Hydro-Force Brush Pro 17 User manual

Product Manual
and Users Guide
FOR MORE INFORMATION
VISIT WWW.HYDROFORCE.COM
Hydro-Force Manufacturing
4282 South 590 West
Salt Lake City, UT 84123
800-948-1779 • www.hydroforce.com
Brush Pro

Use original Brush Pro brushes only.

157
6
6

The machine may only be used by persons who have been instructed in its use and given authority to do so.
The power cord must be disconnected from the power outlet before cleaning, servicing the machine and before changing parts thereof.
Make sure the power cord is not damaged in any way by running over it, squashing or tearing it, etc.
The power cord must only be replaced by original spare part number 46 or a DIN 57.281 part 402/VDE 0281 part 402 05W3x 1 mm2 cable.
All connections of the main power cord supplied and all other power cord extensions that may be used by customer, must be splash water proof
certied and protected.
The machine must be tted with a power safety switch with a capacity of 10 amps or a 10 amps fuse.
This appliance is not to be used or stored outdoors in wet
conditions and is not suitable for working with or picking up
hazardous substances.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge unless they have been
given initial supervision or instruction concerning use of the
appliance by a person responsible for their safety.
No se con agentes quimicos o lipiadores que facilmente hacen
espuma cuando se estan aplicando o agentes limpiadores que
contengan solventes inamables. La valvula ph de los pro-
ductos limpiadores y quimicos usados con nuestro equipo no
deben exceder arriba de 10 PH y de bafo de 5 PH.
Technical Data Brush Pro 17 Brush Pro 20
Motor 800 W 800 W
Brush rotations 483 RPM 395 RPM
Sound level at 1.64 feet 57.8 dB 57.8 dB
Weight, lbs 46.9 lbs. 51.3 lbs.
Length, inches 17” 20”
Width, inches 11.2” 11.2”
Height without / with handle 9.1” / 46.1” 9.1” / 46.1”
Cable length 230V / 110V 32.81’ / 49.21’ 32.81’ / 49.21’
Dirty water capacity 95 . oz. 118 . oz.
Coverage - carpets* 2,500 sq. ft. per hour 3,500 sq. ft. per hour
Coverage - hard oors 3,500 sq. ft. per hour 4,500 sq. ft. per hour
* sq. ft. per hour based on excapsulation cleaning only
Pay particular attention to the following points regarding operation, use and maintenance:
ENGLISH
La máquina solo debe ser utilizada por personas que hayan tenido un entrenamiento previo y autorización para el uso de la misma.
La máquina debe estar desconectada antes de limpiarla, hacerle servicio o cambiale un repuesto.
Ver que el cable no este dañado pasando encima del mismo con la máquina.
El cable sólo debe ser rembplazado por por pieza original G 46 un cable DIN 57.281 o uno 402/VDE 0281 o uno 402 o5W 3x 1 mm2 cable.
La máquina no debe ser utilzada al aire libre, en condiciones lluviosas o húmedas ni con químicos o sustancias peligrosas.
La máquina debe tener un interruptor de corriente de una capa-
cidad de 10 amps o un fusible de 10 amps.
Toda las conexiones principales de corriente deben estar prote-
gidas al menos contra salpicones de agua.
La máquina no debe ser utilizada por personas con defectos
sicos, mentales, o con falta de experiencia a menos de que
estos sean supervisados por una persona responsable de su
seguridad.
No se use con agentes qumicos o limpiadores que facilmente
hacen espuma cuando se estan aplicando o agentes limpiad-
ores que contengan solventes inamables. La valvula pH de los
productor limpiadores y qumicos usados con nuestro equipo no
deben exceder arriba de 10 pH y de bajo de 5 pH.
Technical Data Brush Pro 17 Brush Pro 20
Motor 800 W 800 W
Rotacion de cepillos 483 RPM 395 RPM
Nivel de sonido 57.8 dB 57.8 dB
Peso en kilos 46.9 lbs. 51.3 lbs.
Longitud en cm 17” 20”
Ancho en cm 11.2” 11.2”
Altura sin el manubrio 9.1” / 46.1” 9.1” / 46.1”
Longitud del cable 230V / 110V 32.81’ / 49.21’ 32.81’ / 49.21’
Capacidad de aqua sucia 95 . oz. 118 . oz.
Cobertura alfrombra 2,500 sq. ft. per hour 3,500 sq. ft. per hour
Cobertura para pisos 3,500 sq. ft. per hour 4,500 sq. ft. per hour
* sq. ft. basado en limpieza con quimico encapsulador unicamente
Ponga particular atención a los siguientes punto relacionados con la operación, uso y mantenimiento:
ESPAÑOL

1
2
1
2
Carpet cleaning / Limpieza de alfombra

spare parts / repuestos

list of spare parts / repuestos
1
NM5200
SNAP RING A12
57
NM5266
CYLINDERHEAD SCREW M3 X 25
2
NM5202
BALL BEARING 6202 2RS
58
NM5267
WIRE FIXING PLATE
3
NM5371
DISTANCE PIECE G 20LM
60
NM5269
TERMINAL BLOCK
4
NM5203
SPLIT PIN 3 X 20A2
61
NM5271
V-RING
5
NM5205
VENTILATOR
62
NM5273
WORMSCREW
6
NM5373
MOTOR 20LM
63
NM5275
NUT M4
7
NM5374
DISTANCE PIECE E 20LM
64
NM5277
LOCK WASHER M4 A2
9
NM5211
TENSION SPRING
66
NM5379
CABLE PROTECTOR 20LM
10
NM5213
WORM SCREW M3 X 40
67
NM5279
BLIND
11
NM5215
NUT M3 BRASS
68
NM5242
HANDLE STOP KIT – SOLD WITH #27
12
NM5217
SPRING RING M3
69
NM5244
HANDLE STOP SPRING
13
NM5206
MICROSWITCH
70
NM5381
SEAL – COVER 20LM
14
NM5208
SWITCH PART
71
NM5283
SNAP RING A15
15
NM5221
WORM SCREW M5 X 25
72
NM5285
COVER - MICROSWITCHES
16
NM5223
NUT M5
74
NM5287
HANDLE CONNECTOR – UPPER PART
17
NM5225
DISC M5
75
NM5386
FLATBAR 20LM
18
NM5227
CYLINDER HEAD SCREW M5 X 12
77
NM5293
SCREW M3 X 5
19
NM5210
BALL BEARING 6003 2RS
78
NM5295
SNAP-IN
20
NM5212
FLANGE
79
NM5297
HANDLE UPPER PART
21
NM5229
HOUSING UNIT E COMPLETE
80
NM5299
BEARING
22
NM5214
SNAP RING 16X1
83
NM5387
CROSS BAR 20LM
23
NM5282
PROTECTIVE PLATE
84
NM5303
T-PIECE LEFT
24
NM5375
MOTOR STUD 20LM
25
NM5376
BRUSH COVER 20LM
86
NM5388
TANDEM BAR 20LM
26
NM5377
BRUSH AXLE 20LM
88
NM5389
HANDLE COMPLETE 20LM
27
NM5218 SEE #68
HANDLE CONNECTOR LOWER PART G
95
NM5309
SPRING RING M6
28
NM5237
CYLINDER HEAD SCREW M6 X 25
96
NM5311
SCREW M6 X 30
29
NM5219
HANDLE CONNECTOR LOWER PART E
109
NM5313
ISOLATING PLATE
30
NM5239
CYLINDER HEAD SCREW M6 X 16
122
NM5323
HANDLE LOWER PART LEFT
31
NM5220
GEAR 48 RIGHT
123
NM5325
HANDLE LOWER PART RIGHT
32
NM5222
GEAR 48 LEFT
124
NM5327
T-PIECE RIGHT
33
NM5241
GEAR COVER
126
NM5246
CABLE HOLDER
34
NM5243
LOCKWASHER M5
127
NM5329
SCREW COUNTERSUNK HEAD M5 X 6
35
NM5224
GEAR 66 RIGHT
128
NM5331
HOLDER LEFT
36
NM5245
HOUSING UNIT G COMPLETE
129
NM5333
HOLDER RIGHT
37
NM5378
COVER 20LM
130
NM5396
THROW-IN ACCELORATOR 20LM
39
NM5226
THERMO-RELAY
131
NM5337
SCREW COUNTERSUNK HEAD M4 X 12
40
NM5228
GEAR 66 LEFT
132
NM5339
PROTECTIVE COVER
41
NM5230
GEAR 85 RIGHT
133
NM5341
SCREW COUNTERSUNK HEAD M4 X 8
45
NM5234
GROMMET – CORD PROTECTOR
134
NM5343
O-RING
46
NM5236
CABLE – POWER CORD
136
NM5347
WHEEL – COVER PLATE
47
NM5249
BEARING PIN
152
NM5398
HOLDER TROLLEY – LM20
49
NM5251
CYLINDERHEAD SCREW M4 X 8
153
NM5353
WHEEL - TROLLEY
50
NM5238
RUN CAPACITOR
154
NM5399
AXLE - TROLLEY
51
NM5253
STARTING CAPACITOR
155
NM5357
BELT - TROLLEY
52
NM5255
CYLINDERHEAD SCREW M5 X 12
156
NM5401
TRAY WITH CLIPS & BELT – 20LM
53
NM5257
STARTING CONTROL
X45B
NM5409
RENOVATOR KIT 20LM (2 PIECESS)
54
NM5259
CLAMP STRIP
X45C
NM5411
DUST COVER WITHOUT WHEEL 20LM
(1 ONLY)
55
NM5261
FIXING SPRING
X45D
NM5415
TRANSPORT DOLLY COMPLETE 20LM
56
NM5263
CABLE CLAMP
X45E
NM5413
DUST COVER WITH WHEEL 20LM
(1 ONLY)

1
NM5200
SNAP RING A12
57
NM5266
CYLINDERHEAD SCREW M3 X 25
2
NM5202
BALL BEARING 6202 2RS
58
NM5267
WIRE FIXING PLATE
3
NM5201
DISTANCE PIECE G 17LM
60
NM5269
TERMINAL BLOCK
4
NM5203
SPLIT PIN 3 X 20A2
61
NM5271
V-RING
5
NM5205
VENTILATOR
62
NM5273
WORMSCREW
6
NM5207
MOTOR 17LM
63
NM5275
NUT M4
7
NM5209
DISTANCE PIECE E 17LM
64
NM5277
LOCK WASHER M4 A2
9
NM5211
TENSION SPRING
66
NM5240
CABLE PROTECTOR LM17
10
NM5213
WORM SCREW M3 X 40
67
NM5279
BLIND
11
NM5215
NUT M3 BRASS
68
NM5242
HANDLE STOP KIT – SOLD WITH #27
12
NM5217
SPRING RING M3
69
NM5244
HANDLE STOP SPRING
13
NM5206
MICROSWITCH
70
NM5281
SEAL – COVER 17LM
14
NM5208
SWITCH PART
71
NM5283
SNAP RING A15
15
NM5221
WORM SCREW M5 X 25
72
NM5285
COVER - MICROSWITCHES
16
NM5223
NUT M5
74
NM5287
HANDLE CONNECTOR – UPPER PART
17
NM5225
DISC M5
75
NM5289
FLATBAR 17LM
18
NM5227
CYLINDER HEAD SCREW M5 X 12
77
NM5293
SCREW M3 X 5
19
NM5210
BALL BEARING 6003 2RS
78
NM5295
SNAP-IN
20
NM5212
FLANGE
79
NM5297
HANDLE UPPER PART
21
NM5229
HOUSING UNIT E COMPLETE
80
NM5299
BEARING
22
NM5214
SNAP RING 16X1
83
NM5301
CROSS BAR 17LM
23
NM5282
PROTECTIVE PLATE
84
NM5303
T-PIECE LEFT
24
NM5233
MOTOR STUD 17LM
25
NM5235
BRUSH COVER 17LM
86
NM5306
TANDEM BAR 17LM
26
NM5216
BRUSH AXLE 17LM
88
NM5307
HANDLE COMPLETE 17LM
27
NM5218 SEE #68
HANDLE CONNECTOR LOWER PART G
95
NM5309
SPRING RING M6
28
NM5237
CYLINDER HEAD SCREW M6 X 25
96
NM5311
SCREW M6 X 30
29
NM5219
HANDLE CONNECTOR LOWER PART E
109
NM5313
ISOLATING PLATE
30
NM5239
CYLINDER HEAD SCREW M6 X 16
122
NM5323
HANDLE LOWER PART LEFT
31
NM5220
GEAR 48 RIGHT
123
NM5325
HANDLE LOWER PART RIGHT
32
NM5222
GEAR 48 LEFT
124
NM5327
T-PIECE RIGHT
33
NM5241
GEAR COVER
126
NM5246
CABLE HOLDER
34
NM5243
LOCKWASHER M5
127
NM5329
SCREW COUNTERSUNK HEAD M5 X 6
35
NM5224
GEAR 66 RIGHT
128
NM5331
HOLDER LEFT
36
NM5245
HOUSING UNIT G COMPLETE
129
NM5333
HOLDER RIGHT
37
NM5247
COVER 17LM
130
NM5335
THROW-IN ACCELORATOR 17LM
39
NM5226
THERMO-RELAY
131
NM5337
SCREW COUNTERSUNK HEAD M4 X 12
40
NM5228
GEAR 66 LEFT
132
NM5339
PROTECTIVE COVER
41
NM5230
GEAR 85 RIGHT
133
NM5341
SCREW COUNTERSUNK HEAD M4 X 8
45
NM5234
GROMMET – CORD PROTECTOR
134
NM5343
O-RING
46
NM5236
CABLE – POWER CORD
136
NM5347
WHEEL – COVER PLATE
47
NM5249
BEARING PIN
152
NM5351
HOLDER TROLLEY – 17LM
49
NM5251
CYLINDERHEAD SCREW M4 X 8
153
NM5353
WHEEL - TROLLEY
50
NM5238
RUN CAPACITOR
154
NM5355
AXLE – TROLLEY 17LM
51
NM5253
STARTING CAPACITOR
155
NM5357
BELT - TROLLEY
52
NM5255
CYLINDERHEAD SCREW M5 X 12
156
NM5359
TRAY WITH CLIPS & BELT – 17LM
X35B
( )
list of spare parts / repuestos

Important Safeguards!
When using an electrical appliance, always follow basic precautions, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
WARNING: To reduce the risk of re, electric shock, or injury:
• Do not use outdoors
• Keep out of the reach of children
• Close supervision is necessary when any appliance is used by or near children. Do not allow carpet cleaning machine to be used as
a toy or to run unattended at any time
• Keep hair, loose clothing, ngers, feet and all parts of body away from openings, rotating agitator, brushes and other moving parts
• Do not operate machine/cleaner in bare feet or when wearing open toe shoes or sandals
• Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes
• Do not use to pick up ammable or combustible materials such as but not limited to: gasoline or alcohol or use in areas where they
may be present
• Avoid picking up hard, sharp objects with the cleaner. They may damage the cleaner
• Always turn o this appliance before connecting or disconnecting the power cord to the power outlet
• Do not use without dust covers or renovators in place. Empty renovators and clean the machine frequently when picking up very
ne materials such as dry cleaning compound
• Use extra care when cleaning on stairs
• Do not put any objects into openings or near brushes. Do not use with any opening blocked; keep free of dust, lint, hair, or anything
that may reduce brush action
• Do not pull or carry by cord, use cord as a handle, close door on cord or pull cord around sharp edges or corners. Do not run appli-
ance over cord. Keep cord away from heated surfaces
• Always disconnect cord from electrical outlet before servicing the cleaner
• Unplug cleaner when not in use. Turn o all controls before unplugging
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. Never handle plug or appliance with wet hands
• The use of an extension cord is not recommended
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or
dropped into water, take it to a Brush Pro Sales and Service Center or Authorized Brush Pro Warranty Service Dealer (Depot)
• Use carpet cleaning machine only for its intended use as described in the instructions. Use only attachments recommended by The
Brush Pro Company; others may cause hazards
WARNING: Always wash hands after handling chemicals or cleaning materials.
Save these instructions!
© 2009 Hydro-Force • www.hydroforce.com
Please enter the COMPLETE model and serial numbers in the spaces provided.
Model: _______________________________
Serial number: _______________________________
Hint: Attach your sales receipt to the owner’s manual / instructions. Verication of date of purchase may be
required for warranty service of your Brush Pro product. Be sure to ll out and return the product registration
card included with your cleaning machine. (see back cover)
Review these instructions before
operating cleaner.
Thank you for choosing a Brush Pro product.

Salvaguardias importantes!
Al usar un aparato eléctrico, observe siempre las precauciones básicas, incluyendo las siguientes:
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE APARATO
Advertencia:
Para reducir el riesgo de incendios, electrocutamiento o lesiones:
• No use este aparato en el exterior.
• Manténgalo alejado del alcance de niños
• Es necesaria una supervisión estricta cuando cualquier aparato es utillzado por o cerca de niños. No permita que la máquina lim-
piadora de alfombras sea usada como un juguete ni que funcione sin la supervisión de adultos en ningún momento.
• Mantenga el cabello, la ropa holgada, los dedos de las manos y pies y todas las partes del cuerpo alejados de las aberturas del agi-
tador rotatorio, cepillos y otras piezas en movimiento.
• No haga funcionar la máquina descalzo, ni cuando calce sandalias o zapatos que dejen los dedos de los pies al deacubierto.
• No aspire nada que se esté quemando o echando humo, como cigarrillos, cerillos o cenizas calientes.
• No use este aparato para aspirar materiales inamables o combustibles como, pero no únicamente, gasolina o alcohol, ni en areas
donde pudieran estar presentes.
• Evite recoger objetos duros o alados con la aspiradora. Estos pueden dañarla.
• Apague siempre este aparato antes de conectar o desconectar la manguera.
• No use la aspiradora sin tener la tapa del depósito para polvo o los ltros en su lugar.
• Vacíe el depósito y limpie con la máquina con frecuencia cuando aspire materiales muy nos como compuestos de tintorería.
• Tenga especial cuidado al limpiar escaleras.
• No coloque ningún objeto en las aberturas o cerca de los cepillos. No la use con ninguna abertura obstruida; manténgala libre de
polvo, pelusa, cabello o cualquier cosa que pueda impedir o reducir la acción de los cepillos.
• No tire de esta ni la transporte por el cable, ni tampoco use el cable como mango, no cierre la puerta sobre el cable ni tire del
mismo alrededor de los bordes agudos ni esquinas. No pase el aparato sobre el cable.
• Mantenga el cable alejado de las supercies calientes.
• Desconecte siempre el cable del a toma de corriente antes de prestar servicio a la aspiradora.
• Desconecte el cable cuando la aspiradora no esté en uso.
• Antes de desenchufarla, apague todos los controles.
• No la desconecte tirando del cable. Para desenchufarla, sujete el enchufe
• Nunca toque el enchufe ni el aparato con las manos mojadas
• No se recomienda el uso de cables de extensión.
• No use el aparato si el cable o el enchufe esta dañado. Si el aparato no está funcionando apropiadamente, se ha dejado caer, ha
sido dañado, se ha dejado a la intemperie o se ha dejado caer en agua, llévelo a un Centro de Ventas y Servicio de Brush Pro o a un
Concesionario Autorizado de servicio de garantia de Brush Pro (Depósito).
• Use la máquina de limpiar alfombras solamente para lo que ha sido diseñada según se describe en las instrucciones. Use solamente
los accesorios recomendados por The Brush Pro Company; el Uso de otros accesorios puede ser peligroso.
Guarde estas instrucciones!
© 2009 Hydro-Force • www.hydroforce.com
Anote los números COMPLETOS de modelo y serie en los espacios previstos,
Modelo: _______________________________
Número de serie: _______________________________
Sugerencia: Adjunte su recibo de compra a este Manual del Propietario. Para obtener el servicio de garantía de
su producto Brush Pro puede requerirse la vericación de la fecha de compra. Asegúrese de llenar y retornar
la tarjeta de registro incluída con su máquina limpiadora. (ver carátula externa
REVISE ESTAS INSTRUCCIONES ANTES DE MANEJAR
LA MAQUINA LIMPIADORA
Gracias por haber elegido un producto Brush Pro

Hydro-Force 4282 South 590 West, Salt Lake City, UT 84123
1-800-948-1779
Hydro-Force.
Hydro-Force 4282 South 590 West, Salt Lake City, UT 84123
1-800-948-1779
Hydro-Force.

IMPORTANT: This Warranty will not be valid unless this Warranty Card is fully
completed and mailed to the Brush Pro Company. Fill out all information to receive
your FREE end user training video.
Please type or print.
Name: _____________________________________________________________________
Title: ______________________________________________________________________
Facility/Company: ___________________________________________________________
Address: ___________________________________________________________________
City, State, Zip: ______________________________________________________________
Phone: _________________________ FAX: ___________________________
Email: _____________________________________________________________________
Serial # _________________________________
Purchase Date ___________________________
IMPORTANT: Warranty will not be valid unless the attached War-
ranty Card is lled in and mailed to Brush Pro Company. Retain
this portion for your le.
1. Machines requiring repair under the Warranty must be
sent to the Brush Pro Corporate Headquarters, freight
prepaid. Repairs will be made and the machine returned
to the original purchaser freight prepaid in the USA.
2. When machines under this Warranty are returned
with parts or accessories missing, the Purchaser will
be charged for all parts and labor by the Brush Pro
Company. After the Warranty has expired, a rebuilding
charge will be quoted after the Brush Pro Company has
inspected the machine.
3. This Warranty gives you specic legal rights and you may
also have other rights which vary from state to state.
4. This limited 2 year Warranty applies to all original Brush
Pro’s Dry Carpet Extraction Cleaning Machines used in the
U.S. when purchased from a Brush Pro Authorized Dis-
tributor, Aliate or directly from the Brush Pro Company.
Outside the United States, machines are warranted by the
local Distributors.
5. This machine is warranted to be free from defects in mate-
rials and workmanship when used solely for the purpose
of pile lifting and Brush Pro Dry Extraction Cleaning of
carpets using Brush Pro carpet cleaning compound only.
This Warranty applies to original purchaser only. If machine
is sold, transferred, traded or lost, this Warranty becomes
invalid.
6. In the event of failure of a part or parts within 2 year from
original purchase date and upon inspection by the Manu-
facturer or Manufacturer Rep. to determine that failure is
due to defective materials or workmanship, such defec-
tive parts will be repaired or replaced at Manufacturer’s
expense.
7. This Warranty does not cover damages caused by but not
limited to: accident, neglect, or abuse, nor does it cover
expandable parts subject to normal wear. These items
include but are not limited to the cleaning brushes and
timing belts. Any modication to the equipment by the
customer will absolve Brush Pro Company of any and all
liability under this Warranty.
Job Function:
Facility Manager
Maintenance Executive
Cleaning Manager
BSC/Janitorial Services
Professional Carpet Cleaner
Type of Facility:
Oce Building
Gov?t/Public Building
School/College/University
Restaurant
Hotel/Motel/Resort
Apartment Building
Hospital
Airport
Nursing Home
Other ________________________________
Brush Pro Distributor from whom you purchased:
_________________________________________________
Sales Rep: ________________________________________
Sq. ft. of carpet: ___________________________________
Would you like someone to contact you regarding training
for the BrushPro System? YES NO
Brush Pro Warranty
Manufacturer:
Hydro-Force Manufacturing
4282 South 590 West
Salt Lake City, UT 84123
800-948-1779
www.hydro-force.com
Limited Warranty
Brush Pro Product Warranty
The Original Dry Extraction Carpet Cleaning System
