HT HT9020 User manual

Copyright HT ITALIA 2016 Release EN 1.00 - 29/12/2016
ENGLISH
User manual

LINESPLITTER
EN - 1
Table of Contents:
1PRECAUTIONS AND SAFETY MEASURES...............................................................2
1.1Preliminary instruction....................................................................................................... 2
2GENERAL DESCRIPTION...........................................................................................3
3PREPARATION FOR USE...........................................................................................3
3.1Initial checks...................................................................................................................... 3
3.2Instrument power supply................................................................................................... 3
3.3Calibration......................................................................................................................... 3
3.4Storage.............................................................................................................................. 3
4NOMENCLATURE........................................................................................................4
4.1Description of instrument................................................................................................... 4
5INSTRUMENT FUNCTIONS ........................................................................................4
6OPERATING INSTRUCTIONS.....................................................................................5
6.1Line current measurement ................................................................................................ 5
6.2Leakage current measurement ......................................................................................... 5
6.3Voltage and power measurement ..................................................................................... 6
7MAINTENANCE ...........................................................................................................6
7.1Cleaning the instrument .................................................................................................... 6
7.2End of life .......................................................................................................................... 6
8TECHNICAL SPECIFICATIONS ..................................................................................7
8.1Accessories....................................................................................................................... 7
8.1.1Accessories provided................................................................................................................... 7
9ASSISTANCE...............................................................................................................8
9.1Warranty conditions........................................................................................................... 8
9.2Assistance......................................................................................................................... 8

LINESPLITTER
EN - 2
1 PRECAUTIONS AND SAFETY MEASURES
The instrument has been designed in compliance with IEC/EN61010-1 guidelines relevant
to electronic measuring instruments. For your safety and in order to prevent damaging the
instrument, please carefully follow the procedures described in this manual and read all
notes preceded by symbol with the utmost attention. Before and after carrying out
measurements, carefully observe the following instructions:
Do not carry out any measurement in humid environments.
Do not carry out any measurements in case gas, explosive materials or flammables are
present, or in dusty environments.
Avoid any contact with the circuit under test if no measurement is in progress.
Avoid any contact with exposed metal parts, with unused measuring probes, circuits,
etc.
Do not carry out any measurement in case you find anomalies in the instrument such
as deformation, breaks, substance leaks, absence of display on the screen, etc.
Pay special attention when measuring voltages higher than 25V AC, since a risk of
electrical shock exists.
In this manual, and on the instrument, the following symbols are used:
Warning: observe the instructions given in this manual; improper use could
damage the instrument or its components.
High Voltage danger: electrical shock risk
AC voltage or current
Ground reference
1.1 PRELIMINARY INSTRUCTION
CAUTION
The instrument can be used for AC CURRENT and AC VOLTAGE
measurements on installations with CAT II 240V to ground, max load
current of 16A
Do not use the instrument on loads with absorbed currents over 16A
Do not use the instrument if the protection conditions on the circuit are
limited or protection devices are damaged.
Do not use the instrument in circuits with voltages higher than the rated
ones
Do not carry out any measurement in case you find anomalies in the
instrument such as deformation, breaks, substance leaks, absence of
display on the screen, etc.
Use only indoor

LINESPLITTER
EN - 3
2 GENERAL DESCRIPTION
The instrument has the following features:
Splitting phase conductor L from N and PE conductors for 2-poles, 3-poles cables
Easy (L-N, L-PE, N-PE) AC voltage measurement with clamps/multimeters
Easy AC current measurement with external clamps
Current ring x1 for direct AC current measurement
Current ring x10 for direct AC low current measurement
Leakage current direct measurement on PE conductor
Leakage current indirect measurement on L-N conductors
Use with loads with 16A maximum absorbed current
3 PREPARATION FOR USE
3.1 INITIAL CHECKS
Before shipping, the instrument has been checked from an electric as well as mechanical
point of view. All possible precautions have been taken so that the instrument is delivered
undamaged. However, we recommend thoroughly checking the instrument in order to
detect possible damage suffered during transport. In case anomalies are found,
immediately contact the forwarding agent. We also recommend to check whehter the
packaging contains all components indicated in § 8.1.1. In case of discrepancy, please
contact the Dealer. In case the instrument should be returned, please follow the
instructions given in § 9.
3.2 INSTRUMENT POWER SUPPLY
The instrument is supplied directly by the main 230V with the integrated Schuko plug
3.3 CALIBRATION
The instrument’s technical specifications are described in this manual. Thanks to its simple
structure, no periodical calibration procedure is required.
3.4 STORAGE
In order to guarantee precise measurement, after a long storage time, wait for the
instrument to come back to normal condition (see § 8).

LINESPLITTER
EN - 4
4 NOMENCLATURE
4.1 DESCRIPTION OF INSTRUMENT
CAPTION:
1. Schuko plug for
connection to main
supply
2. Ring for leakage
measurement on
PE cable
3. Not usable current
rings
4. Input terminals for
L-N, L-PE, N-PE
voltage
measurements
5. Ring for leakage
measurement on
L-N cables
6. Ring for line
current
measurement x1
7. Ring for line
current
measurement x10
8. Schuko plug for
load connection
Fig. 1: Description of LINESPLITTER instrument
5 INSTRUMENT FUNCTIONS
LINESPLITTER is a useful accessory capable of performing electrical splitting between the
active conductors of phase, neutral and PE for single-phase loads supplied by 2 or 3 poles
cords with absorbed current up to 16A. It aims at performing an immediate current
measurement directly on the cords using clamps or multimeters which would not be
possible without it (null result).
LINESPLITTER has 2 rings (Ax1 and Ax10 - see Fig.1 parts 6 and 7) so as to respectively
perform the measurement of the line current and the measurement of the same current
multiplied by a factor 10 (useful with current clamps having poor sensitivity or too high
ranges).
LINESPLITTER also includes other two rings (mA PE and mA L-N - see Fig 1 parts 2 and
5) for easy leakage current measurement respectively direct to ground (on the PE
conductor) and indirect/differential (on L-N conductors).
Finally LINESPLITTER also allows to perform AC L-N, L-PE and N-PE voltage
measurements (see Fig. 1 part 4) using digital multimeters.

LINESPLITTER
EN - 5
6 OPERATING INSTRUCTIONS
6.1 LINE CURRENT MEASUREMENT
1. Connect LINESPLITTER to 230V AC main socket through Schuko plug.
2. Connect the main cable of the load to the instrument’s Schuko plug.
3. Put the clamp around the Ax1 or Ax10 rings and switch on the load.
4. Read the value of line current in the Ax1 ring or divide by 10 the value of current read
in the Ax10 ring (see Fig. 2)
Fig. 2: Use of the instrument for line current measurement
6.2 LEAKAGE CURRENT MEASUREMENT
1. Connect LINESPLITTER to 230V AC main socket through Schuko plug
2. Connect the main cable of the load to the instrument’s Schuko plug.
3. Put a leakage clamp around the mA PE or mA L-N rings and switch on the load.
4. Read the direct value of leakage current (PE conductor) in the mA PE ring or the
indirect/differential value of leakage current (L-N conductors) in the mA L-N ring (see
Fig. 3).
Fig. 3: Use of the instrument for leakage current measurement

LINESPLITTER
EN - 6
6.3 VOLTAGE AND POWER MEASUREMENT
1. Connect LINESPLITTER to 230V AC main socket through Schuko plug
2. Connect the main cable of the load to the instrument’s Schuko plug.
3. Put a power clamp (e.g. HT9020 or HT9022 models) around the Ax1 ring and the
clamp’s test leads in the Vinputs of the instrument and switch on the load
4. Read the correspondent values of current, voltage and absorbed power of the load
(see Fig. 4).
Fig. 4: Use of the instrument for current, voltage and power measurement
7 MAINTENANCE
CAUTION
Only expert and trained technicians should perform maintenance
operations. Before carrying out maintenance operations, disconnect all
cables from the input terminals.
Do not use the instrument in environments with high humidity levels or
high temperatures
7.1 CLEANING THE INSTRUMENT
Use a soft and dry cloth to clean the instrument. Never use wet cloths, solvents, water, etc.
7.2 END OF LIFE
CAUTION: the symbol on the instrument indicates that the appliance and its
accessories must be collected separately and correctly disposed of.

LINESPLITTER
EN - 7
8 TECHNICAL SPECIFICATIONS
Power supply: 230VAC (10%), 240VAC (10%) 50/60Hz
Main connection integrated Schuko plug, 50cm length
Load connection: integrated Schuko plug
Load current: max 16A
Operating temperature: -20°C 40°C (-4°F 104°F)
Operating humidity: <80%RH
Storage temperature: -20°C 60°C (-4°F 140°F)
Storage humidity: <80%RH
Safety: IEC/EN61010-1, IEC/EN61010-02-030
Measurement category : CAT II 240V
Max operating altitude: 2000m (6562ft)
Dimensions (L x W x H): 210 x 60 x 35mm (8 x 2 x 1in)
Weight: 385g (14 ounces)
This instrument complies with requirements of Low Voltage Directive 2014/35/EU
(LVD) and of EMC Directive 2014/30/EU
This instrument complies with requirements of European Directive 2011/65/EU
(RoHS) and 2012/19/EU (WEEE)
8.1 ACCESSORIES
8.1.1 Accessories provided
User manual

LINESPLITTER
EN - 8
9 ASSISTANCE
9.1 WARRANTY CONDITIONS
This instrument is warranted against any material or manufacturing defect, in compliance
with the general sales conditions. During the warranty period, defective parts may be
replaced. However, the manufacturer reserves the right to repair or replace the product.
Should the instrument be returned to the After-sales Service or to a Dealer, transport will
be at the Customer's charge. However, shipment will be agreed in advance. A report will
always be enclosed to a shipment, stating the reasons for the product's return. Only use
original packaging for shipment. Any damage due to the use of non-original packaging
material will be charged to the Customer. The manufacturer declines any responsibility for
injury to people or damage to property.
The warranty shall not apply in the following cases:
Repair and/or replacement of accessories and battery (not covered by warranty).
Repairs that may become necessary as a consequence of an incorrect use of the
instrument or due to its use together with non-compatible appliances.
Repairs that may become necessary as a consequence of improper packaging.
Repairs which may become necessary as a consequence of interventions performed
by unauthorized personnel.
Modifications to the instrument performed without the manufacturer's explicit
authorization.
Use not provided for in the instrument's specifications or in the instruction manual.
The content of this manual cannot be reproduced in any form without the manufacturer's
authorization.
Our products are patented and our trademarks are registered. The manufacturer
reserves the right to make changes in the specifications and prices if required by
improvements in technology.
9.2 ASSISTANCE
If the instrument does not operate properly, before contacting the After-sales Service,
please check the conditions. Should the instrument still operate improperly, check that the
product is operated according to the instructions given in this manual. Should the
instrument be returned to the After-sales Service or to a Dealer, transport will be at the
Customer's charge. However, shipment will be agreed in advance. A report will always be
enclosed to a shipment, stating the reasons for the product's return. Only use original
packaging for shipment. Any damage due to the use of non-original packaging material will
be charged to the Customer.
