HP 2520 Series User instructions

Models
HP 2520-8-PoE Switch J9137A
HP 2520-24-PoE Switch J9138A
HP 2520-8G-PoE Switch J9298A
Key features
Fully managed Layer 2 switch in 8 or 24 ports
Choice of Fast Ethernet or Gigabit PoE models
Power over Ethernet for voice, video, and wireless
Energy-efficient design and quiet operation
Rack-mountable and compact form factors
Introduction
The HP 2520 switch series is ideally suited for small and medium businesses looking to deploy voice, video, or wireless solutions that
require Power over Ethernet (PoE) connectivity. The series consists of three switches: the HP 2520-8-PoE, 2520-24-PoE, and 2520-8G-
PoE Switches. The three models offer a choice of either Fast Ethernet or Gigabit Ethernet connectivity. All models also include support
for dual-personality Gigabit Ethernet ports that can be used for either copper or fiber connectivity. All products are fully managed via
SNMP, command-line interface (CLI), and graphical user interface (GUI) and offer a Layer 2 feature set. In addition, the products provide
deployment flexibility with compact, quiet, and energy-efficient designs.
Features and Benefits
Quality of Service (QoS)
Selectable queue configuration : allows you to increase performance and/or traffic reliability by selecting the number of
queues that best meet the requirements of your network applications; switch will map 8 priorities to either 2 or 4 queues
Simplified QoS configuration :
Port-based: prioritize traffic by specifying a port and priority level
VLAN based: prioritize traffic by specifying a VLAN and priority level
IEEE 802.1p traffic prioritization : honors and sets IEEE 802.1p priority in the VLAN tag
Type of service :
IP precedence : honors IP precedence bits and allows mapping to a priority queue
Differentiated Services Code Point values : honors Differentiated Services Code Point (DSCP) bits and allows mapping to
a priority queue
Flow control : helps ensure reliable communications during full-duplex operation
Management
Choice of management interfaces :
Web graphical user interface (GUI): easy-to-use graphical interface allows configuration of the switch from any Web
browser
Command-line interface (CLI): robust command-line interface provides advanced configuration and diagnostics
Simple Network Management Protocol (SNMPv2c/SNMPv3): allows switch to be managed with a variety of third-party
network management applications
Integration with HP PCM : enables discovery, mapping, logging, and configuration via HP PCM, which is available as a free
QuickSpecs
HP 2520 Switch Series
Overview
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 1

download from the Web
Virtual stacking : single IP address manages up to 16 switches
Port mirroring : allows traffic to be mirrored on any port or a network analyzer to assist with diagnostics or detecting network
attacks
Multiple configuration files : configuration file management tools allow up to three configuration files to be managed and
stored on the switch
Dual flash images : provide independent primary and secondary operating system files for backup while upgrading
Network tools : command-line interface includes telnet client, ping, traceroute, and Layer 2 link test tools for diagnostics
IEEE 802.1AB Link Layer Discovery Protocol (LLDP): automated device discovery protocol for easy mapping by network
management applications
Command authorization : leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login;
also provides an audit trail
Logging : local and remote logging of events via SNMP (v2c and v3) and syslog
IPv6 host : allows switches to be managed using IPv6
RMON : provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events
Find-Fix-Inform : finds and fixes common network problems automatically, then informs the administrator
Front-panel LEDs :
Locator LED : allows users to set the locator LED on a specific switch to either turn on, blink, or turn off; simplifies
troubleshooting by making it easy to locate a particular switch within a rack of similar switches
Per-port LEDs : provides an at-a-glance view of status, activity, speed, and full-duplex operation
Power and fault LEDs : display any issues
Connectivity
Auto-MDIX : automatically adjusts for straight-through or crossover cables on all ports
Small Form-Factor Pluggable (SFP) slots : dual-personality ports allow for either copper or fiber connectivity such as Gigabit-
SX, -LX, -LH, and -BX or 100-FX and -BX
IEEE 802.3af Power over Ethernet : provides up to 15.4 W per port to IEEE 802.3af-compliant PoE-powered devices such as IP
phones, wireless access points, and security cameras (see product specifications for total PoE power available); supports some
prestandard PoE devices (see product FAQs for more details)
RJ-45 serial console port : front of unit location provides easy access to the switch CLI
Performance
Switch on a chip : provides highly integrated, high-performance switch design with a non-blocking architecture
Jumbo packet support : supports up to 9216-byte frame size to improve performance of large data transfers (2520G switch)
Resiliency and high availability
Port trunking and link aggregation :
Trunking: supports up to eight links per trunk to increase bandwidth and create redundant connections
IEEE 802.3ad Link Aggregation Protocol (LACP): eases configuration of trunks through automatic configuration
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP): provides high link availability in multiple VLAN environments by allowing
multiple spanning trees; provides legacy support for IEEE 802.1w (Rapid Reconfiguration of Spanning Tree Protocol) and IEEE
802.1d (Spanning Tree Protocol)
Layer 2 switching
VLAN support and tagging : supports the IEEE 802.1Q (4,094 VLAN IDs) and up to 256 port-based VLANs simultaneously
GARP VLAN Registration Protocol (GVRP): allows automatic learning and dynamic assignment of VLANs
QuickSpecs
HP 2520 Switch Series
Overview
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 2

Broadcast control : allows limitation of broadcast traffic rate to cut down on unwanted broadcast traffic on the network
Security
Manager and operator privilege levels : enables read-only (operator) and read-write (manager) access on management
interfaces
RADIUS/TACACS+ for management access authentication : eases switch management security administration by using a
password authentication server
Secure protocols for encryption of management traffic :
Secure Shell (SSHv2): encrypts all transmitted data for secure, remote CLI access over IP networks
Secure Sockets Layer (SSL): encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in
the switch
Simple Network Management Protocol (SNMP) v3: allows encryption of traffic between switch MIBs and network
management software
Secure FTP (SFTP): encrypts uploads and downloads of configuration file
Protected ports : prevents designated ports from communicating with each other while allowing access to unprotected ports
Port security : allows access only to specified MAC addresses, which can be learned or specified by the administrator
MAC address lockout : prevents particular configured MAC addresses from connecting to the network
MAC address lockdown : allows only specified MAC addresses access to the network on a specified port
Denial-of-service (DoS) attack filtering : automatically filters and drops common DoS attack traffic types
User authentication for port access :
IEEE 802.1X : utilizes an industry-standard user authentication with an IEEE 802.1X supplicant on the client in conjunction
with a RADIUS server
Web-based : similar to IEEE 802.1X, it provides a browser-based environment to authenticate clients
MAC-based : client is authenticated with the RADIUS server based on MAC address
Concurrent authentication schemes : each switch port will accept up to two sessions of IEEE 802.1X, Web, and/or MAC
authentications concurrently
Custom banner : displays security policy when users log in to the switch
Spanning Tree Protocol Bridge Protocol Data Unit (BPDU) port protection : blocks BPDUs on ports that do not require BPDUs,
preventing forged BPDU attacks
Spanning Tree Protocol Root Guard : when running the spanning tree protocol, protects root bridge from malicious attack or
configuration mistakes
Physical security :
Front-panel buttons: provides the ability to disable reset and clear buttons on front panel for added security
Kensington Lock: 2520-8-PoE and 2520G-8-PoE switches include a Kensington Lock slot for securing the switches in
open-space deployments
Convergence
LLDP-MED (Media Endpoint Discovery): is a standard extension of LLDP that automatically configures network devices such as IP
phones
IP multicast snooping and data-driven IGMP : automatically prevents flooding of IP multicast traffic
Voice VLAN : uses LLDP-MED to automatically configure a VLAN for IP phones
Flexibility
Quiet operation :
Fanless design (2520-8-PoE and 2520G-8-PoE switches): enables quiet operation for deployment in open spaces
Variable-speed fans (2520-24-PoE switch): improves fan speed for the operating environment while lowering noise and
energy consumption levels
QuickSpecs
HP 2520 Switch Series
Overview
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 3

Flexible mounting :
Rackable : is mountable in a standard 19-inch rack with included hardware (2520-8-PoE and 2520G-8-PoE rack kit
available free of charge via the Web)
Wall mountable : allows the switch to be mounted to a wall using included hardware
Surface mountable : allows the product to be mounted above or below a surface (such as a desk or table) with included
hardware
Compact size : products are designed to reduce space requirements (see product specifications for exact dimensions)
Product Architecture
Energy-efficient design :
Fans : fanless (2520-8-PoE and 2520G-8-PoE switches) and variable-speed fans (2520-24-PoE switch) help reduce power
consumption
Port LEDs : port link and activity LEDs can be turned off to conserve energy
Port low-power mode : when no link is detected on a port, the port will automatically go into low-power mode to
conserve energy (2520G switch)
Warranty and support
Lifetime warranty : for as long as you own the product with advance replacement and next-business-day delivery (available in
most countries) †
Electronic and telephone support : limited electronic and telephone support is available from HP; refer to:
www.hp.com/networking/warranty for details on the support provided and the period during which support is available
Software releases : refer to: www.hp.com/networking/warranty for details on the software releases provided and the period
during which software releases are available for your product(s)
† Hardware warranty replacement for as long as you own the product, with next business day advance replacement (available in most
countries) with a five-year hardware warranty replacement for the disk drive included with HP AllianceONE Services zl Module, HP
Threat Management Services zl Module, HP PCM+ Agent with AllianceONE Services zl Module, and HP E-MSM765 zl Mobility Controller.
For details, refer to the HP Software License, Warranty, and Support booklet at: www.hp.com/networking/warranty .
QuickSpecs
HP 2520 Switch Series
Overview
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 4

Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
HP 2520-8-PoE Switch J9137A
24 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
HP 2520-24-PoE Switch J9138A
24 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
HP 2520-8G-PoE Switch J9298A
8 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X121 1G SFP LC LH Transceiver J4860C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143A
Note 2 Localization required. (See Localization Menu for list.)
Factory Racked Models
HP 2520-24-PoE Switch J9138A
24 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
HP 2520-8G-PoE Switch J9298A
QuickSpecs
HP 2520 Switch Series
Configuration
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 5

8 autosensing 10/100 ports
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port or as a SFP slot
min=0 \ max=2 SFP Transceivers
1U - Height
See Configuration
Note:1, 2
Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X121 1G SFP LC LH Transceiver J4860C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143A
Note 2 If this switch is factory installed in HP Universal Racks, Then the J9583A orJ9583A#0D1 is required.
EMEA then J9583A is required.
APD, Japan and China then J9583A#0D1 is required.
CLIC Only - Allow the J9583AZ in all regions.
Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.
Transceivers
SFP Transceivers
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
HP X121 1G SFP LC LH Transceiver J4860C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143B
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
Internal Power Supplies
No Power supplies
Cables
Multi-Mode Cables
QuickSpecs
HP 2520 Switch Series
Configuration
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 6

HP .5m Multi-mode OM3 LC/LC FC Cable AJ833A
HP 1m Multi-mode OM3 LC/LC FC Cable AJ834A
HP 2 m Multimode OM3 LC/LC FC Cable AJ835A
HP 5 m Multimode OM3 LC/LC FC Cable AJ836A
HP 15 m Multimode OM3 LC/LC FC Cable AJ837A
HP 30 m Multimode OM3 LC/LC FC Cable AJ838A
HP 50 m Multimode OM3 LC/LC FC Cable AJ839A
HP Premier Flex LC/LC OM4 2f 1m Cbl QK732A
HP Premier Flex LC/LC OM4 2f 2m Cbl QK733A
HP Premier Flex LC/LC OM4 2f 5m Cbl QK734A
HP Premier Flex LC/LC OM4 2f 15m Cbl QK735A
HP Premier Flex LC/LC OM4 2f 30m Cbl QK736A
HP Premier Flex LC/LC OM4 2f 50m Cbl QK737A
Switch Enclosure Options
Rack Mount Kit
HP X410 1U Univ 4-post Rack Mnt Kit J9583A
See Configuration
Note:1, 2
Cofiguration Rules:
Note 1 If this Mounting Kit is order with #0D1 then it integrates to the HP Rack. (not the switch)
Note 2 If the J9583A is ordered in EMEA fire the following UNBUILDABLE error:
"The J9583A cannot be ordered with option integrated to the Rack in the EMEA region. The Rack Mount kit must be
ordered as BTO using supplier 8OCZ."
Cable Guard
HP X510 1U Cable Guard J9700A
See Configuration
Note:1
Cofiguration Rules:
Note 1 This Cable Guard is supported only on J9137A and J9298A.
Rack Mount Kit
HP X520 1U Power Adapter Shelf J9701A
QuickSpecs
HP 2520 Switch Series
Configuration
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 7

See Configuration
Note:1
Cofiguration Rules:
Note 1 This Cable Guard is supported only on J9137A and J9298A.
QuickSpecs
HP 2520 Switch Series
Configuration
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 8

HP 2520-8-PoE Switch
(J9137A)
Ports 8 RJ-45 autosensing 10/100 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3af PoE)
Media Type: Auto-MDIX
Duplex: half or full
2 dual-personality ports
each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type
10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit
Ethernet) or as a SFP slot (for use with SFP transceivers)
1 RJ-45 serial console port
Physical characteristics Dimensions 6.28(d) x 10(w) x 1.75(h) in. (15.95 x 25.4 x 4.45
cm) (1U height)
Weight 3.62 lb. (1.64 kg) including power adapter and
power cord
Memory and processor Processor Freescale PowerPC 8313 @ 266 MHz, 32 MB flash,
128 MB DDR2 SDRAM; packet buffer size: 384 KB
dynamically allocated
Mounting Mounts in an EIA-standard 19-inch telco rack or equipment cabinet
(rack-mounting kit available); horizontal surface mounting; wall mounting
Performance 100 Mb Latency < 1.9 µs (LIFO 64-byte packets)
1000 Mb Latency < 1.5 µs (LIFO 64-byte packets)
Throughput 4.1 million pps
Switching capacity 5.6 Gbps
MAC address table size 8000 entries
Environment Operating temperature 32°F to 113°F (0°C to 45°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Non-operating/
Storage temperature
-40°F to 158°F (-40°C to 70°C)
Non-operating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB, Pressure: 0 dB
Electrical characteristics Description Use only the external power adapter module
(5070-6082, PA1 AC adapter) supplied with this
product
Maximum heat
dissipation
87 BTU/hr (91.79 kJ/hr)
Voltage 100-240 VAC
Current 1.5 A
Idle power 9.4 W
Maximum power rating 85.5 W
PoE power 67 W
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 9

Frequency 50/60 Hz
Notes Idle power is the actual power consumption of the
device with no ports connected.
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
PoE power is the total power budget available to
all PoE ports.
Achieved Miercom Certified Green Award
Safety cUL (CSA 22.2 No. 60950); CE Labeled; UL 60950-1; UL Listed; CAN/CSA
22.2 No. 60950; EN 60825; AS/NZS 60950; IEC 60950-1; EN 60950-1
Emissions FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A;
ICES-003 (Canada); AS/NZS CISPR 22; IEC/EN 61000-3-2; IEC/EN
61000-3-3; IEC 61000:4-2, 4-3, 4-4, 4-5, 4-6, 4-8, 4-11
Immunity Generic EN 55024, CISPR 24
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics EN 61000-3-2, IEC 61000-3-2
Flicker EN 61000-3-3, IEC 61000-3-3
Management HP PCM+; HP PCM; command-line interface; Web browser; configuration
menu; out-of-band management (serial RS-232C); IEEE 802.3 Ethernet MIB;
Repeater MIB; Ethernet Interface MIB
Notes When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, for example, J4858B,
J4859C) are required.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (U6321E)
3-year, 24x7 SW phone support, software updates (UF792E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR948E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR949E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 10

(UR950E)
4-year, 24x7 SW phone support, software updates (UR951E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR952E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR953E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR954E)
5-year, 24x7 SW phone support, software updates (UR955E)
3 Yr 6 hr Call-to-Repair Onsite (UW368E)
4 Yr 6 hr Call-to-Repair Onsite (UW369E)
5 Yr 6 hr Call-to-Repair Onsite (UW370E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR853E)
1-year, 24x7 software phone support, software updates (HR852E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS554E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS555E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS556E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS557E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS558E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS559E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS560E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS561E)
Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 2520-24-PoE Switch
(J9138A)
Ports 24 RJ-45 autosensing 10/100 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3af PoE); Media Type: Auto-MDIX;
Duplex: half or full
2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type:
Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a SFP slot (for
use with SFP transceivers)
1 RJ-45 serial console port
Physical characteristics Dimensions 9.69(d) x 17.44(w) x 1.75(h) in. (24.61 x 44.3 x
4.45 cm) (1U height)
Weight 7.1 lb. (3.22 kg)
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 11

Memory and processor Processor Freescale PowerPC 8313 @ 266 MHz, 32 MB flash,
128 MB DDR2 SDRAM; packet buffer size: 384 KB
dynamically allocated
Mounting Mounts in an EIA-standard 19-inch telco rack or equipment cabinet
(rack-mounting kit available); horizontal surface mounting; wall mounting
Performance 100 Mb Latency < 1.9 µs (LIFO 64-byte packets)
1000 Mb Latency < 1.5 µs (LIFO 64-byte packets)
Throughput 6.2 million pps
Switching capacity 12.8 Gbps
MAC address table size 8000 entries
Environment Operating temperature 32°F to 113°F (0°C to 50°C)
Operating relative
humidity
15% to 95% @ 104ºF (40ºC), non-condensing
Nonoperating/
Storage temperature
-40ºF to 158ºF (-40ºC to 70ºC)
Non-operating/
Storage relative humidity
15% to 95% @ 149ºF (65ºC), non-condensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 27.9 dB, Pressure: 36.0 dB; DIN 45635T.19
per ISO 7779
Electrical characteristics Maximum heat
dissipation
208 BTU/hr (219.44 kJ/hr)
Voltage 100-127 / 200-240 VAC
Current 3.3/1.6 A
Idle power 21.6 W
Maximum power rating 257 W
PoE power 195 W
Frequency 50/60 Hz
Notes Idle power is the actual power consumption of the
device with no ports connected.
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
PoE power is the total power budget available to
all PoE ports.
Achieved Miercom Certified Green Award
Safety cUL (CSA 22.2 No. 60950); CE Labeled; UL 60950-1; UL Listed; CAN/CSA
22.2 No. 60950; EN 60825; AS/NZS 60950; IEC 60950-1; EN 60950-1
Emissions FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A;
ICES-003 (Canada); AS/NZS CISPR 22; IEC/EN 61000-3-2; IEC/EN
61000-3-3; IEC 61000:4-2, 4-3, 4-4, 4-5, 4-6, 4-8, 4-11
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 12

Immunity Generic EN 55024, CISPR 24
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics EN 61000-3-2, IEC 61000-3-2
Flicker EN 61000-3-3, IEC 61000-3-3
Management HP PCM+; HP PCM; command-line interface; Web browser; configuration
menu; out-of-band management (serial RS-232C); IEEE 802.3 Ethernet MIB;
Repeater MIB; Ethernet Interface MIB
Notes When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, for example, J4858B,
J4859C) are required.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (U6321E)
3-year, 24x7 SW phone support, software updates (UF792E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR948E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR949E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR950E)
4-year, 24x7 SW phone support, software updates (UR951E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR952E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR953E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR954E)
5-year, 24x7 SW phone support, software updates (UR955E)
3 Yr 6 hr Call-to-Repair Onsite (UW368E)
4 Yr 6 hr Call-to-Repair Onsite (UW369E)
5 Yr 6 hr Call-to-Repair Onsite (UW370E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR853E)
1-year, 24x7 software phone support, software updates (HR852E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS554E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS555E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS556E)
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 13

3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS557E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS558E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS559E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS560E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS561E)
Refer to the HP website at: www.hp.com/networking/services for details on
the
service-level descriptions and product numbers. For details about services
and
response times in your area, please contact your local HP sales office.
HP 2520-8G-PoE Switch
(J9298A)
Ports 8 RJ-45 autosensing 10/100/1000 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE);
Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-TX;
IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a SFP slot (for use with SFP
transceivers)
1 RJ-45 serial console port
Physical characteristics Dimensions 6.28(d) x 10(w) x 1.75(h) in. (15.95 x 25.4 x 4.45
cm) (1U height)
Weight 3.66 lb. (1.66 kg) including power adapter and
power cord
Memory and processor Processor Freescale PowerPC 8313 @ 266 MHz, 32 MB flash,
128 MB DDR2 SDRAM; packet buffer size: 512 KB
dynamically allocated
Mounting Mounts in an EIA-standard 19-inch telco rack or equipment cabinet
(rack-mounting kit available); horizontal surface mounting; wall mounting
Performance 100 Mb Latency < 5.3 µs (LIFO 64-byte packets)
1000 Mb Latency < 2.7 µs (LIFO 64-byte packets)
Throughput 14.8 million pps
Switching capacity 20 Gbps
MAC address table size 8000 entries
Environment Operating temperature 32ºF to 113ºF (0ºC to 45ºC)
Operating relative
humidity
15% to 95% @ 104ºF (40ºC), non-condensing
Non-operating/
Storage temperature
-40ºF to 158ºF (-40ºC to 70ºC)
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 14

Non-operating/
Storage relative humidity
15% to 95% @ 149ºF (65ºC), non-condensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB, Pressure: 0 dB
Electrical characteristics Description Use only the external power adapter module
(5070-6082, PA1 AC adapter) supplied with this
product
Maximum heat
dissipation
89 BTU/hr (93.9 kJ/hr)
Voltage 100-240 VAC
Current 1.5 A
Idle power 9.3 W
Maximum power rating 86.2 W
PoE power 67 W
Frequency 50/60 Hz
Notes Idle power is the actual power consumption of the
device with no ports connected.
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
PoE power is the total power budget available to
all PoE ports.
Achieved Miercom Certified Green Award
Safety cUL (CSA 22.2 No. 60950); CE Labeled; UL 60950-1; UL Listed; CAN/CSA
22.2 No. 60950; EN 60825; AS/NZS 60950; IEC 60950-1; EN 60950-1
Emissions FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A;
ICES-003 (Canada); AS/NZS CISPR 22; IEC/EN 61000-3-2; IEC/EN
61000-3-3; IEC 61000:4-2, 4-3, 4-4, 4-5, 4-6, 4-8, 4-11
Immunity Generic EN 55024, CISPR 24
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics EN 61000-3-2, IEC 61000-3-2
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 15

Flicker EN 61000-3-3, IEC 61000-3-3
Management HP PCM+; HP PCM; command-line interface; Web browser; configuration
menu; out-of-band management (serial RS-232C); IEEE 802.3 Ethernet MIB;
Repeater MIB; Ethernet Interface MIB
Notes When using mini-GBICs with this product, mini-GBICs with revision "B" or later
(product number ends with the letter "B" or later, for example, J4858B,
J4859C) are required.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support
and SW updates (U6321E)
3-year, 24x7 SW phone support, software updates (UF792E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR948E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR949E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR950E)
4-year, 24x7 SW phone support, software updates (UR951E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR952E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR953E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone
(UR954E)
5-year, 24x7 SW phone support, software updates (UR955E)
3 Yr 6 hr Call-to-Repair Onsite (UW368E)
4 Yr 6 hr Call-to-Repair Onsite (UW369E)
5 Yr 6 hr Call-to-Repair Onsite (UW370E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR853E)
1-year, 24x7 software phone support, software updates (HR852E)
1-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS554E)
1-year, 24x7 software phone support, software updates + 4 hour hardware
exchange (HS555E)
3-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS556E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS557E)
4-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS558E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS559E)
5-year, 24x7 software phone support, software updates + Next Business Day
Hardware Exchange (HS560E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware
Exchange (HS561E)
Refer to the HP website at: www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
Standards and protocols Denial of service protection
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 16

(applies to all products in
series)
CPU DoS Protection
Device management
RFC 1591 DNS (client)
SSHv1/SSHv2 Secure Shell
General protocols
IEEE 802.1D MAC Bridges
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s Multiple Spanning Trees
IEEE 802.1w Rapid Reconfiguration of Spanning Tree
IEEE 802.3 Type 10BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
IEEE 802.3af Power over Ethernet
IEEE 802.3x Flow Control
RFC 768 UDP
RFC 783 TFTP Protocol (revision 2)
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 854 TELNET
RFC 868 Time Protocol
RFC 951 BOOTP
RFC 1350 TFTP Protocol (revision 2)
RFC 1542 BOOTP Extensions
RFC 2030 Simple Network Time Protocol (SNTP) v4
RFC 2131 DHCP
IP multicast
RFC 3376 IGMPv3 (host joins only)
IPv6
RFC 1981 IPv6 Path MTU Discovery
RFC 2460 IPv6 Specification
RFC 2925 Remote Operations MIB (Ping only)
RFC 3315 DHCPv6 (client only)
RFC 3513 IPv6 Addressing Architecture
RFC 3596 DNS Extension for IPv6
RFC 4022 MIB for TCP
RFC 4113 MIB for UDP
RFC 4251 SSHv6 Architecture
RFC 4252 SSHv6 Authentication
RFC 4253 SSHv6 Transport Layer
RFC 4254 SSHv6 Connection
RFC 4293 MIB for IP
RFC 4419 Key Exchange for SSH
RFC 4443 ICMPv6
RFC 4861 IPv6 Neighbor Discovery
RFC 4862 IPv6 Stateless Address Auto-configuration
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 17

MIBs
RFC 1213 MIB II
RFC 1493 Bridge MIB
RFC 2021 RMONv2 MIB
RFC 2613 SMON MIB
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting MIB
RFC 2665 Ethernet-Like-MIB
RFC 2668 802.3 MAU MIB
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2737 Entity MIB (Version 2)
RFC 2863 The Interfaces Group MIB
Network management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
RFC 1098 A Simple Network Management Protocol (SNMP)
RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9
(events)
SNMPv1/v2c/v3
QoS/CoS
RFC 2474 Diffserv precedence, with 4 queues per port
RFC 2475 DiffServ Architecture
RFC 2597 DiffServ Assured Forwarding (AF)
RFC 2598 DiffServ Expedited Forwarding (EF)
Security
IEEE 802.1X Port Based Network Access Control
RFC 1492 TACACS+
RFC 2138 RADIUS Authentication
RFC 2866 RADIUS Accounting
Secure Sockets Layer (SSL)
QuickSpecs
HP 2520 Switch Series
Technical Specifications
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 18

HP 2520 Switch Series accessories
Transceivers HP X111 100M SFP LC FX Transceiver J9054C
HP X112 100M SFP LC BX-D Transceiver J9099B
HP X112 100M SFP LC BX-U Transceiver J9100B
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X121 1G SFP LC LH Transceiver J4860C
HP X122 1G SFP LC BX-D Transceiver J9142B
HP X122 1G SFP LC BX-U Transceiver J9143B
Cables HP 0.5 m Multimode OM3 LC/LC Optical Cable AJ833A
HP 1 m Multimode OM3 LC/LC Optical Cable AJ834A
HP 2 m Multimode OM3 LC/LC Optical Cable AJ835A
HP 5 m Multimode OM3 LC/LC Optical Cable AJ836A
HP 15 m Multimode OM3 LC/LC Optical Cable AJ837A
HP 30 m Multimode OM3 LC/LC Optical Cable AJ838A
HP 50 m Multimode OM3 LC/LC Optical Cable AJ839A
NEW HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable QK732A
N EW HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable QK733A
NEWHP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable QK734A
NEW HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable QK735A
NEW HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable QK736A
NEW HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable QK737A
Mounting Kit HP X410 1U Universal 4-post Rack Mounting Kit J9583A
HP 2520-8-PoE Switch
(J9137A)
NEW HP X510 1U Cable Guard J9700A
NEW HP X520 1U Power Adapter Shelf J9701A
HP 2520-8G-PoE Switch
(J9298A)
NEW HP X510 1U Cable Guard J9700A
NEW HP X520 1U Power Adapter Shelf J9701A
QuickSpecs
HP 2520 Switch Series
Accessories
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 19

NOTE: Details are not available for all accessories. The following specifications were available at the time of publication.
HP X111 100M SFP LC FX
Transceiver (J9054C)
Ports 1 LC 100BASE-FX port (IEEE 802.3u Type 100BASE-FX); Duplex: half or full
Physical characteristics Dimensions: 2.7(d) x 0.54(w) x 0.48(h) in. (6.86 x 1.38 x 1.22 cm)
Weight: 0.06 lb. (0.03 kg)
Environment Operating temperature: 32ºF to 158ºF (0ºC to 70ºC)
Operating relative humidity: 5% to 95%
Nonoperating/Storage temperature: -40ºF to 185ºF (-40ºC to 85ºC)
Nonoperating/Storage relative humidity: 5% to 85%
Altitude: up to 10,000 ft. (3 km)
Cabling Type:
62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low
metal content, multimode fiber optic, complying with ITU-T G.651 and
ISO/IEC 793-2 Type A1b or A1a, respectively
Maximum distance:
2 km (full duplex) or 412 m (half duplex)
Notes Transmitter wavelength: 1310nm
Power consumption is 1.1 watt maximum.
For supported platforms and minimum software requirements to support this
product, see the document titled "Support for the J9054B 100-FX SFP-LC
Transceiver" on the "HP Mini-GBICs and SFPs" Manuals Web page.
Services Refer to the HP website at www.hp.com/networking/services for details on the
service-level descriptions and product numbers. For details about services and
response times in your area, please contact your local HP sales office.
HP X112 100M SFP LC BX-D
Transceiver (J9099B)
A small form-factor
pluggable (SFP) 100-
Megabit BX (bi-directional)
"downstream" transceiver
that provides 100 Mbps
full-duplex connectivity up
to 10 km on one strand of
singlemode fiber. The
J9099B connects to the
J9100B "upstream"
transceiver, or to any IEEE-
standard 100BASE-BX10-U
("upstream") device.
Ports 1 LC 100BASE-BX10 port (IEEE 802.3ah Type 100BASE-BX10-D); Duplex: full
only
Physical characteristics Dimensions 2.7(d) x 0.55(w) x 0.48(h) in. (6.86 x 1.39 x 1.22
cm)
Weight 0.04 lb. (0.03 kg)
Environment Operating temperature 32ºF to 158ºF (0ºC to 70ºC)
Operating relative
humidity
0% to 95%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 185ºF (-40ºC to 85ºC)
Cabling Type:
Single-mode fiber optic, complying with ITU-T G.652;
Maximum distance:
0.5-10,000 m (single-mode fiber)
QuickSpecs
HP 2520 Switch Series
Accessory Product Details
DA - 13525 Worldwide — Version 12 — November 12, 2013 Page 20
