Husqvarna 967 669701-00 User manual

Lea el manual de instrucciones detenidamente
y asegúrese de comprender las instrucciones
antes de utilizar la máquina.
La gasolina que contiene hasta 10 % de etanol
(E10) se puede usar en esta máquina. El uso
de gasolina que tenga más de 10 % de etanol
(E10) anulará la garantía del producto.
Operator Manual
Manual del operador
Z 560x / 967 669701-00
Please read the operator manual carefully and
make sure you understand the instructions
before using the machine.
Gasoline containing a maximum of 10% ethanol
(E10) is permitted for use in this machine. The
use of gasoline with more than 10% ethanol
(E10) will void the product warranty.
English / Spanish
115 89 62-27 Rev. D

CONFORMITY CERTIFICATES
USA requirements
Labels are placed on the engine and/or in the engine compartment stating that the machine
will fulll the requirements. This is also applicable to special requirements for any of the states,
(California emission rules etc.). Do not remove these labels. Certicates can also be supplied
with the machine at delivery or written in the Engine manual. Take care of them as they are
valuable documents.
WARNING! The rollover protection
system's capabilities may be impaired by
damage if the mower is overturned or if
alteration to the ROPS occurs. If these
conditions take place, the total structure MUST
be replaced.
When this product is worn out and no longer
used, return it to the reseller or other party for
recycling.
To implement improvements, specications
and designs can be altered without prior
notication.
Note that no legal demands can be placed
based on the information contained in these
instructions.
Use only original parts for repairs. The use of
other parts voids the warranty.
Do not modify or install non-standard
equipment to the unit without consent from the
manufacturer. Modications to the unit may
cause unsafe operations or damage the unit.
WARNING! Failure to follow cautious
operating practices can result in dangerous
injury to the operator or other persons. The
owner must understand these instructions,
and must let only approved persons who
understand these instructions to operate the
mower.
Each person operating the mower must be of
sound mind and body and must not be under
the inuence of mind altering substances.
WARNING! Engine exhaust, some of its
constituents, and certain vehicle components
contain or emit chemicals known to the State of
California to cause cancer and birth defects or
other reproductive harm.
WARNING! Battery posts, terminals
and related accessories contain lead and lead
compounds, chemicals known to the State of
California to cause cancer and birth defects
or other reproductive harm. Clean your hands
after handling.
WARNING! Engine exhaust and certain
vehicle components contain or emit chemicals
considered to cause cancer, birth defects,
or other reproductive system damage. The
engine exhaust contains carbon monoxide,
which is an odorless, colorless, poisonous gas.
Do not use the machine in enclosed spaces.
©2018 All rights reserved.
Orangeburg SC. Printed in U.S.A.

CONTENTS
INTRODUCTION............................................... 4
Driving and Transport on Public Roads....... 4
Towing ......................................................... 4
Operating..................................................... 4
SYMBOLS AND DECALS................................. 6
SAFETY............................................................ 7
Protecting Children...................................... 7
Personal Safety Equipment......................... 8
Slope Operation........................................... 8
Safe Handling of Gasoline........................... 9
Transport ................................................... 10
Towing ....................................................... 10
Spark Arrestor............................................ 10
Rollover Protection System........................11
CONTROLS.................................................... 12
Steering Control Levers............................. 13
Park Brake................................................. 13
Throttle Control.......................................... 13
Ignition Switch ........................................... 14
Choke Control............................................ 14
Blade Switch.............................................. 14
Service Meter ............................................ 14
Fuel Gauges.............................................. 14
Fuses......................................................... 14
Fuel Shut Off Valve.................................... 15
Seat Adjustment ........................................ 15
Cutting Height............................................ 15
Fuel Tanks ................................................. 15
Tracking..................................................... 16
OPERATION................................................... 17
Training...................................................... 17
Operating on Hills...................................... 18
Moving Machine By Hand.......................... 19
MAINTENANCE.............................................. 20
Battery....................................................... 22
V-belts........................................................ 22
Cutting Blades........................................... 23
Adjusting the Mower Deck......................... 24
Deck Lift Spring......................................... 25
Neutral Adjustment .................................... 25
Park Brake................................................. 25
Tire Pressures ........................................... 25
Safety System ........................................... 26
Caster Wheels........................................... 26
Anti-scalp Rollers....................................... 26
LUBRICATION ................................................ 27
Engine oil................................................... 28
Wheels and Blades.................................... 28
Transaxle Fluid Change............................. 28
TROUBLESHOOTING.................................... 30
STORAGE....................................................... 31
SCHEMATIC ................................................... 32
TECHNICAL DATA.......................................... 33
SERVICE JOURNAL....................................... 35
INTRODUCCIÓN ............................................ 43
Conducción y transporte en vías públicas. 43
Remolque.................................................. 43
Funcionamiento......................................... 43
SÍMBOLOS Y RÓTULOS................................ 45
SEGURIDAD................................................... 46
Seguridad infantil....................................... 46
Equipo de seguridad personal................... 47
Funcionamiento en pendientes ................. 47
Manipulación segura de la gasolina .......... 48
Transporte ................................................. 50
Remolque.................................................. 50
Parachispas............................................... 50
Sistema de protección antivuelco.............. 50
CONTROLES.................................................. 52
Palancas de control de la dirección........... 53
Freno de estacionamiento......................... 53
Interruptor de arranque.............................. 53
Acelerador................................................. 54
Medidor de servicio ................................... 54
Estrangulador............................................ 54
Interruptor de la cuchilla............................ 54
Indicadores de combustible....................... 54
Altura de corte........................................... 55
Fusibles..................................................... 55
Palanca de ajuste del asiento.................... 55
Válvula de corte de combustible................ 55
Desplazamiento......................................... 56
Depósito de combustible........................... 56
OPERACIÓN .................................................. 57
Capacitación.............................................. 57
Trabajo en pendientes............................... 59
Mover la máquina manualmente ............... 60
MANTENIMIENTO.......................................... 61
Batería....................................................... 63
Sistema de seguridad................................ 64
Presión de los neumáticos ........................ 64
Discos de corte.......................................... 64
Correas en V ............................................. 64
Ajuste del equipo de corte......................... 66
Resorte de elevación del equipo............... 67
Ajuste Neutral............................................ 67
Freno de estacionamiento......................... 67
Ruedecillas................................................ 68
Ruedas de apoyo ...................................... 68
LUBRICACIÓN ............................................... 69
Cambio de aceite del motor....................... 70
Engrasadores de rueda y equipo .............. 70
Cambio de líquido del transeje.................. 70
SOLUCIÓN DE PROBLEMAS........................ 73
ALMACENAMIENTO ...................................... 74
ESQUEMA ...................................................... 75
DATATÉCNICOS............................................ 76
REGISTRO DE SERVICIO............................. 78

Congratulations
Thank you for purchasing a Husqvarna ride-
on mower. This machine is built for superior
efciency to rapidly mow primarily large areas. A
control panel that the operator can easily access
and a hydrostatic transmission regulated by
steering controls each contribute to the machine’s
performance.
This manual is a valuable document. Read the
contents carefully before using or servicing the
machine. The following of instructions (use,
service, maintenance) by all who operate this
machine is important for the safety of the operator
and others. It can also largely increase the life
span of the machine and increase its resale
value.
If you sell your machine, be sure to give the
operator manual to the new owner.
The last chapter of this operator manual supplies
a Service Journal. Make sure that service and
repair work are documented. A correctly kept
service journal reduces service costs for the
maintenance and affects the machine’s resale
value. Please contact your dealer for more
information. Take the operator manual along
when the machine is taken to your dealer for
service.
General
In this operator manual, left and right, rearward
and forward are used in relation to the machine’s
usual driving direction.
Continuous dedication to make our products
better requires that specications and design are
subject to change without notice.
Driving and Transport on Public Roads
Check applicable road trafc regulations before
transporting on public roads. If the machine is
transported, you must always use approved
fastening equipment and make sure that the
machine is correctly attached. DO NOT operate
this machine on public roadways.
Towing
If machine is equipped with a tow hitch, use much
more care when towing. Do not let children or
others in or on the towed equipment. Make wide
turns to avoid jack-kning. Travel slowly and leave
more distance to stop.
Do not tow on sloped ground. The weight of the
towed equipment can cause loss of traction and
loss of control.
Obey the manufacturer's recommendation for
weight limits for towed equipment. Do not tow
near ditches, canals, and other dangerous areas.
Operating
This machine is constructed only for mowing
grass on lawns and even ground without
obstacles such as stones, tree stumps, etc. The
machine can also be used for other tasks when
equipped with special accessories supplied by
the manufacturer. Operating instructions for the
accessories are supplied with delivery. All other
types of uses are incorrect. The manufacturer’s
directions concerning operation, maintenance,
and repairs must be carefully followed.
Lawn mowers and all power equipment, can
be potentially dangerous if used incorrectly.
Safety requires good judgment, careful use in
accordance with these instructions and common
sense.
The machine must only be operated, maintained,
and repaired by persons who know the machine’s
special qualities and who are also knowledgeable
about the safety instructions. Use only approved
repair parts to maintain this machine.
Accident prevention regulations, other general
safety regulations, occupational safety rules, and
trafc regulations must be followed without fail.
Unauthorized modications to the design of the
machine can absolve the manufacturer from
liability for resulting personal injury or damage to
property.
4
INTRODUCTION

Good Service
Husqvarna's products are sold throughout the
world and only in specialized retail stores with
complete service. This ensures that you as a
customer receive only the best support and
service. Before the product is delivered, the
machine has, for example, been inspected and
adjusted by your retailer. See the certicate in the
Service Journal in this operator manual.
When you need spare parts or support in
service questions, warranty issues, etc., consult
the following professional:
Manufacturing Number
The machine’s manufacturing number can be
found on the printed plate afxed to the engine
compartment.
Stated on the plate, from the top are:
• The machine’s type designation (I.D.)
• The manufacturer’s type number (Model)
• The machine’s serial number (Serial no.)
Please have the type designation and serial
number available when ordering spare parts.
This manual belongs to the machine with the
manufacturing number: Engine Transmission
The engine’s manufacturing number is stamped
on one of the valve covers.
The plate states:
• The engine’s model.
• The engine’s type.
• Code
Please have these available when ordering spare
parts.
The wheel motors and hydrostatic pumps have a
barcode decal afxed at the rear.
5
INTRODUCTION

Reverse Neutral Fast Slow Choke Fuel Park Brake
Danger Use protective
glasses Use protective gloves Wear hearing protection Do not stand here
Read Operator
Manual
Shut off engine,
remove key before
maintenance
or repair
Keep a safe
distance from
the machine Use on slopes no greater than 10° No passengers
Whole body
exposure to
thrown objects
Severing of ngers
and toes Do not open or remove safety
shields wIth engine
running
Careful backing up,
watch for
other people
Careful going
forward, watch for
other people
Warning!
Battery acid is
corrosive, explosive
and ammable
Warning!
Do not touch parts Warning!
Use caution when
lifting the cover
Warning!
Do not use without
deector
or grass catcher
These symbols are found on the machine and in
the operator manual. Study them carefully until
you know what they mean.
WARNING! Xxxx xxxxxx xxxxx xxxx
xxxxxxxxx xxxxxx xxxxxxxxx.
Used in this publication to tell the reader of a
risk of personal injury or death, particularly if the
reader neglects to obey the instructions in the
manual.
IMPORTANT INFORMATION Xxxx xxxxxx
xxxxx xxxx xxxxxxxxx xxxxxx xxxxxxxxx.
Used in this publication to tell the reader of a
risk of material damage, particularly if the reader
neglects to obey the instructions in the manual.
Used also when there is a possibility for misuse or
misassembly.
R N
6
SYMBOLS AND DECALS

Safety Instructions
These instructions are for your safety. Read them
carefully.
WARNING! THIS CUTTING MACHINE
CAN AMPUTATE HANDS AND FEET AND
THROW OBJECTS. FAILURE TO OBEY
THE FOLLOWING SAFETY INSTRUCTIONS
COULD RESULT IN SERIOUS INJURY OR
DEATH.
WARNING! CHILDREN CAN BE
SERIOUSLY INJURED OR KILLED BY THIS
EQUIPMENT. Carefully read and obey all the
safety instruction that follow.
IMPORTANT INFORMATION The American
Academy of Pediatrics recommends that
children be a minimum of 16 years of age
beforeoperating a riding lawn mower.
Protecting Children
Tragic accidents can occur if the operator is not
alert to the presence of children. Children are
frequently attracted to the machine and the
mowing activity. Do not think that children will
stay where you last saw them.
• Keep children out
of the mowing area
and in the watchful
care of a responsible
adult other than the
operator.
• Be alert and turn
machine off if a child
enters the area.
• Before and while backing, look behind and
down for small children.
• Do not carry
children, even with
the blades shut off.
They can fall off and
be seriously injured
or interfere with safe
machine operation.
Children who have
been given rides in the past can suddenly come
into the mowing area to ride again and be run
over or backed over by the machine.
• Do not let children to operate the machine.
• Use extreme care when going near blind
corners, shrubs, trees, or other objects that can
block your view of a child.
General Operation
• Read, understand,
and obey all
instructions on the
machine and in
the manual before
starting.
• It is recommended
that someone knows
that you are mowing and can give aid if there is
an injury or accident.
• Those who operate, maintain, and/or service
this machine must rst read and understand this
Operator Manual. Local laws can regulate the
age of the user. The owner is responsible for
training the users of this equipment.
• The owner and operator of this equipment
can prevent accidents and is responsible for
accidents or injuries occurring to themselves,
other persons and/or property.
• Do not put hands or feet near rotating parts
or under the machine. Keep away from the
discharge opening at all times.
• Only let responsible adults, who are familiar
with the instructions, to operate the machine.
• Clean the area of
objects such as
rocks, toys, wire,
etc., which could
be picked up and
thrown by the
blades.
• Be sure the area
is has no bystanders before operating. Stop
machine if someone enters the area.
• Do not mow in reverse unless fully necessary.
Always look down and behind before and while
backing.
• Do not point discharged material toward
someone. Avoid discharging material against a
wall or obstruction. Material can ricochet back
toward the operator. Stop the blades when
going across gravel surfaces.
• Do not operate machine without the full grass
catcher, discharge guard, or other safety
devices in place and working.
• Slow down before turning.
• Always turn off blades, move the steering
control lever out to the park brake position, stop
engine and remove keys before dismounting.
• Do not carry passengers. The machine is only
intended for use by one person.
• Operate the machine only in daylight or good
articial light.
7
SAFETY

• Disengage blades when not mowing. Shut off
engine and wait for all parts to come to a full
stop before cleaning the machine, removing
the grass catcher or unclogging the discharge
guard.
• Do not operate the machine while under the
inuence of alcohol or drugs.
• Look for trafc when operating near or going
across roadways.
• Use more care when loading or removing the
machine into a trailer or truck.
• Always wear eye protection when operating
machine.
WARNING! When using the machine,
approved personal protective equipment must
be used. Personal protective equipment cannot
remove the risk of injury but it will reduce the
degree of injury if an accident does occur.
Speak to your retailer for aid in choosing the
right equipment.
• Wear correct Personal Protective Equipment
(PPE) while operating this machine, including
(at a minimum) sturdy footwear, eye protection,
and hearing protection. Do not mow in shorts
and/or footwear with open toes.
• Data shows that operators age 60 years and
above are involved in a large percentage of
riding mower-related injuries. These operators
must evaluate if they can safely operate the
riding mower sufciently to protect themselves
and others from serious injury.
• Obey the manufacturer’s recommendation for
wheel weights or counterweights.
• Keep machine free of grass, leaves or other
debris buildup which can touch hot exhaust or
engine parts and burn. Do not let the mower
deck plow leaves or other debris that can cause
a buildup to occur. Clean oil or fuel spillage
before operating or storing the machine.
• Let machine cool before storage.
Personal Safety Equipment
• Make sure that rst
aid equipment is
near at hand when
using the machine.
• Do not use the
machine when
barefoot.
• Always wear
protective shoes or boots. Steel toe caps are
recommended.
• Always wear approved protective glasses or a
full visor when assembling or driving.
• Always wear gloves when handling the blades.
• Do not wear loose clothing that can become
caught in moving parts.
• Use ear protectors to avoid damage to hearing.
Slope Operation
Slopes are a major cause related to loss of
control and tip-over accidents, which can result in
severe injury or death. Operation on slopes
requires more care. If you cannot back up the
slope or if you feel uneasy on it, do not mow it.
• Mow up and down
slopes (10 degrees
maximum), not
across.
• Look for holes, ruts,
bumps, rocks, or
other hidden objects.
Uneven terrain
could overturn the machine. Tall grass can hide
obstacles.
• Select a low ground speed so it will not be
necessary to stop while on the slope.
• Do not mow on wet grass. Tires can lose
traction.
• Avoid starting, stopping, or turning on a slope. If
the tires lose traction, disengage the blades and
continue slowly straight down the slope.
• Move slowly and
gradually on slopes.
Do not make
sudden changes in
speed or direction,
which could cause
machine to roll over.
• Use more care while
operating machine with grass catchers or other
attachments; the stability of the machine can be
effected.
• Do not use on steep slopes.
• Do not try to stabilize the machine by putting a
foot on the ground.
• Do not mow near drop-offs, ditches, or
embankments. The machine could suddenly
roll over if a wheel is over the edge or the edge
caves in.
WARNING! Do not drive up or down hills
with slopes greater than 10 degrees. Do not
drive across slopes.
8
SAFETY

Safe Handling of Gasoline
To avoid personal injury or damage to property,
use care in handling gasoline. Gasoline is very
ammable and the vapors are explosive.
WARNING! The engine and the exhaust
system become very hot during operation.
There is a risk for burns if touched. Let engine
and exhaust system to cool before refueling.
• Do not fuel the
machine indoors.
• Extinguish all
cigarettes, cigars,
pipes, and other
sources of ignition.
• Use only approved
gasoline containers.
• Do not remove gas cap or add fuel with
the engine running. Let engine cool before
refueling.
• Do not keep the machine or fuel container
where there is an open ame, spark or pilot light
such as on a water heater or other appliance.
• Before you start refueling, keep the risk of static
electricity to a minimum by touching a metal
surface.
• Do not ll containers in a vehicle or on a truck
or trailer bed with plastic liner. Always put
containers on the ground away from the vehicle
when lling.
• Do not put too much fuel in the tank. Replace
gas cap and tighten securely.
• Remove gas-powered equipment from the truck
or trailer and refuel it on the ground. If this is not
possible, refuel such equipment with a portable
container, rather than from a gasoline dispenser
nozzle.
• Keep the nozzle in contact with the rim of the
fuel tank or container opening at all times until
fueling is complete. Do not use a nozzle lock-
open device.
• If fuel is spilled on clothing, change clothing
immediately.
• Do not start the engine near spilled fuel.
• Do not use gasoline as a cleaning agent.
• If leaks occur in fuel system, the engine must
not be started until problem has been resolved.
• Check the fuel level before each use and leave
space for the fuel to expand, because the heat
from the engine and the sun can otherwise
cause the fuel to expand and overow.
General Maintenance
• Do not use the
machine indoors or
in spaces lacking
correct ventilation.
The exhaust
fumes contain
carbon monoxide,
an odorless and
poisonous lethal gas.
• Make sure that the equipment is in good
condition and that all nuts and bolts, especially
those fastening the blade attachments, are
correctly tightened and torqued.
CAUTION! Use protective glasses
for maintenance work.
• Maintain or replace safety and instruction labels
as necessary.
• Do not interfere with the intended operation
of or reduce the protection given by a safety
device. Check their operation regularly. DO
NOT operate a machine with a safety device
that does not operate correctly.
• Check grass catcher components and the
discharge guard frequently and replace with
manufacturer’s recommended parts when
necessary.
WARNING! The engine must not
be started when the driver’s oor plate or
protective plates for the mower deck’s drive
belt is removed.
• Do not change the settings of engine controllers
and avoid running the engine at overly high
engine speeds. If you run the engine too fast,
machine components could be damaged.
• To reduce the risk of re, keep machine free of
grass, leaves or other debris buildup. Clean oil
or fuel spills and remove fuel-soaked debris. Let
machine cool before storing.
• Stop to do an inspection of the equipment if you
run over or into anything. If necessary, make
repairs before starting.
• Do not make adjustments or repairs with the
engine running.
• The blades are sharp and can cause cuts and
gashes. Wrap blades or use protective gloves
when handling them.
• Check the park brake’s operation regularly.
Adjust and service as necessary.
• Do not work with the starter circuit if there is
spilled fuel.
9
SAFETY

• Make sure that the fuel ller cap is mounted
tightly and no ammable substances are kept in
an open vessel.
• Sparking can occur
when working with
the battery and the
heavy cables of the
starter circuit. This
can cause battery
explosion, re or eye
injury. Sparking will
not occur after the grounding cable (normally
negative, black) is removed from the battery.
• Disconnect the grounding cable from the battery
rst and reconnect it last.
• Do not make a bridge short circuit across the
starter relay to run the starter.
• Be very careful when handling battery acid.
Acid on skin can cause serious corrosive burns.
If you spill battery acid on your skin, rinse
immediately with water.
• Acid in the eyes can cause blindness, contact a
doctor immediately.
• Be careful when
servicing the battery.
Explosive gases form
in the battery. Do
not do maintenance
on the battery when
smoking or near
open ames or
sparks. The battery can explode and cause
serious injury or damage.
• The machine is tested and approved only
with the equipment originally supplied or
recommended by the manufacturer. Only use
approved repair parts for the machine.
• The mulch blades must only be used in familiar
areas when higher quality mowing is necessary.
• Regularly clean the deck and the underside of
the deck. Avoid spraying engine and electrical
components with water.
Transport
• The machine is heavy and can cause serious
crushing injuries. Be more careful when it is
loaded on or removed from a vehicle or trailer.
• Use full width ramps for loading machine into a
trailer or truck.
• The two front and rear tie down straps must
be used and directed down and out from the
machine.
• Check and abide by local trafc regulations
before transporting the machine on roads.
• Use an approved trailer to transport the
machine. Turn off the fuel supply. Fasten the
machine down with approved devices such as
bands, chains or straps.
• Do not tow this machine, it can cause damage
to the drive system.
• Do not tow trailers, etc. with this mower. They
can jackknife or overturn, causing damage to
the mower and possible serious injury to the
operator.
• Load the unit onto truck or trailer by driving up
ramps of sufcient strength using a slow speed.
Do not lift! The machine is not intended to be
lifted by hand.
• When loading or removing this machine, do not
use more than the maximum recommended
operation angle of 10 degrees.
WARNING! Use extreme care when
loading the machine into a truck or trailer using
ramps. There is the possibility of serious injury
or death if the machine falls off the ramps.
IMPORTANT INFORMATION The park brake
is not sufcient to lock the machine in place
during transport. Make sure the machine is
correctly fastened to the transport vehicle.
Always reverse the machine onto the transport
vehicle to avoid tipping it over.
Towing
If machine is equipped with a tow hitch, use much
more caution when towing. Do not let children or
others in or on towed equipment.
Make wide turns to avoid jack-kning. Travel
slowly and leave more distance to stop. Do not
tow on sloped ground. The weight of the towed
equipment may cause loss of traction and loss of
control.
Follow the manufacturer’s recommendation for
weight limits for towed equipment. Do not tow
near ditches, canals, and other hazards.
Spark Arrestor
This mower is equipped with an internal
combustion engine and must not be used on
or near unimproved forested, bush covered
or grassy lands unless the engine’s system is
equipped with a spark arrestor meeting applicable
local or state laws. Federal laws apply on federal
lands. If a spark arrestor is used, it must be
maintained in good working order by the operator.
A spark arrestor for the mufer is available
through your authorized Husqvarna dealer.
10
SAFETY

Rollover Protection System
The Rollover Protection System (ROPS)
increases the basic weight of the unit by 73 lb (33
kg).
• Do not use ROPS as a lifting, attaching or
anchoring point.
• Do not use ROPS for wrecking or towing.
• Do not exceed Max GVW: 1900 lb (862 kg).
• Read the operator manual before use.
• Securely fasten the seat belt if the unit has a
ROPS.
• Be certain the seat belt operates correctly
and can be released quickly in the event of an
emergency.
• Keep folding ROPS in the raised and locked
position and use the seat belt when operating
the machine.
• Lower a folding ROPS temporarily only when
absolutely necessary. Do NOT wear the seat
belt when the ROPS is folded down.
• Check carefully for overhead clearance (i.e.
before driving under trees, electrical wires,
through doorways) while loading into a truck or
trailer.
• Keep the ROPS in safe operating condition by
periodically inspecting for damage and keeping
all mounting fasteners tight. Check all bolts,
including on the seat belt, for correct torque
before each use.
• Check the ROPS structure for damage before
each use. If any part of the ROPS is damaged,
the entire ROPS must be replaced.
• DO NOT remove the ROPS.
• Where possible, avoid operating the unit near
ditches, embankments and holes.
• Reduce speed when turning, crossing slopes
and on rough, slick or muddy surfaces. Stay off
slopes too steep for safe operation.
• Watch where you are going, especially at row
ends, on roads and around trees.
• Do not permit others to ride.
• Operate mower smoothly, no jerky turns, starts
or stops.
• When mower is stopped, engage park brake
securely.
• ROPS bar is NOT intended for use in sub zero
temperatures.
WARNING! Please note that there is NO
roll over protection when the ROPS is folded
down.
11
SAFETY

2
3
4
5
12
11
10
9
8
7
1
6
13
14
15
2
5
3
This operator manual describes the Husqvarna
Zero Turn Rider. The rider is tted with a four-
stroke overhead valve engine.
Transmission from the engine is made via
belt-driven hydraulic pumps. Using the left and
right steering controls, the ow is regulated and
thereby the direction and speed.
1.Steering / park brake controls
2.Tracking controls
3.Fuel gauges
4.Service meter
5.Fuel tank caps
6.Fuses
7.Fuel tank selector
8.Choke control
9.Ignition switch
10.Throttle control
11.Blade switch
12.Seat adjustment lever
13.Deck height pin
14.Deck lift pedal
15.Deck release pedal
12
CONTROLS

Steering Control Levers
The machine’s speed and direction are
continuously variable using the two steering
controls. The steering controls can be moved
forward or backward about a neutral position.
There is a neutral position, which is locked if the
steering controls are moved out.
When the two controls are in the neutral position
(N), the machine stands still. Equally moving
the two controls forward or backward moves the
machine in a straight line forward or backward.
For example, to turn right while moving forward,
move the right control towards the neutral
position. The rotation of the right wheel is reduced
and the machine turns to the right.
Forward
Neutral
Reverse
Park
Brake
Zero turn can be achieved by moving one control
backward (behind the neutral position) and
carefully moving the other steering control forward
from its neutral position. The rotation direction
when zero turning is determined by which
steering control is moved backward behind the
neutral position. If the left steering control is pulled
backward, the machine turns to the left. Use more
care when using this maneuver.
If the steering controls are in uneven positions
when standing still or do not t in the slots for
moving the controls out, they can be adjusted.
WARNING! The machine can turn very
rapidly if one steering control is moved much
further forward than the other.
Park Brake
The park brake is integrated with the steering
control levers. Move the two levers out from the
neutral position to engage the park brake.
To release the park brake, pull the two steering
control levers inwards to the neutral position at
the same time. Do not operate the unit without
the two levers being inwards out of the engaged
position or machine components could be
damaged.
IMPORTANT INFORMATION Failure to bring
the steering / park brake controls inward at the
same time will cause the unit's safety system to
shut the unit down.
Throttle Control
The throttle control regulates the engine speed
and the rate of rotation of the blades, assuming
the blade switch is pulled out.
To increase or decrease the engine speed, the
control is moved forward or back respectively.
Avoid idling the engine for long periods, as there
is a risk of fouling the spark plugs. USE FULL
THROTTLE WHEN MOWING, for best mower
performance and battery charging.
13
CONTROLS

Fuses
Fuses are located on the left hand side of the
machine and are accessed by tilting the seat
forward. Fuses are at pin fuses type as used in
automobiles. The 20Ais the primary fuse. The
7.5 A is for the mower deck coupling. The 10A is
for accessories.
Blade Switch
To engage the mower deck, pull the knob out;
mower blades are disengaged when the knob is
pressed down.
Service Meter
The service meter is located on the left hand
control panel and shows the total operating time
with the blades engaged.
After every 50 hours of operation, an oil can icon
will appear and stay on for two hours, before
an automatic reset occurs. To manually reset
the meter, turn the key off and on ve times at
one second intervals. To service the engine and
mower, see the Service Journal of this manual.
Choke Control
The choke control is used for cold starts to
provide the engine with a richer fuel mixture.
For cold starts, pull the control up.
Ignition Switch
The ignition switch is used to start and stop the
engine. On models equipped with headlights, turn
the key clockwise to ACCESSORY for headlight
use.
Fuel Gauges
Fuel gauges for each fuel tank are located the
right and left control panels.
14
CONTROLS

Fuel Shut Off Valve
The fuel shut off valve is located at the right rear
of the seat. The valve has three positions: right
tank, left tank and OFF.
Cutting Height
The cutting height pedals release the deck lift and
set the desired deck height. Apply pressure to
the lift pedal (lower) and rotate foot to also apply
pressure to the release pedal (upper), unlocking
the deck lift.
For transport, push the lift pedal forward until the
deck lift latches in the transport (highest) position.
The cutting height can be set from 1" – 5" (25.4
mm – 127 mm). To set the deck cutting height,
press the button on the top of the height pin to
remove it. Slip the height pin into the hole for the
desired cutting height.
Release deck height control pedal by pushing it
forward.
IMPORTANT INFORMATION Always raise the
deck to the highest position for transport.
Seat Adjustment
The seat can be adjusted lengthways with the
lever located at the right hand side of the seat.
When making adjustments the lever is moved
upward.
Adjustments may be made to seat suspension by
turning the center knob.
IMPORTANT INFORMATION Seat must not
be adjusted while unit is in motion.
Seat Release
The seat can be rotated forward to access the
mower battery and hydro gears. Push down on
the latch lever to release the seat. Raise the seat
until the rod engages.
Fuel Tanks
Read the safety instructions before refueling. The
capacity for each tank is six gallons (22.7 litres).
Regularly check the gas cap gasket for damage
and keep the cap properly tightened.
WARNING! Fill to bottom of ller neck.
Do not overll. Wipe off spilled oil or fuel. Do
not store, spill or use gasoline near an open
ame.
The engine will run on a minimum of 87-octane
unleaded gasoline (no oil mix). Environmentally
adapted alkylate gasoline can be used. See
15
CONTROLS

Tracking
If the mower is not tracking straight, check the air
pressure in the two rear tires. Recommended air
pressure for the rear tires is 15 psi (1 bar).
1.Tracking adjustments are made using the
tracking bolts. The bolts act as limiting devices
for the motion control levers when in the full-
forward position.
Technical Data concerning ethanol fuel. Methanol
fuel is not allowed. Do not use E85 alcohol based
fuel. Damage to the engine and components may
occur.
When operating in temperatures below 32°F
(0°C), use fresh, clean winter grade gasoline to
help insure good cold weather starting.
IMPORTANT INFORMATION Experience
indicates that alcohol blended fuels (called
gasohol, ethanol or methanol) can attract
moisture which leads to separation and
formation of acids during storage. Acidic gas
can damage the fuel system of an engine while
in storage. To avoid engine problems, the fuel
system must be emptied before storage of 30
days or longer. Drain the gas tank, start the
engine and let it run until the fuel lines and
carburetor are empty. Use fresh fuel the next
season. See Storage for more information. Do
not use engine or carburetor cleaners in the
fuel tank or permanent damage may occur.
WARNING! Gasoline is highly ammable.
Observe caution and ll the tank outdoors (see
the safety section).
WARNING! The engine and the exhaust
system, become very hot during operation.
There is a risk for burns if touched. Let engine
and exhaust system to cool before refueling.
2.For preliminary tracking adjustment, move
unit to an open, unobstructed area such as an
empty parking lot or open eld.
3.Back the bolts out until ush with nut.
4.Test operate unit by driving it at full throttle
and the full forward position on the two
steering control levers. Gradually turn in the
tracking bolt on the right hand side until the
unit noticeably starts drifting right.
5.Drive forward at full throttle with the two
steering control levers in the full forward
position. Gradually turn in the left hand
tracking bolt until unit tracks straight.
16
CONTROLS

Read the Safety section and following pages, if
you are unfamiliar with the machine.
Training
Due to unique steering capabilities, zero turn
mowers are far more maneuverable than typical
riding mowers.
Review this section fully before trying to move the
mower under its own power. When rst operating
the mower or until becoming comfortable with
controls, use a reduced throttle speed and
reduced ground speed. DO NOT move control
levers to the furthest forward or reverse positions
during initial operation.
First time users must become familiar with the
mower’s movement on a hard surface, such as
concrete or blacktop BEFORE trying to operate
on turf. Until the operator becomes comfortable
with the mower controls and zero turn, overly
aggressive maneuvers can damage turf.
Steering
To move forward and rearward
The direction and speed of the mower’s
movements are effected by the movement of
the control lever(s) on each side of mower. The
left lever controls the left wheel. The right lever
controls the right wheel.
First time users must push the mower (see
Moving Machine By Hand in the Operation
section) to an open, at area without other
persons, vehicles or obstacles nearby. To move
the unit under its own power, the operator must
sit in the seat and start the engine (see Before
Starting in the Operation section). Adjust the
engine speed to idle but do not engage the
blades. Pull control levers inward. As long as the
control levers have not been moved forward or
rearwards, the mower will not move.
Slowly move the two control levers forward
slightly. This will let the mower start moving
forward in a straight line. Pull the control levers
back to the neutral position and stop the mower
from moving.
Pull back slightly on control levers, allowing the
mower to move rearwards. Push the control
levers forward to the neutral position to stop the
mower from moving.
To turn to the right
While moving in a forward direction, pull the right
lever back towards the neutral position while
maintaining the position of the left lever, this will
slow the rotation of the right wheel and cause the
machine to turn in that direction.
To turn to the left
While moving in a forward direction pull the left
lever back towards the neutral position while
maintaining the position of the right lever, this will
slow the rotation of the left wheel and cause the
machine to turn in that direction.
To zero turn
While moving in a forward direction, rst pull the
two control levers back until the mower stops or
slows dramatically.
Then by alternating one lever slightly to the
forward position and the other in the reverse
position, complete the turn.
WARNING! Make sure the work area is
free of stones and other objects that could be
thrown by the rotating blades.
Roll Bar
Operate the unit with the roll bar in the raised and
locked position and use the seat belt. There is
no rollover protection when the roll bar is down.
If it is necessary to lower roll bar, do not wear the
seat belt. Raise the roll bar as soon as clearance
permits.
WARNING! The seat belt must be used
when the roll bar is in upright position.
Before Starting
WARNING! Make sure the work area is
free from of stones and other objects that could
be thrown by the rotating blades.
1.Read the sections on Safety and Controls
before starting the machine.
2.Perform the daily maintenance before
starting (see Maintenance Schedule in the
Maintenance section).
3.Check that there is sufcient fuel in the fuel
tank.
4.Adjust the seat to the desired position.
The following conditions must be fullled before
the engine can be started:
• The blade switch must be pressed down into
the disengaged position.
• The two steering / park brake controls must be
in the locked (outer) position.
Starting the Engine
1.Sit on the seat.
2.Raise the mower deck to the transport
position by pushing the lift pedal forward.
17
OPERATION

3.Disengage the mower blades by pressing the
blade switch down.
4.Move the steering / park brake controls to the
locked (outer) position.
5.Move throttle control to the middle position. If
the engine is cold, pull the choke control up.
6.Set the fuel tank valve to the desired tank.
7.Set the deck height pin in the desired position.
8.Press in and turn the ignition key to the start
position.
IMPORTANT INFORMATION Do not run the
starter for more than ve seconds each time. If
the engine does not start, wait approximately
ten seconds before retrying.
9.When the engine starts, immediately release
the ignition key back to the run position.
Slowly push in the choke control knob, if it
was used to start a cold engine.
10.Set the engine speed with the throttle.Allow
the engine to run at a moderate speed,
approximately mid throttle, for a short time
before use. USE FULL THROTTLE WHEN
MOWING (no choke).
Running
1.Release the park brake by pulling the steering
/ park brake controls in to the neutral position
at the same time.
NOTE: The mower is equipped with an
operator presence system. If the operator
tries to leave the seat with the engine running,
without rst engaging the park brake, the
engine will shut off.
2.Release deck height control by pushing the
pedal forward to lower the deck to selected
setting.
3.Move throttle control to full throttle.
4.Engage the mower deck by pulling the blade
switch up.
WARNING! Make sure that no one is
near mower when engaging blade switch.
5.Pull control levers inward and slowly move
the two control levers slightly forward to move
forward in a straight line.
Stopping the Engine
1.Move the throttle to the minimum position
(tortoise symbol).
2.Move the steering / park brake controls at the
same time out to the park brake position.
3.Release the mower deck by pressing the
blade switch down.
4.Raise the mower deck by pressing the foot
pedals forward to the transport position.
If the engine has been worked hard, allow it to
idle at least sixty seconds to attain a normal
operating temperature before stopping. To
prevent fouling the spark plugs, avoid idling
the engine for longer periods.
5.Turn the ignition key to the stop position and
remove the key. Always remove the key when
leaving the mower to prevent unauthorized
use.
IMPORTANT INFORMATION When stopping
and leaving the machine, the two steering /
park brake controls must be moved out to the
locked position at the same time.
IMPORTANT INFORMATION Leaving the
ignition switch in a position other than OFF will
cause the battery to be discharged.
Operating on Hills
Read the Safety Instructions Driving on Slopes
in the Safety section.
• Use the slowest speed possible before starting
up or down hills.
• If stopping is fully necessary, pull steering / park
brake controls into the neutral position and push
outward to engage the park brake.
• Pull the steering / park brake controls back to
the center of the mower and push forward to
regain forward movement.
18
OPERATION

Mowing Tips
• Find and ag rocks and other xed objects to
avoid collisions.
• Begin with a high cutting height and reduce it
until the desired mowing result is attained. Cut
the average lawn to 2-1/2" (63.5 mm) during
the cool season and over 3" (76.2 mm) during
the hot months. For healthier and better looking
lawns, mow often after moderate growth.
• For best cutting performance, mow grass over
6" (15.2 cm) in height twice. Make the rst cut
relatively high; the second to the desired height.
• The mowing result will be best with a high
engine speed (the blades rotate rapidly) and
low speed (the rider moves slowly). If the grass
is not too long and dense, the driving speed can
be increased without negatively affecting the
mowing result.
• When mowing large areas, start by turning to
the right so that clippings will discharge away
from shrubs, fences, driveways, etc. After one
or two rounds, mow in the opposite direction
making left hand turns until nished.
• The nest lawns are obtained by mowing
often. The lawn becomes more even and the
grass clippings more evenly distributed over
the mown area. The total time taken is not
increased as a higher operating speed can be
used without poor mowing results.
• Avoid mowing wet lawns. The mowing result
is poorer because the wheels sink into the soft
lawn, clumps build, and grass clippings fasten
under the cowling.
• Hose the mower deck underside with water
after each use. When cleaning, the mower deck
shall be raised into the transport position. Make
sure the mower is cooled and the engine is off.
• Use compressed air to clean top surface of
the deck. Avoid ooding water on top surface,
engine and electrical components.
• When the mulching kit is used, it is important
that the mowing interval is frequent.
WARNING! Do not make adjustments
unless:
• the engine is stopped,
• the ignition key is removed,
• the park brake is engaged
Moving Machine By Hand
Bypass Valves
Bypass valves are used to release the system so
the machine may be moved by hand when not
running.
Hydraulic Pumps
When pushing or pulling the mower, engage
the bypass valve on each transaxle. Access to
the valves is from the lower rear of the unit. the
bypass valves are located on the front, inner
sides of the transaxles. Set the deck to the lowest
position when accessing the pump valves. To
disengage each pump, turn the slot on the pump
valve 45O clockwise from the RUN position to the
BYPASS position.
Load the machine into truck or trailer by driving up
ramps in low gear. DO NOT LIFT! The machine is
not intended to be lifted by hand.
WARNING! Use extreme caution when
loading the machine into a truck or trailer using
ramps. There is the possibility of serious injury
or death if the machine falls off the ramps.
• Try not to stop or change speed on hills.
• Make all turns slowly.
WARNING! Do not drive the rider on
terrain that slopes more than 10 degrees. Mow
slopes up and down, never side to side. Avoid
sudden directional changes.
19
OPERATION

Maintenance Schedule
Following is a list of maintenance procedures
that must be performed on the machine. For
those points not described in this manual, visit an
authorized service workshop. An annual service
MAINTENANCE
DAILY
AT
LEAST
ONCE
EACH
YEAR
MAINTENANCE
INTERVAL
IN HOURS
BEFORE AFTER 50 250 500
CHECK
Park brake for adjustment ● ● ● ● ●
Engine’s oil level (every refueling) ■
Safety system ●
For fuel and oil leakages ♦
For damage ♦ ♦ ♦ ♦
For loose hardware (screws, nuts) ●
For mower deck damage ●
Tire pressures ● ● ● ●
Battery connections ● ● ● ●
CLEAN
Engine’s cooling air intake ■
Under the mower deck ● ● ● ●
Around the engine ♦ ♦ ♦ ♦
Around belts, belt pulleys ♦ ♦ ♦ ♦
Engine’s cooling air intake 2) ■ ■ ■ ■
Air cleaner foam pre-lter 2) ■ ■
Air cleaner paper lter cartridge 2) ■ ■
ALSO
Inspect mufer/spark arrestor ♦ ♦ ♦ ♦
Start the engine & blades, listen for unusual sounds ♦
Sharpen3)/ Replace mower blades ● ● ● ●
1) First change after 8-10 hours. When
operating with a heavy load or at high ambient
temperatures, replace every 50 hours.
2) In dusty conditions, cleaning and replacement
are required more often.
3) Performed by authorized service workshop.
carried out by an authorized service workshop
is recommended to maintain your machine in
the best possible condition and to ensure safe
operation.
Read General Maintenance in the Safety
section.
●= Described in this manual
♦= Not described in this manual
■= Refer to the engine manufacturer’s manual
WARNING! Before performing service or
adjustment:
• Engage the park brake.
• Place the blade switch in the disengaged
position.
• Turn the ignition switch to OFF position and
remove the key.
• Make sure the blades and all moving parts
have stopped.
20
MAINTENANCE
