HYPERION Installation Manual
2
This manual contains important safety instructions for the Photovoltaic Modules (hereafter referred to as " Modules")
of American Hyperion Solar LLC. (hereafter referred to as Hyperion Solar). Installers should follow all safety
precautions described in this guide as well as local codes when installing Modules.
Installing photovoltaic systems requires specialized skills and knowledge. Installation should only be performed by
qualified personnel.
Before installing a photovoltaic system, installers should familiarize themselves with its mechanical and electrical
requirements. Keep this guide in a safe place for future reference and in case of sale or disposal of the Modules.
For any questions, please contact our Global Quality and Customer Service department for further information.
1. INTRODUCTION
Thank you for choosing HYPERION SOLAR modules!
This Installation Manual contains essential information for electrical and mechanical installation that you must know
before handling and installing Hyperion Solar Modules. This Manual also contains safety information you need to be
familiar with. All the information described in this Manual is the intellectual property of Hyperion Solar and is based on
the technologies and experience that have been acquired and accumulated by Hyperion Solar.
This Manual does not constitute a warranty, expressed or implied. Hyperion Solar does not assume responsibility and
expressly disclaims liability for loss, damage, or expense arising out of or in any way connected with installation,
operation, use or maintenance of Modules. No responsibility is assumed by Hyperion Solar for any infringement of
patents or other rights of third parties that may result from use of Modules. Hyperion Solar reserves the right to make
changes to the product, specifications or installation manual without prior notice.
Failure to comply with the requirements listed in this manual will invalidate the Limited Warranty for Modules as provided
by Hyperion Solar at the same time of sale to the direct customer. Additional recommendations are provided to enhance
safety practices and performance results. Please provide a copy of this manual to the PV system owner for their
reference, and inform them of all relevant aspects of safety, operation, and maintenance.
2. CODES AND REGULATIONS
The mechanical and electrical installation of PV systems should be performed in accordance with all applicable codes,
including electrical codes, building codes and electric utility interconnection requirements. Such requirements may vary
for mounting location. Requirements may also vary with system voltage, and for DC or AC application. Contact local
authorities for governing regulations.
3. GENERAL
3.1. Product Identification
3.1.1. Nameplate:
Nameplate describes the product type, peak power, Max. power voltage, open circuit voltage, short circuit current,
all as measured under standard test conditions; certifications mark, the maximum system voltage etc.

HYPERION Installation Manual
3
3.1.2. Barcode:
Each individual module has a unique serial number. The serial number has 20 digits. The 6th and the 7th digits are
the year code, the 8th and the 9th digits are the month code, and the 10th and the 11th digits are the data code.
For example, H0101220627000401133 means the module was assembled and tested on 2022.06.27. Each
module has only one bar code. It is permanently attached to the interior of the module and is visible from the top
front of the module. This bar code is inserted prior to laminating.
Typical serial number barcode label
3.2. Conventional safety requirement
Hyperion Solar Modules are designed to meet the requirements of IEC61215 and IEC61730, application class A.
Modules rated for use in this application class may be used in system greater than 50V DC or 240W, where general
contact access is anticipated. Modules qualified for safety through IEC 61730-1 and IEC 61730-2 and within this
application class are considered to meet the requirements for safety class II equipment.
When modules are mounted on rooftops, the roof must have a fire-resistant covering suitable for this application.
Rooftop PV systems should only be installed on rooftops capable of handling the additional weighted load of PV system
components, including modules, and have a complete analysis of the structure performed by a certified building
specialist or engineer.
For your safety, do not attempt to work on a rooftop until safety precautions have been identified and taken, including
without limitation fall protection measures, ladders or stairways, and personal protective equipment.
For your safely, do not install or handle modules under adverse conditions, including without limitation strong or gusty
winds, and wet or frosted roof surfaces.
3.3. Electrical performance safety
Photovoltaic modules can produce DC electricity when exposed to light and therefore can produce an electrical shock.
DC voltage of 30 Volts or higher is potentially lethal.
Modules produce voltage even when they are not connected to an electrical circuit or load. Please use insulated tools
and appropriately rated rubber gloves when working with modules in sunlight.
Modules have no on/off switch. Modules can be rendered inoperative only by removing them from sunlight, or by fully
covering them with cloth, cardboard, or other completely opaque material.
In order to avoid arcs and electrical shock, please do not disconnect electrical connections under load. Faulty
connections can also result in arcs and electrical shock. So please keep connectors dry and clean, and ensure that
they are in proper working condition. Never insert metal objects into the connector, or modify them in any way in order
to secure an electrical connection.
Also, in order to avoid the sand or water vapor entering which may cause a safety issue with the connection, the

HYPERION Installation Manual
4
modules need to be installed and connected to the combiner box once they are taken out from the carton box; keep
the connectors dry and clean during the installation, if the modules are not be installed within a week, rubber connector
covers shall be added as a protective measure. Note that pollution from sand, dust and water will result in arcs and
electrical shock of connectors. We suggest that customers add rubber connector covers as protection method
especially in areas with heavy dust or seaside areas with higher salinity or serious polluted areas.
Reflection from snow or water can increase sunlight and therefore boost current and power. In addition, colder
temperature can substantially increase voltage and power. If the glass or other material is damaged, please wear
personal protection equipment and separate the module from the circuit.
Work only under dry conditions, and use only dry tools. Do not handle modules when they are wet unless wearing
appropriate protective equipment. If you need to clean the modules, please follow the cleaning requirements mentioned
in the manual.
Installation must be carried out under the guidance of a qualified electrician
3.4. Operating safety
Do not open the package of Hyperion Solar modules until they are ready to be installed during transportation and
storing.
At the same time please protect the package against exposure to damage. Secure pallets from falling over. Do not
exceed the maximum height of pallets to be stacked, as indicated on the pallet packaging. Store pallets in a
ventilated, rain-proof and dry location until the Modules are ready to be unpacked. Please unpack the package of
Hyperion Solar modules according to "Hyperion Solar Modules Unpacking Instruction”.
Do not lift the modules by grasping the module's junction box or electrical leads in any condition. Do not
stand or step on the Modules.
Do not drop the Modules on another Module.
Do not place any heavy objects on the Modules to avoid glass breakage.
Be cautious when setting the modules down on to a surface, especially on the corner of the modules. Inappropriate
transport and installation may break the modules.
Do not attempt to disassemble the modules, and do not remove any attached nameplates or components from the
modules.
Do not apply paint or adhesive to the modules’ top surface.
Do not drill holes in the frame. This may compromise the frame strength and cause corrosion of the frame.
Do not scratch the anodized coating of the frame (except for grounding connection). It may cause corrosion of the
frame or compromise the frame strength.
Do not attempt to repair the modules with damaged glass.
The scrapped modules shall be recovered and disposed by the qualified institution.
In dry areas, modules are easily affected by static electricity during installation. The installation personnel should wear
anti-static assembly to ensure that the equipment and installation personnel are not affected or hurt by staticelectricity.

HYPERION Installation Manual
5
3.5. Fire safety
Consult your local authority for guidelines and requirements for building or structural fire safety. Hyperion Solar
modules have been designed in accordance with IEC 61730-2 standard.
For roof installations, modules should be mounted over a fire-resistant covering suitable for this application, with
adequate ventilation between the module backside and the mountingsurface.
Roof constructions and installations may affect the fire safety of the building. Improper installation may create
hazards in the event of a fire.
Use appropriate components such as fuses, circuit breaker and grounding connector as requires by local authority.
Do not use modules where flammable gasses may be generated.
HYPERION modules have not been tested for explosion protection. Please consult local regulations whether the
modules can be used or not.
3.6. Wiring Method
Note: An extension cord is required at the rotor head of the double row assembly and at the end of the single row.
Vertical Installation
with standard cable
length：

HYPERION Installation Manual
6
Horizontal Installation
with extended cable
length:
4. INSTALLATION
4.1. Installation position and working environment
Hyperion Solar modules are intended for use in terrestrial applications, no outer space use. Do not use mirrors or
other magnifiers to concentrate sunlight onto the modules.
Modules must be mounted on appropriate mounting structures positioned on suitable buildings, the ground, or other
structures suitable for modules (e.g., carports, building facades or PV trackers).
Modules must not be installed in locations where they could be submerged in water.
The recommended ambient temperature should be within -40℃(-40°F) to 40°C(104°F). The temperature limits are
defined as the monthly average high and low of the installation site. The limit operating temperature should be -40°C (-
40°F) and 85°C (185°F).
Ensure modules are not subject to wind or snow loads exceeding the maximum permissible loads.
The modules should be installed in a location where there's no shading throughout the year. Ensure there's no obstacle
to block light near the installation site.
Lightning protection is recommended for PV systems that are to be installed in locations with high probability of lightning
strikes.
Do not use modules near equipment or in locations where flammable gas may be generated or collected.
Modules cannot be installed or used in extreme areas or weather conditions, and highly corrosive areas should be
considered carefully.
Please adopt appropriate measures to ensure the performance and safety of the modules when they are installed or
operated in areas with heavy snow, extremely cold, strong wind, or near an island or desert that is prone to produce
salty fog, or nearwater.
Hyperion Solar modules have passed salt-mist test based on IEC 61701, but galvanic corrosion can occur between
the aluminum frame of the modules and mounting or grounding hardware if such hardware is comprised of dissimilar
metals. Hyperion Solar Modules can be installed at seaside locations 50m to 500m from the sea, but the components
should be protected against corrosion. For the detailed requirements, follow Hyperion Solar seaside installation
instructions.
Modules cannot be applied for some special requirements, e.g., for buildings, marine and vehicle applications. Please
refer to local law and regulations for details

HYPERION Installation Manual
7
4.2. Tilt angel selection
The tilt angle of the modules is measured between the surface of the modules and a horizontal ground surface. The
modules generate maximum power output when it faces the sun directly.
In the northern hemisphere, modules should typically face south, and in the southern hemisphere, modules should
typically face north.
For detailed information regarding the best installation angle, please refer to standard solar photovoltaic installation
guides or consult a reputable solar installer or systems integrator.
Dust building up on the surface of the modules can impair module performance. Hyperion Solar recommends installing
the modules with a tilt angle of at least 10 degrees, making it easier for dust to be washed off by rain.
5. MECHANICAL INSTALLATION
5.1. Conventional requirements
Ensure the installation method and supporting system of modules is strong enough to withstand all the load conditions.
The Installer must provide this guarantee. The installation supporting system must be tested by third-party organization
with the analysis ability of Static Mechanical, according to the local national or international standards.
The modules mounting structure must be made of durable, corrosion- resistant and UV- resistant material.
Modules must be securely attached to the mounting structure.
In regions with heavy snowfall in winter, select the height of the mounting system so that the lowest edge of the modules
is not covered by snow for any length of time. In addition, ensure that the lowest portion of the modules is placed high
enough so that it is not shaded by plants or trees or damaged by flying sand.
When the modules are supported parallel to the surface of a building wall or roof, a minimum clearance of 10cm
between the modules frame and the surface of the wall or the roof is required to allow air to circulate behind the
modules and to prevent wiring damage.
Do not attempt to drill holes in the glass surface and the frames of the modules as this will void the warranty.
Before installing modules on a roof, ensure that the roof construction is suitable. In addition, any roof penetration
required to mount the modules must be properly sealed to prevent leaks.
Observe the linear thermal expansion of the module frames (the recommended minimum distance between two
modules is 10 mm). The module frames will warp at low temperature.
Avoid the frame receiving the lateral tension and pressure, which may damage the frame and glass.
Modules have been certified for a maximum static load on the back side of 2400Pa (i.e., wind load) and a maximum
static load on the front side of either 2400 Pa or 5400Pa (i.e., wind and snow load), depending on the modules type
(please refer to the following installation methods for details).
The mounting method must not result in the direct contact of dissimilar metals with the aluminum frame of the modules
as it will result in galvanic corrosion. IEC 60950-1 standard recommends metal combinations not exceed an
electrochemical potential difference of 0.6 Volts.
Hyperion Solar modules can be mounted in landscape or portrait orientation. For the bifacial modules, in order to
maintain the energy yield of module’s rear side, the distance between the bottom of modules and the

HYPERION Installation Manual
8
roof or ground surface is recommended to be at least 1m.
5.2. Installation methods
Modules can be installed to the racks by clamps or hooks. Modules must be installed according to the following
examples and recommendation. If Modules are not mounted according to these instructions, please consult Hyperion
Solar in advance and it must be approved by Hyperion Solar, otherwise this act may damage the Modules and void the
warranty.
5.2.1. Modules installed with clamp (For framed bifacial PERC mono double-glass modules)
A. Module should be attached on a supporting structure rail by metal clamps.
It is recommended to use the clamps under the following condition or parts approved by Hyperion:
Width: ≥ 50mm;
Thickness: ≥3mm
Material: Aluminum Alloy, 6063-T5
Bolt: Stainless Steel
Nut：Stainless Steel
Washer：Stainless Steel
Clamp A
Clamp B
Figure 1 Mounting details

HYPERION Installation Manual
9
B. Recommended bolt torque range: 18N.m to 24N.m.
C. The modules clamps should not contact the front glass or deform the frame in any way. Avoid shading
effects from the module’ s clamps. Drainage holes on the modules frame should not be closed or obscured by the
clamps. Besides, two or more screws or two full threads of a single screw shall engage the metal.
5.2.2. Modules installed with mounting hole
Modules should be bolted to support structures through mounting holes located in the frame' s back flanges. Refer
to what is shown in Figure 2 (Mounting Details).
Figure 2 Mounting Details
For your reference, please use the components specified below：
1.Bolt
2. Washer
3. Spring washer
4.Nut
Material
Steel
Stainless Steel
Stainless Steel
Stainless Steel
Size& length
M8*16mm
M8
M8
M8
Remark
Recommended torque is between 12N.m to 16N.m
5.3. Installation position and corresponding static loads
The low/normal level of load condition is applicable to the installation in most of environmental conditions: the maximum
static load on the back of the modules is 2400Pa (i.e. wind load), and the maximum static load on the front of modules
is 2400 Pa (i.e. wind and snow load).
The high level of load condition is applicable to the installation in harsher environmental conditions such as storm,
heavy snow, etc.: the maximum static load on the back of the modules is 2400Pa (i.e., wind load), and the maximum
static load on the front of modules is 5400Pa (i.e., wind and snow load), depending on the pressure level that it would
endure according to IEC standard.

HYPERION Installation Manual
10
For the dynamic loads, such as wind, the safety factor needs to be increased by 3 times. It means that the maximum
dynamic load is 800Pa when the wind speed is less than 130 km/h.
#1 Bolts in outer holes
Outer four holes, mounting rails across the long frame
#2 Bolts in inner holes
Inner four holes, mounting rails across the long frame
#3 Bolts in special holes
Mounting by 400mm spaced holes
#4 Clamps on long frame
Mounting by clamps (S=1/4 L±50mm), mounting rails across
the long frame
Figure 3 Installation Position and Corresponding Load Relation
#1 Bolts in outer
holes
#2 Bolts in inner
holes
#3 Bolts in special
holes
#4 Clamps on
long frame
HY-DH144P8
HY-DH144N8
HY-DH132P8
HY-DH132N8
HY-DH120P8
HY-DH120N8
HY-DH108P8
HY-DH108N8
+5400pa/-2400pa
+3600pa/-2400pa
——
+5400pa/-2400pa
Installation Method
Framed bifacial
double-glass modules
with 2.0mm&2.0mm
glass
+5400pa/-2400pa
+3600pa/-2400pa
+2400pa/-2400pa
+5400pa/-2400pa
+3600pa/-2400pa
——
+5400pa/-2400pa
+5400pa/-2400pa
+3600pa/-2400pa
+2400pa/-2400pa
+5400pa/-2400pa
+5400pa/-2400pa

HYPERION Installation Manual
11
6. ELECTRICAL INSTALLATION
6.1. Electrical property
The rated electrical characteristics, Isc is within +/- 4% and Voc is within +/- 2% of measured values at Standard Test
Conditions, but for the Pmax, it is within +/-3%. Standard Test Conditions: 1000W/㎡, Irradiance, 25℃Cell
Temperature and 1.5 AM.
Under normal conditions, the photovoltaic modules may experience conditions that produce more current and/ or
voltage than reported at Standard Test Conditions. Accordingly, the values of short circuit current, Isc, and open circuit
voltage, Voc, marked on modules should be multiplied by a factor of 1.25 when determining component voltage ratings,
conductor capacities, fusing sizes, and size of controls connected to the module output
Voltages are additive when modules are connected directly in series, and modules currents are additive when modules
are connected directly in parallel, as illustrated in Figure 4.
Modules with different electrical characteristics must not be connected directly in series.
Figure 4: Electrical diagrams of series and parallel wiring
The maximum number of modules that can be connected in a series string must be calculated in accordance with
applicable regulations in such a way that the specified maximum system voltage (The maximum system voltage of
Hyperion Solar Modules is DC 1500V) of the modules and all other electrical DC components will not be exceeded in
open-circuit operation at the lowest temperature expected at the PV system location.
Correction factor for the open-circuit voltage can be calculated based on the following formula: Cvoc= 1-βvoc*(25-T).
T is the lowest expected ambient temperature at the system location. β(%/℃) is the temperature coefficient of the
selected module Voc ( refer to corresponding datasheet).
An appropriately rated over- current protection device must be used when the reverse current could exceed the value of
the maximum fuse rating of the modules. An overcurrent protection device is required for each series string if more than

HYPERION Installation Manual
12
two series strings are connected in parallel, in Figure 4.
6.2. Cables and Wiring
These junction boxes have been designed to be easily interconnected in series for their well- connected cable and
the connector with IP68 protection grade. Each module has two single-conductor wires, one positive and one negative,
which are pre-wired inside the junction box. The connectors at the opposite end of these wires allow easy series
connection of adjacent modules by firmly inserting the positive connector of a module into the negative connector of
an adjacent module until the connector is fully locked.
Use field wiring with suitable cross- sectional areas that are approved for use at the maximum short- circuit current of
the modules. Hyperion Solar recommends installers use only sunlight resistant cables qualified for direct current (DC)
wiring in PV systems. The minimum wire size should be 4 mm²(12 AWG)
Rating Required Minimum Wiring：
Testing standard
Wire size
Temperature rating
EN 506182014
4 ㎜²
-40℃ to +90℃
Cables should be fixed to the mounting structure in such a way that mechanical damage of the cable and/ or the
modules is avoided. Do not apply stress to the cables. The minimum cables bending radius should not be less than 8
times of the cable diameter. Any cable damage caused by bending too much or cable management system is not
covered under Hyperion Solar' s warranty. For fixing, use appropriate means, such as sunlight resistant cable ties and/
or wire management clips specifically designed to attach to the module frame. While the cables are sunlight resistant
and waterproof, where possible, avoid direct sunlight exposure and water immersion of the cables.
Cable arrangement must comply with local laws and regulations.
6.3. Connectors
Keep connectors dry and dean, and ensure that connector caps are hand tight before connecting the modules. Do not
attempt making an electrical connection with wet, soiled, or otherwise faulty connectors. Avoid sunlight exposure and
water immersion of the connectors. Avoid connectors resting on the ground or roof surface.
Faulty connections can result in arcs and electrical shock. Check that all electrical connections are securely fastened.
Make sure that all locking connectors are fully engaged and locked. Connector interconnect must reach the
corresponding IP protection level, so as to achieve the electrical security.
Do not contact organic solvents and other corrosive materials in connector connection and the using environment, such
as alcohol, gasoline, pesticides, herbicides, etc. Please consult HYPERION for details. Otherwise, Hyperion will not be
responsible for connector cracking caused by this aspect. Two examples of incorrect usage are listed below:

HYPERION Installation Manual
13
The unlock method of connectors is different according to local laws and regulations, please pay attention.
6.4. bypass diodes
The junction boxes used with Hyperion Solar modules contain bypass diodes wired in parallel with the PV cell
strings. In the case of partial shading, the diodes bypass the current generated by the non- shaded cells, thereby
limiting modules heating and performance losses. Bypass diodes are not over-current protection devices.
In the event of a known or suspected diode failure, installers or maintenance providers should contact Hyperion
Solar. Never attempt to open the junction box by yourself.
Please pay attention to guard against inductive lightning, backflow and wrong connection.
7. GROUNDING
The grounding is only used on the framed bifacial modules.
Hyperion Solar modules use an oxidized aluminum frame to resist corrosion. So the frame of modules must be
connected to the equipment grounding conductor to prevent thunder and static hurt.
The grounding device should fully contact with the inside of the aluminum alloy, and penetrate the surface of the frame
oxidation film.
Please don't drill any additional grounding hole on the frame of the modules, otherwise Hyperion Solar expressly
disclaim liability for voiding the warranty.
Besides equipment grounding, negative system grounding is also recommended by Hyperion. Failure to comply with
this requirement maybe reduce the performance of the system.
The grounding method should not result in the direct contact of dissimilar metals with the aluminum frame of the
modules that will result in galvanic corrosion. IEC 60950-1 standard recommends metal combinations not exceed an
electrochemical potential difference of 0.6 Volts.
The frame rails have pre-drilled holes marked with a grounding sign. These holes should be used for grounding
purposes and must not be used for mounting the modules.
The following grounding methods are available.
7.1. Grounding by using grounding bolt
There is a grounding hole with 4.2mm diameter on the edge side closer to the middle of the modules. The middle line
of the grounding mark is overlapped with the grounding hole, and the direction is same as the longer frame.
The grounding between modules must be approved by a qualified electrician. The grounding device must be produced
by a qualified electrical manufacturer. The recommended torque value is 2.3 N.m. 12 AWG copper wire can be used as

HYPERION Installation Manual
14
the equipment grounding conductor in conjunction with the grounding bolt. The copper wire should not be squashed
during the installation.
Figure 5: Installation method
7.2. Grounding by using unused mounting hole
The existing mounting holes which have not been used can be used for grounding.
• Direct the grounding clamp to the mounting hole on the frame. Thread the grounding clamp and the frame
with grounding bolt.
• Put the toothed gasket into the other side, then tighten and lock the nut. The recommended torque of locking
the nut is 2.0N.m~2.2N.m.
• Thread the grounding clamp with grounding wire. The materiel and size of grounding wire should meet
relevant requirements of the national, regional and local code, law and standard.
• Finish the mounting with tightening the binding bolt of the grounding wire.
7.3. Additional third-party grounding devices
Hyperion Solar modules can be grounded using third party grounding devices so long as they are certified for
grounding modules and the devices are installed according to the manufacturer’s specified instructions.
8. OPERATION AND MAINTENANCE
It is required to perform regular inspection and maintenance of the Modules, especially within warranty scope. It is the
user's responsibility to report to the supplier regarding the damages found within 2 weeks.
8.1. Cleaning
The dust accumulated on the front transparent substrate may reduce the power output, and may even cause regional
hot- spot effect. Industrial effluents or bird drops may be a serious case, and the extent of the severity depends on the

HYPERION Installation Manual
15
transparency of the foreign objects. It' s usually not dangerous for the accumulated dust to reduce the sunshine,
because the light intensity is still homogeneous and the power reduction usually is not obvious.
When Modules are operational, there may exist environmental factors that may distinctly reduce the power output.
Hyperion Solar advises that there should be no obstructed object over the Module' s surface at any time.
The cleaning frequency depends on the accumulating velocity of the fouling. In many instances the front substrate is
cleaned with rain, and we can decrease the cleaning frequency. It is recommended to wipe the glass surface with wet
sponge or soft cloth. Please do not clean the glass with cleaning agent which contains acid or alkali. Please refer to
“cleaning manual" for specific contents.
8.2. The visual inspection of the modules
Inspect the Modules visually to find if there are appearance defect, the following three types need more attention
especially:
• Whether the glass is broken;
• Corrosion along the cells* bus-bar. The corrosion is caused by the dampness infiltrated into the Modules
when the surface encapsulation material is damaged during the installation or transportation.
• If there is burning vestige on the backsheet.
8.3. Inspection of the connector and the cables
It' s recommended to implement the following preventive maintenance every 6 months:
• Check the encapsulation of the connector with the cable.
• Check the sealing gel of the junction box to ensure it is not cracked.
9. CONTACT US
Company: Runergy PV Technology (Thailand) Co., Ltd.
Manufacturer Address: 7/559 M.6, Mapyangphon, Pluak Daeng, Rayong, 21140, Thailand.
Email: info@ hyperion-usa.com
10. PRODUCT SUPPLEMENT
The installation manual is applicable for module types below. The module types are subject to changes without
prior notice due to continuous product innovation, research and development.
Name
Dimension
HY-DH108N8
1722*1134*30/35
HY-DH108P8
1722*1134*30/35
HY-DH120N8
1909*1134*30/35
HY-DH120P8
1909*1134*30/35
HY-DH132N8
2094*1134*30/35
HY-DH132P8
2094*1134*30/35
HY-DH144N8
2278*1134*30/35
HY-DH144P8
2278*1134*30/35
