Huawei E5776s-32 User manual

Product Description
HUAWEI E5776s-32 Mobile WiFi
V100R001
Issue 01
Date 2012-07-25
HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 6 of 20
1 Overview
HUAWEI E5776s-32 Mobile WiFi (hereinafter referred to as the E5776s-32) is a
high-speed packet access mobile hotspot. It is a multi-mode wireless terminal for
SOHO (Small Office and Home Office) and business professionals. It supports:
LTE: FDD 2600/2100/1800/900/800 MHz
DC-HSPA+/HSPA+/HSPA/UMTS: 2100/1900/900/850 MHz
EDGE/GPRS/GSM: 1900/1800/900/850 MHz
The E5776s-32 supports the following standards:
Long Term Evolution (LTE)
Dual Carrier High Speed Packet Access Plus (DC-HSPA+)
High Speed Packet Access Plus (HSPA+)
High Speed Uplink Packet Access (HSUPA)
High Speed Downlink Packet Access (HSDPA)
Universal Mobile Telecommunications System (UMTS)
Enhanced Data rates for Global Evolution (EDGE)
General Packet Radio Service (GPRS)
Global System for Mobile communications (GSM)
The E5776s-32 provides the following services:
High-speed LTE packet data service of up to 150 Mbit/s
High-speed DC-HSPA+ packet data service of up to 43.2 Mbit/s
High-speed HSPA+ packet data service of up to 21.6 Mbit/s
High-speed HSPA (HSUPA/HSDPA)/UMTS packet data service of up to 14.4
Mbit/s
EDGE/GPRS packet data service of up to 236.8 kbit/s
Short Message Service (SMS)
You can connect the E5776s-32 with the Wi-Fi, or connect the E5776s-32 with the
USB interface of a computer. In the service area of the
LTE/DC-HSPA+/HSPA+/HSPA/UMTS or EDGE/GPRS/GSM network, you can surf the
Internet and send/receive messages/emails cordlessly. The E5776s-32 is fast, reliable,
and easy to operate. Thus, mobile users can experience many new features and
services with the E5776s-32. These features and services will enable a large number

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 7 of 20
of users to use the E5776s-32 and the average revenue per user (ARPU) of operators
will increase substantially.
Figure 1-1 shows the profile of the E5776s-32.
Figure 1-1 E5776s-32 profile

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 8 of 20
2 Features
2.1 Main Features
The E5776s-32 mainly supports the following features:
LTE (DL) data service of up to 150 Mbit/s
LTE (UL) data service of up to 50 Mbit/s
DC-HSPA+ (DL) data service of up to 43.2 Mbit/s
DC-HSPA+ (UL) data service of up to 5.76 Mbit/s
HSPA+ (DL) data service of up to 21.6 Mbit/s
HSPA+ (UL) data service of up to 5.76 Mbit/s
HSDPA (DL) data service of up to 14.4 Mbit/s
HSUPA (UL) data service of up to 5.76 Mbit/s
UMTS data service of up to 384 kbit/s
EDGE data service of up to 236.8 kbit/s
GPRS data service of up to 85.6 kbit/s
PS domain data service based on LTE and UMTS
SMS
Sharing Data Stored on the microSD card
Wi-Fi
WPS
Fast boot
Plug and Play (PnP)
IPv6 /IPv4 dual stack
Display current SSID and Wi-Fi key on the screen
Built-in DHCP Server, DNS RELAY and NAT
Online software upgrade
Traffic statistic
Standard Micro USB interface
TFT-LCD screen
Windows XP, Windows Vista, Windows 7, MAC OS X 10.5, 10.6 and 10.7

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 9 of 20
2.2 Optional Features
Optional features refer to features that are not supported by the standard version or are
disabled by default. These features can be customized according to operator or
customer requirements. The E5776s-32's optional features is as follows:
LTE/3G/Wi-Fi auto offload
2.3 Technical Specifications
2.3.1 Hardware
Table 2-1 lists the hardware specifications.
Table 2-1 Hardware specifications
Item Specifications
Technical
standard
WAN: LTE/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM
WLAN: IEEE 802.11b/g/n
Operating
frequency
LTE: FDD 2600/2100/1800/900/800 MHz
DC-HSPA+/HSPA+/HSPA/UMTS: 2100/1900/900/850 MHz
EDGE/GPRS/GSM: 1900/1800/900/850 MHz
WLAN: 2400–2452 MHz
Internal memory 256 MB flash and 128 MB Memory
Maximum
transmitter
power
LTE: Conform to Power Class 3 Definition
UMTS: Conform to Power Class 3 Definition
WLAN 802.11b: 11 dBm
802.11g: 10 dBm
802.11n: 8 dBm
Receiver
sensitivity
LTE: Confirm to 3GPP Requirements
UMTS: Confirm to 3GPP Requirements
WLAN 802.11b: -76 dBm@11 Mbit/s
WLAN 802.11g: -65 dBm@54 Mbit/s
WLAN 802.11n: -64 dBm@65 Mbit/s
WLAN speed 802.11b: Up to 11 Mbit/s
802.11g: Up to 54 Mbit/s

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 10 of 20
Item Specifications
802.11n HT20: Support MCS0–MCS7; Up to 72.2 Mbit/s.
Support MCS8–MCS15; Up to 144.4 Mbit/s.
HT40: Support MCS0–MCS7; Up to 150 Mbit/s.
Support MCS8–MCS15; Up to 300 Mbit/s.
Maximum power
consumption
5 W
Power supply AC: 100–240 V
DC: 5 V, 2 A
Battery Type: Li (rechargeable and non-removable)
Capacity: 3.7 V, 3000 mAh
Maximum working time: 10 hours (depending on the network)
Maximum standby time: 500 hours (depending on the network)
External
interfaces
USB interface: Micro USB
Standard microSD card interface
SIM card: standard 6-pin SIM card interface
External main diversity antenna interface
Screen TFT-LCD
key-press Power switch, WPS switch, Reset switch
Antenna Built-in LTE/UMTS/GSM main diversity antenna
Built-in LTE/UMTS diversity antenna
Built-in WLAN antenna
Dimensions
(D × W × H)
106.4 mm×66.0 mm×15.5 mm
Weight < 150 g (including the battery)
Temperature Operating: 0℃to +35℃
Storage: -20℃to +60℃
Humidity 5% to 95% (non-condensing)
2.3.2 Software
Table 2-2 lists the software specifications.

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 11 of 20
Table 2-2 software specifications
Item Description
SMS Writing/Sending/Receiving
Sending/Receiving extra-long messages
Storage: Up to 500 messages can be saved in the
internal memory of the E5776s-32.
New message prompt
Network connection
setup
APN management: create, delete and edit.
Set up network connection
WLAN setup SSID broadcasting and hiding
Open system and shared key authentication
ASCII and HEX keys
64/128-bit WEP encryption
256-bit WPA-PSK and WPA2-PSK encryption
TKIP and AES encryption algorithm
TKIP and AES integrated encryption algorithm
Automatic adjustment of ratios
Display STA status
Turn off Wi-Fi automatically
WLAN MAC filter
Firewall setup Firewall Switch
LAN IP Filter
Virtual Server
DMZ Service
UPnP Service
WAN Ping block
NAT setup CONE NAT
Symmetric NAT
VPN passthrough
DHCP setup DHCP server enabling and disabling
Address pool of the DHCP server setup
DHCP lease time setup
Software installation Automatic installation (PnP)
LTE/3G/Wi-Fi auto
offload (optional)
Accessing to WAN via LTE/3G or Wi-Fi
Automatic offload between LTE/3G and Wi-Fi
IPv6/IPv4 dual stack DHCPv6/v4 server and client
DNSv6/v4 server and client
Display IPv6/v4 WAN address

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 12 of 20
Item Description
Other Network connection settings:
Automatic network selection and registration
Manual network selection and registration
Network status display: signal, operator name, system
mode, and so on.
Selection of network connection types, for example:
LTE Only
3G Only
Auto
PIN management: activate/deactivate PIN, PIN lock,
changing PIN, unblocking by using the PUK.
System requirement Windows XP, Windows Vista, Windows 7
Mac OS X 10.5, 10.6 and 10.7
Your computer’s hardware system should meet or
exceed the recommended system requirements for the
installed version of OS

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 13 of 20
3 Services and Applications
3.1 Data Service
3.1.1 Wireless Modem
The E5776s-32 can be used as a wireless modem when the Wi-Fi is enabled. You can
directly use the default settings (or configure APN on the E5776s-32 WEB page) and
set up a wireless network connection. Then you can access the Internet.
A maximum of ten wireless users can access the E5776s-32 at the same time. You
can set up the WLAN with the access point (AP) function.
Figure 3-1 Multi-device access via Wi-Fi

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 14 of 20
Figure 3-2 Multi-device access via Wi-Fi and USB at the same time
3.1.2 USB Modem
After you connect the E5776s-32 and PC with a USB data cable, the E5776s-32 driver
is installed on the PC automatically and the shortcut of the web page is displayed on
the PC desktops. You can directly use the default settings (or configure APN on the
E5776s-32 WEB page) and set up a network connection. Then you can send or
receive E-mail, access the network through wireless connection, and download files
through wireless data channels.
Figure 3-3 One-device access via USB
3.1.3 LTE/3G/Wi-Fi Auto Offload (Optional)
The E5776S-32 allows you to access the Internet via LTE/3G or Wi-Fi. When you are
using the E5776S-32 in areas with a Wi-Fi hotspot, for example, an airport, a cafe, a
hotel, or your home, the E5776S-32 switches to Wi-Fi connection automatically,
saving your LTE/3G network traffic fees.

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 15 of 20
Figure 3-4 LTE/3G/Wi-Fi auto offload
3.2 SMS
The E5776s-32 supports message writing/sending/receiving. You can manage
messages through the WEB page, such as an inbox, an outbox and a draft.
3.3 Sharing Data Stored on the microSD card
After the microSD card is inserted, you can store data on the card or use the web
management page to share data stored on the card.

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 16 of 20
4 System Architecture
4.1 System Architecture
Figure 4-1 shows the system architecture.
Figure 4-1 System architecture
Protocol stack
Bottom layer drivers
(include USB, Wi-Fi
and user interface)
Application
systerm
WEB page
WEB server
User
interface USB
Wi-Fi
Baseband signal
processing
Radio frequency
module
Power module
Software module
Mobile WiFi
PC
Mobile
phone/Tablet
USB / Wi-Fi
Wi-Fi
Hardware module

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 17 of 20
4.2 Functional Modules
1. Radio frequency module: It sends/receives radio signals and
modulates/demodulates the radio frequency (RF) signals and baseband signals
2. Baseband signal processing: It processes LTE/DC-HSPA+/HSPA+/UMTS/
EDGE/GPRS/GSM baseband digital signals, including:
Modulating/Demodulating
LTE/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM baseband signals
Encoding/Decoding LTE/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM
channel
3. Bottom layer driver: It drives peripherals, including a USB device, Wi-Fi devices,
a screen, buttons, a SIM card and a microSD card.
4. Protocol stack system: It processes protocols of
LTE/DC-HSPA+/HSPA+/UMTS/EDGE/GPRS/GSM and TCP/IP.
5. Application system: It provides management system, including SMS, PS
domain service, Wi-Fi configuration, network service, WEB service and WEB
page. The user can set management parameters by WEB page.
6. User interface: It provides human-computer interaction, including a screen and
buttons.

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 18 of 20
5 Packing List
This chapter describes the items contained in the package of the E5776s-32.
Table 5-1 lists the items contained in the package of the E5776s-32.
Table 5-1 Packing list of the E5776s-32
Item Quantity Remarks
Mobile WiFi 1 Standard
Rechargeable Battery (irremovable, 3000 mAh) 1 Standard
USB Cable 1 Standard
Quick Start 1 Standard
Safety Information 1 Standard
Power Adapter 1 Standard
Warranty Card 1 Optional

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 19 of 20
A Acronyms and Abbreviations
3G The Third Generation
AES Advanced Encryption Standard
APN access point name
ARPU average revenue per user
ASCII American Standard Code for Information Interchange
DC-HSPA+ Dual Carrier High Speed Packet Access Plus
DHCP Dynamic Host Configuration Protocol
DMZ demilitarized zone
DNS Domain Name Server
EDGE Enhanced Data Rates for GSM Evolution
FDD frequency division duplex
GPRS General Packet Radio Service
GSM Global System for Mobile Communications
HSPA+ High Speed Packet Access Plus
HSUPA High Speed Uplink Packet Access
HSDPA High Speed Downlink Packet Access
IEEE Institute of Electrical and Electronics Engineers
IP Internet Protocol
LCD Liquid Crystal Display
LTE Long Term Evolution
MAC Medium Access Control
Modem Modulator Demodulator
NAT Network Address Translation

HUAWEI E5776s-32 Mobile WiFi V100R001
Product Description
Issue 01 (2012-07-25) Commercial in Confidence Page 20 of 20
OS Operating System
PC personal computer
PIN personal identification number
PnP Plug and Play
PS packet switched
PUK PIN unblocking key
SIM subscriber identity module
SMS short messaging service
SOHO small office home office
SSID Service Set Identifier
TFT Thin Film Transistor
TKIP Temporal Key Integrity Protocol
UMTS Universal Mobile Telecommunications System
UPnP Universal Plug and Play
USB Universal Serial Bus
WAN wireless area network
WEP wired equivalent privacy
Wi-Fi Wireless Fidelity
WLAN wireless local area network
WPA Wi-Fi Protected Access
