HP 2600-PWR Series User manual

Access Security Guide
www.hp.com/go/hpprocurve
Switch 2600 Series
Switch 2600-PWR Series
Switch 2800 Series
Switch 4100 Series
Switch 6108

HP ProCurve
Switch 2600 Series
Switch 2600-PWR Series
Switch 2800 Series
Switch 4100gl Series
Switch 6108
Access Security Guide
October 2004

© Copyright 2001-2004 Hewlett-Packard Company,L..P. The infor-
mation contained herein is subject to change without notice.
Publication Number
5990-6024
October 2004
Applicable Products
HP ProCurve Switch 2626 (J4900A)
HP ProCurve Switch 2626-PWR (J8164A)
HP ProCurve Switch 2650 (J4899A)
HP ProCurve Switch 2650-PWR (J8165A)
HP ProCurve Switch 2824 (J4903A)
HP ProCurve Switch 2848 (J4904A)
HP ProCurve Switch 4104gl (J4887A)
HP ProCurve Switch 4108gl (J4865A)
HP ProCurve Switch 6108 (J4902A)
Trademark Credits
Windows NT®, Windows®, and MS Windows® are US
registered trademarks of Microsoft Corporation.
Software Credits
SSH on HP ProCurve Switches is based on the OpenSSH
software toolkit. This product includes software developed
by the OpenSSH Project for use in the OpenSSH Toolkit. For
more information on OpenSSH, visit http://
www.openssh.com.
SSL on HP ProCurve Switches is based on the OpenSSL
software toolkit. This product includes software developed
by the OpenSSL Project for use in the OpenSSL Toolkit. For
more information on OpenSSL, visit
http://www.openssl.org.
This product includes cryptographic software written by
Eric Young ([e-mail])
This product includes software written by Tim Hudson
([e-mail])
Disclaimer
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FORA PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
Hewlett-Packard Company shall not be liable for technical
or editorial errors or omissions contained herein. The
information is provided "as is" without warranty of any kind
and is subject to change without notice. The warranties for
Hewlett-Packard Company products are set forth in the
express limited warranty statements for such products.
Nothing herein should be construed as constituting an
additional warranty.
Hewlett-Packard assumes no responsibility for the use or
reliability of its software on equipment that is not furnished
by Hewlett-Packard.
Warranty
See the Customer Support/Warranty booklet included with
the product.
A copy of the specific warranty terms applicable to your
Hewlett-Packard products and replacement parts can be
obtained from your HP Sales and Service Office or
authorized dealer.
Hewlett-Packard Company
8000 Foothills Boulevard, m/s 5551
Roseville,California 95747-5551
http://www.hp.com/go/hpprocurve

Contents
1 Getting Started
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Introduction and Applicable Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
About the Feature Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Overview of Access Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
General SwitchTraffic Security Guideline . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Command Syntax Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Simulating Display Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Command Prompts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Screen Simulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Port Identity Convention for Examples . . .. . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Getting Documentation From the Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Sources for MoreInformation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Need Only a Quick Start? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
To Set Up and Install the Switch in Your Network . . . . . . . . . . . . . . . . . . 1-11
2 Configuring Username and Password Security
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Configuring Local Password Security .. . .. . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Menu: Setting Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
CLI: Setting Passwords and Usernames . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Web: Setting Passwords and Usernames . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Front-Panel Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
When Security Is Important . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Front-Panel Button Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
iii

Configuring Front-Panel Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Password Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Password Recovery Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
3 Web and MAC Authentication for the Series 2600/
2600-PWR and 2800 Switches
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Client Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
How Web and MAC Authentication Operate . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Authenticator Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
General Setup Procedure for Web/MAC Authentication . . . . . . . . . . . . . . 3-12
Do These Steps Before You ConfigureWeb/MAC Authentication . . 3-12
Additional Information for Configuring the RADIUS Server To Support
MAC Authentication . . .. . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Configuring the Switch To Access a RADIUS Server . . . . . . . . . . . . . . . . 3-15
Configuring Web Authentication on the Switch . . . . . . . . . . . . . . . . . . . . . 3-17
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Configure the Switch for Web-Based Authentication . . . . . . . . . . . . . 3-18
Configuring MAC Authentication on the Switch . . . . . . . . . . . . . . . . . . . . 3-22
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
Configure the Switch for MAC-Based Authentication . . . . . . . . . . . . 3-23
Show Statusand Configuration of Web-Based Authentication . . . . . . . . 3-26
Show Statusand Configuration of MAC-Based Authentication . . . . . . . . 3-28
Client Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
4 TACACS+ Authentication
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
iv

Terminology Used in TACACS Applications: . . . . . . . . . . . . . . . . . . . . . . . . 4-3
General System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
General Authentication Setup Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Configuring TACACS+ on the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
BeforeYou Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
CLI CommandsDescribed in this Section . . . . . . . . . . . . . . . . . . . . . . . 4-9
Viewing the Switch’s Current Authentication Configuration . . . . . . . 4-9
Viewing the Switch’s Current TACACS+ Server
Contact Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Configuring the Switch’s Authentication Methods . . . . . . . . . . . . . . . 4-11
Configuring the Switch’sTACACS+ Server Access . . . . . . . . . . . . . . 4-15
How Authentication Operates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
General Authentication Process Using a TACACS+ Server . . . . . . . . 4-20
Local Authentication Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
Using the Encryption Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
Controlling Web Browser Interface Access When Using TACACS+
Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
Messages Related to TACACS+ Operation . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
5 RADIUS Authentication and Accounting
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Switch Operating Rules for RADIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
General RADIUS Setup Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Configuring the Switch for RADIUS Authentication . . . . . . . . . . . . . . . . . . 5-6
Outline of the Steps for Configuring RADIUS Authentication . . . . . . 5-6
1. Configure Authentication for the AccessMethods You Want RADIUS
To Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
2. Configure the Switch To Access a RADIUS Server . . . . . . . . . . . . 5-10
3. Configure the Switch’s Global RADIUS Parameters . . . . . . . . . . . 5-12
Local Authentication Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
v

Controlling Web Browser Interface Access When Using RADIUS
Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
Configuring RADIUS Accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
Operating Rules for RADIUS Accounting . . . . . . . . . . . . . . . . . . . . . . 5-19
Steps for Configuring RADIUS Accounting . . . . . . . . . . . . . . . . . . . . . 5-19
Viewing RADIUS Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
General RADIUS Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
RADIUS Authentication Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
RADIUS Accounting Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
Changing RADIUS-Server AccessOrder . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-29
Messages Related to RADIUS Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
6 Configuring Secure Shell (SSH)
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Prerequisite for Using SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Public Key Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Steps for Configuring and Using SSH for Switch and
Client Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
General Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Configuring the Switch for SSH Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
1. Assigning a Local Login(Operator) and
Enable (Manager) Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
2. Generating the Switch’s Public and Private Key Pair . . . . . . . . . . 6-10
3. Providing the Switch’s Public Key to Clients . . . . . . . . . . . . . . . . . . 6-12
4. Enabling SSH on the Switch and Anticipating SSH Client Contact
Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
5. Configuring the Switch for SSH Authentication . . . . . . . . . . . . . . . 6-18
6. Use an SSH Client To Access the Switch . . . . . . . . . . . . . . . . . . . . . 6-21
Further Information on SSH Client Public-Key Authentication . . . . . . . . 6-21
Messages Related to SSH Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27
vi

7 Configuring Secure Socket Layer (SSL)
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Prerequisite for Using SSL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Steps for Configuring and Using SSL for Switch and
Client Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
General Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Configuring the Switch for SSLOperation . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
1. Assigning a Local Login(Operator) and
Enable (Manager)Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
2. Generating the Switch’s Server Host Certificate . . . . . . . . . . . . . . . . 7-9
3. Enabling SSL on the Switch and Anticipating SSL Browser Contact
Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
Common Errors inSSL setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-21
8 Configuring Port-Based Access Control (802.1X)
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Why Use Port-Based Access Control? . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
How 802.1X Operates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Authenticator Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Switch-Port Supplicant Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
General Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
General Setup Procedure for Port-Based Access Control (802.1X) . . . . . 8-12
Do These Steps Before You Configure 802.1X Operation . . . . . . . . . 8-12
Overview: Configuring 802.1X Authentication on the Switch . . . . . . 8-13
Configuring Switch Ports as 802.1X Authenticators . . . . . . . . . . . . . . . . . 8-15
1. Enable 802.1X Authentication on Selected Ports . . . . . . . . . . . . . . 8-15
3. Configure the 802.1X Authentication Method . . . . . . . . . . . . . . . . . 8-19
4. Enter the RADIUSHost IP Address(es) . . . . . . . . . . . . . . . . . . . . . . 8-20
vii

5. Enable 802.1X Authentication on the Switch . . . . . . . . . . . . . . . . . 8-20
802.1X Open VLAN Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-21
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-21
Use Models for 802.1X Open VLAN Modes . . . . . . . . . . . . . . . . . . . . . 8-22
Operating Rules for Authorized-Client and
Unauthorized-Client VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-25
Setting Up and Configuring 802.1X Open VLAN Mode . . . . . . . . . . . . 8-27
802.1X Open VLAN Operating Notes . . . . .. . . . . . . . . . . . . . . . . . . . . 8-31
Option For Authenticator Ports: Configure Port-SecurityTo Allow Only
802.1X Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-32
Configuring Switch Ports To Operate As Supplicants for 802.1X Connections
to Other Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-34
Displaying 802.1X Configuration, Statistics, and Counters . . . . . . . . . . . . 8-38
Show Commands for Port-Access Authenticator . . . . . . . . . . . . . . . . 8-38
Viewing 802.1X Open VLAN Mode Status . . . . . . . . . . . . . . . . . . . . . . 8-40
Show Commands for Port-Access Supplicant . . . . . . . . . . . . . . . . . . . 8-43
How RADIUS/802.1X Authentication Affects VLAN Operation . . . . . . . . 8-44
Messages Related to 802.1X Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-48
9 Configuring and Monitoring Port Security
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Blocking Unauthorized Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Trunk Group Exclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
Planning Port Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
Port Security Command Options and Operation . . . . . . . . . . . . . . . . . . . . . 9-6
Retention of StaticMAC Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Displaying Current Port Security Settings . . . . . . . . . . . . . . . . . . . . . . 9-10
Configuring Port Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-12
MAC Lockdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
Differences Between MAC Lockdown and Port Security . . . . . . . . . 9-19
Deploying MAC Lockdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
viii

MAC Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-25
Port Security and MAC Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-27
Web: Displaying and Configuring Port Security Features . . . . . . . . . . . . . 9-27
Reading Intrusion Alerts and Resetting Alert Flags . . . . . . . . . . . . . . . . . . 9-28
Notice of Security Violations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-28
How the Intrusion Log Operates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-29
Keeping the Intrusion Log Current by Resetting Alert Flags . . . . . . . 9-29
Using the Event Log To Find Intrusion Alerts . . . . . . . . . . . . . . . . . . . 9-35
Web: Checking for Intrusions, Listing Intrusion Alerts, and Resetting
Alert Flags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-35
Operating Notes for PortSecurity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-36
10 Traffic/Security Filters
(HP ProCurve Series 2600/2600-PWR and 2800 Switches)
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
Using Source-Port Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4
Operating Rules for Source-Port Filters . . . . . . . . . . . . . . . . . . . . . . . . 10-4
Configuring a Source-Port Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5
Viewing a Source-Port Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-7
Filter Indexing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-8
Editing a Source-Port Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-9
11 Using Authorized IP Managers
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3
Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3
Defining Authorized Management Stations . . . . . . . . . . . . . . . . . . . . . . . . . 11-4
Overview of IP Mask Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4
Menu: Viewing and Configuring IP Authorized Managers . . . . . . . . . 11-5
CLI:Viewing and Configuring Authorized IP Managers . . . . . . . . . . . 11-6
Web:Configuring IP Authorized Managers . . . . . . . . . . . . . . . . . . . . . . . . . 11-9
ix

Building IP Masks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-9
Configuring One Station Per Authorized Manager IP Entry . . . . . . . 11-9
Configuring Multiple Stations Per Authorized Manager IP Entry . . 11-11
Additional Examples for Authorizing Multiple Stations . . . . . . . . . 11-13
Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13
Index
x

1
Getting Started
Contents
Introduction and Applicable Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
About the Feature Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Overview of Access Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
General SwitchTraffic Security Guideline . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Command Syntax Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Simulating Display Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Command Prompts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Screen Simulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Port Identity Convention for Examples . . .. . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Getting Documentation From the Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Sources for MoreInformation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Need Only a Quick Start? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
To Set Up and Install the Switch in Your Network . . . . . . . . . . . . . . . . . . 1-11
1-1

Getting Started
Introduction and Applicable Switches
Introduction and Applicable Switches
This guide describes how to use HP’s switchsecurity features to protect
access to your HP ProCurveProCurve switch. This guide is intended for these
switch models:
 HP ProCurveSwitch 4100GL Series (4104GL, 4108GL)
 HP ProCurveSwitch 2800 Series (2824, 2848)
 HP ProCurveSwitch 2600 Series (2626, 2650)
 HP ProCurveSwitch 6108
The Product Documentation CD-ROM shipped with the switch includes this
guide. You can also download the latest version from the HP ProCurve
website. (Referto “Getting Documentation From the Web” on page 1-9.)
About the Feature Descriptions
In cases where a software feature is not available in all of the switch products
covered by this guide, the text specifically indicates which devices offer the
feature.
1-2

Getting Started
Overview of Access Security Features
Overview of Access Security Features
 Local Manager and Operator Passwords(page 2-1): Control
access and privileges for the CLI, menu, and web browser interfaces.
 TACACS+ Authentication (page 4-1): Uses an authentication appli-
cation on a serverto allow or deny access to a switch.
 RADIUS Authentication and Accounting (page 5-1): Like
TACACS+,uses an authentication application on a central server to
allow or deny access to the switch. RADIUSalso providesaccounting
services for sending data about user activity and system events to a
RADIUS server.
 Secure Shell (SSH) Authentication (page 6-1): Provides
encrypted paths for remote access to switch managementfunctions.
 Secure Socket Layer (SSL) (page 7-1): Provides remote web access
to the switch via encrypted authentication paths between the switch
and management station clients capable of SSL/TLS operation.
 Port-Based Access Control (802.1X) (page 8-1): On point-to-point
connections, enables the switch to allow or deny traffic between a
port and an 802.1X-aware device (supplicant) attempting to access
the switch. Also enables the switch to operate as a supplicant for
connections to other 802.1X-aware switches.
 Port Security (page 9-1): Enables a switch port to maintain a unique
list of MAC addresses defining which specific devices are allowed to
access the network through that port. Also enables a port to detect,
prevent, and log access attempts by unauthorized devices.
 Traffic/Security Filters (page 10-1 ): Source-Port filtering enhances
in-band security by enabling outbound destination ports on the switch
to forward or droptraffic from designated sourceports (within the
same VLAN).
 Authorized IP Managers (page 11-1): Allows access to the switch
by a networked device havingan IP address previouslyconfigured in
the switch as "authorized".
HP recommends that you use local passwords together with your switch’s
other security features to provide a more comprehensive security fabric than
if you use only local passwords. For an overview, refer to Table 1-1.
1-3

Getting Started
Overview of Access Security Features
Table 1-1. Management Access Security Protection
Security Feature OffersProtection Against Unauthorized Client Access to
Switch Management Features
Offers Protection
Against
Unauthorized Client
Access to the
Network
Connection Telnet SNMP
(Net Mgmt)
Web
Browser
SSH
Client
Local Manager and Operator
Usernames and Passwords1 PtP: Yes No Yes Yes No
Remote: Yes No Yes Yes No
TACACS+1 PtP: Yes No No Yes No
Remote: Yes No No Yes No
RADIUS1 PtP: Yes No No Yes No
Remote: Yes No No Yes No
SSH Ptp: Yes No No Yes No
Remote: Yes No No Yes No
SSL Ptp: No No Yes No No
Remote: No No Yes No No
Port-BasedAccess Control (802.1X) PtP: Yes Yes Yes Yes Yes
Remote: No No No No No
Port Security (MAC address) PtP: Yes Yes Yes Yes Yes
Remote: Yes Yes Yes Yes Yes
Authorized IP Managers PtP: Yes Yes Yes Yes No
Remote: Yes Yes Yes Yes No
1The local Manager/Operator, TACACS+, and RADIUS options (direct connect ormodem access) also offer protection
for serial port access.
There are two security areas to protect: access to the switch management
features and access to the network through the switch. The preceeding table
shows the type of protection each switch security feature offers.
1-4

Getting Started
GeneralSwitch Traffic Security Guideline
General Switch Traffic Security
Guideline
Where the switch is running multiple security options, it implements network
traffic security based on the OSI (Open Systems Interconnection model)
precedence of the individualoptions, from the lowest to the highest. The
following list shows the order in which the switch implements configured
security features on traffic moving through a given port.
1. Disabled/Enabled physical port
2. MAC lockout (Applies to all ports on the switch.)
3. MAC lockdown
4. Port security
5. AuthorizedIP Managers
6. Application features at higher levels in the OSI model, such as SSH.
(The above list does not address the mutually exclusive relationshipthat
exists among some security features.)
1-5

Getting Started
Command SyntaxConventions
Command Syntax Conventions
Thisguide usesthe following conventions for command syntax and displays.
Syntax: aaa port-access authenticator < port-list >
[ control < authorized | auto | unauthorized>]
 Vertical bars ( | ) separate alternative, mutually exclusive elements.
 Square brackets ( [ ] ) indicate optional elements.
 Braces ( < > ) enclose required elements.
 Braces within square brackets ( [ < > ] ) indicate a required element
within an optional choice.
 Boldface indicates use ofa CLI command, part of a CLI command
syntax, or other displayed element in general text. For example:
“Use the copy tftp command to download the key from a TFTP server.”
 Italics indicate variables for which you must supplya value when
executing the command. For example, in this command syntax, you
must provide one or more port numbers:
Syntax: aaa port-access authenticator < port-list >
Simulating Display Output
Command Prompts
In the default configuration, yourswitch’s CLI prompt includes the switch
model number, and appears similar to the following examples:
HP ProCurve Switch 4108#
HP ProCurve Switch 2650#
HP ProCurve Switch 6108#
To simplify recognition, this guide uses HPswitch to represent command
prompts for all models. That is:
HPswitch#
(You can use the hostname command to change the text in the CLI prompt.)
Commands or command output positioned to simulate displays of switch
information in a computer screen are printed in a monospace font, as shown
above.
1-6

Getting Started
PortIdentity Convention for Examples
Screen Simulations
Figures containing simulated screen text and command output appear similar
to this:
Figure 1-1.Exampleof a Figure Showing a Simulated Screen
In some cases, brief command-output sequences appear without figure iden-
tification. For example:
HPswitch(config)# clear public-key
HPswitch(config)# show ip client-public-key
show_client_public_key: cannot stat keyfile
Port Identity Convention for Examples
This guide describes software applicable to both chassis-based and stackable
HP ProCurveswitches. Where port identities are needed in an example, this
guide uses the chassis-based port identity system, such as "A1", "B3 - B5", "C7",
etc. However, unless otherwise noted, such examples apply equally to the
stackable switches, which typically use only numbers, such as "1", "3-5", "15",
etc. for port identities.
Related Publications
Product Notes and General SoftwareUpdate Information. The
printed Read Me First shipped with yourswitch provides software update
information, product notes, and other information. For the latest version, refer
to “Getting Documentation From the Web” on page 1-9.
Physical Installation and Initial Network Access. Use the Installation
and Getting Started Guide shipped with your switch to prepare for and
perform the physical installation. This guide also steps you through connect-
ing the switch to your network and assigning IP addressing, as well as
describing the LED indications for correct operation and trouble analysis. A
1-7

Getting Started
Related Publications
PDF version of this guide is also provided on the Product Documentation CD-
ROM shipped with the switch. And you can download a copy from the HP
ProCurve website. (See “Getting Documentation From the Web” on page 1-9.)
General Switch Management and Configuration. Use the Management
and Configuration Guide for information on:
 Using the command line interface (CLI), Menu interface, and web
browser interface
 Learning the operation and configuration of all switchsoftware
features other than the access security features includedin this guide
 Troubleshooting software operation
HP provides a PDF version of thisguide on the Product Documentation CD-
ROM shipped with the switch. You can also download the latest copy from the
HP ProCurve website. (See“Getting Documentation From the Web” on page
1-9.)
Release Notes. Release notes are posted on the HP ProCurve website and
provide information on new software updates:
 New features and how to configure and use them
 Software management, including downloading software to the switch
 Software fixes addressed in current and previous releases
To view and download a copy of the latest release notes for your switch, see
“Getting Documentation From the Web” on page 1-9.
1-8
