Huawei WS5800 User manual

Quick Start Guide
96727034_01

Contents
Quick Start Guide ................................................... 1
Guide de démarrage rapide.................................... 14
Schnellstartanleitung............................................. 27
Guida rapida ....................................................... 40
Snelstartgids ....................................................... 53
Guia de início rápido ............................................. 66
Guía de inicio rápido ............................................. 79

1
Quick Start Guide
Getting Started
1
4
6
7
8
5
2 3
NFC detection area
RESET button
Power button: Press once to power on the device, or
press and hold for at least three seconds to power it o󰀨.
WAN port: Connect to optical modems, broadband
modems, etc.
LAN port: Connect to a wired Internet device, such as a
computer.
Power port
H button Indicator
Scan the QR code to download and install the HUAWEI smart
device management app on your mobile phone or tablet.
Step 1: Install the app
If the app is already installed on your
phone, make sure you have the latest
version of the app.

2
Step 2: Connect the cables
Take out a router from HUAWEI WiFi Mesh, connect it to the
optical/broadband/cable modem using a network cable, then
connect it to a power supply.
Optical/broadband/cable modem
(from your broadband provider)
Router
Insert the cable to the
WAN port on the router
Internet
If the indicator is steady red, this indicates that the router is not
connected to the Internet. Please refer to "Step 3: Set up the
router".
POWER
RESET
WAN
LAN1
LAN2
LAN3
POWER
LA N
ADSL
RESET
LAN WAN
Step 3: Set up the router
Method 1: Congure the router on the app
Connect your mobile phone to the Wi-Fi
®of the router
connected to the modem (no password required). Check for
the Wi-Fi name on the bottom of the router.
1
WiFi
WiFi
Connected
Wi-Fi Name: XXXXXX

3
Open the app. After the app has detected the router, touch
CONFIGURE.
If the prompt box does not appear,
touch +.
2
CONFIGURE
LATER
Touch GET STARTED.
3
GET STARTED
4Enter your broadband account and password.
If your Internet connection does not require an account and
password, please skip to the next step.
Step 1
VLAN
Broadband account
Broadband password
CONNECT
If you need to congure VLAN on
your network, contact your broadband
carrier to conrm the VLAN
parameters, and enable the VLAN
switch on the screen.

4
Step 2
Wi-Fi name
Wi-Fi password
Tri-band
auto-selection
Enable Tri-band auto-selection: The 2.4 GHz and 5 GHz
Wi-Fi names will be the same. You will automatically connect
to the faster Wi-Fi network.
• Reconnect to the router's Wi-Fi to access the Internet.
• If the router cannot be congured on the app, congure the
router on the web-based management page by following the
instructions in Method 2.
Set a new Wi-Fi name, Wi-Fi password, and management
password for the new router.
5
NEXT
Connect to Wi-Fi

5
Method 2: Congure the router on the web-based
management page
Connect your mobile phone to the Wi-Fi of the router
connected to the modem (no password required). Check for
the Wi-Fi name on the bottom of the router.
1
2Open the browser and you will be automatically redirected
to the web-based management page (if the page is not
displayed automatically, enter "192.168.3.1" in the browser
address bar). Follow the onscreen instructions to congure
the router.
Let's get started
WiFi
WiFi
Connected
Wi-Fi Name: XXXXXX

6
The other router(s) in the HUAWEI WiFi Mesh is/are plug and
play.
Place the router(s) where Wi-Fi signal reception is poor, and
connect it/them to the power supply. Wait for approximately two
minutes until the indicator turns steady blue, indicating that the
router is connected to the network. You can also check their
network connection through the app.
Step 4: Connect the other router(s) to the
power supply
• For best results, place the routers within 10 meters of each other
with one wall in-between at most.
• All routers share the same Wi-Fi name and password. When you
move across rooms, you will automatically connect to the faster
Wi-Fi network.
• If a router's indicator is steady red, this means that it cannot
connect to the Internet. Please refer to "Indicator - Steady red"
below for more details.

7
Indicator
Steady blue: Connected to the Internet.
Steady red: Not connected to the Internet.
Flashing: The router has detected a pairable device.
When other HUAWEI routers (with Hor Hi button) are detected,
the indicator on the HUAWEI WiFi Mesh will ash. When
this happens, touch the HUAWEI WiFi Mesh's Hbutton. The
indicator should ash quickly, indicating that the pairable device
is connecting to the HUAWEI WiFi Mesh. The connection
process is complete when the indicator stops ashing.
• If you touch the Hbutton accidentally, wait for approximately
two minutes and the indicator will be back to normal
automatically.
• The Hbutton also features WPS functionality.
For the router that is connected to the modem:
• Ensure that the Ethernet cable is not loose and connected
correctly.
• Contact your carrier to check for any network failure.
For the router(s) that is/are not connected to the modem:
• Ensure that the distance between two routers is less than 10
meters and there are no more than two walls in between.

8
Frequently Asked Questions (FAQs)
1. What should I do if after conguring my router, my mobile
phone automatically connects to the Wi-Fi network of the
previously connected optical/broadband/cable modem
instead of the Wi-Fi network of my router?
2. What should I do if the router is not recognized on the
app?
It is recommended that you disable the Wi-Fi network of your
previous optical/broadband/cable modem to reduce potential
signal interference with your router.
• Ensure that you have the latest version of the app.
• Ensure that your phone is connected to the Wi-Fi network
of the router that is connected to the modem and is to be
congured.
• Ensure that all routers are new or restored to factory
settings.
• Ensure that the router's power supply is well connected. Wait
until the router completes the startup process and try again.
• Ensure that there are no more than two walls between your
phone and the router that you are conguring.
• Ensure that the distance between two routers is less than 10
meters and there are no more than two walls in between.
3. What should I do if I encounter any of the following issues
during the conguration of the router?
• If your phone cannot nd the router's Wi-Fi, ensure that the
router is connected to a power supply. Wait until the router
completes the startup process. Then try searching for the
router's Wi-Fi again on your phone.
• If "Internet cable not detected" is prompted, ensure that the

9
4. How do I restore the router to its factory settings?
Connect the router to the power supply and wait until the
router completes the startup process. Use a needle or pin
to press the RESET button on the router for more than two
seconds until the indicator light goes out. Wait for the router
to complete the restart process. When the indicator turns red,
this indicates that the router has been restored to its factory
settings.
If the problem persists, restore the router to its factory settings
and follow the instructions in this guide to reconnect the cables
and re-congure the router.
If the congured router has been restored to factory settings,
you need to congure it again. Then restore the other router(s)
to the factory settings so that it/they can automatically connect
to the congured router.
Ethernet cables are well connected and in good condition.
• If "Incorrect username or password" is prompted, re-enter
your broadband account and password. If the problem
persists, contact your carrier for assistance.
5. How do I connect an add-on HUAWEI router (with H/Hi
button) to my HUAWEI WiFi Mesh to expand the Wi-Fi
network?
You can connect the router in either of the following ways:
• Wired connection. Connect the WAN port of the add-on
router (new or restored to factory settings) to the LAN port of
the congured HUAWEI WiFi Mesh using an Ethernet cable.
• Wireless connection (using the Hbutton).
Step 1: Place the add-on router (new or restored to factory
settings) within one meter of the congured HUAWEI WiFi
Mesh and connect it to the power supply.

10
6. How do I connect a Wi-Fi device to my router using WPS?
When your router is powered on, touch its Hbutton, and then
press the WPS button on the Wi-Fi device (such as a phone)
within two minutes to initiate standard WPS negotiation and
connect the Wi-Fi device to the router's Wi-Fi network.
Step 2: When the indicator on the HUAWEI WiFi Mesh starts
to ash, touch the Hbutton on it. Wait until the indicator on
the add-on router shows it is connected to the network.
The following HUAWEI device models are supported: WS5800,
WS7100 and WS7200. For details about more device models,
see the device manual.
7. How do I use the NFC function of the router to quickly
connect to the Wi-Fi network?
Unlock your phone, enable NFC on it, and touch the NFC
area on the back against the NFC area on the router, then
follow the onscreen instructions to connect the phone to the
Wi-Fi network.
This feature is available on Android devices that support NFC,
but some devices with non-standard NFC may be unable to
connect. iOS devices do not support connecting through NFC.

11
Safety information
Operation and safety
• Do not use your device if using the device is prohibited. Do not
use the device if doing so causes danger or interference with other
electronic devices.
• Pacemaker manufacturers recommend that a minimum distance of
15 cm be maintained between a device and a pacemaker to prevent
potential interference with the pacemaker. If using a pacemaker,
hold the device on the side opposite the pacemaker and do not
carry the device in your front pocket.
• Avoid dusty, damp, or dirty environments. Avoid magnetic fields.
Using the device in these environments may result in circuit
malfunctions.
• Ideal operating temperatures are 0 °C to 40 °C. Ideal storage
temperatures are -40 °C to +70 °C. Extreme heat or cold may
damage your device or accessories.
• Keep the device and accessories in a well-ventilated and cool area
away from direct sunlight. Do not enclose or cover your device with
towels or other objects. Do not place the device in a container with
poor heat dissipation, such as a box or bag.
• The device should be installed and operated with a minimum
distance of 20 cm between the radiator and your body.
• Using an unapproved or incompatible power adapter, charger, or
battery may damage your device, shorten its lifespan, or cause a
re, explosion, or other hazards.
• For pluggable devices, the socket-outlet shall be installed near the
devices and shall be easily accessible.
• Unplug the power adapter from electrical outlets and the device
when not in use.
• Do not touch the device or the charger with wet hands. Doing so
may lead to short circuits, malfunctions, or electric shocks.
Disposal and recycling information
The symbol on the product, battery, literature, or packaging
means that the products and batteries should be taken to
separate waste collection points designated by local authorities
at the end of the lifespan. This will ensure that EEE waste is
recycled and treated in a manner that conserves valuable materials
and protects human health and the environment.

12
For more information, please contact your local authorities, retailer, or
household waste disposal service or visit the website
https://consumer.huawei.com/en/.
Reduction of hazardous substances
This device and its electrical accessories comply with local applicable
rules on the restriction of the use of certain hazardous substances in
electrical and electronic equipment, such as EU REACH regulation,
RoHS and Batteries (where included) directive. For declarations of
conformity about REACH and RoHS, please visit the website
https://consumer.huawei.com/certication.
EU regulatory conformance
Statement
Hereby, Huawei Devices Co., Ltd. declares that this device WS5800
is in compliance with the following Directive: RED 2014/53/EU, RoHS
2011/65/EU, ErP 2009/125/EC.
The full text of the EU declaration of conformity, the detailed ErP
information and most recent information about accessories & software
are available at the following internet address:
https://consumer.huawei.com/certication.
This device may be operated in all member states of the EU.
Observe national and local regulations where the device is used.
This device may be restricted for use, depending on the local network.
Restrictions in the 5 GHz band:
The 5150 to 5350 MHz frequency range is restricted to indoor use in:
AT, BE, BG, CH, CY, CZ, DE, DK, EE, EL, ES, FI, FR, HR, HU, IE, IS,
IT, LI, LT, LU, LV, MT, NL, NO, PL, PT, RO, SE, SI, SK, TR, UK (NI).
In accordance with the relevant statutory requirements in the UK, the
5150 to 5350 MHz frequency range is restricted to indoor use in the
United Kingdom.
Frequency Bands and Power
The frequency bands and transmitting power (radiated and/or
conducted) nominal limits applicable to this radio equipment are as
follows: Wi-Fi 2.4G: 20 dBm, Wi-Fi 5G: 5150-5350 MHz: 23 dBm,
5470-5725 MHz: 30dBm.
Legal Notice
Copyright © Huawei 2020. All rights reserved.

13
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND
DOES NOT CONSTITUTE ANY KIND OF WARRANTIES.
Trademarks and Permissions
Wi-Fi®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are trademarks
of Wi-Fi Alliance.
Other trademarks, product, service and company names mentioned
may be the property of their respective owners.
Version Update
In order to improve the security of the product and provide you with a
better user experience, we will push version update information to you
on a regular basis when an important update is released.
Privacy Policy
To better understand how we use and protect your personal
information, please read the privacy policy at
http://consumer.huawei.com/privacy-policy.
End User License Agreement
Please read and agree to the End User License Agreement (HUAWEI
EULA) on the product’s management page before using the product.
For More Help
Please visit https://consumer.huawei.com/en/support/hotline for
recently updated hotline and email address in your country or region.

14
Guide de démarrage rapide
Premiers pas
1
4
6
7
8
5
2 3
Zone de détection NFC
Bouton RESET
Bouton Marche/Arrêt : pour allumer l'appareil, appuyez une
fois ; pour l'éteindre, appuyer au moins trois secondes.
Port WAN : pour la connexion de modems optiques, de
modems haut débit, etc.
Port LAN : pour la connexion d'appareils Internet laires
(ordinateur, par exemple).
Port d'alimentation
Bouton H Voyant
Scannez le QR code pour télécharger et installer sur votre
téléphone portable ou votre tablette l'application HUAWEI
d'administration d'appareil intelligent.
Étape 1 : Installer l'application
Si l'application est déjà installée sur
votre téléphone, vériez que vous
avez bien sa version la plus récente.

15
Étape 2 : Connecter les câbles
Sortez un routeur HUAWEI WiFi Mesh, connectez-le au
modem optique/haut débit/laire à l'aide d'un câble réseau, puis
branchez-le sur un bloc d'alimentation électrique.
Modem optique/haut débit/laire
(provenant de votre fournisseur haut débit)
Routeur
Insérez le câble dans le port WAN du routeur.
Internet
Si le voyant est au rouge xe, cela indique que le routeur n'est
pas connecté à Internet. Reportez-vous à l'étape 3 : Congurer le
routeur.
POWER
RESET
WAN
LAN1
LAN2
LAN3
POWER
LA N
ADSL
RESET
LAN WAN
Étape 3 : Congurer le routeur
Méthode 1 : congurer le routeur dans l'application
Connectez votre téléphone portable au Wi-Fi®du routeur
connecté au modem (aucun mot de passe n'est exigé). Vous
trouverez le nom du réseau Wi-Fi (Wi-Fi Name) en bas du
routeur.
1
Wi-Fi
Wi-Fi
Connecté
Wi-Fi Name: XXXXXX

16
Ouvrez l'application. Après que l'application a détecté le
routeur, touchez CONFIGURER.
Si la boîte de dialogue n'apparaît
pas, touchez +.
2
CONFIGURER
ULTÉRIEUREMENT
Touchez COMMENCER.
3
COMMENCER
4Saisissez votre compte et votre mot de passe haut débit.
Si votre connexion Internet n'exige pas d'identiant (compte
et mot de passe), passez directement à l'étape suivante.
Étape 1
VLAN
Compte haut débit
Mot de passe haut débit
SE CONNECTER
Si vous devez congurer le réseau
local virtuel (VLAN) sur votre réseau,
contactez votre opérateur haut débit
pour conrmer les paramètres du
réseau local virtuel, puis activez le
bouton VLAN sur l'écran.
