Hyperion EOSLBA10-A User manual

HYPERION Lithium Balance Adapter - For Lithium Polymer and A123 2007-01-25
Warnings:
•Batteries can be a fire hazard if
charged or discharged improperly.
Always use your battery charger and
batteries as directed by the makers.
•Never Charge Batteries unattended
•Charge in an area free of flammable
materials, on non-flammable brick,
concrete, etc
•Keep Batteries, Charger, and
Balancer AWAY FROM CHILDREN
and PETS!
•Never attempt to charge an impact-
damaged (crashed) battery pack
•Packs which are chronically far out
of balance may be damaged and
should be discarded
Photo Notes: 1: Option Cable #HP-EOSLBA10-DPC required and charger must have DataPort option
2: Option Set #HP-EOSLBA10-MSC required for Networking LBA10
The Hyperion Lithium Balance Adapter (LBA10-A) is an extremely versatile device. It can balance either lithium 3.7V or A123 3.3V packs - with
“balance connector” correctly attached to the pack - in voltage range of 2S~6S three ways:
•Stand-Alone* discharge method (without using a charger or discharge device)
•Loaded discharge method (using any load device for discharge load)
•Balance while Charging (using a LiPo or A123 compatible charger)
*Standalone is called “Disconnection” mode, because the path to charger/discharger is disconnected
To use the LBA10, a Balance-Connector must be wired to your battery pack. The LBA 10 comes with 2S and 3S harnesses which fit Hyperion,
Polyquest, Poly-Q, E-Tec and some other brand lithium packs. 4S to 6S harnesses are available separately. (Hyperion A123 packs use 7-pin “6S”
connector for all packs, 2S~6S). Hyperion also offers JST EH and JST XH type harnesses, which fit many other liPoly pack brands. If your pack
does not have such a connector, and you are confident in your ability to install one, you may purchase the connector Part #HP-EOSLBA-MC-P4
(2S~4S packs), #HP-EOSLBA-MC-P5 (5S packs), or #HP-EOSLBA-MC-P6 (6S LiPo, all Hyperion A123 packs), and attach it according to the
diagrams at the end of this manual.
Note: Packs with Hyperion-style “6S” balance connectors wired correctly can connect directly to LBA 10 without intermediate harness.
USE OF THE LBA10
Note: LBA10 usage is identical for both Lithium Polymer and A123 lithium cell types. By default, the LBA10 is in “LiPo” mode when the battery is
connected. To enter “A123” mode, push the MODE/RESET button for 2 seconds, until you see the Red A123 Mode LED light up. See technical
differences and cautions later in this document.
Prepare your LBA by soldering a mating Main Connector for your battery pack to the red/black PACK CHG (LBA OUTPUT) wires
Let’s attach your lithium pack to the LBA in Disconnection Mode to see how the LED indicators work…
•Be sure the NETWORK switch is set to MASTER
•Select the appropriate harness for 2S~6S. Connect harness to LBA at port marked ‘Balance Harness’
•Connect your Lithium pack to the LBA Multi-Connector
•The LiPo 3.7V MODE LED will blink at one-second intervals
(if A123 pack, hold down Mode/reset button 2 seconds now to switch to A123 3.3V mode)
•WITHIN 12 SECONDS, Connect your Lithium Battery Connector to the connector you installed on the LBA OUTPUT wires
•watch the MODE LED
•MODE LED will be ON continuously in Disconnection Mode … OR will show an ERROR:
oFlashes Twice: Battery Voltage higher than expected
oFlashes Three Times: Battery Voltage lower than expected
oFlashes FourTimes: Other Connection orWiringError
If you have errors, check to see that you have the proper harness installed and battery in good condition
If your pack is already very closely balanced, the LBA 10 will automatically shut down and turn off all LED. There is no work for the
LBA to do! After shutdown the LBA puts an extremely small drain on the battery. However, you should always disconnect the battery from LBA as
soon as possible after balancing is complete, especially for the smallest packs.
If your pack needs balancing, the LBA will go to work, discharging the cells with highest voltage. Each CELL LED will have one of these
three states:
ON SOLID: Discharging that cell at max rate
QUICKLY FLASHING: Discharging that cell at low/medium rate
OFF: That cell’s voltage is low, so no discharging
*LED COLOR: Cells 1-3-5 are always RED; 2-4-6 always GREEN. The colors just help you identify which cell is which.
If you leave the Lithium pack attached to the LBA now, it will continue discharging the high-voltage cells until the pack is very closely balanced.
When balancing is complete, the CELL Condition LEDs will each Flash, then all LEDs will go dark and the LBA will power OFF. At this point the draw
on the Lithium pack is very small (490uA), so you could leave the pack connected for extended periods without damage. HOWEVER, lithium packs
should always be disconnected from the LBA as soon as possible after completion. Charging should NEVER be left unattended!!
NOTE: When a lithium pack is first connected to the LBA, you start in “Disconnection” mode. When the LBA is not connected to a charger, the two
4mm gold connectors on the LBA are not insulated. In disconnection mode, these may freely touch each other without harm. However, if they
touch while in “Connection” mode, the LBA fuse will blow. To avoid this, use the connector covers included with your LBA10 to insulate the
connectors, whenever not connected to a charger! Continued reverse page
NOTE: The LBA contains Auto-Cut circuitry to avoid over-discharging a badly out-of-balance pack, or a pack which starts with voltage too low
already. If any one cell ever falls below the protection limit, the LBA microprocessor powers OFF, regardless of balance state, and discharging is
stopped.

Charging with a single LBA 10 in “Connection Mode”, using a Compatible Charger, for 2S to 6S
First, set your charger cell count and charge rate appropriately for your battery pack. For example, if you have a 11.1V LiPo 1200mAh pack, set
the charger for “lipo mode”, 3S (11.1V) and 1.2A (“1C” for 1200mA pack). The LBA can be used at charge rates up to 10.0 amps. Note: All
Hyperion Lithium Polymer support 2C max charge rates (2.4A for a 1200mAh pack) but other brands may be limited to “1C”. Consult documentation
before exceeding 1C rate with LiPoly. (see A123 notes, last page)
CONNECTION SEQUENCE (after step 5, push MODE/RESET 2 seconds if A123 Battery)
1) Check to be sure that the LBA Network Switch is in MASTER mode
2) Connect the LBA 10 INPUT LEADS to the Charger, via the two male 4mm gold plugs
3) Connect the appropriate 2S-6S balance harness to the LBA 10
4) Connect the Balance Harness to your Lithium pack
5) Quickly (within 12 seconds) connect your pack Main Wires to the Red/Black LBA OUTPUT wires
At this point, the sequence is the same as before: We start in “Disconnection Mode. You should see a solid STATUS LED, and at least one blinking
CELL LED. If so, push the MODE/RESET Switch on the LBA to enter CONNECTION MODE.
After a brief pause, the STATUS LED should start single flashes to indicate that connection mode is active. Check to be sure the STATUS LED is
blinking in one-second intervals before continuing.
Now push the “START” button on your charger. There’s nothing else to do, until your charger indicates the charge has completed. At that time,
press the MODE button to enter DISCONNECT MODE, then detach components in this order:
1) Disconnect your lithium pack Main Connector from the LBA Output Wires
2) Disconnect the Balance Harness from your Lithium pack
3) If desired, disconnect LBA 10 from the charger
NOTE: if you start with a very closely balanced pack, the LBA may power off shortly after the battery is connected. In that case,
push the MODE button TWICE to enter connection mode for charging.
NOTE: Chargers which do not have a start button will begin charging when you start Connect Mode by pushing the MODE button (or pushing MODE
twice if the LBA has already shut down with well balanced pack)
NOTE: If you have connected your LBA 10 to a DataPort equipped charger (EOS5i DP, EOS 1210i...), via the optional DataPort Cable,
you need not press the MODE button to disconnect when charge/balancing is finished. The charger automatically tells the LBA to disconnect… The
DataPort cable and supporting charger allow you to monitor the voltage of each cell during the charge process, via the charger’s LCD screen. If
Charger and LBA Battery Type Setting (LiPo vs A123) do not match, the charger will error: DATA RANGE OVER ERROR
Using a single LBA 10 in “Connection Mode” with Discharge Load
If you want to speed the discharge balance process (compared to Disconnection Mode), you can attach an appropriate load to the LBA Power INPUT
4mm Gold Connectors. While this could be a simple as a 12V light bulb, you do need to be sure that the current drawn is appropriate for your pack,
and does not exceed the LBA’s 10A limit. Any charger which has Discharge capability can be used, even if it does not have an Auto-Cut function,
because the LBA will properly limit discharging of the pack, assuming all cells are above minimum voltage to start.
Procedure is the same as with Connection Mode Charging. Make the appropriate settings on your discharger, and select the appropriate LBA
Harness to match your pack. Connect the Discharger (or light bulb, or other load you have chosen), via the LBA’s two male 4mm gold banana plugs.
We start in Disconnection Mode by connecting the lithium pack to the LBA’s multi-connector harness, and then quickly attaching the Main Pack
Wires to the LBA Output Wire set. Push the MODE/RESET Switch on the LBA to enter Connection Mode. After a brief pause, the Status LED should
start single flashes to indicate that connection mode is active.
Now push the “START” button on your discharger. When the LBA completes balancing, or shuts down because one cell is getting too low, the circuit
will be disconnected. Many Dischargers (such as the EOS series) will sound an alarm when the circuit is opened. If using a Light Bulb, the bulb will
light when you push the MODE/RESET Switch to enter connection mode, and bulb will go off when the LBA completes balancing and shuts down.
Using Two LBA 10, Networked to Balance two similar packs as a single unit
ETWORK CHARGING NOTES:
The two packs must be from the same maker, of same capacity and
Ideally, the two packs should have similar history. That is, they are
* A lithium charger rated to suit the total SERIES (S) cell count of the
As an alternative to a single high-S charger connected as below, you
N
*
type (ex: VX3700-3S, VX3700-4S to make 7S)
*
both new, or they have both been used in the same model, separately,
for about the same number of flight hours before. You simply want to
avoid pairing tired or old packs with fresh, new packs.
two packs is required. That is, to charge a 4S and a 4S pack as 8S,
you need a charger rated for 8S or higher.
*
could use two chargers each connected separately to LBA10 and pack.
After each pack is balance-charged separately, check cell voltages of
each pack. If within 0.05V/cell, connect and fly. If not, connect the
two packs as in the Master/Slave example below, and balance them via
DISCONNECT Mode as a unit. Only the high cells are reduced in
voltage, and effect on capacity is negligible…
Two-Pack System Advantages
5S packs flown in 2.5Kg model can be
Damage to one pack means replacing
Two packs can easily be rearranged to
Versatile: change from Series to Parallel
*
combined to 10S to fly a new 5Kg model,
for example.
*
only ½ the battery system.
*
fit in a model, to provide proper CG
without adding weight
*
connections effortlessly

T
cells in both packs are balanced within 0.05V of each other, or better. This allows you, after balance charging is complete, to safely connect the
two packs in series and fly them as a single unit in your model.
C
he LBA 10 Net Balancer can be connected as in the preceding diagram, in order to balance charge two similar packs such that the voltage of all
ONNECTION SEQUENCE mode on Network Switch, one on MASTER mode SLBA10-MSC, as shown above by the blue line between A10
t the two remaining Red/Black LBA 10 INPUT LEADS to the Charger, via the two male 4mm gold plugs
BA first!
k to the Red/Black LBA OUTPUT wires
you have trouble, it is most like that the first Slave LBA has timed out before you got all the connections made. Arranging the various
isconnection after charging is finished by reversing the sequence above.
-- Connecting Packs in Series before Flight, Disconnecting before Charging or ‘Disconnect Mode Balancing’ ----
OTE: When wiring two packs in series for flight, we suggest using Gold Bullet Connectors of the appropriate current rating. Hyperion offers y,
ake it
hen Charge, Discharge, or Disconnect Balancing each of these packs, the main RED/BLACK wires must all be disconnected. Then each LBA’s
Male Connector on battery (+) is industry standard. Batteries do not have Ground (Earth), so it doesn’t matter if the (+) connector has exposed
e
ECHNICAL ADDENDUM
OS LBA 10 – HARNESS WIRING FOR HYPERION (and compatible) LITHIUM-POLYMER 3.7V nominal PACKS
•Set one LBA10 to SLAVE
•Connect the 4mm Female-Female Series Adapter from option pack #HP-EO
Positive/Negative Input Cables of the two LBA units. Connect the NETWORK CABLE, as shown by the Orange line, between the two LB
units.
•Connec
•Connect the appropriate 2S-6S balance harness to each LBA 10
•Connect the appropriate pack to the balance harness on SLAVE L
•Connect the appropriate pack to the balance harness on MASTER LBA
•Quickly (within 12 seconds) connect the Main Leads of each lithium pac
•Press the MODE button to enter CONNECTION mode (or leave ‘as is’ to DISCONNECT balance without charging)
•Start your charger (unless you are disconnect balancing!)
If
components carefully on the table beforehand is very helpful. After a little practice, it’ll be easy...
D
--
N
3.5mm short gold connectors for battery <> ESC connections up to 25A continuous (40A peak /10 seconds), 4mm long connectors for 20~60A
continuous (80A peak/10 seconds), and 6mm short connectors for 40A~80A continuous, (110A peak /10 seconds). It is always well to keep the
wires between Battery and Speed Controller (ESC) as short as possible [they should never be made longer than as supplied by maker - if necessar
add length to wires between Motor and ESC instead]. For packs which will always be paired in Series in your model, we recommend that you cut
short the RED wire on one pack and the BLACK wire on the OTHER pack - just long enough that the two wires can be joined by a single Male/Female
pair of Bullet Connectors. The remaining longer RED wire should have a MALE connector attached*, and the remaining longer BLACK wire a
FEMALE connector. These two will connect to your ESC. In this way, you not only reduce the total length of battery<>ESC circuit, you also m
very clear which two leads get connected for Series (the short ones). BE SURE YOU NEVER SHORT THE TWO BATTERIES BY CONNECTING THEM
DIRECTLY TOGETHER! (it may sound silly, but can happen if you aren’t paying attention!)
W
Output Wires connected directly to each battery pack’s main Red/Black wires.
*
metal (as long as ONE of the two connectors is shielded, you’re ok). Your charger does have ground, however. Therefore you want the FEMALE
connector on charger side (+) Output, because it is covered completely with shrink tubing. As such, it cannot short on the grounded (-) metal cas
of the charger.
T
E
(2S and 3S harnesses are included with LBA10. 4S, 5S, 6S available as accessory items)

EOS LBA 10 – HARNESS WIRING FOR HYPERION A123 PACKS
Hyperion A123 packs use the ‘lipoly’ 6S-type battery-side connector for all packs 2S~6S. The A123 PACK Connector plugs directly into LBA10
without additional harnesses between A123 pack and LBA10. If you are building your own large-capacity lithium polymer packs from loose cells, or
your own packs using A123 cells, we suggest this method below as best practice. (use #HP-EOSLBA-MC-P6-L connector to wire packs)
Note: Current A123 2300mAh cells have a protruding button which is NEGATIVE polarity. Whenever assembling any pack, be sure of the polarity
before beginning wiring. Future A123 cells could differ from the diagram supplied above, in this respect.
Note: Current A123 Cells may be safely fast charged at rates up to 10A per cell (or roughly 4C), for charge times in the range of 10 to 15 minutes.
Consult documentation for your pack to be sure about max recommended charge rates.
EOSLBA10-A General Specifications Protection Voltages (± 0.01V)
Input Voltage (charger) 55.0 Volts Max * Over Charge 4.30 V/cell
Lithium Poly/Ion 3.7V nominal type only Over Discharge 3.05 V/cell
Supported Output
Battery Types A123-Brand cells 3.3V nominal only Power Down V 2.90 V/cell
Battery Volt Range 6.0V~26.0V ( 2S~6S LiPo or A123)
3.7V LiPo
Mode
Short Protect 2.00 V/cell
Max Charge Current 10A Over Charge 3.90 V/cell
Voltage Resolution ±5mV Over Discharge 2.85 V/cell
Power Down V 2.70 V/cell
3.3V
A123
Mode Short Protect 2.00 V/cell
For additional technical support, please first contact the Hyperion dealer from whom you purchased the LBA10.
*Note: The LBA10 has been specifically designed to be compatible with the majority of chargers on the market, and tolerant of high transient
voltages. However, some chargers on the market may output extremely high transient voltages when they encounter an open circuit, which could
potentially damage any Balancer or PCM device, regardless of safeguards employed. Therefore, it is “best practice” to use Hyperion chargers, as
they are expressly designed to limit voltage under open-circuit conditions, and are guaranteed safe with any PCM or Balancer device.
Warranty
Hyperion LBA10 are fully guaranteed against defects in material or workmanship for 12 months from date of purchase. The warranty does NOT
cover damage to reverse-polarity connection, over-spec use, water or impact damage, nor any other claim not arising from a defect in materials or
assembly. You must contact your selling dealer with details of the problem before making a return. In most cases, the problem is an
issue with setup, and can easily be resolved at no expense to you. Items returned without notice in which defects are not found can only be
returned to the sender at his expense.
We sincerely hope you enjoy this Hyperion Product!
The Hyperion Team
