Hueda led H-2819s User manual

RGBW RF Remote Control

1. Product Introduction:

Before you begin, read all warnings and installation instructions and save for future use.

1/3

Model: H-2819S

2. Product Dimension:

Four zones/areas

Press-button RGB+W controller

Receivers work with WIFI-RF converter to be controlled by smart phone

SR-2819S RGBW remote controller has 4 different zones. It can get Red/Green/Blue/White color

directly. The remote controller can save up to 3 colors or modes into corresponding buttons

(S1, S2, S3) for each zone. You can choose any color through color wheel. You can set the

system as RGB 3-channel output or RGBW 4 channel output.

120mm (4.72”)

55mm (2.16”)

17mm (0.66”)

ŸThis product is intended to be installed and serviced by a qualied licensed electrician. Install in accordance with

the National Electric Code, and local regulations. Disconnect power before installing or servicing. Only power with

a regulated (listed) constant voltage Class 2 power supply (12-24V DC).

ŸEnsure applicable wire is installed between driver, xture, and any controls in between. When choosing wire, factor

in voltage drop, amperage rating and type (in-wall rated, wet location rated, etc.). Inadequate wire installation

could overheat wires and cause re.

ŸThis product is rated for indoor installation and can be used for dry locations. Avoid the direct sun light.

ŸDo not modify this product beyond the instructions in this guide or the warranty will be voided.

ŸWiring diagrams in this installation guide for basic installations. Please carefully review your installation before

proceeding.

ŸAlways be sure to mount this unit in an area with proper ventilation to avoid overheating.

ŸPlease check if the output voltage of any LED power supplies used comply with the working voltage of the product.

ŸNever connect any cables while power is on and always assure correct connections to avoid short circuits before

switching on.

ŸPlease ensure that the cable is secured tightly in the connector

ŸFor updated information please consult your supplier.
