Installation of Wheels to Powermax900
Kit: 128316
Page 1 of 3
KitContents-128316
Powermax900WheelKit
metI rebmuNtraP noitpircseD .ytQ
1825100tfeL-009xmP:reneffitSsissahC1
2555100thgiR-009xmP:reneffitSsissahC1
3750720"8:leehW2
4276400sleehW009xmP:elxA1
5709800"2/1x"2/1:rehsaWredluohS2
6942720gniRgniniateR2
7992720retsaC2
806157023-01:tunpeK21
9274570naPHP"4/3-1x23-01:S/M21
042308tiKleehW009xmP:BSF1
123 34
56
7789

Installation of Wheels to Powermax900
Kit: 128316
Page 2 of 3
WARNING
SHOCK HAZARD: Always turn off power and unplug cord from wall before installing wheels on the
power supply. If power unit is directly connected to a line disconnect box, place line disconnect
switch to OFF position. Lock out and tag out switch before proceeding!
1. If the torch is connected to the power supply,
unscrew and remove it.
2. Remove the screws (075467- qty. 18) that
secure the cover to the power supply
chassis.
3. Remove the power supply cover.
4. Carefully tilt the power supply forward on to its
front handle.
5. Align the right chassis stiffener (001555) to the
bottom of the power supply - see Fig. 2 for
outside view. Be certain that the holes in the
chassis stiffener are offset to the far left side
with two holes on the top and four holes on the
bottom.
6. Attach the right chassis stiffener to the power
supply chassis:
• Push 2 of the screws (075472) through the
top 2 holes of the chassis stiffener from the
outside (bottom) of the power supply - see
Fig. 1. Be certain that the screws also go
through the holes of the chassis floor.
• Hand tighten 2 of the kepnuts (075160) to
the screw ends that protrude through the
chassis floor. Figure 1 Power Supply on Front Handles -
Inside Floor View
Push 075472 screws through
these 2 holes from the outside
(bottom) of the power supply.
Holes to mount
right caster.
Right chassis stiffener 001555
on far side.

Installation of Wheels to Powermax900
Kit: 128316
Page 3 of 3
7. Attach one of the casters (027299) to the right
chassis stiffener as shown in Fig. 2. Insert 4
screws (075472) through the bottom 4 holes of
the chassis stiffener from the outside of the
power supply as in the previous steps.
• Hand tighten 4 kepnuts to the screw ends
that protrude through the chassis floor.
• Using a 3/8" (10 mm) nut driver, tighten
the 2 upper chassis stiffener kepnuts and
the 4 caster kepnuts firmly.
8. Repeat steps 5 through 7 to mount the left
chassis stiffener (001528) and remaining caster.
(Chassis stiffener holes offset to the right)
9. Snap a retaining ring (027249) on one end of
the axle (004672).
10. Slide one of the wheels (027057) onto the axle.
11. Slide one of the shoulder washers (008907)
over the end of the axle with the larger diam-
eter end of the washer facing the mounted
wheel.
12. Slide the axle through the axle hole in the right
chassis stiffener as shown in the figure.
13. Continue sliding the axle through to the axle
hole in the left chassis stiffener and mount the
other wheel as shown in the figure.
14. Tilt the power supply back on the wheels and
replace the power supply cover. Note that the
rear wheels interfere with the replacement of 2
of the power supply cover screws. It is not
necessary to insert these 2 screws.
Wheel installation is complete. See Powermax900
operator manual 803080 for further installation and
operation instructions.
Figure 2 Power Supply on Front Handles
Outside Bottom View
Right chassis
stiffener
001555
Left chassis
stiffener
001528
Shoulder
washer
008907
Retaining
ring
027249
Axle
004672 Wheel
027057
Caster
027299
Screws
075472
