Huawei IdeaShare Key User manual

Issue：04
Date：2021-03-30
Quick Start
IdeaShare Key

1Appearance
•USB Connector
•Button
•LED Ring
IdeaShare Key is used with endpoints to share
materials.
Used to start or stop video/audio sharing
from the PC to the endpoints.
Indicator
O
Blinking blue at
low brightness
Steady blue at
low brightness
•Inserted in endpoint and
is pairing or upgrading.
•Inserted in PC and is
connecting.
•Inserted in PC and is
diagnosing.
•Inserted in endpoint and
is paired or upgraded.
•Inserted in PC and
connected.
•Screen sharing is stopped.
IdeaShare Key Status
(once per second)
USB connector LED ring Button
Not inserted in any PC or
endpoint.
Blinking blue at
low brightness
(twice per second)
•Inserted in endpoint but
fails to be paired or
upgraded.
•Inserted in PC but fails
to be connected.
Used to connect IdeaShare Key to an
endpoint or PC.

2Pairing
Ensure that the to-be-paired endpoint is of the
required version.
Insert IdeaShare Key in an endpoint. Wait until
a message is displayed indicating that IdeaShare
Key issuccessfully paired on the endpoint’s user
interface.
Steady blue at
high brightness The screen is being shared.
Faulty
Blinking blue at
low brightness
(four times per
second)
Indicator
IdeaShare Key Status
Model
IdeaHub All
Collabration Device
Version
All

3Installation
Install the IdeaShare Key program on the PC for
the first time.
1
2
Remove the paired IdeaShare Key from
endpoint and connect it to the USB port of
the PC.
Double-click IdeaShare key.exe to install the
program.
4Operation
1
2
Insert IdeaShare Key in the USB port of the
PC.
Wait until a message is displayed, indicating
that the connection is successful and the
LED indicator turns blue at low brightness.
Press the button on IdeaShare Key to share
the PC screen and audio to endpoint. Then
you can watch the PC screen on endpoint.
Press the button again to stop sharing.
To share the screen using IdeaShare Key,
perform the following steps:
The path of the installation file varies
according to the operating system version.
For example, in Windows 10 Professional,
the path is This PC > IdeaShare Key >
IdeaShare Key.exe.

5Specifications
5 V DC
Maximum power
consumption
Ambient
temperature
•Operating state:
0°C to 40°C (32°F to 104°F)
•Non-operating state:–40°C
to +70°C（–40°F to +158°F)
Relative
humidity
•Operating state:
5% to 95%
•Non-operating state:
0% to 95%
Package
dimensions
(H x W x D)
Product
dimensions
(H x W x D)
Gross weight
Net weight
Windows 7, 8, 8.1, and 10
(32- and 64-bit)
Power supply
1.5 W
(non-condensing)
Wi-Fi frequency
Wi-Fi operating
frequency bands
Wi-Fi
transmission
power
2.4 GHz and 5 GHz
2400 MHz～2483.5 MHz
5150 MHz～5250 MHz
<20 dBm
Local view: up to 4Kp 15fps
Ongoing conference: up to
1080p 30fps
Data resolutions
OS
177.3 mm × 65 mm
× 19.8 mm
196 g
80 g
213 mm × 100 mm
× 28 mm
Item Specification

Statement on a Class A Product
municipal waste. They should be handed over to a certified
collection point for recycling or proper disposal when they
can no longer be used.
For more detailed information about the recycling of the
device or batteries, contact your local city oce, the
household waste disposal service, or the retail store where
you purchased this device.
The disposal of this device is subject to the Waste from
Electrical and Electronic Equipment (WEEE) Directive of the
European Union. The purpose for separating WEEE and
batteries from other waste is to minimize any environmen-
tal impact and health hazards due to the presence of
hazardous substances.
Disposal and Recycling Information
This symbol on the device and any included
batteries indicates that they should not be
disposed of as normal household garbage. Do not
dispose of your device or batteries as unsorted
Hereby, EShare Technology Co., Ltd. declares that
the radio equipment type is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address:
http://www.ee-share.com/en/product-certification.
This device is compliant with the EU Registration,
Evaluation, Authorization and Restriction of Chemicals
(REACH) Regulation (Regulation No 1907/2006/EC of the
European Parliament and of the Council) and the EU
Restriction of Hazardous Substances (RoHS) Directive
(Directive 2011/65/EU of the European Parliament and of
the Council).
Reduction of Hazardous Substances
Angaben zu einem Produkt der Klasse A
This is a class A product. In a domestic environment this
product may cause radio interference in which case the
user may be required to take adequate measures.
Hierbei handelt es sich um ein Produkt der Klasse A. In
einer häuslichen Umgebung verursacht dieses Produkt
möglicherweise Funkstörungen, gegen die der Nutzer
geeignete Maßnahmen ergreifen muss.

Thank you for choosing our products. Please read this
warranty card carefully and fill in the required information.
Keep the card in a safe place. If lost it cannot be replaced.
Contact
Address
Telephone
Product Model
Serial Number
Invoice Number
Expiration Date
Dealer's Name
Dealer's Address
Dealer's Telephone
Dealer's Seal:
Limited Warranty
We warrant the products that are purchased from
authorized dealers to be free from defects in materials and
workmanship, under proper use and in normal conditions,
during the expressed warranty period.
Contact Information
EShare Technology Co., Ltd.
13A25, Hongfa Center Building
Bao'an, Shenzhen 518100
People's Republic of China
Warranty Card
Registry
Your Name (or Company Name):
1. The terms of warranty expressed in the purchase
contract enjoy higher validity than the terms expressed
within this card. This card is intended to be used solely
as a warranty certificate.
2. The warranty card must be preserved in good condition
and free of any scratch or alterations.
3. The warranty card must be presented to the authorized
service technician when the product is being returned
for repairs.
This warranty card does not cover defects caused by:
1. Modifications and alterations performed on the
warranted product by parties other than authorized
dealers.
2. Damage caused by using the product under inadequate
operating environments.
3. Force majeure including but not limited to fires,
earthquakes, lightning storms, and tsunami.
4. Operations performed on the product unexpressed
within User Guide.
5. Normal wear and tear of components, including but not
limited to the shell and the power module.
6. The warranty card is altered or rendered illegible, or the
product serial number recorded on the warranty card is
inconsistent with the serial number imprinted or labeled
on the product.
For cases not included within this limited warranty, not
applicable, or where the warranty is rendered void or
expired, we reserve the right to charge for the repair
services should the said products be capable of being
repaired.
We reserve the right to interpret this limited warranty.
Special Notice:
