HP OV-UX User manual

HPHub&SwitchManagementfor
OV-UX
User Guide

Hewlett-Packard Company
8000 Foothills Boulevard, m/s 5551
Roseville, California 95747-5551
http://www.hp.com/go/network_city
© Copyright 1998 Hewlett-Packard Company
All Rights Reserved.
This document contains information which is protected by
copyright. Reproduction, adaptation, or translation without
prior permission is prohibited, except as allowed under the
copyright laws.
Publication Number
Edition 1
September 1998
Applicable Product
HP Hub & Switch Management for OV-UX
J3250M
Disclaimer
The information contained in this document is subject to
change without notice.
HEWLETT-PACKARD COMPANY MAKES NO WARANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
Hewlett-Packard assumes no responsibility for the use or
reliability of its software on equipment that is not furnished
by Hewlett-Packard.
Warranty
A copy of the specific warranty terms applicable to your
Hewlett-Packard products and replacement parts can be
obtained from your HP Sales and Service Office or autho-
rized dealer.

i
Contents
1 Information About HP Hub & Switch Management for OV-
UX
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features of HP Hub & Switch Management . . . . . . . . . . . . . . . . . . . . . 1-2
HP Proactive Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Support for New Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Technical Product Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2 Before Installing HP Hub & Switch Management for OV-
UX
Support Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Management Station Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Required Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Required Patches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Before Installing HP Hub & Switch Management . . . . . . . . . . . . . . . . 2-4
Removing HP Hub & Switch Management . . . . . . . . . . . . . . . . . . . . . . . 2-5
3 Introduction to HP Hub & Switch Management
HP Hub & Switch Management Overview . . . . . . . . . . . . . . . . . . . . . . . 3-1
HP OpenView Network Management Platform . . . . . . . . . . . . . . . . . . 3-2
Definitions, Processes, and Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
SNMP Manager and Agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Community Names for Manager and Agent Interaction . . . . . . . . . . . . 3-3
What HP Devices Can Be Managed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
HP ProCurve Family of Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
4 Running HP Hub & Switch Management
Starting the Manager Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

ii
Starting HP OpenView . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Verifying Installation of the Manager Product Set . . . . . . . . . . . . . . 4-3
Stopping and Restarting the Manager Application . . . . . . . . . . . . . . . 4-4
Stopping the Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Restarting the Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
5 Alerts - Find/Fix/Inform
HP Proactive Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Uptime . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Interpreting the Alert Log - Find/Fix/Inform . . . . . . . . . . . . . . . . . . . . 5-3
6 Accessing Hub Features
More Information on Device Features . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Accessing the Device View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Viewing Device Identity Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Interpreting Device Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Reading the Performance Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Status - Global Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Status - Port Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Configuring Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Configuration - Fault Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Configuration - System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Configuring IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Configuration - Backup Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Configuring Load Balancing - Switching Hubs . . . . . . . . . . . . . . . . . . 6-11
Configuration - Support URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
7 Managing Switches
Switch Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Status - Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

iii
Status - Port Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Status - Port Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Identity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Device View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Configuration - Fault Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Configuration - System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Configuration - IP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Configuration - Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Configuration - Assigning a Monitoring Port . . . . . . . . . . . . . . . . . . . . 7-10
Configuration - Device Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Automatic Broadcast Control (ABC) . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Internet Group Management Protocol (IGMP) . . . . . . . . . . . . . . . . . . 7-14
The Spanning Tree Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Configuration - Support/Mgmt URLs . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
8 Setting Up Security for a Device
Device Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Manager/Operator Password Combinations . . . . . . . . . . . . . . . . . . . . . 8-2
The Function of Community Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Port Security (hubs only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Address Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Authorized Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Eavesdrop Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Send Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Disable Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
Set Security Policy for Selected Ports (hubs only) . . . . . . . . . . . . . . 8-7
The Intrusion Log (hubs only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
9 Performing Diagnostics
Performing a Ping/Link Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Rebooting a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Resetting a Hub to Factory Default Settings . . . . . . . . . . . . . . . . . . . . 9-3

iv
Producing a Configuration Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
10 HP Hub & Switch Management Admin
Starting HP Hub & Switch Management Admin . . . . . . . . . . . . . . . . 10-5
HP Admin Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-5
Network Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-6
User Interface Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-7
Graph Options Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-9
Printer Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-10
OpenView Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
11 Management for Non-Browserable Devices
About Closeup Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
Displaying the Closeup View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
Closeup View Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3
Overview of Toolbar Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4
Configuration Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-8
Appendix A
Agent Firmware Versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Verifying Device Agent Versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Preparing Network Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Device Network Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Globally Assigned IP Network Addresses . . . . . . . . . . . . . . . . . . . . . . A-3
Configuring IP Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

1-1
Information About HPHub &
Switch Management for OV-
1
Information About HP Hub & Switch
Management for OV-UX
This chapter includes:
■Introduction
■Features of HP Hub & Switch Management
■Technical Product Support
Introduction
This guidewill help youuse HP Hub& Switch Managementfor basic manage-
ment of HP network devices.
We assume that you are a knowledgeable HP-UX system and network admin-
istrator,andhavesupervisoryaccesstoyournetworksystemanddevices.For
example, you should know the following:
■how to update your HP-UX system with new software
■how to kill processes
■how to write scripts
■how to modify X Window/Motif resources
■how to view, search, and edit files
You should understand the functions and correct operation of your network
devices, such as hubs, bridges, routers, and switches. Your system should be
set up to support the use of the HP OpenView platform and HP Hub & Switch
Management. You should already have the appropriate network software
running and know how to use your network utilities.

1-2
Information About HP Hub & Switch Management for OV-UX
Features of HP Hub & Switch Management
Information About HPHub &
Switch Management for OV-
Features of HP Hub & Switch
Management
This sectionpresents some ofthe featuresthat are included inthis version of
HP Hub & Switch Management.
HP Proactive Networking
HP Proactive Networking offers the combined benefits of outstanding prod-
uctsandeffective,easy-to-usenetworkmanagementthatprovideyouwiththe
control, uptime and performance your network needs.
Control
■Increases visibility into the network by monitoring all segments and
displaying network performance information
■Provides Anywhere Management with an easy-to-use Web browser inter-
face
■Is compatible with other vendor’s products
Uptime
■Finds and fixes common network problems, then informs the network
administrator
■Provides high availability and high performance
• Switch meshing for switching
• Cisco Fast EtherChannel®for servers
■Standards-based products
■Lifetime warranty (for as long as you own the product) and free end-user
telephone support
Performance
■Award winning products
■Large capacity “pipes” (up to 20 Gbps) between switches
■Provides high availability and high performance
• Switch meshing for switching
• Cisco Fast EtherChannel®for servers

1-3
Information About HP Hub & Switch Management for OV-UX
Features of HP Hub & Switch Management
Information About HPHub &
Switch Management for OV-
■Scalable solutions from 10 Mbps to Gigabit Ethernet
■Blocks unwanted traffic with Protocol Filtering
HP Proactive Networking products save time, money and increase produc-
tivity. The agent-enabled, web-based management component of Proactive
NetworkingisembeddedinnewlyintroducedHPmanagedhubsandswitches.
ItconsistsofaJava-basedWebagentandanembeddedwebserver.Inthepast,
if you wanted to see a graphical representation of your network or get device-
specificinformation, youhadtofirstloadmanagement softwareon aspecific
station and then be at that station to view the screens.
You can now use most Web browsers that supports Java and frames. There is
no need to learna new application. Yousee the same interface with the same
look and feel —Java is operating-system independent. You can use a Web
browser on any networked computer, day or night, to configure, control, and
monitornetworkingdevices(managedhubsandswitches),andtoqueryfaults
from any of these devices. You will immediately see the reduced cost of
ownership, since the devices can be managed with minimal effort anytime,
anywhere, and with any platform.
Using your Web browser, you can now perform network management func-
tions for several HP devices.
Note: The device must have an IP address in order to be managed with
a browser. The management station must also have an IP address.
Support for New Switches
Several new switches are supported, as described below.
■HP ProCurve Switch 8000M (J4110A) — a 10/100/Gigabit Ethernet
modularbackboneswitchthatprovidesscalable,highportdensity10/100/
Gigabit switching with HP Proactive Networking. Features include:
• 10/100 auto-sensing ports (up to 80 ports)
• Multiple Gigabit connectivity
• Fast EtherChannel® to servers
• 100Base-FX fiber-optic port connectivity
• Automatic Broadcast Control
•Switchmeshing
■HP ProCurve Switch 1600M (J4120A) — a 10/100/Gigabit server farm
connectivityswitchthatprovides10/100/GigabitswitchingwithHPProac-
tive Networking. Features include:
• Sixteen 10/100 auto-sensing ports optimized for Ethernet

1-4
Information About HP Hub & Switch Management for OV-UX
Technical Product Support
Information About HPHub &
Switch Management for OV-
• An expansion slot for Gigabit connectivity
• Gigabit Fiber Optic port or 8 10/100 auto-sensing ports
• Layer 3 switching
• Fast EtherChannel® to servers
•Switchmeshing
HP ProCurve Switch 4000M (J4121A) — a 10/100/Gigabit Ethernet modular
desktopswitchthat providesscalable/expandable,low-costmigration10/100/
Gigabit switching to the desktop with HP Proactive Networking. Features
include:
• Forty 10/100Base-T desktop switch auto-sensing ports
• Five open slots for additional modules
• Can support up to 80 10/100 auto-sensing ports
HPProCurveSwitch2400M(J4122A)—a10/100desktopswitch,idealforlow-
cost migration to desktop switching.
HPProCurveSwitch212M (J3298A)andHPProCurveSwitch224M(J3299A)
—10Mbpsdesktopswitchesthatprovide12or24portsofdedicatedswitching
tothedesktopwithtwo10/100Mbps“fat”pipesandHPProactiveNetworking.
Technical Product Support
Product support is available on the World Wide Web. The URL is:
http://www.hp.com/go/network_city
Click on Support. The information available at this site includes:
■HP network device MIBs
■HP network device firmware
■HP Hub & Switch Management frequently asked questions
In addition, you can call your HP Authorized Dealer or the nearest HP Sales
and Support Office.

2-1
Before Installing HP Hub &
Switch Management for OV-
2
Before Installing HP Hub & Switch
Management for OV-UX
This chapter includes:
■Support Information
■Management Station Requirements
■Hardware Requirements
■Software Requirements
■Required Network Configuration
■Before Installing HP Hub & Switch Management
■Removing HP Hub & Switch Management
It is assumed that your network devices are properly set up.
Support Information
If you have difficulty installing or using this product, call your HP Authorized
Dealer or the nearest HP Sales and Support Office. You can also obtain
information by accessing the HP World Wide Web pages at the following
URL:
http://www.hp.com/go/network_city

2-2
Before Installing HP Hub & Switch Management for OV-UX
Management Station Requirements
Before Installing HP Hub &
Switch Management for OV-
Management Station Requirements
Hardware
The following table shows the recommendations for HP 9000 hardware.
Software
The following table shows the software that must be installed, configured,
and verified to run properly prior to installing HP Hub & Switch
Management. These prerequisites assume that you are running a single
HP OpenView Windows (ovw) session.
HP 9000 Systems with HP-UX 10.20 or 11.00
Models all (except 705 with Series 700)
Memory
(minimum megabytes) 64 MB*
Disk Space
(minimum megabytes**) 150 MB
Monitor Color with at least 1280 x 1024 resolution
Color planes 8
Mouse Yes
* The larger your IP network or the more HP OpenView Windows (ovw) sessions you run,
the more memory you will need. A good guideline is 10 megabytes for every additional 500
nodes,or25megabytesofmemoryforeveryadditionalovw sessionthatyouexpecttorun.
**Includes HP OpenView Network Node Manager.
HP 9000 Systems
OS version HP-UX 10.20 and 11.00
OS configured swap space
(minimum megabytes) 120 MB*
Type of window software X Window with OSF/Motif/CDE
LAN software LAN/Link for HP 9000 & ARPA Services/9000

2-3
Before Installing HP Hub & Switch Management for OV-UX
Required Network Configuration
Before Installing HP Hub &
Switch Management for OV-
Required Network Configuration
The installation starts the automatic discovery and layout of the network
map, based on your internetwork’s IP addressing scheme. This depends on
the following:
■Correct IP addressing. The IP addresses and subnet masks must be
correctly configured on the manager station, and on all routers and
gatewayhoststhatsupportSNMP.Otherwise,theautomaticallygenerated
mapcouldcontainincorrectnetworkswithnodesfromoutsidetheadmin-
istrative domain.
■Network design that aids isolation of network faults and traffic, by doing
the following:
• Logically subdividing an internetwork into manageable-sized
networks and subnetworks, using routers, gateway hosts and IP
subnet addressing.
• Physically subdividing networks and subnetworks into manageable-
sized segments using hubs, bridges, and gateway hosts. HP recom-
mends that the segments have no more than 200 nodes each.
■SNMP-based, MIB-I (RFC 1156) or MIB-II (RFC 1213) compliant agents
running on management stations, routers, and gateway hosts at a
minimum, and running on bridges and hubs for manageable segments.
This ensures speed and accuracy of map generation.
■All HP 9000 Systems (manager stations orhosts) that are running HP-UX
version 10.20 or HP-UX version 11.00 should also be running the HP
OpenView SNMP Agent software as part of their networking software.
■All managed HP devices should contain a supported version of agent
firmware.
* The more OpenView Windows (ovw) sessions you run, the more OS configured swap
space will be necessary. A good guideline is to configure 25megabytes of swap space for
each additional ovw session that you expect to run.

2-4
Before Installing HP Hub & Switch Management for OV-UX
Required Patches
Before Installing HP Hub &
Switch Management for OV-
Required Patches
The following patches must be installed before installing HP Hub & Switch
Management for OV-UX. Contact your HP Authorized Dealer or the nearest
HP Sales and Support Office, or download the patches from the HP
Electronic Support Center. The URL is:
http://us-support2.external.hp.com
The two patches are:
■For HP-UX 10.20 — PHSS_15043 S700_800 10.x HP aC++ runtime library
components (A.01.15)
■ForHP-UX11.00—S700_80011.00HPaC++runtimelibrarycomponents
(A.03.10)
Before Installing HP Hub & Switch
Management
Before you can begin installing HP Hub & Switch Management, you must
have successfully completed installing your Network Node Manager
product. See the HP OpenView Network Node Manager Products
Installation Guide for instructions on installing the HP Network Node
Manager and obtaining your software license.
You may set up multiple manager stations on your network. Each manager
on which you install the manager product set does its own polling, so the
manager traffic on your network will increase in proportion to the number of
managers.
Note: This applies only if you buy multiple copies. Your license only
entitles you to install one copy.
If you are installing this product set on a workstation with an existing
application, be sure you first exit any ovw sessions currently running, then
stop all HP OpenView processes using the ovstop command (available to
root user).

2-5
Before Installing HP Hub & Switch Management for OV-UX
Removing HP Hub & Switch Management
Before Installing HP Hub &
Switch Management for OV-
Note: It is also a good practice to make a backup of your current
OpenView application (especially your network map) before
proceeding with the installation of new applications.
Installation Directories
The HP Hub & Switch Management product is installed in the following
directories:
• /var/opt/HPASA
• /opt/HPASA
In compliance with the OSF standards, the /opt/HPASA directories hold the
read-only files, which include all the executables, libraries, release notes,
and Device Model Files. The /var/opt/HPASA directories contain the
writeable directories such as product data directories. Be sure you have the
required amount of free disk space before you install the products. You can
make one of the following arrangements for the required space:
• having the required amount of disk space in /opt and /var
• mounting a dedicated volume for /var/opt/HPASA and
/opt/HPASA
•making/var/opt/HPASA and /opt/HPASA symbolic links to a
file system with enough disk space.
The management system must have both manager and agent software
installed.
Make sure the drive that you will be loading from is connected to the
workstation and that your workstation is configured to recognize the CD-
ROM drive.
Consult the README file on the HP Hub & Switch Management CD for
installation procedures.
Removing HP Hub & Switch
Management
If necessary, you can remove products that you installed by using the
command that is appropriate for your operating system. You must be logged
on as root and you must remove them in the reverse order that you installed

2-6
Before Installing HP Hub & Switch Management for OV-UX
Removing HP Hub & Switch Management
Before Installing HP Hub &
Switch Management for OV-
them, that is, remove Hub & Switch Management first, then remove Network
Node Manager and/or the SNMP Management Platform.
Instructions are given here for removing the Hub & Switch Management
product. If you want to remove Network Node Manager, see the HP
OpenView Network Node Manager Products Installation Guide.
To remove products for HP-UX 10.20 or 11.00, use the HP System
Administration Manager.
1. Select Software Management
2. Select Remove Software
3. Select Remove Local Host Software
4. Highlighttheprogramyouwanttoremoveandpicktheappropriateaction
from the Actions menu.
If you used the “install” command to install the software, you can also use
this method for removing it:
1. MounttheHub &SwitchManagement productCDinyourCD-ROMdrive.
2. Type in the command:
./remove
This command will remove the Hub & Switch Management files and its
directories. The swinstall command only removes the program files.
Note: The remove command only works with current Hub & Switch
Management products.

3-1
Introduction to HP Hub &
Switch Management
3
IntroductiontoHPHub&SwitchManagement
This chapter introduces HP Hub & Switch Management and includes the
following topics:
■HP Hub & Switch Management Overview
■HP OpenView Network Management Platform
■Definitions, Processes, and Files
■What Devices Can Be Managed
HPHub&SwitchManagementOverview
HP Hub & Switch Management for OV-UX is a network management
application that allows you to manage and control Hewlett-Packard (HP)
hubs, bridges, and switches on a TCP/IP network. HP Hub & Switch
Management runs on the HP OpenView platform, which allows multivendor
enterprise-wide network management. For communications with managed
devices, Hub & Switch Management uses the Simple Network Management
Protocol (SNMP)—an industry standard network management
communications protocol.
HP Hub & Switch Management is integrated with HP OpenView Network
Node Manager applications.
When using Hub & Switch Management, you can do the following:
■use HP OpenView functions to automatically discover and display the IP
map (and submaps). HP hubs, bridges, and switches that are set up for
SNMP/IP operation will be displayed as appropriate “connector” devices.
■use your Web browser to launch Device Views for Proactive network
management
■manage HP hub and switch security features
■run network tests to troubleshoot network or device problems

3-2
Introduction to HP Hub & Switch Management
HP OpenView Network Management Platform
Introduction to HP Hub &
Switch Management
HP OpenView Network Management
Platform
HP OpenView is a “platform” for network management applications. As a
platform, it allows multiple network management applications that are
OpenView compliant—such as HP Hub & Switch Management—to share
platform functionality and a common display.
Using the HP OpenView, Network Node Manager provides many shared
management functions, which include:
■automatic discovery and mapping of IP networks and objects
■dynamic submap creation
■map navigation Tool Bar
■Quick Navigator
■a map zoom viewer
■device polling to monitor devices on an OpenView map
■an event notification and logging system
■generic SNMP device management
■graphing and logging of traffic
■client/server architecture enabling processes to be run on other worksta-
tions
For more information on HP OpenView platform operation and functions,
refer to the HP OpenView Network Node Manager documentation.
Definitions, Processes, and Files
The basic concepts and processes of management for networks are
described briefly in the following paragraphs.

3-3
Introduction to HP Hub & Switch Management
Definitions, Processes, and Files
Introduction to HP Hub &
Switch Management
SNMP Manager and Agents
HP Hub & Switch Management uses SNMP (Simple Network Management
Protocol) to communicate with managed devices. SNMP commands are
transmitted and received on the network using the Internet Protocol (IP).
The network management station used to run Hub & Switch Management is
referred to as an SNMP manager system. HPdevices with SNMP agents are
called agent systems. Each network management operation requested by
the manager system is executed by one or more agent systems.
The manager system communicates with HP devices to retrieve or modify
management information. The devices contain Network Management SNMP
Agent software to support this communication.
Note: For Hub & Switch Management operation, you must set up HP
network devices for SNMP/IP operation. See Appendix A for more
information.
Community Names for Manager and Agent Interaction
Most SNMP exchanges involve a community name, which can be thought
of as a password for a managed device or group of devices.
Depending on the device, SNMP get requests for information from a device
agent may require the manager to supply a community name that is
configured on the device.
If a password has been specifically configured on a device, then password
authentication is required to perform any SNMP set operations that alter the
configuration or invoke self-test or reset on that device. The manager system
automatically asks you for the password, then puts the encrypted password
in the community name field of subsequent set operations.
Configuring a password on HP devices is recommended but not required. As
described later in this manual, you can use Hub & Switch Management to set
a device password.

3-4
Introduction to HP Hub & Switch Management
What HP Devices Can Be Managed
Introduction to HP Hub &
Switch Management
What HP Devices Can Be Managed
For device management, HP Hub & Switch Management provides a Device
View for most managed HP devices.
Youcan displaya Device View usingyour browser ifthis feature is supported
for the device. The devices that support this feature are noted in the table
below.
Table 3-1. HPDevices That Can be Managed
HP AdvanceStack Family of Hubs andSwitches HP EtherTwist Familyof Hubs and
Bridges
HP J2410A AdvanceStack 100 VG Hub-15Note 1 HP 28688A/B EtherTwist Hub Plus (12 -
port)
HP J2413A AdvanceStack 100VG Hub-7MNote 1 HP 28699A EtherTwist Hub Plus/48
HP J2415A AdvanceStack 100VG Hub-14Note 1 HP J2355A EtherTwist Hub Plus/24S
HP J2600A AdvanceStack 10Base-T Hub-12Note 2 HP 28682A Fiber-Optic Hub Plus
HP J2601A/B AdvanceStack 10Base-T
Hub-24Note 2 HP 28692A ThinLAN Hub Plus
HP J2602A/B AdvanceStack 10Base-T
Hub-48Note 2 HP 28674B Remote Bridge RB
HP J2610A/B 10Base-T Hub-8UNote 3 HP 28673A 10:10 LAN Bridge
HP J2611A/B 10Base-T Hub-16UNote3
HP J2631A 10Base-T Hub-24 (SNMP bundle)Note2
HP J2632A 10Base-T Hub-48 (SNMP bundle)Note2
HP J2980A AdvanceStack 10/100 LAN Switch-16Note4
HP J3100A/B AdvanceStack Switch 2000
HP J3100B is browser-manageable (firmware B.04.xx)
HP J3101A AdvanceStack Switch 2000 Bundle
HP J3125A AdvanceStack Switch 200Note 5
HP J3126A AdvanceStack Switch 100Note 5
