HTC VIVE User manual

VR Here operation guide
2017

Operation Guide –HTC Vive Controller
1
22
3
Trigger Trackpad
Menu button

Operation Guide –Button Conventions
Button Name
Operation
Function
Trigger
Pull
Remotely trigger or select an item. For example,
play a video on the wall.
Hold
Interact with a virtual object. For example,
pick up a book.
Trackpad
Press, hold,
and release
Move around a VR environment.
Menu button
Press
Return to the upper level.

Operation Guide –Typical Operations
How can I move around a VR environment?
Procedure:
1. Press and hold the Trackpad with your thumb.
2. Point the HTC Vive controller to the ground and
then point to the position where you want to move
to.
3. Release the Trackpad to move to the target
position.

Operation Guide –Typical Operations
How can I interact with a virtual object?
Procedure:
1. Move next to the target virtual object.
2. Position the controller near to the object. When the
controller starts to vibrate, pull and hold the Trigger.

Operation Guide –Typical Operations
How can I trigger UI information?
Procedure:
1. Move to an area where you can best see the target
UI information.
2. Point the controller towards the target UI so that
the controller's laser is aimed at the UI area.
3. When the controller starts to vibrate, pull the
Trigger.

Operation Guide –Typical Operations
How can I play a video?
Procedure:
1. Move to an area where you can best see the target
video.
2. Point the controller at the Play button of the video
screen.
3. When the controller starts to vibrate, pull the
Trigger.

Operation Guide –Typical Operations
How can I remove and re-insert a board?
Procedure:
1. Move to an area where you can best remove and
re-insert the target board.
2. Position the controller near to the target board in
the subrack.
3. When the controller starts to vibrate, pull and hold
the Trigger to remove the board from the subrack.
4. After you remove board, position the controller near
to the removed board. When the controller starts to
vibrate, pull and hold the Trigger to re-insert the
board.

Operation Guide –Typical Operations
How can I exit from the current scenario?
Procedure:
1. Press the Menu button on the controller.
