HP AP775A - Nexus Converged Network Switch 5010 Programming manual

HP C-series Nexus 5000 Converged Network
Switch quick start instructions
© Copyright 2009 Hewlett-Packard Development Company, L.P.
First edition: June 2009
The information in this document is subject to change without notice.
www.hp.com
5697-0043
1 Overview
Read these instructions to set up and configure the HP C-series Nexus 5000 Converged Network (CN)
Switch.
For the latest information on the C-series switches, including additional product information, supported SAN
configurations, related documentation, and software and firmware downloads, go to the following HP website
and select the C-series switch product of interest: http://h18006.www1.hp.com/storage/networking/
c_switches/index.html.
For model-specific information or information about supported versions, see the HP Single Point of Connectivity
Knowledge (SPOCK) website: http://www.hp.com/storage/spock.
These instructions provide basic configuration steps. For detailed rack mount and configuration instructions,
download the Cisco Nexus 5000 Series Hardware Installation Guide and Cisco Nexus 5000 Series Switch
CLI Software Configuration Guide from the Storage section of the HP website: http://www.hp.com/support/
manuals.
Table 1 lists the Nexus 5000 CN components and part numbers.
Table 1 Nexus 5000 CN Components and Part Numbers
HP part numberComponent
AP775AHP Nexus 5010 Converged Network Switch
AP776AHP Nexus 5020 Converged Network Switch
AP779AHP Nexus 5000 8-port 4Gb FC Expansion Module
AP778AHP Nexus 5000 4-port 4Gb FC + 4-port 10GbE Expansion Module
AP777AHP Nexus 5000 6-port 10GbE Expansion Module
AP783AHP 10GbE Short Range SFP+ Transceiver
AP784AHP 3m C-series Passive Copper SFP+ Cable
AP785AHP 5m C-series Passive Copper SFP+ Cable
For more information, see the HP Nexus 5000 Converged Network Switch QuickSpecs available at http:/
/h18006.www1.hp.com/storage/saninfrastructure/switches/5000nexus/index.html.
Figure 1 and Figure 2 show sample SAN configurations with Nexus 5000 CN Switches. Figure 3 and Figure
4show the port side of the Nexus 5020 and 5010, respectively; Figure 5 and Figure 6 show the non-port
side of the Nexus 5020 and 5010 respectively. Figure 7 and Figure 8 show the Nexus 5000 expansion
modules.
Figure 1 Sample configuration with Fibre Channel storage fabric attached to Nexus 5000 CN Switch
.
Figure 2 Sample configuration with Nexus 5000 CN Switch in a C-series SAN
.
2. Ethernet connector with two cross-connect ports
on the left side and two network management1 (top)
and management2 (bottom) ports on the right side
1. System status LED
4. Slot 1 with 40 fixed 10-GbE ports3. Console port
6. Slot 3 for an optional expansion module; shown
here with a 4–port FC plus a 4–port 10-GbE expan-
sion module
5. Slot 2 with an optional expansion module
7. AC power connectors
Figure 3 Nexus 5020 port side
.
2. Ethernet connector with two cross-connect ports
on the left side, and two network management1
(top) and management2 (bottom) ports on the right
side
1. System status LED
4. Slot 1 with 20 fixed 10-GbE ports3. Console port
6. AC power connectors5. Slot 2 for an optional expansion module; shown
here with a 4–port FC plus 4–port 10-GbE expan-
sion module
Figure 4 Nexus 5010 port side
.
2. Five fan modules1. Two power supplies
3. System status LED
Figure 5 Nexus 5020 non-port side
.
2. Two fan modules1. Two power supplies
3. System status LED
Figure 6 Nexus 5010 non-port side
.
Figure 7 Nexus 5000 4–port 1/2/4–Gb Fibre Channel + 4–port 10–GbE expansion module
.
Figure 8 Nexus 5000 8–port 1/2/4–Gb Fibre Channel expansion module
.
2 Verify the carton contents
The carton contains the following:
•One Nexus 5020 or Nexus 5010 CN Switch
•Grounding lug kit and electrostatic discharge (ESD) wrist strap
•Power cords
•Rack mount kit
3 Verify the installation requirements
To set up the Nexus 5000 CN Switch for the first time, you will need the following:
•A workstation with an installed terminal emulator (such as HyperTerminal)
•An unused IP address and corresponding subnet mask and gateway address
•A serial cable (supplied with the switch)
•An Ethernet cable
•Access to an FTP server to back up the switch configuration (optional)
•Cisco branded SFP transceivers and compatible cables as specified in the HP Nexus 5000 Converged
Network Switch QuickSpecs, available at http://h18006.www1.hp.com/storage/saninfrastructure/
switches/5000nexus/index.html.
4 Plan the site environment
Air flows through the Nexus 5000 CN Switch from front to back (port- side exhaust). You must maintain
ambient airflow throughout the data center to ensure normal operation. The ambient air temperature must
not exceed 40° C (104° F) and the ambient humidity (relative humidity, noncondensing) must remain between
5% and 95% while the switch is operating.
To install and operate the switch successfully, ensure that:
•The primary AC input is 90-264 VAC, 47-63 Hz.
•The supply circuit, line fusing, and wire size are adequate, as specified by the electrical rating on the
switch nameplate.
For specific power supply information, see the Cisco Nexus 5000 Series Hardware Installation Guide,
available at http://h18006.www1.hp.com/storage/saninfrastructure/switches/5000nexus/index.html.
5 Choose the rack mount
HP strongly recommends installing the switch in one of the following optional HP custom racks:
•HP StorageWorks System/e Rack
•HP StorageWorks 9000 Series Rack
•HP StorageWorks 10000 Series Rack
•HP StorageWorks 10000 G2 Series Rack
Follow these guidelines:
•Ground all equipment in the rack through a reliable branch circuit connection and maintain ground at
all times. Do not rely on a secondary connection to a branch circuit, such as a power strip.
•Ensure that airflow and temperature requirements are being met, especially if the switch is installed in a
closed or multirack assembly.
•Ensure that the additional weight of the switch does not exceed the rack’s weight limits or unbalance the
rack.
•Secure the rack to ensure stability in case of unexpected movement.
For specific temperature and power requirement, see the Cisco Nexus 5000 Series Hardware Installation
Guide, available at http://h18006.www1.hp.com/storage/saninfrastructure/switches/5000nexus/
index.html.
6 Set up a single-switch configuration
To set up a single-switch configuration, you will need the following:
•Fixed IP address (IPv4 or IPv6) for the switch
•Subnet mask value
•Default gateway value
•Host computer with a Converged Network Adapter (CNA) installed for connection to the 10 GbE ports
•FCoE, Ethernet, and Fibre Channel cables
•Disk array with Fibre Channel ports
7 Power on the switch
1. Connect the power cords to both power supplies and to the power sources on separate circuits to protect
against AC failure.
2. Power on the power supplies by flipping both AC switches.
3. After the power-on self test (POST) is complete, verify that the switch power and status LEDs are green.
8 Connect the serial cable
1. Connect the serial cable to the RJ-45 console port on the switch and to a DB9 serial port on the
workstation.
2. Disable any serial communication programs running on the workstation.
3. Open a terminal emulator (such as HyperTerminal on a PC, TERM, TIP, or Kermit in a UNIX environment),
and configure the application as follows:
For most Windows systems:
Bits per second: 9,600
Data bits: 8
Stop bits: 1
Parity: None
For most UNIX systems:
tip /dev/ttyb -9600
If ttyb is already in use, use ttya instead:
tip /dev/ttya -9600
9 Log in to the serial console port
1. Verify that the switch has completed POST.
When POST is complete, the chassis, fan, power supply, and expansion module status LEDs are green.
2. Create an admin password and complete the basic configuration dialog. In the following example,
10.10.10.10 is the management IP address, 255.255.255.0 is the netmask, and 10.10.10.1 is the
gateway.
Enter the password for "admin":
Confirm the password for "admin":
---- Basic System Configuration Dialog ----
This setup utility will guide you through the basic
configuration of the system. Setup configures only
enough connectivity for management of the system.
Please register Cisco Nexus 5020 Family devices
promptly with your supplier. Failure to register
may affect response times for initial service calls.
Nexus devices must be registered to receive entitled
support services.
Press Enter at anytime to skip a dialog. Use ctrl-c at
anytime to skip the remaining dialogs.
Would you like to enter the basic configuration dialog
(yes/no): yes
Create another login account (yes/no) [n]: no
Configure read-only SNMP community string (yes/no)
[n]: no
Configure read-write SNMP community string (yes/no)
[n]: no
Enter the switch name : Nexus5010
Continue with Out-of-band (mgmt0) management
configuration? (yes/no) [y]: yes
Mgmt0 IPv4 address : 10.10.10.10
Mgmt0 IPv4 netmask : 255.255.255.0
Configure the default gateway? (yes/no) [y]: yes
IPv4 address of the default gateway : 10.10.10.1
Enable the telnet service? (yes/no) [y]: yes
Enable the ssh service? (yes/no) [n]: no
Configure the ntp server? (yes/no) [n]: no
Enter basic FC configurations (yes/no) [n]: no
The following configuration will be applied:
switchname Nexus5010
interface mgmt0
ip address 10.10.10.10 255.255.255.0
no shutdown
exit
vrf context management
ip route 0.0.0.0/0 10.10.10.1
exit
telnet server enable
no ssh server enable
Would you like to edit the configuration? (yes/no)
[n]: no
Use this configuration and save it? (yes/no) [y]: yes

10 Connect the devices
1. Attach an ESD wrist strap.
2. Remove the dust cover from the port cage.
3. Insert the transceiver into the port:
• If the transceiver has a Mylar tab, position the transceiver with the tab on the bottom and then gently
insert the transceiver into the port until it clicks into place.
• If the transceiver has a bale clasp, position the transceiver with the clasp on the bottom, close the
clasp by pushing it up over the transceiver, and then gently insert the transceiver into the port until
it clicks into place.
CAUTION:
If you have difficulty inserting the transceiver, ensure that it is positioned correctly and that
the tab or clasp is in the correct position before continuing.
4. Check the LEDs to verify that all components are functioning.
5. Verify correct operation of the switch by entering the show interface transceiver command
from the workstation.
11 Configure IEEE DCB ports for CNA connectivity
To establish CNA connectivity and log in to the C-series Nexus 5000 CN Switch, perform the configuration
steps on the IEEE Data Center Bridging (IEEE DCB) ports as shown in the following example. In this example,
you enable FCoE on a Nexus 5010, create a VLAN200, and bind the Ethernet ports to VSAN2 from an
8-port FC expansion module.
1. Log into the switch:
Nexus 5000 Switch
Nexus5010 login: admin
Password:
Nexus5010#
2. Enable FCoE (disabled by default).
NOTE:
The Nexus 5010 will require a reload.
Nexus5010# configure terminal
Nexus5010(config)# feature fcoe
Nexus5010(config)#
2009 Apr 1 12:05:06 Nexus5010 %$ VDC-1 %$
%PLATFORM-2-FC_LICENSE_DESIRED: FCoE/FC
feature will be enabled after the configuration
is saved followed by a reboot
Nexus5010(config)# exit
Nexus5010# copy running-config startup-config
[########################################] 100%
Packaging and storing to flash: \Packaging and
storing to flash: |Packaging
and storing to flash: /
Nexus5010# reload
WARNING: This command will reboot the system
Do you want to continue? (y/n) [n] y
The system is going down for reboot NOW!
3. Create a new VLAN. By default all ports are in VLAN 1. HP recommends that you use a different VLAN
for FCoE. In this example you create a VLAN 200, allow access to Ethernet ports 1/1 to 1/20, and
create virtual Fibre Channel (VFC) ports 1-20.
Nexus5010# configure terminal
Nexus5010(config)# vlan 200
Nexus5010(config-vlan)# exit
Nexus5010(config)# exit
Nexus5010# show vlan brief
VLAN Name Status Ports
---- --------------- ------- -------------------------
1 default active Eth1/1, Eth1/2, Eth1/3,
Eth1/4, Eth1/5, Eth1/6,
Eth1/7, Eth1/8, Eth1/9,
Eth1/10, Eth1/11, Eth1/12,
Eth1/13, Eth1/14, Eth1/15,
Eth1/16, Eth1/17, Eth1/18,
Eth1/19, Eth1/20
2 VLAN200 active
Nexus5010# configure terminal
Nexus5010(config)# interface ethernet 1/1-20
Nexus5010(config-if-range)# switchport mode trunk
Nexus5010(config-if-range)# switchport trunk allowed vlan 1, 200
Nexus5010(config-if-range)# interface vfc 1-20
Nexus5010(config-if-range)# exit
Nexus5010(config)# exit
4. Create a new VSAN and include the desired Fibre Channel and VFC ports. By default, all ports are in
VSAN 1. HP recommends that you use a different VSAN for SAN connectivity. In this example you
create a VSAN 2 and include Fibre Channel ports 2/1 to 2/8 and VFC ports 1 to 20.
Nexus5010# show vsan membership
vsan 1 interfaces:
fc2/1 fc2/2 fc2/3 fc2/4 fc2/5 fc2/6
fc2/7 fc2/8
vfc1 vfc2 vfc3 vfc4 vfc5 vfc6
vfc7 vfc8
vfc9 vfc10 vfc11 vfc12 vfc13 vfc14
vfc15 vfc16
vfc17 vfc18 vfc19 vfc20
vsan 4094(isolated_vsan) interfaces:
Nexus5010# configure terminal
Nexus5010(config)# vsan database
Nexus5010(config-vsan-db)# vsan 2
Nexus5010(config-vsan-db)# exit
Nexus5010(config)# exit
Nexus5010# show vsan membership
vsan 1 interfaces:
fc2/1 fc2/2 fc2/3 fc2/4 fc2/5 fc2/6
fc2/7 fc2/8
vsan 2 interfaces:
vsan 4094(isolated_vsan) interfaces:
Nexus5010# configure terminal
Nexus5010(config)# vsan database
Nexus5010(config-vsan-db)# vsan 2 interface fc2/1-8
Nexus5010(config-vsan-db)# vsan 2 interface vfc 1-20
Nexus5010(config-vsan-db)# exit
Nexus5010(config)# exit
Nexus5010# show vsan membership
vsan 1 interfaces:
vsan 2 interfaces:
fc2/1 fc2/2 fc2/3 fc2/4 fc2/5 fc2/6
fc2/7 fc2/8
vfc1 vfc2 vfc3 vfc4 vfc5 vfc6
vfc7 vfc8
vfc9 vfc10 vfc11 vfc12 vfc13 vfc14
vfc15 vfc16
vfc17 vfc18 vfc19 vfc20
vsan 4094(isolated_vsan) interfaces:
5. Associate the VLAN with the VSAN. The following example associates VLAN 200 with VSAN 2.
Nexus5010# configure terminal
Nexus5010(config)# vlan 200
Nexus5010(config-vlan)# fcoe vsan 2
Nexus5010(config-vlan)# exit
Nexus5010(config)# exit
Nexus5010# show vlan fcoe
VLAN VSAN Status
-------- -------- --------
200 2 Operational
6. Bind each VFC port to a unique Ethernet port. In this example you create VFC 1 through VFC 8 and
bind each VFC to Ethernet 1/1 through Ethernet 1/8, respectively.
Nexus5010# configure terminal
Nexus5010(config)# interface vfc 1
Nexus5010(config-if)# bind interface ethernet 1/1
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 2
Nexus5010(config-if)# bind interface ethernet 1/2
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 3
Nexus5010(config-if)# bind interface ethernet 1/3
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 4
Nexus5010(config-if)# bind interface ethernet 1/4
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 5
Nexus5010(config-if)# bind interface ethernet 1/5
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 6
Nexus5010(config-if)# bind interface ethernet 1/6
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 7
Nexus5010(config-if)# bind interface ethernet 1/7
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 8
Nexus5010(config-if)# bind interface ethernet 1/8
Nexus5010(config-if)# exit
Nexus5010(config)# interface vfc 1-8
Nexus5010(config-if)# no shutdown
Nexus5010(config-if)# exit
Nexus5010(config)# exit
7. Enable the Fibre Channel ports. In this example you enable FC ports 2/1 through 2/8.
Nexus5010# configure terminal
Nexus5010(config)# interface fc 2/1-8
Nexus5010(config-if)# no shutdown
Nexus5010(config-if)# exit
Nexus5010(config)# exit
8. Save the running configuration to the startup configuration:
Nexus5010# copy running-config startup-config
[########################################] 100%
12 Back up the configuration
As a best practice, copy the running configuration to a remote server after making configuration changes.
In this example you save the running-configuration to an FTP site.
Nexus5010# copy running-config ftp://10.10.20.1/backup.txt
Enter vrf (If no input,
default vrf is considered): management
Enter username: [
username ]
Password: [
password ]
***** Transfer of file Completed Successfully *****
Nexus5010#
