The HP StoreEver MSL Tape Libraries meet demanding storage requirement of businesses needing unattended backup, disaster
recovery, or archive capability. The MSL Libraries offer a broad choice of storage capacity and interfaces with LTO-6, LTO-5, LTO-4, or
LTO-3 Ultrium tape drives. Web-based remote management makes the MSL Libraries easily managed from across the room or across
the globe, eliminating the need for remote office IT staff. Quickly and simply manage the tape media both in and out of the library with
the standard bar code reader, configurable mail slots, and multiple 12-slot removable magazines. If a tape were lost or stolen, protect
important business data from unauthorized access with the library-based encryption option. Library investment and uncertain data
growth are easily managed with MSL accessory kits. Quickly increase capacity and/or performance with tool-free drive upgrades, slot
license capacity upgrades, or library expandability. Now with TapeAssure to monitor drive and media utilization, monitor operational
performance, report life and health information as well as provide notifications of drive and tape parameters that fall below HP
recommended standards
HP StoreEver MSL2024 Tape Library
HP StoreEver MSL4048 Tape Library
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Overview
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 1

HP StoreEver MSL8048/8096 Tape Library
What's New
LTO-6 Ultrium 6250 half-height SAS and FC tape drives and LTO-6 Ultrium 6250 tape media are now available in the MSL tape
library family, improving performance by 44% and more than doubling the storage capacity of the MSL Libraries.
Key Features Exceptional storage density from 4.8 TB (2024) up to 600 TB of compressed capacity (2.5:1) in 8096
Achieve up to 900 TB of storage capacity with the MSL Library Extender Kit
Easy-to-use web-based remote management
Integrated bar code reader
Tool-free tape drive upgrades
Customer upgradeable redundant power supply in the MSL 4048, 8048, or 8096 libraries.
Multiple interface choices available (FC, SAS, or SCSI)
Removable magazines with user-configurable mail slots
Easy-to-enable AES 256-bit embedded hardware encryption with compression
Extensive OS and software compatibility testing
Proven high reliability
Proactive drive and media health and operational performance reporting with TapeAssure.
Achieve the highest level of encryption security to secure confidential business information while
meeting compliance guidelines with the HP 1/8 G2 & MSL Encryption Kit.
Proactively monitor utilization, operational performance, and overall life and health of the drives
and media with TapeAssure.
Leverage library investment to upgrade to higher performance and capacity points using the MSL
Library Extender.
Grow library capacity without adding additional hardware with the MSL8048 slot license upgrade
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Overview
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 2

option. Quick, easy, and affordable capacity growth.
Family Comparison MSL2024 MSL4048 MSL8048/8096
Drive Technology LTO-6 Ultrium 6250
LTO-5 Ultrium 3280
LTO-5 Ultrium 3000
LTO-4 Ultrium 1840
LTO-4 Ultrium 1760
LTO-3 Ultrium 920
LTO-6 Ultrium 6250
LTO-5 Ultrium 3280
LTO-5 Ultrium 3000
LTO-4 Ultrium 1840
LTO-4 Ultrium 1760
LTO-3 Ultrium 920
LTO-6 Ultrium 6250
LTO-5 Ultrium 3280
LTO-5 Ultrium 3000
LTO-4 Ultrium 1840
LTO-4 Ultrium 1760
Maximum Number of Drives 1 (Ultrium 3280, 1840)
2 (Ultrium 6250, 3000, 1760,
920)
2 (Ultrium 3280, 1840)
4 (Ultrium 6250, 3000, 1760,
920)
4
(Ultrium 6250, 3280, 3000,
1840, 1760)
Maximum Capacity
(2.5:1 compression)
150 TB (LTO-6) 300 TB (LTO-6) 600 TB (LTO-6, 96 slots)
300 TB (LTO-6, 48 slots)
Maximum Capacity
(2:1 compression)
72 TB (LTO-5)
38.4 TB (LTO-4)
19.2 TB (LTO-3)
144 TB (LTO-5)
76.8 TB (LTO-4)
38.4 TB (LTO-3)
288 TB (LTO-5, 96 slots)
153.6 TB (LTO-4, 96 slots)
76.8 TB (LTO-3, 96 slots)
144 TB (LTO-5, 48 slots)
76.8 TB (LTO-4, 48 slots)
38.4 TB (LTO-3, 48 slots
Maximum Data Transfer
(2.5:1 compression)
1.4 TB/hr (one 6250) 1.4 TB/hr (one 6250)
2.8 TB/h4 (two 6250)
2.8 TB/hr (two 6250)
4.8 TB/hr (four 6250)
Maximum Data Transfer
(2:1 compression)
1 TB/hr (one 3280/3000)
864 GB/hr (one 1840)
576 GB/hr (one 1760)
864 GB/hr (two 920
1.0 TB/hr (one 3280)
2.0 TB/hr (two 3000)
864 GB/hr (one 1840)
1.7 TB/hr (two 1840)
1.1 TB/hr (two 1760)
432 GB/hr (one 920)
864 GB/hr (two 920)
2.0 TB/hr (two 3280/3000)
4.0 TB/hr (four 3280/3000)
1.7 TB/hr (two 1840)
3.4 TB/hr (four 1840)
1.1 TB/hr (two 1760)
Drive Interface 8 Gb Native Fibre Channel
(LTO 6, 5)
4 Gb Native Fibre Channel
(LTO 6, 5, 4, 3)
6 Gb/sec SAS (LTO 6, 5)
3 Gb/sec SAS (LTO 6, 5, 4, 3)
Ultra320 LVD SCSI (LTO 4, 3)
8 Gb Native Fibre Channel
(LTO 6, 5)
4 Gb Native Fibre Channel
(LTO 6, 5, 4, 3)
6 Gb/sec SAS (LTO 6, 5)
3 Gb/sec SAS (LTO 6, 5, 4, 3)
Ultra320 LVD SCSI (LTO 4, 3)
8 Gb Native Fibre Channel
(LTO 6, 5)
4 Gb Native Fibre Channel
(LTO 6, 5, 4, 3)
6 Gb/sec SAS (LTO 6, 5)
3 Gb/sec SAS (LTO 6, 5, 4, 3)
Ultra320 LVD SCSI (LTO 4, 3)
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Overview
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 3

Manageability The MSL Tape Libraries come with web-based remote manageability so they can be easily monitored and
managed from across the room or across the globe. Functions included in the management tool include:
Status information on the drive and system
System configuration operations and reporting
System error and status logs
Library and drive firmware upgrade capabilities
Diagnostic tests and information
Cartridge movement for maintenance and management purposes
Cleaning cartridge support
Security and access control
SNMP support for IP communication
Partitioning and Encryption management
HTTPS capable
IPv6 and IPv4 network protocol support
TapeAssure HP TapeAssure makes managing, optimizing and archiving on the HP MSL 2024, 4040, 8048 or 8096
libraries faster and easier. TapeAssure provides comprehensive summaries and detailed information about
the status, performance, utilization, and health of all tape drives and tapes for HP MSL libraries.
TapeAssure utilization and performance reporting features allow you to optimize the use of your existing
HP MSL tape libraries to make informed purchasing decisions if an increase in capacity is needed. With
TapeAssure data you can:
Modify backup schedules to make best use of the drives and tapes available and evenly distribute
their workload
Predict and prevent failures through early warnings and recommended service actions
Determine if each drive and each tape is experiencing a high (or low) rate of usage
Know when to retire tapes
Find out the compression ratios actually achieved
TapeAssure health reports and alerts give you peace of mind knowing the condition of the drives, the
tapes and the data on each tape. TapeAssure monitors every backup to ensure the highest standards of
reliability, sends alerts when these standards are not met, and ensures that you can maintain the drives
and tapes used in an archive environment to have the highest integrity.
TapeAssure builds a database of drive and tape history information that you can export as .CSV (comma-
separated-value) files and import into Excel or other tools to create pivot-charts, pie charts and bar charts
for graphical presentation or further analysis. This data can be automatically exported on a schedule or on
demand and written to a local or network drive where analysis scripts can also be run.
TapeAssure real time alerts notify instantly if drive and data quality standards are not being achieved:
In-depth analysis pinpoints if drive, tape or data characteristics fall below HP backup and archiving
standards
View alerts and statistics is real-time in the Command View TL GUI
NOTE: an alert does not imply that a failure has occurred as HP backup and archiving standards are very
high. This allows you to treat many of the alerts as predictive and to follow up on the recommended
service actions at a time that is least disruptive.
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 4

Easy Installation The MSL Tape Libraries are shipped as a rack-ready unit. The rack mount hardware included with the
library allows installation in a variety of HP racks. For more information on the HP rack offerings, please
see the following URL: http://h18004.ww1.hp.com/products/servers/platforms/rackandpower.html
Ease of use with LTFS and
HP StoreOpen
LTFS and HP StoreOpen provide a self-describing file system on a HP LTO cartridge, which enables the
combined archiving benefits of application independence, transportability, and protection from
obsolescence.
Partitioning The MSL Tape Libraries now include the ability to be configured as a partitioned library. Most MSL Libraries
may be configured with up to one partition per drive; four partitions if four drives are installed. Partitioning
allows each partitioned library to be presented to the host as an independent library, separate from other
partitions in the library. Hosts for each partition own independent sets of media and can use ISV software
that is different from the other partitions allowing maximum flexibility and utilization of the MSL library.
NOTE: The MSL 8048 can only be partitioned into a maximum of two partitions, while the MSL8096 can be
partitioned into four partitions.
Proven Reliability With a rating of 2,000,000 robot load/unload cycles, the MSL Tape Libraries provides necessary high
reliability for today's demanding environment. To improve reliability and longevity, all HP Ultrium
products feature Data Rate Matching (DRM). This allows the tape drive to dynamically and continuously
adjust the speed of the drive, to match the speed of the host or network. This increases performance,
reduces mechanical wear on the tape drive and extends tape life.
Longevity Organizations need to be confident that their data in archive is still there when they need it. LTO tape
media is specified with a 30 year shelf life in normal ambient conditions.
Disaster Recovery and
Security
Removable media also has the advantage that data is held 'offline' which means that archive data on tape
has the additional level of protection from the threats to on-line data from viruses, hackers and cyber-
attacks. LTO-6 Ultrium tape drives include hardware based data encryption to prevent unauthorized
access to data at rest and cartridges are available with write-once-read-many (WORM) capability to
prevent accidental overwriting of data archived on the tape. Both WORM and hardware data encryption
features help organizations to comply with increased data security regulations
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 5

Data Encryption The HP 1/8 G2 & MSL Encryption Kit provides a library-enabled encryption solution providing data
privacy, confidentiality, and integrity of your critical business data while supporting compliance
requirements. The HP 1/8 G2 & MSL Encryption Kit is an easy and affordable library-enabled encryption
solution for small businesses.
Protect the confidentiality and integrity of your data :
The encryption kit includes two USB key server tokens, product documentation, and firmware support.
One encryption kit is needed per library or autoloader. One USB key server token is installed in the USB
port of the library to enable encryption. The token must remain in the tape library or tape autoloader
while encryption is enabled. The USB key server token generates and stores keys for the LTO-6, LTO-5
or LTO-4 Ultrium drives. The USB key server token uses a hardware random number generator, a
cryptographic module running on FIPS 140-2 Level 3 validated hardware, password authentication, and
digital envelopes for strong encryption keys and security operations. A second USB key server token is
provided in the kit to be used as a backup token which can be stored in a secure location. The keys are
transferred securely token-to-token for backup or export, with no exposure to insecure PCs, servers, or
networks. An option is also provided to save the token contents to a secure file. You may now also save
the most recently added keys on the token to a file to enable you to seed new tokens with keys from
other tokens. The encryption kit provides a self-contained solution for MSL libraries with no additional
software, PCs, or servers required or involved.
Protect IT resources and meet compliance requirements :
With the HP 1/8 G2 & MSL Encryption Kit, users can enable or disable encryption, configure and manage
the USB key server tokens, restore encrypted data, as well as a variety of other tasks. In addition, the
LTO-6, LTO-5 and LTO-4 Ultrium tape drives use the Advanced Encryption Standard (AES) with the
longest and most secure keys -- 256 bits. AES-256 encryption is implemented using the Galois Counter
Mode (GCM). This method adds Message Authentication Codes to ensure the integrity as well as privacy
of the backup data stored on tape. The HPLTO-6, LTO-5 and LTO-4 Ultrium Tape Drives are designed to
be compliant with the standard for tape media security (IEEE 1619.1).
Slot license upgrade Leverage the MSL8048 library investment to address both current and future data requirements with the
MSL 48 to 96 slot license upgrade option. Using all the same features of the MSL8096, the MSL8048 will
ship with 96 slots physically installed but only 48 are usable, until you decide you need more. As your data
grows, simply enable the remaining 48 slots with a slot license upgrade.
The MSL8048 will ship with the four left 12-slot magazines enabled and ready for use, including 3 mail
slots. Once additional slots are needed, the library will need the MSL 48 to 96 slot license upgrade (product
# TA739A) to quickly and easily double capacity from 48 to 96 slots. The slot license upgrade entitlement
certificate will direct you to the HP Webware site for access to your license key. Insert the license key into
the library GUI interface and the remaining four right 12-slot magazines, with additional mail slot
capability, will now be enabled for use. No reconfiguring a rack or installing new hardware. In addition,
once all 96 slots have been enabled, additional capacity and performance can be added using the MSL
Library Extender. The HP MSL8048 makes capacity growth easy, quick, and affordable.
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 6

Library Extender Leverage the investment in your MSL Library, now or in the future, to increase both capacity and
performance as data needs change. The HP MSL Library Extender Kit can be used to connect two MSL
libraries to create one larger, logical library. The stacked libraries appear to the host as a single library. The
Extender Kit can be used with MSL2024, 4048, or 8096 libraries and is compatible with both new and
currently installed libraries. The Extender Kit is customer installable in under 60 minutes.
The Library Extender occupies the lowest half-height drive bay in the top library and the upper half-height
drive bay of the lower library. No additional external power or communication cabling is necessary. The
upper Library (MSL4048 or MSL8096) controls the extended library. Any drive in the extended library may
host the library interface. Only the operator control panel (OCP), USB port, and Ethernet connection of the
upper library are used in the extended mode.
The Library Extender Kit does not support combining two MSL2024 or two MSL8096 libraries. The Extended
Library will not support partitioning.
Possible configurations include:
Extended Library Configurations Slot Numbers (without mail slots enabled)
Lower Library Master Library Lower Library Master Library
MSL2024 MSL4048 1-24 25-72
MSL4048 MSL4048 1-48 49-96
MSL2024 MSL8096 * 1-24 25-120
MSL4048 MSL8096 * 1-48 49-144
*In configurations with an 8U library, the 8U must always be the top library
NOTE: An MSL8048 must have all 96 slots enabled before using the Library Extender. Once all 96 slots are
usable, configurations are the same as the MSL8096.
Serviceability Modular in design, the MSL Tape Libraries has easily replaceable components minimizing the Mean-Time-
to-Repair on the unit. Replaceable components include the tape drive, the magazines, the power supply
and the controller board. HP Library and Tape Tools (L&TT) provides easy access to the MSL error log,
generates support tickets, and enables firmware downloads. L&TT can be downloaded for free at:
http://www.hp.com/support/tapetools .
LTO Ultrium Technology HP LTO (Linear Tape Open) Ultrium Tape Drives use best of breed technology. By taking the best features
from other tape technologies and combining them into a single new technology, Ultrium tape drives are in
a league of their own. Inclusion of innovative features such as Adaptive Tape Speed (ATS) ensure that
Ultrium drives can meet the performance and reliability demands of a library environment. LTO technology
is an open industry standard format; thus data written on HP Ultrium Tape Drives can be interchanged
directly with Ultrium Tape Drives from other vendors.
Investment protection HP LTO tape drives and automation products are founded on the LTO open standard and adhere to the
published LTO format roadmap to generation 8 at 32TB of compressed capacity per cartridge by
Generation 8. With in-built two generation backwards compatibility, LTO customers can be assured of
investment protection.
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 7

Data Rate Matching Data Rate Matching combines sophisticated buffer management with HP's exclusive variable Adaptive
Tape Speed technology, to allow the tape drive to match its transfer rate to the host speed dynamically
and continuously across the wide range of transfer rates. This feature ensures that the tape drive
continues to stream data regardless of the environment, and brings two big advantages:
It optimizes backup performance and maximizes overall efficiency allowing the drive to respond
immediately to any speed changes from the host
It minimizes rewinding and repositioning of the tape, significantly reducing physical wear and
increasing reliability
It minimizes the power requirements for the drive by reducing the number of repositions needed
LTO Ultrium Tape Drive ATS data transfer rate range (native)
HP LTO-6 Ultrium 6250 54 to 160 MB/s
HP LTO-5 Ultrium 3280/3000 47 to 140 MB/s
HP LTO-4 Ultrium 1840 40 to 120 MB/s
HP LTO-4 Ultrium 1760 35 to 80 MB/s
HP LTO-3 Ultrium 920 26 to 60 MB/s
HP Ultrium WORM Critical to the success of data retention policies in highly regulated environments is the ability to store and
manage data in an unalterable state. Following stringent guidelines set forth by regulatory agencies such
as the SEC and HIPPA, IT organizations must now integrate new solutions and policies that can verify the
integrity of stored data for periods that can extend well beyond seven years.
The LTO-6, LTO-5, LTO-4 Ultrium and LTO-3 Ultrium tape drives features the ability to archive and store
data in a non-rewriteable format that meets the most stringent regulatory guidelines. Using a combination
of integrated fail-safe features in the drive firmware, cartridge memory, and tape formatting, the tape
drives can archive large amounts of data for periods of up to 30 years in a secure, untampered state. Since
all LTO-6, LTO-5, LTO-4 and LTO-3 Ultrium tape drives include support for both rewritable and WORM
media, IT organizations can now easily integrate a secure, long-term archiving solution into their current
data protection strategy. As compared to other technologies that feature support for WORM storage, the
tape drives offer the advantages of:
A single drive to support all backup and archiving needs
Two distinctive tape cartridges to easily distinguish and manage both rewriteable and WORM data
cartridges
A specially designed WORM data cartridge with multiple integrated fail-safe features to prevent
accidental or intentional overwriting of data
High-capacity, low-cost HP WORM media that can store up to 6.25 TB (2.5:1 compression) of data on
a single data cartridge
Support from many backup and archiving software vendors, providing the most comprehensive and
mainstream support in the industry
The LTO open standard that offers greater choice and compatibility across all third- and fourth-
generation Ultrium products
NOTE: While all HP LTO-6, LTO-5, LTO-4, and LTO-3 Ultrium tape drives support LTO Ultrium WORM media,
some LTO Ultrium tape drives from other manufacturers may not include read and write support for LTO
Ultrium WORM media. For non-HP LTO Ultrium tape drives, please check the manufacturers' specifications
to ensure this support is provided if you are using your WORM media. If WORM support is not provided, the
drive will eject the WORM tape cartridge immediately upon insertion into to the tape drive
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 8

Included backup and
recovery software
The MSL2024 and MSL4048 tape libraries include the option to download Barracuda's (BN) Yosemite
Server Backup Basic software free-of-cost . It is an easy-to-use backup and recovery application that is
installed in minutes and includes all the features needed to protect a single machine by backup to a HP
tape product. Yosemite Server Backup Basic software includes pre-defined and customizable media
rotation schemes so you can define when you backup and how long your backups are retained, while easily
managing your data cartridges. Using the included software you can easily backup a single Windows or
Linux to a single drive MSL tape library.
For more information please visit: www.barracudaware.com/ysbbasic
HP Data Protector
software
HP Data Protector software automates high performance backup and recovery, from disk or tape, over
unlimited distances, to enable 24x7 business continuity and improve IT resource utilization. Data Protector
software responds to the pressure for lower IT costs and greater operational efficiency by offering
acquisition and deployment costs which are 30 - 70 % less than competition. The license model is very
simple and easy to understand, helping to reduce complexity. Extensive scalability and features for
continuous backup and recovery operations enable growth with a single product. A superb solution, no
other software can integrate better with the HP market-leading line of disk and tape family of products, as
well as with other heterogeneous storage infrastructures. As an integral component of the fast-growing
HP software portfolio, which includes storage resource management, archiving, replication, and device
management software, Data Protector software also fully integrates with the HP management solutions,
allowing managing data protection as an essential element of an overall IT service. This solution offers the
unique advantage of being able to source hardware, software, and award winning service offerings from a
single, trusted source.
Data Protector software simplifies the use of complex backup and recovery procedures with the fastest
installation, automated routine tasks, and easy-to-use features. The centralized multi-site management
easily allows implementing multi-site changes, adapting in real time to changing business requirements.
Appropriate for medium and large companies in any industry, Data Protector software is the ideal solution
to reduce IT costs and complexity while remaining reliable and scalable to grow from single server
environments to the largest distributed enterprise infrastructures.
If you are using HP Data Protector software with your MSL8048 or MSL8096 tape library, a FREE 61-250
slot License-to-Use entitlement certificate is included in the box.
For further information, please visit our web page at: http://www.hp.com/go/dataprotector
Linear Tape File System
(LTFS)
HP LTFS makes tape self-describing, file-based, and easy-to-use, it also provides users with the ability to
use standard file operations on tape media for accessing, managing and sharing files with an interface that
behaves just like a hard disk. In addition, LTFS provides the ability to share data across platforms, as you
would with a USB drive or memory stick. Simply load a tape into the drive, mount it into the file system,
and it becomes visible as a disk. For more information, including user guide, downloads and compatibility,
visit: http://www.hp.com/go/ltfs
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 9

HP StoreOpen
Automation
HP StoreOpen Automation is a free downloadable application that extends the LTFS capability to HP
Autoloaders, HP MSL and ESL Tape Libraries. By simply mounting the tape autoloader or library as a file
system, the intuitive HP StoreOpen Automation interface makes it easier to copy, rename, create or move
files. When a cartridge folder is selected for use, that tape is automatically moved to an available tape
drive.
When two drives are present, HP StoreOpen Automation supports tape-to-tape operations. HP StoreOpen
Automation takes advantage of other standard HP Tape Library features including data encryption and HP
TapeAssure.
For more information, including user guide, downloads and compatibility, visit:
http://www.hp.com/go/HPStoreOpen
HP Library and Tape Tools The MSL Tape Libraries are supported on HP's industry-leading diagnostic tool - HP Library and Tape Tools
(L&TT). L&TT is a single, convenient program that is easy to install and simple to operate. L&TT's intuitive
user interface eliminates the need for training and deploys in less than five minutes. This robust diagnostic
tool is designed for both the experienced professional and the untrained administrator. It ensures product
integrity through self-diagnostics and fast resolution to device concerns. Additional information on L&TT
plus download information can be found at: http://www.hp.com/support/tapetools .
HP Storage Media HP recommends that you use HP-branded cartridges in the MSL Tape Libraries to assure the highest level
of protection for your valuable data. The test program for HP media is the most thorough and
comprehensive in the industry.
All HP cartridges must satisfy an exhaustive battery of additional tests that relate directly to real life
situations, where real data and real businesses are at stake. The benefit of the HP brand specification for
media is consistent quality. Through the testing of thousands of HP drives and HP cartridges, the ideal
formulation for backup performance is defined and then continuously monitored. This hugely resource-
intensive process is unique to HP and affords deep insight into the HP+HP backup solution for a wide range
of environments and duty cycles. Your best choice for ease of support and maximum dependability is to
use HP-branded Ultrium cartridges at all times.
HP strongly encourages the use of bar code labels on tapes to track media and ensure optimum library
performance and usability. Correctly labeling your media will allow the library to quickly determine media
and drive compatibility.
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 10

Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed. Customization must comply with all relevant product specifications and
factory supported configurations. Factory Express offers service packages for simple configuration,
racking, installation, complex configuration and design services as well as individual factory services, such
as image loading, asset tagging, and custom packaging. HP products supported through Factory Express
include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP
BladeSystem, and HP 9000 servers as well as MSA, VA7xxx, EVA, and XP disk arrays, rackable tape libraries
and configurable network switches.
Type of service support varies by platform and product family. For more information on Factory Express
services for your specific server model or storage device please contact your sales representative or go to:
http://www.hp.com/go/factory-express .
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Product Highlights
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 11

HP's extensive compatibility testing program assures that your HP MSL Tape Libraries work with leading servers, operating systems,
and backup applications - and not just those sold by HP. The MSL libraries work seamlessly in many environments, making them
especially suitable if you have a mixed system environment. For the latest list of servers, workstations, operating systems, and
backup software that support the MSL tape libraries, check the HP Enterprise Backup Solution compatibility matrix at:
http://www.hp.com/go/ebs .
Server Compatibility The MSL Tape Library is supported on a wide range of HP systems. For details of which MSL Libraries work
with which systems, including third-party systems, reference the EBS compatibility matrix at:
http://www.hp.com/go/ebs for the latest hardware compatibility information.
OS Support Reference the EBS compatibility matrix for the most up-to-date OS compatibility information at:
http://www.hp.com/go/ebs .
Software Support Reference the EBS compatibility matrix for the most up-to-date software compatibility information at:
http://www.hp.com/go/ebs .
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Compatibility
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 12

Warranty MSL2024: The warranty for this product consists of 1-year parts exchange, next business day
MSL4048: The warranty for this product consists of 1-year parts exchange, next business day
MSL8048: The warranty for this product consists of 1-year onsite, next business day.
MSL8096: The warranty for this product consists of 1-year onsite, next business day.
NOTE: The HP MSL Tape Libraries warranty includes support for Customer Self Repair (CSR). The tape
library cartridges, terminators, external cables, drives, magazines, controller board and power supplies
are mandatory customer self repair parts. This means both the removal and replacement of the above
parts are designed for easy replacement; the on-site warranty does not extend to these parts. However,
customers may request HP Services to replace these replaceable units (RUs) for an additional charge. Also,
customers who purchase an HP Support Agreement have the option to perform CSR or receive onsite
support.
Please refer to HP's Limited Warranty Statement for further details:
http://h18006.www1.hp.com/products/storageworks/warranty.html
For increased uptime, productivity and ROI -HP Care Pack packaged services for Storage
These days, you need to get the most out of your storage investment-you can't afford not to. When you buy HP storage products and
solutions, it's also a good time to think about what levels of service and support you may need. To help take the worry out of
deploying, designing, maintaining, and managing your environment, we've designed a portfolio of service options that are as: flexible,
reliable and scalable as your storage. Unlike storage-only vendors, we take a holistic approach to your entire environment, bridging
storage, servers, blades, software and network infrastructures with our HP Care Pack packaged services for Storage.
Protect your business beyond the warranty
When it comes to robustness and reliability, standard warranties on today's computing equipment have matured just as the
technologies have matured. Good news on some fronts-but also a source of potential problems and subsequent consequences that
come from depending on standard warranties alone. Standard warranty protects against product defects and some causes of
downtime- but not the business. By using a standard approach to warranty uplifts, such as HP Care Pack Services, you can reduce
downtime risks and be more certain of operational consistency for both mission-critical and standard business computing. Simply put,
HP Care Pack Services normalize the warranty of combined products - helping you proactively guard against unplanned downtime.
Extending warranties with HP Care Pack Services
For cost-effective upgrading or extending your standard warranty, HP Care Pack Services offer a suite of standard reactive hardware
and software support services that are sold separately, or combined as with our Support Plus and Support Plus 24 services. The
portfolio also provides a combination of proactive and reactive services, such as Proactive 24 Service and Critical Service. In addition,
with HP Proactive Select we offer an innovative approach to service delivery that gives you the flexibility to acquire the specific
proactive services you need today, then add services as your needs evolve. HP Proactive Select offers a broad set of technical or per-
event type service options - including server, storage, and network, SAN device, and software, environment, installation and education
services. Services that you can mix and match depending on your specific requirements, from preliminary planning and equipment
delivery to installation, configuration, integration, and testing, through every level of ongoing support. Our HP Care Pack packaged
services for Storage assures help when you need it most. And for many products, post-warranty HP Care Pack Services are available
when your original warranty has expired.
HP Storage Services: Offering reliability, flexibility and value-just like your storage
HP Storage Services offers a full spectrum of customer care, from technology support to complex migrations to complete completely
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Service and Support, HP Care Pack and Warranty Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 13

managed services. HP Factory Express provides customization, integration and deployment services for turnkey solutions. HP
Education offers flexible, comprehensive training on storage networking, disk storage systems, and storage software to help your IT
staff get the most out of your investments. And HP Financial solutions extend innovative financing and asset management programs
to cost-effective buy, manage and eventually retire your older equipment.
HP Storage Services, the trusted business technology experts who manage your technology in action, because when technology
works, business works. http://www.hp.com/services/storage
NOTE: Care Pack Services availability may vary by product and country.
HP Care Pack Services are sold by HP and HP Authorized Service Partners:
Services for customers purchasing from HP or an enterprise reseller are quoted using HP order configuration tools.
Customers purchasing from a commercial reseller can find HP Care Pack Services at
http://www.hp.com/go/lookuptool
Recommended Services 3-Year HP Support Plus 24
For a higher return on your storage investment, HP Support Plus 24 provides integrated hardware and
software support services designed specifically for your technology. Available 24x7, this 3-year combined
reactive support option delivers onsite hardware support and over-the-phone software support around-
the-clock. Leverage the full strength of HP Technology Services - customers can trust the services
professionals at HP to work collaboratively with them, putting our strategic and technical know-how to
work across their entire infrastructure.
Improve uptime with responsive hardware and software services
Enjoy consistent service coverage across geographically dispersed sites
Update HP software at a predictable cost
Increase customer satisfaction-with no interoperability gaps
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6638EN.pdf
HP ESL, MSL Tape Libraries Installation and Startup
Deployment of your HP Midrange Storage Library (MSL) products in SAN environments, including the
installation of a Fibre Channel Interface Controller.
System installation and setup by an HP technical specialist
Verification prior to installation that all service prerequisites are met
Delivery of the service at a mutually scheduled convenient time
Provides product installation according to the product specifications
Offers deployment activities that are designed to bring the Fibre Channel-based tape library into
operation
Helps improve performance
Makes the most of the value of the HP ESL, MSL, and EML libraries in an IT environment by
leveraging HP knowledge in implementing Fibre Channel-based systems and solutions
Helps reduce implementation-related disruptions in the IT environment
Helps increase system reliability and provides more effective data management
http://h20195.www2.hp.com/v2/GetPDF.aspx/5981-7355EN.pdf
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Service and Support, HP Care Pack and Warranty Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 14

HP Backup and Recovery Solution Service
Rapid recovery from system downtime can hinge on the efficiency of your backup and recovery
management environment - and on how well that environment is integrated with your storage
infrastructure. But integration processes can be time-consuming and complex, and your IT resources are
already stretched thin. Where can you find the expert help you need?
For fast, effective integration of your backup solution into an existing or new storage infrastructure, turn
to the storage experts at HP Services. Our Backup and Recovery Solution Service (BRSS) provides end-to-
end management of your backup integration process. The BRSS team works with you to analyze your
business and IT environment; develop a comprehensive integration plan and timetable; design an
architecture that suits your critical requirements; install backup software; implement your solution; and
validate your configuration.
By engaging HP to implement HP Data Protector, customers' IT staff can stay focused on their core
tasks and priorities, resulting in less impact to your business
Professional backup and recovery planning that aligns with customer's business needs and
implementation that reduces project execution time and risk to the storage environment
HP's expertise with backup and recovery helps ensure issues are avoided
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-7442EN.pdf
Optional Services 5-Year HP Support Plus 24
As an alternative to our recommended support level, for customers who need to improve uptime with
responsive 24x7 product support:
HP Support Plus 24 helps you increase performance and availability with comprehensive, consistent
hardware and software services. Working with your IT team, HP Services engineers deliver onsite
hardware support and over-the-phone software support around-the-clock 365 days per year. Service
coverage encompasses HP products and selected multivendor hardware and software.
In addition, this convenient HP Care Pack packaged service makes software updates available to you at
substantial savings.
Choose Support Plus 24 when you need to:
Improve uptime with responsive hardware and software services available anytime
Cost-effectively obtain expert 24x7 multivendor hardware and software support
Enjoy consistent service coverage across geographically dispersed sites
Update HP and selected third-party software at a predictable cost
Take advantage of subscription savings on software updates
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6638EN.pdf
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Service and Support, HP Care Pack and Warranty Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 15

eSupport HP eSupport is a portfolio of technology-based services that assist you with managing your business
environment - from the desktop to the data center.
Support Portal
The HP support portal provides one-stop access to the information, tools and services you need to
manage the daily operations of your IT environment.
Features include:
Access to self-solve tools (including search technical knowledge base)
Efficient logging and tracking of support cases
Collaboration with other business and IT professionals
Download of patches and drivers
Access to diagnostic tools
Proactive notification of relevant information
Access to certain features of the support portal requires an HP service agreement. To access the support
portal, visit: http://www.hp.com/support
Customer Technical
Training
Consider education as an integral part of your strategy to get the best return on investment for your HP
storage solution. HP offers a variety of training courses on storage software, networking, archiving and
disk storage systems. Our classes are available in many delivery modalities from traditional instructor-led
courses at one of our 80 training centers worldwide to on-site training customized to your needs or online.
www.hp.com/learn/storage
HP Services Awards HP Services continues to be recognized for service and support excellence by customers, partners,
industry organizations and publications around the world. Recent honors and award reflect our services
team's dedications, technical expertise, professionalism and uncompromising commitment to customer
satisfaction. For a list of all our awards, please visit:
http://h20219.www2.hp.com/services/cache/433028-0-0-225-121.htm
Additional Services
Information
For more information about HP Care Pack Services for Storage, please visit:
http://www.hp.com/services/storage
If you have specific questions, contact your local HP representative. Contact information for a
representative in your area can be found at "Contact HP" http://www.hp.com
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Service and Support, HP Care Pack and Warranty Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 16

Step 1 - Base Configuration
HP StoreEver MSL2024
Tape Library
MSL2024 Model Description Part Number
HP MSL2024 1 LTO-6 Ultrium 6250 SAS Tape Library C0H20A
HP MSL2024 2 LTO-6 Ultrium 6250 SAS Tape Library C0H21A
HP MSL2024 1 LTO-6 Ultrium 6250 FC Tape Library C0H22A
HP MSL2024 1 LTO-5 Ultrium 3280 FC Tape Library BL531B
HP MSL2024 1 LTO-5 Ultrium 3000 SAS Tape Library BL537B
HP MSL2024 1 LTO-5 Ultrium 3000 FC Tape Library BL542B
HP MSL2024 1 LTO-4 Ultrium 1840 FC Tape Library AJ034B
HP MSL2024 1 LTO-4 Ultrium 1760 SAS Tape Library AK378B
HP MSL2024 1 LTO-4 Ultrium 1760 SCSI Tape Library AJ817B
HP MSL2024 0-Drive Tape Library AK379A
*All SKUs meet the new RoHS requirements required 1 Jan 2013
NOTE: The HP MSL2024 Tape Library comes standard with either one or two drives and
a 24-slot library which is shipped rack-ready; a racking kit is included in the box. The HP
MSL2024 Tape Libraries no longer ship standard US Power Cord (C13, 10A, 1.83m, P/N
AF556A) that allow connection to 110V US wall outlets in a home or office. HP MSL2024
Tape Libraries are primarily connected to PDU's in data center racks so they now ship
with only a PDU power cord (C13/C14, 10A, P/N 142257-002). If a user wishes to power
a HP MSL2024 Tape Library using a 110V receptacle the US Power Cord (P/N AF556A)
must be ordered separately. If customers require a power cord, they can check the
power cord matrix for the appropriate cord. Please see the UPS and PDU cable matrix's
on the Power Protection page under Power Cords that lists cable descriptions,
requirements, and specifications for UPS and PDU units at the new HP Power Cord Link
@ HP.com. Use the following new link: www.hp.com/products/powercords
Kit Contents (for each library):
Zero-drive Model :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
SCSI Models :
One 2.5M PDU Power Cord, C13/C14, 10A
One 6 ft VHDCI to HDTS68 SCSI cable per tape drive
One HDTS68 SCSI terminator per SCSI tape drive
One RJ-45 Ethernet cable
Rack-mount hardware
SAS Model :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
Fibre Channel Models :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
HP StoreEver MSL4048
Tape Library
MSL4048 Model Description Part Number
HP MSL4048 2 LTO-6 Ultrium 6250 FC Tape Library C0H24A
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Configuration Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 17

HP MSL4048 2 LTO-6 Ultrium 6250 SAS Tape Library C0H23A
HP MSL4048 1 LTO-5 Ultrium 3280 FC Tape Library BL532B
HP MSL4048 2 LTO-5 Ultrium 3000 SAS Tape Library BL538B
HP MSL4048 2 LTO-5 Ultrium 3000 FC Tape Library BL543B
HP MSL4048 1 LTO-4 Ultrium 1840 FC Tape Library AJ036B
HP MSL4048 2 LTO-4 Ultrium 1840 FC Tape Library AJ038B
HP MSL4048 2 LTO-4 Ultrium 1760 SAS Tape Library AK380B
HP MSL4048 0-Drive Tape Library AK381A
*All SKUs meet the new RoHS requirements required 1 Jan 2013
NOTE: The HP MSL4048 Tape Library comes standard with either one or two drives, and
a 48-slot library which is shipped rack-ready; a racking kit is included in the box. The HP
MSL4048 Tape Libraries no longer ship standard US Power Cord (C13, 10A, 1.83m, P/N
AF556A) that allow connection to 110V US wall outlets in a home or office. HP MSL4048
Tape Libraries are primarily connected to PDU's in data center racks so they now ship
with only a PDU power cord (C13/C14, 10A, P/N 142257-002). If a user wishes to power
a HP MSL4048 Tape Library using a 110V receptacle the US Power Cord (P/N AF556A)
must be ordered separately. If customers require a power cord, they can check the
power cord matrix for the appropriate cord. Please see the UPS and PDU cable matrix's
on the Power Protection page under Power Cords that lists cable descriptions,
requirements, and specifications for UPS and PDU units at the new HP Power Cord Link
@ HP.com. Use the following new link: www.hp.com/products/powercords
Kit Contents (for each library):
Zero-drive Model :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
SAS Model :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
Backup and recovery software for Windows/Linux/NetWare
Fibre Channel Models :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
Backup and recovery software for Windows/Linux/NetWare
HP StoreEver MSL8048
Tape Library
MSL8048 Model Description Part Number
HP MSL8048 0-drive Tape Library
NOTE: The HP MSL8048 Tape Library comes with zero drives, and 48 of the 96 physical
slot enabled for use. To upgrade from 48 to 96 slots, the 48 to 96 slot upgrade license
must be purchased (TA739A). Drive kits must be ordered separately
NOTE: The MSL8048 is shipped rack-ready; a racking kit is included in the box. The HP
MSL8048 Tape Libraries no longer ship standard US Power Cord (C13, 10A, 1.83m, P/N
AF556A) that allow connection to 110V US wall outlets in a home or office. HP MSL8048
Tape Libraries are primarily connected to PDU's in data center racks so they now ship
with only a PDU power cord (C13/C14, 10A, P/N 142257-002). If a user wishes to power
a HP MSL8048 Tape Library using a 110V receptacle the US Power Cord (P/N AF556A)
must be ordered separately. If customers require a power cord, they can check the
AU300A
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Configuration Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 18

power cord matrix for the appropriate cord. Please see the UPS and PDU cable matrix's
on the Power Protection page under Power Cords that lists cable descriptions,
requirements, and specifications for UPS and PDU units at the new HP Power Cord Link
@ HP.com. Use the following new link: www.hp.com/products/powercords
HP MSL8048 Tape Library 48-96 Slot Upgrade LTU
NOTE: For use with MSL8048 to upgrade from 48 to 96 slots using a license key.
All 96 slots must be enabled prior to using the MSL Library Extender Kit.
TA739A
MSL8048 Kit Contents :
Zero-drive Model :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
HP Data Protector software 61-250 slot License-to-Use entitlement
certificate. Warranty for 61-250 slot LTU will need to be purchased
separately
HP StoreEver MSL8096
Tape Library
MSL8096 Model Description Part Number
HP MSL8096 2 LTO-6 Ultrium 6250 SAS Tape Library C0H25A
HP MSL8096 2 LTO-6 Ultrium 6250 FC Tape Library C0H26A
HP MSL8096 2 LTO-5 Ultrium 3280 FC Tape Library BL533B
HP MSL8096 4 LTO-5 Ultrium 3280 FC Tape Library BL534B
HP MSL8096 2 LTO-5 Ultrium 3000 SAS Tape Library BL539B
HP MSL8096 2 LTO-4 Ultrium 1840 FC Tape Library AJ040B
HP MSL8096 4 LTO-4 Ultrium 1840 FC Tape Library AN974B
*All SKUs meet the new RoHS requirements required 1 Jan 2013
NOTE: The HP MSL8096 Tape Library comes standard with either two or four drives, and
a 96-slot library which is shipped rack-ready; a racking kit is included in the box. The HP
MSL8096 Tape Libraries no longer ship standard US Power Cord (C13, 10A, 1.83m, P/N
AF556A) that allow connection to 110V US wall outlets in a home or office. HP MSL8096
Tape Libraries are primarily connected to PDU's in data center racks so they now ship
with only a PDU power cord (C13/C14, 10A, P/N 142257-002). If a user wishes to power
a HP MSL8096 Tape Library using a 110V receptacle the US Power Cord (P/N AF556A)
must be ordered separately. If customers require a power cord, they can check the
power cord matrix for the appropriate cord. Please see the UPS and PDU cable matrix's
on the Power Protection page under Power Cords that lists cable descriptions,
requirements, and specifications for UPS and PDU units at the new HP Power Cord Link
@ HP.com. Use the following new link: www.hp.com/products/powercords
Kit Contents (for each library):
SCSI Models :
One 2.5M PDU Power Cord, C13/C14, 10A
One 6 ft VHDCI to HDTS68 SCSI cable per SCSI tape drive
One HDTS68 SCSI terminator per SCSI tape drive
One RJ-45 Ethernet cable
Rack-mount hardware
HP Data Protector software 61-250 slot License-to-Use entitlement
certificate. Warranty for 61-250 slot LTU will need to be purchased
separately
SAS Model :
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Configuration Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 19

One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
HP Data Protector software 61-250 slot License-to-Use entitlement
certificate. Warranty for 61-250 slot LTU will need to be purchased
separately
Fibre Channel Models :
One 2.5M PDU Power Cord, C13/C14, 10A
One RJ-45 Ethernet cable
Rack-mount hardware
HP Data Protector software 61-250 slot License-to-Use entitlement
certificate. Warranty for 61-250 slot LTU will need to be purchased
separately
Step 2 - Additional Options
Select each option as required with quantities specified:
Quantity Description Part Number
1 each Power Cord, C13, 10A, 1.83m
NOTE: This cord does not ship standard with MSL Tape Library.
AF556A
1 each PDU Power Cord, C13/C14, 10A, 2.5m
NOTE: This cord ships standard with each MSL Tape Library; can be
used to connect the rack-mounted device to PDUs with IEC-320
receptacles.
142257-002
WARNING: This product can ONLY be used with an HP approved power cord for your specific geographic
region. Use of a non-HP approved power cord may result in: 1) not meeting individual country specific
safety requirements; 2) insufficient conductor amperage that could result in overheating with potential
personal injury and/or property damage; and 3) an unapproved power cord could fracture resulting in the
internal contacts being exposed, which potentially could subject the user to a shock hazard. HP disclaims
all liability in the event a non-HP approved power cord is used.
Regional Power Cords 1 each Power Cord, Euro, C13, 10A, 1.83m AF568A
1 each Power Cord, UK, C13, 10A, 1.83m AF570A
1 each Power Cord, Danish, C13, 10A, 1.83m AF566A
1 each Power Cord, Swiss, C13, 10A, 1.83m AF565A
1 each Power Cord, Italian, C13, 10A, 1.83m AF571A
1 each Power Cord, South Africa, C13, 10A, 2.5m AF567A
1 each Power Cord, Taiwan, C13, 12A, 1.83m AF561A
1 each Power Cord, China, C13, 10A, 1.83m AF557A
1 each Power Cord, Japan, C13, 12A, 2.0m AF572A
1 each Power Cord, Australia, C13, 10A, 2.5m AF569A
1 each Power Cord, Argentina, C13, 10A, 2.5m AF558A
1 each Power Cord, Brazil, C13, 10A, 1.83m AF559A
1 each Power Cord, Korea, C13, 10A, 1.83m AF560A
1 each Power Cord, Israel, C13, 10A, 1.83m AF564A
1 each Power Cord, India, C13, 10A, 2.0m AF562A
NOTE: One power cord is required; please select the correct power cord for your geographical location.
QuickSpecs
HP StoreEver MSL2024/MSL4048/MSL8048/MSL8096
Tape Libraries
Configuration Information
DA - 13258 Worldwide — Version 36 — January 18, 2013 Page 20
