Huawei LTE CPE E5172 User manual

1
Thank you for purchasing the CPE. This CPE brings you a high speed
wireless network connection.
This document will help you understand your CPE so you can start using it right away. Please read this
document carefully before using your CPE.
For detailed information about the functions and configurations of the CPE, refer to the online help on the web
management page that comes with the CPE.
Note:
You must install Adobe Reader version 6.0 or higher to read the online help.
Packing List
The following items are included in your CPE package. If any items are missing or damaged, please contact
your local dealer. If any of the optional accessories are not included in the package, you can contact an
authorized dealer to purchase them separately.
Item Quantity
LTE CPE 1
Power adapter 1
Quick Start Guide 1
Safety Information 1
Network cable 1
Battery (optional) 1
External antenna (optional) 1
Getting to Know Your CPE
Note:
The CPE function descriptions and illustrations in this document are for your reference only. The product
you have purchased may vary.

2
○
1Power indicator
Steady blue: The device is powered on. The power adapter is in use and working properly, or the power
adapter is not in use but the battery level is high.
Alternating blue and pink: The device is powered on. The power adapter is not in use or not working
properly, and the battery level is low.

3
Steady pink: The device is malfunctioning.
Note:
If your device malfunctions, power it off. Wait at least 15 minutes before you power it on again. If the
problem persists, contact your dealer.
Off: The device is powered off.
○
2WLAN indicator
On: WLAN function enabled
Blinking: Transmitting data through WLAN
Off: WLAN function disabled
○
3WPS indicator
On: WPS function enabled
Blinking: WPS interconnection verification is in progress. This process should not take longer than 2
minutes.
Off: WPS function disabled
○
4LAN indicator
On: The port is connected to a device.
Blinking: Data is being transmitted through the port.
Off: No device is connected to the port.
○
5Voice indicator
On: Off-hook condition
Blinking: Incoming call
Off: On-hook condition
○
6Signal indicator
On: Indicates network signal strength. Full light indicates strong signal.
Off: No network signal.
○
7WLAN button
Press and hold for more than 2 seconds to enable or disable the WLAN function.
○
8Reset button
Press and hold for more than 2 seconds to restore the device to its factory settings.
Note:
Restoring the default settings of the CPE will override all the previous settings.
○
9WPS button

4
After the WPS function is enabled, press and hold this button for more than 2 seconds to initiate WPS
interconnection.
○
10 External antenna port
Connect to an external antenna.
○
11 Power button
Press this button to power the device on or off.
○
12 Power port
Connect to the device's power adapter.
○
13 LAN port
Connect to computers, switches, or other network devices.
○
14 TEL port
Connect to a phone.
○
15 USIM card slot
Accommodate a USIM card.
○
16 Battery compartment
Install the battery.
○
17 Battery port
Insert the battery connection cable.
○
18 Back cover
Note:
On: An indicator is on.
Blinking: An indicator turns on and off at regular intervals.
Off: An indicator is off.
All indicators except the power indicator are blinking: The device is being upgraded or is restarting. To
avoid damage to the device, do not power off during this process.
Getting Started
Installing the USIM Card and the Battery
Install the USIM card and the battery according to the illustration.

5
Note:
Do not remove the USIM card when it is in use. Doing so will affect the performance of your CPE and
data stored on the USIM card may be lost.
The CPE automatically charges its battery when connected to a power source.
The battery is an optional accessory. If it is not included in the package, you may contact an authorized
dealer to buy a battery compatible with the CPE.
Connecting to a Power Adapter
Install the power adapter according to the illustration.

6
Note:
Only use power adapters compatible with the CPE and provided by a designated manufacturer. Use of
an incompatible power adapter or one from an unknown manufacturer may cause the CPE to
malfunction, fail, or could even cause a fire. Such use voids all warranties, whether expressed or
implied, on the product.
The CPE's power adapter model is HW-120100XYW, HW-120200XYW, HKA01212010-XY, or
HKA02412020-XY. X and Y represent letters or numbers that vary by region. For details about the
specific adapter model, contact an authorized dealer.
Connecting a Device to the CPE
Before connecting the device, please read the safety information carefully.
Note:
During thunderstorms and rainy weather, turn off and disconnect the device.
Use a standard or authorized external antenna to avoid device malfunctions.
Selecting the Installation Environment
Obstacles such as concrete and wooden walls will affect the transmission of the network signal. It is
recommended that when you install devices you choose an open space and ensure that there are no
obstructions between the computer and the device.
Keep the device away from equipment that generates strong magnetic and electric fields, for instance
microwaves, refrigerators, and satellite receivers.

7
Cable Connection
When connecting, use the power adapter that came as a set with the product. When finished, press the power
button to turn on the device.
The connection cable illustration is for reference only.
When the device is in use, you can alter its position or orientation to improve signal reception. The signal
strength light indicates the received signal strength.

8
Logging In to the Web Management Page
The web-based configuration utility can be used for initial device installation, parameter configuration, and
function management through the browser.
The Windows XP operating system and Internet Explorer 7.0 are used as an example. Ensure that the device is
connected to the computer. Follow these steps to log in to the web management page:
1. Connect device cables.
2. Configure the computer's IP address so that the IP addresses of the computer and the device are in the
same network segment.
Note:
The device's default IP address is 192.168.1.1, the subnet mask is 255.255.255.0.
It is recommended that you use the automatically obtained IP addresses for the computer and domain
name system (DNS) server. If you manually configure the computer IP address, you must set the DNS
server IP address to the device IP address. Otherwise, you will fail to log in to the web management
page.
3. Open the browser, and enter http://192.168.1.1 in the address box.
4. Enter the user name and password to log in to the web management page.
Note:
The default user name is admin.
The default password is admin.
LTE is a trademark of ETSI.
Version: V100R001_01Part Number: 31010***
