HP D2D User manual

HP D2D NAS
Integration with Symantec™ Backup Exec™
2010
Abstract
This guide provides step by step instructions on how to configure and optimize Symantec Backup Exec 2010 in order to back
up to HP D2D Backup Systems using a CIFS backup target.
HP Part Number: EH985-90932
Published: February 2011
Edition: 1

© Copyright 2011 Hewlett-Packard Development Company, L.P.
Confidential computer software. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211 and 12.212, Commercial
Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under
vendor's standard commercial license.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
WARRANTY STATEMENT: To obtain a copy of the warranty for this product, see the warranty information website:
http://www.hp.com/go/storagewarranty
Linear Tape-Open, LTO, LTO Logo, Ultrium and Ultrium Logo are trademarks of Quantum Corp, HP and IBM in the US, other countries or both.
Microsoft, Windows, Windows NT, and Windows XP are U.S. registered trademarks of Microsoft Corporation.
Symantec and Backup Exec™ are trademarks or registered trademarks of Symantec Corporation or its affiliates in the U.S. and other countries.

Contents
1 Configure the D2D CIFS server.....................................................................4
More about authentication modes...............................................................................................4
Configuring User Authentication mode........................................................................................5
Configuring AD Authentication Mode..........................................................................................6
To join a domain.................................................................................................................6
To create shares and grant access permission..........................................................................8
2 Configure Backup Exec to use D2D CIFS Share............................................12
Create a D2D CIFS target for backup........................................................................................12
Create a Backup Exec Backup-to-disk folder...............................................................................13
3 Configure a backup rotation scheme...........................................................18
To create a media set..............................................................................................................18
To create backup policy...........................................................................................................20
Housekeeping considerations..............................................................................................24
About this guide..........................................................................................25
Intended audience..................................................................................................................25
Related documentation............................................................................................................25
Document conventions and symbols..........................................................................................25
HP technical support...............................................................................................................26
HP websites...........................................................................................................................26
Documentation feedback.........................................................................................................26
Index.........................................................................................................28
Contents 3

1 Configure the D2D CIFS server
The first step in configuring the D2D device as a target for backups from Symantec Backup Exec
is to configure the CIFS server on the D2D Backup System
On the D2D Web Management Interface navigate to the NAS — CIFS Server page and select Edit.
The available Authentication options for the CIFS server are:
•None – All shares created are accessible to any user from any client (this is the least secure
option)
•User – Local (D2D) User account authentication
•AD – Active Directory User account authentication
More about authentication modes
None: This authentication mode requires no username or password authentication and is the
simplest configuration. Backup Exec will always be able to use shares configured in this mode with
no changes to either server or Backup Exec configuration. However, this mode provides no data
security because anyone can access the shares and add or delete data.
User: In this mode it is possible to create “local D2D users” from the D2D Web Management
Interface. This mode requires the configuration of a respective local user on the Backup Exec media
server and configuration changes to the Backup Exec services. Individual users can then be assigned
access to individual shares on the D2D Backup System. This authentication mode is ONLY
recommended when the Backup Exec media server is not a member of an AD Domain.
AD: In this mode the D2D CIFS server becomes a member of an Active Directory Domain. In order
to join an AD domain the user needs to provide credentials of a user who has permission to add
computers and users to the AD domain. After joining an AD Domain access to each share is
controlled by Domain Management tools and domain users or groups can be given access to
individual shares on the D2D Backup System. This is the recommended authentication mode, if the
Backup Exec Media server is a member of an AD domain.
4 Configure the D2D CIFS server

Configuring User Authentication mode
1. Select the User authentication mode on the D2D Web Management Interface and click Update
to create a local user account on the D2D Backup System. Provide a User Name and Password
for the new user.
2. Use Server Manager to create a correspondingly named user on the Windows server that
hosts the Backup Exec Media server.
3. It is then necessary to configure Backup Exec to use this Local user account as the credentials
used to run its services. Do this from the Backup Exec interface by selecting Tools — Backup
Exec Services ….
Then click the Services Credentials button and provide the new User Name, Domain name
(local server name) and password.
Configuring User Authentication mode 5

4. Restart the Backup Exec services before continuing with configuration. Note, however, that
this is the ONLY user account that the Backup Exec Media server will be able to use to connect
to remote storage that requires authentication, so this account must be the same for any other
disk storage devices.
Configuring AD Authentication Mode
These are the steps required in order to configure backups in AD authentication mode:
•Join the D2D CIFS server to the AD Domain and configure DNS.
•Create or specify a user to be used for backups.
•Apply user permissions to D2D shares.
•Configure Backup Exec services to use the correct Domain account.
To join a domain
1. Connect to the D2D Web Management Interface, navigate to the NAS — CIFS Server page,
click Edit and choose AD from the drop-down menu. Provide the name of the domain that you
wish to join, e.g “mydomain.local”
2. Click Update. If the domain controller is found, a pop-up box will request credentials of a user
with permission to join the domain. (Note that joining or leaving the domain will result in
failure of any backup or restore operations that are currently running.) Provide credentials
(username and password) of a domain user that has permission to add computers to the
domain and click Register.
6 Configure the D2D CIFS server

3. After joining the domain, the DNS server should be automatically updated (if a DHCP server
is used) with Forward and Reverse Lookup zone entries, however, some DNS configurations
do not allow this. In this case, or if a DHCP is not used on the network, the user must also
configure the domain’s DNS server to be able to correctly manage the D2D shares, as
described in the next section.
To configure entries manually if the DNS server does not update automatically
From a Windows client server that has domain and DNS management tools installed launch
the DNS Management Tool. (From the command line type dnsmgmt.msc or launch DNS
from the Administrative Tools menu).
Create a new Host(A) record in the forward lookup zone for the domain to which the D2D
Backup System belongs with the hostname and IP address of the D2D Backup System.
Also create a Pointer(PTR) in the reverse lookup zone for the domain for the D2D Backup
System by providing the hostname and IP address.
Configuring AD Authentication Mode 7

To create shares and grant access permission
Now that the D2D Backup System is part of a domain and can be managed, it is possible to create
shares and grant access permission to them for domain account users or groups.
1. Create a share on the D2D Backup System that is going to be used as a backup target, by
selecting NAS — Shares from the D2D Web Management Interface and clicking Create.
Provide a share Name and Description, select the CIFS protocol and click Create.
2. Now that the D2D Backup System is a member of the domain its shares can be managed
from any computer on the domain by configuring a customized Microsoft Management Console
(MMC) with the Shared Folders snap-in. To do this first open a new MMC window by typing
mmc at the command prompt or from the Start Search box. This will launch a new empty MMC
window.
8 Configure the D2D CIFS server

3. To this empty MMC window add the Shared Folders snap-in. Select File — Add/Remove
Snap-in ..., then select Shared Folders from the left-hand pane.
4. Click Add > and in the dialog box choose the computer to be managed and select Shares
from the View options.
5. Click Finish and OK to complete the snap-in set up.
Configuring AD Authentication Mode 9

Note that the Folder Path field contains an internal path on the D2D Backup System.
6. Save this customized snap-in for future use.
7. Select the Share Permissions tab and Add a user or group of users from the domain.
Specify the level of permission that the users will receive and click Apply.
8. Now, from any Windows server on the domain, it is possible to access the newly created
share using the credentials of anyone who had been given permission to access the share. If
a permitted user is logged into Windows, access to the share will be granted automatically
with those permissions.
10 Configure the D2D CIFS server

NOTE: In some cases, when switching the D2D Backup System from No Authentication or
User Authentication mode to AD mode, it may be necessary to log out and back into a
Windows client before it is possible to access the D2D shares.
9. It may also be necessary to configure Backup Exec to use this AD Domain user account as the
credentials used to run its services. Do this from the Backup Exec interface by selecting Tools
— Backup Exec Services ….
Select the Services Credentials button and provide the new User Name, Domain name and
password.
10. Restart the Backup Exec services before continuing with configuration. Note, however, that
this is the ONLY user account that the Backup Exec Media server will be able to use to connect
to remote storage that requires authentication, so this account must be the same for any other
disk storage devices.
Configuring AD Authentication Mode 11

2 Configure Backup Exec to use D2D CIFS Share
Create a D2D CIFS target for backup
If a new D2D CIFS share has not already been created as part of the authentication configuration
process in the previous section, it is now necessary to create a new CIFS NAS share.
The available options for share creation are:
•Name – This is the name of the CIFS share to be created
•Description – A “friendly” description of the share and its use, this will be presented to the
Windows host for easy identification.
•Access Protocol – CIFS is the only option provided
•Network Path – This is a non-configurable field which shows the share name appended to the
IP address upon creation of the share
•Write Protection – Global write protect for the share, to be used if no further writing is to be
permitted to the share.
1. Click Create, the share is configured and starts after a few seconds.
2. After the share has started it will report as “Online”. If required, configure User or AD
authentication mode, as already described, so that the share is accessible to the appropriate
users. After that it is possible to access the share from the Windows server, for example by
clicking the Network Path link from the Shares page which will open a Windows Explorer
window.
12 Configure Backup Exec to use D2D CIFS Share

Create a Backup Exec Backup-to-disk folder
Backup Exec refers to NAS backup targets as “Backup-To-Disk” folders, which may be one of three
types of folder:
•Backup-To-Disk folder – This is used for CIFS shares or local disk devices
•Removable Backup-To-Disk folder – Used for removable media devices, such as HP RDX
•Shared Backup-To-Disk folder – Used with the CASO or SAN Shared Storage options to share
a NAS backup target across multiple Backup Exec Media servers.
When using an HP D2D CIFS share the “Backup-To-Disk” folder type should be used.
1. From the Backup Exec, Devices page select the Media server and right click, then select New
Backup-To-Disk Folder…
2. This will launch a Backup-To-Disk Wizard to step through the creation and configuration of a
Backup-To-Disk folder.
Enter a name for this folder that Backup Exec will use to identify it. A best practice is to use
the name of the D2D Backup System and share name in order to easily identify where this
backup-to-disk folder resides.
Create a Backup Exec Backup-to-disk folder 13

3. The next step is to provide the path to the backup-to-disk folder, this is the path to the CIFS
share on the D2D Backup System. There is no need to mount the D2D CIFS share as a Windows
drive letter because the full path including domain extension or IP address with share name
will allow direct access to the D2D share.
4. If more than one Backup-To-Disk folder is required per D2D CIFS share, it is necessary to
create multiple folders within the D2D NAS share because each Backup-to-disk folder must
be in a different folder on disk.
Use Windows Explorer to create a new folder on the D2D CIFS share.
5. The next step in the wizard provides the user with the option to pre-allocate the maximum size
of each Backup-To-Disk file as it is created, this option MUST be set to “No”.
Pre-allocating disk space for each backup to disk file will result in incorrectly reported
deduplication ratio, and also poor performance or failures because the D2D Backup System
will need to “pad” the data file when created.
6. Configure the maximum size that each Backup-To-Disk file may reach before spanning to a
new file.
The default size is 4GB; however this should be set to a larger size in order to improve
performance. It is suggested that this maximum file size is set to at least the size of the full
backup with enough headroom for future data growth. (If in doubt about the amount of growth
expected, setting this to the maximum value of 4TB (4096GB) will have no detrimental effect.)
This means a single file can hold the entire backup and prevents the houskeeping process,
which starts whenever a file is closed, from interfering with the remainder of the backup job.
14 Configure Backup Exec to use D2D CIFS Share

An exception to this rule is when D2D replication is being used when it may be beneficial to
use a smaller file size in order to start replicating backup files before the whole backup
completes. However this may reduce backup performance, if the D2D Backup System is heavily
loaded with other backups or housekeeping processes.
7. Configure the Maximum number of backup sets that can be held in each backup to disk file.
This setting should be set to 1; this prevents backups from appending to backup-to-disk files.
No space is lost in this configuration because no space is allocated per file. Appending of
backups to Backup-to-disk files is undesirable because it prevents that file being overwritten
until all sets have expired. It also causes additional D2D replication overhead because
replicating an appended file requires the replication target file to be “cloned” before new
data can be added to it, which reduces performance.
An exception is if a large Backup-to-disk file size is configured but backups are quite small.
These backups could be appended to the Backup-to-disk file (if appending is enabled in the
backup job) and, in this case, the maximum number of backups per file can be configured
8. Configure the Maximum Number of Concurrent jobs.
This is an important selection for D2D due to the limitation on the number of concurrently open
files that are permitted. The default setting for this variable is 1, which means that only one
backup job is permitted to that Backup-To-Disk file at any one time.
Create a Backup Exec Backup-to-disk folder 15

When Backup Exec is backing up flat file data (rather than database or any other media
agent) it will have four files open concurrently during the backup. One is the backup data file
(B2DXXXXXX.bkf) which is deduplicated; the other three files are smaller than the 24KB
pre-deduplication limit and consist of a file lock (B2DXXXXXX.lck), a changer configuration
file (Changer.cfg) and a Backup-To-Disk folder configuration file (Folder.cfg).
However, it is possible that a second backup file may be temporarily open on the D2D Backup
System during transitional periods when the backup spans to a new *.bkf file. This is because
the Windows operating system will report that the previous file is closed before the D2D
Backup System actually closes the file.
It is recommended that no more than four backup jobs run concurrently to a D2D share - the
maximum number of concurrent jobs setting is used to prevent more than four concurrently
open files. Depending on the number of Backup-To-Disk folders configured within a single
NAS share this value should be set in the range between 1 and 4.
When Backup Exec is using media agents to back up other types of data, e.g. Exchange or
Oracle Database, it is possible that a much larger number of small (pre-deduplication) files
are held open concurrently. Thus it is recommended that only a single job runs to a D2D NAS
share when backing up these data types.
See the D2D Best Practices for VTL, NAS and Replication implementations for more information
on the maximum number of concurrently open deduplicated and pre-deduplicated files per
D2D Share and per D2D Backup System appliance for different D2D Backup System models.
9. Configure the Low Disk Space Threshold setting.
This is a number of GB of remaining disk space at which point backups to the Backup-To-Disk
folder are suspended. The default for this setting is 0GB, i.e. there is no low space threshold
set, and it is the recommended setting.
With deduplication a physical disk space remaining figure is meaningless, because a backup
may use a fraction of the physical disk space compared to the amount of data backed up.
16 Configure Backup Exec to use D2D CIFS Share

10. Finally Backup Exec will present a summary of the Backup-To-Disk folder configuration before
creating the folder.
Once complete the Backup-To-Disk device will be created and presented on the Devices page
in Backup Exec. At creation time two small configuration files will be created on the D2D CIFS
share (Changer.cfg and Folder.cfg).
Create a Backup Exec Backup-to-disk folder 17

3 Configure a backup rotation scheme
When backing up to CIFS shares on the D2D Backup System it is recommended that a similar
retention and rotation scheme to that of virtual tape is used. There is some simplification over virtual
tape in that no account needs to be taken of the number of cartridges within the virtual library,
only the total number of files that can be supported on a D2D CIFS share (25000), which should
be more than adequate.
It is, however, important to ensure that the amount of data in the share does not grow in an
uncontrolled fashion due to keeping all backups forever. The default media set in Backup Exec is
the Keep Data Indefinitely set, this should not be used for CIFS backups.
The following is an example of a “Best Practice” backup rotation and retention scheme configuration
with Backup Exec. This scheme observes the following best practices:
•Backup-To-Disk files are never appended to; appended backups reduce replication performance,
prevent files from being overwritten until all sessions have expired and have no disk space
benefit for NAS targets.
•Different media pools are used to set retention periods for different types of backup (Daily,
Weekly, Monthly).
•Only one type of data is backed up in this Backup-To-Disk folder, in this case it is flat file data,
other types would be Exchange, SQL, Oracle etc.
•This backup will create only one concurrent backup stream; up to three other flat file backups
(of other client servers perhaps) could use the same Backup-To-Disk folder concurrently.
•Most backups will not include a Verify pass because this impacts overall performance.
•Software compression is disabled because this will slow the backup job and result in a worse
deduplication ratio.
The rotation and retention scheme for this backup rotation scheme employs GFS as follows:
1. Daily (Monday – Friday) Incremental backups, overwritten every week.
2. Weekly (Saturday) Full backups, overwritten every 4 weeks.
3. Monthly (1st Day Month) Full backups, overwritten every 12 months.
4. Yearly (Jan 1st) Full backups, never overwritten.
Monthly full backups will replace the last weekly full backup.
To create a media set
The first step in creating this scheme is to create new Backup Exec Media sets that employ the
correct protection. Once this protection period expires media (in this case Backup-To-Disk Files)
will be overwritten by the next backup job that uses the media set.
In this example we need four new media sets as follows:
Append PeriodOverwrite Protection PeriodMedia Set Name
Infinite (though not used)5 DaysDaily Incremental Backup
Infinite (though not used)4 WeeksWeekly Full Backup
Infinite (though not used)1 YearMonthly Full Backup
Infinite (though not used)Infinite – Do not overwriteYearly Full Backup
18 Configure a backup rotation scheme

1. To create these media sets, go to the Media page of the Backup Exec interface and select
New Media Set from the Tasks panel. An example of a media set configuration for the Daily
Incremental Backup is shown.
2. It is also useful to change the Media overwrite options.
From the Tools — Options menu select Media Management and change the Media overwrite
option to Overwrite recyclable media contained in the targeted media set before overwriting
scratch media. This will ensure that the retention period of the media is not exceeded by
creating new Backup-To-Disk files rather than overwriting expired ones.
To create a media set 19

To create backup policy
1. Once media sets have been created, a new backup policy can be created from the Job Setup
page on the Backup Exec User interface. There is a default backup policy that is similar to the
required scheme in this example, so copying this provides a start point for modification.
2. Once copied the new template can be renamed and edited to match the rotation scheme in
the example, the policy already consists of three individual job templates for Daily, Weekly
and Monthly backups.
Note that the individual Job templates for Daily, Weekly and Monthly backups need to be
modified.
Device and Media
Firstly adjust the Device and Media options to:
•Select the new Backup-To-Disk folder
•Change the media set to the newly created sets
•Set the job to always overwrite
The daily incremental backup template changes are shown here
20 Configure a backup rotation scheme
