HSU HC-1 MK2 User manual

HC-1 MK2 Center Channel
Owner’s Manual
Features
High Definition
The HC-1 MK2 utilizes a controlled-directivity horn that gives excellent micro dynamics
and imaging under real world conditions that few other transducers can match without
the typical horn sound.
Wide Dynamic Range
The HC-1 MK2 is both efficient and high power handling. It provides effortless dynamics
to handle high-definition audio programs and home theater.
Works Perfectly with Subwoofers
The HC-1 MK2 was designed specifically to work best in systems using a subwoofer or
mid-bass module plus low-bass subwoofer.
High-Definition Audio Speakers by HSU Research.
Designed and engineered in the U.S.A.

A. UNPACKING
Carefully remove your new HSU speaker from its box, avoiding staples
which can cause damage to the cabinet. If you discover damage, contact
us and the shipper immediately.
Save your cartons – they are the best possible protection for your
speakers should you ever need to move them.
B. PLACEMENT
Note: For optimum bass performance, the addition
of a subwoofer,or a mid bass module plus a low
bass subwoofer is highly recommended.
Positioning Your Subwoofer
See the subwoofer owner’s manual.
Positioning Your Center Channel
For best imaging, the HC-1 MK2 should be placed close to ear level when
seated. This may be somewhat limited by the position of the TV, since
the center channel usually has to be above or below the TV. To the
extent that the TV height is flexible, try to position the TV so the center
channel speaker can be at the right height. If the position of the TV is
fixed, place the center channel so it is as close to ear level as the situ-
ation allows. The HC-1 MK2 comes with a base that allows you to tilt it so
the speaker aims at the listener.
If you prefer an in-wall alternative, get the in-wall version of the HB-1 MK2.
The HC-1 MK2 is not magnetically shielded. This should not be an issue
with all the new TVs (DLP, LCD, plasma).
Using the HC-1 MK2 as
Left and Right Speakers
Although designed primarily as a center channel, many customers
have used it as main speakers. You can stand it up vertically, rotate the
horn 90 degrees, take out the rubber Crescents (part of the tilting
base that is attached to the speaker), and use it like you would with
the HB-1 MK2.
Positioning Your Satellites
For best imaging, the HC-1 MK2 should be placed such that the tweeter
is at ear level when seated, aimed directly at the primary listener. The
distances to the three nearest solid surface should be in the ratio
1:1.26:1.60. When you have the distance to the floor the greatest, for
a typical ear height of 40˝ , this translates into 25 and 32˝ from the two
nearest walls (Figure 1).
C. WIRING
The HC-1 MK2s do not come with wires. We suggest getting 16 AWG for
runs under 10 feet, 14 AWG for runs of 10 - 25 feet, and 12 AWG for
runs of 26 - 50 feet.
Strip 1/2˝ of insulation from each end of the wire to expose the bare
metal. Insert this into the 5-way gold plated binding posts on the back
of the HC-1 MK2 (Figure 2). Alternatively, you can use banana plugs.
If you are connecting using bare wires, make sure the binding posts
are tight, and no stray wires strands are causing a short.
D. SETTING UP
Most speaker wire is polarity coded. This means that each conductor
is labeled either (+) positive or (-) negative. The (+) positive side may
be a different color or texture than the (-) negative side. On the back of
your amplifier, each channel is probably labeled (+) and (-) as well as
color coded red for (+) positive and black for (-) negative. HSU speak-
er terminals are color coded red for (+) positive and black for (-) neg-
ative. Be sure to hook (+) to (+), (red to red), and (-) to (-), (black
to black).
Figure 2
Figure 1

©2008 HSU Research
E. TROUBLESHOOTING
AND SERVICE
We use components and designs of the highest caliber as a means of
ensuring a long and trouble free life for your speaker. However, no
amount of protection will prevent damage caused by defective associated
equipment or extreme abuse.
If you have a problem, first try to determine if it is indeed a speaker
problem. Determine whether the problem exists in more than one speak-
er. If it does, the problem likely originates in some other component in
the system. If the problem is in the center channel only, try connecting the
HC-1 MK2 to another channel on the amplifier. If the HC-1 MK2 now sounds
fine, your problem is not in the HC-1MK2. Once you have determined that
you have a speaker problem, contact us at the location shown below for
service. Please describe the problem in detail. We will decide on the most
appropriate course of action.
F. SPECIFICATIONS
Woofer: Dual 61/2˝ treated paper cone woofers with treated cloth sur-
rounds, flat polycotton spiders and high temperature aluminum voice
coils
Tweeter: Very high efficiency controlled directivity horn with aluminum
diaphragm, neodymium magnet, and ferro-fluid cooled voice coil.
Crossover: Computer aided, final voicing by Dr. Hsu
(i.e., fine tuning by Dr. Hsu to sound good to his ears)
Frequency Response: 60 - 20 kHz +/– 2dB
Recommended crossover to subwoofer/mid bass module: 80 Hz
Sensitivity: 92 dB/1m/2.83V rms, half space
Nominal impedance: 12 ohms
Minimum impedance: 8 ohms
Enclosure type: Vented
Enclosure material: 3/4˝ MDF
Dimensions: 8˝ H x 23˝ W x 10˝D
(9.25 - 10˝ H with base, depending on tilt angle)
Net Weight: 21 pounds, Shipping Weight: 24 pounds
Recommended Amplifier Power: 10 - 250 W rms
G. HSU SPEAKER SYSTEM
SEVEN YEAR LIMITED
WARRANTY
If the speaker system proves to be defective in materials or workmanship
within seven years from the date of the original customer’s purchase, we
will, at our option, repair or replace the defective product. If for any
reason, we are unable to repair or replace a defective product within
a reasonable time, we will refund your purchase price.
*DISCLAIMER
THE WARRANTY STATED HEREIN IS IN LIEU OF ALL OTHER WAR-
RANTIES, EXPRESS OR IMPLIED, INCLUDING MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE AND ALL OTHER LIABILITIES AND
OBLIGATIONS OF HSU, ALL OF WHICH ARE EXPRESSLY DISCLAIMED.
HSU HAS NOT MADE AND DOES NOT HEREBY MAKE ANY OTHER
REPRESENTATION, WARRANTY OR COVENANT WITH RESPECT TO THE
CONDITION, QUALITY, DURABILITY, DESIGN, OPERATION, CAPACITY,
FITNESS FOR USE OR SUITABILITY OF THE SPEAKER SYSTEMS.
Exclusion of Certain Damages
HSU’s liability for any defective product is limited to repair or replace-
ment of the product at our option. HSU shall not be liable for incidental
or consequential damages of any kind or character because of product
defects. Some states do not allow limitations on how long an implied
warranty lasts and/or do not allow the exclusion or limitation of inciden-
tal or consequential damages, so the above limitations and exclusions
may not apply.
This Warranty Does Not Cover:
• Damage caused by abuse, accident, misuse, negligence, or
improper operation.
• Products that have been altered or modified.
• Any product whose serial number has been altered, defaced,
or removed.
• Normal wear and maintenance.
• Damages caused by shipping. (All claims for shipping damage
must be made with the carrier.)
Warranty Service
Warranty repairs can only be performed by HSU Research. As soon as
the problem is found, contact us for instructions and information.
All warranty repairs must be accompanied by the original bill of sales.
No other document is acceptable or is required. This warranty gives you
specific legal rights, and you may also have other rights which vary from
state to state.
Due to our continual efforts to improve product quality as new technology and
techniques become available, HSU reserves the right to revise its Speaker Systems
specifications without notice.
HSU Research
985 N. Shepard St.
Anaheim, CA 92806
1-800-554-0150
HSURESEARCH.COM
