HPM Forta User manual

Read all the instructions before installation. This instruction manual is to
be left at the installation site. These Floodlights must only be connected to
a 230V-240Va.c. 50Hz supply by a licensed electrician.
Where to mount your flood light:
1. Installation is to be made in dry weather conditions.
2. Choose a wall mount position that is in a sheltered location (e.g under
the eaves of the house). A mounting height of greater than 2m
is recommended.
3. Do not operate in close proximity to combustible materials or
substances affected by heating or drying. Keep a minimum distance
of 0.5m from adjacent objects.
Installation:
Installing a wall switch adjacent to the power source is recommended.
1. Remove mounting bracket from the fitting and use to mark position on
the wall/ceiling.
2. Mount the bracket on the wall/ceiling. Ensure the method of fixing can
support up to a 10kg weight.
3. Reattach fitting to the bracket.* Do not tighten bolts completely
to allow for mains wiring termination.
* Ensure that cord gland faces downwards in the final mounting
position (as shown in Fig.1)
4. Choose rubber-sheathed 3-core circular cord, H05RN-F 3G 1mm2
(not supplied) for the mains wiring.
5. Remove junction box cover, strip insulation from cord and insert in to
cord gland. Wire up as shown in Fig 2.
6. Replace junction box and tighten screws to ensure a weatherproof
seal. Tighten gland
7. Orient fitting to desired position and tighten bolts completely.
Instruction Manual
Forta LED Floodlight
Cat. Nos. LFL0110WBL, LFL0120WBL, LFL0130WBL, LFL0140WBL
Fig 1
1 Lamp Cover Screw
2 Terminal Block
3 Junction Box Cover Screws (x 4pcs)
4 Wall Mounting Bracket Screws (x 2pcs)
5 Wall Mounting Bracket
6 Gland
7 Power Cable (not provided)
Blue wire to Neutral N
N
L
L
Green-yellow to earth
Brown wire to switch
White wire to light
Green-yellow to light
White wire to light
Fig 2
1
3
4
7
65
2
FORTA
LFL0130WBL

05/15
LE08110AAA
Warranty
HPM Legrand warrants this product for a period of 3 years from the
date of purchase.
These goods come with guarantees that cannot be excluded under
the Australian and New Zealand Consumer Laws. You are entitled to a
replacement or a refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired if the goods fail to be acceptable quality and
the failure does not amount to a major failure.
See the Warranty card enclosed with this product for further details.
Customer Service
For all Customer Service and Technical Support
please call Monday to Friday during business hours.
HPM Legrand Australia
1300 369 777
www.hpm.com.au
HPM Legrand New Zealand
0800 476 009
www.hpm.co.nz
ABN: 31 000 102 661
Specifications:
Cat No
LFL0110WBL LFL0120WBL LFL0130WBL LFL0140WBL
Supply
voltage 230-240V a.c 50Hz
Input power 11W 23W 32W 43W
Lumen output 730lm 1615lm 2250lm 3000lm
Colour
temperature Cool White 4000K Nominal
Mounting
height >2m (recommended)
Protection
class Class I
IP rating IP44
Dimensions: 115 x 87
x 130mm
180 x 140
x 135mm
228 x 188
x 175mm
228 x 188
x 175mm
Weight (excl.
packaging): 0.6kg 0.9kg 1.5kg 1.6kg
Power cord
requirement: H05RN-F 3G 1mm2
Disclaimers
1. This product must be installed and used as per these instructions.
2. An IP rating of IP44 is generally considered suitable for external walls
with supplementary protection such as overhanging eaves.
3. This product contains no serviceable parts and no attempt should be
made to repair this product. If the product is faulty it should be discarded.
4. This product has been designed to operate in ambient temperatures:
-10°C to 40°C.
5. This product is not suitable for installation in hazardous and/or
corrosive areas.
6. The material in this product may vary in colour from batch to batch.
Colour matching from one batch to another cannot be guaranteed.
7. This product utilises intellectual property in the form of registered
designs, trademarks, and/or patents. Such intellectual property remains
the property of HPM Legrand in all cases.
8. HPM Legrand reserves the right to modify the specification of this
product at any time.
