HP 1810 series User instructions

Models
HP 1810-8G v2 Switch J9802A
HP 1810-24G v2 Switch J9803A
HP 1810-48G Switch J9660A
HP 1810-8 v2 Switch J9800A
HP 1810-24 v2 Switch J9801A
Key features
Customized operation using intuitive Web interface
Flexible connection and deployment options
Layer 2 operation at wire speeds
Fanless design for quiet operation
Lifetime warranty
Product overview
HP 1810 Switch Series devices are smart-managed, fixed-configuration Gigabit Ethernet and Fast Ethernet Layer 2 switches designed
for small businesses looking for key features in an easy-to-administer solution.The series includes 8- and 24-port Gigabit Ethernet and
Fast Ethernet models and a 48-port Gigabit Ethernet switch. Some models include SFP ports for fiber connectivity and some are
fanless, making them ideal for office deployments. All 1810 Switches support flexible installation options, including mounting on
walls, under tables, or on desktops. The 8-port Gigabit Ethernet model can be powered by an upstream Power over Ethernet (PoE)
switch for environments where no line power is available.Customizable features include VLANs, Spanning Tree, and link aggregation
trunking; 8- and 24-port switches offer Rapid Spanning Tree Protocol (RSTP) and DSCP QoS policies. The 8- and 24-port models also
include the latest energy-saving capabilities—Energy Efficient Ethernet (EEE) and idle-port power down. The HP 1810 Switch Series
have a lifetime warranty.
Features and Benefits
Connectivity
Auto-MDI/MDIX
automatically adjusts for straight-through or crossover cables on all ports
Packet storm protection
protects against broadcast, multicast, or unicast storms with user-defined thresholds
IEEE 802.3af PoE-powered device option
obtains power provided by a standard PoE device connected to Port 1; deploy the switch wherever an Ethernet cable can reach
as a power outlet is not needed (8-port GbE model only)
SFP ports for fiber connectivity
provides fiber connections for uplinks and other connections across longer distances than what copper cabling can support;
"true" SFP ports operate in addition to available copper Ethernet ports, providing a higher total number of available ports vs.
"combo" ports which are either a copper or fiber connection
Performance
Half-/Full-duplex auto-negotiating capability on every port
doubles the throughput of every port
QuickSpecs
HP 1810 Switch Series
Overview
DA - 13447 North America — Version 18 — January 17, 2014 Page 1

Link aggregation (trunking)
brings together groups of ports automatically using Link Aggregation Control Protocol (LACP) or, manually, to form an ultra-
high-bandwidth connection to the network backbone; helps prevent traffic bottlenecks; the 8-port models have four trunks of
four links each, the 24-port models have eight trunks of four links each, and the 1810-48G switch has 16 trunks of eight links
each
Quality of Service (QoS)
Traffic prioritization (IEEE 802.1p)
allows real-time traffic classification with eight priority levels mapped to four queues
IEEE 802.1p prioritization with DSCP
delivers data from the switch to devices based on the priority and type of traffic using Differentiated Services Code Point (DSCP);
available only with v2 switch models
Broadcast control
allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic
Layer 2 switching
VLAN support and tagging
support up to 64 port-based VLANs and dynamic configuration of IEEE 802.1Q VLAN tagging, providing security between
workgroups
Jumbo packet support
improves the performance of large data transfers; supports frame size of up to 9220 bytes
Resiliency and high availability
IEEE 802.1D Spanning Tree Protocol (STP) and IEEE 802.1W Rapid Spanning Tree Protocol (RSTP )
provides redundant links while preventing network loops; available only with v2 switch models
Security
Secure Sockets Layer (SSL)
encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch
Automatic denial-of-service protection
monitors six types of malicious attacks and protects the network by blocking the attacks
Management password
provides security so that only authorized access to the Web browser interface is allowed
Ease of use
Locator LED (switch)
allows users to set the locator LED on a specific switch to either turn on, blink, or turn off; simplifies troubleshooting by making
it easy to locate a particular switch within a rack of similar switches
Comprehensive LED display with per-port indicators
provides an at-a-glance view of status, activity, speed, and full-duplex operation
Flexibility
Flexible installation
allows mounting on wall, desktop, or under-table
Rack mountable (24- and 48-port models)
QuickSpecs
HP 1810 Switch Series
Overview
DA - 13447 North America — Version 18 — January 17, 2014 Page 2

offers a rack-mounting option with included hardware
Kensington lock slot
allows switches to be physically secured in open-space deployments
Management
Simple Web management
allows easy management of devices by even nontechnical users with its intuitive Web GUI
Secure Web GUI
provides a secure, easy-to-use graphical interface for configuring the module via HTTPS
SNMPv1, v2c
enables devices to be discovered and monitored from an SNMP management station
Dual flash images
provide independent primary and secondary operating system files for backup while upgrading
Port mirroring
enables traffic on a port to be simultaneously sent to a network analyzer for monitoring
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
advertises and receives management information from adjacent
devices on a network, facilitating easy mapping by network
management applications
Additional information
Energy savings
utilizes Energy Efficient Ethernet (EEE) IEEE 802.3az standard for lower power consumption; available only with v2 switch
models
Green IT and power
places inactive ports automaticaly in low power mode and its LED in power-down mode to conserve energy
Green initiative support
provides support for RoHS and WEEE regulations
Warranty and support
Lifetime warranty
for as long as you own the product with advance replacement and
next-business-day delivery (available in most countries)†
Electronic and telephone support
limited electronic and telephone support is available from HP; to reach our support centers, refer to
www.hp.com/networking/contact-support ; for details on the duration of support provided with your product purchase, refer to
www.hp.com/networking/warrantysummary
†HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance
replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP
Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765zl Mobility Controller
and HP Survivable Branch Communication zl Module powered by Microsoft Lync has a five-year hardware warranty. For details, refer to
the Software license and hardware warranty statements at www.hp.com/networking/warranty .
QuickSpecs
HP 1810 Switch Series
Overview
DA - 13447 North America — Version 18 — January 17, 2014 Page 3

Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
HP 1810-8 Switch J9800A
7 RJ-45 autosensing 10/100 ports
1 RJ-45 autosensing 10/100/1000 port
1U - Height
See Configuration
Note:2
HP 1810-8G Switch J9802A
8 RJ-45 autosensing 10/100/1000 ports
1U - Height
See Configuration
Note:2
HP 1810-24 Switch J9801A
22 RJ-45 autosensing 10/100 ports
2 RJ-45 autosensing 10/100/1000 ports
2 SFP autosensing 100/1000 ports
1U - Height
See Configuration
Note:1, 3
PDU Cable NA/MX/TW/JP J9801A#B2B
C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW J9801A#B2C
C15 PDU Jumper Cord (ROW)
HP 1810-24G Switch J9803A
24 RJ-45 autosensing 10/100/1000 ports
2 SFP 100/1000 ports
1U - Height
See Configuration
Note:1, 3
PDU Cable NA/MX/TW/JP J9803A#B2B
C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW J9803A#B2C
C15 PDU Jumper Cord (ROW)
HP 1810-48G Switch J9660A
48 autosensing 10/100/1000 ports
4 SFP 100/1000 Mbps ports
1U - Height
See Configuration
Note:1, 3
PDU Cable NA/MX/TW/JP J9660A#B2B
C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW J9660A#B2C
C15 PDU Jumper Cord (ROW)
QuickSpecs
HP 1810 Switch Series
Configuration
DA - 13447 North America — Version 18 — January 17, 2014 Page 4

Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
HP X122 1G SFP LC BX-D Transceiver J8177C
Note 2 Localization required. (See Localization Menu for list.)
Note 3 Localization (Wall Power Cord) required on orders without #B2B or #B2C (PDU Power Cord). (See Localization Menu)
CTO Models
HP 1810-48G Switch J9660A
48 autosensing 10/100 ports
4 SFP 100/1000 Mbps ports
1U - Height
See Configuration
Note:1, 2, 3
PDU Cable NA/MX/TW/JP J9660A#B2B
C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW J9660A#B2C
C15 PDU Jumper Cord (ROW)
Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
HP X122 1G SFP LC BX-D Transceiver J8177C
Note 2 Localization (Wall Power Cord) required on orders without #B2B or #B2C (PDU Power Cord). (See
Localization Menu)
Note 3 If this switch is factory installed in HP Universal Racks, Then the J9583A#0D1 is required.
EMEA then J9583A#0D1 is required.
APD, Japan and China then J9583A#0D1 is required.
CLIC Only - Allow the J9583AZ in all regions.
Internal or External Power Supplies (Model Dependant)
QuickSpecs
HP 1810 Switch Series
Configuration
DA - 13447 North America — Version 18 — January 17, 2014 Page 5

Power supplies Included
Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.
Transceivers
SFP Transceivers
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
HP X121 1G SFP RJ45 T Transceiver J8177C
Cables
Multi-Mode Cables
HP .5m Multi-mode OM3 LC/LC FC Cable AJ833A
HP 1m Multi-mode OM3 LC/LC FC Cable AJ834A
HP 2 m Multimode OM3 LC/LC FC Cable AJ835A
HP 5 m Multimode OM3 LC/LC FC Cable AJ836A
HP 15 m Multimode OM3 LC/LC FC Cable AJ837A
HP 30 m Multimode OM3 LC/LC FC Cable AJ838A
HP 50 m Multimode OM3 LC/LC FC Cable AJ839A
OM4 Cables
HP Premier Flex LC/LC OM4 2f 1m Cbl QK732A
HP Premier Flex LC/LC OM4 2f 2m Cbl QK733A
HP Premier Flex LC/LC OM4 2f 5m Cbl QK734A
HP Premier Flex LC/LC OM4 2f 15m Cbl QK735A
QuickSpecs
HP 1810 Switch Series
Configuration
DA - 13447 North America — Version 18 — January 17, 2014 Page 6

HP Premier Flex LC/LC OM4 2f 30m Cbl QK736A
HP Premier Flex LC/LC OM4 2f 50m Cbl QK737A
HP Premier Flex LC/LC OM4 2f 1m Cbl QK732A
HP Premier Flex LC/LC OM4 2f 2m Cbl QK733A
HP Premier Flex LC/LC OM4 2f 5m Cbl QK734A
HP Premier Flex LC/LC OM4 2f 15m Cbl QK735A
HP Premier Flex LC/LC OM4 2f 30m Cbl QK736A
HP Premier Flex LC/LC OM4 2f 50m Cbl QK737A
Switch Enclosure Options
Rack Mount Kit
HP X410 1U Univ 4-post Rack Mnt Kit J9583A
See Configuration
Note:1
Configuration Rules:
Note 1 If this Mounting Kit is order with #0D1 then it integrates to the HP Universal Rack. (not the switch)
QuickSpecs
HP 1810 Switch Series
Configuration
DA - 13447 North America — Version 18 — January 17, 2014 Page 7

HP 1810-8G v2 Switch
(J9802A)
Ports 8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Supports a maximum of 8 autosensing 10/100/1000 ports
Physical characteristics Dimensions 7.93(w) x 4.65(d) x 1.73(h) in
(20.14 x 11.81 x 4.39 cm) (1U height)
Weight 0.84 lb (.38 kg)
Memory and processor 128 MB RAM, 8 MB flash; packet buffer size: 512 KB
Mounting wall, desktop and under table mounting
Performance 100 Mb Latency < 3.3 µs (64-byte packets)
1000 Mb Latency < 2.3 µs (64-byte packets)
Throughput up to 11.9 million pps
Switching capacity 16 Gbps
MAC address table size 8000 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C)
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 140°F (60°C)
Altitude up to 10,000 ft (3 km)
Acoustic Power: 0 dB no fan
Electrical characteristics Voltage 100-127/200-240 VAC
Current 0.5 A
Maximum power rating 7.2 W
Frequency 50/60 Hz
Notes Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
Safety UL 60950-1; IEC 60950; EN 60950
Emissions EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B
Class A; VCCI V-4
Immunity ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 8

Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management Web browser
Notes Use only supported genuine HP mini-GBICs with your switch.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UE256E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UE257E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UE258E)
3-year, 24x7 SW phone support, software updates (UE260E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR846E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR847E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR848E)
4-year, 24x7 SW phone support, software updates (UR849E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR850E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR851E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR852E)
5-year, 24x7 SW phone support, software updates (UR853E)
3 Yr 6 hr Call-to-Repair Onsite (UW383E)
4 Yr 6 hr Call-to-Repair Onsite (UW384E)
5 Yr 6 hr Call-to-Repair Onsite (UW385E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR899E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR900E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR903E)
1-year, 24x7 software phone support, software updates (HR902E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR901E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HU347E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HU348E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HU349E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HU350E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS810E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS811E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS812E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 9

Exchange (HS813E)
Refer to the HP website at: www.hp.com/networking/services for details on
the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 1810-24G v2 Switch
(J9803A)
Ports 24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-
T/100BASE-TX: half or full; 1000BASE-T: full only
2 SFP 100/1000 Mbps ports
Supports a maximum of 24 autosensing 10/100/1000 ports plus 2 SFP ports
Physical characteristics Dimensions 12.99(w) x 6.81(d) x 1.73(h) in
(32.99 x 17.3 x 4.39 cm) (1U height)
Weight 2.54 lb (1.15 kg)
Memory and processor 128 MB RAM, 8 MB flash; packet buffer size: 512 KB
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included), horizontal
surface, wall and under table mounting
Performance 100 Mb Latency < 3.3µs (64-byte packets)
1000 Mb Latency < 2.2µs (64-byte packets)
Throughput up to 38.7 million pps
Switching capacity 52 Gbps
MAC address table size 8000 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C)
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 140°F (60°C)
Altitude up to 10,000 ft (3 km)
Acoustic Power: 0 dB no fan
Electrical characteristics Voltage 100-127/200-240 VAC
Current 0.4/0.3 A
Maximum power rating 22 W
Frequency 50/60 Hz
Notes Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
Safety UL 60950-1; IEC 60950; EN 60950
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 10

Emissions EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B
Class A; VCCI V-4
Immunity ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management Web browser
Notes Use only supported genuine HP mini-GBICs with your switch.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (U6321E)
3-year, 24x7 SW phone support, software updates (UF792E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR849E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR850E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7
software phone support (HR851E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR948E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR949E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR950E)
4-year, 24x7 SW phone support, software updates (UR951E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR952E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR953E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR954E)
5-year, 24x7 SW phone support, software updates (UR955E)
3 Yr 6 hr Call-to-Repair Onsite (UW368E)
4 Yr 6 hr Call-to-Repair Onsite (UW369E)
5 Yr 6 hr Call-to-Repair Onsite (UW370E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR853E)
1-year, 24x7 software phone support, software updates (HR852E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR851E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS554E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS555E)
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 11

3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS556E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS557E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS558E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS559E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS560E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS561E)
Refer to the HP website at: www.hp.com/networking/services for details on
the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 1810-48G Switch
(J9660A)
Ports 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 SFP 100/1000 Mbps ports
Supports a maximum of 48 autosensing 10/100/1000 ports plus 4 SFP ports
Physical characteristics Dimensions 17.4(w) x 9.75(d) x 1.75(h) in
(44.2 x 24.77 x 4.45 cm) (1U height)
Weight 6.31 lb (2.86 kg)
Memory and processor 8 MB flash, 64 MB SDRAM; packet buffer size: 1.5 MB
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop,
tabletop, and under-table mounting
Performance 100 Mb Latency < 8.4 µs (64-byte packets)
1000 Mb Latency < 3.2 µs (64-byte packets)
Throughput up to 77.4 million pps (64-byte packets)
Switching capacity 104 Gbps
MAC address table size 16000 entries
Environment Operating temperature 32°F to 113°F (0°C to 45°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 22 dB single fan
Electrical characteristics Maximum heat 204 BTU/hr (215.22 kJ/hr)
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 12

dissipation
Voltage 100-127/200-240 VAC
Current 0.9/0.5 A
Maximum power rating 60 W
Frequency 50/60 Hz
Notes Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
Safety CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950
Emissions EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B
Class A; VCCI V-4
Immunity ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management Web browser
Notes Use only supported genuine HP mini-GBICs with your switch.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (HS854E)
3-year, 4-hour onsite, 24x7 coverage for hardware (HS856E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (U6321E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (HS858E)
3-year, 24x7 SW phone support, software updates (UF792E)
3-year, 24x7 SW phone support, software updates (HS859E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HS846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HS848E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7
software phone support (HS850E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (HS862E)
4-year, 4-hour onsite, 24x7 coverage for hardware (HS864E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(HS866E)
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 13

4-year, 24x7 SW phone support, software updates (HS867E)
5-year, 4-hour onsite, 13x5 coverage for hardware (HS870E)
5-year, 4-hour onsite, 24x7 coverage for hardware (HS872E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(HS874E)
5-year, 24x7 SW phone support, software updates (HS875E)
3 Yr 6 hr Call-to-Repair Onsite (HS860E)
3 Yr 6 hr Call-to-Repair Onsite (UW368E)
4 Yr 6 hr Call-to-Repair Onsite (HS868E)
5 Yr 6 hr Call-to-Repair Onsite (HS876E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HS852E)
1-year, 24x7 software phone support, software updates (HS851E)
Refer to the HP website at: www.hp.com/networking/services for details on
the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 1810-8 v2 Switch
(J9800A)
Ports 7 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u
Type 100BASE-TX); Duplex: half or full
1 RJ-45 autosensing 10/100/1000 port (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-
T/100BASE-TX: half or full; 1000BASE-T: full only
Supports a maximum of 7 autosensing 10/100 ports plus 1 autosensing
10/100/1000 ports
Physical characteristics Dimensions 7.93(w) x 4.65(d) x 1.73(h) in
(20.14 x 11.81 x 4.39 cm) (1U height)
Weight 0.77 lb (.35 kg)
Memory and processor 128 MB RAM, 8 MB flash; packet buffer size: 512 KB
Mounting wall, desktop and under table mounting
Performance 100 Mb Latency < 3.3 µs (64-byte packets)
Throughput up to 2.5 million pps
Switching capacity 3.4 Gbps
MAC address table size 8000 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C)
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 140°F (60°C)
Altitude up to 10,000 ft (3 km)
Acoustic Power: 0 dB no fan
Electrical characteristics Voltage 100-240 VAC
Current 0.5 A
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 14

Maximum power rating 4.8 W
Frequency 50/60 Hz
Notes Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
Safety UL 60950-1; IEC 60950; EN 60950
Emissions EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B
Class A; VCCI V-4
Immunity ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management Web browser
Notes Use only supported genuine HP mini-GBICs with your switch.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UE256E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UE257E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (UE258E)
3-year, 24x7 SW phone support, software updates (UE260E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR846E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR847E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR848E)
4-year, 24x7 SW phone support, software updates (UR849E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR850E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR851E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR852E)
5-year, 24x7 SW phone support, software updates (UR853E)
3 Yr 6 hr Call-to-Repair Onsite (UW383E)
4 Yr 6 hr Call-to-Repair Onsite (UW384E)
5 Yr 6 hr Call-to-Repair Onsite (UW385E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR899E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR900E)
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 15

1-year, 6 hour Call-To-Repair Onsite for hardware (HR903E)
1-year, 24x7 software phone support, software updates (HR902E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR901E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HU347E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HU348E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HU349E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HU350E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS810E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS811E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS812E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS813E)
Refer to the HP website at: www.hp.com/networking/services for details on
the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 1810-24 v2 Switch
(J9801A)
Ports 22 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u
Type 100BASE-TX); Duplex: half or full
2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-
T/100BASE-TX: half or full; 1000BASE-T: full only
2 SFP 100/1000 Mbps ports
Supports a maximum of 22 autosensing 10/100 ports plus 2 autosensing
10/100/1000 ports plus 2 SFP port
Physical characteristics Dimensions 12.99(w) x 6.81(d) x 1.73(h) in
(32.99 x 17.3 x 4.39 cm) (1U height)
Weight 2.2 lb (1 kg)
Memory and processor 128 MB RAM, 8 MB flash; packet buffer size: 512 KB
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included), horizontal
surface, wall and under table mounting
Performance 100 Mb Latency < 3.4µs (64-byte packets)
Throughput up to 38.7 million pps
Switching capacity 12.4 Gbps
MAC address table size 8000 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C)
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 16

Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 140°F (60°C)
Altitude up to 10,000 ft (3 km)
Acoustic Power: 0 dB no fan
Electrical characteristics Voltage 100-127/200-240 VAC
Current 0.4/0.3 A
Maximum power rating 22 W
Frequency 50/60 Hz
Notes Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
Safety UL 60950-1; IEC 60950; EN 60950
Emissions EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B
Class A; VCCI V-4
Immunity ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Management Web browser
Notes Use only supported genuine HP mini-GBICs with your switch.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (U6321E)
3-year, 24x7 SW phone support, software updates (UF792E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR948E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR949E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR950E)
4-year, 24x7 SW phone support, software updates (UR951E)
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 17

5-year, 4-hour onsite, 13x5 coverage for hardware (UR952E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR953E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR954E)
5-year, 24x7 SW phone support, software updates (UR955E)
3 Yr 6 hr Call-to-Repair Onsite (UW368E)
4 Yr 6 hr Call-to-Repair Onsite (UW369E)
5 Yr 6 hr Call-to-Repair Onsite (UW370E)
1-year, 4-hour onsite, 13x5 coverage for hardware (HR849E)
1-year, 4-hour onsite, 24x7 coverage for hardware (HR850E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR853E)
1-year, 24x7 software phone support, software updates (HR852E)
1-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
support and software updates (HR851E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS554E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS555E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS556E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS557E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS558E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS559E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS560E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS561E)
Refer to the HP website at: www.hp.com/networking/services for details on
the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
Standards and protocols
(applies to all products in
series)
Denial of service protection
CPU DoS Protection
General protocols
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
IEEE 802.3x Flow Control
RFC 1534 DHCP/BOOTP Interoperation
RFC 2030 Simple Network Time Protocol (SNTP) v4
Network management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014 Page 18

HP 1810 Switch Series
accessories
Cables
HP 0.5 m Multimode OM3 LC/LC Optical Cable AJ833A
HP 1 m Multimode OM3 LC/LC Optical Cable AJ834A
HP 2 m Multimode OM3 LC/LC Optical Cable AJ835A
HP 5 m Multimode OM3 LC/LC Optical Cable AJ836A
HP 15 m Multimode OM3 LC/LC Optical Cable AJ837A
HP 30 m Multimode OM3 LC/LC Optical Cable AJ838A
HP 50 m Multimode OM3 LC/LC Optical Cable AJ839A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable QK732A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable QK733A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable QK734A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable QK735A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable QK736A
HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable QK737A
Mounting Kit
HP X410 1U Universal 4-Post Rack Mounting Kit J9583A
HP 1810-24G v2 Switch (J9803A)
HP X111 100M SFP LC FX Transceiver J9054C
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X121 1G SFP RJ45 T Transceiver J8177C
HP 1810-48G Switch (J9660A)
HP X111 100M SFP LC FX Transceiver J9054C
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X121 1G SFP RJ45 T Transceiver J8177C
HP 1810-24 v2 Switch (J9801A)
HP X111 100M SFP LC FX Transceiver J9054C
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X121 1G SFP RJ45 T Transceiver J8177C
QuickSpecs
HP 1810 Switch Series
Accessories
DA - 13447 North America — Version 18 — January 17, 2014 Page 19

NOTE: Details are not available for all accessories. The following specifications were available at the time of publication.
HP 0.5 m Multimode OM3
LC/LC Optical Cable
(AJ833A)
Cabling Cable type :
50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of
up to 300 m
Maximum distance :
10Gbps Transfer Rate (Ethernet): 300m
Notes Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one end
and LC duplex connectors on other end.
Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um
Coating diameter: 245 ± 10um
Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km
@850/1300nm.
Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km
@850/1300nm. VCSEL Laser sources: 600 / 600 meters @850/1300nm
for Gigabit Ethernet compliant links.
CABLE: The cable is duplex zipcord graded index 50/125um multimode
optical fiber and designed to work in both the 850 and 1300 nm
wavelength windows.
BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.
Jacket Color: Aqua for OM3 multimode per TIA 598
Boot Color: White
Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M
added for lengths > 30 meters.
Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310
nm @ 23°C as tested in accordance with EIA 455-46.
Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg
Services Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
QuickSpecs
HP 1810 Switch Series
Accessory Product Details
DA - 13447 North America — Version 18 — January 17, 2014 Page 20
