HyperX QuadCast HX-MICQC-BK User manual

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 1 of 16
HyperX QuadCastTM
Part Numbers
HX-MICQC-BK

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 2 of 16
TABLE OF CONTENTS
Overview ................................................................................................................................... 3!
Specifications .......................................................................................................................... 4!
Microphone Controls ............................................................................................................... 5!
Using with PC or Mac .............................................................................................................. 7!
Using with PS4™ ................................................................................................................... 11!
Connecting Headphones....................................................................................................... 12!
Controlling Microphone Monitoring ..................................................................................... 13!
Installing the Mount Adapter ................................................................................................ 15!

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 3 of 16
Overview
A. Tap-to-Mute Sensor
B. Gain Control Knob
C. Polar Pattern Knob
D. Headphone Jack
E. USB Cable Port
F. USB Cable
G. Mount Adapter*
*Supports both 3/8” and 5/8” thread sizes

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 4 of 16
Specifications
Microphone
Power consumption: 5V 125mA
Sample/bit rate: 48kHz/16-bit
Element: Electret condenser microphone
Condenser type: Three 14mm condensers
Polar patterns: Stereo, Omnidirectional, Cardioid, Bidirectional
Frequency response: 20Hz - 20kHz
Sensitivity: -36dB (1V/Pa at 1kHz)
Cable length: 3m
Weight:
• Microphone: 254g
• Shock mount and stand: 364g
• Total with USB cable: 710g
Headphone Output
Impedance: 32 Ω
Frequency response: 20Hz - 20kHz
Maximum power output: 7mW
THD: ≤ 0.05% (1kHz/0dBFS)
SNR: ≥ 90dB (1kHZ, RL=∞)

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 5 of 16
Microphone Controls
Selecting a Polar Pattern
Rotate the polar pattern knob to select one of the four polar patterns.
Symbol
Sound Direction
Polar Pattern
Scenarios
Stereo
Vocals, instruments
Omnidirectional
Multi-person
podcasts, conference
calls
Cardioid
Podcasts, streaming,
voiceovers,
instruments
Bidirectional
Face-to-face
interviews

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 6 of 16
Adjusting Gain Control
Rotate the gain control knob to adjust the gain of the microphone.
Muting the Microphone
Tap the top of the microphone to mute/unmute the microphone. The microphone LED will indicate the
current mute status of the microphone.
Microphone LED
Mute Status
Red
Mute off
Off
Mute on

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 7 of 16
Using with PC or Mac
Connect the microphone to a USB port on the PC or Mac with the included USB cable.
Windows
To ensure the microphone is configured correctly on the PC, follow the steps below:
1. Right-click on the sound icon on the system
tray and select Sounds.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 8 of 16
2. On the Playback tab, select Speakers
HyperX QuadCast and click on the Set
Default button.
3. On the Recording tab, select Microphone
HyperX QuadCast and click on the Set
Default button.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 9 of 16
macOS
To ensure the microphone is configured correctly on the macOS, follow the steps below:
1. Open System Preferences and select Sound.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 10 of 16
2. On the Output tab, select HyperX QuadCast.
3. On the Input tab, select HyperX QuadCast.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 11 of 16
Using with PS4™
Connect the microphone to a USB port on the PS4 with the included USB cable.
To ensure the microphone is configured with the most optimal settings on the PS4, follow the steps
below:
1. From the PS4 main menu, go to Settings > Devices > Audio Devices
2. Set Input Device to USB Headset (HyperX QuadCast)
3. Set Output Device to USB Headset (HyperX QuadCast)
4. Set Output to Headphones to All Audio
5. Set Volume Control (Headphones) to desired volume.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 12 of 16
Connecting Headphones
Connect headphones to the headphone jack on the microphone for microphone monitoring and
playback audio.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 13 of 16
Controlling Microphone Monitoring
PC
1. From the Sound control panel, on the
Playback tab, right-click on Speakers
HyperX QuadCast and select Properties.
2. On the Levels tab, adjust the Microphone
volume slider to adjust the level of
microphone monitoring.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 14 of 16
macOS
1. Open the Finder app and go to Applications > Utilities > Audio MIDI Setup
2. Click on HyperX QuadCast 2 and click on the checkbox under the Thru column to toggle
microphone monitoring on or off.
PS4
Microphone monitoring level cannot be directly controlled on PS4.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 15 of 16
Installing the Mount Adapter
1. Secure the included mount adapter onto a microphone boom arm. The mount adapter supports 3/8”
and 5/8” thread sizes.
2. Remove both the thumb screw and nut from the microphone stand.
3. Remove the microphone stand from the microphone.
4. Align the mount adapter with the microphone mount holes and secure the adapter with the thumb
screw and nut.

Document No. 480HX-MICQC.A01
HyperX QuadCastTM
Page 16 of 16
Questions or Setup Issues?
Contact the HyperX support team at: hyperxgaming.com/support/
