Husky 8200445 User manual

Item # 0000000000
Model # 8200445
THANK YOU
We appreciate the trust and confidence you have placed in Husky through the purchase of this vacuum. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Husky!
USE AND CARE GUIDE
4 GALLON PORTABLE POLY WET/DRY VACUUM
Questions, problems, missing parts?
Before returning to the store, call
Husky Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday,
9 a.m. – 6 p.m., EST, Saturday
1-888-HD-HUSKY
HUSKYTOOLS.COM

2
Table of Contents
Safety Information.........................................................2
Warranty.........................................................................3
Pre-Assembly ................................................................4
Assembly........................................................................6
Operation .......................................................................7
Care and Maintenance ................................................. 8
Care and Cleaning ........................................................ 9
Troubleshooting............................................................ 9
Service Parts ................................................................. 10
Safety Information
IMPORTANT SAFETY INSTRUCTIONS
SAVE THIS MANUAL FOR FUTURE USE.
When using an electrical appliance, basic precautions should
always be followed, including the following: READ ALL
INSTRUCTIONS BEFORE USING THIS APPLIANCE.
1. Do not leave appliance when plugged in. Unplug from outlet
when not in use and before servicing.
2. Do not expose to rain. Store indoors.
3. Always disconnect the plug from the wall outlet before
removing the tank cover.
4. Do not use as a toy. Close attention is necessary when used
by or near children.
5. Do not use with a damaged cord or plug. If appliance is not
working as it should, has been dropped, damaged, left
outdoors or dropped into water, contact the service center
for assistance.
6. Do not pull or carry by cord, use the cord as a handle, close
a door on the cord or pull the cord around sharp edges or
corners. Do not run appliance over cord. Keep cord away
from heated surfaces.
7. Do not unplug by pulling on the cord. To unplug, grasp the
plug, not the cord.
8. Do not handle the plug or appliance with wet hands.
9. Do not put any object into openings. Do not use with any
openings blocked; keep the openings free of dust, lint, hair
and anything that may reduce airflow.
10. Keep hair, loose clothing, fingers and all parts of body away
from openings and moving parts.
11. Do not pick up anything that is burning or smoking, such as
cigarettes, matches or hot ashes.
12. Do not use without dust bag and/or filters in place.
13. Turn off all controls before unplugging.
14. Use extra care when cleaning on stairs.
15. Do not use to pick up flammable or combustible liquids such
as gasoline or use in areas where they may be present.
16. Do not use your cleaner as a sprayer of flammable liquids
such as oil-based paint, lacquers, etc.
17. Do not vacuum toxic, carcinogenic, combustible or other
hazardous materials such as asbestos, arsenic, barium,
beryllium, lead, pesticides or other health endangering
materials.
18. Do not pick up soot, cement, plaster or drywall dust without
a filter and dust bag in place. These are very fine particles
that may affect the performance of the motor or be
exhausted back into the air. Additional dust bags are
available.
19. Do not leave the cord lying on the floor once you have
finished the cleaning job. It can become a tripping hazard.
20. Use special care when emptying heavily loaded tanks.
21. To avoid spontaneous combustion, empty the tank after
each use.
22. The operation of a utility vacuum can result in foreign
objects being blown into eyes, which can result in eye
damage. Always wear safety goggles when operating
vacuum.
23. STAY ALERT. Watch what you are doing and use common
sense. Do not use vacuum cleaner when you are tired,
distracted or under the influence of drugs, alcohol or
medication causing diminished control.
24. This appliance is provided with double insulation. Use only
identical replacement parts. See instructions for servicing
double insulated appliances.
25. Unplug before connecting the hose, nozzles, filters, or other
accessories.
DANGER: Never operate this unit when flammable
materials or vapors are present because electrical devices
produce arcs or sparks that can cause a fire or explosion.
WARNING: Read all safety rules carefully before
attempting to operate. Retain for future reference. NEVER
LEAVE OPERATING VACUUM UNATTENDED!
CAUTION: If the supply cord is damaged, it must be
replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.

MOC.SLOOTYKSUH3
SUH-DH-888-1tcatnocesaelP KY for further assistance.
Safety Information (continued)
CAUTION: Remove the plug from the socket before
performing maintenance. Before using the machine make
sure that the frequency and voltage shown on the rating
plate correspond with the mains voltage. Specifications and
details are subject to change without prior notice. The
accessories shown in the pictures may vary from model to
model.
NOTICE: Use only as described in this manual. Use only
manufacturer's recommended attachments. This Wet/Dry Vacuum is
intended for household use only.
SERVICING OF A DOUBLE-INSULATED
WET/DRY VACUUM
In a double-insulated Wet/Dry Vacuum, two systems of insulation
are provided instead of grounding. This means that no grounding
is provided on a double-insulated appliance, nor should a means
for grounding be added. Servicing a double-insulated Wet/Dry
Vacuum requires extreme care and knowledge of the system and
should be done only by qualified service personnel. Replacement
parts for a double-insulated Wet/Dry Vacuum must be identical to
the parts they replace. Your double-insulated Wet/Dry Vacuum is
marked with the words "DOUBLE INSULATED" and the symbol
(square within a square) may also be marked on the appliance.
To reduce the risk of injury from electrical shock:
1. This appliance has a polarized plug (one blade is wider than
the other). This plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to
install the proper outlet. Do not change the plug in any way.
2. Unplug the power cord before servicing the electrical parts
of the Wet/Dry Vac.
SAVE THIS MANUAL
Warranty
HUSKY 2 YEAR LIMITED WARRANTY
If within two years from date of purchase, this Husky product fails due to a defect in materials or workmanship, return the product to any The
Home Depot retail store with a receipt indicating proof of purchase for replacement with an item of equal or greater value. This warranty
excludes incidental/inconsequential damages and failures due to misuse, abuse or normal wear and tear. This warranty gives you specific
rights, and you may also have other rights, which vary from state to state. Please see store or call 1-888-HD-HUSKY for details.

4
Pre-Assembly
PACKAGE CONTENTS
Key No. Description Quantity
A
1
1
eldnaH
1hctiwsffO/nOB
2hctaLC
D Vacuum port inlet
1knattsuDE
1tropgniwolBF
1koohdrocrewoPG
4redlohyrosseccAH
4retsaCI
1esoHJ
1Floor nozzleK
3dnawnoisnetxEL
M
1
1
retlifmaoFN
J K L M N
Cartridge filter - replace with multi-fit
cartridge filter
B
D
E
A
C
F
G
H
I

TOOLS REQUIRED
Phillips Screw Driver
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA Screw ST 3.9X16F 4
Pre-Assembly
AA
MOC.SLOOTYKSUH5
SUH-DH-888-1tcatnocesaelP KY for further assistance.

6
Assembly
WARNING: To reduce the risk of fire or explosion, do not operate this vacuum in areas with flammable gases, vapors or explosive
dust in the air. Flammable gases or vapors include but are not limited to: lighter fluid, solvent-type cleaners, oil-based paints, gasoline,
alcohol or aerosol sprays. Explosive dusts include but are not limited to: coal, magnesium, aluminum, and grain or gun powder. Do not
vacuum explosive dust, flammable or combustible liquids or hot ashes. Do not use this vacuum as a sprayer for any flammable or
combustible liquid. To reduce the risk of health hazards from vapors or dusts, do not vacuum toxic materials.
WARNING: The operation of any utility vacuum can result in foreign objects being blown into the eyes, which can result in severe eye
damage. Always wear safety eyewear complying with ANSI Z87.1 (or in Canada, CSA Z94.3) before starting operation.
CAUTION: To reduce risk of hearing damage, wear ear protectors when using the vacuum for extended hours or when using it in a
noisy area. This 15.1 Liter / 4 Gal wet/dry vacuum is not fully assembled at the factory and need install casters and handle following
below steps when you remove it from the carton. The unit is featured with vacuuming and blowing function. fully assembled, plug the
power cord into the wall receptacle, turn the unit “ON” by pushing theswitch from position “O” to position “I” as shown in Figure A.
The “O” is the “OFF” position and the “I” is the “ON” position.
□Insert the casters (I) into the bottom of the caster base as shown
in Figure B.
□
□
Install Four Accessory holders(H) into the dust tank grooves
Insert provided screws
□Strong pressure is required. Listen for the click to ensure they are
locked in place.
Figure B
INSTALLING CASTERS
Figure A
O = OFF
I = ON
A
□
□
INSTALLING HANDLE
Place handle (A) in recess
Insert provided screws
H
I

INSTALLING THE CARTRIDGE FILTER
Operation
1Dry Pick-up 2Wet Pick-up
□
□
□
With the power head in an upside down position, slide the
cartridge filter (M) down over the lid cage and push the
filter seals against the power head.
The cartridge filter (M) can be used for wet or dry pick-up.
Installation is the same for both.
Place the filter retainer into the top of the cartridge filter,
hold the power head with one hand, and turn the handle on
the filter retainer clockwise to tighten, locking the filter into
place.
To remove the filter for cleaning, hold the power
head and turn the filter retainer counter-clockwise to
loosen and remove. Then the cartridge filter off the lid cage.
□To clean the cartridge filter, shake or brush off excess
dirt or rinse (from the inside of the filter) with water. Then
completely (approximately 24 hours) and re-install.
NOTE: If the filter has been used for wet pick-up, it must be
cleaned and dried before using for dry pick-up.
□Remove the cartridge filter (M) and replace it with the foam
filter (N) when you do wet pick-ups.
□This wet/dry vacuum is equipped with a float mechanism
which will rise automatically to cut off the airflow when the
liquid in the tank reaches a predetermined level. When this
happens, turn off the vacuum, unplug the power cord, and
empty the dust tank. You will know that the float has shut
the airflow off because the suction ceases and the motor
noise becomes higher in pitch due to increased motor
speed. The liquid capacity may vary with the rate of pickup.
IMPORTANT: To reduce the risk of damage to the vacuum,
do not run the motor with the float in raised position. Wet pick
up accessories should be washed periodically.
3Blower
This vacuum contains a blowing feature. Follow the steps below to
use the vacuum as a blower.
□Locate the blower port (F) on your vacuum.
□Insert one end of the 1.52 m x
3.2 cm / 5 ft. x 1-1/4 in.
hose (J) into the blower port (F).
□Turn the vacuum “ON”.
Float in raised position
J
F
M
N
MOC.SLOOTYKSUH7
SUH-DH-888-1tcatnocesaelP KY for further assistance.

8
Care and Maintenance
FILTER REPLACEMENT – REPLACE WITH MULTI-FIT CARTRIDGE FILTER SKU#332340
WARNING: To reduce the risk of injury from accidental starting, unplug the power cord before changing or cleaning the filter. Your
filter should be cleaned often to maintain peak vacuum performance.
WARNING: Do not remove the filter cage and float. The float prevents water from entering the impeller and damaging the motor. The
cage prevents fingers from touching the moving impeller.
IMPORTANT: To avoid damage to the blower wheel and motor, always reinstall the reusable dry filter before using the vacuum for
dry pickups and always reinstall the foam filter before using the vacuum for wet pickups.
IMPORTANT:After cleaning, check the filter for tears or small holes. Do not use a filter with holes or tears in it. Even a small hole can
cause dust to come out of your vacuum. Replace it immediately.
NOTE: Before installing the filter on the vacuum, clean the area of the lid so that the clamp ring will seal the bag against the lid and
stop small particles from bypassing the filter bag. If the filter is clean and not damaged, replace it on the filter cage. If it cannot be
reused, place a new filter over the filter cage.
NOTE: Clean the filter in an open area.
CLEANING
To keep your wet/dry vacuum looking its best, clean the outside with a cloth dampened with warm water and mild soap.
To clean the tank:
1. Dump out debris.
2. Wash the tank thoroughly with warm water and mild soap.
3. Wipe out with a dry cloth.
STORAGE
Before storing your vacuum, the dust tank should be emptied and cleaned. The cord should be wrapped and hung on the unit and the
accessories should be kept in the accessory holder so they can be readily available. The vacuum should be stored indoors.

Care and Cleaning
WARNING: To reduce the risk of injury from accidental starting, unplug the power cord before emptying the dust tank.
1. Remove the power head assembly of the wet/dry vacuum by pulling outward on the lid clips located on each side of the vacuum. Lift off
the power head assembly.
2. Dump the tank contents into the proper waste disposal container.
Troubleshooting
WARNING: To reduce the risk of injury from moving parts and/or electrical shock, turn power switch off and disconnect power plug
from electrical outlet before performing troubleshooting checks.
Minor problems often can be fixed without calling customer service.
Problem Possible Cause Corrective Action
The vacuum does not run. No electricity. Make sure electrical outlet has voltage (a qualified
electrician may need to be contacted).
There is a loss of suction during wet
pick-up.
□The tank is full.
□The hose is clogged.
□The filter is clogged.
□Drain and clean the tank.
□Remove the hose and clean out the debris.
□Clean or replace the filter.
There is a loss of suction during dry
pick-up.
□The tank is full.
□The hose is clogged.
□The filter is clogged.
□Drain and clean the tank.
□Remove the hose and clean out the debris.
□Clean or replace the filter.
MOC.SLOOTYKSUH9
SUH-DH-888-1tcatnocesaelP KY for further assistance.

10
Service Parts
Key No. Description Quantity
11
21
31
41
51
61
71
8
9
1Filter Cage
01
1Power Cord
11
2Latch
21
1Dust Tank
31
1
14
4Accessory holder
4Caster
Vacuum Port Inlet
HandleHKY04001
HKY04002
HKY04003
HKY04004
HKY04005
HKY04006
HKY04007
HKY04008
HKY04009
HKY04010
HKY04011
HKY04012
HKY04013
HKY04014
ON/OFF Switch
Top Cover
lid
Motor
Noise Reducing Sponge
Part No.

Questions, problems, missing parts? Before returning to the store,
call Husky Customer Service
8 a.m. – 7 p.m., EST, Monday-Friday
9 a.m. – 6 p.m., EST, Saturday
1-888-43-HUSKY
HUSKYTOOLS.COM
Retain this manual for future use.
