Husqvarna LFe 60 User manual

LFe 60
EN Operator's manual 2-26

Contents
Introduction..................................................................... 2
Safety..............................................................................5
Operation...................................................................... 11
Maintenance................................................................. 13
Troubleshooting............................................................ 17
Transportation, storage and disposal........................... 18
Technical data.............................................................. 21
Accessories.................................................................. 24
Declaration of Conformity............................................. 25
Introduction
Product description
The product is a walk-behind light forward plate
compactor with an electric motor. The product is used
for compaction of thin to moderately thick layers of
granular soils. With the optional water tank, the product
can also be used for compaction of asphalt.
Descriptions of the identification letters for the product
variants:
• L = Low vibration handle is included.
• A = Water tank for compaction of asphalt is included.
• T = Transport wheels are included.
Intended use
The product is for professional operation only. Use the
product for repairs and maintenance of driveways, paths
and parking lots. With the optional block paving kit the
product can also be used for block paving. Do not use
the product for other tasks.
21661 - 002 - 13.03.2023

Product overview front
ALERT ERROR
16
17
7
2
3
1
7
7
5
18
19
6
4
15
21
20
13 14
910 11
12
8
1. Handle
2. Upper handle
3. Handle knobs
4. Lift point
5. Eccentric element
6. Water supply
7. Vibration damping units
8. Battery cable
9. Battery check button
10. Battery status indicator
11. "ALERT" indicator for the battery
12. "ERROR" indicator for the battery
13. Battery handle
14. Battery (not included)
15. Battery connector
16. Air intake
17. Battery charger (not included)
18. Water tank
19. Water tank cap
20. Water tap
21. Operator's manual
1661 - 002 - 13.03.2023 3

Product overview rear
10 11
12
13
14
6
8
7
3
4
2
1
9
9
9
9
5
1. Battery cable
2. Battery fastener lever
3. Transportation wheel
4. Transportation wheel lever
5. Type plate
6. Lifting handle
7. Bottom plate
8. V-belt cover
9. Vibration damping units
10. Power indicator
11. Power button
12. ON / OFF" button
13. "ALERT" indicator for the product
14. "ERROR" indicator for the product
Symbols on the product
WARNING: This product can be
dangerous and cause serious injury or
death to the operator or others. Be careful
and use the product correctly.
Read the manual carefully and make
sure that you understand the instructions
before you use the product.
Use heavy-duty slip-resistant boots.
41661 - 002 - 13.03.2023

Wear approved hearing protection.
To lift the product, attach lifting equipment
to the lift point on the product.
The product is not domestic waste.
Recycle it at an approved disposal
location for electrical and electronic
equipment.
This product is in compliance with
applicable EC directives. Refer to EC
Declaration of Conformity on page 25 .
This product conforms to the applicable
UK regulations. Refer to
UK Declaration of
Conformity on page 26
.
Note: Other symbols/decals on the product refer to
special certification requirements for some markets.
Type plate
1
2
3
45 6 87
9
1. Rated voltage
2. IP classification
3. Product type
4. Product number
5. Product weight
6. Serial number
7. Manufacturer
8. Rated power
9. Production year
Product liability
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not
from the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
Safety
Safety definitions
Warnings, cautions and notes are used to point out
specially important parts of the manual.
WARNING: Used if there is a risk of
injury or death for the operator or bystanders
if the instructions in the manual are not
obeyed.
CAUTION: Used if there is a risk of
damage to the product, other materials or
the adjacent area if the instructions in the
manual are not obeyed.
Note: Used to give more information that is necessary
in a given situation.
General power tool safety warnings
WARNING: Make sure to read the
approved accessory manual together with
this power units manual.
WARNING: Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool. Failure to
follow all instructions listed below may result
in electric shock, fire and/or serious injury.
1661 - 002 - 13.03.2023 5
