Installation Guide for Scotsman Flaker
Installation Guide for:
Scotsman MF - Modular Flakers (Electronic)

Installation Guide for Scotsman Flaker
Unpacking
•Remove the two banding strips securing equipment to pallet.
•Remove cardboard carton and packaging material.
•Inspect exterior of machine for any potential damage.
•Remove Front, Left & Right hand panels & release machine from the pallet
Remove from inside the machine:
•1 x water inlet tube
•1 x drain tube complete with clip
If a separate Storage bin is supplied –Unpack as suggested above, then open the
bin door and remove:
•1 x drain tube kit (complete with clip)
•1 x drain fitting (may be supplied separately !!)
•1 x Unit leg kit
Installation
Storage Bin:
Fix ‘Legs’ onto the base of the Storage bin
If required, install the drain fitting to the base of the storage bin (using PTFE tape
also) Secure correctly, the drain hose to the drain fitting using the clip supplied
Stand the storage bin upright and level the bin using the ‘adjustable legs’ as
appropriate
Check that the bin has the foam strip installed all around the top edge
Ice Machine Production Head:
Mount the machine onto the top of the Storage bin locate so to ensure the ‘Ice drop’
area of the unit is correctly placed. Secure the machine to the Storage bin !!
Again, check that the assembly is level. Adjust legs as required.

Installation Guide for Scotsman Flaker
Check the following:
•Ambient temperature - minimum 10°C, maximum 40°C
•Adequate space at rear of machine for water and drain connections.
•Minimum airflow clearance requirement of 15cm to both sides of machine.
Note: if clearance is less, ice production rate could decrease by as much as 25% due to
potential overheating if an Air Cooled version is used
Service Connections:
Check ID on rear of machine for correct voltage (e.g. 230 volt 50 hz for UK use)
Check that the following services are within 1 metre of machine location:
•Cold water supply terminated with a ¾ BSP washing machine style stop valve.
•Mains drainage with a connection point lower then the drain outlet of the machine.
Connection point must be at least 1 ¼" diameter open and trapped (similar to a
domestic washing machine) with any connection made to include a suitable ‘back
flow’ prevention device to ‘EN1717’.
•If drain is too high, a stand or condensate pump must be used for the bin only !!
•Suitable Electrical Supply (Due to potential high starting current, any socket adaptor
with other appliances should not be used.)
Note: If an external condensate tank pump is to be used, then an additional 13 amp socket outlets
will be required.
•Unit –Connect unit electrical cable to either a suitable Plug & socket
arrangement or connect direct into a suitable rated electrical isolator
NOTE - Ensure electrical supply has a correctly rated Circuit Breaker at the
distribution unit
•Fit ¾ water inlet hose to the machine. Do not overtighten.
•Fit flexible drain hose to machine and secure using clips provided.
Note: Both hose’s are fitted with one straight end and one angled end. Use which ever is the most
suitable for this installation.
•Connect water inlet hose to water supply ‘stop valve’. Do not overtighten.
•Connect drain hose to main waste drain provided by inserting hose into
upstand (similar to domestic washing machine).
Note: To prevent drainage problems caused by loops in the hose, reduce hose length as far as
reasonably practicable

Installation Guide for Scotsman Flaker
Start Up Procedure for MF Modular Models
•Turn on water and power supply (Green pushbutton on front panel).
•At this point, a GREEN LED will show and a RED LED flash, water should
then enter the machine and begin to fill the water tank.
•When the water tank is full, the float valve will stop incoming water with any
excess or overflow water possibly running out of the drain (Gravity drain !!)
•The machine should start an ice making cycle (this after approx 3 minutes)
with the compressor then in operation.
•After approximately 2-3 minutes, ice should become visible & fall from the
chute/spout area and into the storage bin. The machine will then continue to
fill to the ‘bin level sensor’ level
•Any adjustments to settings for ice consistency should be discussed with the
engineer installing the equipment or Hubbard Ice Technical Department in the
first instance.
NOTE - The above procedures are designed to supplement guidance given in the
user handbook, not replace it.
