Important Tip
Image Retention Effect (Image Sticking)
1. Cause :
- Image Retention Effect may come from displaying a still picture in certain period of time with at a
certain area continuously, as the feature of LCD panel. This is caused due to brightness degradation.
Many LCD manufacturers are trying to overcome this limitation.
2. Prevention
- To avoid this matter, use the product after reducing brightness and contrast, especially when a still
image is displaying for a long time. (Contrast 50/Brightness 50 - See 32 page)
Once image retention occurs, use the mode that displays more motion pictures. It will help reduce this
matter.
3. Solution
- The temporary image sticking would decrease with displaying Full-White pattern during 10 hours.
* The permanent image sticking could not take off under the latest technology.
This method may be used to eliminate a temporary retained image that occurs after displaying a still
image for a certain period of time. Since it may take several minutes to several hours to remove image
sticking, it is recommendable to display motion pictures during 2~3 minutes every hour when keeping
displaying a still image. As image sticking is influenced by the brightness of a still image being
displayed and its display time, it is recommended that you reduce the brightness of the screen when
displaying a still image for a long time.
* Image Sticking does not come under the warranty.

HYUNDAI Vvuon Digital LCD TV
Image Sticking Precaution
When watching a still Image within motion pictures and
Panorama/Wide/4:3 screen
1. Note :
- When the central area of the screen and the screen edges are fixed, the different brightness level of
the edges may cause image retention on the edges when watching for a long time
- This phenomenon is the same matter to other LCD manufacturers. Please do not watch a still image
for a long time.
- If you watch a still image for a long time, this may damage your TV.
* This matter does not come under the warranty.
Panorama, Wide, 4:3 screen
Box still image

Features
Dual Scan/Multi-Viewing
You can program analog TV broadcasting and digital TV broadcasting automatically at the same
time for multi-viewing.
A Wide Array of Screen Settings
You can choose different screen settings depending on the type of program you are watching or
the surrounding conditions (the outside weather conditions). You can switch among Standard,
Dynamic, Movie, and Mild options or you can configure the screen settings for yourself.
A Wide Array of Sound Settings
You can choose an optimal sound setting for the type of program you are watching.
You can switch among Standard, News, Music, and Sport options or you can configure the
sound settings for yourself.
TV Program Reservation
If you reserve a digital TV program you are going to watch, the channel you are currently
watching is automatically switched to the reserved channel.
Favorite Channel Memory
You can memorize the channels you are watching frequently.
SRS TrueSurround XT
You can enjoy dynamic and surround sound with ordinary speakers.
Dolby-Digital
When receiving digital broadcast signal, you can enjoy dynamic and surround sound with two
ordinary speakers just like Dolby 5.1.
A Variety of Aspect Ratios
You can adjust the screen size at your preference.
Auto On/Off Function
This function allows you to turn on or off your TV at the preset time.
Game Prevention Function
This function is designed to prevent a VCR or game player from being connected to the TV.
Memory Card Support
You can enjoy photo images, music files and movies by inserting a variety of memory cards.

HYUNDAI Vvuon Digital LCD TV
Table of Contents

WARNING
WARNING
5
Safety Precaution
The contents of this section are provided for the safety of users and their property.
Please read the instructions carefully before using.
Do not connect multiple electrical
appliances to a single outlet.
- It may cause a fire due to overheating from
the outlet.
If there is a persistent accumulation
of dusts or water on the plug, please
make sure to wipe it off using a dry
cloth.
- It may cause a fire or an electric shock.
Do not put a water bowl, vase,
candle, bug repellant smoke,
cigarette, plants, or heavy thing on
the TV.
- It may cause electric shock or fire and also
heavy things may cause injury when they
fall.
Do not install in a place where there
is oil, smoke, excessive humidity, or
where water may be sprinkled on it.
- This may cause electric shock or fire.

Safety instructions are divided into “Warning” and “Alert”. Their meanings are as follows.
This icon is intended to alert the user to the presence of potential danger and important operating instructions.
WARNING : When there is a possibility of serious injury if not observed.
ALERT : When there is a possibility of slight injury or product damage if not observed.
6
HYUNDAI Vvuon Digital LCD TV
Firmly plug in the power cord so that
it does not pull out.
- An unstable connection may cause fire.
Do not use a damaged power cord
or plug, or loose outlet.
- It may cause electric shock or fire.
Do not install on an unstable place
or small support.
- This may cause the TV to fall, resulting in
serious injury to a child or adult.
Do not use or store a flammable
spray or inflammable things near the
TV.
- They may cause explosion or fire.
Do not install the TV in a
bookshelf, closet, or a place where
there is poor air circulation.
- Fire may be caused due to the rise of
internal temperature.
Make sure to remove the speakers
before moving the TV with speakers
mounted on it.
- When the speakers are detached from the
unit while carrying it, this may cause damage
to the unit or personal injury.

7
Safety Precaution ......................................Continued from previous page
The contents of this section are provided for the safety of users and their property.
Please read the instructions carefully before using.
WARNING
WARNING
Do not place any heat sources such as
radiators and heat registers, etc. near the TV.
- It may cause a fire.
Do not block ventilating slits with a table
cloth.
- Blocking the ventilation slits may produce
inner heat increase, resulting in a fire.
Any necessary action such as making the
antenna cable loop at the entrance of the
building should be taken to prevent rainwater
on the outdoor antenna cable from possibly
running into the indoor.
- If raindrop gets into the LCD TV, it may
cause a fire or an electric shock.
Never attempt to open, fix, or modify
your TV.
- When there is a need for fixing, call a
service center. Fire or electric shock may be
caused.

Safety instructions are divided into “Warning” and “Alert”. Their meanings are as follows.
This icon is intended to alert the user to the presence of potential danger and important operating instructions.
WARNING : When there is a possibility of serious injury if not observed.
ALERT : When there is a possibility of slight injury or product damage if not observed.
8
HYUNDAI Vvuon Digital LCD TV
Do not install the product on the floor.
- If it falls over, your child may be injured.
Unplug the product during lightning or
thunderstorms and never touch the antenna
cable.
- It may cause a fire or an electric shock.
Keep the remote control batteries out of
sight and out reach of children.
- If your child swallows a battery, see your
doctor immediately.
Do not put a metallic object like chopstick,
wire, or puncher or inflammables like paper
or a match in a vent, headphone jack, or AV
jacks of the TV.
- Electric shock or fire may be caused.
When the TV produces abnormal noise,
burning smell, or smoke, unplug the TV
immediately and call a service center.
- Electric shock or fire may be caused.
Keep the TV at least 10cm away from the
wall for ventilation.
- Fire may be caused due to the rise of inner
temperature.

Safety Precaution ......................................Continued from previous page
The contents of this section are provided for the safety of users and their property.
Please read the instructions carefully before using.
9
ALERT
WARNING
Do not allow children to climb or play on the
TV.
- If it falls over on children, it may cause
serious injury.
Do not place toys and cookies, etc. on the TV,
which may attract children’s attention.
- If it falls over on children, it may cause serious
injury.
In the event of damaging or dropping the
product, switch off the power and remove
the plug.
- Using a damaged product may cause an
electric shock or a fire.
- Contact your local service center.
Unplug when you do not use your TV for a
long time.
- If dust is stacked on the TV, electric shock
or fire may be caused from heat, fire, or
deterioration of insulation.

10
HYUNDAI Vvuon Digital LCD TV
When cleaning the TV, make sure to
disconnect the power plug and use a dry, soft
cloth for a cleanup.
- Please avoid using chemicals such as wax,
benzene, alcohol, thinner, mosquito spray,
air freshener, lubricant or synthetic
detergent.
When replacing batteries, make sure to
match the batteries to the (+) and (-) marks
in the battery compartment.
- Mismatching of polarities may result in
internal damage to batteries, fire due to
leakage or contamination.
Always use the standard batteries and avoid
using old batteries together with new ones.
- Otherwise it may result in internal damage
to batteries, fire due to leakage or
contamination.
When moving the TV, two or more people are
advised to carry it.
- Injury or damage may be caused when the
TV falls.
Before moving the product, ensure to switch
off the power and unplug all the electrical
cords and the external connection cords such
as an antenna cable and other source
connections, etc.
- An electrical cord(s) may be damaged,
resulting in a fire or an electrical shock.
Consult a service center or customer service
for inside cleaning about once a year.
- When dust is piled inside the TV for long
time, fire or malfunction may be caused.
Safety instructions are divided into “Warning” and “Alert”. Their meanings are as follows.
This icon is intended to alert the user to the presence of potential danger and important operating instructions.
WARNING : When there is a possibility of serious injury if not observed.
ALERT : When there is a possibility of slight injury or product damage if not observed.

11
Contents of the Package
When opening the package, please ensure to check the following accessories provided.
Products Sold Separately
If you want to purchase separately sold products, consult a service center, electronics shops, or parts seller.
Power Cord
Antenna Cable
(coaxial cable)
User's GuideRemote Control & 2 batteries
(1.5V AAA)
Scart cable
Component Cable
(Y, Pb, Pr)
Composite Cable
(Video/Audio)
PC signal Cable (D-SUB)
Audio Cable (PC)Audio Cable (DIV/DVD)
Wall Mounting Support
S-video Cable

HYUNDAI Vvuon Digital LCD TV
12
Kensington Lock Anti-theft Device
- This display unit supports Kensington standard security lock to prevent theft.
- You should purchase the Kensington lock device personally, if you need. The security lock is available at an
electronics shop.
- For more information, please refer to the following contact information..
* Kensington Technology Group
• Address : 2000 Alameda de las Pulgas 2F san mateo, California 94403-1289
• Tel : [phone] • Fax : [phone] • Web-site : www.kensington.com

How to Mount and Detach The Speakers
You can attach the speakers to the base of the unit or use them separately.
How to mount the speakers onto the base of the unit
1. Tilt the unit backward until its base faces to yourself (See page 12 How to adjust the view angle).
2. Lift up the hooks on the speaker.
3. Align the speaker hooks with the cavity holes.
4. Slide speakers inward to attach securely as shown in Figure below.
13
The provided speakers are designed for this product only. It is recommended not to
connect the speakers to other device. When connecting other amplifier, the amplifier
output should be within 10W. The output that exceeds 10W may cause fire.
Make sure to remove the speakers before moving the TV. When the speakers are
detached from the unit while carrying it, this may cause damage to the unit or personal
injury.
WARNING
ALERT
When detaching the speakers
When you are going to detach the speakers,
press the tension hook and remove the
speakers in reverse order as shown in the
above figure.

How to adjust the view angle
You can adjust the panel downward or upward at a 0~15 degree angle.
14
HYUNDAI Vvuon Digital LCD TV
15O

15
How To Install Wall Mount Support
1. Caution
1. Install on the vertical wall surface only.
2. Do not install on the following places to protect the performance of LCD TV and to prevent malfunction.
- Near sprinkler detector - Near heating devices - Places where vibration or shock may be applied
- Near high-voltage power line
3. Wall mounts must not be mounted to surfaces or building materials that cannot support the wall mount.
If the wall is not strong enough to stand the weight of TV set, reinforce the wall surface before installation.
4. Do not install within a wall.
2. Accessories
The above image may look different from the real product.
3. Angle Adjustment (Optional)
The wall mount bracket allows you to adjust the angle of TV from 0 degree to 20 degree on a 5 degree basis.
When adjusting the angle, use the holes on the side of the bracket.
50angle 200angle No angle
a
b
c
d
Holes for angle adjustment
0
0
: A + a
5
0
: B + c
10
0
: A + b
15
0
: A + c
20
0
: A + d
A
B
267.5
328.3
Base Frame Assembly Fixing Pin - 2 EA
Short Screw - 8 EA
Washer - 12 EA
Long Screw - 12 EA
Plastic Anchor - 12 EA
Fixing Panel Assembly

16
HYUNDAI Vvuon Digital LCD TV
4. Installation Method
1. Unscrew the screws fastened on 4 spots on the stand
of TV.
2. Fasten the Fixing Panel Assembly on the back of panel
as shown on the Figure (Tighten the screws in order
of the number shown in the Figure).
3. Fix the Base Frame Assy on the wall with screws or
nails.
4. Hook the Fixing Panel Assy with the LCD TV
attached on the Base Frame Assy. Use the fixing pin
to ensure that the TV is secured.
1
2
3
4
7
8
5
6
Insert fixing
pin here.

17
- Power Indicator Status -
Parts Names and Functions
Front View
Volume buttons
Use these buttons for your desired sound level.
These buttons also serve as the cursor of
Select/Adjust when in Menu mode.
Channel buttons
Use these buttons to change channels. These
buttons also serve as the cursor of Down and
Up buttons when in Menu mode.
Select button
Use this button to select each item of menu.
Menu button
Use this button to display or exit from menus.
Source button
Use this button to switch among inputs
connected to the TV.
Power button
Use this button to turn on or off the TV.
Remote sensor and power LED.
- Point the remote control toward here.
- It displays standby or operation status.
Remote sensor and power LED.
See page 13 for information on how to mount
speakers.
Indicator
Red
Green
Status
Standby
Power on
* This product image may be a bit different from the actual product.

Rear View
HYUNDAI Vvuon Digital LCD TV
18
Power switch
Use this switch to turn on/off power.
Power (AC) input terminal
Connect the power cord to this
terminal.
DVI Video input terminal
D-SUB input terminal
DVI/D-SUB Audio input terminal
Subwoofer output terminal
When producing bass, connect the
cable to the woofer with *AMP.
Component 2 Video input terminal
Component 2 Audio input terminal
Component 1 Video input terminal
Component 1 Audio input terminal
S-Video input terminal
Video input terminal
S-Video/Video Audio input terminal
RS-232 input terminal
Connect to the RS-232 terminal of a
PC to check its service.
Monitor Video output terminal
Monitor Audio output terminal
Antenna 1 (Analog/DTV) input
terminal
Antenna 2 (DTV) input terminal
Digital Audio output terminal for
coaxial cable
SPDF optical digital audio output
terminal
Speaker terminal
Connect your speaker jacks
* This product image may be a bit different from the actual product.
