Hunnebeck BOSTA User manual

User guide
REINFORCEMENT
INSTALLATION SCAFFOLDS

2
Contents
Contents
1 Introduction................................................................................................................4
1.1 About this user guide............................................................................................................4
1.2 Other relevant documents...................................................................................................4
1.3 Conventions in this user guide...........................................................................................4
2 Safety ......................................................................................................................... 5
2.1 Intended use ...........................................................................................................................5
2.2 General safety information..................................................................................................6
2.3 Obligations of the operator.................................................................................................8
2.4 Personnelqualication .........................................................................................................8
2.5 Structure and characteristics of the information on hazards to persons................9
2.6 Structure and characteristics of the information on property damage....................9
2.7 Safety devices and protective equipment ......................................................................9
3 System overview .....................................................................................................10
3.1 BOSTAstandardcongurations........................................................................................ 11
3.2 MODEXstandardcongurations ......................................................................................17
4 Components............................................................................................................ 27
4.1 Basic cross-system components .....................................................................................27
4.2 BOSTA system ..................................................................................................................... 30
4.3 MODEX components ......................................................................................................... 36
4.4 System-free accessories................................................................................................... 39
5 Preparation for assembly .......................................................................................41
5.1 Complying with regulations............................................................................................... 41
5.2 Planning principles .............................................................................................................. 41
5.3 Checking the components ................................................................................................ 41
5.4 Preparing the ground......................................................................................................... 42
6 ErectingBOSTAreinforcementinstallationscaolds....................................... 43
6.1 Creating connections using drop latches......................................................................43
6.2 Preparingtherstscaoldbay ........................................................................................44
6.3 Attaching the plank .............................................................................................................47
6.4 Attaching the Base Jack Securing Device ................................................................... 48
6.5 Increasing stability.............................................................................................................. 49
6.6 Attachingthescaoldbayattheside........................................................................... 50
6.7 Attachingtheupperscaoldbay..................................................................................... 51
6.8 Installing Compression Bearings .................................................................................... 64
7 ErectingtheMODEXreinforcementinstallationscaold................................. 65
7.1 Creating connections with the MODEX node ............................................................. 65
7.2 Preparing the ground......................................................................................................... 66
7.3 Assemblingthescaoldbay.............................................................................................67
7.4 Attachingthescaoldbayattheside........................................................................... 69
7.5 Increasing stability.............................................................................................................. 69
7.6 Attaching the Base Jack Securing Device ................................................................... 70
7.7 Attaching planks.................................................................................................................. 70
7.8 Installing the guard rails .....................................................................................................72
7.9 Attaching toe boards and lifting retainers.....................................................................73
7.10 Attachingtheupperscaoldbay.....................................................................................76
7.11 Installing Compression Bearings .....................................................................................77

3
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
8 Checks before use.................................................................................................. 78
9 Movingthescaoldwithacrane......................................................................... 78
9.1 MovingtheMODEXscaold.............................................................................................78
10 Temporarystorageofthescaold....................................................................... 79
11 Dismantlingthescaolds...................................................................................... 80
11.1 DismantlingtheBOSTAreinforcementinstallationscaold.................................... 80
11.2 DismantlingtheMODEXreinforcementinstallationscaold .................................. 80

4
Introduction
Unless stated otherwise, all dimensions in mm.
1 Introduction
1.1 About this user guide
This user guide describes the safe assembly and use of reinforcement installation scaf-
foldsfromtheBOSTAandMODEXsystems.Thereinforcementinstallationscaoldsare
referredtoas"scaolds"inthisuserguide.
Theactivitiesdescribedinthisuserguideincludetheerectionofscaoldswithupto
twolevelsandalevelheightoftwometres.Scaoldsthatexceedthisarepossibleafter
consultation with HÜNNEBECK.
This user guide is intended for commercial users with appropriate technical training.
The information and procedures described here comply with the laws and the occupa-
tional health and safety regulations of Germany and Austria. HÜNNEBECK accepts no
responsibility for the use of this user guide outside this area of application.
Read this user guide carefully before working with this product. Keep the user guide for
future reference.
Theuserguideisanessentialcomponentofthereinforcementinstallationscaolds.It
containssafetynotes,informationonthestandardconguration,theintendeduseand
a description of the system. It facilitates taking into account the requirements of the
German ordinance on industrial safety and health ("Betriebssicherheitsverordnung") in
the respective assembly and use situation.
Weexplicitlyreservetherighttomakechangesresultingfromtechnicalimprovements.
Availability of the user guide
The contractor has to ensure that site personnel are familiar with the user guide pro-
vided by HÜNNEBECK and that it is readily accessible at all times. The user guide must
be legible and complete. A replacement user guide can be obtained from HÜNNEBECK.
1.2 Other relevant documents
Fortheapplicationanduseoftheproducts,allcurrentcountry-speciclaws,standards
and other safety regulations are to be complied with. They form a part of the obliga-
tions of employers and employees regarding occupational and industrial safety.
1.3 Conventions in this user guide
Variouselementsofthisuserguideareprovidedwithdeneddesignfeatures.This
makes it possible to easily distinguish between the following elements:
Normaltext
• Lists
• Secondary lists
Intheseinstructions,guidelinesarealwaysidentiedwiththeword"Step,"e.g.
Step 1 Align the base frame horizontally by adjusting the base jacks.
TIP Tip!
Tipssharepracticalexperiencewiththeuser,e.g.howtoperformataskmoreeasilyor
quickly.

5
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
Directional terms
In this user guide, the directions are indicated as follows:
• Thereinforcementsideofthescaoldisthelongsideofthescaoldonwhichthe
reinforcement is to be erected.
• Theoutersideisthelongsideofthescaoldfacingawayfromthereinforcement.
• Theendfacesarethenarrowsidesofthescaold.Scaoldscanbeconnectedto
one another at the end faces.
2 Safety
2.1 Intended use
HÜNNEBECKreinforcementinstallationscaoldsareworkequipmentintendedforcom-
mercial use only. They serve as a working platform for reinforcement work in building
construction and can be used as:
• Workingscaoldsinloadclass4accordingtoDINEN12811-1(withoutpassageplank)
• Workingscaoldsinloadclass3accordingtoDINEN12811-1(withpassageplank)
Based on the hazard assessment that the erector or user is required to compile as
speciedintheGermanordinanceonindustrialsafetyandhealth,theerectororuseris
responsible for using his own discretion to implement essential preventive measures.
Thespecicsofeachcasemustalwaysbetakenintoconsideration.
• Only the components shown in this user guide have been proven to be structurally
stable.Specialcasesrequireseparatecerticationtakingintoconsiderationthe
expectedloads.
• Whenusingthereinforcementinstallationscaolds,allstatutoryandotherregu-
lations applicable at the site of use must be observed, in particular all regulations
relating to occupational safety.
The equipment may be used only by properly trained personnel under the authority
ofqualiedsupervisors.Theworkonthereinforcementinstallationscaoldsmustbe
supervisedbyaproperlyqualiedsupervisor,speciedbythecontractor,whoensures
that the work is carried out safely.
OnlytheuseofcomponentsfromtheMODEXandBOSTA70/100systemsdescribedin
thisuserguideisconsideredintended.Extensions,deviationsorchangesareonlyper-
mitted with separate proof. This proof must be requested from the manufacturer.
All other uses are considered to be unintended. This applies in particular to additions,
deviations or changes to this user guide without the consent of HÜNNEBECK.
HÜNNEBECK is not responsible for any misconduct on the part of the contractual part-
ner if the latter does not comply with the applicable laws and guidelines on equipment
and work performance.

6
Safety
Unless stated otherwise, all dimensions in mm.
2.2 General safety information
2.2.1 Risk of fatal injury
Risk of fatal injury from using damaged or unsuitable components!
Damaged components may result in a diminished load-bearing capacity or failure of
componentsofthescaold.
• Checkthatallcomponentsareinawlessconditionbeforeuseandatthespecied
intervals.
• Do not use damaged or unsuitable components.
• Contact HÜNNEBECK if there are any doubts about potentially harmful factors.
• Have damaged components repaired immediately or replace damaged components
with new ones of the same type.
• Dispose of damaged components that cannot be repaired.
OnlycomponentsthatmeettherequirementsspeciedinthesectionIntended use are
suitable.
Donotrepair,modifyoralteranycomponentsofthescaoldswithoutwrittenpermis-
sion from HÜNNEBECK.
Riskoffatalinjuryduetounauthorisedmodicationorreplacementofcomponents!
Replacing or modifying components may result in a risk of falling due to component
failure.
• Onlyusethesuitablecomponentsspeciedinthisuserguide.
• Donotmakeanychangestocomponentswithouttheexpressconsentof
HÜNNEBECK.
• Do not repair any components.
• Replace damaged components with new ones of the same type.
Riskoffatalinjuryduetoincorrectassemblyormovingofthescaold!
Incorrect assembly of components can lead to a risk of falling due to component failure.
• Only assemble the components as described and illustrated in this user guide, or
provide evidence of alternatives by means of a suitable hazard assessment.
• Ensurethatthemaximumload-bearingcapacityofthecomponentsisnotexceeded.
• Ensurethatthegroundissucientlyload-bearingfortheloadofthescaold,includ-
ing all persons working on it and the stored material.
• When assembling the equipment, observe and follow all legal regulations and other
directives applicable at the place of use as well as the assembly instructions of the
operator.
• Ensurethatonlysuitablyqualiedpersonsassemblethescaold.
• Havethescaoldcheckedbyaqualiedpersonafterassemblyormoving.
InformationonthequalicationsrequiredcanbefoundintheSection Personnel quali-
cation on page 8.

7
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
Riskoffatalinjuryintheeventoffallingfromthescaoldduetomissingcompo-
nents or mounting parts!
Missing, damaged, incorrectly or inadequately fastened mounting parts may cause the
scaoldtofallduetoadiminishedload-bearingcapacity.
• Do not use any damaged components.
• Ensurethatallbarriers,decksandguardrailsarettedtothescaoldasdescribed
and illustrated in this user guide.
• Ensure that all mounting parts are securely attached.
Riskoffatalinjuryintheeventoffallingfromthescaoldduetomissingorincor-
rectly mounted fall protection!
Aguardrailattachedtothescaoldmayexceedtheloadlimitsofthescaold.
• Makesurethatallareasofthescaoldthatarenotsecuredbyaproperlyinstalled
and complete guard rail (unsecured area) are clearly separated from the secured
areas by a temporary barrier.
• Allpersonsenteringanunsecuredareaofthescaoldmustbeprotectedbymeans
of additional, separate fall protection.
• Attach the personal fall protection (harness) to suitable, load-bearing structures that
areindependentofthescaold.
Risk of fatal injury due to falling components if the load limits are exceeded!
Ifthescaoldissubjectedtoimpermissiblyhighloads,componentsmaycomeloose.
This poses a risk of falling and of serious injury from falling parts.
• Assemblethescaoldonlyasdescribedandshowninthisuserguide,ordemon-
strate alternatives by means of a suitable hazard assessment.
• Makesurethatthemaximumload-bearingcapacityofthecomponentsisnot
exceeded.
• Subjectthecomponentsofthescaoldtoloadsonlyinaccordancewiththespeci-
cationsinthisuserguideandthestaticcalculationsforthespecicapplication.
• Make sure that all load-bearing components and fastenings can support the antici-
pated load and are not overloaded.
• OnlycomponentsthatmeettherequirementsspeciedinthesectionIntended use
are suitable.
2.2.2 Risk of serious injury
Risk of injury from falling objects!
Componentsthatarenotproperlysecuredormaterialstoredonthescaoldmayfall
oandcauseseriousinjury.
• Secure all components properly and as described in this user guide.
• Ensure that all mounting parts are securely attached.
• Properly secure material stored on the framework.
• Makesurethattheload-bearingcapacityoftheframeworkisnotexceeded.
• EnsurethatallpersonsworkingonthescaoldweartheprescribedPPE.
• Whenmovingit,makesurethattherearenopersonsunderthescaold.

8
Safety
Unless stated otherwise, all dimensions in mm.
2.3 Obligations of the operator
Theoperatormustensurethatonlypersonnelwithknowledgeandexperienceinthe
useofthescaoldandallrelevantsafetyregulationsworkonandwiththescaold.All
otherpersonsmayonlyaccessthescaoldunderthedirectsupervisionandinstruction
of a person with this knowledge.
2.3.1 Responsible supervisor
The operator must ensure that all work is carried out under the supervision of a spe-
cially trained person. This person must have knowledge and skills in the following
areas:
• Accident prevention measures
• Determinationandestimationoftheloadlimitsofthescaold,takingintoaccountall
relevant factors and regulations
2.3.2 Preparing a hazard assessment and assembly instructions
The operator must prepare a hazard assessment and assembly instructions for the
specicapplication.Thehazardassessmentandtheassemblyinstructionshavetotake
intoaccountallcomponentsofthescaold.
Theassemblyinstructionsmustcontainprecisespecicationsforthespecicapplica-
tion. It is essential that they contain the following points:
• Calculation of the loads in the current case
• Assessment of the hazard potential at the point of use
• Determinationofdangerareasinthespecicapplication
• Determination of suitable safety measures and protective equipment
This user guide does not replace the assembly instructions or the hazard assessment.
The operator is responsible for the compilation, documentation, implementation and
revision of a hazard assessment for each construction site. His employees are obliged
to implement the resulting measures in accordance with all legal requirements.
The operator is responsible for compiling written assembly instructions that contain
specicationsforthespecicapplication.Theuserguideisafundamentalbasisfor
the assembly instructions. HÜNNEBECKsuppliesfurtherspecicationsandcalculation
bases for this on request.
2.3.3 Keeping user guide available
The contractor must ensure that site personnel are familiar with the user guide pro-
vided by HÜNNEBECK before assembling or using the equipment and that the user
guide is accessible at all times. The user guide must be legible and complete. A
replacement user guide can be obtained from HÜNNEBECK.
2.3.4 Carrying out measures on site
Theoperatormustobserveallapplicableregulationsforthespeciclocation.Inpartic-
ular, he must carry out or initiate the following measures:
• Provide personal protective equipment (PPE).
• Deneareasforstoringthematerial.
2.4 Personnelqualication
Onlypersonswithknowledgeandexperienceintheerection,modicationanddisman-
tlingofreinforcementinstallationscaoldsmaycarryoutthiswork.
Aqualiedmanagerwithsucienttechnicalexpertise,appointedbytheoperator,has
tooverseeerectionofthescaold.Erectionofthescaoldhastobeoverseenbya
supervisorwhoisresponsibleforthesafeexecutionofthework.Thesupervisormust
havesucientknowledgeandexperience.

9
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
2.5 Structure and characteristics of the information on hazards to persons
DANGER DANGER!
DANGER indicates a hazardous situation that, if not avoided,
will cause death or serious injury.
WARNING WARNING!
WARNING indicates a hazardous situation that, if not avoided,
can cause death or serious injury.
CAUTION CAUTION!
CAUTION indicates a hazardous situation that, if not avoided, can cause minor or mod-
erate injury.
2.6 Structure and characteristics of the information on property damage
NOTE NOTE!
NOTE indicates a hazard that can cause property damage.
2.7 Safety devices and protective equipment
2.7.1 Safety devices
Side protection
Eachworkinglevelofthereinforcementinstallationscaoldmustbeequippedwith
three-partsideprotection.Thesideprotectionmustbeprovidedontheexteriorandon
both end faces. On the interior (reinforcement side), side protection is only required if
thescaoldismorethan0.30mawayfromthereinforcement.
The side protection consists of the following parts:
• Toe board
• Tube ledger as knee rail
• Tube ledger as guard rail
Temporary side protection
The temporary side protection allows assembly to be performed without wearing PPE
to prevent falling from heights. This includes AGR posts, AGR railings and the associ-
ated side protection.
Stage Bracket
Thewidthofthestandingareaonthereinforcementinstallationscaoldmustalways
bescaled1:3orgreaterinproportiontotheheightofthereinforcementinstallation.If
necessary,astagebracketcanbeaddedtoextendthestandingarea.
Whenthescaoldisstoredfree-standing,therehastobeastagebracketonbothlong
sidesorothermeasuresmustbetakentopreventthescaoldfromtippingover.

10
System overview
Unless stated otherwise, all dimensions in mm.
2.7.2 Personal protective equipment (PPE)
Personal protective equipment (PPE) must be used for all work on and with the scaf-
folds. The PPE has to comply with the regulations applicable at the place of use for the
work to be carried out. The supervisor appointed by the operator shall ensure that the
appropriate PPE is available and worn by all persons in the hazardous area.
The PPE always consists of at least the following components:
• Safety helmet
• Safety glasses
• Safety gloves
• Safety shoes, class 3
The operator must specify further components of the PPE in the assembly instructions
forthespecicapplicationandtheworktobeperformed.
3 System overview
The HÜNNEBECKscaoldsystemsBOSTA70,BOSTA100andMODEXmeetthe
requirementsofDIN4420,DINEN12810andDINEN12811asworkingandprotective
scaold.BOSTA70,BOSTA100andMODEXeachhaveaGermantechnicalapproval
forthestandardcongurationasworkingandprotectivescaoldsaccordingtothe
German Institute for Structural Engineering ("Deutsches Institut für Bautechnik", DIBt)
approval guidelines.
Manufacturing and labelling of the components are regulated in the German technical
approvalZ-8.1-54.2forBOSTA70,Z-8.1-150forBOSTA100orZ-8.22-67forMODEX.

11
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
3.1 BOSTAstandardcongurations
3.1.1 System overview
12
31
11
10
7
9
8
6
5
2
4
Item number Designation Description Assembly
1 Guard Rail Page 31 Page 54
2 Plank Page 27 Page 47
3 Compression Bearing Page 40 Page 64
4 Cross Pipe Page 40 –
5 Vertical Frame BOSTA 70: Page 32
BOSTA 100: Page 33
Page 44
6 Double Rail BOSTA 70: Page 32
BOSTA 100: 34
Page 51
7 Base Jack Securing
Device
Page 27 Page 48
8 Ladder Page 28/39 Page 47
9 Base Jack Page 27 Page 44
10 Diagonal Page 31 Page 45
11 Stage Bracket Page 31 Page 49
12 Toe Board Page 29 Page 61
13 Ladder Page 28/39 Page 47

12
System overview
Unless stated otherwise, all dimensions in mm.
3.1.2 Standardcongurations
Type Interior side protection Height Length Width Load-bearing capacity
1 Without 2000 5000 700 LC 3
2 With 2000 5000 700 LC 3
3 Without 4000 5000 700 LC 3
4 With 4000 5000 700 LC 3
Allofthereinforcementinstallationscaoldsmentionedherecanbemovedusing
hoisting equipment.
WARNING Warning!
Whenmovingthescaoldwithliftingequipment,allverticalframesmustbeconnected
with frame pins or screws such that they are resistant to tension. Secure the base jacks
with the base jack securing device to prevent them from falling out. Secure the base
jacks used on stage brackets with wing nuts to prevent them from falling out.
TheverticalframesoftheBOSTA100scaoldsmustbeconnectedwith12mmframe
pinsorM12screws.
TheverticalframesoftheBOSTA70scaoldsmustbeconnectedwith8mmframe
pinsorM8screws.

13
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
Type 1
Required materials:
Part code Component Quantity Part code Component Quantity
144131 BaseJack50/3.3 6 426545 WingNut30/150 3
652044 VerticalFrame200/70,light 3 651762 Base Jack Securing Device 6
116370 HalfCoupler48/Gw.a.f.22 3 422753 Ladder Lock 1
2113 Guard Rail 250 8 652880 Twin-Railing Post 70 Trans, light 2
110020 Diagonal 200 2 652114 Railing Post 70N, light 1
465031 AluPassagePlank250/70with
Ladder 1 651977 ToeBoard250/15 2
531334 HollowBoxPlank250/32 2 651991 ToeBoard74/15Trans 2
424226 Stage Bracket 70 3 61312 Ø 8 mm Frame Pin 6
540575 BaseJack70/3.8 3 169012 ScaoldTube48.3/100 6
2525 SwivelCoupler48/48w.a.f.22 6 2514 RigidCoupler48/48w.a.f.22 6

14
System overview
Unless stated otherwise, all dimensions in mm.
Type 2
With two-part side protection for the interior plane!
Required materials:
Part code Description Quantity Part code Description Quantity
144131 BaseJack50/3.3 6 422753 Ladder Lock 1
652044 VerticalFrame200/70,light 3 652880 Twin-Railing Post 70 Trans, light 2
116370 HalfCoupler48/Gw.a.f.22 7 133120 Single Post 70 2
2113 Guard Rail 250 12 417348 Plank Retainer 74 cpl. 1
110020 Diagonal 200 2 651977 ToeBoard250/15 2
465031 AluPassagePlank250/70with
Ladder 1 651991 ToeBoard74/15Trans 2
531334 HollowBoxPlank250/32 2 61312 Ø 8 mm Frame Pin 6
424226 Stage Bracket 70 3 169012 ScaoldTube48.3/100 6
540575 BaseJack70/3.8 3 2525 SwivelCoupler48/48w.a.f.22 6
426545 WingNut30/150 3 2514 RigidCoupler48/48w.a.f.22 6
651762 Base Jack Securing Device 6

15
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
Type 3
Required materials:
Part code Description Quantity Part code Description Quantity
144131 BaseJack50/3.3 6 651762 Base Jack Securing Device 6
652044 VerticalFrame200/70,light 6 422753 Ladder Lock 1
116370 HalfCoupler48/Gw.a.f.22 3 652880 Twin-Railing Post 70 Trans, light 2
2113 Guard Rail 250 12 652114 Railing Post 70N, light 1
110020 Diagonal 200 4 534419 Double Railing 70 Trans 2
465031 AluPassagePlank250/70with
Ladder 2 651977 ToeBoard250/15 4
531334 HollowBoxPlank250/32 4 651991 Double Railing 70 Trans 4
424226 Stage Bracket 70 3 61312 Ø 8 mm Frame Pin 12
540575 BaseJack70/3.8 3 169012 ScaoldTube48.3/100 6
426545 WingNut30/150 3 2525 SwivelCoupler48/48w.a.f.22 6
2514 RigidCoupler48/48w.a.f.22 6

16
System overview
Unless stated otherwise, all dimensions in mm.
Type 4
With two-part side protection for the interior plane!
Required materials:
Part code Description Quantity Part code Description Quantity
144131 BaseJack50/3.3 6 422753 Ladder Lock 1
652044 VerticalFrame200/70,light 6 652880 Twin-Railing Post 70 Trans, light 2
116370 HalfCoupler48/Gw.a.f.22 3 652114 Railing Post 70N, light 1
2113 Guard Rail 250 20 534419 Double Railing 70 Trans 2
110020 Diagonal 200 4 417348 Plank Retainer 74 cpl. 1
465031 AluPassagePlank250/70with
Ladder 2 651977 ToeBoard250/15 4
531334 HollowBoxPlank250/32 4 651991 ToeBoard74/15Trans 4
424226 Stage Bracket 70 3 61312 Ø 8 mm Frame Pin 12
540575 BaseJack70/3.8 3 169012 ScaoldTube48.3/100 6
426545 WingNut30/150 3 2525 SwivelCoupler48/48w.a.f.22 6
651762 Base Jack Securing Device 6 2514 RigidCoupler48/48w.a.f.22 6

17
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
3.2 MODEXstandardcongurations
3.2.1 System overview
10
11
2
1
9
7
5
6
4
3
8
Item number Component Description Assembly
1 Side protection Page 37 Page 66
2 Plank Page 27 Page 70
3TubeLedger/Com-
pression Bearing
Page 27 Page 64
4 Transom U Page 37 Page 66
5 Base Jack Securing
Device
Page 27 Page 70
6 V-diagonal Page 36 Page 67
7 Base Jack Page 27 Page 66
8 Ladder Page 28/39 Page 70
9 Enlargement Bracket Page 31 Page 69
10 Vertical Post Page 36 Page 67
11 Toe Board Page 29 Page 77

18
System overview
Unless stated otherwise, all dimensions in mm.
3.2.2 Standardcongurations
Type Interior side protection Height Length Width Load-bearing capacity
1 Without 2000 4000 820 LC 3
2 With 2000 4000 820 LC 3
3 Without 2000 4000 1130 LC 3
4 With 2000 4000 1130 LC 3
5 Without 4000 4000 820 LC 3
6 With 4000 4000 820 LC 3
7 Without 4000 4000 1130 LC 3
8 With 4000 4000 1130 LC 3
Allofthereinforcementinstallationscaoldsmentionedherecanbemovedusing
hoisting equipment.
WARNING Warning!
Whenmovingthescaoldusingliftingequipment,allpostjointshavetobesecured
with M12screwsor12mmframepinssuchthattheyareresistanttotension.Secure
the base backs with the base jack securing device to prevent them from falling out.
Secure the base jacks used on support brackets with wing nuts to prevent them from
falling out.

19
Unless stated otherwise, all dimensions in mm.
Reinforcementinstallationscaolds
Type 1
820
Required materials:
Part code Component Quantity Part code Component Quantity
470907 Vertical Post 300 5 465031 AluPassagePlank250/70with
Ladder 1
470892 Vertical Post 200 1 651742 SteelPlank82/15Trans 2
470940 Tube Ledger 250 10 470962 Transom 82U 3
651472 Side Protection 250 2 479047 Lifting Retainer 82* 3
470930 Tube Ledger 82 11 424226 Stage Bracket 70 3
651477 Side Protection 82 2 651762 Base Plate Securing Device 6
577863 Tube Ledger 25 3 540575 BaseJack70/3.8 9
470973 V-diagonal200/250 2 426545 WingNut30/150 3
427973 SteelPlank250/32 2 470929 Starting Piece 6
531448 SteelPlank250/15 2 422753 Ladder Lock 1
* Alternative:
LiftingRetainerTube82(partcode:651430)and2no.ConnectionParts(partcode:
651440)

20
System overview
Unless stated otherwise, all dimensions in mm.
Type 2
With two-part side protection for the interior plane!
820
Required materials:
Part code Component Quantity Part code Component Quantity
470907 Vertical Post 300 6 465031 AluPassagePlank250/70with
Ladder 1
470892 Vertical Post 200 - 651742 SteelPlank82/15Trans 2
470940 Tube Ledger 250 12 470962 Transom 82U 3
651472 Side Protection 250 4 479047 Lifting Retainer 82* 3
470930 Tube Ledger 82 11 424226 Stage Bracket 70 3
651477 Side Protection 82 2 651762 Base Plate Securing Device 6
577863 Tube Ledger 25 3 540575 BaseJack70/3.8 9
470973 V-diagonal200/250 2 426545 WingNut30/150 3
427973 SteelPlank250/32 2 470929 Starting Piece 6
531448 SteelPlank250/15 2 422753 Ladder Lock 1
* Alternative:
LiftingRetainerTube82(partcode:651430)and2no.ConnectionParts(partcode:
651440)
