HVCAM HV-72CIC User manual

1
User Manual
(For Web browser viewing)
Mode: HV-72CIC
Indoor Wireless IP Camera
Color: White

2
Chapter 1 Camera installation guide
Product overview

3

4
Chapter 2 Features
1. Basic features
The basic function of IPCAM is to provide remote video on the IP network. Real-time
video images (720P, QVGA and VGA) quality are transmitted at up to 30fps on the
LAN/WAN by using H.264/MJPEG hardware compression technique.
IPCAM is completely based on TCP/IP standard network protocol, Embedded WEB
server in IPCAM supports IE browser, Centralized monitoring the client and mobile phone
client browser. Therefore the management and maintenance of your device is simplified
by using the network to remotely configure, start-up, and upgrade the firmware of your
IPCAM. You can easily monitor and control image anytime in any place via clicking on the
net.
2. Advanced Features
 Powerful High-performance media processor 32Bit RSIC
 High Definition COMS Sensor, up to real-time 30fps
 Optimized Motion—JPEG/H.264 video compression algorithm for high-definition
video transmission
 Support livestream,videostream and snapshot mode, each mode can be browsed by
4 users or less.
 Embedded Web Server for users to realize real-time monitoring and settings
management
 Support WIFI WIRELESS LAN
 Support wireless P2P mode
 Support DDNS, you can add manufactories domain name.
 Support Motion Detection and Alarm by sending emails, ftp pictures and Output
warning.
 Support mobile phones
 Support two-way voice intercom

5
Chapter 3 web instructions
1. Search Tool:
1.1 Please connect the camera to the power and network cable, then open
from CD to enter the following interface:
1.2 Then click to search online camera list, double click the
selected camera:

6
1.3 Input the user name: “admin”(no password). Click
2. Select Language and Login mode
Select languages
2.1 Double click the selected mode to enter IE page, It will appear a prompt as below:

7
2.2 You need to download and install OCX plug-in for first time using IE
2.3 Install directly after decompression
2.4 Refresh the IE page to watch video after installation

8
3. Direction for using IE operating interface
3.1 Direction for main interface
：Flip vertical image ：mirroring image
：IO switch
: You can choose 50HZ or 60HZ to adjust indoor and
outdoor mode.
: Resolution adjustment; 720p（1280×720）
VGA(640×480) and QVGA(320×240) can be set.

9
：Frame rate adjustment；1-30 frame rate can be
set
：Adjustable if needed；
Factory default: It’s used to restore factory default in case you
adjust disorderly
：Speaker, You can listen to the sound from the camera where it is located
：Microphone, When click both icons, the operator and front of the camera can
achieve two-way voice talking.
: Recording Local video ：Snapshot
： parameters settings
One camera viewing
Four cameras viewing
Nine cameras viewing

10
3.2 Basic information
Click to enter parameter management page in the main interface as follows:
3.2.1 Device information
Click as follows:
: The version number of system software

11
: The version number of application software
: Display the name of device (customers can set the name if they want)
: That is Factory Series Number
: Alarm status display
: You can see whether the device enabled UPNP function and its state
: You can see a prompt of DDNS server if DDNS is set normally,
: Display wired MAC address of the device
: Display Wireless MAC address of the device
3.2.2 Video path
Click as shown below, click to choose where to store local
videos on your computer.
The camera will record automatically according to your time
schedule.

12
3.3 Alarm service settings
3.3.1 Alarm service
Click as shown below:
Choosing alarm mode: If you select , you will see:

13
There are some Alarm modes for selection: IO Linkage, sending mails, uploading images,
Alarm preset linkage. for example: all-day motion detection Arming, you can set detection
sensitivity to 10; it will output high level via liking IO, sending mails, uploading a ftp image
every 10 seconds, then aiming at preset position”1”; please see below settings:
Click to confirm.
3.3.2 Mail service settings
Click , the following screen will appear:

14
The key feature is E-mail Alarm, if the camera is triggered alarm, it will send alar
m messages to your settled email address.
: fill in E-mail address of the sender.
: Fill in E-mail address to receive Alarm messages.
: Fill in the sender’s mailbox website, such as QQ mailbox: smtp.qq.com
: Fill in username of sender’s mailbox
: Fill in the password of sender’s mailbox
Note: The camera need to connect Internet, if the password of sender’s mailbox changed,
the camera password must be the same as mailbox password before normal using.

15
3.3.3 FTP service
Click as shown below:
This feature is used to upload snapshots to specified folder on FTP server, it can’t be
normally used if there is no access to internet.
: Fill in URL of the site on which you want to upload
: The default is 21
: Fill in FTP username
: Fill in FTP user’s password
: Automatically and regularly upload capture pictures to FTP (in
seconds)

16
3.3.4 Alarm log
Click , you can check alarm information in below blank form:
4. Network configuration
Click
Get DHCP, device will obtain IP automatically:

17
Click to connect your Wi-Fi network:
Click
 Unlike legacy solutions, HVCAM does not require port forwarding. There is no risk
from leaving ports open on the network. HVCAM uses secure peer to peer networking
solution which provides a secure, encrypted connection each time your camera is viewed
from a remote location.

18
5. Multi-Device Settings
Click , you can control 9 camera(in LAN) simultaneously.
Then video show, you can add 9 cameras at the same time.

19
6. Back
Click , It will back to monitoring main interface.
Product Parameters:
Model HV-72CIC
Platform Smartphones Android，IOS app in CD
Sensor CMOS sensor
Display resolution 720P
sensor
Lens f: 3.6mm,
Audio Input/Output Linear input/output, two-way voice intercom
Video compression MJPEG/H264
Working frequency 50Hz, 60Hz
Image frame rate 25fps（50Hz), 30fps（60Hz),Automatic downward adjustment.
Image resolution 720P,640 x 480(VGA), 320 x 240(QVGA)
Night vision 10 infrared lights, infrared irradiation distance:8-12 meters
Wireless standard WIFI(IEEE802.11b/g/n)
P2P No Need to do Port forwarding,Easy to USE
Video
Support IP addresses Static and dynamic IP address
Alarm detection Motion detection
Alarm
Alarm notification Support Email, FTP alarm notification
Gross Weight
Specification
Packingl size(LxH) 184 x150x 110mm （LxWxH）about 440g
