HP ElitePad 1000 G2 Installation instructions

Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP ElitePad 1000 G2
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
Mother board
1
Batteries
All types including standard alkaline and lithium coin
or button style batteries battery and RTC battery
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps LCD
1
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Power cords,Adapter
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
EL-MF877-00 Page 1
Template Revision A

2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1 screw driver
Philip #0
Description #2 service fixture
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove bumper ring sub assy.
2. Remove Battery cable,EDP FPC & T/S FPC
3. Remove Powe Board assy, Audio Board Assy and Power FPC
4. Remove Battery Pack
5. Remove Remove Docking support bracket
6. Remove Speaker module
7. Remove WWAN module & GPS module
8. Remove WLAN module
9. Remove MB Assy
10. Remove WLAN Antenna & WWAN Main/Aux Antenna
11. divide Power Board assy (remove 1st Mic,8M camera ,Volume board)
12. divide MB assy (remove Docking FPC, 2nd Mic, 2M CAMERA)
13.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Step 1 Remove bumper ring sub assy Step2 Remove Battery cable, EDP FPC & TS FPC
EL-MF877-00 Page 2
Template Revision A

Step3 Remove Power Board Assy, Audio Board Assy and Power FPC Step4 Remove Battery Pack
Step5 Remove Docking support bracket Step6 Speaker module
EL-MF877-00 Page 3
Template Revision A

Step7 Remove WWAN module & GPS module Step8 Remove WLAN Module
Step9 Remove MB Assy Step10 Remove WLAN Antenna & WWAN Main/Aux Antenna
EL-MF877-00 Page 4
Template Revision A

Step11 divide Power Board assy (remove 1st Mic,8M camera ,Volume board)
Step12 divide MB assy (remove Docking FPC, 2nd Mic, 2M CAMERA)
EL-MF877-00 Page 5
