HQST 100W Monocrystalline Solar Suitcase
User Manual

2
Product Features
1. Plug and play system with 9ft length alligator clips cable
2. Highly efficient monocrystalline panels in aluminum protective casing
3. Includes traveling case
4. Included HQST 10A controller for 12V and 24V systems
5. An upgraded 3-stage PWM charging algorithm is adopted. Application of an equalizing charging to the battery periodically or when
over discharged, can effectively prevent the battery from non-equalization and sulfating, thus extending the battery's service life.
6. With temperature compensation employed, charging parameters can be automatically adjusted.
7. A wide range of load working modes facilitate the product's application to different types of load.
8. The product provides overcharge, over-discharge, overload protection, as well as short-circuit protection.
9. By virtue of an advanced load starting method, large-capacitance loads can be started smoothly.
10.The product provides a dot matrix graphic LCD screen and a human-machine interface with a key.
11.The user-friendly design of browser and dynamic interfaces ensure convenient and intuitive operations.
12.Boasting an industrial grade design, the product can function well in various tough conditions.
13.TVS lighting protection is adopted.
Controller Structure

3
Solar Panel Structure
Installation Instructions and Precautions
1.Unfold panel and lock butterfly washer when tilt angle desired
Tilt Stand
Handle
Aluminum Frame

4
2. Controller Operation Instructions
a) Step 2: Connect the battery. If the connection is correct, the controller screen lights up; otherwise, check whether the
connection is correct.
b) Step 3: Connect the solar panel. If sunlight is present and strong enough (the solar panel voltage is greater than battery
voltage), the sun icon on the LCD screen is on; otherwise, check whether the connection is correct.
c) Step 4: Connect the load. Connect the load leads to the controller's load output terminal, and the current shall not exceed
the controller's rated current.
3.As the controller generates heat during operation, it is recommended that the controller be installed in
an environment with good ventilation conditions.
4.Choose cables with large enough capacity for connection, in case too much loss incurred on the lines
causes the controller to misjudge.
5.The controller has a common positive pole inside. If grounding is needed, ground the positive pole.
6.It's important to fully charge the battery regularly. At least once full charging every month is
recommended, and failure to do that may cause permanent damage to the battery. Only when in-flow
energy outpaces out-flow energy can the battery be charged fully. Users shall bear this in mind when
configuring the system.
7.Check whether the controller's each connection terminal is tightened securely; if not, it may suffer
damage when there is excessive current.
State Indicators
LCD Icon
Indicated Object
State
Daytime or
charging
Steady on
Night recognition
Steady off
Load short circuit or
overload
Quick flashing
Load switched on
Steady on
Load switched off
Steady off
Normal battery
All on
Over discharge
Only the outline
flashes
Overvoltage
3 dashes
flashing

5
Browsing Menu on LCD Screen
The following menus are shown in an automatic cycle on the screen, with an interval of 3s.
Setting Menu on LCD Screen
Long press the key in any mode to enter the load mode setting interface, and the load mode begins to flash. Short press the key
to adjust the load mode, and long press the key again to save and exit mode setting or wait for 10s to let the system save and exit
automatically.
Five load Working Modes
1. Pure light control (0): When sunlight disappears and the light intensity drops to the starting point, the controller initiates a one-minute
delay (settable) to confirm the starting signal, and then switches on the load for operation. When sunlight emerges and the light intensity
reaches the starting point, the controller initiates a one-minute delay to confirm the shutting-down signal, and then shuts down the
output to stop the load's operation.
Load mode
Long press
the key
Mode flashing
Mode flashing
Load mode
Long press the key to
save the setting
Short press the key
Set the needed mode

6
2. Light control + time control (1 to 14): The starting process is the same as pure light control. After operating for a preset period of
time (settable from 1 to 14 hours), the load stops operation automatically.
3. Manual mode (15): In this mode, the user can switch the load on or off by the key, no matter whether it's day or night.
4. Debugging mode (16): In cases of 6V with light signals, the load will be shut off. In cases of 5V (varies according to the preset light
controlled voltage and system voltage) without light signals, the load will be switched on. This mode enables fast check of the
correctness of system installation during installation and debugging.
5. Normal on (17): The energized load keeps in output state.
LED Display
Mode
00
Pure light control mode
01-14
Light control + time control (1 to 14 hours)
15
Manual mode（default）
16
Debugging mode
17
Normal on mode
Manually Switching On/Off Load
When the load mode is set to 15 (manual mode), short press the key (non-setting mode) in any interface to switch on or off the
load.
Note: As load start is a type of soft start, display of the load icon on the LCD screen will be delayed after the load is switched on.
Overload and Short Circuit Recovery
Overload and short circuit automatic recovery time: 5s at the 1st time; 10s at the 2nd time; 25s at the 3rd time; 30s at the 4th time; 30s at
the 5th time, or automatic recovery the next day.
Load switched on
Load switched off
Short press the key

7
Error Code List
Code on LCD screen
Corresponding error
E0
No error
E1
battery over-discharging
E2
battery overvoltage
E4
Load short circuit
E5
Overload
E6
Controller inner temperature over heat
Common Problems and Solutions
Symptoms
Causes and Solutions
LCD screen does not light up.
Check whether the battery is correctly connected.
Incomplete display or no renewal on LCD screen
Check whether the ambient temperature is too low and whether
the display recovers when the temperature rises.
No charging with sunlight present
Check whether the solar panel is correctly connected, and
contact is good and reliable.
Check whether the solar panel voltage falls below the battery
voltage.
The battery icon flashes quickly, and there is no output.
System overvoltage. Check whether the battery voltage is too
high.
The battery icon flashes slowly, and there is no output.
The battery is over-discharged, and will recover after recharged
adequately.
The load icon flashes quickly, and there is no output.
The load's power exceeds the rated value or the load is short-
circuited. After the problem is solved, long press the key or wait
until it recovers automatically.
Other symptoms
Check whether wiring is sound and reliable, and system voltage
is correctly recognized.
Solar Panel Technical Data Sheet
Standard Testing Conditions (STC): 1000W/m2, T = 25°C, AM = 1.5
Max Power at STC
100 W
Open circuit voltage (Voc)
21.6 V
Optimum operating voltage (Vmp)
18.0 V
Optimum operating current (Imp)
2x2.78 A
Short circuit current (Isc)
2x3.08 A
Cell Type
Monocrystalline
Number of Cells
36 per panel (3 x 12 arrangement)
Max system voltage
600VDC (UL)
Max series fuse rating
15 A
Fire rating
Class C
Weight
27.05 lbs.
Dimensions Unfolded (l x h x w)
39.8 x 27.2 x 1.5 in
Dimensions Folded (l x h x w)
19.9 x 27.2 x 2.8 in

8
Charge Controller Technical Data Sheet
Rated current
10A
current display function
No
System voltage
Automatic recognition of 12 V/ 24 V
No-load loss
< 10mA/12V；< 12mA/24V
Max. Solar energy input voltage
<55V
Max. voltage
at the battery end
<35V
Overvoltage protection
17.0V；×2/24V；
Equalizing charging
voltage
14.6V；×2/24V；
Boost charging voltage
14.4V；×2/24V；
Floating charging voltage
13.8V；×2/24V；
Charging recovery voltage
13.2V；×2/24V；
Over-discharge recovery voltage
12.6V；×2/24V；
Over-discharge voltage
11.1V；×2/24V；
Equalizing charging interval
30days
Equalizing charging time
1H
Boost charging time
2H
Temperature
compensation
-3.0mV/℃/2V
Light control voltage
Light control on 5V, ×2/24V；
light control off 6V, ×2/24V；
Light control
judgment time
1minute
Operating temperature
-25℃to +55℃；
IP protection degree
IP30
Net weight
3.5 oz.
Protection functions
Solar panel short circuit and reverse-connection
protection
Over-temperature, overload and short circuit protection
Dimensions (l x h x w)
4.1 ×2.8 × 1.4 in
