HRT SC-DV-2 User manual

DVI -to -VGA Video Scaler
Converts Digital DVI to Analog VGA or HDTV Component Output
With programmable output Resolution !
December 8, 2005
H
Ha al ll l R Re es se ea ar rc ch h T Te ec ch hn no ol lo og gi ie es s, , I In nc c. .
Order toll-free in the U.S. 800-959-6439
FREE technical support, Call 714-641-6607 or fax [phone]
Mail order: Hall Research Technologies, 1163 Warner Ave., Tustin, CA 92780
Web site: www.hallresearch.com • E-mail: info@ hallresearch.com
CUSTOMER
SUPPORT
INFORMATION
UMA1061 Rev. n/c

DVI
-
to
-
VGA Video Scaler
1
TRADEMARKS USED IN THIS MANUAL
Hall Research, HRT, and (logo) are trademarks of Hall Research
Technologies, Inc. IBM is a registered trademark of International Business
Machines Corporation.
Any other trademarks mentioned in this manual are acknowledged to be the
property of the trademark owners.
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment generates, uses, and can radiate radio frequency energy and
if not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication.
It has been designed to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part 15 of FCC
rules, which are intended to provide reasonable protection against such
interference when the equipment is operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause
interference, in which case the user at his or her own expense will be
required to take whatever measures may be necessary to correct the
interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

Model SC
-
DV
-
2
2
Contents
1. Introduction ...............................................................................page 3
1.1 General ...................................................................................page 3
1.2 Features ..................................................................................page 4
2. Installation .................................................................................page 4
2.1 Input Connection ...................................................................page 4
2.2 Output connection ..................................................................page 4
2.3 Connection Block Diagrams ..................................................page 5
3. Configuration and Operation......................................................page 6
3.1 Front and Rear Panels ............................................................page 6
3.2 Menus and Adjustments .........................................................page 6
4. Troubleshooting.........................................................................page 8
Contacting Hall Research Technologies.....................................page 8
Shipping & Packaging................................................................page 8
5. Specifications.............................................................................page 9
Hall Research Technologies, Inc.
Home of the Mini-Cat® !

DVI
-
to
-
VGA Video Scaler
3
1. Introduction
1.1 General
SC-DV-2 is a high performance PC/HDTV
scaler that accepts Digital DVI input and
converts it to analog RGB output (PC VGA or
HDTV Component).
The input resolution is automatically detected
while the output resolution and refresh rate
can be selected through OSD menu and front panel push buttons.
The SC-DV-2 Video Processor combines the functions of a video scaler,
scan-converter, and format transformer and is packed into a compact and
durable metal housing with easy-to-use touch buttons.
The controls include input/output setup picture adjustment, H/V phase
adjustment, System information and many other advance options.
The SC-DV-2 allows you to specify a resolution and refresh rate for it's
output. Then it will output a steady (uninterrupted) VGA signal to your
display device at the specified rate regardless of the input. This effectively
allows any DVI switch, such as HRT's SW-DVI-2A or SW-DVI-4A, to
become a seamless switch. The output timing is constant regardless of what
is happening at the input. So when you switch from one input to another, the
display device does not see any interruption in the signal coming to it.

Model SC
-
DV
-
2
4
1.2 Features
•Converts Digital DVI from any PC (or digital output from DVD player)
to analog VGA or component output.
•Ideal for use with high-resolution displays such as LCD, plasma, or DLP
projectors.
•The resolution of any PC or HDTV video signal can be scaled up or
scaled down to any other PC or HDTV resolution. It can also change the
frame rate of the output.
•50 MB Video memory for real-time frame rate conversion.
•Signal format conversion between RGBHV and YPbPr.
•Input: PC(VGA/SVGA/XGA/SXGA) + HDTV(480i 576i 480p 567p
720p 1080i), @ 60 to 85 Hz
•Output: PC(VGA/SVGA/XGA/SXGA) + HDTV(480p/576p/720p/1080i)
•Automatically detects input mode and timing parameters
•Easy-to-use push buttons and OSD menu control.
2. Installation
2.1 Input connection:
The SC-DV-2 can accept both PC and HDTV input in digital DVI format.
Use the DVI-to-DVI cable to connect the DVI output of a PC or HDTV
device to the DVI input connector of the SC-DV-2.
The SC-DV-2 can automatically detect the mode and resolution of the DVI
input.
2.2 Output connection:
The SC-DV-2 can output a variety of PC and HDTV resolutions in analog
RGBHV (or YPbPr) formats.
When one of the PC resolutions is selected as output, use a 15-pin D-Sub
VGA cable to connect the PC/HDTV output of the SC-DV-2 to the VGA
input of a display monitor.

DVI
-
to
-
VGA Video Scaler
5
When one of the HDTV resolutions is selected as output. use a 15-pin D-
Sub to YPbPr/3 RCA adaptor cable to connect the PC/HDTV output of the
SC-DV-2 to the YPbPr input of a HDTV device.
2.3 Connection Block Diagrams
In the above diagrams the output of the SC-DV-2 connects to the VGA
monitor via a HD15 Cable and to the HDTV via a HD15 to 3 RCA cable.
Note that the SC-DV-2 is not HDCP compliant. HDCP refers to digital
content protection of some high-resolution DVD players or Satellite
receivers. Depending on the brand of the equipment, if you are playing a
high-resolution HDCP encoded video through the SC-DV-2, you may not
get a picture, or the output of the DVD player may emerge at a lower
resolution!

Model SC
-
DV
-
2
6
3. Configuration & Operation
3.1 Front and Rear Panels
3.2 Menus and Adjustments
Pressing the Menu button will bring up the OSD menu controls on the
screen as follows:
ØInput set up
ØOutput set up
ØPicture Adjust
ØHV Adjust
ØOSD Adjust
ØSystem Information
ØAuto Adjust
ØExit
Use +,or -to move the arrow cursor to your desired selection, then press
MENU to confirm your selection and enter into sub menu.
I
In np pu ut t s se et t u up p - -When it is selected, a sub menu for selecting
YPbPr/RGB as below will appear..
YPBPR … üRGB
The SC-DV-2 automatically detects and shows the input format as YPbPr or
RGB. However, you can manually select the YPbPr or RGB to match the
format of your input. Selecting a format that doesn't coincide with your
input will result in an abnormal picture.
O
Ou ut tp pu ut t s se et t u up p - -When it is selected, a sub-menu appears, that allows
you to set the Output Mode (refresh-rate and resolution).

DVI
-
to
-
VGA Video Scaler
7
Output Modes
PC Resolutions HDTV Resolutions
VGA 640 X 480@60/72/75/85Hz 1080i-RGB 1920 X1080@60Hz
VGA 70 720 X 400@70Hz 720p-RGB 1280X 720@60Hz
VESA 85 640 X 400@85Hz 576p-RGB 720X 576@60Hz
SVGA 800 X 600@60/72/75/85Hz 480p-RGB 720 X 480@60Hz
XGA 1024 X 768@60/70/75/85Hz 1080i-YPbPr 1920 X1080@60Hz
Mac 1152 X 864@ 70/75Hz 720p-YPbPr 1280 X 720@60Hz
WXGA 1280 X 768@60Hz 576p-YPbPr 720 X 576@60Hz
1280A 1280 X 960@60Hz 480p-YPbPr 720 X 480@60Hz
SXGA 1280 X 1024@60/75Hz
P
Pi ic ct tu ur re e A Ad dj ju us st t - -When it is selected the following adjust parameters
will appear:
The factory preset values are shown above
Select reset to reset all adjustment back to the factory preset values.
H
HV V a ad dj ju us st t - -When it is selected the following sub-menu appears.
Use + -to adjust the best horizontal and vertical position of the picture.
O
OS SD D a ad dj ju us st t - -When it is selected, you can adjust the Horizontal and
Vertical position of the OSD menu.
S
Sy ys st te em m i in nf fo or rm ma at ti io on n - -When it is selected, it shows the input/output
resolution and their vertical refresh rate on the screen.
A
Au ut to o a ad dj ju us st t - -When it is selected the SC-DV-2 will automatically
adjust all the parameter to the factory preset value.
E
Ex xi it t - -Select to exit from the current menu page.

Model SC
-
DV
-
2
8
Notes
vThe default output resolution is XGA @ 60Hz.
vThe unit has non-volatile memory and memorizes all your settings
before power off and recalls those settings on next power on.
vAt any time, pressing + and -buttons simultaneously will reset the
output resolution to XGA@60Hz, and other settings back to
factory default values.
4. Troubleshooting
There are no field serviceable parts or circuits in the device. If you think that
the device is malfunctioning, please first try to reset to factory default
settings by pressing the + and -buttons simultaneously for 2 seconds.
Contacting Hall Research Technologies
If you determine that your scaler is malfunctioning, do not attempt to repair
the unit. Contact HRT’s Tech. Support at 714-641-6607.
Before you do, make a record of the history of the problem. We will be able
to provide more efficient and accurate assistance if you have a complete
description.
Shipping and Packaging
If you need to transport or ship your Video Processor:
• Package it carefully. We recommend that you use the original
container.
• Before you ship the units back to Hall Research Technologies for
repair or return, contact us to get a Return Authorization (RMA)
number.

DVI
-
to
-
VGA Video Scaler
9
5. Specifications
General
Input Format: Digital RGBHV, YPbPr, YCbCr
Input Connector: 29-pin DVI-I
Output Signal: RGB:0.7Vp-p, 75 ohm, HV: 3 to 5 Vp-p TTL
Y: 1 Vp-p 75 ohm; PbPr: 0.7 Vp-p 75 ohm
Output Connector: HD-15 Female VGA
Power: 5V DC at 2 A max (Universal power supply included)
Input Resolutions
PC Resolutions HDTV Resolutions
VGA 640 X 480@60/72/75/85Hz 1080i 1920 X1080@60Hz
VGA 70 720 X 400@70Hz 720p 1280X 720@60Hz
VESA 85 640 X 400@85Hz 576p 720X 576@50Hz
SVGA 800 X 600@60/72/75/85Hz 576i 720X 576@50Hz
XGA 1024 X 768@60/70/75/85Hz 480p 720 X 480@60Hz
Mac 1152 X 864@ 70/75Hz 480i 720 X 480@60Hz
WXGA 1280 X 768@60Hz
1280A 1280 X 960@60Hz
SXGA 1280 X 1024@60/75Hz
Output Resolutions
PC Resolutions HDTV Resolutions
VGA 640 X 480@60/72/75/85Hz 1080i-RGB 1920 X1080@60Hz
VGA 70 720 X 400@70Hz 720p-RGB 1280X 720@60Hz
VESA 85 640 X 400@85Hz 576p-RGB 720X 576@60Hz
SVGA 800 X 600@60/72/75/85Hz 480p-RGB 720 X 480@60Hz
XGA 1024 X 768@60/70/75/85Hz 1080i-YPbPr 1920 X1080@60Hz
Mac 1152 X 864@ 70/75Hz 720p-YPbPr 1280 X 720@60Hz
WXGA 1280 X 768@60Hz 576p-YPbPr 720 X 576@60Hz
1280A 1280 X 960@60Hz 480p-YPbPr 720 X 480@60Hz
SXGA 1280 X 1024@60/75Hz

Model SC
-
DV
-
2
10
Reference Information
DVI Connector pinout N/U = Not Used
Pin Signal name Pin Signal name
1TMDS Data2–13 TMDS Data3+ (N/U)
2TMDS Data2+ 14 +5V Power
3TMDS Data2/4 Shield 15 Ground for +5V Power
4TMDS Data4–(N/U) 16 Hot Plug Detect
5TMDS Data4+ (N/U) 17 TMDS Data0–
6DDC Clock 18 TMDS Data0+
7DDC Data 19 TMDS Data0/5 Shield
8Analog vertical sync 20 TMDS Data5–(N/U)
9TMDS Data1–21 TMDS Data5+ (N/U)
10 TMDS Data1+ 22 TMDS Clock Shield
11 TMDS Data1/3 Shield 23 TMDS Clock+
12 TMDS Data3–(N/U) 24 TMDS Clock–
C1 Analog red C4 Analog horizontal sync
C2 Analog green C5 Analog ground
C3 Analog blue

DVI
-
to
-
VGA Video Scaler
11

Model SC
-
DV
-
2
12

The difference between a “good” installation and a “great” one! ™
Products Designed and Made in the USA
© Copyright 2005. Hall Research Technologies, Inc..
All rights reserved.
1163 Warner Ave., Tustin, CA 92780
Ph: [phone] , Fax: [phone]
