Hussmann Q1-DC Wedge Instruction Manual

26
1 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series
ETL Listed
40427
ETL Sanitation
40427
ETL Sanitation
These merchandisers are manufactured to meet ANSI/National Sanitation
Foundation Standard #7 requirements.
We reserve the right to change or revise specifications and
p
roduct design in connection with any feature of our
p
roducts. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75F and 55% R.H.
Deli
Discharge Air (F) 26
Evaporator (F) 20
N
ote: Not recommended to control temp by regulating
coil temp allow t-stat to cycle and control temp.
B
tu/hr/
ft
*
Parallel 450
Conventional 518
*For all refrigeration equipment other than Hussmann,
use conventional Btu values.
DEFROST DATA
Frequency Hrs 6
OFFTIME
Temp Term °F 54
Failsafe Minutes 40
ELECTRIC or GAS Not Recommended
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/2
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 5/8
Estimated Charge (lb)***
4ft 1.2
5ft 1.5
6ft 1.8
*** This is an average for all refrigerants types. Actual
refrigerant charge may vary by approximately half a
p
ound. GLYCOL REQUIREMENTS
GPM PSI
3ft 0.5 1.6
4ft 0.6 3.1
5ft 0.8 4.9
6ft 1.0 1.9
8ft 1.3 3.5
10ft 1.6 5.4
12ft 1.9 3.8

26
2 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series
Engineering
CROSS SECTION

26
3 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series
Q1-DC Curved Glass Service Deli
Engineering
CROSS SECTION

26
4 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series
Engineering
PLAN VIEW

26
5 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series
Q1-DC Q1-DC-4R 4' W1750001
Deli-Curve Glass Q1-DC-6R 6' W1750002
RJ-45,Ledge Lights Q1-DC-8R 8' W1750003
12' W1750005
Q1-DC Q1-DC-4R 4' W1750006
Q1-DC-5R 5' W1750026
Deli-Curve Glass Q1-DC-6R 6' W1750007
Standard Case Q1-DC-8R 8' W1750008
Q1-DC-9R 9' W1750009
Q1-DC-10R 10' W1750009
Q1-DC-12R 12' W1750010
Q1-DC-S Q1-DC-3S 3' W1750034-01
Q1-DC-4S 4' W1750034-02
Q1-DC-5S 5' W1750034-03
Q1-DC-6S 6' W1750034-04
Q1-DC-7S 7' W1750034-05
Q1-DC-8S 8' W1750034-06
Q1-DC-9S 9' W1750034-07
Q1-DC-10S 10' W1750034-08
Q1-DC-11S 11' W1750034-09
Q1-DC-12S 12' W1750034-10
Q1-DS-S Q1-DS-3S 3' W1750034-01
Q1-DS-4S 4' W1750034-02
Q1-DS-5S 5' W1750034-03
Q1-DS-6S 6' W1750034-04
Q1-DS-7S 7' W1750034-05
Q1-DS-8S 8' W1750034-06
Q1-DS-9S 9' W1750034-07
Q1-DS-10S 10' W1750034-08
Q1-DS-11S 11' W1750034-09
Q1-DS-12S 12' W1750034-10

26
6 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
7 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
8 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
9 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
10 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
11 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
12 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
13 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
14 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
15 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
16 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
17 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
18 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
19 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series

26
20 of 26
Q1-DC/DS
Technical Data Sheet
P/N Q1-DC/DS
Rev B
S
p
ecialt
y
Products
Q-Series
