Hyundai XG250 User manual

NAME:
STREET:
TOWN:
COUNTRY:
P.CODE:
NAME:
STREET:
TOWN:
COUNTRY:
P.CODE:
A000A01A-GAT
This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the
next owner.
OWNER'S I.D.
ORIGINAL:
ADDRESS:
DATE OF SALE:
SUBSEQUENT:
ADDRESS:
TRANSFER DATE:

OWNER'S MANUAL
A030A02L-GAT
Operation
Maintenance
Specifications
All information in the Owner's Manual is current at the time of publication. Hyundai reserves the right to make
changes at any time as part of our policy of continual product improvement may be carried out.
This manual applies to current Hyundai XG250, XG300, XG350 models and explanations of optional as well as
standard equipment are included. As a result, you may find material in this manual that does not apply to your
specific vehicle.
Please note that some XG250, XG300, XG350 models are equipped with Right-Hand Drive (RHD). The explanations
and illustrations for some operations in RHD models are opposite of those written in this manual.
HXGS001

RESPONSIBILITY FOR MAINTENANCE
The maintenance requirements for your new Hyundai are found in Section 5. As the
owner,itisyourresponsibilitytoseethatallmaintenanceoperationsspecifiedbythe
manufacturer are carried out at the appropriate intervals. When the vehicle is used
in severe driving conditions, more frequent maintenance is required for some
operations. Maintenance requirements for severe operating conditions are also
included in Section 5.
A020A01A-AAT

A050A04A-AAT HYUNDAI MOTOR COMPANY
Note: Becausefutureownerswill also needtheinformationincluded in thismanual,ifyou sell this
Hyundai, please leave the manual in the vehicle for their use. Thank you.
CAUTION:
Severe engine and transaxle damage may result from the use of poor quality fuels and
lubricantsthatdonotmeet Hyundaispecifications.You mustalwaysuse highqualityfuels
and lubricants that meet the specifications listed on Page 9-4 in the Vehicle Specifications
section of the Owner's Manual.
Copyright 2002 Hyundai Motor Company. All rights reserved. No part of this publication may be
reproduced,storedinany retrieval systemor transmittedinany form orbyanymeanswithout the
prior written permission of Hyundai Motor Company.
A040A01A-AAT FOREWORD
Thank you for choosing Hyundai. We are pleased to welcome you to the growing number of
discriminating people who drive Hyundais. The advanced engineering and high-quality construc-
tion of each Hyundai we build is something of which we're very proud.
Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is
suggested that you read it carefully because the information it contains can contribute greatly to
the satisfaction you receive from your new car.
The manufacturer also recommends that all service and maintenance on your car be performed
by an authorized Hyundai dealer. Hyundai dealers are prepared to provide high-quality service,
maintenance and any other assistance that may be required.
!

TWO-WAY RADIO OR CELLULAR TELEPHONE INSTALLATION
Your vehicle is equipped with electronic fuel injection and other electronic compo-
nents. It is possible for an improperly installed/adjusted two-way radio or cellular
telephone to adversely affect electronic systems. For this reason, we recommend
thatyoucarefullyfollowtheradiomanufacturer'sinstructionsorconsultyourHyundai
dealerfor precautionary measuresor specialinstructionsif youchoose to installone
of these devices.
A080A01S-AAT
A070A01A-GAT !
CAUTION: MODIFICATIONS TO YOUR HYUNDAI
Modification of components may void the manufacturer's warranty
YourHyundaishould not bemodifiedinany way.Modificationsmayadversely affect
the safety, durability and performance of your Hyundai. Components which are
subjected to modification or are added to the vehicle resulting in consequential
damage are not covered by the vehicle manufacturer's warranty.

TABLE OF CONTENTS
SECTION PAGE
1. FEATURES OF YOUR HYUNDAI .......................................................................1-1
2. DRIVING YOUR HYUNDAI..................................................................................2-1
3. WHAT TO DO IN AN EMERGENCY ................................................................... 3-1
4. CORROSION PREVENTION & APPEARANCE CARE ...................................... 4-1
5. VEHICLE MAINTENANCE REQUIREMENTS.....................................................5-1
6. DO-IT-YOURSELF MAINTENANCE ................................................................... 6-1
7. EMISSION CONTROL SYSTEMS .......................................................................7-1
8. CONSUMER INFORMATION ..............................................................................8-1
9. VEHICLE SPECIFICATIONS............................................................................... 9-1
10. INDEX ................................................................................................................ 10-1
1
2
3
4
5
6
7
8
9
10

!
SAFETY AND VEHICLE DAMAGE WARNING
This manual includes information titled as WARNING, CAUTION and NOTE.
These titles indicate the following:
WARNING:
This indicates that a condition may result in harm, serious injury or death to
you or other persons if the warning is not heeded. Follow the advice provided
with the warning.
CAUTION:
This indicates that a condition may result in damage to your vehicle or its
equipment if the caution is not heeded. Follow the advice provided with the
caution.
NOTE:
This indicates that interesting or helpful information is being provided.
A090A01A-AAT
!

A100A01L-GAT
GUIDE TO HYUNDAI GENUINE
PARTS
1.WhatareHyundaiGenuineParts?
HyundaiGenuinePartsarethesame
parts used by Hyundai Motor Com-
panytomanufacturevehicles.They
are designed and tested for the
optimum safety, performance, and
reliability to our customers.
2. Why should you use genuine parts?
Hyundai Genuine Parts are engi-
neered and built to meet rigid origi-
nal manufacturing requirements.
A100A01L
Using imitation, counterfeit or used
salvagepartsarenotcoveredunder
the Hyundai New Vehicle Limited
WarrantyoranyotherHyundaiwar-
ranty.In addition,any damageto or
failure of Genuine Hyundai Parts
caused by the installation or failure
of an imitation, counterfeit or used
salvage part is not covered by
Hyundai Motor Company.
3. How can you tell if you purchasing
Hyundai Genuine Parts?
LookfortheHyundaiGenuineParts
Logo on the package (see below).
The export specifications are writ-
ten in English only.
A100A02L A100A04L
A100A03L
Hyundai Genuine Parts are only
sold through authorized Hyundai
Dealership and Service Center.

YOUR VEHICLE AT A GLANCE
B250A01L-GAT
INSTRUMENTS AND CONTROLS (LEFT-HAND DRIVE)
B250A02L
1345678910
11 12 13 14
15 16 17 18 19 20
2
21

YOUR VEHICLE AT A GLANCE
1. Headlight Leveling Switch (If installed)
2. Rear Fog Light Switch (If installed)
3. Panel Brightness Control Knob
(Rheostat Switch)
4. Traction Control Switch (If installed)
5. Multi-Function Light Switch
6. Cruise Control Main Switch (If installed)
7. Horn and Driver's Airbag
8. Cruise Control Switch/ Audio Remote Control Switch
(If installed)
9. Windshield Wiper/Washer Switch
10. Ignition Switch
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the
instrument cluster nor on the instrument panel pad surface. If there is any leakage from the
air freshener onto these areas (Instrument cluster, instrument panel pad or air ventilator), it
maydamagetheseparts.Iftheliquidfromairfreshenerdoesleakontotheseareas,washthem
with water immediately.
11. Hazard Warning Switch
12. Digital Clock
13. Audio System (If installed)
14. Passenger's Airbag (If installed)
15. Hood Release Lever
16. ParkingBrakeReleaseLever/ParkingBrake(Foottype)
17. Heater/Air Conditioning Control Panel
18. Shift Lever (If installed)
19. Ashtray
20. Accessory Box
21. Glove Box
!

YOUR VEHICLE AT A GLANCE
6
HXG501J
B250B01L-GAT
INSTRUMENTSANDCONTROLS(RIGHT-HANDDRIVE)
12345 89
10
11
12
713
14 15 1617
18
19 20 21

YOUR VEHICLE AT A GLANCE
1. Passenger's Airbag (If installed)
2. Digital Clock
3. Hazard Warning Switch
4. Cruise Control Main Switch (If installed)
5. Multi-Function Light Switch
6. Traction Control Switch (If installed)
7. Horn and Driver's Airbag
8. Cruise Control Switch/ Audio Remote Control Switch
(If installed)
9. Ignition Switch
10. Windshield Wiper/Washer Switch
11. Panel Brightness Control Knob
(Rheostat Switch)
12. Rear Fog Light Switch (If installed)
13. Headlight Leveling Switch (If installed)
14. Glove Box
15. Audio System (If installed)
16. Heater/Air Conditioning Control Panel
17. Shift Lever (If installed)
18. Ashtray
19. Accessory Box
20. Parking Brake Release Lever/Parking Brake
(Foot type)
21. Hood Release Lever
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the
instrument cluster nor on the instrument panel pad surface. If there is any leakage from the
air freshener onto these areas (Instrument cluster, instrument panel pad or air ventilator), it
maydamagetheseparts.Iftheliquidfromairfreshenerdoesleakontotheseareas,washthem
with water immediately.
!

YOUR VEHICLE AT A GLANCE
Turn Signal Indicator Lights
ABS Service Reminder Indicator
Traction Control Indicator Light
Seat Belt Warning Light
High Beam Indicator Light
Trunk Lid Open Warning Light
Front Fog Indicator Light
Low Oil Pressure Warning Light
Parking Brake/Low Brake Fluid Level
Warning Light
Charging System Warning Light
Door Ajar Warning Light and Chime
Low Fuel Level Warning Light
SRS (Airbag) Service Reminder
Indicator
Cruise Indicator
Stop/Tail Light Failure
Warning Light
Malfunction Indicator Light
B255A01L-GAT
INDICATOR SYMBOLS ON THE INSTRUMENT PANEL
* A more detailed explanations of these items will be found beginning on page 1-41

1. FEATURES OF YOUR HYUNDAI
Fuel Recommendations.................................................................. 1-2
Breaking In Your New Hyundai ...................................................... 1-3
Key (Immobilizer System)............................................................... 1-4
Door Locks (Theft-Alarm System) .................................................. 1-6
Power Windows ............................................................................ 1-10
Seat (Power Seat) ........................................................................ 1-11
I.M.S (Integrated Memory System)............................................... 1-15
Seat Belt ....................................................................................... 1-18
Child Restraint System ................................................................. 1-23
Supplemental Restraint (AIRBAG) System .................................. 1-31
Instrument Cluster and Indicator Lights........................................ 1-39
Warning Light and Indicator ......................................................... 1-41
Multi-function Light Switch............................................................ 1-48
Windshield Wiper/Washer Switch................................................. 1-50
Trip Computer ............................................................................... 1-53
Sunroof ......................................................................................... 1-57
Mirror............................................................................................. 1-62
Hood Release ............................................................................... 1-68
Cruise Control ............................................................................... 1-72
Audio Rmote Control Switch......................................................... 1-75
Heating and Cooling Control ........................................................ 1-76
Stereo Sound System................................................................... 1-91
Audio System................................................................................ 1-93
Antenna ...................................................................................... 1-115
1

1- 2 FEATURES OF YOUR HYUNDAI
B010B01A-AAT
What About Gasohol?
Gasohol (a mixture of 90% unleaded
gasoline and 10% ethanol or grain
alcohol)maybeusedinyourHyundai.
However, if your engine develops
driveabilityproblems,theuseof100%
unleaded gasoline is recommended.
Fuels with unspecified quantities of
alcohol,oralcoholsotherthanethanol,
should not be used.
B010D01S-AAT
Do not Use Methanol
Fuels containing methanol (wood al-
cohol) should not be used in your
Hyundai. This type of fuel can reduce
vehicleperformanceanddamagecom-
ponents of the fuel system.
B010E01A-AAT
Gasolines for Cleaner Air
To help contribute to cleaner air,
Hyundai recommends that you use
gasolines treated with detergent addi-
tives, which help prevent deposit for-
mationinthe engine. Thesegasolines
will help the engine run cleaner and
enhanceperformanceoftheEmission
Control System.
B010A02A-GAT
FUEL RECOMMENDATIONS
Use Unleaded Gasoline
Unleaded gasoline with a Pump Oc-
tane Rating of 87 (Research Octane
Number 91) or higher must be used in
Hyundai vehicle. If leaded gasoline is
used, it will cause the catalytic con-
verter to become ineffective and the
emission control system to malfunc-
tion.
Thiscanalsoresultinincreasedmain-
tenanceexpense.Toavoidaccidental
use of leaded fuel, the large nozzle
used with leaded gasoline at service
stations can not be inserted into fuel
tank opening of Hyundai vehicle.
NOTE:
o For some countries, Hyundai ve-
hiclesaredesignedtouseleaded
gasoline. When you are going to
use leaded gasoline, ask to
Hyundai dealer whether leaded
gasoline in your vehicle is avail-
able or not.
o Octane Rating of leaded gaso-
line is same with unleaded one.
B010A02L-1
!CAUTION:
Your Hyundai's New Vehicle Lim-
ited Warranty may not cover dam-
age to the fuel system and perfor-
manceproblemsthatarecausedby
the use of methanol or fuels con-
taining methanol.

FEATURES OF YOUR HYUNDAI 1- 3
B010F01A-AAT
Operation in Foreign Countries
If you are going to drive your Hyundai
in another country, be sure to:
o Observe all regulations regarding
registration and insurance.
o Determine that acceptable fuel is
available.
B020A01S-GAT
BREAKING IN YOUR NEW
HYUNDAI
During the First 2,000 Km (1,200
Miles)
No formal "break-in" procedure is re-
quired with your new Hyundai. How-
ever, you can contribute to the eco-
nomicaloperationanddurabilityofyour
Hyundai by observing the following
recommendationsduringthefirst2,000
km (1,200 miles).
B030A01Y-AAT
KEYS
Forgreaterconvenience,yourHyundai
has two master keys and a sub key.
The master keys will open all locks on
your vehicle. The sub key will only
function in the ignition and the door
locks.
Leaving your sub key with a parking
attendantwillensurethatyourvehicle's
trunk,trunklidrelease,gloveboxcom-
partment and rear trunk access may
not be unlocked in your absence.
NOTE:
Before leaving your sub key with a
parking attendant, make sure that
the lock levers of the rear seat back
HXG116
Master key Sub key
o Don't drive faster than 88 km/h (55
mph).
o While driving, keep your engine
speed (rpm, or revolutions per
minute) between 2,000 rpm and
4,000 rpm.
o Use moderate acceleration. Don't
start,depresstheacceleratorpedal
fully.
o For the first 300 km (200 miles), try
to avoid hard stops.
o Don'tlugtheengine(inotherwords,
don't drive so slowly in too high a
gearthattheengine"bucks":shiftto
a lower gear).
o Whether going fast or slow, vary
your speed from time to time.
o Don't let the engine idle longer than
3 minutes for a catalytic converter
equipped engine.
o Don't tow a trailer during the first
2,000 km (1,200 miles) of opera-
tion.

1- 4 FEATURES OF YOUR HYUNDAI
B030B01L
B880A01A-GAT
IMMOBILIZER SYSTEM
(If Installed)
Theimmobilizersystemisananti-theft
device, designed to deter automobile
theft.
B030B01A-AAT
Record Your Key Number
A code number is stamped on the
number plate that came with the keys
to your Hyundai. This key number
plate should not be left with the keys
but kept in a safe place, not in the
vehicle. The key number should also
be recorded in a place where it can be
found in an emergency.
If you need additional keys, or if you
shouldloseyourkeys,yourauthorized
Hyundai dealer can make new keys if
you can supply the key number.
B880B03Y-GAT
Three Types of Keys
1) ID key
Thiskey mustbe usedfirst toregis-
ter a unique ID code in the ICM.
2) Master key
This key is for general use. It will
open all locks on your vehicle. One
sideofthekeyhastheHyundailogo
andtheother sidehasthe "M" sym-
bol.
3) Sub key
Similar to the master key, this key
will only function in the ignition and
thedoorlocks,butitwillnotoperate
the trunk and the glove box. One
sideofthekeyhastheHyundailogo
andtheothersidehasa"S"symbol.
4) Leavingyoursubkeywithaparking
attendant will ensure that your
vehicle's trunk, trunk lid release,
glove box compartment and rear
trunk access may not be unlocked
in your absence.
NOTE:
Before leaving your sub key with a
parking attendant, make sure that
thelock levers of theseatbacklock
and the trunk lid lock are switched
to the "LOCK" position.
Forgreaterconvenience,yourHyundai
hasthreetypesofkeysasshowninthe
illustration.
ID-key
Masterkey
Subkey
B880B01L
lock and the trunk lid lock are
switched to the "LOCK" position.

FEATURES OF YOUR HYUNDAI 1- 5
B880C01A-GAT
Key Numbers
The vehicle key number is recorded
upon a metal tag attached to the keys
when the vehicle is first delivered to
you.
The key number should be recorded
and kept in a safe place in case the
needtoorderfurtherkeysarises.New
keys are available from any Hyundai
dealer by quoting the relevant key
number.
Intheinterestofsecurity,themetaltag
attached to the keys which bears the
key number should be removed from
thekeyringafteryoureceiveyournew
vehicle.In addition, key numbers can-
not be provided by Hyundai for secu-
rity reasons.
B880C01L
CAUTION:
Don't lose your ID key or forget the
password.Always keep your IDkey
inaplacewhereyourememberand
record your password. If you don't
haveboth thepasswordand ID key,
consult your authorized Hyundai
dealer.
!
5) If you need additional keys or if you
should lose your keys, your autho-
rizedHyundaidealercanmakenew
keysifyou cansupplythe key num-
ber and ID key.
NOTE:
Ifyoumakeyourownduplicatekey,
you will not be able to cancel the
system or start the engine.
If you need additional keys or if you
shouldloseyourkeys,yourauthorized
Hyundai dealer can make new keys if
youcansupplythekeynumberandID
key.
B030C01L-AAT
ILLUMINATED IGNITION
SWITCH
Whenever a door is opened, the igni-
tion switch will be illuminated for your
convenience, provided the ignition
switch is not in the "ON" position.
The light will go off approximately 10
secondsafterclosingthedoororwhen
the ignition switch is turned on.
B030C01L

1- 6 FEATURES OF YOUR HYUNDAI
UNLOCK
LOCK
HXG018
B040A01A-AAT
DOOR LOCKS B040B01A-AAT Locking and unlocking front
doors with a key
o Thedoorcanbelockedorunlocked
with a key.
o Lock the door by turning the key
toward the front of the vehicle and
unlock it by turning the key toward
the rear.
!
B040C03L
B040C02Y-AAT
Locking From the Outside
Thedoorscanbelockedwithoutakey.
To lock the doors, first push the inside
lock switch to the "LOCK" position, so
that the red mark on the switch is not
visible, then closed the door.
Thedoor willnotlockifthekeyis leftin
theignitionswitchwhenthefrontdoors
close. This is normal.
NOTE:
o When locking the door this way,
be careful not to lock the door
with the ignition key left in the
vehicle.
WARNING:
o Unlocked doors can be danger-
ous. Before you drive away (es-
pecially if there are children in
thecar),besurethatallthedoors
are securely closed and locked
sothat the doors cannotbe inad-
vertentlyopenedfromtheinside.
This helps ensure that the doors
will not be opened accidentally.
Also, when combined with the
proper use of seat belts, locking
the doors helps keep occupants
from being ejected from the car
in case of an accident.
o Before opening the door, always
lookforandavoidoncomingtraf-
fic.

FEATURES OF YOUR HYUNDAI 1- 7
o To protect against theft, always
remove the ignition key, close all
windows, and lock all doors and
the trunk lid when leaving your
vehicle unattended.
YourHyundaiisequippedwitha"child-
protector" rear door lock assembly.
Whenthelockmechanismisengaged,
the rear door cannot be opened from
the inside. Its use is recommended
whenever there are small children in
the rear seat.
To engage the child-protector feature
so that the door cannot be opened
fromtheinside,movethechild-protec-
torlevertothe" "positionandclose
the door. Move the lever to the oppo-
sitedirectionofthe" "positionwhen
normal door operation is desired.
B040D01S-AAT
Locking From the Inside
To lock the doors from the inside,
simply close the door and push the
lock switch to the "LOCK" position.
When this is done, neither the outside
nor the inside door handle can be
used.
NOTE:
When the door is locked, the red
mark on the switch is not visible.
HXGS226
LOCK
UNLOCK B040E03L
B040E03A-AAT
CHILD-PROTECTOR REAR
DOOR LOCK
If you wish to be able to open the door
from the outside, the outside door
handle will function normally.
B040G01L-AAT
Central Door Locks
The central door locking switch is lo-
cated on the driver's arm rest. It is
operated by depressing the door lock
switch. If any door is open when the
switch is depressed, the door will re-
main locked when closed.
NOTE:
o When pushing the front portion
of the driver's door lock switch,
all vehicle doors will lock.
B040G02L-1
LOCK
UNLOCK
