465c G6
BL465c G6 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL465c G7
BL465c G7BL465c G7
BL465c G7 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL495c G6
BL495c G6BL495c G6
BL495c G6 Half
HalfHalf
Half 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL620c G7
BL620c G7BL620c G7
BL620c G7 Full
FullFull
Full 2
22
2 Yes
YesYes
Yes 2
22
2 3
33
3
BL685c G6
BL685c G6BL685c G6
BL685c G6 Full
FullFull
Full 2
22
2 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL685c G7
BL685c G7BL685c G7
BL685c G7 Full
FullFull
Full 2
22
2 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL680c G7
BL680c G7BL680c G7
BL680c G7 Full
FullFull
Full Not supported
Not supportedNot supported
Not supported n/a
n/an/a
n/a n/a
n/an/a
n/a n/a
n/an/a
n/a
Integrity server blades
Integrity server bladesIntegrity server blades
Integrity server blades
BL860c i2
BL860c i2BL860c i2
BL860c i2 Full
FullFull
Full 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL860c
BL860cBL860c
BL860c Full
FullFull
Full 1
11
1 Yes
YesYes
Yes 3
33
3 n/a
n/an/a
n/a
BL870c
BL870cBL870c
BL870c Full
FullFull
Full Not supported
Not supportedNot supported
Not supported n/a
n/an/a
n/a n/a
n/an/a
n/a n/a
n/an/a
n/a
BL870ci2
BL870ci2BL870ci2
BL870ci2 Full
FullFull
Full 1
11
1 No
NoNo
No n/a
n/an/a
n/a n/a
n/an/a
n/a
BL890ci2
BL890ci2BL890ci2
BL890ci2 Full
FullFull
Full Not supported
Not supportedNot supported
Not supported n/a
n/an/a
n/a n/a
n/an/a
n/a n/a
n/an/a
n/a
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Product Highlights
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 3

Operating Systems
Operating SystemsOperating Systems
Operating Systems Windows Server: 2003, 2008
Red Hat Enterprise: RHEL5, RHEL6
SLES (x86): SLES10, SLES11
VMware ESX: 3.5, 4.0, ESXi 5.0
HP-UX
NOTE:
NOTE:NOTE:
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
http://www.hp.com/go/supportos .
Software Suite
Software SuiteSoftware Suite
Software Suite Systems Insight Manager
Systems Insight ManagerSystems Insight Manager
Systems Insight Manager
Powerful server and server options/storage manager tool
Monitors over 1,200 system wide parameters
Configuration/Diagnostic Utilities
HP Array Configuration Utility
HP Array Configuration UtilityHP Array Configuration Utility
HP Array Configuration Utility (ACU)
Powerful Web based configuration utility for all Smart Array controllers
Provides a graphical view of HP drive array configurations
Allows for management of multiple arrays over a secure internet connection from anywhere in the
world
Easy to use Wizards for configuration
Runs offline for all supported Operating Systems and runs online for Windows and Linux. For
online configuration of NetWare, use CPQONLIN
HP Option ROM Configuration for Arrays
HP Option ROM Configuration for ArraysHP Option ROM Configuration for Arrays
HP Option ROM Configuration for Arrays (ORCA)
A simple method for managing logical drives during system power up by pressing F8 during POST
Allows the ability to create arrays, logical drives, and assign an online spare drive
Allows the ability to view and delete logical drives
Allows the ability to select the boot controller or advanced array configurations use ACU
HP Array Diagnostic Utility
HP Array Diagnostic UtilityHP Array Diagnostic Utility
HP Array Diagnostic Utility (ADU)
In depth diagnostic and reporting utility for all Smart Array controllers
Runs offline for all supported Operating Systems, and runs online for Windows and Linux
HP Smart Array Advanced Pack
HP Smart Array Advanced PackHP Smart Array Advanced Pack
HP Smart Array Advanced Pack (SAAP)
Group of firmware that provides additional and advanced feature functionality within the Smart
Array Controllers that requires a license key for activation. These licensed features provides an
easy key activation to enable features such as added RAID protection, drive erase and
performance optimization and more. For more information visit the following URL:
http://h18000.www1.hp.com/products/servers/proliantstorage/arraycontrollers/smartarray-
advanced/index.html
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Product Highlights
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 4

Warranty
WarrantyWarranty
Warranty Protected by HP Services and a worldwide network of HP Authorized Channel Partners. Three-year parts
limited global warranty. Certain restrictions and exclusions apply.
Hard drive Pre-Failure Warranty: When used with any one of the Smart Array Family controllers and
monitored under HP Systems Insight Manager (v4.20 or later), HP hard drives are supported by a Pre-
Failure (replacement) Warranty. Hard drives have a one year warranty.
HP Care Pack Services: Packaged server and storage services for increased uptime, productivity and ROI
HP Care Pack Services: Packaged server and storage services for increased uptime, productivity and ROIHP Care Pack Services: Packaged server and storage services for increased uptime, productivity and ROI
HP Care Pack Services: Packaged server and storage services for increased uptime, productivity and ROI
When you buy HP server and storage products and solutions, it's also a good time to think about what levels of support you may
need. Our portfolio of service options reduce deployment and management worries while helping you get the most out of your
server and storage investments. We take a holistic approach to your environment, bridging servers, blades, storage, software and
network infrastructures with our packaged HP Care Pack Services for servers and storage.
Protect your business beyond warranty
Protect your business beyond warrantyProtect your business beyond warranty
Protect your business beyond warranty
When it comes to robustness and reliability, standard computing equipment warranties have matured along with technology. Good
news that can also create problems stemming from depending on standard warranties designed to only protect against product
defects and some downtime causes. Using a standard approach to warranty uplifts, such as HP Care Pack Services, helps reduce
downtime risks and provides operational consistency for mission-critical and standard business computing.
HP Care Pack Services: Upgrading or extending standard server and storage warranties cost effectively
HP Care Pack Services: Upgrading or extending standard server and storage warranties cost effectivelyHP Care Pack Services: Upgrading or extending standard server and storage warranties cost effectively
HP Care Pack Services: Upgrading or extending standard server and storage warranties cost effectively
HP Care Pack Services offer a standard reactive hardware and software support services suite sold separately, or combined with our
Support Plus and Support Plus 24 services. The portfolio also provides a combination of integrated proactive and reactive services,
such as Proactive 24 Service and Critical Service. In addition with HP Proactive Select, you can acquire the specific proactive
constancy and technical services. HP Proactive Select menu offers a broad set of service options that you can mix and match
depending on your specific requirements. Proactive service options include offers for server, storage, network, SAN device, software,
environment and education services.
HP server and storage lifecycle support services offers a full spectrum of customer care-from technology support to complex
migrations to complete managed services. HP Factory Express provides customization, integration and deployment services for
turnkey solutions. HP Education Services offer flexible, comprehensive training on to help your IT staff get the most out of your server
and storage investments. HP Financial solutions extend innovative financing and cost-effective asset management programs-from
purchase to equipment retirement.
Learn more: www.hp.com/services/servers and www.hp.com/services/storage
NOTE:
NOTE:NOTE:
NOTE: Care Pack Services availability may vary by product and country.
HP Care Pack Services are sold by HP and HP Authorized Service Partners:
Services for customers purchasing from HP or an enterprise reseller are quoted using HP order configuration tools.
Customers purchasing from a commercial reseller can find HP Care Pack Services at
http://www.hp.com/go/lookuptool
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Service and Support, HP Care Pack, and Warranty Information
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 5

Recommended HP Care Pack Services for optimal satisfaction with your HP product.
Recommended HP Care Pack Services for optimal satisfaction with your HP product.Recommended HP Care Pack Services for optimal satisfaction with your HP product.
Recommended HP Care Pack Services for optimal satisfaction with your HP product.
3-Year HP Support Plus
3-Year HP Support Plus3-Year HP Support Plus
3-Year HP Support Plus
24
2424
24
For a higher return on your server and storage investment, HP Support Plus 24 provides integrated
hardware and software support services designed specifically for your technology. Available 24x7, this 3-
year combined reactive support option delivers onsite hardware support and over-the-phone software
support around-the-clock. Leverage the full strength of HP Technology Services - customers can trust the
services professionals at HP to work collaboratively with them, putting our strategic and technical know-
how to work across their entire infrastructure.
Improve uptime with responsive hardware and software services
Enjoy consistent service coverage across geographically dispersed sites
Update HP software at a predictable cost
Increase customer satisfaction-with no interoperability gaps
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6638EEE
HP Install Storage Blade
HP Install Storage BladeHP Install Storage Blade
HP Install Storage Blade
Service
ServiceService
Service
For smooth startup and better business outcomes, HP Install Storage Blade Service- this service provides
initial hardware installation of your HP Storage Blade (system configuration is not included). In today's
new era of business technology- customers can trust the services professionals at HP to work
collaboratively with them, putting our strategic and technical know-how to work across their entire
infrastructure.
Allows your IT resources to stay focused on their core tasks and priorities
Reduces implementation time, impact and risk to your storage environment
http://h71028.www7.hp.com/ERC/downloads/5981-9356EN.pdf
HP Proactive Select
HP Proactive SelectHP Proactive Select
HP Proactive Select
Service
ServiceService
Service
HP Proactive Select Service improves your IT performance and manageability through the use of cost
effective flexible services. HP provides technical expertise and best practices to accelerate ROI of your
technology investment. Selectable proactive services span a wide range of technology and process
services - a flexible way to purchase proactive services that fit your particular environment and situation.
HP Proactive Select Service is technology agnostic and purchased in addition to your choice of
underlying reactive support.
Access to a list of flexible and customizable proactive service activities
Enhance customers' in-house IT team with complementary assistance from HP
Improved time to solution
Reduce business risk and project costs by accessing HP specialists
Simplify IT operational procedures by leveraging HP best practices
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA2-3842ENN.pdf
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Service and Support, HP Care Pack, and Warranty Information
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 6

Optional HP Care Pack Services that will enhance your HP product experience.
Optional HP Care Pack Services that will enhance your HP product experience.Optional HP Care Pack Services that will enhance your HP product experience.
Optional HP Care Pack Services that will enhance your HP product experience.
HP BladeSystem c3000
HP BladeSystem c3000HP BladeSystem c3000
HP BladeSystem c3000
Infrastructure (ICE + OS)
Infrastructure (ICE + OS)Infrastructure (ICE + OS)
Infrastructure (ICE + OS)
Installation & Startup
Installation & StartupInstallation & Startup
Installation & Startup
For customers who need professionally integrated hardware and software BladeSystem implementation:
The HP Installation and Startup Service for HP BladeSystem c-Class Infrastructure provides for the
installation of an HP BladeSystem c-Class enclosure, c-Class ProLiant and Integrity server blades, storage
blades, SAN switch blades, Virtual Connect modules (Ethernet and Fibre Channel), Ethernet network
interconnects, and Infiniband, as well as deployment and basic configuration of HP Insight Control
Environment for HP BladeSystem software.
Service benefits
Efficient and effective HP BladeSystem c-Class infrastructure setup, server deployment, and
management
Delivery of the service at a mutually scheduled time convenient to your organization
Expedited installation, provided all service prerequisites are met prior to commencement of
service
Verification prior to installation that all service prerequisites are met
Reduced implementation time and cost
More effective IT resource planning
Increased data-center efficiency through reduction of manually intensive tasks
Allows IT resources to stay focused on their core tasks and priorities
Helps improve IT infrastructure uptime
Automated diagnosis and remote support for hardware problems (via HP Service Essentials
Remote Support Pack)
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA0-5964ENW
HP Entry Storage Data
HP Entry Storage DataHP Entry Storage Data
HP Entry Storage Data
Migration Service for
Migration Service forMigration Service for
Migration Service for
Windows
WindowsWindows
Windows
For customers who need to safely migrate Windows data within their TCP/IP networks with minimal
impact to their operations:
You have a need to migrate data between Windows servers within your TCP/IP network. Or you have a
need to migrate storage for your Windows servers. Or both. And you need to accomplish these
migrations efficiently while minimizing risk at the same time.
HP Entry Storage Data Migration Service for Windows offers you a cost competitive and convenient way
to accommodate data migration triggered by a need to refresh or consolidate storage, or to create
different storage tiers. This service offers a migration cost in line with the costs of storage products in
small and medium-sized storage environments. The service is delivered via a skilled HP service specialist
with special consideration for data availability, integrity, and ongoing operational performance during
the transfer process.
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA2-4734ENW.pdf
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Service and Support, HP Care Pack, and Warranty Information
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 7

eSupport
eSupporteSupport
eSupport HP eSupport is a portfolio of technology-based services that assist you with managing your business
environment - from the desktop to the data center.
Support Portal
The HP support portal provides one-stop access to the information, tools and services you need to
manage the daily operations of your IT environment.
Features include:
Access to self-solve tools (including search technical knowledge base)
Efficient logging and tracking of support cases
Collaboration with other business and IT professionals
Download of patches and drivers
Access to diagnostic tools
Proactive notification of relevant information
Access to certain features of the support portal requires an HP service agreement. To access the support
portal, visit: http://www.hp.com/support
HP Insight Remote Support software delivers secure remote monitoring and support for your HP Servers
and Storage, 24 X 7, so you can spend less time solving problems and more time focused on your
business. You can have your systems remotely monitored for hardware failure using secure technology
that's been proven at thousands of companies around the world. In many cases, you can avoid problems
before they occur.
Customer Technical
Customer TechnicalCustomer Technical
Customer Technical
Training
TrainingTraining
Training
HP Education Services
HP Education ServicesHP Education Services
HP Education Services
In today's cost-conscious business environment, IT professionals, developers, consultants and users face
an interesting challenge: how to keep up with the latest technologies and expand important skills while
delivering profitable results on current projects. To help address this challenge, HP offers innovative
training solutions that help keep you up-to-date on virtualization, server, storage, Insight Control, Citrix,
Microsoft® and open source/Linux-related topics-while spending less time away from business-critical
activities.
HP Services Awards
HP Services AwardsHP Services Awards
HP Services Awards HP Technology Services continues to be recognized for service and support excellence by customers,
partners, industry organizations and publications around the world. Recent honors and award reflect our
services team's dedications, technical expertise, professionalism and uncompromising commitment to
customer satisfaction.
Additional Services
Additional ServicesAdditional Services
Additional Services
Information
InformationInformation
Information
To learn more on HP ProLiant servers, HP BladeSystem servers and HP storage products, please contact
your HP sales representative or HP Authorized Channel Partner. Or visit www.hp.com/services/proliant
or www.hp.com/services/bladesystem or http://www.hp.com/hps/storage
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Service and Support, HP Care Pack, and Warranty Information
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 8

Step 1: D2200sb Storage Blade Configuration
Step 1: D2200sb Storage Blade ConfigurationStep 1: D2200sb Storage Blade Configuration
Step 1: D2200sb Storage Blade Configuration
Models
ModelsModels
Models HP D2200sb Storage Blade AP880A
HP D2200sb Storage Blade Bundle with SAAP License
NOTE:
NOTE:NOTE:
NOTE: Includes the D2200sb Storage Blade, A Smart Array Advanced Pack (SAAP)
single server License (Part number 516471-B21)
BK781A
HP D2200sb PCIe Storage Blade with (12) 600GB 6G SAS HDD bundle AP882A
HP D2200sb PCIe and P4000 VSA Bundle with SAAP License
NOTE:
NOTE:NOTE:
NOTE: Includes the D2200sb Storage Blade, A Smart Array Advanced Pack (SAAP)
single server License (Part number 516471-B21) and a single P4000 VSA license.
VSA software is installed in a virtual machine on a VMware ESX/ESXi & Microsoft
Hyper-V host server adjacent to the D2200sb.
NOTE:
NOTE:NOTE:
NOTE: Includes 1 yr 9x5 software support for P4000 VSA software.
For detailed deployment information, see the HP P4000 VSA in an HP BladeSystem
environment solution guide:
NOTE:
NOTE:NOTE:
NOTE: P4000 VSA is supported on VMware ESX/ESXi & Microsoft Hyper-V
http://bizsupport1.austin.hp.com/bc/docs/support/SupportManual/c01729139/
c01729139.pdf
AP881A
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Configuration Information - Factory Integrated Models (North America Only)
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 9

c-Class Mezzanines
c-Class Mezzaninesc-Class Mezzanines
c-Class Mezzanines HP PCI Express Mezzanine pass-thru card for HP BladeSystem 431643-B21
NOTE:
NOTE:NOTE:
NOTE: Required to support the HP D2200sb Storage Blade with HP c-Class
BladeSystem full-height server blades
HP Hard Drives
HP Hard DrivesHP Hard Drives
HP Hard Drives SAS Hot Plug SFF Enterprise (ENT) Drives
SAS Hot Plug SFF Enterprise (ENT) DrivesSAS Hot Plug SFF Enterprise (ENT) Drives
SAS Hot Plug SFF Enterprise (ENT) Drives
HP 72GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
512545-B21
HP 146GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
512547-B21
HP 146GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
507125-B21
HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
507127-B21
HP 300GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
627117-B21
HP 450GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
581284-B21
HP 600GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
581286-B21
HP 900GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
619291-B21
NOTE:
NOTE:NOTE:
NOTE: SAS drives have a 3 year warranty.
NOTE:
NOTE:NOTE:
NOTE: Please see the for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html
(Worldwide)
NOTE:
NOTE:NOTE:
NOTE: Go to the HP Hard Drive Compatibility table for complete drive compatibility
information ( http://www.hp.com/products/harddiskdrives ). Using hard drives in
unsupported configurations will result in voiding the warranty and could result in
damage to the drive and/or loss of data.
SATA Hot Plug Enterprise Mainstream Solid State Drives
SATA Hot Plug Enterprise Mainstream Solid State DrivesSATA Hot Plug Enterprise Mainstream Solid State Drives
SATA Hot Plug Enterprise Mainstream Solid State Drives
HP 400GB 3G SATA MLC SFF SSD 636597-B21
HP 200GB 3G SATA MLC SFF SSD 636595-B21
HP 100GB 3G SATA MLC SFF SSD 636593-B21
NOTE:
NOTE:NOTE:
NOTE: SATA MLC SSD drives have 3 year warranty
SATA Hot Plug Midline (MDL) Solid State Drives
SATA Hot Plug Midline (MDL) Solid State DrivesSATA Hot Plug Midline (MDL) Solid State Drives
SATA Hot Plug Midline (MDL) Solid State Drives
HP 60GB 3G SATA SFF MDL SSD 572071-B21
HP 120GB 3G SATA SFF MDL SSD
NOTE:
NOTE:NOTE:
NOTE: SATA MDL SSD drives have a 1 year warranty .
..
.
572073-B21
NOTE:
NOTE:NOTE:
NOTE: Customers can use SATA MDL SSD if they update D2200sb to Smart Array
FW 5.06 available through notices on HP.com
6G SAS Hot Plug Enterprise Performance Solid State Drives
6G SAS Hot Plug Enterprise Performance Solid State Drives6G SAS Hot Plug Enterprise Performance Solid State Drives
6G SAS Hot Plug Enterprise Performance Solid State Drives
HP 400GB 6G SAS SLC SFF SSD 632494-B21
HP 200GB 6G SAS SLC SFF SSD
NOTE:
NOTE:NOTE:
NOTE: SAS SSD drives have a 3 year warranty.
632492-B21
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Options
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 10

6G SAS Hot Plug Enterprise Mainstream Solid State Drives
6G SAS Hot Plug Enterprise Mainstream Solid State Drives6G SAS Hot Plug Enterprise Mainstream Solid State Drives
6G SAS Hot Plug Enterprise Mainstream Solid State Drives
HP 800GB 6G SAS MLC SFF SSD 632506-B21
HP 400GB 6G SAS MLC SFF SSD 632504-B21
HP 200GB 6G SAS MLC SFF SSD
NOTE:
NOTE:NOTE:
NOTE: SAS SSD drives have a 3 year warranty.
632502-B21
SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SATA Hot Plug SFF (2.5-inch) Midline (MDL) DrivesSATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
HP 1TB 3G SATA 7.2K SFF 625609-B21
HP 500GB 3G SATA 7.2K SFF 507750-B21
NOTE:
NOTE:NOTE:
NOTE: SATA MDL HDD drives have a 1 year warranty.
NOTE:
NOTE:NOTE:
NOTE: In order to support SATA MDL HDD/ SATA SSDs in a D2200sb, the Smart
Array Firmware has to be upgraded to version 5.06.
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Options
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 11

Top view of the D2200sb, with the drive drawer opened
Top view of the D2200sb, with the drive drawer openedTop view of the D2200sb, with the drive drawer opened
Top view of the D2200sb, with the drive drawer opened
Hard Drives
Hard DrivesHard Drives
Hard Drives
SAS Hot Plug SFF Enterprise (ENT) Drives
SAS Hot Plug SFF Enterprise (ENT) DrivesSAS Hot Plug SFF Enterprise (ENT) Drives
SAS Hot Plug SFF Enterprise (ENT) Drives
Quantity
QuantityQuantity
Quantity
Supported
SupportedSupported
Supported
Position
PositionPosition
Position
Supported
SupportedSupported
Supported Controller
ControllerController
Controller
12 1-12 Smart Array P410i Controller
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Storage
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 12

HP D2200sb Storage
HP D2200sb StorageHP D2200sb Storage
HP D2200sb Storage
Blade
BladeBlade
Blade
Dimensions
DimensionsDimensions
Dimensions (HxWxD) 5.316cm x 18.070cm x 51.565cm (2.093" x7.114" x 20.301")
Weight
WeightWeight
Weight (unloaded) 3.9KG (8.58 lbs)
Weight
WeightWeight
Weight (loaded) 7.19KG (15.8 lbs)
Protocol Support
Protocol SupportProtocol Support
Protocol Support 6Gb/s SAS
O/S Support
O/S SupportO/S Support
O/S Support Defined by specific HP array controller or SAS/ adapter used; please refer to
the QuickSpecs and/or User Guide of the specific array controller or adapter
LED Indicators
LED IndicatorsLED Indicators
LED Indicators UID
System Health LED
Drive LED Indicators
Drive LED IndicatorsDrive LED Indicators
Drive LED Indicators (on
drive trays)
Drive LED (top) - On-line/Activity
Drive Failure LED (bottom) - Drive Fault/Locate
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity (non-
condensing)
Operating 20% to 80%
Shipping 5% to 95%
Temperature Range
Temperature RangeTemperature Range
Temperature Range Operating 50° to 95° F (10° to 35° C°)
Shipping -22° to 140° F (-30° to 60° C)
NOTE:
NOTE:NOTE:
NOTE: To maintain proper cooling and airflow, a drive blank or drive must occupy all bays during
operation.
Power Consumption
Power ConsumptionPower Consumption
Power Consumption 12V/11A
Smart Array P410i
Smart Array P410iSmart Array P410i
Smart Array P410i
Controller
ControllerController
Controller
Disk Drive and Enclosure
Disk Drive and EnclosureDisk Drive and Enclosure
Disk Drive and Enclosure
Interface
InterfaceInterface
Interface
6G SAS (Serial Attached SCSI)
SAS Connectors
SAS ConnectorsSAS Connectors
SAS Connectors 2 internal (SFF8484) x4 wide port connectors
Cache Memory Speed
Cache Memory SpeedCache Memory Speed
Cache Memory Speed DDR2-533MHz with provides up to 4.2 GB/s maximum bandwidth.
SAS Speed
SAS SpeedSAS Speed
SAS Speed x8 6G SAS
Cache Memory
Cache MemoryCache Memory
Cache Memory 40-bit 256 MB cache; ECC protection, battery-backed, and transportable
Logical Drives Supported
Logical Drives SupportedLogical Drives Supported
Logical Drives Supported Up to 32 logical drives
Maximum Logical Drive
Maximum Logical DriveMaximum Logical Drive
Maximum Logical Drive
Capacity
CapacityCapacity
Capacity
10.8TB SAS or 12TB SATA
Host Memory Addressing
Host Memory AddressingHost Memory Addressing
Host Memory Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support
RAID SupportRAID Support
RAID Support RAID 6 with ADG (Advanced Data Guarding)
RAID 5 (Distributed Data Guarding)
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
Upgradeable Firmware
Upgradeable FirmwareUpgradeable Firmware
Upgradeable Firmware Upgradeable Firmware with recovery ROM feature
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Technical Specifications
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 13

Environment-friendly
Environment-friendlyEnvironment-friendly
Environment-friendly
Products and Approach
Products and ApproachProducts and Approach
Products and Approach
End-of-life Management
End-of-life ManagementEnd-of-life Management
End-of-life Management
and Recycling
and Recyclingand Recycling
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to
http://www.hp.com/go/green . To recycle your product, please go to:
http://www.hp.com/go/green or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/green . These instructions may
be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
© Copyright 2012 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.
QuickSpecs
HP D2200sb Storage Blade
HP D2200sb Storage BladeHP D2200sb Storage Blade
HP D2200sb Storage Blade
Technical Specifications
DA - 13714 Worldwide — Version 11 — March 2, 2012 Page 14
