Hytek SPT80A Instruction manual

S559/5
Technical Data
SPT80A
DIRECT DRIVE PUMP UNIT
230v - 80 LPM
Please read carefully before commencing installation
Registered Office: HYTEK (GB) LIMITED, Delta House, Green Street, Elsenham, Bishop’s Stortford
CM22 6DS UK. Registered in England No. 1915382
Tel: [phone] Fax: [phone] email: [e-mail]
Web: www.hytekgb.com

S559/5
ENVIRONMENTAL INFORMATION
European Directives 2002/96/EC and 2003/108/EC require that the
equipment bearing this symbol on the product an/or its packaging must
not be disposed of with unsorted municipal waste. The symbol
indicates that this product must be disposed of separately from regular
household waste streams. It is your responsibility to dispose of this and
other electric and electronic equipment via designated collection
facilities appointed by the government or local authorities.
1. This dispenser MUST NOT be used to dispense petrol or other
flammable liquids.
2. It must not be sited adjacent to a petrol dispenser or any other
hazardous zone.
3. On above ground storage tanks, a spring loaded angle check valve or
pressure regulating valve must be fitted at the tank outlet to prevent
loss of fuel under gravity in the event of vandalism or accidental
damage.
4. Installation of this equipment and its associated tank, pipe work and
fittings should only be carried out by qualified fuel installation
engineers.
5. The installation must conform to all relevant electrical and local
authority regulations and standards.
6. The supplied strainer or a suitable strainer/filter MUST be fitted to the
suction line to prevent the pump unit from being damaged.
IMPORTANT ARNING NOTES

S559/5
INSTALLATION
1. If no wall-mounting bracket is supplied, mount on a horizontal surface
using the holes provided in the pump feet, or use a tank/barrel mount
adaptor if provided.
2. Fit the supplied strainer to the pump inlet.
3. Connect the pipe from the tank to the suction inlet of the pump. If the
pump is more than 2m from the tank the pipe should be 1½ diameter
reducing to the appropriate size just before the pump inlet. Seal the
threads with a suitable thread-sealing compound.
4. Connect a suitable “soft wall” hose to the pump outlet. In turn, fit a
suitable trigger or automatic nozzle onto the hose. Seal both with a
suitable thread-sealing compound.
5. Connect the flying lead to a suitable power supply, fused at 10 amps
for 230v AC and 16A for the 110v AC as follows:
230v AC: Brown – Live
Blue – Neutral
Yellow/Green – Earth
6. To prime the pump, first ensure the pump is switched off, there is fuel
in the tank, and the end of the suction hose is fully immersed. Remove
the filter cap and pour in fuel until the pump chamber is full. Replace
the filter cap and operate as per instruction for use.

S559/5
INSTRUCTIONS FOR USE
1. Switch on pump.
2. Place nozzle spout in the fuel tank.
3. Squeeze nozzle trigger to dispense fuel.
4. On completion of delivery, release nozzle trigger and remove nozzle
from fuel tank.
OPERATION ARNING - FAILURE TO OBSERVE THE
ARNINGS BELO MAY LEAD TO THE PUMP UNIT BEING
DAMAGED:
1. Please ensure that the delivery hose is stowed correctly after each use
to prevent it being run over by a vehicle.
2. Do not run the pump dry.
3. Do not run the pump for prolonged periods on bypass. (Nozzle closed).
Maximum running time on bypass = 2 minutes.
4. The supplied strainer or a suitable strainer/filter MUST be fitted to the
suction line to prevent the pump unit from being damaged.

S559/5
DIMENSIONS

S559/5
PARTS DIAGRAM
PARTS LIST
DIAGRAM No. PART NUMBER DESCRIPTION
9 SPT80A.1 ROTOR
10 SPT80A.2 VANE
14 SPT80A.3 SHAFT KEY
16 SPT80A.4 ON/OFF SWITCH
7 SPT80A.5 PUMP HOUSING
8 SPT80A.6 PUMP HOUSING O-RING
20 SPT80A.7 SHAFT SEAL
17 SPT80A.17 JUNCTION BOX

S559/5
NOTES

S559/5
E.C. DECLARATION OF CONFORMITY
Date of Issue: 23/12/09
Equipment Details: SPT80A Pump Unit And Motor
Applicable standards: EMC
EN61000-6-3:2007
EN61000-3-2:2006
EN61000-3-3:2008 Emissions
EN61000-6-1:2007 Immunity
2006/95/EC Electrical Equipment (Low Voltage)
Machinery Directive 2006/42/EC
The Pressure Equipment Regulations
1999 S.I. 1999/2001
Entry Into Force:- 29 November 1999
Amended to S.I. 2002/1267
Pressure Equipment Directive 97/23/EC
Waste Electrical and Electronic Equipment
Regulations 2006
2002/96/EC 2003/108/EC
Authorized By: Clive Wellings
Technical Manager Hytek
Declaration Number: EC019/5
