Husky HV06000 User manual

Model Numbers:
HV06000 • HV09000
6U.S. Gallon/22.5 Liter and
9U.S. Gallon/34.1 Liter Wet/Dry Vacs
FOR QUESTIONS OR INFORMATION CONTACT US AT
1-866-99-HUSKY
PartNo. SP6688 Printed in Mexico
OPERATOR’S MANUAL
SAVE THIS MANUAL FOR FUTURE REFERENCE
WARNING:
Toreduce the risk of injury,the user must read and understand the operator’s
manual before using this product.
!
The Toughest Name In Tools®
HV06000 HV09000
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 1

Safety is a combination of common sense,
staying alert, and knowing how your
wet/dry vacuum cleaner (“Vac”) works.
Safety Signal Words
DANGER: Indicates a hazardous
situation which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury, or
property damage.
When using your Vac,always follow basic
safety precautions including the following:
WARNING
-To reduce the risk of fire, electric
shock, or injury:
• Read and understand this manual and
all labels on the Vac before operating.
• Use only as described in this manual.
• Do not leave Vac running while
unattended - you may fail to notice
important signs indicating abnormal
operation such as loss of suction,
debris/liquid exiting exhaust, or
abnormal motor noises. Immediately
stop using Vac if you notice these signs.
• Sparks inside the motor can ignite
flammable vapors or dust. To reduce
the risk of fire or explosion, do not
vacuum or use near flammable or
combustible liquids, gases, or
explosive dusts, such as gasoline or
other fuels, lighter fluid, cleaners,
2
Important Safety Instructions. . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking and Checking Carton Contents. . 4
Caster/Caster Foot Assembly . . . . . . . . 5
Replacement Filter Assembly . . . . . . . . 5
Wet/Dry Vac Assembly . . . . . . . . . . . . . 6
To Store Your Accessories. . . . . . . . . . . 7
Operation. . . . . . . . . . . . . . . . . . . . . . . . 7
Vacuuming Dry Materials . . . . . . . . . . 8
Vacuuming Liquids . . . . . . . . . . . . . . . 8
Emptying the Drum . . . . . . . . . . . . . . 9
Moving the Wet/Dry Vac . . . . . . . . . . . 9
Blowing Feature . . . . . . . . . . . . . . . . . 9
Maintenance . . . . . . . . . . . . . . . . . . . . 10
Repair Parts. . . . . . . . . . . . . . . . . . . . . 12
Warranty . . . . . . . . . . . . . . . . . . . . . . . 14
Section Page
Section Page
IMPORTANT SAFETY INSTRUCTIONS
!
!
!
!
oil-based paints,natural gas, hydrogen,
coal dust, magnesium dust, aluminum
dust, grain dust, or gun powder.
• Do not vacuum anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
• Do not vacuum drywall dust, cold
fireplace ash, or other fine dusts with
standard filter. These may pass through
the filter and be exhausted backinto
the air. Use a fine dust filter instead.
• Toreduce the risk of inhaling toxic
vapors,do not vacuum or use near
toxic or hazardous materials.
• To reduce the risk of electric shock, do
not expose to rain or allow liquid to
enter motor compartment. Store
indoors.
•Do not allowto be used as a toy. Close
attention is necessary when used by or
near children.
• Do not use with a tornfilter or without
the filter installed except when
vacuuming liquids as described in this
manual. Dry debris ingested by the
impeller may damage the motor or be
exhausted back into the air.
•WARNING: The power cord on this
product contains lead, a chemical
known in the State of California to
cause birth defects or other
reproductive harm. Wash hands
after handling.
•Do not leaveVac when plugged in.
Unplug from outlet when not in use and
before servicing.
• Turn off Vac before unplugging.
Table of Contents
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 2

3
•To reduce the risk of injury from
accidental starting, unplug power cord
before changing or cleaning filter.
• Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
• Do not use with damaged cord, plug or
other parts. If your Vac is not working
as it should, has missing parts, has
been dropped, damaged, left outdoors,
or dropped into water, call customer
service.
• Do not pull or carry by cord, use cord
as handle, close a door on cord, or pull
cord around sharp edges or corners.
Do not run Vac over cord. Keep cord
away from heated surfaces.
• Do not handle plug, switch, or the Vac
with wet hands.
• Do not put any object into ventilation
openings. Do not vacuum with any
ventilation openings blocked; keep free
of dust, lint, hair or anything that may
reduce air flow.
• Keep hair, loose clothing, fingers, and
all parts of body away from openings
and moving parts.
• Toreduce the risk of falls, use extra
care when cleaning on stairs.
• To reduce the risk of back injury or
falls, do not lift a Vac that is heavy with
liquid or debris. Partially empty the vac
by scooping debris or draining liquid to
make it comfortable to lift.
• To reduce the risk of personal injury or
damage to Vac, use only Husky or
RIDGID®recommended accessories.
• When using as a blower:
- Direct air discharge only at work
area.
-Do not direct air at bystanders.
- Keep children away when blowing.
- Do not use blower for any job except
blowing dirt and debris.
- Do not use as a sprayer.
- Wear safety eyewear.
•To reduce the risk of eye injury, wear
safety eyewear. The operation of any
utility Vac or blower can result in
foreign objects being blown into the
eyes,which can result in severe eye
damage.
• This Wet/Dry Vac is double-insulated,
eliminating the need for a separate
grounding system. Use only identical
replacement parts. Read the
instructions for Servicing Double-
Insulated Wet/Dry Vacs before
servicing.
• Use only extension cords that are rated
for outdoor use. Extension cords in
poor condition or too small in wire size
can pose fire and shock hazards.
To reduce the risk of these hazards,
be sure the cord is in good condition
and that liquid does not contact the
connection. Do not use an extension
cord with conductors smaller than 16
gauge (AWG) in size. To reduce power
loss, use a 14 gauge extension cord if
25 to 50 ft. long and 12 gauge for 50 ft.
or longer.
CAUTION:
• To reduce the risk of hearing damage,
wear ear protectors when using for
extended hours or in a noisy area.
• For dusty operations, wear dust mask.
•Static shocks are common when the
relative humidity of the air is low.
Vacuuming fine debris with your Vac
can deposit static charge on the hose
or Vac. To reduce the frequency of
static shocks in your home or when
using this Vac,add moisture to the air
with a humidifier.
Observethe following warnings that
appear on the motor housing of your Vac:
DOUBLE INSULATED
GROUNDING NOTREQUIRED.
WHEN SERVICING USE ONLY
IDENTICAL REPLACEMENT PARTS.
!
WARNING: For your own safety,
read and understand operator’s
manual. Do not run unattended.
Do not pick up hot ashes, coals,
toxic, flammable or other hazardous
materials. Do not use around
explosive liquids or vapors.
WARNING: To reduce the risk of
electric shock - do not expose to
rain - store indoors.
!
SAVE THIS MANUAL
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 3

Unpacking and Checking Carton Contents
Carton Contents List
Key Description Qty
A Wet/Dry Vac ................................1
B* Filter .............................................1
C* Filter Plate....................................1
D* Filter Nut ......................................1
E Hose Assembly ............................1
F Casters.........................................4
G Caster Foot w/Storage .................4
H Extension Wands .........................2
IUtility Nozzle ................................1
J Operator’s Manual........................1
IMPORTANT:
A
HV06000 VAC SHOWN
G
E
I
B*
C*
D*
F
J
H
Remove entire contents of carton. Check
each item against the Carton Contents
List. Contact 1-866-99-HUSKY or E-mail
us at inf[email protected] if any parts
are damaged or missing.
Included with 9-Gallon Models Only
Key Description Qty
K Wet Nozzle ..................................1
LCar Nozzle ...................................1
Introduction
This Wet/Dry Vac is intended for house-
hold use. It may be used for vacuuming
wet or dry media and may be used as a
blower.
Read this operator’s manual to familiarize
yourself with the product features and to
understand the specific usage of your
new Vac.
4
*These items may come preassembled.
If they are not present in the carton,
checkthe vac power head to see if they
are preassembled.
L
K
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 4

1. Turn the dust drum upside down on
the floor.
2. Insert the caster feet into the bottom of
drum, as shown (4 places).
3. Push on the caster foot until the foot is
flush with bottom of the dust drum.
4. Insert the caster stem into the socket
of the caster foot, as shown (4 places).
5. Push on the caster until the ball on the
caster stem is inserted all the way into
the socket. You will hear the ball snap
into the socket and the caster will
swivel easily when positioning is
correct.
6. Turn the drum upright.
Caster/Caster Foot Assembly
Caster
Foot
Dust
Drum
Pin
Caster
Hole
Caster Ball
Caster Stem
1. Carefully slide the filter over the filter
cage, sliding it over the center ring
covering the 3 slots until the filter stops
against the lid.
2. Place filter nut and filter plate onto
threaded stud and tighten it down.
Finger tighten only.
NOTE: Lever of filter nut should be away
from plate as shown.
IMPORTANT: Do not overtighten as this
maydeform or crack the filter cage, or
filter.
NOTE: If filter cage or float needs to be
replaced or removed, use a flat blade
screwdriver and insert the blade near one
of the tabs between the filter cage and
the center ring of the lid. Pry the tab out
of the slot. Tilt the cage and lift away from
the lid. To replace, follow the assembly
instructions below:
Replacement Filter Assembly
WARNING: For your own safety,
never connect plug to power source
outlet until all assembly steps are
complete and you have read and
understood the safety and operation
instructions. Do not operate vac
with anyparts damaged or missing.
Filter Cage
Filter Nut
Lever
Filter Nut
Filter Plate
Filter
Slots (3)
Threaded
Stud
!
5
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 5

6
1. Line up vacuum port above drum
label.
2. Place lid on top of drum with the
handles snug against the drum
channel.
3. Be sure lid completely covers the top
of the drum so leakage does not
occur.
4. Make sure that the locking tabs are
snapped in place to prevent the lid
from coming off (see insert).
Wet/DryVac Assembly
Insert Hose
Insert the larger end of the hose into the
vacuum port.
Place the utility nozzle securely on the
opposite end of the hose and the vac is
ready for use.
Powerhead
Flexible
Locking Tab
Push Down
and Pull Out
Flexible
Locking Tab
(located
under latch)
Drum
Channel
Vacuum Port
Drum
Flexible Locking
Tab Pulled Out
Replacement Filter Assembly (continued)
3. Place the float over the opening in the
center of the lid with the words "This
Side Towards Lid" laying face down
over the hole.
4. Line up filter cage tabs with slots in the
center ring of the lid.
5. Push on the filter cage until the tabs
snap into slots for a secure fit.
Filter
Cage
Tabs (3)
Slots
(3)
Power
Assembly
THIS SIDE
TOWARD LID
Filter
Cage
Tabs (3)
Float
Solid End
Slots (3)
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 6

To Store Your Accessories
7
1. Slide extension wands and acces-
sories onto posts of the caster feet for
storage.
2. To remove wands and accessories,
lightly rotate and pull upward.
Operation
Cord Storage
Simply, wrap the power cord around the
powerhead (as shown) and snap the
connector on the plug to a wrap of the
cord.
Caster Feet Storage
Utility
Nozzle
Extension
Wand (2)
Cord Wrap
Storage
Power Cord
WARNING: To reduce the risk of fire, explosion, or damage to Vac:
• Do not leave Vac running while unattended - you may fail to notice important
signs indicating abnormal operation such as loss of suction, debris/liquid exiting
exhaust, or abnormal motor noises. Immediately stop using Vac if you notice
these signs.
• Do not leave Vac plugged-in when not in use.
• Do not continue running when float has cut off suction.
• Do not operate Vac in areas with flammable gases, vapors or explosive dust in
the air. Sparks inside the motor can ignite airborne flammables. Flammable gases
and vapors include: lighter fluid, solvent-type cleaners, oil-based paints, gasoline,
alcohol, or aerosol sprays. Flammable dusts include: coal, magnesium,
aluminum, grain, or gun powder.
• Do not vacuum up explosive dusts, flammable liquids, or hot ashes.
• Do not use Vac as a sprayer.
!
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 7

Hose - Provides transfer of vacuum or
blowing capability to work site. Provides
the means of attaching extension wands
and nozzles.
Vacuuming Dry Materials
1. The filter must always be in correct
position at all times to avoid leaks and
possible damage to vac.
8
Operation (continued)
2. When using your vac to pick up very
fine dust, it will be necessary for you to
empty the drum and clean the filter at
more frequent intervals to maintain
peak vac performance.
NOTE: Adryfilter is necessaryto pick up
dry material. If you use your vac to pick
up material when the filter is wet, the filter
will clog quickly and be very difficult to
clean.
3. If your filter is wet but you need to use
the vac to pick up dry material, you
must first allow the filter to dry.
Vacuuming Liquids
1. When picking up small amounts of
liquid the filter maybe left in place.
2. When picking up large amounts of
liquid we recommend that the filter be
removed. If the filter is not removed, it
will become saturated and misting may
appear in the exhaust.
To reduce the risk of electric shock, this
appliance has a polarized plug (one blade
is wider than the other). This plug will fit
in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a
qualified electrician to install the proper
outlet. Do not change the plug in any way.
Utility Nozzle - General purpose nozzle for
most vacuuming applications.
Wet Nozzle (9 gallon models only) -
Used for wet pickup on smooth surfaces
to pick up liquid and drythe surface in
one stroke.
Car Nozzle (9 gallon models only) - Dry
pickup nozzle for car interiors and most
upholstery cleaning.
Extension Wands - These wands can be
connected together and provide
additional length.
=OFF =ON
Familiarize yourself with the accessories
included with the vac. Each accessory may
be used in various ways for vacuuming and
blowing debris. Here is a list of the
accessories and their uses.
After you plug the power cord into the outlet,
turn the unit on by pushing the switch from
position "O" to position "l". The symbols
used on the switch actuator are international
"On & Off" symbols. "O" is the symbol for
"OFF" and "l" is the symbol for "ON".
WARNING: To reduce the risk of electric shock or injury:
• Do not expose to rain or allow liquid to enter the motor compartment. Store indoors.
• Do not handle plug, switch, or Vac with wet hands.
• Do not service Vac while it is plugged-in. If your Vac is not working as it should, has
missing parts, has been dropped, damaged, left outdoors, or dropped into water,
return it to an independent service center or call customer service.
• When using an extension cord, use only outdoor-rated cords that are in good
condition. Do not allow the connection to come into contact with liquid.
• Do not vacuum toxic materials to reduce the risk of inhaling the vapors or dust.
!
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 8

Emptying the Drum
9
Moving the Wet/Dry Vac
Should it become necessary to pick the
vac up to move it, DO NOT pick the vac
up by the lid handles unless dust drum is
empty. To avoid dropping the vac, due to
latches releasing or possible part
breakage,pickthe vac up by the dust
drum.
Blowing Feature
Your Wet/Dry Vac features “Full Blowing”.
Itcan blow sawdust and other debris.
Follow the steps below to use your vac as
ablower.
1. Remove the lid. Pull the flexible latches
outward on each side of the lid to
release from the drum.
2. While holding the latches out, lift the
top assembly up and away from the
drum.
1. Locate blowing port of your Wet/Dry
Vac.
2. Insertthe larger end of hose into the
blowing port of the vac.
3. (Optional) Attach extension wand to
swivel end of hose.
4. Turn vac on and you are ready to use
your vac as a blower.
3. Lay top assembly upside down on a
clean area while emptying drum or
changing filter.
4. Dump the drum contents into the
proper waste disposal container.
WARNING: Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
using as a blower.
CAUTION: Wear a dust mask if
blowing creates dust which might
be inhaled.
WARNING: To reduce the risk of
injuryto bystanders, keep them
clear of blowing debris.
!
!
!
Hose
Extension
Wand
(optional)
Swivel
End of
Hose
Blowing
Port
3. When the liquid in the drum reaches a
predetermined level, the float
mechanism will rise automatically to cut
off air-flow. You will know that the float
has risen because suction stops and the
motor noise will become higher in pitch,
due to increased motor speed. When this
happens, turn off the vac, unplug the
power cord, and empty the drum.
4. After using the vac to pick up liquids, the
filter must be dried to avoid possible
mildew and damage to the filter.
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 9

10
Cleaning A Wet Filter
After filter is removed, run water through
the filter from a hose or spigot. Take care
that water pressure from the hose is not
strong enough to damage filter.
Installation
Refer to page 5 "Replacement Filter
Assembly" Section of this manual.
Allow the filter to dry before reinstalling
and storing the vac.
NOTE: The filter is made of high quality
paper designed to stop very small
particles of dust. The filter can be used
for dry pick up or small amounts of liquid.
Handle the filter carefully when removing
to clean or installing it. Creases in the
filter pleats may occur from installation
but will not affect the performance of the
filter.
Filter Cleaning
Your filter should be cleaned often to
maintain peak vac performance.
Allow the filter to dry before storing or
picking up dry debris.
IMPORTANT: After cleaning, check the
filter for tears or small holes. Do not use a
filter with holes or tears in it. Even a small
hole can cause a lot of dust to come out
of your vac. Replace it immediately.
Filter Removal
Toremovethe filter for cleaning or
replacement, unscrew the filter nut from
the filter cage and lift off filter and filter
plate.
IMPORTANT: To avoid damage to the
blower wheel and motor,always reinstall
the filter before using the vac for dry
material pick-up.
Cleaning A DryFilter
Maintenance
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before changing
or cleaning filter.
Filter
!
1. Some removal of dry debris can be
accomplished without removing the
filter from the vac. Slap your hand on
top of the lid while the vac is turned
off.
2. For best cleaning results due to
accumulated dust, clean the filter in an
open area. Cleaning SHOULD be
done outdoors and not in the living
quarters.
3. After filter removal from vac, remove
the dry debris by gently tapping filter
against the inside wall of your dust
drum. The debris will loosen and fall.
4. For thorough cleaning of dry filter with
fine dust (no debris), run water
through it as described under
"Cleaning A Wet Filter"
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 10

11
Cleaning and Disinfecting the
Wet/Dry Vac
T
okeep your Wet/Dry Vac looking its
best, clean the outside with a cloth
dampened with warm water and mild
soap.
To clean the drum:
1. Dump debris out.
2. Wash drum thoroughly with warm
water and mild soap.
3. Wipe out with dry cloth.
Before prolonged storage or as needed
(i.e.; waste water pick up) the drum
should be disinfected.
To disinfect the drum:
1. Pour 1 gallon of water and 1 teaspoon
chlorine bleach into the drum.
2. Let solution stand for 20 minutes,
carefully swishing every few minutes,
making sure to wet all inside surfaces
of the drum.
3. Empty drum after 20 minutes. Rinse
with water until bleach smell is gone.
Allow drum to dry completely before
sealing the motor on the drum.
Storage
Before storing your vac, the dust drum
should be emptied and cleaned. The cord
should be wrapped around the unit and
the hose should be stored as described
in this manual. Accessories should be
kept in the same area as the vac so they
can be readily available. The vac should
be stored indoors.
Casters
If your casters are noisy, you may put a
drop of oil on the roller shaft to make
them quieter.
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 11

Key HV06000 HV09000
No. PartNo. PartNo. Description
1 832086 832086 Rocker Switch
2 832659 832661 Power Head Assembly
(Includes Keys 3 & 4)
3 509488 509488 Float
4 823201-1 823201-1 Filter Cage
5VF4000 VF4000 Filter
6 73317 73317 Filter Plate
773316 73316 Filter Nut
8832783 832084 Caster Foot w/Storage
9331605 331605 Caster
10 VT1709 VT1709 Utility Nozzle
11 — VT1781 Car Nozzle (9-Gallon Only)
12 — VT1710 Wet Nozzle (9-Gallon Only)
13 VT1708 VT1708 Extension Wands
14 832635 832635 Hose
15 SP6688 SP6688 Operator’s Manual
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) mayalso be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
Repair Parts
6or 9 U.S. Gallon Wet/Dry Vac
Model Numbers HV06000 or HV09000
HUSKY parts are available
Always order by Part Number - Not by Key Number
†These replacement parts are available where you purchased your vac.
12
†
†
†
†
†
!
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 12

6or 9 U.S. Gallon Wet/Dry Vac
Model Numbers HV06000 or HV09000
HUSKY parts are available
2
5
6
7
3
4
15
14
13
9-GALLON MODELS
ONLY
11
12
8
9
10
1
13
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 13

Part No. SP6688 Form No. SP6688-2 Printed in Mexico 07/08
QUESTIONS OR COMMENTS? CALL
1-866-99-HUSKY
Please have your Model Number and Serial Number on hand when calling.
Stock No. HV0600 or HV0900
Model No. HV06000 or HV09000
Serial Number
Model and serial numbers may be found on a label on the lid.You should record both model and
serial numbers in a safe place for future use.
c2006 Homer TLC, Inc. All Rights Reserved.
The Toughest Name In Tools®
The Toughest Name In Tools®
Model Numbers: HV06000 or HV09000
HUSKY® Limited 3-Year Warranty
If within three years from date of purchase, this Husky product fails due to defect in materials
or workmanship, return the product to any The Home Depot retail store with a receipt indicating
proof of purchase for replacement with an item of equal or greater value. This warranty
excludes incidental/consequential damages and failure due to misuse, abuse or normal wear
and tear.
This warranty supersedes all other express warranties. No other express warranty shall be
deemed to exist in connection with any of the goods or services supplied hereunder, and any
implied warranties, including without limitation implied warranties of merchantability or fitness
for a particular purpose. Some states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.
The Home Depot shall not be liable for any indirect, incidental special or consequential
damages in an wayrelated to the goods or services supplied hereunder. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation
or exclusion may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
No employee, agent or other person is authorized to give any warranties on behalf of The Home
Depot in addition to or different from that herein given or to assume for The Home Depot any
other liability in connection with any of its products except if in a writing which is signed by an
officer of The Home Depot and expressly and intentionally gives such warranties or assumes
such liability.
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 14

Números de modelo:
HV06000 • HV09000
Aspiradora para mojado/seco de 6 galones EE.UU./
22.5 litros o 9 galones EE.UU./34.1 litros
SI TIENE PREGUNTAS O DESEA INFORMACIÓN, CONTÁCTENOS LLAMANDO AL
1-866-99-HUSKY
No. de pieza SP6688 Impreso en México
MANUAL DEL OPERADOR
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
ADVERTENCIA:
Para reducir el riesgo de lesiones, el usuario debe leer y entender el manual del operador antes
de utilizar este producto.
!
El nombre más robusto en herramientas
®
HV06000 HV09000
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 15

La seguridad es una combinación de sentido común,
permanecer alerta y saber cómo funciona la
aspiradora para mojado/seco (“la aspiradora”).
Palabras de señal de seguridad
PELIGRO: indica una situación peligrosa que, si
no se evita, causará la muerte o lesiones graves.
ADVERTENCIA: indica una situación peligrosa
que, si no se evita, podría causar la muerte o lesiones
graves
PRECAUCIÓN: indica una situación peligrosa que,
si no se evita, pudiera causar lesiones leves o
moderadas.
Cuando utilice la aspiradora, siga siemprelas
precauciones básicas de seguridad, incluyendo
las siguientes.
ADVERTENCIA
–Para reducir el riesgo de incendio, sacudidas
eléctricas o lesiones:
•Lea y entienda este manual del usuario y todas las
etiquetas que están colocadas en la aspiradora para
mojado/seco antes de utilizarla
•Utilice la aspiradora únicamente de la manera que
se describe en este manual.
•No deje la aspiradora en marcha mientras esté
desatendida. Usted podría no notar señales
importantes que indiquen un funcionamiento
anormal, tal como pérdida de succión, residuos o
líquido que salen por el escape o ruidos anormales
del motor.Deje de usar la aspiradora
inmediatamente si observa estas señales.
• Las chispas que se producen en el interior del
motor pueden incendiar los vapores inflamables o
el polvo. Para reducir el riesgo de incendio o
explosión: No recoja con la aspiradora líquidos o
gases inflamables o combustibles, o polvos
explosivos como gasolina u otros combustibles,
líquido encendedor,limpiadores, pinturas a base de
aceite, gas natural, hidrógeno, polvo de carbón,
polvo de magnesio, polvo de aluminio, polvo de
granos de cereal o pólvora, ni use la aspiradora
cerca de estos materiales.
•No recoja con la aspiradora nada que esté ardiendo
ohumeando, como cigarrillos, fósforos o cenizas
calientes.
•No recoja con la aspiradora polvo de pared de tipo
seco ni hollín frío o ceniza fría de chimenea con un
filtro estándar. Este material es un polvo muy fino
que puede ser expulsado de vuelta al aire. Utilice un
filtro para polvo fino en lugar de un filtro estándar.
• Para reducir el riesgo de inhalar vapores tóxicos,
no recoja con la aspiradora materiales tóxicos o
peligrosos ni la use cerca de dichos materiales.
• Para reducir el riesgo de descargas eléctricas, no
exponga la aspiradora a la lluvia ni deje que entren
líquidos en el compartimiento del motor.Guarde la
aspiradora en un lugar interior.
• No permita que la aspiradora se utilice como un
juguete. Se necesita prestar máxima atención
cuando sea utilizada por niños o cerca de éstos.
• No use la aspiradora con un filtro desgarrado o sin
tener el filtro instalado, excepto cuando recoja con
ella líquidos de la manera que se describe en este
manual. Los residuos secos absorbidos por el
impulsor podrían dañar el motor o ser expulsados
de vuelta al aire.
•ADVERTENCIA:El cordón de energía de este
producto contiene plomo, una sustancia química
que según los conocimientos del estado de
California causa defectos de nacimiento u otros
daños a la reproducción. Lávese las manos
después de manejar el producto.
• No abandone la aspiradora cuando esté enchufada.
Desenchúfela del tomacorriente cuando no la esté
utilizando y antes de realizar servicio de revisión.
• Apague la aspiradora antes de desenchufarla.
• Para reducir el riesgo de lesiones debidas a un
arranque accidental, desenchufe el cordón de
energía antes de cambiar o limpiar el filtro.
16
Instrucciones de seguridad importantes . . . . . . . . . 16
Introducción . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Desempaquetado y comprobación
del contenido de la caja de cartón. . . . . . . . . . . . 18
Ensamblaje de las ruedecillas/patas
para ruedecilla . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Ensamblaje del filtro de repuesto . . . . . . . . . . . . . . . 19
Ensamblaje de la aspiradora para mojado/seco. . . . 20
Para guardar los accesorios . . . . . . . . . . . . . . . . . . . 21
Funcionamiento. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Recogida de materiales secos
con la aspiradora. . . . . . . . . . . . . . . . . . . . . . . 22
Recogida de líquidos con la aspiradora . . . . . . . 22
Vaciado del tambor . . . . . . . . . . . . . . . . . . . . . . . 23
Traslado de la aspiradora para mojado/seco . . . 23
Dispositivo de soplado . . . . . . . . . . . . . . . . . . . . 23
Mantenimiento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Piezas de repuesto . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Garantía. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Sección Página Sección Página
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
!
!
!
!
Indice
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 16

• No desenchufe la aspiradora tirando del cordón.
Para desenchufarla, agarre el enchufe y no el
cordón.
• No use la aspiradora con el cordón dañado, el
enchufe dañado u otras piezas dañadas. Si la
aspiradora no funciona como debe, le faltan piezas,
se ha caído, ha sido dañada, se ha dejado a la
intemperie o se ha caído al agua, llame a servicio al
cliente.
• No tire de la aspiradora usando el cordón ni la lleve
por el cordón, ni use el cordón como asa, ni cierre
una puerta sobre el cordón, ni tire del cordón
alrededor de bordes o esquinas afilados. No pase la
aspiradora en marcha sobre el cordón. Mantenga el
cordón alejado de las superficies calientes.
• No maneje el enchufe, el interruptor o la aspiradora
con las manos mojadas.
• No ponga ningún objeto en las aberturas de
ventilación. No recoja nada con la aspiradora
cuando cualquiera de las aberturas de ventilación
esté bloqueada; mantenga dichas aberturas libres
de polvo, pelusa, pelo o cualquier cosa que pueda
reducir el flujo de aire.
•Mantenga el pelo, la ropa holgada, los dedos y
todas las partes del cuerpo alejados de las
aberturas y de las piezas móviles.
• Para reducir el riesgo de caídas, tenga cuidado
adicional al limpiar en escaleras.
•Para reducir el riesgo de lesiones de espalda o
caídas, no levante una aspiradora que pese mucho
debido a que contiene líquido o residuos. Vacíe
parcialmente la aspiradora sacando los residuos o
drenando el líquido para hacer que sea cómodo
levantarla.
• Para reducir el riesgo de lesiones corporales o
daños a la aspiradora, utilice únicamente
accesorios recomendados por Husky o RIDGID®.
• Cuando utilice la aspiradora como soplador :
- Dirija la descarga de aire solamente hacia el área
de trabajo.
-No dirija el airehacia las personas que estén
presentes.
-Mantenga alejados a los niños durante la
operación de soplado.
-No utilice el soplador para trabajos que no sean
soplar suciedad y residuos.
- No use la aspiradora como rociador.
-Use protección ocular de seguridad.
• Para reducir el riesgo de lesiones en los ojos, use
protección ocular de seguridad. La utilización de cual-
quier aspiradora utilitaria o soplador utilitario puede
hacer que se soplen objetos extraños hacia los ojos,
lo cual puede causar daños graves en los ojos.
• Esta aspiradora para mojado/seco tiene aislamiento
doble, lo cual elimina la necesidad de un sistema
independiente de conexión a tierra. Utilice
únicamente piezas de repuesto idénticas. Lea las
instrucciones de servicio de revisión de las
aspiradoras para mojado/seco con aislamiento
doble antes de realizar dicho servicio.
• Utilice únicamente cordones de extensión que
tengan capacidad nominal para uso a la intemperie.
Los cordones de extensión que estén en malas
condiciones o tengan un tamaño de alambre
demasiado pequeño pueden crear peligros de
incendio y descargas eléctricas. Para reducir el
riesgo de estos peligros, asegúrese de que el
cordón esté en buenas condiciones y que el líquido
no entre en contacto con la conexión. No utilice un
cordón de extensión que tenga conductores con un
diámetromenor al calibre 16 (AWG). Para reducir la
pérdida de potencia, utilice un cordón de extensión
de calibre 14 si la longitud es de 25 a 50 pies, y de
calibre 12 si la longitud es de 50 pies o más.
PRECAUCIÓN:
• Para reducir el riesgo de daños a la audición, use
protectores de oídos cuando utilice la aspiradora
durante muchas horas seguidas o cuando la
emplee en un área ruidosa.
• Para operaciones que generan polvo, use una
máscara antipolvo.
•Las descargas de estática son comunes en áreas
secas o cuando la humedad relativa del aire es baja.
Si recoge residuos finos con la aspiradora, se
puede depositar carga estática en la manguera o en
la aspiradora. El mejor remedio para reducir la
frecuencia de las descargas de estática en su casa
ocuando use esta aspiradora es añadir humedad al
aire con un humidificador.
!
GUARDE ESTE MANUAL
Siga las siguientes advertencias que aparecen en la
caja del motor de la aspiradora.
AISLAMIENTO DOBLE. NO SE REQUIERE
CONEXION A TIERRA.
CUANDO HAGA SERVICIO DE REVISIÓN DE
LA ASPIRADORA, UTILICE ÚNICAMENTE PIEZAS DE
REPUESTO IDÉNTICAS.
ADVERTENCIA: Para su propia seguridad, lea
yentienda el manual del operador. No tenga en
marcha la aspiradora desatendida. No recoja
cenizas calientes, carbón caliente, materiales
tóxicos ni inflamables ni otros materiales
peligrosos. No use la aspiradora alrededor de
líquidos o vapores explosivos
ADVERTENCIA: Para reducir el riesgo de
sacudidas eléctricas, no exponga la aspiradora a
la lluvia y almacénela en interiores.
!
!
17
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 17

Desempaquetado y comprobación
del contenido de la caja de cartón
Lista del contenido de la caja de cartón
Clave Descripción Cant.
AAspiradora para mojado/seco ...................1
B* Filtro...........................................................1
C* Placa del filtro ............................................1
D* Tuerca del filtro ..........................................1
E Ensamblaje de manguera ...........................1
F Ruedecillas..................................................4
GPata para ruedecilla con área
para guardar...............................................4
H Tubos extensores .......................................2
IBoquilla de uso general..............................1
J Manual del operator....................................1
IMPORTANTE:
A
HV06000 VAC SHOWN
G
E
I
B*
C*
D*
F
J
H
Saque todo el contenido de la caja de cartón.
Asegúrese de que no falte ningún artículo utilizando
la lista del contenido de la caja. Llame al
1-866-99-HUSKY o comuníquese con nosotros por
correo electrónico a [email protected] si alguna
pieza está dañada o falta.
Incluidas con los modelos de 9 galones solamente
Clave Descripción Cant.
K Boquilla para mojado ................................1
L Boquilla para auto ......................................1
L
K
Introducción
Esta aspiradora para mojado/seco está diseñada para
uso doméstico solamente. Se puede utilizar para
recoger materiales mojados o secos y se puede usar
como soplador.
Lea este manual del operador para familiarizarse con
las características del producto y para entender la
utilización específica de su nueva aspiradora.
18
*Es posible que estos artículos vengan
preensamblados. Si no están presentes en la caja
de cartón, revise el interior del tambor para
comprobar si están preensamblados.
SE MUESTRA LA ASPIRADORA HV06000
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 18

ADVERTENCIA: Para su propia seguridad,
nunca conecte el enchufe al tomacorriente de la
fuente de energía hasta que haya completado
todos los pasos de ensamblaje y haya leído y
entendido las instrucciones de seguridad y
utilización. No utilice la aspiradora si alguna de
sus piezas está dañada o falta.
1. Ponga el tambor para polvo en posición invertida
sobre el piso.
2. Introduzca las patas para ruedecilla en la parte
inferior del tambor, tal como se muestra
(4 lugares).
3. Ejerza presión sobre la pata para ruedecilla hasta
que la pata esté al ras con la parte inferior del
tambor para polvo.
4. Introduzca el vástago de la ruedecilla en el
receptáculo de la pata para ruedecilla, tal como
se muestra (4 lugares).
5. Ejerza presión sobre la ruedecilla hasta que la bola
del vástago de la ruedecilla se introduzca del todo
en el receptáculo. Se podrá oír como la bola
encaja en el receptáculo con un chasquido y la
ruedecilla oscilará fácilmente cuando el
posicionamiento sea correcto.
6. Ponga el tambor en posición vertical.
Ensamblaje de las ruedecillas/patas para ruedecilla
Caster
Foot
Dust
Drum
Pin
Caster
Hole
Caster Ball
Caster Stem
1. Deslice cuidadosamente el filtro sobre la jaula del
filtro, deslizándolo sobre el anillo central que
cubre las 3 ranuras hasta que el filtro se detenga
contra la tapa.
2. Coloque la tuerca del filtro y la placa del filtro en el
espárrago roscado y apriete la tuerca hacia abajo.
Apriétela solamente con los dedos.
NOTA: La palanca de la tuerca del filtrodebe estar
alejada de la placa, de la manera que se muestra en
la ilustración.
IMPORTANTE: No apriete excesivamente la tuerca,
ya que esto podría deformar o agrietar la jaula del
filtro o el filtro.
NOTA: Si fuera necesario reemplazar o quitar la jaula
del filtrooel flotador,utilice un destornillador de hoja
plana e introduzca la hoja cerca de una de las
lengüetas entrela jaula del filtro y el anillo central de la
tapa. Haga palanca en la lengüeta hacia fuera, hasta
sacarla de la ranura. Incline la jaula y levántela
alejándola de la tapa. Para colocar de nuevo la jaula
del filtro, siga las instrucciones de ensamblaje que se
dan a continuación:
Ensamblaje del filtro de repuesto
Filter Cage
Filter Nut
Lever
Filter Nut
Filter Plate
Filter
Slots (3)
Threaded
Stud
!
Ruedecilla
Vástago de la ruedecilla
Bola de la ruedecilla
Pasador
Pata para
ruedecilla
Agujero
Palanca de
la tuerca
del filtro
Tuerca del filtro
Placa del filtro
Filtro
Espárrago
roscado
Jaula del filtro
Ranuras (3)
Tambor
para polvo
19
SP6688-2 HUSKY-ES.qxd 7/24/08 9:02 AM Page 19

3. Coloque el flotador sobre la abertura que está en
el centro de la tapa con las palabras “This Side
Towards Lid” – Este lado hacia la tapa –
orientadas hacia abajo sobre el agujero.
4. Alinee las lengüetas de la jaula del filtro con las
ranuras del anillo central de la tapa.
5. Empuje sobre la jaula del filtro hasta que las
lengüetas se acoplen a presión en las ranuras
para lograr un encaje seguro.
20
1. Alinee el orificio de aspiración sobre la etiqueta del
tambor.
2. Coloque la tapa sobreel tambor con las asas
ajustadas perfectamente contra el canal del
tambor.
3. Asegúrese de que la tapa cubra completamente
la parte superior del tambor para que no se
produzcan escapes.
4. Asegúrese de que las lengüetas de fijación estén
encajadas a presión en su sitio para evitar que la
tapa se salga. (Vea el detalle.)
Ensamblaje de la aspiradora para mojado/seco
Introduzca la manguera
Inserte el extremo más grande de la manguera en el
orificio de aspiración.
Coloque la boquilla utilitaria de manera segura en el
extremo opuesto de la manguera y la aspiradora
estará lista para utilizarse.
Powerhead
Flexible
Locking Tab
Push Down
and Pull Out
Flexible
Locking Tab
(located
under latch)
Drum
Channel
Vacuum Port
Drum
Flexible Locking
Tab Pulled Out
Ensamblaje del filtro de repuesto (continuación)
Filter
Cage
Tabs (3)
Slots
(3)
Power
Assembly
THIS SIDE
TOWARD LID
Filter
Cage
Tabs (3)
Float
Solid End
Slots (3)
Jaula
del filtro
Jaula
del filtro
Lengüetas
(3)
Ranuras
(3)
Lengüetas (3)
Flotador
Extremo macizo
Ensamblaje
del motor
Ranuras (3)
Tambor Lengüeta de
fijación flexible
Lengüeta de fijación
flexible tirada hacia fuera
Cabezal del motor
Empuje hacia
abajo la lengüeta
de fijación flexible
(ubicada debajo
del pestillo) y tire
de ella hacia fuera
Canal
del tambor
Orificio de aspiración
SP6688-2 HUSKY-ES.qxd 7/24/08 9:05 AM Page 20
