Display - Remote Installation Kit Instructions
HD4070 Display - Remote Installation Kit
Kit Contents
001736 HD4070 Display Cover
075499 Screw, 6-32 (4)
- Cable (See instructions for cable P/N)
803730 Instructions
Purpose
This kit provides parts and instructions to remove the display from the power supply and mount it remotely.
NOTE: The HD4070 system can only support one touch screen display, either local or remote.
Installing displays at both locations on one system may cause malfunctions or damage.

Page 2
Display - Remote Installation Kit Instructions
HD4070 Display - Remote Installation Kit
Procedure
1. Turn off the power to the power supply.
2. Remove the the top panel from the power supply.
3 Remove the display from the power supply as shown below.
WARNING
ELECTRIC SHOCK CAN KILL
Turn off the power supply before removing any access cover. If the power
supply is directly connected to a line disconnect box, switch the line disconnect
to OFF (O). In the U.S., use a "lock-out / tag-out" procedure until the service or
maintenance work is complete. In other countries, follow appropriate national
or local safety procedures.
All work must be performed by a Hypertherm Distributor or a qualified technician.
4070.58

4070.59
J3
J1 J2 J4
J5
J8
J11
J15
J6
J10
J13
J9
J7
J12
J21
J20
J19
J18
J14
J17
J16
J23
J24
D13
D14
D5
D7
D6
D8
D11
D15 D16
D12
D24
D17
D25
D9
J23
J24
EXTERNAL
INTERNAL
J16
Page 3
Display - Remote Installation Kit Instructions
HD4070 Display - Remote Installation Kit
4 Remove the cable from the J16 connector on the breakout PC board as shown below.
5 Reposition the jumper blocks on the J23 and J24 connectors on the breakout PC board as shown
below.
STATIC ELECTRICITY CAN DAMAGE CIRCUIT BOARDS
•Put on a grounded wrist strap BEFORE handling PC boards.
WARNING

Page 4
Display - Remote Installation Kit Instructions
HD4070 Display - Remote Installation Kit
4070.60
6 Remove and discard the display cable from the power supply.
7 Install the panel into the power supply as shown below. Install the top panel onto the power supply.
4070.61
001736
Panel
075250 Screws (4)

Page 5
Display - Remote Installation Kit Instructions
HD4070 Display - Remote Installation Kit
8 Mount the remote display as shown below.
Cutout
1.7"/43 mm
7.835"/199 mm
5.71"/145 mm
Mounting Panel
(Customer Supplied)
4070.55

Page 6
Display - Remote Installation Kit Instructions
HD4070 Display - Remote Installation Kit
4070.52
A1
Display
1X4
A2
Ground to Chassis
A3
9 Install the remote display cable to the HD4070
power supply 1X4 connector and to the display
connector as shown below.
10 Install the grounding cable as shown below and
ground to chassis
HD4070 Power
Supply
Signal Cable - Power Supply to Remote Display
Part No. Length
123481 10 ft (3 m)
123482 20 ft (6 m)
123018 25 ft (7.5 m)
123484 30 ft (9 m)
Part No. Length
123485 40 ft (12 m)
123019 50 ft (15 m)
123487 75 ft (23 m)
123488 100 ft (30.5 m)
123489 150 ft (46 m)
1X4
A2
A1 Remote Display
Mark the identification num-
ber on the end of the cable.
Installation Notes:
A3 Ground Wire
