HTG KULUMI MINI User manual

Audio Player:
- Short Press: Cycle between
10%, 25%, 50%, 100%, OFF
Micro USB:
- Recharge Kulumi Mini
- 5V DC / 1000mA input
Audio In (RED):
- Line In: Use supplied 800mm AUX
cable to play audio from a laptop,
phone or another Mini player.
Audio Out (GREEN):
- FM reception: Use supplied 800mm
AUX cable as antenna for good
FM
reception.
- Earphone jack: Use any 3.5mm
earphone to listen to audio. Press
“Mute” button to silence the speaker.
- Line out: Use supplied 800mm
AUX cable to play audio to another
speaker or
Mini player.
Standard USB:
- 5V DC / 500mA output
- Charge mobile phone or any other
5V device
Micro SD card slot:
- Remove SD card to access the
Kulumi Mini internal files on your
computer/ phone.
- Return SD card to reactivate the
Kulumi Mini.
- LED light will flash when SD card
is removed or inserted back.
10% 25% 50% 100%
35h 18h 7h 4h
10 lm 40 lm 75 lm 150 lm
Audio Power
Short Press: Pause
Long Press: ON / OFF
Previous / Next Root Folder
Search Previous / Next
FM Station
Previous / Next Folder
Previous / Next File
Mode Button
Switch between FM and
micro SD card
Mute Speaker
- 8GB micro SD card. Auxiliary Audio
sources include FM radio and Line In.
- Built-in 2W speaker that enables
20 people to hear the audio content.
Line-in Earphone
Solar LED Audio Lamp
LED:
Light On / Off

Speaker:
Decrease Volume | Increase Volume
Light Indicator:
Audio Player LED
GREEN SOLID - Play
GREEN FLASHING - Pause
Battery Status
YELLOW - Charging
GREEN - Fully charged
RED - Battery low, recharge soon
KULUMI Mini can be recharged via:
1. The built-in 0.7W solar panel
(typical charge time is 10 to
12 hours in full sunlight).
2. Any USB 5V power adapter / 5V
source using the supplied 500mm
Micro USB charging cable
(typical charge time is 2 hours).
Battery:
- Standard battery size:
3.2V / 1500mAh LiFePO4 battery
- 1000 to 2000 charge cycles
- 4h to 35h of use
- Optional order option: 3.2V /
3000mAh LiFePO4 battery
Package:
KULUMI Mini x 1
AUX Cable x 1
Micro USB Cable x 1
Size: 136x82x33mm
(5.35”x3.21”x 1.29”)
Weight: 195g (0.429 lbs.)
AUX Cable: 800mm (31.5”)
Micro USB Cable: 500mm (19.7”)
WARNING!
• Do not use product near fire or
in a high temperature area.
• Do not soak the product in
water or other liquids.
• Do not disassemble, alter or
apply heat to the product.
• Recommended Operating
Temperature: 0°C to 45°C
(32°F to 113°F)
• Recommended Storage
Temperature: -10°C to 60°C
(14°F to 140 °F)
• Low temperatures
(<-10°C / 14°F) or high
temperatures (> 45°C / 113°F)
will shorten the battery life.
• Warning: Batteries should not
be exposed to excessive heat
such as fire or similar.
• To prevent possible hearing
damage, do not listen to high
volume for long periods of time.
Please be conscious of the
environment and dispose of the
LiFePO4 battery responsibly.
!
Li-ion
www.kulumi.org
KULUMI mini Patent: ZL 2016 3 0566454.5
KULUMI and the “Rising Sun” logo are
Hope Tech Global trademarks
