Hyundai HAS3000 User manual

1
ORIGINAL INSTRUCTIONS
Garden Blower Vacuum
Instruction Manual
HAS3000
IMPORTANT
READ CAREFULLY BEFORE USE.
KEEP FOR FUTURE REFERENCE.
HYUNDAI
32, rue Aristide Bergès - ZI 31270 Cugnaux –France
Fabrique en PRC 2018

2
CONTENTS
1. SAFETY INSTRUCTIONS 3
2. YOUR PRODUCT 9
3. ASSEMBLY 10
4. OPERATION 12
5. MAINTENANCE AND STORAGE 14
6. DISPOSAL 14
7. DECLARATION OF CONFORMITY 15

3
1. SAFETY INSTRUCTIONS
Safe operating practices for hand-held mains-operated electrical garden
vacuums, and garden blower/vacuums with or without shredding means and
garden blowers
Training
a) Read the instructions carefully. Be familiar with the controls and the correct use
of the machine.
b) Never allow children or people unfamiliar with these instructions to use the
machine. Local regulations can restrict the age of the operator
c) Keep in mind, that the operator or user is responsible for accidents or hazards
occurring to other people or their property.
Preparation
a) Obtain ear protection and safety glasses. Wear them at all times while operating
the machine.
b) While operating the machine always wear substantial footwear and long trousers.
Do not operate the machine when barefoot or wearing open sandals. Avoid
wearing clothing that is loose fitting or that has hanging cords or ties.
c) Do not wear loose clothing or jewellery that can be drawn into the air inlet. Keep
long hair away from the air inlets.
d) Operate the machine in a recommended position and only on a firm, level surface.
e) Do not operate the machine on a paved or gravel surface where ejected material
could cause injury.
f) Before using, always visually inspect to see, that the shredding means,
shredding means bolts and other fasteners are secure, the housing is
undamaged and that guards and screens are in place. Replace worn or
damaged components in sets to preserve balance. Replace damaged or
unreadable labels.
g) Before use, check the supply and extension cord for signs of damage or aging. If
the cord becomes damaged during use, disconnect the cord from the supply
immediately. DO NOT TOUCH THE CORD BEFORE DISCONNECTING THE
SUPPLY. Do not use the machine if the cord is damaged or worn.
h) Never operate the machine while people, especially children, or pets are nearby.
Operation
a) Before starting the machine, make certain that the feeding chamber is empty.
b) Keep your face and body away from the feed intake opening.
c) Do not allow hands or any other part of the body or clothing inside the feeding
chamber, discharge chute, or near any moving part.
d) Keep proper balance and footing at all times. Do not overreach. Never stand at a
higher level than the base of the machine when feeding material into it.
e) Always stand clear of the discharge zone when operating this machine.
f) When feeding material into the machine be extremely careful that pieces of metal,
rocks, bottles, cans or other foreign objects are not included.

4
g) If the cutting mechanism strikes any foreign objects or if the machine should start
making any unusual noise or vibration, immediately shut off the power source
and allow the machine to stop. Disconnect the machine from the supply and take
the following steps before restarting and operating the machine:
⚫inspect for damage;
⚫replace or repair any damaged parts;
⚫Check for and tighten any loose parts.
h) Do not allow processed material to build up in the discharge zone; this may
prevent proper discharge and can result in kickback of material through the intake
opening.
i) If the machine becomes clogged, shut-off the power source and disconnect the
machine from supply before cleaning debris.
j) Never operate the machine with defective guards or shields, or without safety
devices, for example debris collector in place.
k) Keep the power source clean of debris and other accumulations to prevent
damage to the power source or possible fire.
l) Do not transport this machine while the power source is running.
m) Stop the machine, and remove plug from the socket. Make sure that all moving
parts have come to a complete stop
⚫whenever you leave the machine,
⚫before clearing blockages or unclogging chute,
⚫Before checking, cleaning or working on the machine.
n) Do not tilt the machine while the power source is running.
Maintenance and storage
a) When the machine is stopped for servicing, inspection, or storage, or to change
an accessory, shut off the power source, disconnect the machine from the supply
and make sure that all moving parts are come to a complete stop. Allow the
machine to cool before making any inspections, adjustments, etc. Maintain the
machine with care and keep it clean.
b) Store the machine in a dry place out of the reach of children.
c) Always allow the machine to cool before storing.
d) When servicing the shredding means be aware that, even though the power
source is switched off due to the interlock feature of the guard, the shredding
means can still be moved
e) Replace worn or damaged parts for safety. Use only genuine replacement parts
and accessorises.
f) Never attempt to override the interlocked feature of the guard.
Additional safety instructions for units with bagging attachments
Switch-off the machine before attaching or removing the bag.
Recommendation
The machine should be supplied via a residual current device (RCD) with a tripping
current of not more than 30 mA.
Additional instructions
⚫This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.

5
⚫Children should be supervised to ensure that they do not play with the appliance.
⚫Never allow children, persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge or people unfamiliar with these
instructions to use the machine, local regulations may restrict the age of the
operator.
⚫Never use the machine when people, especially children, or pets are nearby.
⚫Remember that the operator or user is responsible for accidents or hazards
occurring to persons or their belongings.
⚫Before connecting, check:
oWhether the tool and cable are not damaged. If damaged, do not use the
machine and bring it back to your dealer for inspection and repair.
oThat the voltage on the rating plate of the tool matches with your electrical
installation.
⚫Do not use accessories other than those recommended by the manufacturer;
Non-recommended accessories can damage the unit and/or cause injuries.
⚫Do not disassemble the tool yourself. Disassembly, repair or inspection must be
made exclusively by qualified personnel.
⚫Use the tool fully assembled and secure. Before using, check if the protections
and safety devices are in place.
⚫During the operation of the machine, always wear protective equipment, including
protective masks, visors or goggles, ear protection, helmet, gloves, non-slip
footwear and protective clothing.
⚫Always carry the machine by its handle; never use the cord or any other part of
the machine.
⚫Do not use the machine when you are tired, under the influence of alcohol or
drugs or sick.
⚫Use the tool to suck and blow leaves and similar materials. Do not blow
flammable materials, cigarette butts and materials that can damage the device.
⚫Do not use the appliance to suck water or wet debris.
⚫Always use the machine with the collection bag.
⚫Avoid using the machine in bad weather, especially when there is a risk of
thunderstorms and lightning.
⚫In case of accident, immediately stop using the machine. Turn off and unplug it
and check the problem. Do not use the machine while the machine is damaged.
⚫Do not use the tool if you are drunk, tired, under the influence of drugs or ill. Do
not use the tool if you are not in an adequate physical condition
⚫Do not use the tool during bad weather conditions (lighting, rain, storm, big winds,
etc.)
⚫Do not use the tool in an area where ventilation is poor. Gas emissions can
cause injury.
⚫Do not use the tool in damp locations.
⚫Do not use the tool in the presence of flammable liquids or gases.
⚫Do not operate the product with damaged guards or shields not in place.
⚫Do not lean. Keep a good balance at all times.
⚫Keep handles dry, clean and free from oil and grease.
⚫Use and handle the machine carefully.
⚫Do not put your body, clothes or shoes close to the air opening
⚫Do not lift up the tool when it is in operation.
⚫Do not point the tool in front of people; this can lead to accidents and injuries.

6
⚫Do not put any objects inside the tube and inside the tool.
⚫Before using the product and after any shock, please check it for signs of wear or
damage.
⚫Please carry out repairs if necessary.
⚫Inspect and regularly service the product. Repairs should be carried out only by
an authorized service center or a similarly qualified specialist.
⚫Children should not play with plastic bags, sheets and small parts! Keep them out
of the reach of children. There is a danger of swallowing and suffocation!
⚫Do not use the product on a slippery surface.
⚫Do not use the product on steep, slippery slopes. If you need to work on slopes,
use an extreme care and be careful about your footing. Please wear non slippery
footwear.
⚫When planning your work schedule, allow enough time for rest. Limit continuous
use of the device, e.g. use 30 ~ 40 minutes per session, and take 10 ~ 20
minutes of rest between work sessions. Work a maximum of two hours per day.
⚫Do not connect a damaged cord to supply or touch a damaged cord before it is
disconnected from the supply; damaged cords can lead to contact with live parts.
⚫Keep extension cords away from moving hazardous parts to avoid damages to
the cords which can lead to contact with live parts.
⚫When a cable is damaged or entangled, please stop immediately to use the tool.
Switch off the tool, let it cool and unplug it in a secure way.
⚫When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
⚫Use extra care when using on stairs.
⚫In dusty conditions, slightly dampen surfaces or use mister attachment if
available
⚫Use the full blower nozzle extension so the air stream can work closer to the
ground
⚫Never use the appliance for spreading chemicals, fertilizer, or any other
substances that may contain toxic materials. Do not use appliance as a sprayer
of flammable liquids.
⚫Keep all the air intakes and the blower tube free of dust, lint, hair and other
material that may cause a reduction in air flow.
⚫Do not switch on the tool in enclosed or poorly ventilated spaces or in the
presence of inflammable and/or explosive substances such as liquids, gasses,
and powders.)
⚫Disconnect electrical supply before opening inlet cover or installing pick up tubes.
Never operate unit without inlet cover secured or pick-up tubes in place.
⚫Always inspect the area before starting the appliance to remove debris and hard
or sharp objects that can be blown or cause damaged during operation
⚫Never operate this appliance when you are tired, ill or under the influence of
alcohol, drugs or medication.
⚫Always run the appliance with the blower tubes attached to the unit.
⚫Always work moving away from solid objects such as walls, large stones,
automobiles and fences.
⚫Clean spaces with corners by starting in corners and moving outward to straight
areas to prevent an accumulation of debris, which could fly into face.
⚫Be careful when working near valuable plants. The force of air could damage
tender plants.

7
⚫Uses for your blowers: sweeping debris or grass clippings from driveways,
sidewalks, patios, parks, parking lots, barns, etc. Gathering grass clippings, straw
or leaves into piles. Removing debris from corners, around joints and between
bricks.
⚫Stay alert. Watch what you are doing and use common sense when operating a
power tool. Do not operate tool when you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury.
Residual risks
Even if you use this product in compliance with all safety requirements, the potential
risks of injury and damage remain. The following hazards may arise in the structure
and design of this product:
a. There are harmful health consequences resulting from the emission of vibrations if
the product is used for long periods of time or not properly managed and properly
maintained.
b. Risk of injury to persons and property caused by flying objects.
c. Prolonged use of this product exposes the operator to vibration and can produce
so-called "white finger" disease. To reduce the risk, wear gloves and keep your
hands warm.
d. If any of the symptoms of "white finger syndrome" occur, seek immediate medical
attention. Symptoms of the "white finger" include numbness, loss of sensitivity,
tingling, and pain, loss of strength, colour changes or skin condition. These
symptoms usually appear on the fingers, hands or wrists. Risk increases at low
temperatures.
e. Inhalation of particles of material blown/vacuumed
f. Unattended projections
g. Contact with foreign objects
h. Contact with the tool in operation
i. Hearing loss in the absence of correct hearing protection
Explanation of symbol
a. Description
This product is double insulated electrically
Read instruction manual before operating or attempting any maintenance work
Conforms to all relevant EC Directives

8
Denotes risk of personal injury, loss of life, or damage to the tool in case of
non-observance
SWITCH OFF: Remove plug from mains before cleaning or maintenance.
Do not use in the rain or leave outdoors while it is raining.
Wear an eye protection
Keep bystanders away
Guarantee sound power level
Remove plug from the mains immediately if the cable is damaged or cut.
Intended use
This vacuum blower is intended to be used for the vacuuming and the blowing of
leaves, dust, and similar little materials. It must not to be used for vacuuming and
blowing water, chemical products, flammable material, metal or wood and others
dangerous objects.
⚫This product is intended for private domestic use only. It must be used outdoors.
⚫This product is not intended to be used in a closed room or in places where
exhausted gas and flames can be present.
⚫The use of this product in case of rain or humid environment is prohibited.
⚫Use this vacuum blower only as described in this manual and only for the
intended use as described above.
⚫Any other use might lead to damage of the appliance, property or personal injury.

9
⚫No liability will be accepted for damage resulting from improper use or non-
compliance with this manual.
2. YOUR PRODUCT
a. Description
1. Supply cable
2. Main handle
3. On/off switch
4. Front handle
5. Blower tube
6. Motor housing
7. Function switch (blower/vacuum)
8. Collection bag
9. Wheel
10. Attachment for shoulder harness
11. Speed control roller
b. Technical specifications
Model
HAS3000
Rated input power
3200W
Rated no-load speed
10000-15000/min
Rated Voltage
230-240V~50Hz
Blower velocity
250 km/h
Maximum blower air output
10.7m3/min
Collect bag capacity
40L
Weight
2.7Kg
sound pressure level
87.4dB(A) K=3 dB(A)
sound power level
98.07dB(A) K=0,85 dB(A)
Guarantee sound power level
99dB(A)
vibration
1.66 m/s² K= 1,5 m/s²

10
3. ASSEMBLY
a. Tube assembly
- Slide the upper tube into the motor housing, then tighten the screws and make sure the tube
is firmly fixed with motor housing.
- Insert the 2 lower tubes (one into upper tube and the smaller below) and push them until they
are connected firmly together. Use the provided plate and two screws to fix the tubes
together.

11
- Assemble the wheels to the lower tube. Add one wheel on each side of the hole situated on
smaller lower tube. Fix the wheels together with the screw and the nut. Then fix the provided
two plates and screws to fix the tubes together.
Caution: In the interests of safety the tubes should not be dismantled after they have been
assembled
- Attach the collect bag to the hook on upper tube and the outlet on the bottom of motor
housing.

12
4. OPERATION
Before starting the machine, make sure that collect bag is fitted and the shoulder harness is
adjusted to a suitable working position.
a. Extension cable
The tool must be connected to an extension cable. Plug the cable of the tool into
extension cable. Then, attach the extension to the cable holder to hold it.
The extension cable shall not be lighter than the standardised code H05 RN-F/H05 VV-F.
See your retailer or manufacturer for more advice.
b. Switching on and off the tool
Before start the tool, be sure that the speed control knob is on the position 1 (lower
position).
- To switch on, press the ON/OFF switch (fig 2a).
- To stop the tool, release the ON/OFF switch (fig 2b).
2a 2b
c. Speed Control
You can adjust the power of the air flow with the control knob. The power goes to 1 to 6 (from
the lower to the highest power).
Turn the knob to adjust the power of the airflow, according the work performed.
When stop to use the machine, put the knob to the position 1.
d. Blowing mode
Blowing mode can be used for cleaning corners, fences, walls, wooden areas or beneath cars. Be
careful what you point the jet of air as it could move heavy material and cause injury or damage.
- Inspect the work area before starting. Remove any debris or objects that could be thrown or
those that can get caught or obstruct the device.
- Put the shoulder strap.
- Push down the lever to choose the blowing mode.

13
- Hold the machine by the handle. Walk and hold the tube just above the ground and blow the
debris.
- Switch on the tool by pushing and holding the ON/OFF switch.
- Work in order to gather the debris in one or more lots. Use the vacuum mode to collect the
heap. You can also pick up the pile of debris with a broom (or rake) and a shovel.
- When the operation is finished, release the ON/OFF switch.
- Throw away the debris in a trash bin.
e. Vacuum mode
- Inspect the work area before starting. Remove any debris or objects that could be thrown or
those that can get caught or obstruct the device.
- Put the shoulder strap.
- Push up the lever to choose the vacuum mode.
- Make sure that the collect bag is fitted properly.
- Switch on the tool by pushing and holding the ON/OFF switch.
- Put the tube to the ground without putting it in the debris. Move while sucking debris
- When the collection bag is filled, stop working and empty the bag.
When the collect bag is full, the vacuum power will be greatly reduced. When this happens,
turn the switch to position “1” and disconnect the plug from the electricity supply. Wait until
the suction fan has stopped completely before operation. Open the zip fastener inside the bag;
spread out the opening and empty it completely. If you have collected only leaves or vegetable
matter, they will already have been shredded and will be ready for composting. Zip up the bag
and resume work.
Note: Before re-fitting the bag, clean the inside of the exhaust opening, removing any
shredded deposits. Pay special attention to the cleaning of the supporting edges of the air
flow deviator on the inside of the tube.

14
5. MAINTENANCE AND STORAGE
WARNING! Do not use products that can damage the device (abrasive, corrosive, alcohols,
steam cleaners, abrasive cloths, scrapers, etc.).
Do not install the appliance in a dishwasher for cleaning!
The unit must be completely switched off, unplugged, and cool before cleaning.
a. Care
After each use:
- Remove the collection bag and empty its contents into a dustbin.
- Use a brush to remove debris from fan and inside the tube.
- If necessary, you can clean the body of the tool with a soft dry cloth.
b. Maintenance
After each use:
- Check all nuts, bolts and screws are tight and that the safety devices are properly positioned.
- Check if the machine has not suffered damage. If the machine is damaged, you will need to
hire a qualified technician to inspect the machine and makes repairs.
c. Storage
- Always clean the tool before storage.
- The tool, tube and collector bag must be stored in a well-ventilated place, stable and plane.
- The tool must be out of the reach of children.
6. DISPOSAL
Electrical products should not be discarded with household products. According to the European
Directive 2012/19/EC on waste electrical and electronic equipment and its implementation into
national law, electrical products used must be collected separately and disposed of at collection
points provided for this purpose. Talk with your local authorities or dealer for advice on recycling.

15
7. DECLARATION OF CONFORMITY
HYUNDAI
ZI, 32 rue, Aristide Bergès –31270 Cugnaux - France
Tel: [phone] Fax: [phone]
States that the designated below machine:
Garden Blower Vacuum
HAS3000
Serial number:
Developed, designed and manufactured in accordance with the requirements of directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EC
ROHS Directive 2011/65/EU
Directive Noise 2000/14/EC Annex V and 2005/88/EC
Sound power level: 98.07dB(A) K=0,85 dB(A)
Guarantee sound power level: 99dB(A)
Also meets the following standards
EN 60335-1:2012/A11:2014
EN50636-2-100:2014
EN55014-1:2006+A1:2009+A2:2011
EN55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
EN62233:2008
Philippe MARIE/PDG
Cugnaux, 17/07/2018
Responsible of the technical file: Mr Olivier PATRIARCA
